DS-1697ZJ-Y3(OS)
Wall Mount
Feature
Anti-corrosion design for adverse environments
The safety rope enables convenient installation
Dimension
328.4 mm (12.93'')
126 mm (4.96'')
A
120 mm (4.72'')
11 mm
(0.43'')
Φ 6.5 mm
(0.26'')
Φ 13.5 mm
(0.53'')
79 mm (3.11'')
Φ 8 mm
(0.31'')
Φ 13.5 mm
(0.53'')
A
100 mm (3.94'')
328.4 mm (12.93'')
3-M6
Φ 47.6 mm
(1.87'')
53 mm
(2.09'')
Φ 63 mm (2.48'')
10 mm
(0.39'')
222 mm (8.74'')
Available Model
DS-1697ZJ-Y3(OS)
Parameter
Model
Parameters
DS-1697ZJ-Y
Wall Mount
Appearance
Silver moon grey
Material
SUS316L
Dimension
126 mm × 222 mm × 328 mm (4.96" × 8.74" × 12.93")
Weight
Approx. 2307 g (5.09 lb.)
Note
The mount should be installed on a flat surface.
Waterproof rubber is necessary for the outdoor application.
The wall should be capable of supporting at least 3 times as much as the total weight of the camera, and the mount.
The maximum load capacity of the mount is 8 kg (17.64 lb.).
