CAUTION:
Weight on this product should not exceed 300 lbs.
Owner's
Manual
Product May Vary Slightly From Pictured.
STAMINA PRODUCTS
MADE IN CHINA
©
2020 Stamina Products, Inc.
2020, 11
Exercise can present a
health risk. Consult a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
discontinue use of this
equipment. Serious bodily
injury can occur if this
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
!
WARNING
When calling for parts or
service, please specify
the following numbers
:
Model#: 55-1489
S/N: _____________
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springeld, MO 65803
Customer Care
1 (800) 375-7520
www.staminaproducts.com
EasyDecompressPro
TABLE OF CONTENTS
Safety Instructions ...................................... 3
Before You Begin ........................................ 5
Equipment Warning, Caution & Notice Labels
... 6
Hardware Identication Chart .................... 7
Assembly Instructions ................................ 8
Storage ....................................................... 13
Maintenance ............................................... 13
Operational Instructions ........................... 13
Product Parts Drawing .............................. 16
Parts List .................................................... 17
Warranty ..................................................... 19
Notes ........................................................... 20
Fax/Mail Ordering Form ............................ 22
SAFETY INSTRUCTIONS
3
1. Save these instructions and ensure that other exercisers read this manual prior to using the
Stamina® Active Aging EasyDecompress Pro for the rst time.
2. Read all warnings and cautions posted on the Stamina® Active Aging EasyDecompress Pro.
3. The Stamina® Active Aging EasyDecompress Pro should only be used after a thorough review
of the Owner’s Manual. Make sure that it is properly assembled and tightened before use.
4. We recommend that two people be available for assembly of this product.
5. Keep children away from the Stamina® Active Aging EasyDecompress Pro. Do not allow
children to use or play on the Stamina® Active Aging EasyDecompress Pro. Keep children and
pets away from the Stamina® Active Aging EasyDecompress Pro when it is in use.
6. It is recommended that you place this product on an equipment mat.
7. Set up and operate the Stamina® Active Aging EasyDecompress Pro on a solid level surface.
Do not position the Stamina® Active Aging EasyDecompress Pro on loose rugs or uneven
surfaces.
8. Make sure that adequate space is available for access to and around the Stamina® Active Aging
EasyDecompress Pro.
9. Before using, inspect the Stamina® Active Aging EasyDecompress Pro for worn or loose
components, and securely tighten or replace any worn or loose components prior to use.
10. Consult your physician before using this product. If you feel faint, dizzy, or experience pain during
use, stop immediately and consult with your physician.
11. Choose the intensity that ts your strength and exibility level. Know your body's limits and use this
product within them. Use common sense when using this product.
12. Do not wear loose or dangling clothing while using the Stamina® Active Aging EasyDecompress
Pro. Keep long hair pulled up and away from cords and pulleys at all times.
13. Never exercise in bare feet or socks; always wear proper footwear such as running, walking, or
cross training shoes that t well, provide foot support, and feature non-skid rubber soles.
14. Be careful to maintain your balance while using, mounting, dismounting, or assembling the
Stamina® Active Aging EasyDecompress Pro, loss of balance may result in a fall and bodily
injury.
15. The Stamina® Active Aging EasyDecompress Pro should not be used by persons weighing
over 300 pounds.
16. The Stamina® Active Aging EasyDecompress Pro should be used by only one person at a time.
17. The Stamina® Active Aging EasyDecompress Pro is for consumer use only. It is not for use in
public or semipublic facilities.
!
WARNING
Cancer and Reproductive Harm www.P65Warnings.ca.gov
Consult your physician before starting this or any exercise program. This is
especially important if you are over the age of 35, have never exercised before,
are pregnant, or suer from any health problem. This product is for home use
only. Do not use in institutional or commercial applications. Failure to follow all
warnings and instructions could result in serious injury or death.
To reduce the risk of serious injury, read the following Safety Instructions
before using the Stamina® Active Aging EasyDecompress Pro.
!
WARNING
!
WARNING
NEED HELP?
CONTACT US FIRST
1 (800) 375-7520
customer.care@staminaproducts.com
Hi! From all of us here at Stamina Products, thank you for your purchase. We
know that you have big fitness goals in mind and we are here to help you along.
Call us, email us, or send us a message on Facebook. Be sure to contact us if you
have any questions on your new product. We look forward to hearing from you!
With your body in mind,
Stamina Customer Care
To enact your extended warranty and to help us better
serve you, please go online and register your new product.
register.staminaproducts.com
ONLINE
customer.car[email protected]om
www.staminaproducts.com
TELEPHONE
1 (800) 375-7520
FAX
(417) 889-8064
MAIL
Stamina Products, Inc.
ATTN: Customer Care
2040 N Alliance Ave
Springfield, MO 65803
facebook.com/StaminaProducts
facebook.com/AeroPilates
CUSTOMER CARE HOURS:
Monday-Thursday, 7:30 AM-5:00 PM, Central Time
Friday, 8:00 AM-3:00 PM, Central Time
It is quick and easy to register online, but if you’re a little old school or just need a
reason to raise that little flag on your mailbox, fill out the info on the last page of this
manual and mail it in.
Front Support
Sliding Frame
Cushion
Rear Stabilizer
Spring Knob
Height
Adjustment Beam
Foam Pad
BEFORE YOU BEGIN
5
Caution Label
Leveling
Endcap
Right Handrail
Main Frame
Serial Decal
Foam Rollers
Endcap
Thank you for choosing the Stamina® Active
Aging EasyDecompress Pro. We take great pride
in this quality product and hope it will provide many
hours of quality exercise to make you feel better,
look better, and enjoy life to its fullest.
It's a proven fact that a regular exercise
program can improve your physical and mental
health. Too often, our busy lifestyles limit our
time and opportunity to exercise. The Stamina®
Active Aging EasyDecompress Pro provides
a convenient and simple method to begin your
journey of getting your body in shape and
achieving a happier and healthier lifestyle.
Before reading further, please review the
drawing below and familiarize yourself with the
parts that are labeled. Locate the serial decal on
the product and write the serial number on the
cover of the manual in the space provided. See
page 6 for an image of the serial decal. Model
number and serial number are required when
calling for assistance.
Read this manual carefully before using the
Stamina® Active Aging EasyDecompress Pro.
Providing you with a quality product is Stamina's
top priority. However, sometimes there could be a
missing or incorrectly sized part. If you have any
questions or problems with the parts included with
your Stamina® Active Aging EasyDecompress
Pro, please do not return the product. Contact us
FIRST!
If a part is missing or defective, please contact
Customer Care for assistance. Call us toll free
at 1-800-375-7520 (in the U.S.) or live chat on
staminaproducts.com. Our Customer Care Sta is
available to assist you from 7:30 A.M. to 5:00 P.M.
(Central Time) Monday through Thursday and 8:00
A.M. to 3:00 P.M. (Central Time) on Friday.
Be sure to have the name and model number of
the product available when you contact us.
Front Stabilizer
Footbar
Foam Pad
Handlebar
Armpit Pad
Handlebar
Left Handrail
Cushion Support
Pillow
Swing Arm
Armpit Pad
Support
Allen Wrench (4mm)
Allen Wrench (6mm)
THE FOLLOWING TOOLS ARE INCLUDED FOR ASSEMBLY :
Wrench
Single Ended Wrench
This chart is provided to help identify the warning, caution, and notice labels on the Stamina® Active
Aging EasyDecompress Pro. Please take a moment to familiarize yourself with all of the warning,
caution, and notice labels.
EQUIPMENT WARNING, CAUTION & NOTICE LABELS
6
CAUTION LABEL(84)
To best serve you, our Customer Care Representatives will
need your serial number. For quick access, write in your
serial number on the cover of the manual.
SERIAL DECAL(85)
7
length
length
mm.
in.
INCHES
This chart is provided to help identify the hardware used in the assembly process. Place the washers or
the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to
check the length of the bolts and screws.
NOTICE: The length of all bolts and screws, except those with flat
heads, is measured from below the head to the end of the bolt
or screw. Flat head bolts and screws are measured from the
top of the head to the end of the bolt or screw.
After unpacking the unit, open the hardware bag and make sure that you have all the following items.
Some hardware may be already attached to the part.
MILLIMETERS
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140 150
0 1/2 1 1/2 2 1/2 3 1/2 4 1/2 5 1/2 6
6 8 10 12
3/16" 1/4" 5/16" 3/8" 1/2"
HARDWARE IDENTIFICATION CHART
Part Number and Description Qty
30 Carriage Bolt (M8 x 1.25 x 37mm) 8
44 Carriage Bolt (M8 x 1.25 x 41mm) 2
62 Bolt, Hex Head (M6 x 1 x 35mm) 2
15 Nylock Nut (M8 x 1.25) 10
63 Nylock Nut (M6 x 1) 2
41 Bolt, Button Head (M6 x 1 x 35mm) 4
55 Acorn Nut (M8 x 1.25) 2
56 Arc Washer (M8) 2
81 Washer (M6) 2
13 Bolt, Button Head w/ Washers (M8x1.25x16mm) 4
16
12
56
55
56
55
5
49
1
13
13
13
6
19
3
19
ASSEMBLY INSTRUCTIONS
8
STEP 1
Pull out the PULL PIN(49) from the MAIN FRAME(1). Unfold the FRONT SUPPORT(5) and lock in position
with the PULL PIN(49). Attach the FRONT STABILIZER(6) to the FRONT SUPPORT(5) with ACORN NUTS
(M8x1.25)(55) and ARC WASHERS(M8)(56).
STEP 2
Pull the SPRING KNOB(16), then unfold the REAR SUPPORT(12) and lock in one of the incline positions
with the SPRING KNOB(16). Insert the REAR STABILIZER(3) into the REAR SUPPORT(12) and secure
with BUTTON HEAD BOLTS w/ WASHERS(M8x1.25x16mm)(13). Turn the LEVELING ENDCAPS(19)
on the REAR STABILIZER(3) as needed until the unit is steady and not rocking.
NOTE: There are three adjustment holes in the bracket on the MAIN FRAME(1) which allow the REAR
SUPPORT(12) to be attached in three dierent incline positions.
Place all parts from the box in a cleared area and position them on the oor in front of you. Remove
all packing materials from your area and place them back into the box. Do not dispose of the packing
materials until assembly is completed. Read each step carefully before beginning. If you are missing
a part, please go to staminaproducts.com under the Customer Care section and order the part
(in the U.S.). Our Customer Care Sta is available to assist you from 7:30 A.M. to 5:00 P.M. (Central
Time) Monday through Thursday and 8:00 A.M. to 3:00 P.M. (Central Time) on Friday.
Some product parts are t tested at the factory to ensure proper t and alignment. Marks in
the paint may be noticeable, but are not an indication of damage.
ASSEMBLY INSTRUCTIONS
9
STEP 3
Insert the HANDLEBARS(4) into the HANDLEBAR CONNECTOR(23) and secure with CARRIAGE BOLTS
(M8x1.25x37mm)(30) and NYLOCK NUTS(M8x1.25)(15).
STEP 4
Insert the RIGHT HANDRAIL(79) into the MAIN FRAME(1) and secure with CARRIAGE BOLTS
(M8x1.25x37mm)(30) and NYLOCK NUTS(M8x1.25)(15). Repeat on other side.
15
30
15
30
15
30
15
30
23
4
11
4
79
1
41
41
26
27
69
71
69
71
67
68
68
74
75
67
1
69
ASSEMBLY INSTRUCTIONS
10
STEP 5: Refer to detail view A and the illustration below. Swing up the CUSHION SUPPORT(67), then
place the end of the AIR SHOCK(75) into the bracket on the CUSHION SUPPORT(67) and lock in position
with the T PULL PIN(74).
NOTE: There are two adjustment holes in the CUSHION SUPPORT(67) which allow the AIR SHOCK(75)
to be attached in two dierent positions to oer dierent support force for the CUSHION(27). Select
the position which is most comfortable for you.
STEP 6: Push the BUTTON PIN(70) in and insert the ARMPIT PAD SUPPORT(69) into the SWING ARM
(68). Slide an ARMPIT PAD(71) on the ARMPIT PAD SUPPORT(69). Repeat on other side.
NOTE: There are three adjustment holes in the SWING ARM(6) which allow the ARMPIT PAD SUPPORTS
(69) to be attached in three dierent positions. Start with the center position and adjust if necessary.
STEP 7: Attach the CUSHION(27) to the CUSHION SUPPORT(67) with BUTTON HEAD BOLTS
(M6x1x35mm)(41). Slide the PILLOW(26) onto the CUSHION(27) and make the elastic band go
across the CUSHION SUPPORT(67).
A.
Button Pin(70)
B.
ASSEMBLY INSTRUCTIONS
11
STEP 8
Insert the HEIGHT ADJUSTMENT BEAM(7) into the EXTENDING TUBE(2) and secure with CARRIAGE
BOLTS(M8x1.25x41mm)(44) and NYLOCK NUTS(M8x1.25)(15).
STEP 9
Refer to the illustration below.
Insert the PAD TUBES(51) through the holes in the HEIGHT
ADJUSTMENT BEAM(7) and SLIDING FRAME(8). Slide the FOAM PADS(53) on both ends of the PAD
TUBES(5).
53
53
51
51
7
2
44
15
53
53
8
ASSEMBLY INSTRUCTIONS
12
STEP 10
Insert the FOOTBAR(10) into the SLIDING FRAME(8) and secure with HEX BOLTS(M6x1x35mm)(62),
WASHERS(M6)(81), and NYLOCK NUTS(M6x1)(63). The HEX BOLTS(M6x1x35mm)(62) must t inside
the hex-shaped holes in the SLIDING FRAME(8) to properly secure the FOOTBAR(10).
STEP 11
Insert the ADJUSTABLE INSTEP FRAME(9) into the SLIDING FRAME(8) and lock in one of the adjustment
holes with the SHORT PULL PIN(59). Slide the FOAM PADS(53) on both ends of the ADJUSTABLE
INSTEP FRAME(9).
NOTE: There are four adjustment holes in the SLIDING FRAME(8) which allow the ADJUSTABLE INSTEP
FRAME(9) to be attached in four dierent positions. Find the position which is most comfortable
for holding your ankles while performing the back stretching exercise.
10
81
62
54
59
9
54
8
63
4
4
1. To store the Stamina® Active Aging EasyDecompress Pro, simply keep it in a clean dry place.
2. To move the Stamina® Active Aging EasyDecompress Pro, lift by the back end of the MAIN
FRAME(1) on one end and the FOOTBAR(10) at the other end.
The safety and integrity designed into the Stamina® Active Aging EasyDecompress Pro can only be
maintained when the Stamina® Active Aging EasyDecompress Pro is regularly examined for damage
and wear. Special attention should be given to the following:
1. Verify that all nuts and bolts are present and properly tightened. Replace missing nuts and bolts.
Tighten loose nuts and bolts.
2. Verify that the CAUTION LABEL(84) is in place and easy to read. Call Stamina Products immediately
at 1-800-375-7520 for a replacement CAUTION LABEL(84) if it is missing or damaged.
3. It is the sole responsibility of the user/owner to ensure that regular maintenance is performed.
4. Worn or damaged components must be replaced immediately or the Stamina® Active Aging
EasyDecompress Pro removed from service until repair is made.
5. Only Stamina Products supplied components should be used to maintain/repair the Stamina® Active
Aging EasyDecompress Pro.
6. Keep your Stamina® Active Aging EasyDecompress Pro clean by wiping it o with an absorbent
cloth after use.
STORAGE
MAINTENANCE
13
STRETCH SYSTEM
The Stamina® Active Aging EasyDecompress Pro
stretches the back with its one way rack and pinion
engineering. Lie on the Stamina® Active Aging
EasyDecompress Pro with the FOAM PADS(53) holding
your ankles. Pull the HANDLEBARS(4) back and forth as
many times as needed until you feel a gentle stretch. Stop
pulling at the desired position and stay at the stretched
position for a few minutes. Push the HANDLEBARS(4) rmly
toward your head to release the stretch.
Push the Handlebars
toward your head to
release.
Pull the Handlebars back and
forth as many times as needed
to reach the proper stretch.
OPERATIONAL INSTRUCTIONS
NOTE: Prior to releasing the stretch please remove
your arms from the ARMPIT PAD SUPPORTS(69).
Once the ARMPIT PAD SUPPORTS(69) are no
longer under your arms push the HANDLEBARS(4)
rmly toward your head to release the stretch.
OPERATIONAL INSTRUCTIONS
14
USING THE Stamina® Active Aging EasyDecompress Pro
To use the Stamina® Active Aging EasyDecompress Pro, proper height adjustment is important. Use the
following procedure to set the height adjustment for a revitalizing stretch.
4
4
27
26
42
53
60
8
7
2
53
9
68
69
C.
D.
1. Refer to illustration C. Sit up on the FOAM ROLLERS(42). Push the HANDLEBARS(4) toward your head to
release and pull the EXTENDING TUBE(2) into its shortest position with legs.
2.
Lie on the Stamina® Active Aging EasyDecompress Pro with the ARMPIT PADS(71) under and supporting
your armpits. If the ARMPIT PADS(71) do not rest comfortably under your armpits, adjust the ARMPIT PAD
SUPPORTS(69) by pushing in the BUTTON PIN(70) and sliding them in or out of the SWING ARMS(68). Straighten
your body and legs to determine if a height adjustment needs to be made.
3. To make a height adjustment, loosen and pull the ADJUSTMENT KNOB(60) and slide the SLIDING FRAME(8)
to adjust. Lock the SLIDING FRAME(8) in desired position by inserting the pin of the ADJUSTMENT KNOB(60)
into one of the adjustment holes in the HEIGHT ADJUSTMENT BEAM(7). Tighten the ADJUSTMENT KNOB(60)
to lock the SLIDING FRAME(8) securely.
4. Sit up on the FOAM ROLLERS(42). Adjust the ADJUSTABLE INSTEP FRAME(9) by pulling out the SHORT PULL
PIN(59) and sliding it up, then place your ankles between the FOAM PADS(53). Push the ADJUSTABLE INSTEP
FRAME(9) down to secure your feet and lock in position with the SHORT PULL PIN(59). Place the ADJUSTABLE
INSTEP FRAME(9) at the position which is most comfortable for holding your ankles. Lie down with the ARMPIT
PADS(71) under and supporting your armpits, refer to illustration D.
5. To stretch, pull the HANDLEBARS(4) back and forth as many times as needed to reach the proper stretch.
Stop pulling at the desired stretch position and stay at the stretch position for few minutes. To release, push the
HANDLEBARS(4) rmly toward your head.
Armpit Pad Adjustment
To accommodate different sizes of users, the ARMPIT PAD SUPPORTS(69) can be adjusted to one of three
positions. Refer to the
detail view in
illustration C. There are three adjustment holes in the back of the SWING
ARM(68). Start with the center position and adjust if necessary. To adjust, push the BUTTON PIN(70) in and slide
the ARMPIT PAD SUPPORTS(69) to the position that is comfortable. Make sure that the BUTTON PIN(70) is
snapped into the proper adjustment hole before use.
Button Pin(70)
Incline Angle Adjustment
There are three adjustment holes in the bracket on the MAIN FRAME(1) which allow the REAR
SUPPORT(12) to be attached in three dierent incline positions. Pull the SPRING KNOB(16), then swing
the REAR SUPPORT(12) to desired position and lock in one of the incline positions with the SPRING
KNOB(16). More incline angle will oer more stretch force.
OPERATIONAL INSTRUCTIONS
15
1
16
12
18
50
14
17
16
3
19
19
15
30
4
24
25
25
45
11
43
42
46
42
43
15
21
22
20
1
31
32
33
34
35
40
36
39
37
38
23
2
66
28
29
44
25
24
4
25
79
45
15
30
50
47
47
48
49
5
6
57
55
56
57
55
56
54
53
52
52
58
51
53
54
7
65
52
52
8
61
59
60
9
61
51
61
62
81
63
10
64
64
61
15
30
15
58
54
53
53
54
15
30
84
85
26
15
72
72
73
68
61
70
54
54
69
71
65
65
41
67
74
50
77
78
78
78
77
76
75
80
15
82
78
21
78
27
69
70
61
68
12
41
15
72
72
73
54
54
71
83
83
13
13
13
16
PRODUCT PARTS DRAWING
FRONT
BACK
PART# PART NAME QTY
PARTS LIST
17
1 Main Frame 1
2 Extending Tube 1
3 Rear Stabilizer 1
4 Handlebar 2
5 Front Support 1
6 Front Stabilizer 1
7 Height Adjustment Beam 1
8 Sliding Frame 1
9 Adjustable Instep Frame 1
10 Footbar 1
11 Left Handrail 1
12 Rear Support 1
13 Bolt, Button Head (M8 x 1.25 x 16mm) 4
14 Carriage Bolt (M10 x 1.5 x 71mm) 1
15 Nylock Nut (M8 x 1.25) 15
16 Spring Knob 1
17 Spring (ø1.4 x ø13.8 x 48mm) 1
18 Pin Bolt (M10 x 1.5 x 57mm) 1
19 Leveling Endcap (ø38mm) 2
20 Square Plug (38 x 38mm) 1
21 Square Plug (30mm x 30mm) 2
22 Sleeve (38mm x 38mm) 1
23 Handlebar Connector 1
24 Foam Tube (ø22 x ø28 x 275mm) 2
25 Dome Plug (25mm) 4
26 Pillow 1
27 Cushion 1
28 Bolt, Flat Head (M6 x 1 x 13mm) 3
29 Shoulder Bolt, Button Head (M6 x 1 x 22mm) 1
30 Carriage Bolt (M8 x 1.25 x 37mm) 8
31 Pressing Spring (ø0.8 x ø5.9 x 20mm) 1
32 Gear 1
33 Carriage Bolt (M8 x 1.25 x 60mm) 2
34 Claw Stopper 1
35 C Ring (8mm) 1
36 Handlebar Spacer (ø8.1 x ø12 x 24mm) 1
37 Claw Shaft 1
38 Twist Spring 1
39 Claw 1
40 Handlebar Bumper 1
41 Bolt, Button Head (M6 x 1 x 35mm) 4
42 Foam Roller (ø22 x ø70 x 120mm) 8
43 Roller Sleeve 8
44 Carriage Bolt (M8 x 1.25 x 41mm) 2
45 Long Foam Tube (ø22 x ø28 x 740mm) 2
46 Foam Roller Spacer 4
47 Front Support Bushing (ø10.5 x ø40mm) 2
48 Bolt, Button Head (M10 x 1.5 x 68mm) 1
18
PART# PART NAME QTY
PARTS LIST
49 Pull Pin (ø8 x 68mm) 1
50 Nylock Nut (M10 x 1.5) 3
51 Pad Tube 2
52 Pad Tube Bushing (ø26.5 x ø40mm) 4
53 Foam Pad (ø22 x ø85 x 155mm) 6
54 Round Plug (25mm) 10
55 Acorn Nut (M8 x 1.25) 2
56 Arc Washer (M8) 2
57 Endcap (38mm) 2
58 Bolt, Socket Head (M6 x 1 x 15mm) 2
59 Short Pull Pin (ø8 x ø42mm) 1
60 Adjustment Knob 1
61 Square Bushing (30mm x 30mm) 6
62 Bolt, Hex Head (M6 x 1 x 35mm) 2
63 Nylock Nut (M6 x 1) 2
64 Oval Plug (30mm x 60mm) 2
65 Square Plug (25mm x 25mm) 3
66 Gear Rack 1
67 Cushion Support 1
68 Swing Arm 2
69 Armpit Pad Support 2
70 Button Pin 3
71 Armpit Pad (ø22 x ø70 x 225mm) 2
72 Swing Arm Bushing (ø8 x ø25mm) 4
73 Carriage Bolt (M8 x 1.25 x 52mm) 2
74 T Pull Pin 1
75 Air Shock 1
76 Bolt, Button Head (M10 x 1.5 x 168mm) 1
77 Washer (M10) 2
78 Cushion Support Bushing (ø10 x ø28mm) 6
79 Right Handrail 1
80 Bolt, Button Head (M8 x 1.25 x 66mm) 1
81 Washer (M6) 2
82 Cushion Support Bumper 1
83 Pivoting Bushing (ø8.1 x ø18 x 9.3mm) 2
84 Caution Label 1
85 Serial Decal 1
86 Allen Wrench (4mm) 1
87 Allen Wrench (6mm) 1
88 Wrench 1
89 Single Ended Wrench 1
90 Manual 1
LIMITED WARRANTY
MODEL 55-1489
19
WARRANTY
Stamina Products, Inc. (“Stamina”) warrants to the original purchaser that this product will be free from
defects in materials and workmanship that arise under normal use, service, proper assembly and proper
operation in accordance with product warnings/instructions for a period of 90 days on the parts and three
years on the frame from the date of the original purchase from an authorized retailer. THIS WARRANTY
SHALL NOT APPLY TO ANY PRODUCT WHICH HAS BEEN SUBJECT TO COMMERCIAL USE,
ABUSE, MISUSE, ALTERATION OF ANY KIND OR TO ANY DEFECT OR CHANGE CAUSED BY
IMPROPER ASSEMBLY, REPAIR, REPLACEMENT, SUBSTITUTION OR USE WITH PARTS NOT
PROVIDED BY STAMINA. Commercial use includes use of product in athletic clubs, health clubs, spas,
gyms, and all other public or semipublic facilities whether or not the product’s use is in furtherance of a
prot making enterprise, and all other use which is not for personal purposes.
To implement this limited warranty, send a written notice stating your name, date, and place of purchase
and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance
Ave, Springeld, Missouri, USA, MO 65803, or email us at customer[email protected], or call
us at 1-800-375-7520. If the defect is covered under this limited warranty, you will be requested to return
the product or part to us for free repair or replacement at our option.
NO ACTION FOR BREACH OF THIS LIMITED WARRANTY MAY BE COMMENCED MORE
THAN ONE (1) YEAR AFTER THE DATE THE ALLEGED BREACH WAS OR SHOULD HAVE
BEEN DISCOVERED. NO ACTION FOR BREACH OF ANY IMPLIED WARRANTY (INCLUDING
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE) MAY BE COMMENCED MORE
THAN ONE (1) YEAR AFTER DELIVERY OF THE PRODUCT TO THE PURCHASER. These warranties
are not transferable. IF ANY PART OF THE PRODUCT IS NOT IN COMPLIANCE WITH THIS LIMITED
WARRANTY OR ANY IMPLIED WARRANTY, THE REMEDY OF REPAIR OR REPLACEMENT IS THE
EXCLUSIVE REMEDY. If any claim is made under this limited warranty or any implied warranty, Stamina
reserves the right to require the product to be returned for inspection, at the purchaser’s expense, to
Stamina’s premises in Springfield, Missouri. Return of the enclosed warranty registration card is not
required for warranty coverage, but is merely a way of establishing the date and place of purchase.
Stamina SHALL NOT BE LIABLE FOR THE LOSS OF USE OF ANY PRODUCT, LOSS OF TIME,
INCONVENIENCE, COMMERCIAL LOSS OR ANY OTHER INDIRECT, CONSEQUENTIAL, SPECIAL
OR INCIDENTAL DAMAGES DUE TO BREACH OF THE ABOVE WARRANTY OR ANY IMPLIED
WARRANTY.
THIS LIMITED WARRANTY IS THE ONLY EXPRESS WARRANTY. NO ORAL OR WRITTEN
INFORMATION GIVEN BY STAMINA, ITS AGENTS OR EMPLOYEES, SHALL CREATE A WARRANTY
OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY. This warranty gives you specic legal
rights, and you may also have other legal rights which vary from state to state. ANY OTHER RIGHT
WHICH YOU MAY HAVE, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, IS LIMITED IN DURATION TO THE DURATION OF THIS
WARRANTY.
The laws in some states aect the disclaimer or limitation of implied warranties and consequential and
incidental damages. If any such law is found applicable, the foregoing disclaimers and limitations of and
on implied warranties and consequential and incidental damages shall be deemed to be modied to the
extent necessary to comply with applicable law.
NOTES
20
NOTES
21
Model Number: ...................................................................................... Serial Number: .............................................................................................
Product Name: ..................................................................................................................................................................................................................................
Place Purchased: ..............................................................................................................................................................................................................................
Date of Purchase: .................................................................................. Purchase Price: ............................................................................................
First Name: ............................................................................................ Last Name: ...................................................................................................
City: .................................................................. State: ................................................................ Zip Code: .................................................
Email Address: ....................................................................................... Phone #: ( ) ......................................................................................
Would you like to receive email information or special oers from Stamina Products?* ____Yes ____No
*If yes, be sure your email address is included above.
Stamina Products, Inc.
2040 N Alliance Ave, Springeld, MO 65803
If there are missing or damaged parts, you can go to parts.staminaproducts.com and order those parts. If you have questions,
please contact customer care. Do not return the product. To order parts by mail, fill out the sheet below and fax it to
417-889-8064. The part will be mailed to your address.
Mr./Ms: ..............................................................................................................................................................................................................................................
Address: ........................................ ............................................................................................. Apt. #:..........................................................................
City: .................................................................. State: ................................................................ Zip Code: .................................................
IMPORTANT : We require your phone number to process the order!
Phone #: ( ) ................................................................................ Work Phone #: ( ) .............................................................................
Date of Purchase: ..................................................................................
Model #: ............................................................................................................................................................................................................................................
Purchased From: ..............................................................................................................................................................................................................................
IMPORTANT: Before lling out the portion below, make sure you have the correct information.
Refer to the parts list to make sure you're ordering the right parts!
Stamina Products, Inc.
2040 N Alliance Ave, Springeld, MO 65803
Detach and Mail or Fax the Form Above
TO CONTACT CUSTOMER CARE
For your convenience, Stamina’s customer care representatives can be reached by email at customer.care@staminaproducts.
com or by phone at 1-800-375-7520 (in the U.S.). Our customer care representatives are available Monday through Thursday
from 7:30 a.m. until 5:00 p.m., and Friday 8:00 a.m. until 3 p.m. Central Time.
TO REGISTER YOUR PRODUCT
Would you like to recieve email information or special oers from Stamina Products? Register at contact.staminaproducts.com
TELEPHONE
CUSTOMER CARE
Tel: 1 (800) 375-7520
FAX
CUSTOMER CARE
Fax: (417) 889-8064
MAIL
STAMINA PRODUCTS, INC.
ATTN: Customer Care
2040 N Alliance Ave, Springeld, MO 65803
ONLINE
CUSTOMER CARE
customer[email protected]
www.staminaproducts.com
To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model
number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your
product) ready.
If you don’t have internet access, you can call customer care at 1-800-375-7520, or ll out and mail the product registration form
below to Stamina Products, Inc.; 2040 N Alliance Ave, Springeld, MO 65803.
PRODUCT REGISTRATION FORM
TO ORDER PARTS
Detach and Mail or Fax the Form Below
PARTS ORDER FORM
PART # DESCRIPTION QUANTITY
1 Rear Unit Assembly 1
EXAMPLE:
