INSTRUCTIONS FOR:
MOBILE WORKBENCH 2-LEVEL
MODEL NO: AP1100M
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE PRODUCT
CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL
INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions
and maintained properly, give you years of trouble free performance.
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this bench.
Locate bench in a suitable working area.
Keep the work area clean, uncluttered and ensure there is adequate lighting.
WARNING! Use bench on level and solid ground, preferably concrete. Avoid tarmacadam since the bench may sink into the surface.
Always apply the brakes to the locking castors before using the bench.
Keep the bench clean and tidy in accordance with good workshop practice.
Keep children and unauthorised persons away from the working area.
DO NOT place heavy loads on the lower shelf.
DO NOT use the bench for any purpose other than that for which it is designed.
DO NOT carry out any work on the bench without the workpiece being adequately secured. Use clamps or a vice (not included) to secure
the workpiece (available from your Sealey dealer).
DO NOT use the bench outside.
DO NOT get the bench wet, or use in damp or wet locations or areas where there is condensation.
DO NOT clean the bench with any solvents which may damage the paint surface.
WARNING! This workbench is heavy and assistance should be obtained before assembly.
2. INTRODUCTION
Sturdy steel construction workbench with a capacity of 300kg. Two shelves that allow unobstructed access. Fitted with two xed castors, two
locking castors and a heavy-duty handle.
3. SPECIFICATION
Model No: .............................................. AP1100M
Size incl. Handle (W x D x H): .......................1180 x 700 x 830mm
Work Surface (W x D): ..................................1100 x 700mm
Capacity: .................................................. 300kg
AP1100M Issue: 1 - 05/11/15
© Jack Sealey Limited
Original Language Version
4. ASSEMBLY
Key:
1: Bench Top
2 Leg Frames (x2)
3: Support Brackets (x4)
4: Castor Brackets (x4)
5: Locking Castors (x2)
6: Fixed castors (x2)
7: Handle
8: Shelf
g.1
4.1. Place the bench top (g.1.1) upside on the oor. Use a oor covering to protect the
bench top.
4.2. Fasten the four support brackets (g.1.3) to the leg frames using the xings
provided (g.2).
4.3. Fasten the leg/bracket assemblies to the channels welded to the underside of the bench
top (g.3).
4.4. Fasten the four castor brackets (g.1.4) to the legs.
4.5. Fasten the two locking castors (g.1.5) to the legs at one end.
4.6. Fasten the two xed castors (g.1.6) to the legs at the other end.
4.7. Fasten the shelf (g.1.8) to the crossmembers of the leg frames.
4.8. Using two people, turn the bench right way up.
4.9. Fix the handle (g.1.7) to the end of the bench to which the locking castors are tted.
g.2
g.3
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable dispose of it according to local regulations.
NOTE: It is our policy to improve products continually and as such we reserve the right to alter data, specifications and component parts without
prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
