Vacuum Cleaner
User's manual
EN
EN-1
SVC 45BK / SVC 45BL / SVC 45GR /
SVC 45RD / SVC 45WH
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
Before fi rst use, please read all instructions contained in this user's manual carefully, even if you are
already familiar with using similar products. Only use this product in accordance with the instructions
described in the user's manual. Keep the user's manual in a safe place where it can be easily retrieved
for future use.
Save the original packaging, including the internal packing material, warranty card and proof of
purchase receipt, at least for the duration of the warranty. If you need to ship this product, pack it
in the original cardboard box to ensure maximum protection during shipping or transport (e.g. when
moving or when you need to send this product for repair).
EN-2
EN
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
CONTENTS
IMPORTANT SAFETY NOTICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
DESCRIPTION OF THE VACUUM CLEANER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
VACUUM CLEANER ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
INSTRUCTIONS FOR USE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
VACUUM CLEANER STORAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
CLEANING AND MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
TECHNICAL DETAILS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
PRODUCT INFORMATION SHEET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
INCLUDED CONTENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS . . . 12
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
EN
EN-3
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
IMPORTANT SAFETY NOTICE
1) Carefully unpack the product and take care not to throw away any part of the packaging before
you fi nd all the parts of the product.
2) This product must not be used by persons (including children) with physical or mental impairments
or by inexperienced persons, unless properly trained or schooled in the safe use of the product, or
unless they have been properly supervised by a qualifi ed person who will be responsible for their
safety.
3) Never use accessories that have not been delivered with this product or are not intended for it.
4) Under no circumstances should you try to repair or repair the product on your own - danger of
electric shock! Entrust all repairs and adjustments to a specialised company/service. Tampering with
the product during the warranty period may void the warranty.
5) Only store and use the product away from fl ammable or volatile materials and solutions.
6) Do not expose the product to extreme heat, direct sunlight and excessive humidity.
7) Do not place the product near heaters, open fi res or other appliances or equipment that are sources
of heat.
8) This product is designed for household use. Do not use it in industrial surroundings or outdoors!
9) Do not use the product for purposes other than those intended.
10) Before connecting the product to the power outlet ensure that the voltage on the label is the same
as that in the power outlet.
11) Do not place the power cord near hot places or sharp objects. Do not place heavy objects on the
power cord. Position the cord so that it will not be stepped on or tripped over. Make sure the power
cord is not touching a hot surface.
12) If the power cord of the product is damaged have it repaired by an authorised service technician to
prevent causing a dangerous situation. It is forbidden to use a product with a damaged power cord
or plug.
13} Do not disconnect the power cord from the wall outlet by pulling the cord.
14) Do not spray the product with water or any other liquid. Do not pour water or any other liquids
into the product. Do not submerge the product in water or any other liquid.
15) Never use the product near a bathtub, wash basin or any other container fi lled with water.
16) If you are not using the product, or if you know that you will not be using it soon, turn it off and
disconnect the power cord from the wall socket. Prior to cleaning, proceed in the same manner.
17) Never leave the product switched on without supervision.
18) Use extra care if the product is used near children. Always keep the product out of the reach of
children. Children must be supervised to ensure that they do not play with the product.
19) If the product is being used, do not block the air input and output openings. Blocked air vents can
cause overheating and motor damage.
20) Vacuuming the below mentioned objects can damage your product or cause injuries to the
operating person:
• wet fl oor, water or other liquids
• any type of sharp objects such as broken glass or ceramics, needles, pins, etc.
• burning cigarettes, or smouldering pieces, matches or any other fl ammable or volatile
liquids (e.g. gasoline, paint thinners, etc.)
• fl our, cement, plaster (i.e. dust from holes drilled in walls).
21) In order to avoid damaging furniture or injuries to persons, hold the cord in your hands as it winds
up.
22) Pulling the power cord from the wall power outlet by force may cause damage.
23) Do not vacuum larger pieces of paper or plastic bags. They may easily clog the pipe or hose. If the
product becomes blocked, turn it off by disconnecting the power cord from the socket and clean
the pipe or hose.
24) In order to avoid damage to the hose, do not step on it or forcefully bend it. Do not use the vacuum
if the hose is bent or damaged in any other way.
25) Do not move over the power cord with the vacuum cleaner.
26) Never use the vacuum cleaner without the protective motor fi lter, the output fi lter or the dust bag.
EN-4
EN
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
27) Do not place the vacuuming hose, inlet nozzle or vacuuming accessories near to your eyes or ears.
28) Vacuuming of some types of fl oors or fl oor surfaces can create a static electricity charge, which is
not dangerous for the user.
29) The manufacturer takes no responsibility for damages caused by the incorrect use of this product
and its accessories (injuries, burns, scalding, fi re, food spoilage, etc.).
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
EN
EN-5
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
DESCRIPTION
A
1 Cord winding button
2 Full bag indicator
3 Air suction opening
4 START/STOP button
5 Vacuum cleaner handle
6 Vacuum cleaner wheel
7 Handle
8 Sliding knob for air suction
9 Tube
q; Floor inlet nozzle
qa Flap position for vacuuming
carpets
qs Flap position for vacuuming
hard (smooth) fl oors
qd Hose
qf Stopper for the parking
position
qg Clip
qh Hose end
1
2
3
4
5
6
qd
qf
qg
qh
7
8
9
q;
qa
qs
EN-6
EN
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
B
1
2
3
4
5
6
1 Parking position
2 Cover grill of the outfl ow fi lter
3 Power cord
4 Combination nozzle
5 Carry handle
6 Front wheel mechanism
ASSEMBLY
Insert the hose into the air suction opening
Press both the safety buttons on the end of the hose end and insert the hose end into the air suction
opening on the vacuum cleaner until you hear a “click”. The hose is now secured in correct position.
Attach the holder to the tube
Place the handle on the wider part of the assembled tube.
Attach the fl oor inlet nozzle to the tube:
Make sure the fl oor nozzle is attached the narrower part of the assembled tube.
INSTRUCTIONS FOR USE
Connecting your vacuum cleaner to the electrical power grid
Pull the plug attached to the power cord out from the vacuum cleaner until the desired length of the
cord is out of the product. Insert the plug into the wall outlet.
Note:
Yellow marking on the supply cable warns that the cable is close to its end. Do not pull the
cable more than to the red marking.
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
EN
EN-7
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
Adjusting the fl oor inlet nozzle according to the fl oor surface.
You may set the inlet nozzle according to the fl oor surface by adjusting the inlet fl ap:
• If you want to vacuum carpets, close the bristles of the inlet inside the inlet nozzle, by turning the
fl ap accordingly.
• If you want to vacuum hard and smooth surfaces, move the bristles out of the nozzle, by turning
the fl ap accordingly.
Turning your vacuum cleaner on and off
To switch your machine on or off, press the START / STOP button on the vacuum cleaner body.
Adjusting the suction strength
Suction can be controlled by a sliding fl ap on the hose handle.
Tip:
If the hose holder becomes blocked when vacuuming, disconnect it from the tube and also
disconnect the hose from the vacuum cleaner body. Then place the holder inside the suction hole
on the vacuum cleaner body and vacuum the stuck dirt out.
Temporary interruption of the vacuuming process
If you wish to interrupt vacuuming for a short time, using the lug place the fl oor nozzle into the parking
position in its rear part.
Note:
Do not move the vacuum cleaner from place to place if the hose is in the parked position! You
may brake off the parking position holder!
Using your accessories
A space for the combination nozzle is located in the bottom part of the vacuum cleaner.
The combination nozzle may be used to vacuum in hard-to-reach spaces such as window frames,
libraries, upholstery corners, joints, etc.). By turning the brushes out you get a brush nozzle suitable for
vacuuming e.g. dust from smaller types of surfaces, grills, keyboards, etc.
C
Ending the vacuuming process
When you fi nish vacuuming, switch the vacuum cleaner off by pressing the START / STOP button and
then disconnect the power cord plug from the socket.
To wind the power cord back to the vacuum cleaner, press and hold the winding button with one hand.
Hold the cable with your other hand to protect the vacuum cleaner input area from damage.
EN-8
EN
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
Tip:
If the winding process stops and part of the power cord is still outside, release the winding
button and pull the cable out again by about 50 cm and press the winding button again and
repeat the winding process.
Carrying your vacuum cleaner
If you need to carry the vacuum cleaner, you can hold it by the handle or the holder.
STORAGE OF VACUUM CLEANER
Before storage you can disassemble your product into the individual parts or you can store it assembled
and lock the fl oor nozzle in the parking position.
CLEANING AND MAINTENANCE
Note:
Always remove the power cord from the power socket before cleaning.
Changing the dust bag
If while the suction hose is lifted above the vacuumed area and the power is set to maximum and the
full dust bag indicator seen through the clear window shows „full“ (full colour in the indicator) then it
is necessary to replace the dust bag:
1) Open the vacuum cleaner cover.
2) Remove the old dust bag from the plastic holder.
3) Insert a new one in the same position.
4) Close the vacuum cleaner cover.
D
1 Vacuum cleaner cover clip
2 Vacuum cleaner cover
3 Plastic dust bag holder
4 Dust bag
5 Outfl ow fi lter holder
6 Dust bag
7 Outfl ow fi lter
1
2
3
4
5
6
7
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
EN
EN-9
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
Note:
Never attempt to wash paper bags as they are single use only and once full are to be disposed
of together with household waste. It is only possible to wash textile bags!
Changing the infl ow fi lter
1) Open the vacuum cleaner cover and remove the infl ow fi lter from its holder.
2) Replace the infl ow fi lter with a new one and put it back into the vacuum cleaner.
Changing the outfl ow fi lter
1) Press the safety clip to open the grill of the outfl ow fi lter.
2) Remove the fi lter from the grill and replace with a new one.
3) Together with the grill put the new fi lter back into the vacuum cleaner.
E
1 Clip
2 Cover grill of the
outfl ow fi lter
3 Outfl ow fi lter
1
2
3
To clean the outside parts of the product use a fi ne cloth dipped in lukewarm water. Do not use
aggressive cleaning agents, paint thinners or solvents. Using these solutions could damage the surface
of the product.
EN-10
EN
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
TROUBLESHOOTING
Before you decide to contact an authorized service centre, please read the following tips in the
troubleshooting chart:
Problem Possible cause Recommended action
The motor will not
start.
– The power cord is not connected
correctly to the wall power outlet.
– The wall power socket is damaged.
– The vacuum cleaner is not switched
on.
– Insert the plug fi rmly into the
power socket.
– Inspect the power socket.
– Turn on the vacuum cleaner.
The suction output is
weak.
– The dust bag is completely full.
– The vacuum cleaner is clogged.
– The fi lter is clogged.
– Change the dust bag
– Remove the blockage or foreign
object
– Clean the fi lter.
The power cord is not
wound in completely.
The power cord may have slipped
down from the winding pulley during
winding.
Hold the cable under tension while
winding the cable.
The cable cannot be
pulled out.
The cable is wound up incorrectly. Press the winding button of the
self winding cable and try to
rewind the power cord again.
The output control
does not function.
The vacuum cleaner is out of order. Have the vacuum cleaner repaired
(only by a qualifi ed technician)
The power cord starts
to wind in when it is
not required.
The winding mechanism is damaged. Have the vacuum cleaner repaired
(only by a qualifi ed technician).
The vacuum cleaner
cover cannot be closed.
The dust bag is not inserted, or is
inserted incorrectly.
Check the position of the dust bag
in the plastic holder, or insert a
new bag.
TECHNICAL SPECIFICATIONS
Nominal voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220–240 V AC (alternate current)
Nominal frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50/60 Hz
Nominal power input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1200 W
Safety class (with regard to electric shock protection) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . II
Noise level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82 dB(A)
Length of the power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 m
Operating range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7.5 m
Dimensions (length x width x height) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 345 x 255 x 210 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3.6 kg
The declared noise emission level for this appliance is 82 dB(A), which represents level A of the acoustic
power relative to the reference acoustic power of 1 pW.
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
EN
EN-11
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
PRODUCT INFORMATION SHEET
Name/trademark SENCOR
Model identifi cation number SVC 45BK, 45WH, 45RD, 45BL, 45GR
Energy effi ciency class * D
Annual power consumption (in kWh) ** 44.2
Carpet cleaning effi ciency class F
Hard fl oor cleaning effi ciency class B
Vacuum cleaner dust emission class E
Level of acoustic power (dB(A)) 82
Rated power input (W) 1200
* Class A (highest effi ciency class, low power consumption) to Class G (lowest effi ciency class, high
power consumption)
** Approximate annual power consumption (in kWh per year) based on 50 cleaning cycles. Actual
power consumption will depend on how the appliance is used.
The values are determined pursuant to (EU) No. 665/2013.
SUPPLIED CONTENTS
1x vacuum cleaner
1x fl oor inlet nozzle
2x plastic tube
1x hose
1x combination nozzle
1x infl ow fi lter
1x paper dust bag
1x outfl ow fi lter
1x user's manual
1x warranty card
Amendments to text and technical parameters are reserved.
EN-12
EN
Vacuum Cleaner
SVC 45BK / SVC 45BL / SVC 45GR / SVC 45RD / SVC 45WH
Copyright © 2014, Fast ČR, a.s. Revision 11/2014
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of packaging material at a public waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES
The meaning of the symbol on the product, its accessory or packaging indicates that this product
shall not be treated as household waste. Please, dispose of this product at your applicable
collection point for the recycling of electrical & electronic equipment waste. Alternatively in
some states of the European Union or other European states you may return your products to
your local retailer when buying an equivalent new product. The correct disposal of this product
will help save valuable natural resources and help in preventing the potential negative impact on
the environment and human health, which could be caused as a result of improper liquidation of
waste. Please ask your local authorities or the nearest waste collection centre for further details.
The improper disposal of this type of waste may fall subject to national regulations for fi nes.
For business entities in the European Union
If you wish to dispose of an electrical or electronic device, request the necessary information
from your seller or supplier.
Disposal in other countries outside the European Union
If you wish to dispose of this product, request the necessary information about the correct
disposal method from local government departments or from your seller.
This product meets all the basic EU regulation requirements that relate to it.
Changes to the text, design and technical specifi cations may occur without prior notice and we reserve the
right to make these changes.
