Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
2
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed. These instructions should be saved for future reference:
• Read and familiarise yourself with all operating instructions before using this
Vacuum Cleaner.
• Before plugging your unit into the mains, visually check that the unit is intact
and has not suffered any transit damage.
• Check that the voltage indicated on the data plate corresponds with that of the
local network before connecting the appliance to the mains power supply.
• This appliance can be used by persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
• Keep the appliance and its cord out of reach of children less than 8 years when it
is energised or cooling down.
• Do not immerse the appliance or its cord in water or any other liquids.
• Do not leave the appliance unattended during use.
• Do not leave the appliance unattended whilst connected to the mains supply.
• Do not use this appliance outdoors.
• It is imperative to unplug the power cord after the appliance has been used,
before it is cleaned and whilst being repaired.
• Repairs to electrical appliances should only be performed by a qualified
electrician. Improper repairs may place user at serious risk.
• Do not operate this appliance with a damaged plug or cord, after a malfunction
or after being dropped or damaged in any way.
• Regular, periodic checks should be carried out on the mains cable to
• ensure no damage is evident. Should there be any signs of damage the
appliance should not be used.
• If the power cable is damaged, it should only be replaced by the manufacturer
or a suitable qualified after-sales-service in order to avoid a hazard
• Do not allow the mains cable to hang over sharp edges or come in contact with
hot surfaces.
• Allow the unit to cool before storage.
• Before cleaning, disconnect the appliance from the mains supply and allow to
cool.
• This appliance is intended for household use only and should not be used for
industrial purposes.
• Do not use any accessories or attachments with this appliance other than those
supplied or recommended by supplier.
• Do not use this appliance for anything other than its intended use.
• Do not push objects into any openings as damage to the appliance and/or
electric shock may occur.
• Unplug after each use. Grasp the plug, not the cord.
3
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
• Do not pull or carry the Vacuum Cleaner by the electrical cord, use the handle
provided.
• Ensure fingers and other objects are never placed in any part of the vacuum
cleaner. Clothing or hair may become trapped if the vacuum is used
improperly.
• Keep hair, loose clothing, jewellery, fingers and all parts of the body away
from openings and moving parts.
• Keep all air vents clear and free of dust, lint, hair and anything else that may
reduce airflow.
• Avoid directing the appliance towards naked flames as the air discharged may
extinguish gas fires or pilot lights and may disturb ashes in open fires.
• Do not Vacuum water or any other liquids with this vacuum.
• Do not Vacuum hot ashes or lit cigarettes, etc.
Description of Parts – Vacuum Cleaner
Description of Parts – Accessories
4
1. Dust Compartment Release Catch
2. Foot operated On/Off Switch
3. Rear air outlet & filter
4. Power/speed controller
5. Mains cable & plug
6. Cable retract button (press to retract cable)
7. Wheel(s)
8. Dust Bag Full Indicator
9. Dust compartment
10. Air intake/hose connection
11. Handle
12. Floor Tool
13. Crevice & Upholstery multi tool
14. Flexible hose
15. Hose connector
16. Air control valve
17. Hose tool connector
18. Telescopic Tube
19. Pet Brush
1
2
3
5
6
7
8
16
18
12
13
14
17
15
10
9
11
19
4
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Assembling Your Vacuum Cleaner
CAUTION Ensure that the vacuum cleaner is not connected to the mains supply before using
the attachments.
Attaching the Flexible Hose (14) to the vacuum
Attach the Flexible Hose (14) to the vacuum cleaner by pushing the Hose Connector (15)
into the Air Intake (10) until it clicks home, arrowed below:
NB to remove the hose, press the catches on either side (arrowed below) of the Hose
Connector (15) and pull out of the Air Intake (10):
Attaching the Telescopic Tube (18) and Floor Tool (12)
1. Push the Telescopic Tube (18) onto the Hose tool connector (17) as shown below left:
2. Extend the Telescopic Tube (18) to the desired length by
pushing the catch down and extending.
3. Attach the Floor Tool (12) to the other end as shown above
4. Hose tool connector (17), Telescopic Tube (18) and Floor Tool
(12) shown complete:
1
2
3
Telescopic Tube
Hose Tool Connector
Telescopic Tube
Telescopic Tube
Telescopic Tube
Floor Tool
Left: Removing the flexible
hose from the vacuum
Right: Attaching the flexible
hose to the vacuum
4
5
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Using Your Vacuum Cleaner
1. Pull the Mains Cable and Plug (5) fully out of the vacuum cleaner, do not use the
vacuum without pulling the cable all the way out.
2. Insert the mains plug into the nearest socket.
3. Press the On/off Switch (2) to power up the vacuum.
NB Adjust the lever on the Floor Tool (12) according to the type of floor being cleaned. Push
the lever down for use on hard floors (i.e. non carpeted, laminated, tiled, etc.), pull the
lever up for vacuum cleaning carpets:
Using the Crevice & Upholstery multi tool (13)
Attach the Crevice & Upholstery multi tool (13) onto the Telescopic Tube (18) to
clean carpet edges, upholstered furniture and hard to get at areas:
NB If the Telescopic Tube (18) is not required, the Crevice & Upholstery multi tool (13) or
the Floor tool (12) can attached directly to the Hose tool connector (17) on the end of the
flexible hose, this useful whilst cleaning soft furnishings, stairs, etc. as below:
Left: Adjust the lever on the
Floor Tool for carpeted or
hard floors:
Up for carpets
Down for hard floors
Left: Attached the Crevice &
Upholstery multi tool to
clean carpet edges
Right: Fold the brush down
to clean hard to get at areas
and upholstery.
Left: Attached the Crevice &
Upholstery multi tool to the
Hose. Use the brush to clean
upholstery.
Right: Attached the Floor
tool to the Hose to clean the
stairs.
6
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
1. Once the Dust Bag Full Indicator (8) turns
red as shown left, the dust bag will need
replacing and the filters cleaned.
2. To remove the bag, lift the Dust
Compartment Release Catch (1).
3. lift the dust compartment cover to reveal
the dust bag holder.
4. Lift out the dust bag holder and dust bag
as shown below:
Using the Hose and Pet Brush (19)
For difficult to remove soiling on upholstery such as pet hairs, the
pet brush can be used.
This should be fitted onto the hose as shown above.
The fixed combs and rotating pneumatic brush clean up the
stubborn or matted hairs.
Using the Power/Speed Controller (4)
This control is useful for varying the suction power. Rotate the control anticlockwise to
reduce power whilst cleaning hard floors or similar and rotate clockwise to increase suction
power for carpets, rugs, etc.
NB vacuum power can also be varied using the Air Control Valve (16) on flexible hose.
Emptying and Cleaning Your Vacuum Cleaner
WARNING Always disconnect the cleaner from the mains power supply before cleaning.
WARNING do not continue to use your
vacuum cleaner once the Dust Bag Full
Indicator (8) turns red as permanent
damage may occur to the appliance.
1
7
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
5. Push the bag retaining clip forwards as
shown right (a.).
Slide the card front of the bag out of the
dust bag holder (b.) and dispose of the used
dust bag. Slide the card front of the new
dust bag into the dust bag holder ensuring
the retaining clip locks the card into place.
6
6. Whilst replacing the dust bag, slide out
the dust compartment filter as shown a. &
b. right. Wash the filter in warm running
water until clean. Allow the filter to dry
thoroughly for 24 hours before replacing
and reuse:
2
3
4
5
b.
a.
a.
b.
8
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
7
Care and Use of your Vacuum Cleaner
WARNING Always disconnect the cleaner from the mains power supply before cleaning.
• Clean outside of the cleaner with a clean damp cloth. Never clean with harsh or abrasive
cleaners.
• Do not submerge the cleaner in water or any other liquids.
• Empty the dust bag as soon as the dust bag full indicator (8) turns red.*
• Wash the dust compartment and rear air outlet filters regularly – see table below.
• Allow all the filters to thoroughly dry out for 24 hours before reassembly and use.
*WARNING do not continue to use your vacuum cleaner once the dust bag full indicator (8)
turns red as permanent damage may occur to the appliance.
Recommended cleaning times
Filter Type
Recommended cleaning period
WARNING Ensure the filters are cleaned periodically according to the table above, failure to
clean the filters regularly will severely impair the performance and permanent damage may
occur to the appliance.
7. Finally, push the latch down on the rear air outlet & filter (3)
cover as shown in a, b, & c below. Remove the filter and wash
clean in warm running water ensuring it is thoroughly dry for
24 hours before replacing and reuse:
• Shake
out
debris
once
a
month
•
Rinse
under
war
m
water
once
every
3-6
months
• Allow to dry thoroughly for 24 hours before reuse.
Dust Compartment Filter
Rear Outlet Filter
a.
b.
c.
• Shake
out
debris
once
a
month
•
Rinse
under
war
m
water
once
every
3-6
months
• Allow to dry thoroughly for 24 hours before reuse.
9
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Fitting a new plug
The mains lead must be connected as shown below. The wires are coloured with the
following code - Brown wire = Live (L), Blue wire = Neutral (N).
NB no connection must be made to the Earth (E) terminal.
• The Blue wire must be connected to the terminal marked N or coloured Black.
• The Brown wire must be connected to the terminal marked L or coloured Red.
• Check that there are no cut or stray strands of wire inside the plug.
• Use a 13 Amp BS 1362 fuse, only use BSI or ASTA approved fuses.
• If you are in any way unsure which plug or fuse to use, always refer to a qualified
electrician.
• After replacing or changing a fuse on a moulded plug, the cover must be refitted to the
plug; the appliance must not be used without a fuse cover.
Technical Specification
Model Number
FLR00047
Supply Voltage
AC 220-240V ~ 50/60Hz
Rated Power
700W
Protection Class
II
Unpacked Weight (approx.)
3.9 Kgs
Unpacked Weight with Accessories
4.8 Kgs
Dimensions (approx.)
246mm (h) x 286mm (w) x 430mm (d)
Vacuum
≥16kpa
Dust Compartment Capacity
3.0L
Connect
Brown to
Live (L)
Connect
Blue to
Neutral (N)
Ensure the outer sheath of the mains lead
is securely held by the cable clamp
10
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Solution
Unit fails to turn on.
The unit may not be
properly plugged in.
The fuse may have
tripped.
Ensure the plug is fully
inserted into the socket and
the socket is switched on.
Check the fuse on the mains
board, if it has tripped, reset
it.
Low suction or poor pick-up.
Dust Bag is full.
Filters are clogged.
Blockage in the hose.
Replace Dust Bag. Check and
clean the filters.
Check the hose and clear if
necessary.
The vacuum is making a “hissing”
sound.
The airflow is
restricted
Replace Dust Bag. Check and
clean the filters.
Check the hose and clear any
blockages if necessary.
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
11
Tornado Pet 700W Bagged Vacuum
FLR00047
User Manual
IMPORTANT – RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo Vacuum.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo vacuum product is guaranteed for 1 year from the date of original purchase,
with proof of purchase or receipt. If any defect should occur due to faulty workmanship or
material, your faulty vacuum should be returned to the place of purchase, replacement or refund is
at the discretion of the retailer.
The guarantee is subject to the following provisions:
•
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
•
The product must be used solely for domestic purposes.
•
It does not cover general wear and tear, damage, misuse or any consumable parts.
•
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
•
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
www.daewoowarrantyregistration.com/warranty-registration
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo® is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
