Safety information and specifications . . . . . 2
Tools needed. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Package contents . . . . . . . . . . . . . . . . . . . . . . . . 3
Installation instructions. . . . . . . . . . . . . . . . . . . 5
For wood-stud or concrete
wall installations
Before using your new product, please read these instructions to prevent any damage.
Full Motion Mount for TVs 47" - 80"
NS-HTVMM1703-C
INSTALLATION GUIDE
For VESA patterns:
• 7.9 × 7.9" (200 × 200 mm)
• 11.8 × 7.9" (300 × 200 mm)
• 11.8 × 11.8" (300 × 300 mm)
• 15.7 × 7.9" (400 × 200 mm)
• 15.7 × 11.8" (400 × 300 mm)
• 15.7 × 15.7" (400 × 400 mm)
• 19.7 × 15.7" (500 × 400 mm)
• 23.6 × 15.7" (600 × 400 mm)
