BEFORE YOU BEGIN:
• Unpack all parts before beginning and refer to the drawing below.
• Shelf pegs and door hinges must slide into the channels of the post in the correct order.
They cannot be removed individually without disassembling the whole unit.
SYNERGY 402
Single Instructions
Includes:
(1) Single 40 Unit
(2) S40 Side Panels
(1) S40 Door
!
!
Limited Warranty
For five full years Salamander Designs Ltd. will repair or replace, at our option, any product defective in materials or craftsmanship. Salamander Designs Ltd. will not be responsible for any damage to or destruction of other equipment conse-
quential to our equipment failure. Defective product must be given Return Authorization and is to be returned to the factory prepaid, in the original carton and packing material. Any damage incurred in a shipment not in original packaging
shall be the responsibility of the owner. Warranty repairs will be returned prepaid, via UPS within the continental U.S.A. only. Salamander Designs Ltd. • 800-535-5659 • www.SalamanderDesigns.com
©2002 Salamander Designs Ltd.
Top Shelf (1)
Adjustable Shelf (4)
Bottom Shelf (1)
Joint Connector Bolt 300-540 (4)
Foot & Nut P-300-350 (4)
Door (2)
Aluminum Post (4)
Sides (2)
Washer 300-470 (4)
Shelf Peg
PHK-370 Right (8)
PHK-380 Left (8)
Doc No. 500-650/v6.18 402 -1/4
