IMPORTANT: READ OPERATOR’S MANUAL THOROUGHLY AND FOLLOW THE SAFE OPERATION PRACTICES WHILE OPERATING THE UNIT.
Remove Unit From Carton
Assemble The Unit
Place a hose clamp over
the end of the Flex Tube
and slide the end of the
with the clamp on it over
the elbow tube. Tighten
the clamp screw.
Place a hose clamp over
the other end of Flex Tube
and slide the end over the
top end of the upper
blower tube. Tighten the
clamp screw.
Assemble The Unit
Loosen the 2 screws on
the throttle control. Move
the throttle control to the
position that provides the
best grip and tighten.
Mix thoroughly in separate
fuel can:
– 3.2 fl. oz. of 2-cycle
engine oil
– 1 gallon of unleaded
gasoline
NOTE: Do not mix directly
in fuel tank.
Press primer bulb 10
times, or until fuel is
visible
Move choke lever to
Position 1.
Press down cruise control
to FAST position.
Crouch in starting
position.
Pull rope 5 times. Move choke lever to
Position 2 .
11 2
Remove all contents from
the carton.
6
7
9 10
3
Insert the upper blower
tube into the lower blower
tube and twist the lower
tube clockwise unit it locks
into place.
Place unit on a level
urface and fill fuel tank.
DO NOT overfill.
8
4
Start The Unit
11
12
13
14
10 X
5 X
Starter Rope
Flex Tube
Throttle Control
On/ Off Switch
Lower Blower Tube
Nozzle
DIDN’T START?
Repeat these instructions.
IF the engine hesitates, return the choke lever to
Position 2 and continue the warm-up.
IF the engine does not start, go back to step 9.
IF the unit fails to start after 2 attempts, move choke
lever to Position 3 and pull rope until unit starts
Primer
Bulb
Move choke lever to
Position 3.
Continue to keep the
cruise control in FAST
position and warm unit for
an additional 60 seconds
to complete warm-up. Unit
may be used during this
time.
16
17
Pull rope 3-5 times to
start engine. Keep the
cruise control in FAST
position and allow unit to
warm up for 30 to 60
seconds.
15
Primer Bulb
Tools Required-
Phillips Screwdriver
T-20 Torx
®
Screwdriver
Insert the lower blower
tube into the nozzle and
twist the nozzle clockwise
until it locks into place.
Zip tie the throttle cable to
the elbow tube.
5
Upper Blower
Tube
Fuel Cap
Choke Lever
Cruise Control
1 Gallon 3.2 oz
40:1
SLOW
FAST
SLOW
FAST
Start The Unit
Spark Plug
Operator’s Manual
769-15056 / 00 05/18
NEED HELP? Call 1-800-828-5500 in U.S. or 1–800–668–1238 in Canada
ENGLISH — PAGE 1ESPAÑOL — PAGE 7
TB2BP EC
2-Cycle
Electric Start Capable
Backpack Blower
