RECHARGEABLE HEAD TORCH WITH AUTO-
SENSOR 3W COB LED & 1W SMD LED
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
8 DO NOT shine directly into your, another person’s or an animal’s eyes.
8 DO NOT allow children to use the torch.
8 DO NOT use the torch if you suspect that the battery or the torch casing is damaged.
8 DO NOT leave batteries in a discharged state. Before storage remove batteries and dispose of in the correct manner.
1.2. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8 DO NOT attempt to open the battery.
8 DO NOT crush, puncture, short contacts or dispose of in re or water.
8 DO NOT expose to temperatures above 60°C (140°F).
9 If the electrolyte in the batteries gets on your skin, thoroughly rinse with water. If it gets in your eyes, rinse thoroughly with cool water
and seek immediate medical attention.
2. INTRODUCTION
3W COB + 1W SMD Rechargeable headlight with sensor function. Also includes 3 SMD LEDs producing 300 Lumens. Can also act as
a separate mini worklight with magnet. 3.7V 1000mAh Li-Poly battery with 0.5m USB cable included. Charging and battery indicator
capabilities. Maximum 4hr runtime using COB LED.
3. SPECIFICATION
4. OPERATION
4.1. TORCH OPERATION
4.1.1. Press power button (g.1) once to turn unit on.
4.1.2. The battery charge state is indicated by the 4 blue LEDs.
4.1.3. Press power button again to light the primary light.
4.1.4. Press power button again to also light the secondary light.
4.1.5. Press the power button again to turn the unit o.
4.2. LIGHT SENSOR
4.2.1. Press the sensor button to enable sensing.
4.2.2. Pass hand in-front of light until light comes on.
4.2.3. Pass hand in-front of light again and light goes o.
4.2.4. Press the sensor button to disable sensing.
4.3. TILTING HEAD
4.3.1. The headtorch has 4 possible lockable positions, 0
0
, 20
0
, 40
0
, and 60
0
.
4.4. DISMOUNT TORCH
4.4.1. Twist the light unit through 45
0
to remove it from headband mounting.
4.5. CHARGING:
4.5.1. Connect the USB lead to the port on the side of the unit and to a USB power supply socket at the other.
Refer to
instructions
SMD
Power Button
Secondary
Light
Sensor Button
Light Sensor
Battery
State
Indicators
g.1
Original Language Version
© Jack Sealey Limited
HT300R Issue 4 (H) 21/05/24
MODEL NO: HT300R
MODEL NO: HT300R
Battery: 3.7V 1000mAh Li-Poly battery
Charging Time: 3-4hr
LED Type: COB + SMD
Lumen Output: COB - 150lm
SMD - 300lm
Nett Weight: 0.095
Operating Time: COB/SMD 4hr/2hr
5. MAINTENANCE
9 Keep the torch clean by wiping with a damp cloth.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 sales@sealey.co.uk www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted,
taken to a recycling centre and disposed of in a manner which is compatible with the environment. When the product
becomes completely unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and
dispose of the product and fluids according to local regulations.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Original Language Version
© Jack Sealey Limited
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
HT300R Issue 4 (H) 21/05/24
