Network Camera
User Manual
Legal Informaon
About this Document
●
This Document includes instrucons for using and managing the Product. Pictures, charts,
images and all other informaon hereinaer are for descripon and explanaon only.
●
The informaon contained in the Document is subject to change, without noce, due to
rmware updates or other reasons. Please nd the latest version of the Document at the
Hikvision website ( hps://www.hikvision.com ). Unless otherwise agreed, Hangzhou Hikvision
Digital Technology Co., Ltd. or its aliates (hereinaer referred to as "Hikvision") makes no
warranes, express or implied.
●
Please use the Document with the guidance and assistance of professionals trained in
supporng the Product.
About this Product
●
This product can only enjoy the aer-sales service support in the country or region where the
purchase is made.
●
If the product you choose is a video product, please scan the following QR code to obtain the
"Iniaves on the Use of Video Products", and read it carefully.
Acknowledgment of Intellectual Property Rights
●
Hikvision owns the copyrights and/or patents related to the technology embodied in the
Products described in this Document, which may include licenses obtained from third pares.
●
Any part of the Document, including text, pictures, graphics, etc., belongs to Hikvision. No part
of this Document may be excerpted, copied, translated, or modied in whole or in part by any
means without wrien permission.
●
and other Hikvision’s trademarks and logos are the properes of Hikvision in
various jurisdicons.
●
Other trademarks and logos menoned are the properes of their respecve owners.
LEGAL DISCLAIMER
●
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS DOCUMENT AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED "AS
IS" AND "WITH ALL FAULTS AND ERRORS". HIKVISION MAKES NO WARRANTIES, EXPRESS OR
Network Camera User Manual
i
IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR
FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK.
IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL,
INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF
BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING
NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
Network Camera User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
Network Camera User Manual
iii
Contents
Chapter 1 System Requirement .................................................................................................. 1
Chapter 2 Device Acvaon and Accessing ................................................................................. 2
2.1 Acvate the Device via SADP ................................................................................................. 2
2.2 Acvate the Device via Browser ............................................................................................. 2
2.3 Login ...................................................................................................................................... 3
2.3.1 Plug-in Installaon ........................................................................................................ 3
2.3.2 Admin Password Recovery ............................................................................................ 4
2.3.3 Illegal Login Lock ........................................................................................................... 5
Chapter 3 Live View .................................................................................................................... 6
3.1 Live View Parameters ............................................................................................................. 6
3.1.1 Enable and Disable Live View ........................................................................................ 6
3.1.2 Adjust Aspect Rao ....................................................................................................... 6
3.1.3 Live View Stream Type .................................................................................................. 6
3.1.4 Select the Third-Party Plug-in ....................................................................................... 6
3.1.5 Window Division ........................................................................................................... 7
3.1.6 Light .............................................................................................................................. 7
3.1.7 Count Pixel .................................................................................................................... 7
3.1.8 Start Digital Zoom ......................................................................................................... 7
3.1.9 Auxiliary Focus .............................................................................................................. 7
3.1.10 Lens Inializaon ........................................................................................................ 8
3.1.11 Quick Set Live View ..................................................................................................... 8
3.1.12 Lens Parameters Adjustment ...................................................................................... 8
3.1.13 Conduct 3D Posioning ............................................................................................... 9
3.2 Set Transmission Parameters ................................................................................................. 9
3.3 Set Smooth Streaming ......................................................................................................... 10
Chapter 4 Video and Audio ....................................................................................................... 12
Network Camera User Manual
v
4.1 Video Sengs ...................................................................................................................... 12
4.1.1 Stream Type ................................................................................................................ 12
4.1.2 Video Type .................................................................................................................. 13
4.1.3 Resoluon ................................................................................................................... 13
4.1.4 Bitrate Type and Max. Bitrate ..................................................................................... 13
4.1.5 Video Quality .............................................................................................................. 13
4.1.6 Frame Rate .................................................................................................................. 14
4.1.7 Video Encoding ........................................................................................................... 14
4.1.8 Smoothing ................................................................................................................... 16
4.2 ROI ....................................................................................................................................... 16
4.2.1 Set ROI ........................................................................................................................ 16
4.3 Display Info. on Stream ........................................................................................................ 17
4.4 Audio Sengs ...................................................................................................................... 17
4.4.1 Audio Encoding ........................................................................................................... 17
4.4.2 Audio Input ................................................................................................................. 17
4.4.3 Audio Output .............................................................................................................. 18
4.4.4 Environmental Noise Filter .......................................................................................... 18
4.5 Two-way Audio .................................................................................................................... 18
4.6 Display Sengs .................................................................................................................... 19
4.6.1 Scene Mode ................................................................................................................ 19
4.6.2 Image Parameters Switch ............................................................................................ 22
4.6.3 Video Standard ........................................................................................................... 23
4.6.4 Local Video Output ..................................................................................................... 23
4.7 OSD ...................................................................................................................................... 23
4.8 Set Privacy Mask .................................................................................................................. 24
4.9 Overlay Picture ..................................................................................................................... 24
4.10 Set Target Cropping ............................................................................................................ 24
Chapter 5 Video Recording and Picture Capture ........................................................................ 26
Network Camera User Manual
vi
5.1 Storage Sengs ................................................................................................................... 26
5.1.1 Set New or Unencrypted Memory Card ...................................................................... 26
5.1.2 Set FTP ........................................................................................................................ 28
5.1.3 Set NAS ....................................................................................................................... 29
5.1.4 eMMC Protecon ........................................................................................................ 29
5.1.5 Set Cloud Storage ........................................................................................................ 30
5.2 Video Recording ................................................................................................................... 30
5.2.1 Record Automacally .................................................................................................. 30
5.2.2 Record Manually ......................................................................................................... 32
5.2.3 Set Lite Storage ........................................................................................................... 32
5.2.4 Playback and Download Video .................................................................................... 32
5.3 Capture Conguraon .......................................................................................................... 33
5.3.1 Capture Automacally ................................................................................................ 33
5.3.2 Capture Manually ........................................................................................................ 34
5.3.3 Set Timing Wake ......................................................................................................... 34
5.3.4 View and Download Picture ........................................................................................ 34
Chapter 6 Event and Alarm ....................................................................................................... 36
6.1 Basic Event ........................................................................................................................... 36
6.1.1 Set Moon Detecon .................................................................................................. 36
6.1.2 Set Video Tampering Alarm ........................................................................................ 38
6.1.3 Set PIR Alarm .............................................................................................................. 39
6.1.4 Set Excepon Alarm .................................................................................................... 40
6.1.5 Set Alarm Input ........................................................................................................... 40
6.1.6 Set Video Quality Diagnosis ........................................................................................ 41
6.1.7 Set Vibraon Detecon ............................................................................................... 41
6.2 Smart Event .......................................................................................................................... 42
6.2.1 Detect Audio Excepon ............................................................................................... 42
6.2.2 Set Defocus Detecon ................................................................................................. 43
Network Camera User Manual
vii
6.2.3 Detect Scene Change .................................................................................................. 43
6.2.4 Set Face Detecon ...................................................................................................... 43
6.2.5 Set Video Loss ............................................................................................................. 44
6.2.6 Set Intrusion Detecon ............................................................................................... 44
6.2.7 Set Line Crossing Detecon ......................................................................................... 45
6.2.8 Set Region Entrance Detecon ................................................................................... 46
6.2.9 Set Region Exing Detecon ....................................................................................... 48
6.2.10 Set Unaended Baggage Detecon .......................................................................... 49
6.2.11 Set Object Removal Detecon .................................................................................. 50
6.2.12 Draw Area ................................................................................................................. 50
6.2.13 Set Size Filter ............................................................................................................. 51
Chapter 7 Network Sengs ...................................................................................................... 52
7.1 TCP/IP ................................................................................................................................... 52
7.1.1 Mulcast ..................................................................................................................... 53
7.1.2 Mulcast Discovery ..................................................................................................... 54
7.2 SNMP ................................................................................................................................... 54
7.3 Set SRTP ............................................................................................................................... 54
7.4 Port Mapping ....................................................................................................................... 55
7.4.1 Set Auto Port Mapping ................................................................................................ 55
7.4.2 Set Manual Port Mapping ........................................................................................... 55
7.4.3 Set Port Mapping on Router ....................................................................................... 56
7.5 Port ...................................................................................................................................... 57
7.6 Access to Device via Domain Name ..................................................................................... 58
7.7 Access to Device via PPPoE Dial Up Connecon .................................................................. 58
7.8 Wireless Dial ........................................................................................................................ 59
7.8.1 Set Wireless Dial ......................................................................................................... 59
7.8.2 Set Allowlist ................................................................................................................ 60
7.9 Wi-Fi ..................................................................................................................................... 60
Network Camera User Manual
viii
7.9.1 Connect Device to Wi-Fi .............................................................................................. 60
7.10 Set Network Service ........................................................................................................... 61
7.11 Set Open Network Video Interface .................................................................................... 62
7.12 Set ISUP .............................................................................................................................. 62
7.13 Set Alarm Server ................................................................................................................ 63
7.14 Access Camera via Hik-Connect ......................................................................................... 63
7.14.1 Enable Hik-Connect Service on Camera .................................................................... 64
7.14.2 Set Up Hik-Connect ................................................................................................... 65
7.14.3 Add Camera to Hik-Connect ...................................................................................... 66
Chapter 8 Arming Schedule and Alarm Linkage ......................................................................... 67
8.1 Set Arming Schedule ............................................................................................................ 67
8.2 Linkage Method Sengs ...................................................................................................... 67
8.2.1 Trigger Alarm Output .................................................................................................. 67
8.2.2 FTP/NAS/Memory Card Uploading ............................................................................. 68
8.2.3 Send Email .................................................................................................................. 69
8.2.4 Nofy Surveillance Center .......................................................................................... 70
8.2.5 Trigger Recording ........................................................................................................ 70
8.2.6 Flashing Light .............................................................................................................. 70
8.2.7 Audible Warning ......................................................................................................... 70
Chapter 9 System and Security ................................................................................................. 72
9.1 View Device Informaon ...................................................................................................... 72
9.2 Search and Manage Log ....................................................................................................... 72
9.3 Simultaneous Login .............................................................................................................. 72
9.4 Import and Export Conguraon File .................................................................................. 72
9.5 Export Diagnose Informaon ............................................................................................... 73
9.6 Reboot ................................................................................................................................. 73
9.7 Restore and Default ............................................................................................................. 73
9.8 Upgrade ............................................................................................................................... 73
Network Camera User Manual
ix
9.9 View Open Source Soware License .................................................................................... 74
9.10 Wiegand ............................................................................................................................. 74
9.11 Metadata ........................................................................................................................... 74
9.12 Time and Date .................................................................................................................... 74
9.12.1 Synchronize Time Manually ...................................................................................... 74
9.12.2 Set NTP Server .......................................................................................................... 75
9.12.3 Synchronize Time by Satellite ................................................................................... 75
9.12.4 Set DST ...................................................................................................................... 75
9.13 Set RS-485 .......................................................................................................................... 76
9.14 Set RS-232 .......................................................................................................................... 76
9.15 Power Consumpon Mode ................................................................................................ 76
9.16 External Device .................................................................................................................. 77
9.16.1 Supplement Light Sengs ........................................................................................ 77
9.16.2 Heater ....................................................................................................................... 78
9.17 Security .............................................................................................................................. 78
9.17.1 Authencaon .......................................................................................................... 78
9.17.2 Set IP Address Filter .................................................................................................. 79
9.17.3 Set HTTPS .................................................................................................................. 79
9.17.4 Set QoS ...................................................................................................................... 80
9.17.5 Set IEEE 802.1X ......................................................................................................... 80
9.17.6 Control Timeout Sengs .......................................................................................... 81
9.17.7 Search Security Audit Logs ........................................................................................ 81
9.17.8 Security Reinforcement ............................................................................................. 81
9.17.9 SSH ............................................................................................................................ 82
9.18 Cercate Management .................................................................................................... 82
9.18.1 Create Self-signed Cercate .................................................................................... 82
9.18.2 Create Cercate Request ........................................................................................ 82
9.18.3 Import Cercate ...................................................................................................... 83
Network Camera User Manual
x
9.18.4 Install Server/Client Cercate ................................................................................. 83
9.18.5 Install CA Cercate .................................................................................................. 83
9.18.6 Enable Cercate Expiraon Alarm .......................................................................... 84
9.19 User and Account ............................................................................................................... 84
9.19.1 Set User Account and Permission ............................................................................. 84
9.19.2 Simultaneous Login ................................................................................................... 85
9.19.3 Online Users .............................................................................................................. 85
Chapter 10 Allocate VCA Resource ............................................................................................ 86
10.1 Counng ............................................................................................................................. 86
10.1.1 Set Counng .............................................................................................................. 86
10.1.2 View Counng Stascs ............................................................................................ 87
10.2 Face Capture ...................................................................................................................... 87
10.2.1 Set Face Capture ....................................................................................................... 88
10.2.2 Overlay and Capture ................................................................................................. 88
10.2.3 Face Capture Algorithms Parameters ........................................................................ 89
10.2.4 Set Shield Region ...................................................................................................... 91
10.3 Mul-Target-Type Detecon .............................................................................................. 91
10.3.1 Set Mul-Target-Type Detecon Rule ....................................................................... 91
10.3.2 Overlay and Capture ................................................................................................. 92
10.3.3 Mul-Target-Type Detecon Algorithm Parameters ................................................. 92
10.3.4 Set Shield Region ...................................................................................................... 94
10.4 Queue Management .......................................................................................................... 94
10.4.1 Set Regional People Queuing-Up .............................................................................. 94
10.4.2 Set Waing Time Detecon ...................................................................................... 95
10.4.3 Queue Management Stascs .................................................................................. 96
10.5 Face Counng .................................................................................................................... 97
10.5.1 Set Face Counng Detecon Rule ............................................................................. 97
10.5.2 Overlay and Capture ................................................................................................. 98
Network Camera User Manual
xi
10.5.3 Face Counng Algorithm Parameters ....................................................................... 99
10.5.4 View Face Counng Result ...................................................................................... 100
10.6 Face Picture Comparison and Modeling .......................................................................... 100
10.6.1 Face Picture Comparison ........................................................................................ 100
10.6.2 Face Modeling ......................................................................................................... 103
10.7 Hard Hat Detecon .......................................................................................................... 104
10.7.1 Set Hard Hat Detecon ........................................................................................... 104
10.8 Road Trac ...................................................................................................................... 104
10.8.1 Set Vehicle Detecon .............................................................................................. 105
10.8.2 Set Mixed-Trac Detecon Rule ............................................................................. 106
10.8.3 Uploading Pictures Sengs .................................................................................... 106
10.8.4 Camera Sengs ...................................................................................................... 107
10.8.5 Import or Export Blocklist & Allowlist ..................................................................... 107
Chapter 11 Open Plaorm ...................................................................................................... 108
11.1 Set Open Plaorm ............................................................................................................ 108
Chapter 12 Smart Display ....................................................................................................... 110
Chapter 13 EPTZ ..................................................................................................................... 111
13.1 Patrol ................................................................................................................................ 111
13.2 Auto-Tracking ................................................................................................................... 111
Network Camera User Manual
xii
Chapter 1 System Requirement
Your computer should meet the requirements for proper vising and operang the product.
Operang System Microso Windows XP SP1 and above version
CPU 2.0 GHz or higher
RAM 1G or higher
Display 1024×768 resoluon or higher
Web Browser For the details, see Plug-in Installaon
Network Camera User Manual
1
Chapter 2 Device Acvaon and Accessing
To protect the security and privacy of the user account and data, you should set a login password
to acvate the device when access the device via network.
Note
Refer to the user manual of the soware client for the detailed informaon about the client
soware acvaon.
2.1 Acvate the Device via SADP
Search and acvate the online devices via SADP soware.
Before You Start
Access www.hikvision.com to get SADP soware to install.
Steps
1.
Connect the device to network using the network cable.
2.
Run SADP soware to search the online devices.
3.
Check Device Status from the device list, and select Inacve device.
4.
Create and input the new password in the password eld, and conrm the password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including upper case leers, lower case leers, numbers, and special characters) in
order to increase the security of your product. And we recommend you reset your password
regularly, especially in the high security system, reseng the password monthly or weekly can
beer protect your product.
5.
Click OK.
Device Status changes into Acve.
6.
Oponal: Change the network parameters of the device in Modify Network Parameters.
2.2 Acvate the Device via Browser
You can access and acvate the device via the browser.
Steps
1.
Connect the device to the PC using the network cables.
2.
Change the IP address of the PC and device to the same segment.
Network Camera User Manual
2
Note
The default IP address of the device is 192.168.1.64. You can set the IP address of the PC from
192.168.1.2 to 192.168.1.253 (except 192.168.1.64). For example, you can set the IP address of
the PC to 192.168.1.100.
3.
Input 192.168.1.64 in the browser.
4.
Set device acvaon password.
Cauon
We highly recommend you create a strong password of your own choosing (using a minimum of
8 characters, including at least three of the following categories: upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
5.
Click OK.
6.
Input the acvaon password to log in to the device.
7.
Oponal: Go to Conguraon → Network → Basic → TCP/IP to change the IP address of the
device to the same segment of your network.
2.3 Login
Log in to the device via Web browser.
2.3.1 Plug-in Installaon
Certain operaon systems and web browser may restrict the display and operaon of the camera
funcon. You should install plug-in or complete certain sengs to ensure normal display and
operaon. For detailed restricted funcon, refer to the actual device.
Operang System Web Browser Operaon
Windows
●
Internet Explorer 8+
●
Google Chrome 57 and
earlier version
●
Mozilla Firefox 52 and earlier
version
Follow pop-up prompts to
complete plug-in installaon.
●
Google Chrome 57+
●
Mozilla Firefox 52+
Click
to
download and install plug-in.
Mac OS
●
Google Chrome 57+
●
Mozilla Firefox 52+
●
Mac Safari 16+
Plug-in installaon is not
required.
Network Camera User Manual
3
Operang System Web Browser Operaon
Go to Conguraon →
Network → Advanced Sengs
→ Network Service to enable
WebSocket or Websockets for
normal view. Display and
operaon of certain funcons
are restricted. For example,
Playback and Picture are not
available. For detailed
restricted funcon, refer to the
actual device.
Note
The camera only supports Windows and Mac OS system and do not support Linux system.
2.3.2 Admin Password Recovery
If you forget the admin password, you can reset the password by clicking Forget Password on the
login page aer compleng the account security sengs.
You can reset the password by seng the security queson or email.
Note
When you need to reset the password, make sure that the device and the PC are on the same
network segment.
Security Queson
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, select the security queson and input your
answer.
You can click Forget Password and answer the security queson to reset the admin password when
access the device via browser.
Email
You can set the account security during the acvaon. Or you can go to Conguraon → System →
User Management , click Account Security Sengs, input your email address to receive the
vericaon code during the recovering operaon process.
Network Camera User Manual
4
2.3.3 Illegal Login Lock
It helps to improve the security when accessing the device via Internet.
Go to Conguraon → System → Security → Security Service , and enable Enable Illegal Login
Lock. Illegal Login Aempts and Locking Duraon are congurable.
Illegal Login Aempts
When your login aempts with the wrong password reach the set mes, the device is locked.
Locking Duraon
The device releases the lock aer the seng duraon.
Network Camera User Manual
5
Chapter 3 Live View
It introduces the live view parameters, funcon icons and transmission parameters sengs.
3.1 Live View Parameters
The supported funcons vary depending on the model.
3.1.1 Enable and Disable Live View
This funcon is used to quickly enable or disable live view of the channel.
●
Click to start the live view.
●
Click to stop the live view.
3.1.2 Adjust Aspect Rao
Steps
1.
Click Live View.
2.
Click to select the aspect rao.
●
refers to 4:3 window size.
●
refers to 16:9 window size.
●
refers to original window size.
●
refers to self-adapve window size.
●
refers to original rao window size.
3.1.3 Live View Stream Type
Select the live view stream type according to your needs. For the detailed informaon about the
stream type selecon, refer to Stream Type .
3.1.4 Select the Third-Party Plug-in
When the live view cannot display via certain browsers, you can change the plug-in for live view
according to the browser.
Steps
1.
Click Live View.
2.
Click to select the plug-in.
Network Camera User Manual
6
-
When you access the device via Internet Explorer, you can select Webcomponents or
QuickTime.
-
When you access the device via the other browsers, you can select Webcomponents,
QuickTime, VLC or MJPEG.
3.1.5 Window Division
●
refers to 1 × 1 window division.
●
refers to 2 × 2 window division.
●
refers to 3 × 3 window division.
●
refers to 4 × 4 window division.
3.1.6 Light
Click to turn on or turn o the illuminator.
3.1.7 Count Pixel
It helps to get the height and width pixel of the selected region in the live view image.
Steps
1.
Click to enable the funcon.
2.
Drag the mouse on the image to select a desired rectangle area.
The width pixel and height pixel are displayed on the boom of the live view image.
3.1.8 Start Digital Zoom
It helps to see a detailed informaon of any region in the image.
Steps
1.
Click
to enable the digital zoom.
2.
In live view image, drag the mouse to select the desired region.
3.
Click in the live view image to back to the original image.
3.1.9 Auxiliary Focus
It is used for motorized device. It can improve the image if the device cannot focus clearly.
For the device that supports ABF, adjust the lens angle, then focus and click ABF buon on the
device. The device can focus clearly.
Click to focus automacally.
Network Camera User Manual
7
Note
●
If the device cannot focus with auxiliary focus, you can use Lens Inializaon , then use auxiliary
focus again to make the image clear.
●
If auxiliary focus cannot help the device focus clearly, you can use manual focus.
3.1.10 Lens Inializaon
Lens inializaon is used on the device equipped with motorized lens. The funcon can reset lens
when long me zoom or focus results in blurred image. This funcon varies according to dierent
models.
Manual Lens Inializaon
Click to operate lens inializaon.
Auto Lens Inializaon
Go to Conguraon → System → Maintenance → Lens Correcon to enable this funcon. You
can set the arming schedule, and the device will correct lens automacally during the
congured me periods.
3.1.11 Quick Set Live View
It oers a quick setup of PTZ, display sengs, OSD, video/audio and VCA resource sengs on live
view page.
Steps
1.
Click to show quick setup page.
2.
Set PTZ, display sengs, OSD, video/audio and VCA resource parameters.
-
For PTZ sengs, see
Lens Parameters Adjustment .
-
For display sengs, see
Display Sengs .
-
For OSD sengs, see
OSD .
-
For audio and video sengs, see
Video and Audio .
-
For VCA sengs, see
Allocate VCA Resource .
Note
The funcon is only supported by certain models.
3.1.12 Lens Parameters Adjustment
It is used to adjust the lens focus, zoom and iris.
Network Camera User Manual
8
Zoom
●
Click , and the lens zooms in.
●
Click , and the lens zooms out.
Focus
●
Click , then the lens focuses far and the distant object gets clear.
●
Click , then the lens focuses near and the nearby object gets clear.
PTZ Speed
●
Slide to adjust the speed of the pan/lt movement.
Iris
●
When the image is too dark, click to enlarge the iris.
●
When the image is too bright, click to stop down the iris.
PTZ Lock
PTZ lock means to disable the zoom, focus and PTZ rotaon funcons of the corresponding
channel, so that to reduce the target missing caused by PTZ adjustment.
Go to Conguraon → PTZ , checkEnable PTZ Lock, and click Save.
3.1.13 Conduct 3D Posioning
3D posioning is to relocate the selected area to the image center.
Steps
1.
Click
to enable the funcon.
2.
Select a target area in live image.
-
Le click on a point on live image: the point is relocated to the center of the live image. With
no zooming in or out eect.
-
Hold and drag the mouse to a lower right posion to frame an area on the live: the framed
area is zoomed in and relocated to the center of the live image.
-
Hold and drag the mouse to an upper le posion to frame an area on the live: the framed
area is zoomed out and relocated to the center of the live image.
3.
Click the buon again to turn o the funcon.
3.2 Set Transmission Parameters
The live view image may be displayed abnormally according to the network condions. In dierent
network environments, you can adjust the transmission parameters to solve the problem.
Network Camera User Manual
9
Steps
1.
Go to Conguraon → Local .
2.
Set the transmission parameters as required.
Protocol
TCP
TCP ensures complete delivery of streaming data and beer video quality, yet the real-me
transmission will be aected. It is suitable for the stable network environment.
UDP
UDP is suitable for the unstable network environment that does not demand high video
uency.
MULTICAST
MULTICAST is suitable for the situaon that there are mulple clients. You should set the
mulcast address for them before selecon.
Note
For detailed informaon about mulcast, refer to Mulcast .
HTTP
HTTP is suitable for the situaon that the third-party needs to get the stream from the
device.
Play Performance
Shortest Delay
The device takes the real-me video image as the priority over the video uency.
Balanced
The device ensures both the real-me video image and the uency.
Fluent
The device takes the video uency as the priority over teal-me. In poor network
environment, the device cannot ensures video uency even the uency is enabled.
Custom
You can set the frame rate manually. In poor network environment, you can reduce the
frame rate to get a uent live view. But the rule informaon may cannot display.
3.
Click OK.
3.3 Set Smooth Streaming
It is a funcon to tackle the latency and network congeson caused by unstable network condion,
and keep the live view stream on the web browser or the client soware smooth.
Network Camera User Manual
10
Before You Start
Add the device to your client soware and select NPQ protocol in client soware before
conguring the smooth streaming funcon.
Be sure that the Bitrate Type is selected as Constant and the SVC is selected as OFF before
enabling the funcon. Go to Conguraon → Video/Audio → Video to set the parameters.
Steps
1.
Go to the sengs page: Conguraon → Network → Advanced Sengs → Smooth Streaming .
2.
Check Enable Smooth Streaming.
3.
Select the mode for smooth streaming.
Auto The resoluon and bitrate are adjusted automacally and resoluon takes the
priority. The upper limits of these two parameters will not exceed the values
you set on Video page. Go to Conguraon → Video/Audio → Video , set the
Resoluon and Max. Bitrate before you enable smooth streaming funcon. In
this mode, the frame rate will be adjusted to the maximum value
automacally.
Resoluon
Priority
The resoluon stays the same as the set value on Video page, and the bitrate
will be adjusted automacally. Go to Conguraon → Video/Audio → Video ,
set the Max. Bitrate before you enable smooth streaming funcon. In this
mode, the framerate will be adjusted to the maximum value automacally.
Frame Rate
Priority
The image is sll smooth even under the poor network, while the image
quality may be not good.
Error
Correcon
The resoluon and bitrate stay the same as the set values on Video page. The
mode is used to correct the data error during transmission to ensure the
image quality. You can set the Error Correcon Proporon within range of
0-100.
When the proporon is 0, the data error will be corrected by data
retransmission. When the proporon is higher than 0, the error data will be
corrected via redundant data that is added to the stream and data
retransmission. The higher the value is, the more redundant date will be
generated, the more data error would be corrected, but the larger bandwidth
would be required. When the proporon is 100, the redundant data will be as
large as the original data, and the bandwidth is twice required.
Note
Be sure the bandwidth is sucient in the Error Correcon mode.
4.
Save the sengs.
Network Camera User Manual
11
Chapter 4 Video and Audio
This part introduces the conguraon of video and audio related parameters.
4.1 Video Sengs
This part introduces the sengs of video parameters, such as, stream type, video encoding, and
resoluon.
Go to seng page: Conguraon → Video/Audio → Video .
4.1.1 Stream Type
For device supports more than one stream, you can specify parameters for each stream type.
Main Stream
The stream stands for the best stream performance the device supports. It usually oers the
best resoluon and frame rate the device can do. But high resoluon and frame rate usually
means larger storage space and higher bandwidth requirements in transmission.
Sub Stream
The stream usually oers comparavely low resoluon opons, which consumes less bandwidth
and storage space.
Other Streams
Steams other than the main stream and sub stream may also be oered for customized usage.
Set Custom Video
You can set up addional video streams if required. For custom video streams, you can preview
them, but cannot record or play back them.
Steps
Note
●
The funcon is only supported by certain camera models.
●
Aer restoring the device (not restore to default sengs), quanty of custom video streams and
their names are kept, but the related parameters are restored.
1.
Click to add a stream.
2.
Change the stream name as needed.
Network Camera User Manual
12
Note
Up to 32 leers and symbols (except &, <, >, ', or ") are allowed for the stream name.
3.
Customize the stream parameters (resoluon, frame rate, max. bitrate, video encoding).
4.
Oponal: Add stream descripon as needed.
5.
Oponal: If a custom stream is not needed, click to delete it.
6.
Click Save.
4.1.2 Video Type
Select the content (video and audio) that should be contained in the stream.
Video
Only video content is contained in the stream.
Video & Audio
Video content and audio content are contained in the composite stream.
4.1.3 Resoluon
Select video resoluon according to actual needs. Higher resoluon requires higher bandwidth and
storage.
4.1.4 Bitrate Type and Max. Bitrate
Constant Bitrate
It means that the stream is compressed and transmied at a comparavely xed bitrate. The
compression speed is fast, but mosaic may occur on the image.
Variable Bitrate
It means that the device automacally adjust the bitrate under the set Max. Bitrate. The
compression speed is slower than that of the constant bitrate. But it guarantees the image
quality of complex scenes.
4.1.5 Video Quality
When Bitrate Type is set as Variable, video quality is congurable. Select a video quality according
to actual needs. Note that higher video quality requires higher bandwidth.
Network Camera User Manual
13
4.1.6 Frame Rate
The frame rate is to describe the frequency at which the video stream is updated and it is
measured by frames per second (fps).
A higher frame rate is advantageous when there is movement in the video stream, as it maintains
image quality throughout. Note that higher frame rate requires higher bandwidth and larger
storage space.
4.1.7 Video Encoding
It stands for the compression standard the device adopts for video encoding.
Note
Available compression standards vary according to device models.
H.264
H.264, also known as MPEG-4 Part 10, Advanced Video Coding, is a compression standard. Without
compressing image quality, it increases compression rao and reduces the size of video le than
MJPEG or MPEG-4 Part 2.
H.264+
H.264+ is an improved compression coding technology based on H.264. By enabling H.264+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.264, H.264+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.264+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.264+ is enabled, Video Quality, I Frame Interval, Prole, SVC, Main Stream Smoothing
and ROI are not supported.
H.265
H.265, also known as High Eciency Video Coding (HEVC) and MPEG-H Part 2, is a compression
standard. In comparison to H.264, it oers beer video compression at the same resoluon, frame
rate and image quality.
Network Camera User Manual
14
H.265+
H.265+ is an improved compression coding technology based on H.265. By enabling H.265+, you
can esmate the HDD consumpon by its maximum average bitrate. Compared to H.265, H.265+
reduces storage by up to 50% with the same maximum bitrate in most scenes.
When H.265+ is enabled, Max. Average Bitrate is congurable. The device gives a recommended
max. average bitrate by default. You can adjust the parameter to a higher value if the video quality
is less sasfactory. Max. average bitrate should not be higher than max. bitrate.
Note
When H.265+ is enabled, Video Quality, I Frame Interval, Prole and SVC are not congurable.
I-Frame Interval
I-frame interval denes the number of frames between 2 I-frames.
In H.264 and H.265, an I-frame, or intra frame, is a self-contained frame that can be independently
decoded without any reference to other images. An I-frame consumes more bits than other
frames. Thus, video with more I-frames, in other words, smaller I-frame interval, generates more
steady and reliable data bits while requiring more storage space.
SVC
Scalable Video Coding (SVC) is the name for the Annex G extension of the H.264 or H.265 video
compression standard.
The objecve of the SVC standardizaon has been to enable the encoding of a high-quality video
bitstream that contains one or more subset bitstreams that can themselves be decoded with a
complexity and reconstrucon quality similar to that achieved using the exisng H.264 or H.265
design with the same quanty of data as in the subset bitstream. The subset bitstream is derived
by dropping packets from the larger bitstream.
SVC enables forward compability for older hardware: the same bitstream can be consumed by
basic hardware which can only decode a low-resoluon subset, while more advanced hardware
will be able decode high quality video stream.
MPEG4
MPEG4, referring to MPEG-4 Part 2, is a video compression format developed by Moving Picture
Experts Group (MPEG).
Network Camera User Manual
15
MJPEG
Moon JPEG (M-JPEG or MJPEG) is a video compression format in which intraframe coding
technology is used. Images in a MJPEG format is compressed as individual JPEG images.
Prole
This funcon means that under the same bitrate, the more complex the prole is, the higher the
quality of the image is, and the requirement for network bandwidth is also higher.
4.1.8 Smoothing
It refers to the smoothness of the stream. The higher value of the smoothing is, the beer uency
of the stream will be, though, the video quality may not be so sasfactory. The lower value of the
smoothing is, the higher quality of the stream will be, though it may appear not uent.
4.2 ROI
ROI (Region of Interest) encoding helps to discriminate the ROI and background informaon in
video compression. The technology assigns more encoding resource to the region of interest, thus
to increase the quality of the ROI whereas the background informaon is less focused.
4.2.1 Set ROI
ROI (Region of Interest) encoding helps to assign more encoding resource to the region of interest,
thus to increase the quality of the ROI whereas the background informaon is less focused.
Before You Start
Please check the video coding type. ROI is supported when the video coding type is H.264 or H.
265.
Steps
1.
Go to Conguraon → Video/Audio → ROI .
2.
Check Enable.
3.
Select Stream Type.
4.
Select Region No. in Fixed Region to draw ROI region.
1) Click Draw Area.
2) Click and drag the mouse on the view screen to draw the xed region.
3) Click Stop Drawing.
Network Camera User Manual
16
Note
Select the xed region that needs to be adjusted and drag the mouse to adjust its posion.
5.
Input the Region Name and ROI Level.
6.
Click Save.
Note
The higher the ROI level is, the clearer the image of the detected region is.
7.
Oponal: Select other region No. and repeat the above steps if you need to draw mulple xed
regions.
4.3 Display Info. on Stream
The informaon of the objects (e.g. human, vehicle, etc.) is marked in the video stream. You can
set rules on the connected rear-end device or client soware to detect the events including line
crossing, intrusion, etc.
Steps
1.
Go to the seng page: Conguraon → Video/Audio → Display Info. on Stream .
2.
Check Enable Dual-VCA.
3.
Click Save.
4.4 Audio Sengs
It is a funcon to set audio parameters such as audio encoding, environment noise ltering.
Go to the audio sengs page: Conguraon → Video/Audio → Audio .
4.4.1 Audio Encoding
Select the audio encoding compression of the audio.
4.4.2 Audio Input
Note
●
Connect the audio input device as required.
●
The audio input display varies with the device models.
Network Camera User Manual
17
LineIn Set Audio Input to LineIn when the device connects to the audio
input device with the high output power, such as MP3,
synthesizer or acve pickup.
MicIn Set Audio Input to MicIn when the device connects to the audio
input device with the low output power, such as microphone or
passive pickup.
4.4.3 Audio Output
Note
Connect the audio output device as required.
It is a switch of the device audio output. When it is disabled, all the device audio cannot output.
The audio output display varies with the device modes.
4.4.4 Environmental Noise Filter
Set it as OFF or ON. When the funcon is enabled, the noise in the environment can be ltered to
some extent.
4.5 Two-way Audio
It is used to realize the two-way audio funcon between the monitoring center and the target in
the monitoring screen.
Before You Start
●
Make sure the audio input device (pick-up or microphone) and audio output device (speaker)
connected to the device is working properly. Refer to specicaons of audio input and output
devices for device connecon.
●
If the device has built-in microphone and speaker, two-way audio funcon can be enabled
directly.
Steps
1.
Click Live View.
2.
Click
on the toolbar to enable two-way audio funcon of the camera.
3.
Click , disable the two-way audio funcon.
Network Camera User Manual
18
4.6 Display Sengs
It oers the parameter sengs to adjust image features.
Go to Conguraon → Image → Display Sengs .
Click Default to restore sengs.
4.6.1 Scene Mode
There are several sets of image parameters predened for dierent installaon environments.
Select a scene according to the actual installaon environment to speed up the display sengs.
Image Adjustment
By adjusng the Brightness, Saturaon, Hue, Contrast and Sharpness, the image can be best
displayed.
Exposure Sengs
Exposure is controlled by the combinaon of iris, shuer, and photo sensibility. You can adjust
image eect by seng exposure parameters.
In manual mode, you need to set Exposure Time, Gain and Slow Shuer.
Focus
It oers opons to adjust the focus mode.
Focus Mode
Auto
The device focuses automacally as the scene changes. If you cannot get a well-focused
image under auto mode, reduce light sources in the image and avoid ashing lights.
Semi-auto
The device focuses once aer the PTZ and lens zooming. If the image is clear, the focus does
not change when the scene changes.
Manual
You can adjust the focus manually on the live view page.
Network Camera User Manual
19
Day/Night Switch
Day/Night Switch funcon can provide color images in the day mode and turn on ll light in the
night mode. Switch mode is congurable.
Day
The image is always in color.
Night
The image is black/white or colorful and the supplement light will be enabled to ensure clear
live view image at night.
Note
Only certain device models support the supplement light and colorful image.
Auto
The camera switches between the day mode and the night mode according to the illuminaon
automacally.
Scheduled-Switch
Set the Start Time and the End Time to dene the duraon for day mode.
Note
Day/Night Switch funcon varies according to models.
Grey Scale
You can choose the range of the Grey Scale as [0-255] or [16-235].
Rotate
When enabled, the live view will rotate 90 ° counterclockwise. For example, 1280 × 720 is rotated
to 720 × 1280.
Enabling this funcon can change the eecve range of monitoring in the vercal direcon.
Lens Distoron Correcon
For device equipped with motorized lens, image may appear distorted to some extent. Enable this
funcon to correct the distoron.
Network Camera User Manual
20
Note
●
This funcon is only supported by certain device equipped with motorized lens.
●
The edge of image will be lost if this funcon is enabled.
BLC
If you focus on an object against strong backlight, the object will be too dark to be seen clearly. BLC
(backlight compensaon) compensates light to the object in the front to make it clear. If BLC mode
is set as Custom, you can draw a red rectangle on the live view image as the BLC area.
WDR
The WDR (Wide Dynamic Range) funcon helps the camera provide clear images in environment
with strong illuminaon dierences.
When there are both very bright and very dark areas simultaneously in the eld of view, you can
enable the WDR funcon and set the level. WDR automacally balances the brightness level of the
whole image and provides clear images with more details.
Note
When WDR is enabled, some other funcons may be not supported. Refer to the actual interface
for details.
HLC
When the bright area of the image is over-exposed and the dark area is under-exposed, the HLC
(High Light Compression) funcon can be enabled to weaken the bright area and brighten the dark
area, so as to achieve the light balance of the overall picture.
White Balance
White balance is the white rendion funcon of the camera. It is used to adjust the color
temperature according to the environment.
DNR
Digital Noise Reducon is used to reduce the image noise and improve the image quality. Normal
and Expert modes are selectable.
Normal
Network Camera User Manual
21
Set the DNR level to control the noise reducon degree. The higher level means stronger
reducon degree.
Expert
Set the DNR level for both space DNR and me DNR to control the noise reducon degree. The
higher level means stronger reducon degree.
Defog
You can enable the defog funcon when the environment is foggy and the image is misty. It
enhances the subtle details so that the image appears clearer.
EIS
Increase the stability of video image by using jier compensaon technology.
Mirror
When the live view image is the reverse of the actual scene, this funcon helps to display the
image normally.
Select the mirror mode as needed.
Note
The video recording will be shortly interrupted when the funcon is enabled.
4.6.2 Image Parameters Switch
The device automacally switches image parameters in set me periods.
Go to image parameters switch seng page: Conguraon → Image → Image Parameters Switch ,
and set parameters as needed.
Set Switch
Switch the image parameters to the scene automacally in certain me periods.
Steps
1.
Check Enable.
2.
Select and congure the corresponding me period and the scene.
Network Camera User Manual
22
Note
For the scene conguraon, refer to Scene Mode .
3.
Click Save.
4.6.3 Video Standard
Video standard is an ability of a video card or video display device that denes the amount of
colors that are shown and the resoluon. The two most common video standard used are NTSC
and PAL. In NTSC, 30 frames are transmied each second. Each frame is made up of 525 individual
scan lines. In PAL, 25 frames are transmied each second. Each frame is made up of 625 individual
scan lines. Select video signal standard according to the video system in your country/region.
4.6.4 Local Video Output
If the device is equipped with video output interfaces, such as BNC, CVBS, HDMI, and SDI, you can
preview the live image directly by connecng the device to a monitor screen.
Select the output mode as ON/OFF to control the output.
4.7 OSD
You can customize OSD (On-screen Display) informaon such as device name, me/date, font,
color, and text overlay displayed on video stream.
Go to OSD seng page: Conguraon → Image → OSD Sengs . Set the corresponding
parameters, and click Save to take eect.
Character Set
Select character set for displayed informaon. If Korean is required to displayed on screen, select
EUC-KR. Otherwise, select GBK.
Displayed Informaon
Set camera name, date, week, and their related display format.
Text Overlay
Set customized overlay text on image.
OSD Parameters
Set OSD parameters, such as Display Mode, OSD Size, Font Color, and Alignment.
Network Camera User Manual
23
4.8 Set Privacy Mask
The funcon blocks certain areas in the live view to protect privacy. No maer how the device
moves, the blocked scene will never be seen.
Steps
1.
Go to privacy mask seng page: Conguraon → Image → Privacy Mask .
2.
Check Enable Privacy Mask.
3.
Click Draw Area. Drag the mouse in the live view to draw a closed area.
Drag the corners of the area Adjust the size of the area.
Drag the area Adjust the posion of the area.
Click Clear All Clear all the areas you set.
4.
Click Stop Drawing.
5.
Click Save.
4.9 Overlay Picture
Overlay a customized picture on live view.
Before You Start
The picture to overlay has to be in BMP format with 24-bit, and the maximum picture size is 128 ×
128 pixel.
Steps
1.
Go to picture overlay seng page: Conguraon → Image → Picture Overlay .
2.
Click Browse to select a picture, and click Upload.
The picture with a red rectangle will appear in live view aer successfully uploading.
3.
Check Enable Picture Overlay.
4.
Drag the picture to adjust its posion.
5.
Click Save.
4.10 Set Target Cropping
You can crop the image, transmit and save only the images of the target area to save transmission
bandwidth and storage.
Steps
1.
Go to Conguraon → Video/Audio → Target Cropping .
2.
Check Enable Target Cropping and set Third Stream as the Stream Type.
Network Camera User Manual
24
Note
Aer enabling target cropping, the third stream resoluon cannot be congured.
3.
Select a Cropping Resoluon.
A red frame appears in the live view.
4.
Drag the frame to the target area.
5.
Click Save.
Note
●
Only certain models support target cropping and the funcon varies according to dierent
camera models.
●
Some funcons may be disabled aer enabling target cropping.
Network Camera User Manual
25
Chapter 5 Video Recording and Picture Capture
This part introduces the operaons of capturing video clips and snapshots, playback, and
downloading captured les.
5.1 Storage Sengs
This part introduces the conguraon of several common storage paths.
5.1.1 Set New or Unencrypted Memory Card
Before You Start
Insert a new or unencrypted memory card to the device. For detailed installaon, refer to Quick
Start Guide of the device.
Steps
1.
Go to Conguraon → Storage → Storage Management → HDD Management .
2.
Select the memory card.
Note
If an Unlock buon appears, you need to unlock the memory card rst. See Detect Memory
Card Status for details.
3.
Click Format to inialize the memory card.
When the Status of memory card turns from Uninialized to Normal, the memory card is ready
for use.
4.
Oponal: Encrypt the memory card.
1) Click Encrypted Format.
2) Set the encrypon password.
3) Click OK.
When the Encrypon Status turns to Encrypted, the memory card is ready for use.
Note
Keep your encrypon password properly. Encrypon password cannot be found if forgoen.
5.
Oponal: Dene the Quota of the memory card. Input the percentage for storing dierent
contents according to your needs.
6.
Click Save.
Network Camera User Manual
26
Detect Memory Card Status
The device detects the status of Hikvision memory card. You receive nocaons when your
memory card is detected abnormal.
Before You Start
The conguraon page only appears when a Hikvision memory card is installed to the device.
Steps
1.
Go to Conguraon → Storage → Storage Management → Memory Card Detecon .
2.
Click Status Detecon to check the Remaining Lifespan and Health Status of your memory card.
Remaining Lifespan
It shows the percentage of the remaining lifespan. The lifespan of a memory card may be
inuenced by factors such as its capacity and the bitrate. You need to change the memory
card if the remaining lifespan is not enough.
Health Status
It shows the condion of your memory card. There are three status descripons: good, bad,
and damaged. You will receive a nocaon if the health status is anything other than good
when the Arming Schedule and Linkage Method are set.
Note
It is recommended that you change the memory card when the health status is not "good".
3.
Click R/W Lock to set the permission of reading and wring to the memory card.
-
Add a Lock
a. Select the Lock Switch as ON.
b. Enter the password.
c. Click Save
-
Unlock
●
If you use the memory card on the device that locks it, unlocking will be done automacally
and no unlocking procedures are required on the part of users.
●
If you use the memory card (with a lock) on a dierent device, you can go to HDD
Management to unlock the memory card manually. Select the memory card, and click
Unlock. Enter the correct password to unlock it.
-
Remove the Lock
a. Select the Lock Switch as OFF.
b. Enter the password in Password Sengs.
c. Click Save.
Network Camera User Manual
27
Note
●
Only admin user can set the R/W Lock.
●
The memory card can only be read and wrien when it is unlocked.
●
If the device, which adds a lock to a memory card, is restored to the factory sengs, you can
go to HDD Management to unlock the memory card.
4.
Set Arming Schedule and Linkage Method. See Set Arming Schedule and Linkage Method
Sengs for details.
5.
Click Save.
5.1.2 Set FTP
You can congure the FTP server to save images which are captured by events or a med snapshot
task.
Before You Start
Get the FTP server address rst.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → FTP .
2.
Congure FTP sengs.
FTP Protocol
FTP and SFTP are selectable. The les uploading is encrypted by using SFTP protocol.
Server Address and Port
The FTP server address and corresponding port.
User Name and Password
The FTP user should have the permission to upload pictures.
If the FTP server supports picture uploading by anonymous users, you can check Anonymous
to hide your device informaon during uploading.
Directory Structure
The saving path of snapshots in the FTP server.
Picture Filing Interval
For beer picture management, you can set the picture ling interval from 1 day to 30 days.
Pictures captured in the same me interval will be saved in one folder named aer the
beginning date and ending date of the me interval.
Picture Name
Set the naming rule for captured pictures. You can choose Default in the drop-down list to
use the default rule, that is, IP address_channel number_capture me_event type.jpg (e.g.,
10.11.37.189_01_20150917094425492_FACE_DETECTION.jpg). Or you can customize it by
adding a Custom Prex to the default naming rule.
3.
Check Upload Picture to enable uploading snapshots to the FTP server.
Network Camera User Manual
28
4.
Check Enable Automac Network Replenishment.
Note
Upload to FTP/Memory Card/NAS in Linkage Method and Enable Automac Network
Replenishment should be both enabled simultaneously.
5.
Click Test to verify the FTP server.
6.
Click Save.
5.1.3 Set NAS
Take network server as network disk to store the record les, captured images, etc.
Before You Start
Get the IP address of the network disk rst.
Steps
1.
Go to NAS seng page: Conguraon → Storage → Storage Management → Net HDD .
2.
Click HDD No.. Enter the server address and le path for the disk.
Server Address
The IP address of the network disk.
File Path
The saving path of network disk les.
Mounng Type
Select le system protocol according to the operaon system.
Enter user name and password of the net HDD to guarantee the security if SMB/CIFS is
selected.
3.
Click Test to check whether the network disk is available.
4.
Click Save.
5.1.4 eMMC Protecon
It is to automacally stop the use of eMMC as a storage media when its health status is poor.
Note
The eMMC protecon is only supported by certain device models with an eMMC hardware.
Go to Conguraon → System → Maintenance → System Service for the sengs.
eMMC, short for embedded mulmedia card, is an embedded non-volale memory system. It is
able to store the captured images or videos of the device.
The device monitors the eMMC health status and turns o the eMMC when its status is poor.
Otherwise, using a worn-out eMMC may lead to device boot failure.
Network Camera User Manual
29
5.1.5 Set Cloud Storage
It helps to upload the captured pictures and data to the cloud. The plaorm requests picture
directly from the cloud for picture and analysis. The funcon is only supported by certain models.
Steps
Cauon
If the cloud storage is enabled, the pictures are stored in the cloud video manager rstly.
1.
Go to Conguraon → Storage → Storage Management → Cloud Storage .
2.
Check Enable Cloud Storage.
3.
Set basic parameters.
Protocol Version The protocol version of the cloud video manager.
Server IP The IP address of the cloud video manager. It supports IPv4 address.
Serve Port The port of the cloud video manager. You are recommended to use the
default port.
AccessKey The key to log in to the cloud video manager.
SecretKey The key to encrypt the data stored in the cloud video manager.
User Name and
Password
The user name and password of the cloud video manager.
Picture Storage
Pool ID
The ID of the picture storage region in the cloud video manager. Make
sure storage pool ID and the storage region ID are the same.
4.
Click Test to test the congured sengs.
5.
Click Save.
5.2 Video Recording
This part introduces the operaons of manual and scheduled recording, playback, and
downloading recorded les.
5.2.1 Record Automacally
This funcon can record video automacally during congured me periods.
Before You Start
Select Trigger Recording in event sengs for each record type except Connuous. See
Event and
Alarm for details.
Network Camera User Manual
30
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Record Schedule .
2.
Check Enable.
3.
Select a record type.
Note
The record type is vary according to dierent models.
Connuous
The video will be recorded connuously according to the schedule.
Moon
When moon detecon is enabled and trigger recording is selected as linkage method, object
movement is recorded.
Alarm
When alarm input is enabled and trigger recording is selected as linkage method, the video is
recorded aer receiving alarm signal from external alarm input device.
Moon | Alarm
Video is recorded when moon is detected or alarm signal is received from the external
alarm input device.
Moon & Alarm
Video is recorded only when moon is detected and alarm signal is received from the
external alarm input device.
Event
The video is recorded when congured event is detected.
4.
Set schedule for the selected record type. Refer to Set Arming Schedule for the seng
operaon.
5.
Click Advanced to set the advanced sengs.
Overwrite
Enable Overwrite to overwrite the video records when the storage space is full. Otherwise
the camera cannot record new videos.
Pre-record
The me period you set to record before the scheduled me.
Post-record
The me period you set to stop recording aer the scheduled me.
Stream Type
Select the stream type for recording.
Network Camera User Manual
31
Note
When you select the stream type with higher bitrate, the actual me of the pre-record and
post-record may be less than the set value.
Recording Expiraon
The recordings are deleted when they exceed the expired me. The expired me is
congurable. Note that once the recordings are deleted, they can not be recovered.
6.
Click Save.
5.2.2 Record Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Record File Size and saving path to for recorded les.
3.
Click Save.
4.
Click in the live view interface to start recording. Click to stop recording.
5.2.3 Set Lite Storage
Aer the lite storage is enabled, the frame rate and bitrate of the video stream can be reduced to
lengthen the storage me of the memory card when there is no moving object in the monitoring
scenario.
Steps
1.
Go to Conguraon → Storage → Storage Management → Lite Storage .
2.
Check Enable and set the level. The higher the level is, the larger the frame rate and bitrate are,
and the shorter the recommended storage me is.
3.
Set the storage me. The device automacally calculates the bitrate and oers the
recommended storage me according to the memory card space and level. You are
recommended to set the storage me to the device recommended me.
Note
●
If the lite storage is enabled, unformaed memory card will be formaed automacally.
●
The displayed available space of the memory card is assigned by default according to
Percentage of Record in Storage → Storage Management → Quota . You can adjust it as
required.
●
Only certain device models support the funcon.
5.2.4 Playback and Download Video
You can search, playback and download the videos stored in the local storage or network storage.
Network Camera User Manual
32
Steps
1.
Click Playback.
2.
Set search condion and click Search.
The matched video les showed on the ming bar.
3.
Click to play the video les.
-
Click
to clip video les.
-
Double click the live view image to play video les in full screen. Press ESC to exit full screen.
Note
Go to Conguraon → Local , click Save clips to to change the saving path of clipped video les.
4.
Click on the playback interface to download les.
1) Set search condion and click Search.
2) Select the video les and then click Download.
Note
Go to Conguraon → Local , click Save downloaded les to to change the saving path of
downloaded video les.
5.3 Capture Conguraon
The device can capture the pictures manually or automacally and save them in congured saving
path. You can view and download the snapshots.
5.3.1 Capture Automacally
This funcon can capture pictures automacally during congured me periods.
Before You Start
If event-triggered capture is required, you should congure related linkage methods in event
sengs. Refer to
Event and Alarm for event sengs.
Steps
1.
Go to Conguraon → Storage → Schedule Sengs → Capture → Capture Parameters .
2.
Set the capture type.
Timing
Capture a picture at the congured me interval.
Event-Triggered
Capture a picture when an event is triggered.
3.
Set the Format, Resoluon, Quality, Interval, and Capture Number.
4.
Refer to Set Arming Schedule for conguring schedule me.
5.
Click Save.
Network Camera User Manual
33
5.3.2 Capture Manually
Steps
1.
Go to Conguraon → Local .
2.
Set the Image Format and saving path to for snapshots.
JPEG
The picture size of this format is comparavely small, which is beer for network
transmission.
BMP
The picture is compressed with good quality.
3.
Click Save.
4.
Click near the live view or play back window to capture a picture manually.
5.3.3 Set Timing Wake
When the device is sleeping, it will wake up at the set me interval, and capture pictures and
upload them.
Steps
Note
The funcon is only supported by certain device models.
1.
Go to Conguraon → System → System Sengs → Power Consumpon Mode , under Sleep
Schedule, click the me schedule to set Sleep Capture Interval.
2.
Enter Conguraon → Event → Basic Event → Timing Wake .
3.
Check Enable.
4.
Select Capture Types.
5.
For the linkage method sengs, see Linkage Method Sengs .
6.
Click Save.
Result
The device will wake up at the set sleep capture interval, and capture pictures and upload them.
5.3.4 View and Download Picture
You can search, view and download the pictures stored in the local storage or network storage.
Steps
1.
Click Picture.
2.
Set search condion and click Search.
The matched pictures showed in the le list.
Network Camera User Manual
34
3.
Select the pictures then click Download to download them.
Note
Go to Conguraon → Local , click Save snapshots when playback to change the saving path of
pictures.
Network Camera User Manual
35
Chapter 6 Event and Alarm
This part introduces the conguraon of events. The device takes certain response to triggered
alarm.
6.1 Basic Event
6.1.1 Set Moon Detecon
It helps to detect the moving objects in the detecon region and trigger the linkage acons.
Steps
1.
Go to Conguraon → Event → Basic Event → Moon Detecon .
2.
Check Enable Moon Detecon.
3.
Oponal: Highlight to display the moving object in the image in green.
1) Check Enable Dynamic Analysis for Moon.
2) Go to Conguraon → Local .
3) Set Rules to Enable.
4.
Select Conguraon Mode, and set rule region and rule parameters.
-
For the informaon about normal mode, see
Normal Mode .
-
For the informaon about expert mode, see
Expert Mode .
5.
Set the arming schedule and linkage methods. For the informaon about arming schedule
sengs, see
Set Arming Schedule . For the informaon about linkage methods, see Linkage
Method Sengs .
6.
Click Save.
Expert Mode
You can congure dierent moon detecon parameters for day and night according to the actual
needs.
Steps
1.
Select Expert Mode in Conguraon.
2.
Set parameters of expert mode.
Scheduled Image Sengs
OFF
Image switch is disabled.
Auto-Switch
Network Camera User Manual
36
The system switches day/night mode automacally according to environment. It displays
colored image at day and black and white image at night.
Scheduled-Switch
The system switches day/night mode according to the schedule. It switches to day mode
during the set periods and switches to night mode during the other periods.
Sensivity
The higher the value of sensivity is, the more sensive the moon detecon is. If scheduled
image sengs is enabled, the sensivity of day and night can be set separately.
3.
Select an Area and click Draw Area. Click and drag the mouse on the live image and then release
the mouse to nish drawing one area.
Figure 6-1 Set Rules
Stop Drawing Finish drawing one area.
Clear All Delete all the areas.
4.
Click Save.
5.
Oponal: Repeat above steps to set mulple areas.
Normal Mode
You can set moon detecon parameters according to the device default parameters.
Steps
1.
Select normal mode in Conguraon.
Network Camera User Manual
37
2.
Set the sensivity of normal mode. The higher the value of sensivity is, the more sensive the
moon detecon is. If the sensivity is set to 0, moon detecon and dynamic analysis do not
take eect.
3.
Set Detecon Target. Human and vehicle are available. If the detecon target is not selected, all
the detected targets will be reported, including the human and vehicle.
4.
Click Draw Area. Click and drag the mouse on the live video, and then release the mouse to
nish drawing one area.
Stop Drawing Stop drawing one area.
Clear All Clear all the areas.
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.1.2 Set Video Tampering Alarm
When the congured area is covered and cannot be monitored normally, the alarm is triggered and
the device takes certain alarm response acons.
Steps
1.
Go to Conguraon → Event → Basic Event → Video Tampering .
2.
Check Enable.
3.
Set the Sensivity. The higher the value is, the easier to detect the area covering.
4.
Click Draw Area and drag the mouse in the live view to draw the area.
Stop Drawing Finish drawing.
Clear All Delete all the drawn areas.
Network Camera User Manual
38
Figure 6-2 Set Video Tampering Area
5.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
6.
Click Save.
6.1.3 Set PIR Alarm
A PIR (Passive Infrared) alarm is triggered when an intruder moves within the detector's eld of
view. The heat energy dissipated by a person, or any other warm blooded creature such as dogs,
cats, etc., can be detected.
Steps
Note
Only certain models support PIR alarm.
1.
Go to Conguraon → Advanced Conguraon → Basic Event → PIR Alarm .
Network Camera User Manual
39
2.
Check Enable PIR Alarm.
3.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
4.
Click Save.
6.1.4 Set Excepon Alarm
Excepon such as network disconnecon can trigger the device to take corresponding acon.
Steps
1.
Go to Conguraon → Event → Basic Event → Excepon .
2.
Select Excepon Type.
HDD Full The HDD storage is full.
HDD Error Error occurs in HDD.
Network Disconnected The device is oine.
IP Address Conicted The IP address of current device is same as that of other device in
the network.
Illegal Login Incorrect user name or password is entered.
Voltage Instable The power supply voltage is uctuang.
3.
Refer to
Linkage Method Sengs for seng linkage method.
4.
Click Save.
6.1.5 Set Alarm Input
Alarm signal from the external device triggers the corresponding acons of the current device.
Before You Start
Make sure the external alarm device is connected. See Quick Start Guide for cable connecon.
Steps
1.
Go to Conguraon → Event → Basic Event → Alarm Input .
2.
Check Enable Alarm Input Handling.
3.
Select Alarm Input NO. and Alarm Type from the dropdown list. Edit the Alarm Name.
4.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5.
Click Copy to... to copy the sengs to other alarm input channels.
6.
Click Save.
Network Camera User Manual
40
6.1.6 Set Video Quality Diagnosis
When the video quality of the device is abnormal and the alarm linkage is set, the alarm will be
triggered automacally.
Steps
1.
Go to Conguraon → Event → Basic Event → Video Quality Diagnosis .
2.
Select Diagnosis Type.
3.
Set the corresponding parameters.
Alarm Detecon Interval
The me interval to detect the excepon.
Sensivity
The higher the value is, the more easily the excepon will be detected, and the higher
possibility of misinformaon would be.
Alarm Delay Times
The device uploads the alarm when the alarm reaches the set number of mes.
4.
Check Enable, and the selected diagnosis type will be detected.
5.
Set arming schedule. See Set Arming Schedule .
6.
Set linkage method. See Linkage Method Sengs .
7.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with models.
6.1.7 Set Vibraon Detecon
It is used to detect whether the device is vibrang. The device reports an alarm and triggers linkage
acons if the funcon is enabled.
Steps
1.
Go to Conguraon → Event → Basic Event → Vibraon Detecon .
2.
Check Enable.
3.
Drag the slider to set the detecon sensivity. You can also enter number to set the sensivity.
4.
Set the arming schedule. See Set Arming Schedule .
5.
Set the linkage method. See Linkage Method Sengs .
6.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with models.
Network Camera User Manual
41
6.2 Smart Event
Note
●
The funcon varies according to dierent models.
●
To enable this funcon, you may need to select Smart Event on VCA Resource page. For certain
models, this funcon is supported in the Single Channel mode. See for details.
●
For certain models, when the smart events are in use, the EIS is unavailable.
6.2.1 Detect Audio Excepon
Audio excepon detecon funcon detects the abnormal sound in the scene, such as the sudden
increase/decrease of the sound intensity, and some certain acons can be taken as response.
Steps
1.
Go to Conguraon → Event → Smart Event → Audio Excepon Detecon .
2.
Select one or several audio excepon detecon types.
Audio Loss Detecon
Detect sudden loss of audio track.
Sudden Increase of Sound Intensity Detecon
Detect sudden increase of sound intensity. Sensivity and Sound Intensity Threshold are
congurable.
Note
●
The lower the sensivity is, the more signicant the change should be to trigger the
detecon.
●
The sound intensity threshold refers to the sound intensity reference for the detecon. It is
recommended to set as the average sound intensity in the environment. The louder the
environment sound, the higher the value should be. You can adjust it according to the real
environment.
Sudden Decrease of Sound Intensity Detecon
Detect sudden decrease of sound intensity. Sensivity is congurable.
3.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage methods.
4.
Click Save.
Note
The funcon is only supported by certain models. The actual funcon varies according to
dierent models.
Network Camera User Manual
42
6.2.2 Set Defocus Detecon
The blurred image caused by lens defocus can be detected. If it occurs, the device can take linkage
acons.
Steps
1.
Go to Conguraon → Event → Smart Event → Defocus Detecon .
2.
Check Enable.
3.
Set Sensivity. The higher the value is, the more easily the defocus image can trigger the alarm.
You can adjust the value according to the actual environment.
4.
For the linkage method sengs, refer to Linkage Method Sengs .
5.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with models.
6.2.3 Detect Scene Change
Scene change detecon funcon detects the change of the scene. Some certain acons can be
taken when the alarm is triggered.
Steps
1.
Go to Conguraon → Event → Smart Event → Scene Change Detecon .
2.
Click Enable.
3.
Set the Sensivity.
Note
The higher the value is, the more easily the change of scene can be detected. But the detecon
accuracy is reduced.
4.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
5.
Click Save.
Note
The funcon varies according to dierent models.
6.2.4 Set Face Detecon
It helps to detect the face in the detecon region. If a face is detected, the device triggers the
linkage acons.
Steps
1.
Go to Conguraon → Event → Smart Event → Face Detecon .
Network Camera User Manual
43
2.
Check Enable Face Detecon.
3.
Oponal: Highlight to display the face in the image.
1) Check Enable Dynamic Analysis For Face Detecon.
2) Go to Conguraon → Local , set Rules to Enable.
4.
Set Sensivity. The lower the sensivity is, the prole of the face or unclear face is more dicult
to detect.
5.
Set the arming schedule and linkage methods. For the informaon about arming schedule
sengs, see Set Arming Schedule . For the informaon about linkage methods, see Linkage
Method Sengs .
6.
Click Save.
6.2.5 Set Video Loss
This funcon can detect the video signal loss in me and trigger the linkage acon.
Steps
1.
Go to Conguraon → Event → Basic Event → Video Loss .
2.
Check Enable.
3.
Refer to Set Arming Schedule for seng scheduled me. Refer to Linkage Method Sengs for
seng linkage method.
4.
Click Save.
6.2.6 Set Intrusion Detecon
It is used to detect objects entering and loitering in a pre-dened virtual region. If it occurs, the
device can take linkage acons.
Steps
1.
Go to Conguraon → Event → Smart Event → Intrusion Detecon .
2.
Check Enable.
3.
Select a Region. For the detecon region sengs, refer to
Draw Area .
4.
Set rules.
Sensivity Sensivity stands for the percentage of the body part of an acceptable target
that enters the pre-dened region. Sensivity = 100 - S1/ST × 100. S1 stands
for the target body part that goes across the pre-dened region. ST stands for
the complete target body. The higher the value of sensivity is, the more
easily the alarm can be triggered.
Threshold Threshold stands for the threshold for the me of the object loitering in the
region. If the me that one object stays exceeds the threshold, the alarm is
triggered. The larger the value of the threshold is, the longer the alarm
triggering me is.
Network Camera User Manual
44
Detecon
Target
Human and vehicle are available. If the detecon target is not selected, all the
detected targets will be reported, including the human and vehicle.
Target
Validity
If you set a higher validity, the required target features should be more
obvious, and the alarm accuracy would be higher. The target with less obvious
features would be missing.
Figure 6-3 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to
Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
6.2.7 Set Line Crossing Detecon
It is used to detect objects crossing a pre-dened virtual line. If it occurs, the device can take
linkage acons.
Steps
1.
Go to Conguraon → Event → Smart Event → Line Crossing Detecon .
2.
Check Enable.
3.
Select one Line and set the size lter. For the size lter sengs, refer to Set Size Filter .
4.
Click Draw Area and a line with an arrow appears in the live video. Drag the line to the locaon
on the live video as desired.
5.
Set rules.
Direcon It stands for the direcon from which the object goes across the line.
A<->B: The object going across the line from both direcons can be detected
and alarms are triggered.
A->B: Only the object crossing the congured line from the A side to the B side
can be detected.
Network Camera User Manual
45
B->A: Only the object crossing the congured line from the B side to the A side
can be detected.
Sensivity It stands for the percentage of the body part of an acceptable target that goes
across the pre-dened line. Sensivity = 100 - S1/ST × 100. S1 stands for the
target body part that goes across the pre-dened line. ST stands for the
complete target body. The higher the value of sensivity is, the more easily the
alarm can be triggered.
Detecon
Target
Human and vehicle are available. If the detecon target is not selected, all the
detected targets will be reported, including the human and vehicle.
Target
Validity
If you set a higher validity, the required target features should be more
obvious, and the alarm accuracy would be higher. The target with less obvious
features would be missing.
Figure 6-4 Set Rule
6.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
7.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
8.
Click Save.
6.2.8 Set Region Entrance Detecon
It is used to detect objects entering a pre-dened virtual region from the outside place. If it occurs,
the device can take linkage acons.
Network Camera User Manual
46
Steps
1.
Go to Conguraon → Event → Smart Event → Region Entrance Detecon .
2.
Check Enable.
3.
Select one Region. For the region sengs, refer to Draw Area .
4.
Set the detecon target, sensivity and the target validity.
Sensivity It stands for the percentage of the body part of an acceptable target that goes
across the pre-dened region. Sensivity = 100 - S1/ST × 100. S1 stands for
the target body part that goes across the pre-dened region. ST stands for the
complete target body. The higher the value of sensivity is, the more easily
the alarm can be triggered.
Detecon
Target
Human and vehicle are available. If the detecon target is not selected, all the
detected targets will be reported, including the human and vehicle.
Target
Validity
If you set a higher validity, the required target features should be more
obvious, and the alarm accuracy would be higher. The target with less obvious
features would be missing.
Figure 6-5 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
Network Camera User Manual
47
6.2.9 Set Region Exing Detecon
It is used to detect objects exing from a pre-dened virtual region. If it occurs, the device can take
linkage acons.
Steps
1.
Go to Conguraon → Event → Smart Event → Region Exing Detecon
2.
Check Enable.
3.
Select one Region. For the detecon region sengs, refer to Draw Area .
4.
Set the detecon target, sensivity and the target validity.
Sensivity It stands for the percentage of the body part of an acceptable target that goes
across the pre-dened region. Sensivity = 100 - S1/ST × 100. S1 stands for
the target body part that goes across the pre-dened region. ST stands for the
complete target body. The higher the value of sensivity is, the more easily
the alarm can be triggered.
Detecon
Target
Human and vehicle are available. If the detecon target is not selected, all the
detected targets will be reported, including the human and vehicle.
Target
Validity
If you set a higher validity, the required target features should be more
obvious, and the alarm accuracy would be higher. The target with less obvious
features would be missing.
Figure 6-6 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
Network Camera User Manual
48
7.
Click Save.
6.2.10 Set Unaended Baggage Detecon
It is used to detect the objects le over in the pre-dened region. Linkage methods can be
triggered aer the object is le and stays in the region for a set me period.
Steps
1.
Go to Conguraon → Event → Smart Event → Unaended Baggage Detecon .
2.
Check Enable.
3.
Select one Region. For the detecon region sengs, refer to Draw Area .
4.
Set rules.
Sensivity Sensivity stands for the percentage of the body part of an acceptable target
that enters the pre-dened region. Sensivity = 100 - S1/ST × 100. S1 stands for
the target body part that goes across the pre-dened region. ST stands for the
complete target body. The higher the value of sensivity is, the more easily the
alarm can be triggered.
Threshold It stands for the me of the objects le in the region. Alarm is triggered aer the
object is le and stays in the region for the set me period.
Figure 6-7 Set Rule
5.
Oponal: You can set the parameters of mulple areas by repeang the above steps.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
Network Camera User Manual
49
6.2.11 Set Object Removal Detecon
It detects whether the objects are removed from the pre-dened detecon region, such as the
exhibits on display. If it occurs, the device can take linkage acons and the sta can take measures
to reduce property loss.
Steps
1.
Go to Conguraon → Event → Smart Event → Object Removal Detecon .
2.
Check Enable.
3.
Select a Region. For the region sengs, see Draw Area .
4.
Set the rule.
Sensivity It stands for the percentage of the body part of an acceptable target that leaves
the pre-dened region.
Sensivity = 100 – S1/ST*100
S1 stands for the target body part that leaves the pre-dened region. ST stands
for the complete target body.
Example: If you set the value as 60, a target is possible to be counted as a
removed object only when 40 percent body part of the target leaves the region.
Threshold The threshold for the me of the objects removed from the region. If you set the
value as 10, alarm is triggered aer the object disappears from the region for
10s.
5.
Oponal: Repeat the above steps to set more regions.
6.
For the arming schedule sengs, see
Set Arming Schedule . For the linkage method sengs, see
Linkage Method Sengs .
7.
Click Save.
Note
The funcon is only supported by certain models. The actual display varies with the models.
6.2.12 Draw Area
This secon introduces the conguraon of area.
Steps
1.
Click Draw Area.
2.
Click on the live view to draw the boundaries of the detecon region, and right click to complete
drawing.
3.
Click Save.
Note
Click Clear All to clear all pre-dened areas.
Network Camera User Manual
50
6.2.13 Set Size Filter
This part introduces the seng of size lter. Only the target whose size is between the minimum
value and maximum value is detected and triggers alarm.
Steps
1.
Click Max. Size, and drag the mouse in the live view to draw the maximum target size.
2.
Click Min. Size, and drag the mouse in the live view to draw the minimum target size.
3.
Click Save.
Network Camera User Manual
51
Chapter 7 Network Sengs
7.1 TCP/IP
TCP/IP sengs must be properly congured before you operate the device over network. IPv4 and
IPv6 are both supported. Both versions can be congured simultaneously without conicng to
each other.
Go to Conguraon → Network → Basic Sengs → TCP/IP for parameter sengs.
NIC Type
Select a NIC (Network Interface Card) type according to your network condion.
IPv4
Two IPv4 modes are available.
DHCP
The device automacally gets the IPv4 parameters from the network if you check DHCP. The
device IP address is changed aer enabling the funcon. You can use SADP to get the device IP
address.
Note
The network that the device is connected to should support DHCP (Dynamic Host
Conguraon Protocol).
Manual
You can set the device IPv4 parameters manually. Input IPv4 Address, IPv4 Subnet Mask, and
IPv4 Default Gateway, and click Test to see if the IP address is available.
IPv6
Three IPv6 modes are available.
Route Adversement
The IPv6 address is generated by combining the route adversement and the device Mac
address.
Note
Route adversement mode requires the support from the router that the device is connected
to.
DHCP
The IPv6 address is assigned by the server, router, or gateway.
Manual
Network Camera User Manual
52
Input IPv6 Address, IPv6 Subnet, IPv6 Default Gateway. Consult the network administrator for
required informaon.
MTU
It stands for maximum transmission unit. It is the size of the largest protocol data unit that can
be communicated in a single network layer transacon.
The valid value range of MTU is 1280 to 1500.
DNS
It stands for domain name server. It is required if you need to visit the device with domain
name. And it is also required for some applicaons (e.g., sending email). Set Preferred DNS
Server and Alternate DNS server properly if needed.
Dynamic Domain Name
Check Enable Dynamic Domain Name and input Register Domain Name. The device is
registered under the register domain name for easier management within the local area
network.
Note
DHCP should be enabled for the dynamic domain name to take eect.
7.1.1 Mulcast
Mulcast is a group communicaon where data transmission is addressed to a group of desnaon
devices simultaneously. Aer seng mulcast, you can send the source data eciently to mulple
receivers.
Go to Conguraon → Network → Basic Sengs → Mulcast for the mulcast sengs.
IP Address
It stands for the address of mulcast host.
Stream Type
The stream type of the mulcast source.
Video Port
The video port of the selected stream.
Audio Port
The audio port of the selected stream.
FEC Port
The FEC port of the selected stream.
FEC Rao
The rao of forward error correcon.
Network Camera User Manual
53
7.1.2 Mulcast Discovery
Check the Enable Mulcast Discovery, and then the online network camera can be automacally
detected by client soware via private mulcast protocol in the LAN.
7.2 SNMP
You can set the SNMP (Simple Network Management Protocol) to get device informaon in
network management.
Before You Start
Before seng the SNMP, you should download the SNMP soware and manage to receive the
device informaon via SNMP port.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → SNMP .
2.
Check Enable SNMPv1, Enable SNMP v2c or Enable SNMPv3.
Note
The SNMP version you select should be the same as that of the SNMP soware.
And you also need to use the dierent version according to the security level required. SNMP v1
is not secure and SNMP v2 requires password for access. And SNMP v3 provides encrypon and
if you use the third version, HTTPS protocol must be enabled.
3.
Congure the SNMP sengs.
4.
Click Save.
7.3 Set SRTP
The Secure Real-me Transport Protocol (SRTP) is a Real-me Transport Protocol (RTP) internet
protocol, intended to provide encrypon, message authencaon and integrity, and replay aack
protecon to the RTP data in both unicast and mulcast applicaons.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → SRTP .
2.
Select Server Cercate.
3.
Select Encrypted Algorithm.
4.
Click Save.
Note
●
Only certain device models support this funcon.
●
If the funcon is abnormal, check if the selected cercate is abnormal in cercate
management.
Network Camera User Manual
54
7.4 Port Mapping
By seng port mapping, you can access devices through the specied port.
Before You Start
When the ports in the device are the same as those of other devices in the network, refer to Port
to modify the device ports.
Steps
1.
Go to Conguraon → Network → Basic Sengs → NAT .
2.
Select the port mapping mode.
Auto Port Mapping Refer to
Set Auto Port Mapping for detailed informaon.
Manual Port Mapping Refer to
Set Manual Port Mapping for detailed informaon.
3.
Click Save.
7.4.1 Set Auto Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the camera, or you can use the default
name.
2.
Select the port mapping mode to Auto.
3.
Click Save.
Note
UPnP™ funcon on the router should be enabled at the same me.
7.4.2 Set Manual Port Mapping
Steps
1.
Check Enable UPnP™, and choose a friendly name for the device, or you can use the default
name.
2.
Select the port mapping mode to Manual, and set the external port to be the same as the
internal port.
3.
Click Save.
What to do next
Go to the router port mapping sengs interface and set the port number and IP address to be the
same as those on the device. For more informaon, refer to the router user manual.
Network Camera User Manual
55
7.4.3 Set Port Mapping on Router
The following sengs are for a certain router. The sengs vary depending on dierent models of
routers.
Steps
1.
Select the WAN Connecon Type.
2.
Set the IP Address, Subnet Mask and other network parameters of the router.
3.
Go to Forwarding → Virtual Severs , and input the Port Number and IP Address.
4.
Click Save.
Example
When the cameras are connected to the same router, you can congure the ports of a camera as
80, 8000, and 554 with IP address 192.168.1.23, and the ports of another camera as 81, 8001, 555,
8201 with IP 192.168.1.24.
Figure 7-1 Port Mapping on Router
Note
The port of the network camera cannot conict with other ports. For example, some web
management port of the router is 80. Change the camera port if it is the same as the management
port.
Network Camera User Manual
56
7.5 Port
The device port can be modied when the device cannot access the network due to port conicts.
Cauon
Do not modify the default port parameters at will, otherwise the device may be inaccessible.
Go to Conguraon → Network → Basic Sengs → Port for port sengs.
HTTP Port
It refers to the port through which the browser accesses the device. For example, when the
HTTP Port is modied to 81, you need to enter hp://192.168.1.64:81 in the browser for login.
HTTPS Port
It refers to the port through which the browser accesses the device with cercate. Cercate
vericaon is required to ensure the secure access.
RTSP Port
It refers to the port of real-me streaming protocol.
SRTP Port
It refers to the port of secure real-me transport protocol.
Server Port
It refers to the port through which the client adds the device.
Enhanced SDK Service Port
It refers to the port through which the client adds the device. Cercate vericaon is required
to ensure the secure access.
WebSocket Port
TCP-based full-duplex communicaon protocol port for plug-in free preview.
WebSockets Port
TCP-based full-duplex communicaon protocol port for plug-in free preview. Cercate
vericaon is required to ensure the secure access.
Note
●
Enhanced SDK Service Port, WebSocket Port, and WebSockets Port are only supported by certain
models.
●
For device models that support that funcon, go to Conguraon → Network → Advanced
Sengs → Network Service to enable it.
Network Camera User Manual
57
7.6 Access to Device via Domain Name
You can use the Dynamic DNS (DDNS) for network access. The dynamic IP address of the device can
be mapped to a domain name resoluon server to realize the network access via domain name.
Before You Start
Registraon on the DDNS server is required before conguring the DDNS sengs of the device.
Steps
1.
Refer to TCP/IP to set DNS parameters.
2.
Go to the DDNS sengs page: Conguraon → Network → Basic Sengs → DDNS .
3.
Check Enable DDNS and select DDNS type.
DynDNS
Dynamic DNS server is used for domain name resoluon.
NO-IP
NO-IP server is used for domain name resoluon.
4.
Input the domain name informaon, and click Save.
5.
Check the device ports and complete port mapping. Refer to Port to check the device port , and
refer to Port Mapping for port mapping sengs.
6.
Access the device.
By Browsers Enter the domain name in the browser address bar to access the device.
By Client Soware Add domain name to the client soware. Refer to the client manual for
specic adding methods.
7.7 Access to Device via PPPoE Dial Up Connecon
This device supports the PPPoE auto dial-up funcon. The device gets a public IP address by ADSL
dial-up aer the device is connected to a modem. You need to congure the PPPoE parameters of
the device.
Steps
1.
Go to Conguraon → Network → Basic Sengs → PPPoE .
2.
Check Enable PPPoE.
3.
Set the PPPoE parameters.
Dynamic IP
Aer successful dial-up, the dynamic IP address of the WAN is displayed.
User Name
User name for dial-up network access.
Password
Password for dial-up network access.
Network Camera User Manual
58
Conrm
Input your dial-up password again.
4.
Click Save.
5.
Access the device.
By Browsers Enter the WAN dynamic IP address in the browser address bar to access
the device.
By Client Soware Add the WAN dynamic IP address to the client soware. Refer to the
client manual for details.
Note
The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
aer reboong the camera. To solve the inconvenience of the dynamic IP, you need to get a
domain name from the DDNS provider (e.g. DynDns.com). Refer to Access to Device via Domain
Name for detail informaon.
7.8 Wireless Dial
Data of audio, video and image can be transferred via 3G/4G wireless network.
Note
The funcon is only supported by certain device models.
7.8.1 Set Wireless Dial
The built-in wireless module oers dial-up access to the Internet for the device.
Before You Start
Get a SIM card, and acvate 3G/4G services. Insert the SIM card to the corresponding slot.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Wireless Dial .
2.
Check to enable the funcon.
3.
Click Dial Parameters to congure and save the parameters.
4.
Click Dial Plan. See
Set Arming Schedule for detailed informaon.
5.
Oponal: Set Allowlist. See Set Allowlist for detailed informaon.
6.
Click Dial Status.
Click Refresh Refresh the dial status.
Click Disconnect Disconnect the 3G/4G wireless network.
When the Dial Status turns to Connected, it means a successful dial.
7.
Access the device via the IP Address of the computer in the network.
Network Camera User Manual
59
-
Input the IP address in the browser to access the device.
-
Add the device in client applicaon. Select IP/Domain, and input IP address and other
parameters to access the device.
7.8.2 Set Allowlist
Add the mobile phone number of administrator to the allowlist in order to receive alarm message
from the device.
Steps
1.
Go to allowlist sengs page: Conguraon → Advanced Conguraon → Wireless Dial →
Allowlist .
2.
Check Enable SMS Alarm.
3.
Click
in the allowlist.
1) Input the mobile phone number to receive alarm message.
2) Check Reboot via SMS.
3) Select the certain events, and the mobile phone can receive the alarm message when the
event happens.
4) Click Save.
5) Oponal: Repeat the steps above to set mulple recipients.
Modify the allowlist parameters.
Delete the allowlist that already set.
Send Test SMS Send a message to the mobile phone for test.
4.
Click Save.
7.9 Wi-Fi
Connect the device to wireless network by seng Wi-Fi parameters.
Note
This funcon is only supported by certain device models.
7.9.1 Connect Device to Wi-Fi
Before You Start
Refer to the user manual of wireless router or AP to set SSID, key, and other parameters.
Steps
1.
Go to TCP/IP sengs page: Conguraon → Network → Basic Conguraon → TCP/IP .
2.
Select Wlan to set the parameters. Refer to TCP/IP for detailed conguraon.
Network Camera User Manual
60
Note
For stable use of Wi-Fi, it is not recommended to use DHCP.
3.
Go to Wi-Fi sengs page: Conguraon → Network → Advanced Conguraon → Wi-Fi .
4.
Set and save the parameters.
1) Click Search.
2) Select a SSID, which should be the same as that of wireless router or AP.
The parameters of the network is automacally shown in Wi-Fi.
3) Select the Network Mode as Manage.
4) Input the key to connect the wireless network. The key should be that of the wireless network
connecon you set on the router.
What to do next
Go to TCP/IP sengs page: Conguraon → Network → Basic Conguraon → TCP/IP , and click
Wlan to check the IPv4 Address and log in the device.
7.10 Set Network Service
You can control the ON/OFF status of certain protocol as desired.
Steps
Note
This funcon varies according to dierent models.
1.
Go to Conguraon → Network → Advanced Sengs → Network Service .
2.
Set network service.
WebSocket & WebSockets
WebSocket or WebSockets protocol should be enabled if you use Google Chrome 57 and its
above version or Mozilla Firefox 52 and its above version to visit the device. Otherwise, live
view, image capture, digital zoom, etc. cannot be used.
If the device uses HTTP, enable WebSocket.
If the device uses HTTPS, enable WebSockets.
When you use WebSockets, select the Server Cercate.
Note
Complete cercate management before selecng server cercate. Refer to Cercate
Management for detailed informaon.
SDK Service & Enhanced SDK Service
Check Enable SDK Service to add the device to the client soware with SDK protocol.
Network Camera User Manual
61
Check Enable Enhanced SDK Service to add the device to the client soware with SDK over
TLS protocol.
When you use Enhanced SDK Service, select the Server Cercate.
Note
●
Complete cercate management before selecng server cercate. Refer to Cercate
Management for detailed informaon.
●
When set up connecon between the device and the client soware, it is recommended to
use Enhanced SDK Service and set the communicaon in Arming Mode to encrypt the data
transmission. See the user manual of the client soware for the arming mode sengs.
TLS (Transport Layer Security)
The device oers TLS1.1 and TLS1.2. Enable one or more protocol versions according to your
need.
Bonjour
Uncheck to disable the protocol.
3.
Click Save.
7.11 Set Open Network Video Interface
If you need to access the device through Open Network Video Interface protocol, you can
congure the user sengs to enhance the network security.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Integraon Protocol .
2.
Check Enable Open Network Video Interface.
3.
Click Add to congure the Open Network Video Interface user.
Delete Delete the selected Open Network Video Interface user.
Modify Modify the selected Open Network Video Interface user.
4.
Click Save.
5.
Oponal: Repeat the steps above to add more Open Network Video Interface users.
7.12 Set ISUP
When the device is registered on ISUP plaorm (formerly called Ehome), you can visit and manage
the device, transmit data, and forward alarm informaon over public network.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Plaorm Access .
2.
Select ISUP as the plaorm access mode.
3.
Select Enable.
Network Camera User Manual
62
4.
Select a protocol version and input related parameters.
5.
Click Save.
Register status turns to Online when the funcon is correctly set.
7.13 Set Alarm Server
The device can send alarms to desnaon IP address or host name through HTTP, HTTPS, or ISUP
protocol. The desnaon IP address or host name should support HTTP, HTTP, or ISUP data
transmission.
Steps
1.
Go to Conguraon → Network → Advanced Sengs → Alarm Server .
2.
Enter Desnaon IP or Host Name, URL, and Port.
3.
Oponal: Check Enable to enable ANR.
4.
Select Protocol.
Note
HTTP, HTTPS, and ISUP are selectable. It is recommended to use HTTPS, as it encrypts the data
transmission during communicaon.
5.
Click Test to check if the IP or host is available.
6.
Click Save.
7.14 Access Camera via Hik-Connect
Hik-Connect is an applicaon for mobile devices. Using the App, you can view live image, receive
alarm nocaon and so on.
Before You Start
Connect the camera to network with network cables.
Steps
1.
Get and install Hik-Connect applicaon by the following ways.
-
Visit
hps://appstore.hikvision.com to download the applicaon according to your mobile
phone system.
-
Visit the ocial site of our company. Then go to Support → Tools → Hikvision App Store .
-
Scan the QR code below to download the applicaon.
Network Camera User Manual
63
Note
If errors like "Unknown app" occur during the installaon, solve the problem in two ways.
●
Visit hps://appstore.hikvision.com/stac/help/index.html to refer to the troubleshoong.
●
Visit hps://appstore.hikvision.com/ , and click Installaon Help at the upper right corner of
the interface to refer to the troubleshoong.
2.
Start the applicaon and register for a Hik-Connect user account.
3.
Log in aer registraon.
4.
In the app, tap "+" on the upper-right corner and then scan the QR code of the camera to add
the camera. You can nd the QR code on the camera or on the cover of the Quick Start Guide of
the camera in the package.
5.
Follow the prompts to set the network connecon and add the camera to your Hik-Connect
account.
For detailed informaon, refer to the user manual of the Hik-Connect app.
7.14.1 Enable Hik-Connect Service on Camera
Hik-Connect service should be enabled on your camera before using the service.
You can enable the service through SADP soware or Web browser.
Enable Hik-Connect Service via Web Browser
Follow the following steps to enable Hik-Connect Service via Web Browser.
Before You Start
You need to acvate the camera before enabling the service.
Steps
1.
Access the camera via web browser.
2.
Enter plaorm access conguraon interface. Conguraon → Network → Advanced Sengs
→ Plaorm Access
3.
Select Hik-Connect as the Plaorm Access Mode.
4.
Check Enable.
5.
Click and read "Terms of Service" and "Privacy Policy" in pop-up window.
6.
Create a vericaon code or change the old vericaon code for the camera.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
7.
Save the sengs.
Network Camera User Manual
64
Enable Hik-Connect Service via SADP Soware
This part introduce how to enable Hik-Connect service via SADP soware of an acvated camera.
Steps
1.
Run SADP soware.
2.
Select a camera and enter Modify Network Parameters page.
3.
Check Enable Hik-Connect.
4.
Create a vericaon code or change the old vericaon code.
Note
The vericaon code is required when you add the camera to Hik-Connect service.
5.
Click and read "Terms of Service" and "Privacy Policy".
6.
Conrm the sengs.
7.14.2 Set Up Hik-Connect
Steps
1.
Get and install Hik-Connect applicaon by the following ways.
-
Visit
hps://appstore.hikvision.com to download the applicaon according to your mobile
phone system.
-
Visit the ocial site of our company. Then go to Support → Tools → Hikvision App Store .
-
Scan the QR code below to download the applicaon.
Note
If errors like "Unknown app" occur during the installaon, solve the problem in two ways.
●
Visit hps://appstore.hikvision.com/stac/help/index.html to refer to the troubleshoong.
●
Visit hps://appstore.hikvision.com/ , and click Installaon Help at the upper right corner of
the interface to refer to the troubleshoong.
2.
Start the applicaon and register for a Hik-Connect user account.
3.
Log in aer registraon.
Network Camera User Manual
65
7.14.3 Add Camera to Hik-Connect
Steps
1.
Connect your mobile device to a Wi-Fi.
2.
Log into the Hik-Connect app.
3.
In the home page, tap "+" on the upper-right corner to add a camera.
4.
Scan the QR code on camera body or on the Quick Start Guide cover.
Note
If the QR code is missing or too blur to be recognized, you can also add the camera by inpung
the camera's serial number.
5.
Input the vericaon code of your camera.
Note
●
The required vericaon code is the code you create or change when you enable Hik-Connect
service on the camera.
●
If you forget the vericaon code, you can check the current vericaon code on Plaorm
Access conguraon page via web browser.
6.
Tap Connect to a Network buon in the popup interface.
7.
Choose Wired Connecon or Wireless Connecon according to your camera funcon.
Wireless
Connecon
Input the Wi-Fi password that your mobile phone has connected to, and
tap Next to start the Wi-Fi connecon process. (Locate the camera within 3
meters from the router when seng up the Wi-Fi.)
Wired
Connecon
Connect the camera to the router with a network cable and tap Connected
in the result interface.
Note
The router should be the same one which your mobile phone has connected to.
8.
Tap Add in the next interface to nish adding.
For detailed informaon, refer to the user manual of the Hik-Connect app.
Network Camera User Manual
66
Chapter 8 Arming Schedule and Alarm Linkage
Arming schedule is a customized me period in which the device performs certain tasks. Alarm
linkage is the response to the detected certain incident or target during the scheduled me.
8.1 Set Arming Schedule
Set the valid me of the device tasks.
Steps
1.
Click Arming Schedule.
2.
Drag the me bar to draw desired valid me.
Note
Up to 8 periods can be congured for one day.
3.
Adjust the me period.
-
Click on the selected me period, and enter the desired value. Click Save.
-
Click on the selected me period. Drag the both ends to adjust the me period.
-
Click on the selected me period, and drag it on the me bar.
4.
Oponal: Click Copy to... to copy the same sengs to other days.
5.
Click Save.
8.2 Linkage Method Sengs
You can enable the linkage funcons when an event or alarm occurs.
8.2.1 Trigger Alarm Output
If the device has been connected to an alarm output device, and the alarm output No. has been
congured, the device sends alarm informaon to the connected alarm output device when an
alarm is triggered.
Steps
1.
Go to Conguraon → Event → Basic Event → Alarm Output .
2.
Set alarm output parameters.
Automac Alarm For the informaon about the conguraon, see
Automac Alarm .
Manual Alarm For the informaon about the conguraon, see
Manual Alarm .
3.
Click Save.
Network Camera User Manual
67
Manual Alarm
You can trigger an alarm output manually.
Steps
1.
Set the manual alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Edit a name for the alarm output.
Delay
Select Manual.
2.
Click Manual Alarm to enable manual alarm output.
3.
Oponal: Click Clear Alarm to disable manual alarm output.
Automac Alarm
Set the automac alarm parameters, then the device triggers an alarm output automacally in the
set arming schedule.
Steps
1.
Set automac alarm parameters.
Alarm Output No.
Select the alarm output No. according to the alarm interface connected to the external alarm
device.
Alarm Name
Custom a name for the alarm output.
Delay
It refers to the me duraon that the alarm output remains aer an alarm occurs.
2.
Set the alarming schedule. For the informaon about the sengs, see Set Arming Schedule .
3.
Click Copy to… to copy the parameters to other alarm output channels.
4.
Click Save.
8.2.2 FTP/NAS/Memory Card Uploading
If you have enabled and congured the FTP/NAS/memory card uploading, the device sends the
alarm informaon to the FTP server, network aached storage and memory card when an alarm is
triggered.
Network Camera User Manual
68
Refer to Set FTP to set the FTP server.
Refer to Set NAS for NAS conguraon.
Refer to Set New or Unencrypted Memory Card for memory card storage conguraon.
8.2.3 Send Email
Check Send Email, and the device sends an email to the designated addresses with alarm
informaon when an alarm event is detected.
For email sengs, refer to Set Email .
Set Email
When the email is congured and Send Email is enabled as a linkage method, the device sends an
email nocaon to all designated receivers if an alarm event is detected.
Before You Start
Set the DNS server before using the Email funcon. Go to Conguraon → Network → Basic
Sengs → TCP/IP for DNS sengs.
Steps
1.
Go to email sengs page: Conguraon → Network → Advanced Sengs → Email .
2.
Set email parameters.
1) Input the sender's email informaon, including the Sender's Address, SMTP Server, and
SMTP Port.
2) Oponal: If your email server requires authencaon, check Authencaon and input your
user name and password to log in to the server.
3) Set the E-mail Encrypon.
●
When you select SSL or TLS, and disable STARTTLS, emails are sent aer encrypted by SSL or
TLS. The SMTP port should be set as 465.
●
When you select SSL or TLS and Enable STARTTLS, emails are sent aer encrypted by
STARTTLS, and the SMTP port should be set as 25.
Note
If you want to use STARTTLS, make sure that the protocol is supported by your email server.
If you check the Enable STARTTLS while the protocol is not supported by your email sever,
your email is sent with no encrypon.
4) Oponal: If you want to receive nocaon with alarm pictures, check Aached Image. The
nocaon email has 3 aached alarm pictures about the event with congurable image
capturing interval.
5) Input the receiver's informaon, including the receiver's name and address.
6) Click Test to see if the funcon is well congured.
3.
Click Save.
Network Camera User Manual
69
8.2.4 Nofy Surveillance Center
Check Nofy Surveillance Center, the alarm informaon is uploaded to the surveillance center
when an alarm event is detected.
8.2.5 Trigger Recording
Check Trigger Recording, and the device records the video about the detected alarm event.
For recording sengs, refer to Video Recording and Picture Capture
8.2.6 Flashing Light
Aer enabling Flashing Light and seng the Flashing Light Alarm Output, the light ashes when
an alarm event is detected.
Set Flashing Alarm Light Output
When events occur, the ashing light on the device can be triggered as an alarm.
Steps
1.
Go to Conguraon → Event → Basic Event → Flashing Alarm Light Output .
2.
Set Flashing Duraon, Flashing Frequency and Brightness.
Flashing Duraon
The me that the ashing lasts when one alarm happens.
Flashing Frequency
The rate at which the light ashes. High frequency, medium frequency, low frequency, and
normally on are selectable.
Brightness
The brightness of the light.
3.
Set the arming schedule. See Set Arming Schedule for details.
4.
Click Save.
Note
Only certain device models support the funcon.
8.2.7 Audible Warning
Aer enabling Audible Warning and seng Audible Alarm Output, the built-in speaker of the
device or connected external speaker plays warning sounds when an alarm happens.
For audible alarm output sengs, refer to Set Audible Alarm Output .
Network Camera User Manual
70
Note
The funcon is only supported by certain camera models.
Set Audible Alarm Output
When the device detects targets in the detecon area, audible alarm can be triggered as a
warning.
Steps
1.
Go to Conguraon → Event → Basic Event → Audible Alarm Output .
2.
Select Sound Type and set related parameters.
-
Select Prompt and set the alarm mes you need.
-
Select Warning and its contents. Set the alarm mes you need.
-
Select Custom Audio. You can select a custom audio le from the drop-down list. If no le is
available, you can click Add to upload an audio le that meets the requirement. Up to three
audio les can be uploaded.
3.
Oponal: Click Test to play the selected audio le on the device.
4.
Set arming schedule for audible alarm. See
Set Arming Schedule for details.
5.
Click Save.
Note
The funcon is only supported by certain device models.
Network Camera User Manual
71
Chapter 9 System and Security
It introduces system maintenance, system sengs and security management, and explains how to
congure relevant parameters.
9.1 View Device Informaon
You can view device informaon, such as Device No., Model, Serial No. and Firmware Version.
Enter Conguraon → System → System Sengs → Basic Informaon to view the device
informaon.
9.2 Search and Manage Log
Log helps locate and troubleshoot problems.
Steps
1.
Go to Conguraon → System → Maintenance → Log .
2.
Set search condions Major Type, Minor Type, Start Time, and End Time.
3.
Click Search.
The matched log les will be displayed on the log list.
4.
Oponal: Click Export to save the log les in your computer.
9.3 Simultaneous Login
The administrator can set the maximum number of users logging into the system through web
browser simultaneously.
Go to Conguraon → System → User Management , click General and set Simultaneous Login.
9.4 Import and Export Conguraon File
It helps speed up batch conguraon on other devices with the same parameters.
Enter Conguraon → System → Maintenance → Upgrade & Maintenance . Choose device
parameters that need to be imported or exported and follow the instrucons on the interface to
import or export conguraon le.
Network Camera User Manual
72
9.5 Export Diagnose Informaon
Diagnose informaon includes running log, system informaon, hardware informaon.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance . Check desired
diagnose informaon and click Diagnose Informaon to export corresponding diagnose
informaon of the device.
9.6 Reboot
You can reboot the device via browser.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance , and click Reboot.
9.7 Restore and Default
Restore and Default helps restore the device parameters to the default sengs.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Click Restore or Default according to your needs.
Restore Reset device parameters, except user informaon, IP parameters and video format
to the default sengs.
Default Reset all the parameters to the factory default.
Note
Be careful when using this funcon. Aer reseng to the factory default, all the
parameters are reset to the default sengs.
9.8 Upgrade
Before You Start
You need to obtain the correct upgrade package.
Cauon
DO NOT disconnect power during the process, and the device reboots automacally aer upgrade.
Steps
1.
Go to Conguraon → System → Maintenance → Upgrade & Maintenance .
2.
Choose one method to upgrade.
Firmware Locate the exact path of the upgrade le.
Network Camera User Manual
73
Firmware Directory Locate the directory which the upgrade le belongs to.
3.
Click Browse to select the upgrade le.
4.
Click Upgrade.
9.9 View Open Source Soware License
Go to Conguraon → System → System Sengs → About Device , and click View Licenses.
9.10 Wiegand
Note
This funcon is only supported by certain camera models.
Check Enable and select the protocol. The default protocol is SHA-1 26bit.
If enabled, the recognized license plate number will be output via the selected Wiegand protocol.
9.11 Metadata
Metadata is the raw data that the device collects before algorithm processing. It is oen used for
the third party integraon.
Go to Conguraon → System → Metadata Sengs to enable metadata uploading of the desired
funcon.
Road Trac
The metadata of road trac is detected vehicle informaon, including the vehicle locaon in
the scene, vehicle ID, license plate, validity, moving direcon, country/region, etc.
9.12 Time and Date
You can congure me and date of the device by conguring me zone, me synchronizaon and
Daylight Saving Time (DST).
9.12.1 Synchronize Time Manually
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click Manual Time Sync..
4.
Choose one me synchronizaon method.
Network Camera User Manual
74
-
Select Set Time, and manually input or select date and me from the pop-up calendar.
-
Check Sync. with computer me to synchronize the me of the device with that of the local
PC.
5.
Click Save.
9.12.2 Set NTP Server
You can use NTP server when accurate and reliable me source is required.
Before You Start
Set up a NTP server or obtain NTP server informaon.
Steps
1.
Go to Conguraon → System → System Sengs → Time Sengs .
2.
Select Time Zone.
3.
Click NTP.
4.
Set Server Address, NTP Port and Interval.
Note
Server Address is NTP server IP address.
5.
Click Test to test server connecon.
6.
Click Save.
9.12.3 Synchronize Time by Satellite
Note
This funcon varies depending on dierent devices.
Steps
1.
Enter Conguraon → System → System Sengs → Time Sengs .
2.
Select Satellite Time Sync..
3.
Set Interval.
4.
Click Save.
9.12.4 Set DST
If the region where the device is located adopts Daylight Saving Time (DST), you can set this
funcon.
Steps
1.
Go to Conguraon → System → System Sengs → DST .
2.
Check Enable DST.
Network Camera User Manual
75
3.
Select Start Time, End Time and DST Bias.
4.
Click Save.
9.13 Set RS-485
RS-485 is used to connect the device to external device. You can use RS-485 to transmit the data
between the device and the computer or terminal when the communicaon distance is too long.
Before You Start
Connect the device and computer or termial with RS-485 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-485 .
2.
Set the RS-485 parameters.
Note
You should keep the parameters of the device and the computer or terminal all the same.
3.
Click Save.
9.14 Set RS-232
RS-232 can be used to debug device or access peripheral device. RS-232 can realize communicaon
between the device and computer or terminal when the communicaon distance is short.
Before You Start
Connect the device to computer or terminal with RS-232 cable.
Steps
1.
Go to Conguraon → System → System Sengs → RS-232 .
2.
Set RS-232 parameters to match the device with computer or terminal.
3.
Click Save.
9.15 Power Consumpon Mode
It is used to switch the power consumpon when the device is working.
Note
The funcon is only supported by certain camera models.
Go to Conguraon → System → System Sengs → Power Consumpon Mode , select the
desired power consumpon mode.
Full Consumpon Mode
The device works with all the funcons enabled.
Network Camera User Manual
76
Low Consumpon Real-Time Mode
The device DSP works normally. It records the videos with the main stream at the half frame
rate, and supports the remote login, preview and the conguraon.
Low Power Sleep
When the device power is lower than Threshold of Low Power Sleep Mode, the device enters
sleep mode.
When the device power is recovered to 10% above the threshold, the device enters the user
conguraon mode.
Scheduled Sleep
If the device is during Scheduled Sleep Time, it enters the sleep mode, otherwise it enters the
user conguraon mode.
Note
For the scheduled sleep schedule sengs, see Arming Schedule and Alarm Linkage .
The device supports the ming wake. For the details, see Set Timing Wake .
9.16 External Device
For the device supporng external devices, including the supplement light, wiper on the housing
and the LED light, you can control them via the Web browser when it is used with the housing.
External devices vary with models.
Brightness
Adjust Low Beam Brightness and High Beam Brightness according to the actual scene.
Timing
The LED light will be turned on by the schedule you set. You should set Start Time and End
Time.
Auto
The LED light will be turned on according to the environment illuminaon.
9.16.1 Supplement Light Sengs
You can set supplement light and refer to the actual device for relevant parameters.
Smart Supplement Light
Smart supplement light avoids over exposure when the supplement light is on.
Supplement Light Mode
When the device supports supplement light, you can select supplement light mode.
IR Mode
Network Camera User Manual
77
IR light is enabled.
White Light Mode
White light is enabled.
Mix Mode
Both IR light and white light are enabled.
O
Supplement light is disabled.
Brightness Adjustment Mode
Auto
The brightness adjusts according to the actual environment automacally.
Manual
You can drag the slider or set value to adjust the brightness.
9.16.2 Heater
You can enable heater to remove fog around the lens of the device.
Go to Conguraon → System → System Sengs → External Device and select the mode as
required.
9.17 Security
You can improve system security by seng security parameters.
9.17.1 Authencaon
You can improve network access security by seng RTSP and WEB authencaon.
Go to Conguraon → System → Security → Authencaon to choose authencaon protocol
and method according to your needs.
RTSP Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
RTSP request is sent to the device. If you select digest/basic, it means the device supports
digest or basic authencaon. If you select digest, the device only supports digest
authencaon.
RTSP Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in RTSP authencaon. If you enable the
digest algorithm except for MD5, the third-party plaorm might not be able to log in to the
Network Camera User Manual
78
device or enable live view because of compability. The encrypted algorithm with high strength
is recommended.
WEB Authencaon
Digest and digest/basic are supported, which means authencaon informaon is needed when
WEB request is sent to the device. If you select digest/basic, it means the device supports digest
or basic authencaon. If you select digest, the device only supports digest authencaon.
WEB Digest Algorithm
MD5, SHA256 and MD5/SHA256 encrypted algorithm in WEB authencaon. If you enable the
digest algorithm except for MD5, the third-party plaorm might not be able to log in to the
device or enable live view because of compability. The encrypted algorithm with high strength
is recommended.
Note
Refer to the specic content of protocol to view authencaon requirements.
9.17.2 Set IP Address Filter
IP address lter is a tool for access control. You can enable the IP address lter to allow or forbid
the visits from the certain IP addresses.
IP address refers to IPv4.
Steps
1.
Go to Conguraon → System → Security → IP Address Filter .
2.
Check Enable IP Address Filter.
3.
Select the type of IP address lter.
Forbidden IP addresses in the list cannot access the device.
Allowed Only IP addresses in the list can access the device.
4.
Edit the IP address lter list.
Add Add a new IP address or IP address range to the list.
Modify Modify the selected IP address or IP address range in the list.
Delete Delete the selected IP address or IP address range in the list.
5.
Click Save.
9.17.3 Set HTTPS
HTTPS is a network protocol that enables encrypted transmission and identy authencaon,
which improves the security of remote access.
Network Camera User Manual
79
Steps
1.
Go to Conguraon → Network → Advanced Sengs → HTTPS .
2.
Check Enable to access the camera via HTTP or HTTPS protocol.
3.
Check Enable HTTPS Browsing to access the camera only via HTTPS protocol.
4.
Select the Server Cercate.
5.
Click Save.
Note
If the funcon is abnormal, check if the selected cercate is abnormal in Cercate
Management.
9.17.4 Set QoS
QoS (Quality of Service) can help improve the network delay and network congeson by seng
the priority of data sending.
Note
QoS needs support from network device such as router and switch.
Steps
1.
Go to Conguraon → Network → Advanced Conguraon → QoS .
2.
Set Video/Audio DSCP, Alarm DSCP and Management DSCP.
Note
Network can idenfy the priority of data transmission. The bigger the DSCP value is, the higher
the priority is. You need to set the same value in router while conguraon.
3.
Click Save.
9.17.5 Set IEEE 802.1X
IEEE 802.1x is a port-based network access control. It enhances the security level of the LAN/
WLAN. When devices connect to the network with IEEE 802.1x standard, the authencaon is
needed.
Go to Conguraon → Network → Advanced Sengs → 802.1X , and enable the funcon.
Set Protocol and EAPOL Version according to router informaon.
Protocol
EAP-LEAP, EAP-TLS, and EAP-MD5 are selectable
EAP-LEAP and EAP-MD5
Network Camera User Manual
80
If you use EAP-LEAP or EAP-MD5, the authencaon server must be congured. Register a
user name and password for 802.1X in the server in advance. Input the user name and
password for authencaon.
EAP-TLS
If you use EAP-TLS, input Idenfy, Private Key Password, and upload CA Cercate, User
Cercate and Private Key.
EAPOL Version
The EAPOL version must be idencal with that of the router or the switch.
9.17.6 Control Timeout Sengs
If this funcon is enabled, you will be logged out when you make no operaon (not including
viewing live image) to the device via web browser within the set meout period.
Go to Conguraon → System → Security → Advanced Security to complete sengs.
9.17.7 Search Security Audit Logs
You can search and analyze the security log les of the device so as to nd out the illegal intrusion
and troubleshoot the security events.
Steps
Note
This funcon is only supported by certain camera models.
1.
Go to Conguraon → System → Maintenance → Security Audit Log .
2.
Select log types, Start Time, and End Time.
3.
Click Search.
The log les that match the search condions will be displayed on the Log List.
4.
Oponal: Click Export to save the log les to your computer.
9.17.8 Security Reinforcement
Security reinforce is a soluon to enhance network security. With the funcon enabled, risky
funcons, protocols, ports of the device are disabled and more secured alternave funcons,
protocols and ports are enabled.
Go to Conguraon → System → Security → Advanced Security . Check Security Reinforcement,
and click Save.
Network Camera User Manual
81
9.17.9 SSH
Secure Shell (SSH) is a cryptographic network protocol for operang network services over an
unsecured network.
The SSH funcon is disabled by default.
Cauon
Use the funcon with cauon. The security risk of device internal informaon leakage exists when
the funcon is enabled.
9.18 Cercate Management
It helps to manage the server/client cercates and CA cercate, and to send an alarm if the
cercates are close to expiry date, or are expired/abnormal.
Note
The funcon is only supported by certain device models.
9.18.1 Create Self-signed Cercate
Steps
1.
Click Create Self-signed Cercate.
2.
Follow the prompt to enter Cercate ID, Country/Region, Hostname/IP, Validity and other
parameters.
Note
The cercate ID should be digits or leers and be no more than 64 characters.
3.
Click OK.
4.
Oponal: Click Export to export the cercate, or click Delete to delete the cercate to
recreate a cercate, or click Cercate Properes to view the cercate details.
9.18.2 Create Cercate Request
Before You Start
Select a self-signed cercate.
Steps
1.
Click Create Cercate Request.
2.
Enter the related informaon.
3.
Click OK.
Network Camera User Manual
82
9.18.3 Import Cercate
Steps
1.
Click Import.
2.
Click Create Cercate Request.
3.
Enter the Cercate ID.
4.
Click Browser to select the desired server/client cercate.
5.
Select the desired import method and enter the required informaon.
6.
Click OK.
7.
Oponal: Click Export to export the cercate, or click Delete to delete the cercate to
recreate a cercate, or click Cercate Properes to view the cercate details.
Note
●
Up to 16 cercates are allowed.
●
If certain funcons are using the cercate, it cannot be deleted.
●
You can view the funcons that are using the cercate in the funcons column.
●
You cannot create a cercate that has the same ID with that of the exisng cercate and
import a cercate that has the same content with that of the exisng cercate.
9.18.4 Install Server/Client Cercate
Steps
1.
Go to Conguraon → System → Security → Cercate Management .
2.
Click Create Self-signed Cercate, Create Cercate Request and Import to install server/client
cercate.
Create self-signed cercate Refer to
Create Self-signed Cercate
Create cercate request Refer to
Create Cercate Request
Import Cercate Refer to
Import Cercate
9.18.5 Install CA Cercate
Steps
1.
Click Import.
2.
Enter the Cercate ID.
3.
Click Browser to select the desired server/client cercate.
4.
Select the desired import method and enter the required informaon.
5.
Click OK.
Network Camera User Manual
83
Note
Up to 16 cercates are allowed.
9.18.6 Enable Cercate Expiraon Alarm
Steps
1.
Check Enable Cercate Expiraon Alarm. If enabled, you will receive an email or the camera
links to the surveillance center that the cercate will expire soon, or is expired or abnormal.
2.
Set the Remind Me Before Expiraon (day), Alarm Frequency (day) and Detecon Time (hour).
Note
●
If you set the reminding day before expiraon to 1, then the camera will remind you the day
before the expiraon day. 1 to 30 days are available. Seven days is the default reminding days.
●
If you set the reminding day before expiraon to 1, and the detecon me to 10:00, and the
cercate will expire in 9:00 the next day, the camera will remind you in 10:00 the rst day.
3.
Click Save.
9.19 User and Account
9.19.1 Set User Account and Permission
The administrator can add, modify, or delete other accounts, and grant dierent permission to
dierent user levels.
Cauon
To increase security of using the device on the network, please change the password of your
account regularly. Changing the password every 3 months is recommended. If the device is used in
high-risk environment, it is recommended that the password should be changed every month or
week.
Steps
1.
Go to Conguraon → System → User Management → User Management .
2.
Click Add. Enter User Name, select Level, and enter Password. Assign remote permission to
users based on needs.
Administrator
The administrator has the authority to all operaons and can add users and operators and
assign permission.
User
Network Camera User Manual
84
Users can be assigned permission of viewing live video, seng PTZ parameters, and changing
their own passwords, but no permission for other operaons.
Operator
Operators can be assigned all permission except for operaons on the administrator and
creang accounts.
Modify Select a user and click Modify to change the password and permission.
Delete Select a user and click Delete.
Note
The administrator can add up to 31 user accounts.
3.
Click OK.
9.19.2 Simultaneous Login
The administrator can set the maximum number of users logging into the system through web
browser simultaneously.
Go to Conguraon → System → User Management , click General and set Simultaneous Login.
9.19.3 Online Users
The informaon of users logging into the device is shown.
Go to Conguraon → System → User Management → Online Users to view the list of online
users.
Network Camera User Manual
85
Chapter 10 Allocate VCA Resource
VCA resource oers you opons to enable certain VCA funcons according to actual needs. It helps
allocate more resources to the desired funcons.
Steps
1.
Go to Conguraon → System → System Sengs → VCA Resource .
2.
Select desired VCA funcon.
3.
Save the sengs.
Note
Some VCA funcons are mutually exclusive. When certain funcon or funcons are selected and
saved, others will not be hidden.
10.1 Counng
It helps to calculate the number of people entering or exing a certain congured area.
Note
Counng is only supported by certain models.
10.1.1 Set Counng
It is used to calculate the objects entering and exing the region, alarm events, and upload data.
Steps
1.
Go to Conguraon → Counng .
2.
Check Enable Counng.
3.
Oponal: Check Enable OSD Overlay, and the real-me number of people entering and exing
the region is displayed on the live video.
Note
The overlay informaon only counts the number of the current day. The number is cleared when
the device is restarted or midnight comes. You can also click to clear the number manually.
4.
Set the detecon line and the objects across the line will be detected and counted.
Draw a detecon line.
Delete the detecon line.
Change the direcon.
Network Camera User Manual
86
Figure 10-1 Set Counng
5.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
6.
Click Save.
10.1.2 View Counng Stascs
You can view and export the counng stascs stored in device or memory card.
Before You Start
Go to
Set Counng to set queue management rst.
Steps
1.
Go to Applicaon.
2.
Select Report Type.
3.
Select Stascs Type.
4.
Select Start Time.
5.
Click Counng.
6.
Oponal: Click Export to export the counng stascs.
The counng stascs can be viewed in table, line chart, and bar chart.
10.2 Face Capture
The device can capture the face that appears in the congured area, and the face informaon will
be uploaded with the captured picture as well.
Network Camera User Manual
87
Note
●
For device that supports face capture, you need to enable the funcon in VCA Resource. Refer to
Allocate VCA Resource for details.
●
Face capture is only supported by certain models.
10.2.1 Set Face Capture
The face that appears in the congured area can be captured.
Before You Start
To enable the funcon, go to VCA Resource and select Face Capture.
Steps
1.
Go to Conguraon → Face Capture .
2.
For shield region sengs, refer to Set Shield Region .
3.
Select Rule and check Rule.
4.
Input the min. pupil distance in the text eld, or click to draw the min. pupil distance.
Min. Pupil Distance
The min. pupil distance refers to the minimum area between two pupils, and it is basic for the
device to recognize a face.
5.
Input the max. pupil distance in the text eld, or click to draw the max. pupil distance.
6.
Click to draw the detecon area you want the face capture to take eect. Draw area by le-
clicking end-points in the live view window, and right-clicking to nish the area drawing. It is
recommended that the drawn area occupies 1/2 to 2/3 of the live view image.
7.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
8.
Click Save.
9.
For overlay and capture sengs, refer to Overlay and Capture . For advanced parameters
sengs, refer to Face Capture Algorithms Parameters .
Result
You can view and download captured face images in Picture. Refer to
View and Download Picture
for details.
10.2.2 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Network Camera User Manual
88
Display Target info. on Alarm Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
Custom, Head Shot, Half-Body Shot and Full-Body Shot are selectable.
Note
If you select Custom, you can customize width, head height and body height as required.
You can check Fixed Value to set the picture height.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon. If the background image
need to be uploaded to surveillance center, check Background Upload.
People Counng Overlay
Select ow overlay type.
Select the daily reset me. Click Manual Reset if you want to reset right now.
Camera
You can set Device No. and Camera Info. for the camera, which can be overlaid on captured
picture.
Text Overlay
You can check desired items and adjust their order to display on captured pictures by .
The content of Device No. and Camera Info should be on the same page.
10.2.3 Face Capture Algorithms Parameters
It is used to set and opmize the parameters of the algorithm library for face capture.
Go to Conguraon → Face Capture → Advanced Conguraon → Parameters .
Face Capture Version
It lists the version of the algorithms library.
Detecon Parameters
Generaon Speed
The speed to idenfy a target. The higher the value, the faster the target will be recognized.
Seng the value quite low, and if there was a face in the congured area from the start, this
face will not be captured. It can reduce the misinformaon of the faces in the wall painng or
posters. The default value of 3 is recommended.
Sensivity
Network Camera User Manual
89
The sensivity to idenfy a target. The higher the value is, the easier a face will be recognized,
and the higher possibility of misinformaon would be. The default value of 3 is recommended.
Capture Parameters
Best Shot
The best shot aer target leave the detecon area.
Capture Times
It refers to the capture mes a face will be captured during its stay in the congured area. The
default value is 1.
Capture Threshold
It stands for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Quick Shot
You can dene quick shot threshold and max. capture interval.
Quick Shot Threshold
It stands for the quality of face to trigger quick shot.
Face Exposure
Check the checkbox to enable the face exposure.
Reference Brightness
The reference brightness of a face in the face exposure mode. If a face is detected, the camera
adjusts the face brightness according to the value you set. The higher the value, the brighter the
face is.
Minimum Duraon
The minimum duraon of the camera exposures the face.
Note
If the face exposure is enabled, please make sure the WDR funcon is disabled, and the manual
iris is selected.
Face Filtering Time
It means the me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Note
The face ltering me (longer than 0s) may increase the possibility of the actual capture mes
less than the set value above.
Network Camera User Manual
90
Restore Default
Click Restore to restore all the sengs in advanced conguraon to the factory default.
10.2.4 Set Shield Region
The shield region allows you to set the specic region in which the set smart funcon rule is
invalid.
Steps
1.
Select Shield Region.
2.
Click to draw shield area. Repeat this step above to set more shield regions.
3.
Oponal: Click to delete the drawn areas.
4.
Click Save.
10.3 Mul-Target-Type Detecon
Mul-Target-Type Detecon is to detect, capture and upload data of targets in mulple types, such
as human face, human body, and vehicle.
Note
●
The funcon is only supported by certain device models.
●
For certain device models, you need to enable Mul-Target-Type Detecon on VCA Resource
page rst.
10.3.1 Set Mul-Target-Type Detecon Rule
Aer seng the mul-target-type detecon rules and algorithm parameters, the device captures
targets of mulple types and triggers linkage acons automacally.
Steps
1.
Go to Conguraon → Mul-Target-Type Detecon → Rule .
2.
Check Rule.
3.
Click , and draw a detecon area on live image.
4.
Enter the min. pupil distance in the text eld, or click to draw min. pupil distance.
Min. Pupil Distance
The min. pupil distance refers to the minimum area between two pupils, and it is basic for the
device to recognize a face.
5.
Set arming schedule. See Set Arming Schedule .
6.
Set linkage method. See
Linkage Method Sengs .
7.
Click Save.
Network Camera User Manual
91
What to do next
Go to Picture to search and view the captured pictures.
Go to Smart Display to see currently captured target pictures.
10.3.2 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Display Target info. on Alarm Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
Custom, Head Shot, Half-Body Shot and Full-Body Shot are selectable.
Note
If you select Custom, you can customize width, head height and body height as required.
You can check Fixed Value to set the picture height.
Background Picture Sengs
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon. If the background image
need to be uploaded to surveillance center, check Background Upload.
People Counng Overlay
Select ow overlay type.
Select the daily reset me. Click Manual Reset if you want to reset right now.
Camera
You can set Device No. and Camera Info. for the camera, which can be overlaid on captured
picture.
Text Overlay
You can check desired items and adjust their order to display on captured pictures by .
The content of Device No. and Camera Info should be on the same page.
10.3.3 Mul-Target-Type Detecon Algorithm Parameters
It is used to set and opmize the parameters of the algorithm library for Mul-Target-Type
Detecon.
Network Camera User Manual
92
Go to the Conguraon → Mul-Target-Type Detecon → Advanced Conguraon for
conguraon.
HMS Version
It refers to the current algorithm version, which cannot be edited.
Restore Defaults
Click Restore to restore all the sengs in advanced conguraon to the factory default.
Detecon Parameters
Generaon Speed
It is the speed of deciding whether an object in detecon area is a target or not. The higher the
value is, the faster the target will be detected. The default value is recommended.
Sensivity
It is the sensivity of recognizing a target. The higher the value is, the easier a target will be
recognized, and the higher possibility of misinformaon would be. The default value is
recommended.
Capture Parameters
Best Shot
Capture Threshold
It refers for the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Face Exposure
Enable the funcon, and the device automacally adjusts exposure level when human faces
appear in the scene.
Reference Brightness
It refers to the reference brightness of a face in the face exposure mode. If a face in the
actual scene is brighter than the set reference brightness, the device lower the exposure
level. If a face in the actual scene is darker than the set reference, the device increases the
exposure level.
Minimum Duraon
The extra me the device keeps the face exposure level aer the face disappears in the
scene.
Face Filtering Time
It means the me interval between the camera detecng a face and taking a capture acon. If
the detected face stays in the scene for less than the set ltering me, capture will not be
triggered. For example, if the face ltering me is set as 5 seconds, the camera will capture the
detected face when the face keeps staying in the scene for 5 seconds.
Network Camera User Manual
93
10.3.4 Set Shield Region
The shield region allows you to set the specic region in which the set smart funcon rule is
invalid.
Steps
1.
Select Shield Region.
2.
Click to draw shield area. Repeat this step above to set more shield regions.
3.
Oponal: Click to delete the drawn areas.
4.
Click Save.
10.4 Queue Management
It is used to count queuing-up people number and waing me of each person.
Note
Queue management is only supported by certain models.
10.4.1 Set Regional People Queuing-Up
It is used to count queuing-up persons in dened regions. Alarms are triggered when the alarm
threshold condion and the alarm trigger are both met.
Before You Start
To enable the funcon, go to VCA Resource, and select Queue Management.
Steps
1.
Go to Conguraon → Queue Management .
2.
Select Regional People Queuing-Up.
3.
Click Add Region to draw the detecon area and set Region Name and Alarm Interval. Repeat
this step above to set more areas.
Alarm Interval
During the set alarm interval, alarms of the same type only trigger one nocaon.
Network Camera User Manual
94
Figure 10-2 Set Regional People Queuing-Up
4.
Oponal: Check OSD to display the region name and its real-me queuing-up people number.
5.
Set Alarm threshold. An alarm is triggered when the alarm threshold condion is met.
6.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
7.
Click Save.
10.4.2 Set Waing Time Detecon
It is used to count the waing me of each person that enters the detecon area. Alarms are
triggered when the alarm threshold condion and the alarm trigger are both met.
Before You Start
To enable the funcon, go to VCA Resource, and select Queue Management.
Steps
1.
Go to Conguraon → Queue Management .
2.
Select Waing Time Detecon.
3.
Click Add Region to draw the detecon area and set Region Name and Alarm Interval. Repeat
this step above to set more areas.
Alarm Interval
During the set alarm interval, alarms of the same type only trigger one nocaon
Network Camera User Manual
95
Figure 10-3 Set Waing Time Detecon
4.
Set Alarm threshold. An alarm is triggered when the alarm threshold condion is met.
5.
For the arming schedule sengs, refer to Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
6.
Click Save.
7.
Oponal: Enable Display POS Informaon and Rule in Conguraon → Local .
The detecon area and the me people staying in the detecon area can be viewed on the live
view.
10.4.3 Queue Management Stascs
Queue management supports data analysis and report output.
Before You Start
For queue management sengs, refer to Set Regional People Queuing-Up and Set Waing Time
Detecon .
●
Select Queuing-Up Time Analysis and Regional Comparison to compare queuing-up people
number of dierent regions.
●
Select Queuing-Up Time Analysis and Mul-Level Comparison to compare queuing-up people
number of dierent waing me levels.
●
Select Queue Status Analysis and Regional Comparison to compare the me and duraon that a
queue stays at a certain length in dierent regions.
●
Select Queue Status Analysis and Mul-Level Comparison to compare the me and duraon of
the queue at dierent queue length levels.
Network Camera User Manual
96
Steps
Note
With an on-board memory card installed, the device can save up to one mouth's data. With NO
memory card installed, the device can only save up to one week's data.
1.
Select the analysis mode.
Queuing-Up Time Analysis
Queuing-Up me analysis calculates people number of dierent waing me levels.
Queue Status Analysis
Queue status analysis calculates the me and duraon that a queue stays a certain length.
2.
Select Stasc Type.
Regional Comparison
Mulple regions and one level can be selected for analysis, and an analysis chart can be
drawn.
Mul-Level Comparison
Mulple levels and regions can be selected for analysis, and one analysis chart is drawn for
each region.
3.
Check one or more regions.
4.
Set the queue length level. Check one or more desired range checkboxes and input values.
5.
Select Report Type and Stascs Time.
6.
Click Counng to generate the report.
10.5 Face Counng
Face counng detecon can remove the duplicate faces and calculate the number of objects
entered or exited a certain congured area.
Note
●
For certain device models, you need to select Face Counng on VCA Resource page rst.
●
Only certain camera models support this funcon.
10.5.1 Set Face Counng Detecon Rule
Aer seng the face counng detecon rules and algorithm parameters, the device captures
targets and triggers linkage acons automacally.
Steps
1.
Go to Conguraon → Face Counng → Rule .
2.
Check Rule.
Network Camera User Manual
97
3.
Enter the min. pupil distance in the text eld, or click to draw the min. pupil distance. The
distance of the drawn pupil will be displayed on the box below the live view.
Min. Pupil Distance
The min. pupil distance refers to the minimum square size composed by the area between
two pupils, and it is the basic standard for a camera to idenfy a target.
4.
Enter the max. pupil distance in the text eld, or click to draw the max. pupil distance.
Max. Pupil Distance
The max. pupil distance refers to the maximum square size composed by the area between
two pupils, and it is the basic standard for a camera to idenfy a target.
5.
Click to draw the detecon area. Draw an area by le-clicking end-points in the live view
window, and right-clicking to nish the area drawing.
6.
Click to draw the detecon line. The arrow shows entering direcon, you can click to
change the direcon.
●
If the target crosses the counng area along the entering direcon and crosses the detecon
line, then it is counted as the entering number.
●
If the target crosses the counng area along the exing direcon and crosses the detecon
line, then it is counted as the exing number.
7.
Click and to draw region A and B. Make sure the two areas don't overlap. You can click
to change the direcon.
●
If the target enters from A region to B region, then it is counted as the entering number.
●
If the target enters from B region to A region, then it is counted as the exing number.
8.
Set arming schedule. See Set Arming Schedule .
9.
Set linkage method. See Linkage Method Sengs .
10.5.2 Overlay and Capture
Choose to congure capture parameters and the informaon you want to display on stream and
picture.
Display VCA info. on Stream
Display smart informaon on stream, including the target and rules informaon.
Display Target info. on Alarm Picture
Overlay the alarm picture with target informaon.
Target Picture Sengs
Custom, Head Shot, Half-Body Shot and Full-Body Shot are selectable.
Note
If you select Custom, you can customize width, head height and body height as required.
You can check Fixed Value to set the picture height.
Background Picture Sengs
Network Camera User Manual
98
Comparing to target picture, background picture is the scene image oers extra environmental
informaon. You can set the background picture quality and resoluon. If the background image
need to be uploaded to surveillance center, check Background Upload.
People Counng Overlay
Select ow overlay type.
Select the daily reset me. Click Manual Reset if you want to reset right now.
Camera
You can set Device No. and Camera Info. for the camera, which can be overlaid on captured
picture.
Text Overlay
You can check desired items and adjust their order to display on captured pictures by .
The content of Device No. and Camera Info should be on the same page.
10.5.3 Face Counng Algorithm Parameters
It is used to set and opmize the parameters of the algorithm parameters for Face Counng.
Note
These funcons vary according to dierent models.
Face Capture Mode
It refers to the current algorithm version, which cannot be edited.
Best Shot
The best shot aer the target leaves the detecon area.
Capture Times
It refers to the capture mes a face will be captured during its stay in the congured area.
The default value is 1.
Capture Threshold
It refers to the quality of face to trigger capture and alarm. Higher value means beer quality
should be met to trigger capture and alarm.
Face Exposure
The device adjusts the face brightness when it detects face in the image.
Reference Brightness
The reference brightness of a face in the face exposure mode. If a face is detected, the camera
adjusts the face brightness according to the value you set. The higher the value, the brighter the
face is.
Min. Duraon
Network Camera User Manual
99
The minimum duraon of the camera exposes the face.
Note
If the face exposure is enabled, make sure the WDR funcon is disabled, and the manual iris is
selected.
Real-Time Update Data
Aer enabled, the real-me people counng data will be uploaded to the plaorm.
Data Stascs Cycle
Select the data stascs cycle as required.
Algorithm Validity
The higher the value is, the more dicult it is to detect the target, but the higher the detecon
accuracy would be.
Restore Defaults
Click Restoreto restore all the sengs in advanced conguraon to the factory defaults.
10.5.4 View Face Counng Result
Steps
1.
Go to Applicaon.
2.
Set search condion and click Counng.
Matched results are shown in Face Picture Comparison Stascs and People Counng
Stascsarea.
10.6 Face Picture Comparison and Modeling
For certain device models, you need to enable Mul-Target-Type Detecon or Face Capture on
VCA Resource page rst.
Note
The funcon is only supported by certain device models.
10.6.1 Face Picture Comparison
Face picture comparison serves the purpose of face recognion by comparing the captured face
pictures with those in face picture library.
Network Camera User Manual
100
Set Face Picture Library
Face picture library is used to store modeled human faces and informaon.
Steps
1.
Go to Conguraon → Face Picture Library .
2.
Create a face picture library.
1) Click to add a face picture library.
2) Input library name, threshold and remarks.
Threshold
Face similarity higher than the set threshold triggers face picture comparison alarm
uploading.
3) Click OK.
4) Oponal: Modify a face picture library. Select the desired library and click and change
related parameters.
5) Oponal: Delete a library. Select the desired library and click .
3.
Add face pictures to the library.
Note
The picture format should be JPEG, and the size no larger than 300 KB per le.
Add one face
Click Add and upload the face picture with detailed face informaon.
Import face
pictures in
batch
Click Import and select picture path.
Note
●
When you import face pictures in batch, the picture name is saved as the
face name. For other face informaon, you should modify one by one
manually.
●
The vericaon code for exporng and imporng should be a
combinaon of 8 to 16 digits, containing numerics, upper case and lower
case leers.
4.
Oponal: Modify face informaon.
1) Select a face picture library.
2) Select the target face picture. You can use the search funcon to locate the picture by
inpung search condions, and click Search.
3) Click Modify.
4) Edit detailed informaon.
Note
Face picture is not allowed to change.
5) Click OK.
Network Camera User Manual
101
5.
Create models for each face picture in library.
Modeling process builds up face model for each face picture. Face model is required for face
picture comparison to take eect.
Modeling Select one or more face pictures, and click Modeling.
Batch Modeling Select a face picture library, and click Batch Modeling.
6.
Oponal: Repeat to create more face libraries.
7.
Click Save.
Set Face Picture Comparison
The funcon compares captured pictures with face pictures in library and outputs comparison
result. Comparison result can trigger certain acons when arming schedule and linkage method are
set.
Before You Start
You should rst create a face picture library and add face pictures. See
Set Face Picture Library .
Steps
1.
Go to Conguraon → Comparison and Modeling .
2.
Select Face Picture Comparison.
3.
Check Enable Face Picture Comparison.
4.
Select a face picture library as the reference.
5.
Select desired informaon to upload.
6.
Select a comparison mode.
Best
Comparison
The device captures and compares the target face connuously when the
face target stays in the detecon area, and upload the best scored face
picture and related alarm informaon when the target face leaves the area.
Quick
Comparison
The device capture and compares the target face when the face grading
exceeds the set Face Grading Threshold for Capture.
Face Grading Threshold for Capture
The face grading threshold for the device to judge whether to capture and
upload the face or not.
Max. Capture Interval
The max. interval between two captures when the target is in the
detecon area. The camera takes the capture when it reaches the max.
interval even if the face grading does not reach the set threshold.
Quick Setup Mode
Select the mode according to actual using scenarios. In custom mode, you
can set Comparison Timeout and Comparison Times.
7.
Set arming schedule. See
Set Arming Schedule .
Network Camera User Manual
102
8.
Set linkage method. See Linkage Method Sengs .
View Face Picture Comparison Result
Steps
1.
Go to Applicaon.
2.
Set search condion and click Counng.
Matched results are shown in Face Picture Comparison Stascs area.
10.6.2 Face Modeling
Face modeling serves the purpose of collecng face pictures, creang face models and uploading
data to the surveillance center.
Before You Start
Face Capture or Mul-Target-Type detecon should be congured for face picture collecon. See
Face Capture or Mul-Target-Type Detecon for conguraon instrucons.
Steps
1.
Go to Conguraon → Comparison and Modeling .
2.
Select Face Modeling to start.
3.
Check Enable Face Modeling.
4.
Set parameters for modeling.
Report Face Modeling Informaon in Mul-Target-Type Capture Alarm
When a person triggers the mul-target-type detecon, the alarm informaon includes the
face modeling informaon of the detected face if checked.
Quick Capture
The device starts face modeling when it detects a face which scores higher than the set face
grading threshold for capture.
Face Grading Threshold for Capture
The face grading threshold for the device to judge whether to capture and upload the face or
not. Higher value means beer picture quality.
Max. Capture Interval
The max. interval between two captures when the target is in the detecon area. The camera
takes the capture when it reaches the max. interval even if the face grading does not reach
the set threshold.
5.
Set arming schedule. See Set Arming Schedule .
6.
Set linkage method. See Linkage Method Sengs .
Network Camera User Manual
103
10.7 Hard Hat Detecon
This funcon detects targets in the set monitoring region who do not wear the hard hat and
triggers an alarm.
Note
Only certain device models support the funcon.
10.7.1 Set Hard Hat Detecon
Before You Start
Go to Conguraon → System → System Sengs → VCA Resources to enable Hard Hat
Detecon.
Steps
1.
Go to Conguraon → Hard Hat Detecon , and check Enable Hard Hat Detecon.
2.
Oponal: Set Target Generaon Speed.
Target Generaon Speed
It refers to the target generaon speed of the face entering the detecon region. The greater
the value is, the quicker the generaon speed is.
3.
Set detecon region.
1) Select detecon region.
2) Click Draw Area, and click and draw the endpoints of the region in the live view image.
3) Right click to nish the drawing.
Click Stop Drawing Finish drawing the region.
Click Clear All Draw the region again.
4.
For the arming schedule sengs, refer to
Set Arming Schedule . For the linkage method sengs,
refer to Linkage Method Sengs .
5.
Click Save.
10.8 Road Trac
Motor vehicle, non-motor vehicle, and pedestrian can be detected and captured when they enter
the set lane and the relevant informaon together with the captured picture will be uploaded.
Note
Only certain device models support this funcon.
Network Camera User Manual
104
10.8.1 Set Vehicle Detecon
The vehicle that enters the set lane can be detected and the picture of the vehicle and its license
plate can be captured and stored. Alarm will be triggered and capture can be uploaded.
Before You Start
Go to Conguraon → System → System Sengs → VCA Resources , and select Road Trac.
Steps
1.
Go to Conguraon → Road Trac → Detecon Conguraon , and select Vehicle Detecon as
detecon type.
2.
Check Enable.
3.
Select the lane number.
4.
Click and drag the lane line to set its posion, or click and drag the line end to adjust the length
and angle of the line.
5.
Adjust the zoom rao of the camera so that the size of the vehicle in the image is close to that of
the red frame. Only the posion of red frame is adjustable.
Note
Only 1 license plate can be captured at one me for each lane.
6.
Select Region and Country/Region.
7.
Select the license plate informaon upload mode.
Entrance/Exit The license plate informaon of the detected vehicle will be uploaded when
the vehicle passes the detecon area and triggers the detecon in entrance/
exit.
City Street The license plate informaon of the detected vehicle will be uploaded when
the vehicle passes the detecon area and triggers the detecon in city
streets.
Alarm Input It means the input alarm will trigger a license plate capture and recognion
acon.
Note
●
When Alarm Input is selected, the alarm input A<-1 will automacally be assigned to trigger
vehicle detecon and its alarm type is always NO.
●
If the A<-1 alarm input is used to trigger vehicle detecon, it can not be used for other basic
events.
●
When Alarm Input is selected and saved, previously congured linkage method for A<-1 will
be canceled.
8.
Select the Detecon mode.
9.
Check Remove Duplicated License Plates ans set the Time Interval. The default me interval is 4
minutes.
Network Camera User Manual
105
Note
Up to 8 license plates are supported.
10.
Set arming schedule and linkage method. For the arming schedule sengs, refer to Set Arming
Schedule . For the linkage method sengs, refer to Linkage Method Sengs .
11.
Click Save.
10.8.2 Set Mixed-Trac Detecon Rule
The motor vehicle, non-motor vehicle, and pedestrian that enter the set lane can be detected, and
the picture of targets can be captured and stored. Alarm will be triggered and capture can be
uploaded.
Before You Start
Go to Conguraon → System → System Sengs → VCA Resources , and select Road Trac.
Steps
1.
Go to Conguraon → Road Trac → Detecon Conguraon , and select Mixed-trac
Detecon as detecon type.
2.
Check Enable.
3.
Select the lane number.
4.
Select Region and Country/Region.
5.
Set arming schedule and linkage method. For the arming schedule sengs, refer to Set Arming
Schedule . For the linkage method sengs, refer to Linkage Method Sengs .
6.
Click Save.
10.8.3 Uploading Pictures Sengs
You can set the image parameters of the captured images in vehicle detecon and mixed-trac
detecon.
Go to Conguraon → Road Trac → Picture .
Picture Quality
The larger the value is, the clearer the picture is, but larger storage space is also required.
Picture Size
The larger the value is, the larger the storage space is needed. And the level of network
transmission requirement is also higher.
License Plate Enhancement
The larger the value is, the clearer the license plate is, but larger storage space is also required.
Check License Plate Enhancement and set the level. The default level is 50.
Overlay
Network Camera User Manual
106
You can overlay camera, device or vehicle informaon on the captured image and click to
adjust the order of overlay texts.
For camera sengs, go to Conguraon → Road Trac → Camera to set relevant parameters
and click Save.
10.8.4 Camera Sengs
You can set the parameters of each camera for beer management.
Go to Conguraon → Road Trac → Camera to set relevant parameters and click Save.
10.8.5 Import or Export Blocklist & Allowlist
You can import and export the blocklist and allowlist as desired, and check the list content in this
interface.
Steps
1.
Click Browse to open the PC local directory.
2.
Find the blocklist & allowlist le and click to select it. Click Open to conrm.
Note
●
The le to import should corresponds with the le template that is required by the camera.
You are recommended to export an empty blocklist & allowlist le from the camera as the
template and ll in the content.
●
The le should be in the .xls format and the cell format should be Text.
3.
Click Import to import the selected le.
4.
Click Export to open the PC local directory.
5.
Select a directory in your PC local directory.
6.
Name the le in the le name text led.
7.
Click Save.
Network Camera User Manual
107
Chapter 11 Open Plaorm
Open plaorm allows you to install the applicaon for the third-party to develop and run its
funcon and service.
Note
Only certain device models support the funcon.
11.1 Set Open Plaorm
Steps
1.
Go to Conguraon → Open Plaorm .
Note
Before installing the applicaon, please read the Disclaimer at the boom and make sure that
the applicaon you want to install t the following condions.
●
Each applicaon has its own exclusive name.
●
The FLASH memory space that the applicaon takes up is less than the available FLASH
memory space of the device.
●
The memory and compung power of the applicaon is less than that available memory and
compung power of the device.
2.
In Install Apps, click Browse and select the imported applicaon package.
3.
Click Import to complete the installaon.
Figure 11-1 Open Plaorm
Network Camera User Manual
108
The installed applicaons and their related informaon are displayed in Applicaon List, such as
applicaon name, operaon, version, memory used, ash used, company, status and license.
4.
Oponal: Set applicaon.
Export log.
Set permission.
Delete the applicaon.
Enable or disable the applicaon.
5.
Oponal: In applicaon display, click Browse and import the applicaon cercate.
Network Camera User Manual
109
Chapter 12 Smart Display
It can display the captured pictures when enabling smart funcons.
Note
The funcon is only supported by certain device models.
Layout Preview
Click and select Layout Preview. Select the contents according to your needs. When you select
real-me analysis, you can select the contents only for real-me analysis.
Detecon Aribute
Click and select Detecon Aribute. When you enable this funcon, the aribute informaon of
target analysis can be displayed and the informaon you select will be displayed in the aribute
analysis area.
Network Camera User Manual
110
Chapter 13 EPTZ
EPTZ (Electronic PTZ) is a high-resoluon funcon that digitally zooms and pans into porons of the
image, with no physical camera movement. If you want to use the EPTZ funcon, make sure you
have select the Fourth Stream in the live view. Fourth stream and EPTZ should be both enabled
simultaneously.
Note
The funcon is only supported by certain device models.
13.1 Patrol
Steps
1.
Go to Conguraon → EPTZ .
2.
Check Enable EPTZ.
3.
Check Fourth Stream.
4.
Select Patrol in Applicaon.
5.
Click Save.
What to do next
For the detailed informaon about the patrol sengs, see the PTZ operaons on live view page.
13.2 Auto-Tracking
Steps
1.
Go to Conguraon → EPTZ .
2.
Check Enable EPTZ.
3.
Check Fourth Stream.
4.
Select Auto-tracking in Applicaon.
5.
Click Detecon Area to start drawing.
6.
Click on the live video to specify the four vertexes of the detecon area, and right click to
complete drawing.
7.
Set rules.
Detecon
Target
Human and vehicle are available. If the detecon target is not selected, all the
detected targets will be tracked, including the human and vehicle.
Note
Only certain camera models support this funcon.
Network Camera User Manual
111
Sensivity It stands for the percentage of the body part of an acceptable target that is
tracked. Sensivity = 100 - S1/ST × 100. S1 stands for the target body part that
enters the pre-dened area. ST stands for the complete target body. The
higher the value of sensivity is, the more easily the target can be tracked.
8.
Click Save.
Network Camera User Manual
112
UD22864B-D
