LEVER ACTION PUMP
MODEL NO: TP6803
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure health & safety, local authority, and general workshop practice regulations are strictly adhered to when using
this equipment.
9 Familiariseyourselfwithproductapplicationandlimitations,aswellasthespecicpotentialhazardspeculiartothisproduct.
9 Maintainthepumpingoodcondition(useanauthorisedserviceagent).
9 Replaceorrepairdamagedparts.Use genuine parts only. Non authorised parts will invalidate the warranty.
9 UseonlytopumpNON-Corrosiveuidssuchasoil,anti-freeze,degreasants,solvents,agriculturalandindustrialchemicals,andthelike.
 Ensuresafetyeyeprotectionandprotectiveclothingarewornwhenusingthisproduct.
9 Keeptheworkareaclean,unclutteredandensurethereisadequatelighting.
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslippery.
9 Keepchildrenandunauthorisedpersonsawayfromtheworkingarea.
9 Disposeofwasteliquidsinaccordancewithlocalauthorityregulations.
8 DO NOTusetoextractcorrosiveuids.
8 DO NOT dismantle, tamper with or adapt the pump for any purpose other than for which
itisdesigned.
8 DO NOT usetheunitifithasbeendroppedormishandled,checktheunittoensure
thereisnodamage.
8 DO NOTusethepumpasahandletomovetheuiddrum.
9 Keepthepumpcleanandstoreinasafedry,childprooflocation.
WARNING! DO NOTallowuncontrolleddischargeofuidsthuspollutingtheenvironment.
2. INTRODUCTION
Polypropyleneleverpumpwithsteelrodanddip-tube,suitableforusewithoils,antifreezeand
othernon-corrosivefluids.Featurespolyoxymethylenehandletopreventaggressivefluidsmelting
thehandle.Fittedwith360°outletnozzle.Suitablefor205Ldrums.Deliversapproximately300ml
perstroke.
3. CONTENTS
Unpackandidentifythepartsshowning.1.
1. Handle
2. PumpBody
3. Lowertube(withseal)
4. SlidingTube
5. UpperTube
6. Spout
7. Pivotbolts&nutsx2
4. ASSEMBLY
4.1. AssembletheSpout(6)tothePumpBody(2).
4.2. Attachthehandle(1)totheplungerandpivotonthepumpbodyusingthepivotBolts(7)
asshowning.2.Choosetheouterpivotholeonthehandle(1)forthelongeststroke.
4.3. Assembletheextendiblediptubeasshowning.3.Firstlyinsertthelowertubewithseal
(3)intothebottomoftheslidingtube(4).Seeg.3A.Pushonthelowertubesothatit
emergesfromthetopoftheslidingtubeasshowning.3B.Screwthetopofthelower
tube(3)intothebottomoftheuppertube(5).
4.4. Screwthetopoftheuppertube(5)intothebottomofthepumpbody.Seeg.3C.
4.5. Adjustlengthofdiptubeandinsertintocontainer.Screwbaseofpumpintocontainer
opening.Theunitisnowreadyforpumping.
Refer to
instruction
manual
Wear eye
protection
Wear
protective
clothing
Original Language Version
©JackSealeyLimited
fig.
1
fig.
2
TP6803Issue:2(H,F)10/06/20
background
Original Language Version
©JackSealeyLimited
4.6.
4.7.
.
fig.
3
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycleunwantedmaterialsinsteadofdisposingofthemaswaste.Alltools,accessoriesandpackagingshouldbesorted,takento
arecyclingcentreanddisposedofinamannerwhichiscompatiblewiththeenvironment.Whentheproductbecomescompletely
unserviceableandrequiresdisposal,drainanyfluids(ifapplicable)intoapprovedcontainersanddisposeoftheproductandfluids
accordingtolocalregulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.
Important:NoLiabilityisacceptedforincorrectuseofthisproduct.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
TP6803Issue:2(H,F)10/06/20
