6/12/24V BATTERY FLUID TESTER - TUBE TYPE

MODEL NO: AK414

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,

and properly maintained, give you years of trouble free performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE

THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR

PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.

1. INSTRUCTION

To prepare tester for use:

9 Carefully remove instrument from card.

9  Removebulb,rubberbumperandoatfromjar.

 Removefoamstripfromoat.

9  Holdinstrumentwithtippointingdownward.Insertoat,largeendrstintojar.

9  Placerubberbumperintojar,thenslipthebulboverthejar,slightlywettingthejarmakesbulbgooneasier.

9 Instrument is now ready for use.

To test:

Squeeze bulb, then insert the tip of tester into the cell.

 Releasepressureonbulbuntilenoughelectrolyteisdrawnintothejartofreelyoatthehydrometer.Themarkofhydrometerinline

 withthesurfaceoftheliquidistheapparentspecicgravityreadingofthebattery.Makereadingateyelevelforaccuracy.A

temperature error correction must be applied to this reading as follows: to the right side of the thermometer, note the scale reading

 whichcoincidedwiththetopoftheredliquidcolumn.Addtheblackgurestotheapparentspecicgravityandsubtract

 theredgures.

Note: Apropertestcannotbemadeunlesseachbatterycellhassu󰀩cientelectrolytetopermithydrometeroattorisefreely.An

 accuratereadingcannotbeobtainedifwaterhasjustrecentlybeenaddedtocells.

Refer to

instruction

manual

Wear eye

protection

AK414 Issue:1 14/06/22

Original Language Version

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR

01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk

Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior

notice.

Important: No Liability is accepted for incorrect use of this product.

Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.

ENVIRONMENT PROTECTION

Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento

a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely

unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids

according to local regulations.

Wear protective

gloves
