MODEL:VTB302HD
Heavy Duty Bracket Type Camera with 0 Lux Excellent Night Vision(Trailer, Bus, Truck, RV, Big Rigs and etc)
1.SPECIFICATION
2.Mounting Installation
﹡Waterproof Rating: Ip68
﹡Image Sensors: 1/3" Sony CCD
﹡Video Output: 1.0 Vpp-75 Ohm
﹡PAL/NTSC Compatible
﹡Wired OSD Control
﹡Reverse / Non-Reverse Image Selectable
Resolution: 600 TV Lines
﹡Min. Illumination: 0 Lux (Infrared lamps on)
﹡Wide viewing angle upto 120 degrees
﹡Day / Night sensor for automatic adjustment
﹡Adjustable Sun Shade
﹡Power supply: DC 12 - 24V
﹡
Camera
Monitor
15 meters long, 4Pin jack cable
Yellow jack, Video
OSD Control
3.Wiring Installation Guide
This system will allow you to activate or deactivate Rearview Distance Scale
Display Lines.It also will allow you to mount the camera in the front or
rear of the installation vehicle.
This system supports the function such as “WHITE BALANCE”,”EXPOSURE”,
”DAY & NIGHT”,”SPECIAL”and etc..You can select different options according
to your requirements so that you can get more clear images.
