INSTRUCTIONS FOR:
SIDE CABINET FOR LONG HANDLE TOOLS
- RED/BLACK
MODEL No's: APLHT/APLHTB
1.1. GENERAL SAFETY
WARNING! Ensure Health & Safety, local authority, and general
workshop practice regulations are adhered to when using this
cabinet.
Keep the work area clean, uncluttered and ensure there is
adequate lighting.
Keep the cabinet clean and tidy in accordance with good workshop
practice.
Keep children and unauthorised persons away from the work area.
DO NOT use this cabinet for any purpose other than that for which
it is designed.
DO NOT place the cabinet in a damp or wet location or an area
where there is condensation.
DO NOT clean the cabinet with any solvents which may damage
the surfaces or the protective coating.
Lockable storage unit for long tools, such as prybars, long reach
screwdrivers and breaker bars. Hangs on side of rollcab and can be
fastened securely to side for added security. A range of different diameter
support holes provide great versatility of storage options. Supplied with lock
and two keys.
Model No: APLHT/APLHTB
Overall Size W x D x H: 410 x 90 x 270mm
Support Hole Ø x Quantity: 25mm x 6, 17mm x 4, 15mm x 16
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
1. SAFETY
2. INTRODUCTION
3. SPECIFICATION
4.1. Fit foam pads to back of the side cabinet to prevent damage to the rollcab.
4.2. The side cabinet can be hung from the rollcab, but it is recommended that the side cabinet is secured to the rollcab, using the two self
tappingscrewsandtwoatwashersprovided.
4.3. Hang the side cabinet on the rollcab and open it up. Ensure it is centrally positioned and mark the intended position of the holes to be
drilled.Refertog.2.
4.4. Remove the side cabinet and drill the two holes in to the roll cab using a 4.8mm (3/16") drill bit.
4.5. Re-hangthesidecabinetandsecuretotherollcabusingthetwoselftappingscrewsandtwoatwashersprovided.
4. ASSEMBLY
Fig.1
Fig.2 Fig.3
Original Language Version
© Jack Sealey Limited
APLHT/APLHTB Issue: 3(SP) - 05/07/16
Environmental Protection.
Recycle unwanted materials instead of disposing of them as
waste. All tools, accessories and packaging should be sorted,
taken to a recycle centre and disposed of in a manner which
is compatible with the environment.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
