Axis Q6078-E Outdoor 4K PTZ Camera User Manual

AXISQ6078-EPTZCamera

UserManual

AXISQ6078-EPTZCamera

TableofContents

Getstarted................................................3

Findthedeviceonthenetwork....................................3

Accessthedevice...............................................3

Webpageoverview..............................................5

Additionalsettings..........................................7

Adjusttheimage................................................7

Adjustthecameraview(PTZ)......................................12

Viewandrecordvideo............................................12

Setuprulesandalerts...........................................13

Learnmore................................................18

Cleaningrecommendations.......................................18

Bitratecontrol..................................................18

Capturemodes.................................................20

Privacymasks..................................................20

Overlays.......................................................20

Pan,tilt,andzoom(PTZ)..........................................20

Streamingandstorage...........................................21

Applications....................................................21

Security.......................................................22

Troubleshooting............................................23

Resettofactorydefaultsettings...................................23

Firmwareoptions...............................................23

Checkthecurrentrmware.......................................

Upgradethermware............................................23

Technicalissues,cluesandsolutions................................

Performanceconsiderations.......................................

Needmorehelp?................................................26

Specications..............................................27

Productoverview................................................

LEDindicators..................................................

SDcardslot....................................................

Buttons.......................................................

Connectors....................................................

AXISQ6078-EPTZCamera

Getstarted

Findthedeviceonthenetwork

TondAxisdevicesonthenetworkandassignthemIPaddressesinWindows®,useAXISIPUtilityorAXISDeviceManager.Both

applicationsarefreeandcanbedownloadedfromaxis.com/support.

FormoreinformationabouthowtondandassignIPaddresses,gotoHowtoassignanIPaddressandaccessyourdevice.

Browsersupport

Youcanusethedevicewiththefollowingbrowsers:

Chrome

Firefox

Edge

Safari

Windows

recommended

macOS

recommended

Otheroperatingsystems

Ifyouneedmoreinformationaboutrecommendedbrowsers,gotoaxis.com/browser-support.

Accessthedevice

1.OpenabrowserandentertheIPaddressorhostnameoftheAxisdevice.

IfyoudonotknowtheIPaddress,useAXISIPUtilityorAXISDeviceManagertondthedeviceonthenetwork.

2.Entertheusernameandpassword.Ifyouaccessthedeviceforthersttime,youmustsettherootpassword.SeeSeta

newpasswordfortherootaccountonpage3.

3.Theliveviewpageopensinyourbrowser.

Verifythatnoonehastamperedwiththermware

TomakesurethatthedevicehasitsoriginalAxisrmware,ortotakefullcontrolofthedeviceafterasecurityattack:

1.Resettofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage23.

Afterthereset,securebootguaranteesthestateofthedevice.

2.Congureandinstallthedevice.

Setanewpasswordfortherootaccount

Important

Thedefaultadministratorusernameisroot.Ifthepasswordforrootislost,resetthedevicetofactorydefaultsettings.

AXISQ6078-EPTZCamera

Getstarted

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10098905

Supporttip:Passwordsecurityconrmationcheck

1.Typeapassword.Followtheinstructionsaboutsecurepasswords.SeeSecurepasswordsonpage4.

2.Retypethepasswordtoconrmthespelling.

3.ClickCreatelogin.Thepasswordhasnowbeencongured.

Securepasswords

Important

Axisdevicessendtheinitiallysetpasswordincleartextoverthenetwork.Toprotectyourdeviceaftertherstlogin,set

upasecureandencryptedHTTPSconnectionandthenchangethepassword.

Thedevicepasswordistheprimaryprotectionforyourdataandservices.Axisdevicesdonotimposeapasswordpolicyasthey

maybeusedinvarioustypesofinstallations.

Toprotectyourdatawestronglyrecommendthatyou:

•Useapasswordwithatleast8characters,preferablycreatedbyapasswordgenerator.

•Don’texposethepassword.

•Changethepasswordatarecurringinterval,atleastonceayear.

AXISQ6078-EPTZCamera

Getstarted

Webpageoverview

Liveviewcontrolbar

Liveview

Productname

Userinformation,colorthemes,andhelp

Videocontrolbar

Settingstoggle

AXISQ6078-EPTZCamera

Getstarted

Settingstabs

AXISQ6078-EPTZCamera

Additionalsettings

Adjusttheimage

Thissectionincludesinstructionsabouthowtocongureyourdevice.Ifyouwanttolearnmoreabouthowcertainfeatures

function,gotoLearnmoreonpage18.

Adjustthefocusfasterwithfocusrecallareas

Tosavethefocussettingsataspecicpan/tiltrange,addafocusrecallarea.Eachtimethecameramovesintothatareaitrecallsthe

previouslysavedfocus.It’senoughtocoverhalfofthefocusrecallareaintheliveview.

Werecommendthefocusrecallfeatureinthefollowingscenarios:

•Whenthereisalotofmanualoperationinliveview,forexamplewithajoystick.

•WherePTZpresetpositionswithmanualfocusarenotefcient,forexamplemovementswherethefocussettingchanges

continuously.

•Inlow-lightscenarios,wheretheautofocusischallengedbythelightingconditions.

Important

•Thefocusrecalloverridesthecamera’sautofocusatthespecicpan/tiltrange.

•Apresetpositionoverridesthefocussettingsavedinthefocusrecallarea.

•Themaximumnumberoffocusrecallareasis20.

Createafocusrecallarea

1.Pan,tilt,andzoomintotheareawhereyouwouldliketohavefocus.

Aslongasthefocusrecallbuttonshowsaplus

,youcanaddafocusrecallareainthatposition.

2.Adjustthefocus.

3.Clickthefocusrecallbutton.

Deleteafocusrecallarea

1.Pan,tilt,andzoomintothefocusrecallareayouwanttodelete.

Thefocusrecallbuttontogglestominuswhenthecameradetectsafocusrecallarea:.

2.Clickthefocusrecallbutton.

BenetfromIRlightinlow-lightconditionsusingnightmode

Yourcamerausesvisiblelighttodelivercolorimagesduringtheday.Astheavailablelightdiminishes,youcansetthecamerato

automaticallyshifttonightmode,inwhichthecamerausesbothvisiblelightandnear-infraredlighttodeliverblack-and-white

images.Sincethecamerausesmoreoftheavailablelightitcandeliverbrighter,moredetailed,images.

1.GotoSettings>Image>Dayandnight,andmakesurethattheIRcutlterissettoAuto.

2.Todetermineatwhatlightlevelyouwantthecameratoshifttonightmode,movetheThresholdslidertowardBright

orDark.

AXISQ6078-EPTZCamera

Additionalsettings

Note

Ifyousettheshifttonightmodetooccurwhenit’sbrighter,theimageremainssharperastherewillbelesslow-light

noise.Ifyousettheshifttooccurwhenit’sdarker,theimagecolorsaremaintainedforlonger,buttherewillbemore

imageblurduetolow-lightnoise.

Reducenoiseinlow-lightconditions

Toreducenoiseinlow-lightconditions,youcanadjustoneormoreofthefollowingsettings:

•Adjustthetrade-offbetweennoiseandmotionblur.GotoSettings>Image>ExposureandmovetheBlur-noise

trade-offslidertowardLownoise.

Note

Ahighmaxshuttervaluecanresultinmotionblur.

•Toslowdowntheshutterspeed,setmaxshuttertothehighestpossiblevalue.

Note

Whenyoureducethemaxgain,theimagecanbecomedarker.

•Setthemaxgaintoalowervalue.

•Opentheaperture.

Handlesceneswithstrongbacklight

Dynamicrangeisthedifferenceinlightlevelsinanimage.Insomecasesthedifferencebetweenthedarkestandthebrightest

areascanbesignicant.Theresultisoftenanimagewhereeitherthedarkorthebrightareasarevisible.Widedynamicrange

(WDR)makesbothdarkandbrightareasoftheimagevisible.

ImagewithoutWDR.

ImagewithWDR.

AXISQ6078-EPTZCamera

Additionalsettings

Note

•WDRcancauseartifactsintheimage.

•WDRmaynotbeavailableforallcapturemodes.

1.GotoSettings>Image>Widedynamicrange.

2.TurnonWDR.

3.TosettheamountofWDR,selectLow,MediumorHighfromtheWDRlevellist.

4.Ifyoustillhaveproblems,gotoExposureandadjusttheExposurezonetocovertheareaofinterest.

FindoutmoreaboutWDRandhowtouseitataxis.com/web-articles/wdr.

Verifythepixelresolution

Toverifythatadenedpartoftheimagecontainsenoughpixelsto,forexample,recognizelicenseplates,youcanusethepixel

counter.

ABC 123

1.GotoSettings>System>Orientation.

2.Click

3.Inthecamera’sliveview,adjustthesizeandpositionoftherectanglearoundtheareaofinterest,forexamplewhereyou

expectlicenseplatestoappear.

Youcanseethenumberofpixelsforeachoftherectangle’ssides(XandY),anddecideifthevaluesareenoughfor

yourneeds.

Hidepartsoftheimagewithprivacymasks

Youcancreateoneorseveralprivacymaskstohidepartsoftheimage.

AXISQ6078-EPTZCamera

Additionalsettings

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10106902

Howtocreateaprivacymask

1.GotoSettings>Privacymask.

2.ClickNew.

3.Adjustthesize,color,andnameoftheprivacymaskaccordingtoyourneeds.

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10106902

Howtochangetheappearanceofthemask

Showanimageoverlay

Youcanaddanimageasanoverlayinthevideostream.

1.GotoSettings>Overlay.

2.ClickImagelist.

3.UploadanimageandclickDone.

4.ClickCreateoverlay.

5.SelectImageandclickCreate.

6.Selecttheimagefromthedrop-downlist.

7.Topositiontheimageoverlay,chooseCustomoroneofthepresets.

8.ClickCreate.

Showatextoverlayinthevideostreamwhenthedevicedetectsmotion

Thisexampleexplainshowtodisplaythetext“Motiondetected”whenthedevicedetectsmotion.

AXISQ6078-EPTZCamera

Additionalsettings

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10103832

Howtoshowtextoverlaywhenthecameradetectsmotion

MakesurethatAXISVideoMotionDetectionisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.

Addtheoverlaytext:

4.GotoSettings>Overlay.

5.SelectCreateoverlayandselectTextoverlay.

6.Enter#Dinthetexteld.

7.Choosetextsizeandappearance.

8.Topositionthetextoverlay,chooseCustomoroneofthepresets.

Createarule:

9.GotoSystem>Events>Rulesandaddarule.

10.Typeanamefortherule.

11.Inthelistofconditions,selectAXISVideoMotionDetection.

12.Inthelistofactions,selectUseoverlaytext.

13.Selectaviewarea.

14.Type“Motiondetected”.

15.Settheduration.

16.ClickSave.

Note

Ifyouupdatetheoverlaytextitwillbeautomaticallyupdatedonallvideostreamsdynamically.

Showthepanortiltpositionasatextoverlay

Youcanshowthepanortiltpositionasanoverlayintheimage.

1.GotoSettings>OverlayandclickCreateoverlay.

2.SelectTextandclickCreate.

3.Inthetexteld,type#xtoshowthepanposition.

Type#ytoshowthetiltposition.

AXISQ6078-EPTZCamera

Additionalsettings

4.Chooseappearance,textsize,andalignment.

5.Thecurrentpanandtiltpositionsshowupintheliveviewimageandintherecording.

Adjustthecameraview(PTZ)

Tolearnmoreaboutdifferentpan,tilt,andzoomsettings,seePan,tilt,andzoom(PTZ)onpage20.

Limitthepan,tilt,andzoommovements

Iftherearepartsofthescenethatyoudon’twantthecameratoreach,youcanlimitthepan,tilt,andzoommovements.For

example,youwanttoprotecttheprivacyofresidentsinanapartmentbuilding,whichislocatedclosetoaparkinglotthatyouintend

tomonitor.Tolimitthemovements,gotoSettings>PTZ>Limits.

Createaguardtourwithpresetpositions

Aguardtourdisplaysthevideostreamfromdifferentpresetpositionseitherinapredeterminedorrandomorder,andforcongurable

periodsoftime.

1.GotoSettings>PTZ>Guardtours.

2.Click+.

3.Toedittheguardtour’sproperties,click

4.Typeanamefortheguardtourandspecifythepauselengthinminutesbetweeneachtour.

5.Ifyouwanttheguardtourtogotothepresetpositionsinarandomorder,turnonShufe.

6.ClickDone.

7.ClickAddtoaddthepresetpositionsthatyouwantinyourguardtour.

8.ClickDonetoexittheguardtoursettings.

9.Toscheduletheguardtour,gotoSystem>Events.

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t1011 1157

Viewandrecordvideo

Thissectionincludesinstructionsabouthowtocongureyourdevice.Tolearnmoreabouthowstreamingandstorageworks,goto

Streamingandstorageonpage21.

Reducebandwidthandstorage

Important

Ifyoureducethebandwidthitcanresultinlossofdetailsinthepicture.

AXISQ6078-EPTZCamera

Additionalsettings

1.GotoliveviewandselectH.264.

2.GotoSettings>Stream.

3.Dooneormoreofthefollowing:

Note

ThezipstreamsettingsareusedforbothH.264andH.265.

-TurnondynamicGOPandsetahighGOPlengthvalue.

-Increasethecompression.

-TurnondynamicFPS.

Note

WebbrowsersdonotsupportH.265decoding.UseavideomanagementsystemorapplicationsupportingH.265decoding.

Setupnetworkstorage

Tostorerecordingsonthenetwork,youneedtosetupyournetworkstorage.

1.GotoSettings>System>Storage.

2.ClickSetupunderNetworkstorage.

3.EntertheIPaddressofthehostserver.

4.Enterthenameofthesharedlocationonthehostserver.

5.Movetheswitchifthesharerequiresalogin,andenterusernameandpassword.

6.ClickConnect.

Recordandwatchvideo

Torecordvideoyoumustrstsetupnetworkstorage,seeSetupnetworkstorageonpage13,orhaveanSDcardinstalled.

Recordvideo

1.Gototheliveview.

2.Tostartarecording,clickRecord.Clickagaintostoptherecording.

Watchvideo

1.ClickStorage>Gotorecordings.

2.Selectyourrecordinginthelistanditwillplayautomatically.

Setuprulesandalerts

Youcancreaterulestomakeyourdeviceperformanactionwhencertaineventsoccur.Aruleconsistsofconditionsandactions.

Theconditionscanbeusedtotriggertheactions.Forexample,thedevicecanstartarecordingorsendanemailwhenitdetects

motion,orshowanoverlaytextwhilethedeviceisrecording.

Triggeranaction

1.GotoSettings>System>Eventstosetuparule.Theruledeneswhenthedevicewillperformcertainactions.Rules

canbesetupasscheduled,recurring,orforexample,triggeredbymotiondetection.

AXISQ6078-EPTZCamera

Additionalsettings

2.SelecttheConditionthatmustbemettotriggertheaction.Ifyouspecifymorethanoneconditionfortherule,allofthe

conditionsmustbemettotriggertheaction.

3.SelectwhichActionthedeviceshouldperformwhentheconditionsaremet.

Note

Ifyoumakechangestoanactiverule,youhavetorestarttheruleforthechangestotakeeffect.

Recordvideowhenthecameradetectsmotion

ThisexampleexplainshowtosetupthecameratostartrecordingtotheSDcardvesecondsbeforeitdetectsmotionandto

stoponeminuteafter.

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10106619

Howtorecordavideostreamwhenthecameradetectsmotion

MakesurethatAXISVideoMotionDetectionisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.Ifyouneedhelp,seethe

usermanualforAXISVideoMotionDetection4.

Createarule:

1.GotoSettings>System>Eventsandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,underApplication,selectAXISVideoMotionDetection(VMD).

4.Inthelistofactions,underRecordings,selectRecordvideowhiletheruleisactive.

5.Selectanexistingstreamproleorcreateanewone.

6.Settheprebuffertimeto5seconds.

7.Setthepostbuffertimeto60seconds.

8.Inthelistofstorageoptions,selectSDcard.

9.ClickSave.

Directthecameratoapresetpositionwhenthecameradetectsmotion

Thisexampleexplainshowtosetupthecameratogotoapresetpositionwhenitdetectsmotionintheimage.

AXISQ6078-EPTZCamera

Additionalsettings

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10101129

MakesurethatAXISVideoMotionDetectionisrunning:

1.GotoSettings>Apps>AXISVideoMotionDetection.

2.Starttheapplicationifitisnotalreadyrunning.

3.Makesureyouhavesetuptheapplicationaccordingtoyourneeds.Ifyouneedhelp,seethe

usermanualforAXISVideoMotionDetection4.

Addapresetposition:

GotoSettings>PTZandsetwhereyouwantthecameratobedirectedbycreatingapresetposition.

Createarule:

1.GotoSettings>System>Events>Rulesandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,selectavideomotiondetectionconditionunderApplication.

4.Fromthelistofactions,selectGotopresetposition.

5.Selectthepresetpositionyouwantthecameratogoto.

6.ClickSave.

Zoominonaspecicareaautomaticallywithgatekeeper

Thisexampleexplainshowtousethegatekeeperfunctionalitytomakethecamerazoominautomaticallyonthelicenseplateofa

carthatpassesthroughagate.Whenthecarhaspassed,thecamerazoomsouttothehomeposition.

Createthepresetpositions:

1.GotoSettings>PTZ>Presetpositions.

2.Createthehomepositionthatincludestheentranceofthegate.

3.Createthezoomed-inpresetpositionsothatitcoverstheareaintheimagewhereyouassumethatthelicenseplate

willappear.

Createamotiondetectionprole:

1.GotoSettings>AppsandopenAXISVideoMotionDetection.

2.Createaprolethatcoverstheentranceofthegateandthensavetheprole.

Createarule:

1.GotoSettings>System>Eventsandaddarule.

2.Nametherule“Gatekeeper”.

AXISQ6078-EPTZCamera

Additionalsettings

3.Inthelistofconditions,underApplication,selectthemotiondetectionprole.

4.Inthelistofactions,underPresetpositions,selectGotopresetposition.

5.SelectaVideochannel.

6.SelectthePresetposition.

7.Tomakethecamerawaitawhilebeforeitreturnstothehomeposition,selectHometimeout,andsetatime.

8.ClickSave.

Recordvideowhenthecameradetectsimpact

Shockdetectionallowsthecameratodetecttamperingcausedbyvibrationsorshock.Vibrationsduetotheenvironmentortoan

objectcantriggeranactiondependingontheshocksensitivityrange,whichcanbesetfrom0to100.Inthisscenario,someoneis

throwingrocksatthecameraafterhoursandyouwouldliketogetavideoclipoftheevent.

Turnonshockdetection:

1.GotoSettings>System>Detectors.

2.Turnonshockdetection,andsetavaluefortheshocksensitivity.

Createarule:

1.GotoSettings>System>Eventsandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,underDevicestatus,selectShockdetected.

4.Click+toaddasecondcondition.

5.Inthelistofconditions,underScheduledandrecurring,selectScheduledevent.

6.Inthelistofschedules,selectAfterhours.

7.Inthelistofactions,underRecordings,selectRecordvideowhiletheruleisactive.

8.SelectaCamera.

9.Settheprebuffertimeto5seconds.

10.Setthepostbuffertimeto60seconds.

11.Selectwheretosavetherecordings.

12.ClickSave.

AXISQ6078-EPTZCamera

Additionalsettings

Sendanemailautomaticallyifsomeonespraypaintsthelens

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10106687

Howtosendanemailnoticationifsomeonespraypaintthelens

1.GotoSettings>System>Detectors.

2.TurnonTriggerondarkimages.Thiswilltriggeranalarmifthelensissprayed,covered,orrenderedseverelyoutoffocus.

3.SetadurationforTriggerafter.Thevalueindicatesthetimethatmustpassbeforeanemailissent.

Createarule:

1.GotoSettings>System>Events>Rulesandaddarule.

2.Typeanamefortherule.

3.Inthelistofconditions,selectTampering.

4.Inthelistofactions,selectSendnoticationtoemail.

5.SelectarecipientfromthelistorgotoRecipientstocreateanewrecipient.

Tocreateanewrecipient,click

.Tocopyanexistingrecipient,click.

6.Typeasubjectandamessagefortheemail.

7.ClickSave.

AXISQ6078-EPTZCamera

Learnmore

Cleaningrecommendations

Ifthedevicegetsgreasestainsorbecomesheavilysoiled,youcancleanitwithmild,solvent-freesoapordetergent.

NO NO

TICE TICE

TICE

Neveruseharshdetergent,forexamplegasoline,benzene,oracetone.

1.Useacanofcompressedairtoremoveanydustorloosedirtfromthedevice.

2.Cleanthedevicewithasoftclothdampenedwithmilddetergentandlukewarmwater.

3.Wipecarefullywithadrycloth.

Note

Avoidcleaningindirectsunlightoratelevatedtemperatures,asthismaycausestainswhenthewaterdropletsdry.

Bitratecontrol

Withbitratecontrol,youcanmanagethebandwidthconsumptionofyourvideostream.

Variablebitrate(VBR)

Withvariablebitrate,thebandwidthconsumptionvariesbasedonthelevelofactivityinthescene.Themoreactivityinthescene,

themorebandwidthyouneed.Youareguaranteedconstantimagequalitybutitrequiresstoragemargins.

Maximumbitrate(MBR)

Withmaximumbitrate,youcansetatargetbitratetohandlebitratelimitationsinyoursystem.Youmayseeadeclineinimage

qualityorframeratewhentheinstantaneousbitrateiskeptbelowthespeciedtargetbitrate.Youcanchoosetoeitherprioritize

imagequalityorframerate.Werecommendthatyoucongurethetargetbitratetoahighervaluethantheexpectedbitrate.This

givesyouamarginforadditionalcomplexitythatneedstobecaptured.

AXISQ6078-EPTZCamera

Learnmore

Targetbitrate

Averagebitrate(ABR)

Withaveragebitrate,thebitrateisautomaticallyadjustedoveralongertimescale.Thisissoyoucanmeetthespeciedtargetand

providethebestvideoqualitybasedonyouravailablestorage.Bitrateishigherinsceneswithalotofactivity,comparedtostatic

scenes.Youaremorelikelytogetbetterimagequalitywhenneededwhenusingtheaveragebitrateoption.Youcandenethetotal

storagerequiredtostorethevideostreamforaspeciedamountoftime(retentiontime)whenimagequalityisadjustedtomeetthe

speciedtargetbitrate.Specifytheaveragebitratesettingsinoneofthefollowingways:

•Tocalculatetheestimatedstorageneed,setthetargetbitrateandtheretentiontime.

•Tocalculatetheaveragebitrate,basedonavailablestorageandrequiredretentiontime,usethetargetbitratecalculator.

kbit/s

Targetbitrate

Actualaveragebitrate

Youcanalsoturnonmaximumbitrateandspecifyatargetbitratewithintheaveragebitrateoption.

AXISQ6078-EPTZCamera

Learnmore

kbit/s

Targetbitrate

Actualaveragebitrate

Capturemodes

CapturemodedenesthemaximumframerateavailableintheAxisproduct.Dependingonwhichcapturemodeyouselect,you

maynotbeabletouseWDR.

Whichcapturemodetochoosedependsontherequirementsofframerateandresolutionforthespecicsurveillancesetup.For

specicationsaboutavailablecapturemodes,seetheproduct’sdatasheetataxis.com.

Privacymasks

Aprivacymaskisauser-denedareathatcoversapartofthemonitoredarea.Inthevideostream,privacymasksappeareitheras

blocksofsolidcolororwithamosaicpattern.

You’llseetheprivacymaskonallsnapshots,recordedvideo,andlivestreams.

YoucanusetheVAPIX®applicationprogramminginterface(API)toturnofftheprivacymasks.

Important

Ifyouusemultipleprivacymasksitmayaffecttheproduct’sperformance.

Overlays

Overlaysaresuperimposedoverthevideostream.Theyareusedtoprovideextrainformationduringrecordings,suchasatimestamp,

orduringproductinstallationandconguration.Youcanaddeithertextoranimage.

Thevideostreamingindicatorisanothertypeofoverlay.Itshowsyouthattheliveviewvideostreamislive.

Pan,tilt,andzoom(PTZ)

Guardtours

Aguardtourdisplaysthevideostreamfromdifferentpresetpositionseitherinapredeterminedorrandomorder,andforcongurable

periodsoftime.Oncestarted,aguardtourcontinuestorununtilstopped,evenwhentherearenoclients(webbrowsers)viewingthe

images.

AXISQ6078-EPTZCamera

Learnmore

Streamingandstorage

Videocompressionformats

Decidewhichcompressionmethodtousebasedonyourviewingrequirements,andonthepropertiesofyournetwork.The

availableoptionsare:

MotionJPEG

MotionJPEG,orMJPEG,isadigitalvideosequencethatismadeupofaseriesofindividualJPEGimages.Theseimagesarethen

displayedandupdatedataratesufcienttocreateastreamthatshowsconstantlyupdatedmotion.Fortheviewertoperceivemotion

videotheratemustbeatleast16imageframespersecond.Fullmotionvideoisperceivedat30(NTSC)or25(PAL)framespersecond.

TheMotionJPEGstreamusesconsiderableamountsofbandwidth,butprovidesexcellentimagequalityandaccesstoeveryimage

containedinthestream.

H.264orMPEG-4Part10/AVC

Note

H.264isalicensedtechnology.TheAxisproductincludesoneH.264viewingclientlicense.Toinstalladditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

H.264can,withoutcompromisingimagequality,reducethesizeofadigitalvideolebymorethan80%comparedtotheMotion

JPEGformatandbyasmuchas50%comparedtotheMPEG-4standard.Thismeansthatlessnetworkbandwidthandstoragespace

arerequiredforavideole.Orseenanotherway,highervideoqualitycanbeachievedforagivenbitrate.

H.265orMPEG-HPart2/HEVC

Note

H.265islicensedtechnology.TheAxisproductincludesoneH.265viewingclientlicense.Toinstalladditionalunlicensed

copiesoftheclientisprohibited.Topurchaseadditionallicenses,contactyourAxisreseller.

HowdoImage,Stream,andStreamprolesettingsrelatetoeachother?

TheImagetabcontainscamerasettingsthataffectallvideostreamsfromtheproduct.Ifyouchangesomethinginthistab,it

immediatelyaffectsallvideostreamsandrecordings.

TheStreamtabcontainssettingsforvideostreams.Yougetthesesettingsifyourequestavideostreamfromtheproductanddon’t

specifyforexampleresolution,orframerate.WhenyouchangethesettingsintheStreamtab,itdoesn’taffectongoingstreams,but

itwilltakeeffectwhenyoustartanewstream.

TheStreamprolessettingsoverridethesettingsfromtheStreamtab.Ifyourequestastreamwithaspecicstreamprole,the

streamcontainsthesettingsofthatprole.Ifyourequestastreamwithoutspecifyingastreamprole,orrequestastreamprole

thatdoesn'texistintheproduct,thestreamcontainsthesettingsfromtheStreamtab.

Applications

AXISCameraApplicationPlatform(ACAP)isanopenplatformthatenablesthirdpartiestodevelopanalyticsandotherapplications

forAxisproducts.Tondoutmoreaboutavailableapplications,downloads,trialsandlicenses,gotoaxis.com/applications.

TondtheusermanualsforAxisapplications,gotoaxis.com.

Note

•Severalapplicationscanrunatthesametimebutsomeapplicationsmightnotbecompatiblewitheachother.Certain

combinationsofapplicationsmightrequiretoomuchprocessingpowerormemoryresourceswhenruninparallel.Verify

thattheapplicationsworktogetherbeforedeployment.

AXISQ6078-EPTZCamera

Learnmore

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10001688

Howtodownloadandinstallanapplication

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10001688

Howtoactivateanapplicationlicencecodeonadevice

Autotracking

Withautotracking,thecameraautomaticallyzoomsinonandtracksmovingobjects,forexampleavehicleoraperson.Youcan

manuallyselectanobjecttotrack,orsetuptriggerareasandletthecameradetectmovingobjects.Theapplicationisbestsuited

foropenareaswithnoobscuringobjectsandwheremovementisunusual.Whenthecameradoesn'ttrackanobject,itreturns

toitshomeposition.

Important

•Autotrackingisdesignedforareaswithalimitedamountofmovement.

•Autotrackingdoesnottrackobjectsbehindprivacymasks.

•Ifbothautotrackingandguardtourareenabled,guardtourtakespriorityoverautotracking.Thismeansautotracking

stopsifaguardtourstarts.

Security

TPMmodule

TheTPM(TrustedPlatformModule)isacomponentthatprovidescryptographicfeaturestoprotectinformationfromunauthorized

access.Itisalwaysactivatedandtherearenosettingsyoucanchange.

TolearnmoreaboutTPM,gotoaxis.com/press-center/media-resources/white-papers.

AXISQ6078-EPTZCamera

Troubleshooting

Resettofactorydefaultsettings

Important

Resettofactorydefaultshouldbeusedwithcaution.Aresettofactorydefaultresetsallsettings,includingtheIPaddress,to

thefactorydefaultvalues.

Toresettheproducttothefactorydefaultsettings:

1.Pressandholdthecontrolbuttonandthepowerbuttonfor15–30secondsuntilthestatusLEDindicatorashesamber.

SeeProductoverviewonpage27.

2.ReleasethecontrolbuttonbutcontinuetoholddownthepowerbuttonuntilthestatusLEDindicatorturnsgreen.

3.Releasethepowerbuttonandassembletheproduct.

4.Theprocessisnowcomplete.Theproducthasbeenresettothefactorydefaultsettings.IfnoDHCPserverisavailableon

thenetwork,thedefaultIPaddressis192.168.0.90.

5.UsingtheinstallationandmanagementsoftwaretoolstoassignanIPaddress,setthepasswordandaccessthevideo

stream.

Itisalsopossibletoresetparameterstofactorydefaultthroughthewebinterface.GotoSettings>System>Maintenanceand

clickDefault.

Firmwareoptions

Axisoffersproductrmwaremanagementaccordingtoeithertheactivetrackorthelong-termsupport(LTS)tracks.Beingonthe

activetrackmeanscontinuouslygettingaccesstoallthelatestproductfeatures,whiletheLTStracksprovideaxedplatformwith

periodicreleasesfocusedmainlyonbugxesandsecurityupdates.

Usingrmwarefromtheactivetrackisrecommendedifyouwanttoaccessthenewestfeatures,orifyouuseAxisend-to-endsystem

offerings.TheLTStracksarerecommendedifyouusethird-partyintegrations,whicharenotcontinuouslyvalidatedagainstthelatest

activetrack.WithLTS,theproductscanmaintaincybersecuritywithoutintroducinganysignicantfunctionalchangesoraffecting

anyexistingintegrations.FormoredetailedinformationaboutAxisproductrmwarestrategy,gotoaxis.com/support/rmware.

Checkthecurrentrmware

Firmwareisthesoftwarethatdeterminesthefunctionalityofnetworkdevices.Oneofyourrstactionswhentroubleshootinga

problemshouldbetocheckthecurrentrmwareversion.Thelatestversionmaycontainacorrectionthatxesyourparticular

problem.

Tocheckthecurrentrmware:

1.Gototheproduct’swebpage.

2.Clickonthehelpmenu

3.ClickAbout.

Upgradethermware

Important

Preconguredandcustomizedsettingsaresavedwhenthermwareisupgraded(providedthatthefeaturesareavailablein

thenewrmware)althoughthisisnotguaranteedbyAxisCommunicationsAB.

AXISQ6078-EPTZCamera

Troubleshooting

Important

Makesurethecoverisattachedduringupgradetoavoidinstallationfailure.

Important

Makesuretheproductremainsconnectedtothepowersourcethroughouttheupgradeprocess.

Note

Whenyouupgradetheproductwiththelatestrmwareintheactivetrack,theproductreceivesthelatestfunctionality

available.Alwaysreadtheupgradeinstructionsandreleasenotesavailablewitheachnewreleasebeforeupgradingthe

rmware.Tondthelatestrmwareandthereleasenotes,gotoaxis.com/support/rmware.

AXISDeviceManagercanbeusedformultipleupgrades.Findoutmoreataxis.com/products/axis-device-manager.

Towatchthisvideo,gotothewebversionofthisdocument.

www.axis.com/products/online-manual/68579#t10095327

Howtoupgradethermware

1.Downloadthermwareletoyourcomputer,availablefreeofchargeataxis.com/support/rmware.

2.Logintotheproductasanadministrator.

3.GotoSettings>System>Maintenance.Followtheinstructionsonthepage.Whentheupgradehasnished,the

productrestartsautomatically.

Technicalissues,cluesandsolutions

Ifyoucan’tndwhatyou’relookingforhere,trythetroubleshootingsectionataxis.com/support.

Problemsupgradingthermware

FirmwareupgradefailureIfthermwareupgradefails,thedevicereloadsthepreviousrmware.Themostcommonreason

isthatthewrongrmwarelehasbeenuploaded.Checkthatthenameofthermwarele

correspondstoyourdeviceandtryagain.

ProblemssettingtheIPaddress

Thedeviceislocatedona

differentsubnet

IftheIPaddressintendedforthedeviceandtheIPaddressofthecomputerusedtoaccessthe

devicearelocatedondifferentsubnets,youcannotsettheIPaddress.Contactyournetwork

administratortoobtainanIPaddress.

AXISQ6078-EPTZCamera

Troubleshooting

TheIPaddressisbeingused

byanotherdevice

DisconnecttheAxisdevicefromthenetwork.Runthepingcommand(inaCommand/DOSwindow,

typepingandtheIPaddressofthedevice):

•Ifyoureceive:Replyfrom<IPaddress>:bytes=32;time=10...

thismeansthattheIPaddressmayalreadybeinusebyanotherdeviceonthenetwork.

ObtainanewIPaddressfromthenetworkadministratorandreinstallthedevice.

•Ifyoureceive:Requesttimedout,thismeansthattheIPaddressisavailable

forusewiththeAxisdevice.Checkallcablingandreinstallthedevice.

PossibleIPaddressconict

withanotherdeviceonthe

samesubnet

ThestaticIPaddressintheAxisdeviceisusedbeforetheDHCPserversetsadynamicaddress.

ThismeansthatifthesamedefaultstaticIPaddressisalsousedbyanotherdevice,theremay

beproblemsaccessingthedevice.

Thedevicecannotbeaccessedfromabrowser

Cannotlogin

WhenHTTPSisenabled,ensurethatthecorrectprotocol(HTTPorHTTPS)isusedwhenattempting

tologin.Youmayneedtomanuallytypehttporhttpsinthebrowser’saddresseld.

Ifthepasswordfortheuserrootislost,thedevicemustberesettothefactorydefaultsettings.

SeeResettofactorydefaultsettingsonpage23.

TheIPaddresshasbeen

changedbyDHCP

IPaddressesobtainedfromaDHCPserveraredynamicandmaychange.IftheIPaddresshasbeen

changed,useAXISIPUtilityorAXISDeviceManagertolocatethedeviceonthenetwork.Identify

thedeviceusingitsmodelorserialnumber,orbytheDNSname(ifthenamehasbeencongured).

Ifrequired,astaticIPaddresscanbeassignedmanually.Forinstructions,gotoaxis.com/support.

Thedeviceisaccessiblelocallybutnotexternally

Toaccessthedeviceexternally,werecommendusingoneofthefollowingapplicationsforWindows

•AXISCompanion:freeofcharge,idealforsmallsystemswithbasicsurveillanceneeds.

•AXISCameraStation:30-daytrialversionfreeofcharge,idealforsmalltomid-sizesystems.

Forinstructionsanddownload,gotoaxis.com/vms.

Problemswithstreaming

MulticastH.264only

accessiblebylocalclients

Checkifyourroutersupportsmulticasting,oriftheroutersettingsbetweentheclientandthe

deviceneedtobecongured.TheTTL(TimeToLive)valuemayneedtobeincreased.

NomulticastH.264

displayedintheclient

CheckwithyournetworkadministratorthatthemulticastaddressesusedbytheAxisdevice

arevalidforyournetwork.

Checkwithyournetworkadministratortoseeifthereisarewallpreventingviewing.

PoorrenderingofH.264

images

Ensurethatyourgraphicscardisusingthelatestdriver.Thelatestdriverscanusuallybe

downloadedfromthemanufacturer’swebsite.

Colorsaturationisdifferent

inH.264andMotionJPEG

Modifythesettingsforyourgraphicsadapter.Gototheadapter’sdocumentationformore

information.

Lowerframeratethan

expected

•SeePerformanceconsiderationsonpage26.

•Reducethenumberofapplicationsrunningontheclientcomputer.

•Limitthenumberofsimultaneousviewers.

•Checkwiththenetworkadministratorthatthereisenoughbandwidthavailable.

•Lowertheimageresolution.

•Themaximumframespersecondisdependentontheutilityfrequency(60/50Hz)

oftheAxisdevice.

Can'tselectH.265encoding

inliveview

WebbrowsersdonotsupportH.265decoding.Useavideomanagementsystemorapplication

supportingH.265decoding.

AXISQ6078-EPTZCamera

Troubleshooting

Performanceconsiderations

Whensettingupyoursystem,itisimportanttoconsiderhowvarioussettingsandsituationsaffecttheperformance.Somefactors

affecttheamountofbandwidth(thebitrate)required,otherscanaffecttheframerate,andsomeaffectboth.Iftheloadonthe

CPUreachesitsmaximum,thisalsoaffectstheframerate.

Thefollowingfactorsarethemostimportanttoconsider:

•Highimageresolutionorlowercompressionlevelsresultinimagescontainingmoredatawhichinturnaffectsthe

bandwidth.

•RotatingtheimageintheGUIwillincreasetheproduct'sCPUload.

•Removingorattachingthecoverwillrestartthecamera.

•AccessbylargenumbersofMotionJPEGorunicastH.264clientsaffectsthebandwidth.

•Simultaneousviewingofdifferentstreams(resolution,compression)bydifferentclientsaffectsbothframerateand

bandwidth.

Useidenticalstreamswhereverpossibletomaintainahighframerate.Streamprolescanbeusedtoensurethat

streamsareidentical.

•AccessingMotionJPEGandH.264videostreamssimultaneouslyaffectsbothframerateandbandwidth.

•Heavyusageofeventsettingsaffectstheproduct’sCPUloadwhichinturnaffectstheframerate.

•UsingHTTPSmayreduceframerate,inparticularifstreamingMotionJPEG.

•Heavynetworkutilizationduetopoorinfrastructureaffectsthebandwidth.

•Viewingonpoorlyperformingclientcomputerslowersperceivedperformanceandaffectsframerate.

•RunningmultipleAXISCameraApplicationPlatform(ACAP)applicationssimultaneouslymayaffecttheframerateand

thegeneralperformance.

Needmorehelp?

Usefullinks

•HowtoassignanIPaddressandaccessyourdevice

Contactsupport

Contactsupportataxis.com/support.

AXISQ6078-EPTZCamera

Speciﬁcations

Productoverview

Hookforsafetywire

Networkconnector(HighPoE)

Groundscrew

Unitholder(3x)

Controlbutton

StatusLEDindicator

Partnumber(P/N)andserialnumber(S/N)

Powerbutton

Heater

Dome

SDcardslot

AXISQ6078-EPTZCamera

Speciﬁcations

LEDindicators

StatusLED

Indication

Unlit

Connectionandnormaloperation.

GreenShowssteadygreenfor10secondsfornormaloperationafterstartupcompleted.

Amber

Steadyduringstartup.Flashesduringrmwareupgradeorresettofactorydefault.

Amber/RedFlashesamber/redifnetworkconnectionisunavailableorlost.

SDcardslot

NO NO

TICE TICE

TICE

•RiskofdamagetoSDcard.Donotusesharptools,metalobjects,orexcessiveforcewheninsertingorremovingthe

SDcard.Useyourngerstoinsertandremovethecard.

•Riskofdatalossandcorruptedrecordings.DonotremovetheSDcardwhiletheproductisrunning.UnmounttheSDcard

fromtheproduct’swebpagebeforeremoval.

ThisproductsupportsSD/SDHC/SDXCcards.

ForSDcardrecommendations,seeaxis.com.

SD,SDHC,andSDXCLogosaretrademarksofSD-3CLLC.SD,SDHCandSDXCaretrademarksorregistered

trademarksofSD-3C,LLCintheUnitedStates,othercountriesorboth.

Buttons

Controlbutton

Thecontrolbuttonisusedfor:

•Resettingtheproducttofactorydefaultsettings.SeeResettofactorydefaultsettingsonpage23.

Powerbutton

Pressandholdthepowerbuttontotemporarilypowertheproductwhenthedomecoverisremoved.Thepowerbuttonisalsoused

withthecontrolbuttontoresetthecameratofactorydefaultsettings.Seepage23.

Connectors

Networkconnector

RJ45EthernetconnectorwithPoweroverEthernetPlus(PoE+).

UserManualVer.M1.4

AXISQ6078-EPTZCamera

Date:May2021

PartNo.T10164156

Axis Q6078-E Outdoor 4K PTZ Camera

Product's Documents

User Manual

Specifications

Axis Q6078-E Questions and Answers
