Vacuum Cleaner
User's manual
EN
EN-1
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
Before first use, please read all instructions contained in this user's manual carefully, even if you are
already familiar with using similar products. Only use this appliance in accordance with the instructions
described in the user's manual. Keep this user's manual in a safe place where it can be easily retrieved
for future use.
We recommend saving the original cardboard box, packaging material, purchase receipt and
responsibility statement of the vendor or warranty card for at least the duration of the legal liability
for unsatisfactory performance or quality. If you need to ship this appliance, pack it in the original
cardboard box to ensure maximum protection during shipping or transport (e.g. when moving or when
you need to send this appliance for repair).
EN-2
EN
Vacuum Cleaner
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
TABLE OF CONTENTS
IMPORTANT SAFETY NOTICE .........................................................................................................................3
DESCRIPTION OF THE VACUUM CLEANER ....................................................................................................6
ASSEMBLY .......................................................................................................................................................7
USING THE VACUUM CLEANER .....................................................................................................................8
USING THE ACCESSORIES ...............................................................................................................................9
CLEANING AND MAINTENANCE ....................................................................................................................9
TROUBLESHOOTING .....................................................................................................................................11
STORING THE VACUUM CLEANER ...............................................................................................................11
TECHNICAL SPECIFICATIONS ........................................................................................................................12
PRODUCT INFORMATION SHEET .................................................................................................................13
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS ....14
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT ..............................................................14
Vacuum Cleaner
SVC 682VT / SVC 684TQ
EN
EN-3
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
IMPORTANT SAFETY NOTICE
1) Carefully unpack the appliance and take care not to throw
away any part of the packaging before you find all the parts
of the appliance.
2) This appliance may be used by children 8 years of age and
older and by persons with physical or mental impairments
or by inexperienced persons, if they are properly supervised
or have been informed about how to use the appliance in
a safe manner and understand the potential dangers. Do not
allow children to play with the appliance. Cleaning and user
maintenance must not be performed by unsupervised children.
Keep this appliance and its accessories out of reach of children
that are younger than 8 years of age.
3) Before connecting the appliance to a power socket, make sure
the voltage stated on its rating label corresponds to the voltage
in your power socket.
4) Never use accessories, which have not been supplied with this
appliance or which are not designed for this appliance.
5) Do not place the power cord near hot places or sharp objects.
Do not place heavy objects on the power cord. Position the
power cord so that it will not be stepped on or tripped over.
Make sure the power cord is not touching a hot surface.
6) If the power cord of the appliance is damaged, have it
repaired by an authorised service technician to prevent causing
a dangerous situation. It is forbidden to use the appliance if it
has a damaged power cord or plug.
7) Do not disconnect the power cord from the power socket by
pulling the cord.
8) In no case should you attempt to repair the appliance yourself,
do not make any amendments to it - danger of electrical shock!
Entrust all repairs and adjustments to a specialised company/
service. Failure to do so will expose you to a danger of voiding
the warranty policy.
9) Never use the appliance if you have wet hands or feet.
EN-4
EN
Vacuum Cleaner
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
10) Only store and use the appliance away from flammable or
volatile materials and solutions.
11) The appliance is designed for use in households, offices and
similar types of areas. Do not use it in industrial surroundings
or outdoors!
12) Do not use the appliance for purposes other than those
intended.
13) Do not spray the appliance with water or any other liquid. Do
not pour water or any other liquids into the appliance. Do not
submerge the appliance in water or in any other liquid.
14) Make sure the appliance does not come in contact with water.
Never use the appliance near a bathtub, wash basin or any
other containers filled with water.
15) After finishing using the appliance, turn it off and disconnect
the power cord from the power socket. Prior to cleaning,
proceed in the same manner.
16) Never leave the appliance switched on without supervision.
17) In order to avoid deformation of the plastic components of the
vacuum cleaner or to prevent it from catching on fire, do not
expose the vacuum to direct sunlight, do not place it close to
heaters, open fires or other sources of heat.
18) If the appliance is being used, do not block the air inflow and
outflow vents. Blocked air vents can cause overheating and
motor damage.
19) Vacuuming the below mentioned objects can damage your
appliance or cause injuries to the operating person:
• wet floors, water or other liquids;
• any type of sharp objects such as broken glass or ceramics,
needles, pins, etc.;
• burning cigarettes, or smouldering compounds, matches
or any other flammable or volatile liquids (e.g. gasoline,
paint thinners, etc.);
• flour, cement, plaster (i.e. dust from holes drilled in walls).
20) In order to avoid damaging furniture or injuries to persons,
hold the power cord in your hands as it winds up.
Vacuum Cleaner
SVC 682VT / SVC 684TQ
EN
EN-5
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
21) Do not vacuum larger pieces of paper or plastic bags. They may
easily clog the pipe or hose. In the event that the appliance
becomes clogged for any reason, immediately turn it off by
disconnecting it from the power socket. Then clean out the
clogged pipe or hose.
22) In order to avoid damage to the hose, do not step on it or
forcefully bend it. Do not use the vacuum if the hose is bent
or damaged in any other way.
23) Do not ride over the power cord with the vacuum cleaner.
24) Never use the vacuum cleaner without having inserted the
dust bag, the inflow micro-filter or the outflow H.E.P.A. filter
or micro-filter.
25) Do not place the vacuuming hose, inlet nozzle or vacuuming
accessories near to your eyes or ears.
26) Vacuuming of some types of floors or floor surfaces can create
a static electricity charge, which is not dangerous for the user.
27) The manufacturer takes no responsibility for damages caused by
the incorrect use of this appliance and its accessories (injuries,
burns, scalding, fire, food spoilage, etc.).
EN-6
EN
Vacuum Cleaner
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
DESCRIPTION OF THE VACUUM CLEANER
A
1
3
2
4
5
7
8
6
qj
qh
qk
ql
w;
9
0
qa
qs
qd
qf
qg
1 Cord winding button
2 Full dust bag indicator
3 Vacuum hose connection hole
4 Clip for locking and releasing the lid
5 Cover of the outflow H.E.P.A. filter
6 Motor power control dial
7 START/STOP button
8 Rubber-coated wheel
9 Handle
0 Sliding flap for air suction
qa Telescopic tube
qs Clip for the telescopic tube
qd Floor nozzle
qf Flap position for vacuuming carpets
qg Flap position for vacuuming hard (smooth)
floors
qh Hose
qj Accessory holder
qk Stopper for the horizontal and vertical
parking position
ql Clip
w; Hose end
Vacuum Cleaner
SVC 682VT / SVC 684TQ
EN
EN-7
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
B
2
1
1 Horizontal parking position 2 Power cord
C
1
2
3
1 Carry handle
2 Front travel wheel with swivel mechanism
3 Vertical parking position
ASSEMBLY
Inserting the hose into the air suction hole on the vacuum cleaner.
Press both the safety buttons on the end of the hose end and insert the hose end into the air suction
opening on the vacuum cleaner until you hear a "click". The hose is now secured in the correct position.
Attach the holder to the telescopic tube:
Make sure to place the holder with the hose on the wider part of the telescopic tube.
Attach the floor nozzle to the telescopic tube:
Make sure the floor nozzle is attached the narrower part of the telescopic tube.
Adjust the length of the telescopic tube:
Adjust the length of the telescopic tube as required – disengage and hold the clip on the tube in the
direction shown by the arrow and adjust the length of the tube as required. Then release the clip and slide
out the tube slightly forward until you hear a "click". The telescopic tube is now securely fixed in position.
EN-8
EN
Vacuum Cleaner
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
USING THE VACUUM CLEANER
Connecting your vacuum cleaner to the power grid
Wind out the required length of the power cord by pulling on the power plug. Insert the power plug
into a power socket.
Caution:
Yellow marking on the power cord warns that the power cord is close to its end. Do not pull the
cord further than the red marking.
Adjusting the floor inlet nozzle according to the floor surface.
You may set the inlet nozzle according to the floor surface by adjusting the inlet flap:
• If you want to vacuum carpets, close the bristles of the inlet inside the inlet nozzle, by turning the
flap accordingly.
• If you want to vacuum hard and smooth surfaces, extend the bristles out of the nozzle, by turning
the flap accordingly.
Turning your vacuum cleaner on and off
To switch your vacuum cleaner on, press the START/STOP button. To turn off the vacuum cleaner, press
the button again.
Adjusting the suction power
Suction power can be controlled using the electronic power control dial. Turn the power control dial
clockwise to the MAX position to increase the power of the vacuum cleaner, turn it in the opposite
direction to the MIN position to reduce its power. In a smaller range, you may regulate suction power
using the mechanically sliding flap on the hose handle.
Tips
• Use the maximum suction strength when vacuuming carpets or floors with a hard surface.
Use the reduced strength when vacuuming upholstery, window curtains, etc.
• If the hose holder becomes blocked when vacuuming, disconnect it from the telescopic tube
and also disconnect the hose from the vacuum cleaner body. Then place the holder inside
the suction hole on the vacuum cleaner body and vacuum out the stuck dirt.
Temporary interruption of the vacuuming process
If you wish to interrupt vacuuming for a while, you can use the horizontal or vertical parking position
on the vacuum cleaner, into which you insert the stopper on the floor nozzle.
Attention:
Do not move the vacuum cleaner from place to place if the hose is in the parked position! The
stopper on the floor nozzle could brake off.
Ending the vacuuming process
When you finish vacuuming, switch the vacuum cleaner off by pressing the START/STOP button and then
disconnect the power cord plug from the socket.
To wind the power cord back into the vacuum cleaner, press and hold the winding button with one hand
and guide the power cord with the other.
Tip:
If the winding process stops and part of the power cord is still outside, release the winding
button and pull the cable out again by about 50 cm and then press and hold the winding button
again and repeat the winding process.
Vacuum Cleaner
SVC 682VT / SVC 684TQ
EN
EN-9
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
Carrying the vacuum cleaner
It is possible to hold and carry the vacuum by the handle.
USING THE ACCESSORIES
D
2
1
2
3
1
2
3
1
1 Telescopic slot nozzle for vacuuming in hard to reach places
(e.g. windows, corners, book shelves, areas between mattresses, upholstery, etc.)
2 Upholstery nozzle with an additional brush
Tip:
If you need to have your accessories on hand when vacuuming, you may attach them to the
special holder on the telescopic tube.
CLEANING AND MAINTENANCE
Caution:
Before cleaning, disconnect this appliance from the power source.
Changing the dust bag
When the full dust bag indicator lights up, it is necessary to replace the dust bag. If you do not remove
the dust bag, the suction power will be reduced.
E
1
3
4
2
1 Clip for locking and releasing the lid
2 Dust bag collar
3 Dust bag
4 Dust bag holder
1) Open the vacuum cleaner filter area by pressing the lid clip while pulling it upwards at the same time.
EN-10
EN
Vacuum Cleaner
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
2) By pulling on the collar of the dust bag in the direction of the arrow, remove it from the plastic
holder and insert a new bag.
3) Close the lid of the vacuum cleaner, until you hear a click.
Replacing and cleaning the inflow micro-filter and outflow H.E.P.A. filter and micro-filter
F
1
2
3
4
5
6
1 Clip for locking and releasing the lid
2 Inflow micro-filter
3 Grill of the inflow micro-filter
4 Outflow micro-filter
5 Outflow H.E.P.A. filter
6 Grill of the outflow micro-filter and H.E.P.A.
filter
1) Open the vacuum cleaner filter area by pressing the lid clip while pulling it upwards at the same time.
2) By pulling on the collar of the dust bag in the direction of the arrow, remove it from the plastic
holder to make room for the removal of the filter.
3) Pull the inflow micro-filter grill towards yourself and take out the micro-filter.
4) Simultaneously press both PUSH buttons at the rear of the vacuum cleaner. This will tilt out the rear
grill of the outflow micro-filter and H.E.P.A. filter. Put the grill aside and take out both filters.
5) If the micro-filters are slightly soiled, it is possible to wash them under running lukewarm water. If
the H.E.P.A. filter is slightly soiled, it is possible to quickly wash it under a weak current of running
lukewarm water. This will remove dust and dirt found on its surface. In the event of heavy soiling,
replace the filters with new ones.
6) Allow washed filters to dry naturally. Do not dry them over heaters or using hair dryers. Then put
the inflow micro-filter, outflow H.E.P.A filter, micro-filter and the grills back in their place.
7) Return the dust bag.
8) Close the lid of the vacuum cleaner, until you hear a click.
Attention:
Never insert the filters back into the vacuum cleaner if they are wet or damp! Always wait until
they are thoroughly dry.
Cleaning your vacuum cleaner.
To clean the outside parts of the appliance, use a fine cloth dipped in lukewarm water. Do not use
aggressive cleaning agents, paint thinners or solvents. Using these solutions could damage the surface
of the appliance.
Vacuum Cleaner
SVC 682VT / SVC 684TQ
EN
EN-11
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
TROUBLESHOOTING
Before you decide to contact an authorised service centre, please read these following tips in the
troubleshooting chart:
Problem Possible cause Possible solution
The motor will not start The power cord is not inserted
correctly in the power socket.
The power socket is damaged.
The vacuum cleaner is not
switched on.
Insert the plug firmly into the
power socket.
Inspect the power socket.
Turn on the appliance.
Suction power is weak The appliance cleaner is clogged.
The dust bag is full.
Remove the items that have
clogged the appliance.
Replace it with a new one.
The power cord is not wound
in completely.
The power cord may have
slipped down from the winding
pulley during winding.
Hold the cable under tension
while winding the cable.
The cable cannot be pulled
out.
The cable is wound up
incorrectly.
Press the winding button of the
self winding cable and try to
rewind the power cord again.
The power control does not
function.
The appliance is out of order. Have the appliance repaired
(only by a qualified technician).
The power cord starts to wind
in when it is not required.
The winding mechanism is
damaged.
Have the appliance repaired
(only by a qualified technician).
STORING THE VACUUM CLEANER
You may store the vacuum cleaner disassembled into its individual parts or you can store it assembled
in one of the parking positions.
EN-12
EN
Vacuum Cleaner
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
TECHNICAL SPECIFICATIONS
Rated voltage range ...................................................................................................................... 220−240 V
Rated frequency .................................................................................................................................... 50 Hz
Rated power input ............................................................................................................................... 850 W
Electrical shock protection class ...................................................................................................................II
Noise level ......................................................................................................................................... 75 dB(A)
Length of the power cord ....................................................................................................................... 7 m
Operating range ..................................................................................................................................... 10 m
Dust bag capacity ......................................................................................................................................2.5 l
Dimensions (length x width x height) .......................................................................... 425 × 225 × 315 mm
Weight .................................................................................................................................................. 4.9 kg
The declared noise emission level of the appliance is 75 dB(A), which represents a level A of acoustic
power with respect to a reference acoustic power of 1 pW.
Changes to text and technical parameters are reserved.
Vacuum Cleaner
SVC 682VT / SVC 684TQ
EN
EN-13
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
PRODUCT INFORMATION SHEET
Name/trademark SENCOR
Model identification number SVC 862VT / SVC 864TQ
Energy efficiency class* B
Annual power consumption (in kWh)** 32.3 kWh
Carpet cleaning efficiency class D
Hard floor cleaning efficiency class B
Vacuum cleaner dust emission class B
Level of acoustic power (dB(A)) 75 dB(A)
Rated power input (W) 850 W
* Class A (highest efficiency class, low power consumption) to Class G (lowest efficiency class, high
power consumption)
** Approximate annual power consumption (in kWh per year) based on 50 cleaning cycles. Actual
power consumption will depend on how the appliance is used.
The values are determined pursuant to (EU) No. 665/2013.
EN-14
EN
Vacuum Cleaner
SVC 682VT / SVC 684TQ
Copyright © 2016, Fast ČR, a.s. Revision 01/2016
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electric or electronic
products must not be added to ordinary municipal waste. For proper disposal,
renewal and recycling hand over these appliances to determined collection points.
Alternatively, in some European Union states or other European countries you may
return your appliances to the local retailer when buying an equivalent new appliance.
Correct disposal of this product helps save valuable natural resources and prevents
potential negative effects on the environment and human health, which could result
from improper waste disposal. Ask your local authorities or collection facility for more
details. In accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product,
request the necessary information about the correct disposal method from the local
council or from your retailer.
This appliance meets all the basic requirements of EU directives related to it.
