HRVF384S
2
Contents
Safety and warning information…………2
Installing your new appliance……………7
Description of the appliance……………10
Controls panel……………………………11
Reversing the door………………………14
Using your appliance…………………… 17
Cleaning and care………………………18
Helpful hints and tips……………………19
Troubleshooting………………………….21
Disposal of the appliance………………23
Safety and warning information
For your safety and correct usage, before installing and first using the appliance,
read this user manual carefully, including its hints and warnings. To avoid
unnecessary mistakes and accidents, it is important to make sure that all people
using the appliance are thoroughly familiar with its operation and safety features.
Save these instructions and be sure that they remain with the appliance if it is
moved or sold, so that anyone using it throughout its life, will be properly
informed on its usage and safety notices.
For the safety of life and property, keep the precautions of these user's
instructions as the manufacturer is not responsible for damages caused by
omission.
Safety for children and others who are vulnerable people
●
According to EN standard
This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
●
According to IEC standard
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person being responsible for their safety.
Children
should be supervised to ensure that they do not play with the appliance
Keep all packaging away from children as there is risk of suffocation.
If you are discarding the appliance, pull the plug out of the socket, cut the
connection cable (as close to the appliance as you can) and remove the
door to prevent children playing from suffering an electric shock or from
closing themselves inside it.
If this appliance, featuring a magnetic door seals, is to replace an older
appliance having a spring lock (latch) on the door or lid, be sure to make
the spring lock unusable before you discard the old appliance. This will
prevent it from becoming a death trap for a child.
3
General safety
WARNING - This appliance is intended to be used in household
and similar applications such as
-staff kitchen areas in shops, offices and other working environments;
-farm houses and hotels, motels and other residential type environments;
-bed and breakfast type environments;
-catering and similar non-retail applications.
WARNING - Do not store explosive substances such as aerosol cans with
a flammable propellant in this appliance.
WARNING - If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to
avoid a hazard.
WARNING - Keep ventilation openings, in the appliance enclosure or in
the built-in structure, clear of obstruction.
WARNING - Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
WARNING - Do not damage the refrigerant circuit.
WARNING - Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended
by the manufacturer.
WARNING - The refrigerant and insulation blowing gas are flammable.
When disposing of the appliance, do so only at an authorized waste
disposal center. Do not expose to flame.
WARNING -When positioning the appliance, ensure the supply cord is not
trapped or damaged.
WARNING -Do not locate multiple portable socket-outlets or portable
power supplies at the rear of the appliance.
Replacing the illuminating lamps
WARNING-The illuminating lamps must not be replaced by the user! If
the illuminating lamps is damaged, contact the customer helpline for
assistance. This warning is only for refrigerators that contain illuminating
lamps.
Refrigerant
The refrigerant isobutene (R600a) is contained within the refrigerant circuit of
the appliance, a natural gas with a high level of environmental compatibility,
which is nevertheless flammable. During transportation and installation of the
appliance, ensure that none of the components of the refrigerant circuit
becomes damaged.
The refrigerant (R600a) is flammable.
4
WARNING — Refrigerators contain refrigerant and gases in the insulation.
Refrigerant and gases must be disposed of professionally as they may cause
eye injuries or ignition. Ensure that tubing of the refrigerant circuit is not
damage prior to proper disposal.
It is hazardous for anyone other than an Authorized Service Person to service
this appliance. In Queensland the Authorized Service Person Must hold a Gas
Work Authorized for hydrocarbon refrigerants to carry out servicing or repairs
which involve removal of covers.
WARNING: Risk of fire / flammable materials
If the refrigerant circuit should be damaged:
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is situated.
It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a short circuit, fire, and/or electric shock.
Electrical safety
1.The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged. A crushed or
damaged power plug may overheat and cause a fire.
3. Make sure that you can access the main plug of the appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power plug. There is a
risk of electric shock or fire.
6.You must not operate the appliance without the interior lighting lamp cover.
7.The fridge is only applied with power supply of single phase alternating
current of 220~240V/50Hz. If fluctuation of voltage in the district of user is so
large that the voltage exceeds the above scope, for safety sake, be sure to
apply A.C. Automatic voltage regulator of more than 350W to the fridge. The
fridge must employ a special power socket instead of common one with other
electric appliances. Its plug must match the socket with ground wire.
Daily use
Do not store flammable gas or liquids in the appliance, there is a risk of an
explosion.
Do not operate any electrical appliances in the appliance (e.g. electric ice
cream makers, mixers etc.).
When unplugging always pull the plug from the mains socket, do not pull
on the cable.
Do not place hot items near the plastic components of this appliance.
Do not place food products directly against the air outlet on the rear wall.
Store pre-packed frozen food in accordance with the frozen food
5
manufacturer’s instructions.
The appliances manufactures storage recommendations should be strictly
adhered to. Refer to relevant instructions for storage.
Do not place carbonated or fizzy drinks in the freezer compartment as it
creates pressure on the container, which may cause it to explode,
resulting in damage to the appliance.
Frozen food can cause frost burns if consumed straight from the freezer
compartment.
Do not place the appliance in direct sunlight.
Keep burning candles, lamps and other items with naked flames away
from the appliance so that do not set the appliance on fire.
The appliance is intended for keeping food stuff and/or beverages in
normal household as explained in this instruction booklet. You should take
care when move it as the appliance is heavy.
Do not remove nor touch items from the freezer compartment if your
hands are damp/wet, as this could cause skin abrasions or frost/freezer
burns.
Never use the base, drawers, doors etc. to stand on or as supports.
Frozen food must not be refrozen once it has been thawed out.
Do not consume ice popsicles or ice cubes straight from the freezer as
this can cause freezer burn to the mouth and lips.
To avoid items falling and causing injury or damage to the appliance, do
not overload the door racks or put too much food in the crisper drawers.
Note:
When one of the two doors is open, the LED lights is on. When the two
doors keep at the same angle for 10 seconds, the LED lights is off.
caution!
Care and cleaning
Before maintenance, switch off the appliance and disconnect the mains
plug from the mains socket.
Do not clean the appliance with metal objects, steam cleaner, ethereal
oils, organic solvents or abrasive cleansers.
Do use a plastic scraper instead of a sharp object to remove frost from the
appliance.
Installation Important!
For electrical connection carefully, follow the instructions given in this
manual. Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report possible damages
immediately to the place you bought it. In this case retain packing.
It is advisable to wait at least four hours before connecting the appliance
to allow the oil to flow back in the compressor.
Adequate air circulation should be around the appliance, lacking this leads
6
to overheating. To achieve sufficient ventilation, follow the instructions
relevant to installation.
Wherever possible the back of the product should not be too close to a
wall to avoid touching or catching warm parts (compressor) to prevent the
risk of a fire, follow the instructions relevant to installation.
The appliance must not be locating close to radiators or cookers.
Make sure that the mains plug is accessible after the installation of the
appliance.
Service
Any electrical work required to do the servicing of the appliance should be
carried out by qualified electrician or competent person.
This product must be serviced by an authorized Service
Center, and only genuine spare parts must be used.
1)If the appliance is Frost Free.
2)If the appliance contains freezer compartment.
Note: Children aged from 3 to 8 years are allowed to load and unload
refrigerating appliances. (This clause applies only to the EU region.)
7
Installing your new appliance
Before using the appliance for the first
time, you should be informed of the
following tips.
Warning!
For proper installation, this refrigerator
must be placed on a level surface of hard
material that is the same height as the
rest of the flooring. This surface should be
strong enough to support a fully loaded
refrigerator.
The rollers, which are not castors, should
be only used for forward or backward
movement. Moving the refrigerator
sideways may damage your floor and the
rollers.
Ventilation of appliance
In order to improve efficiency of
the cooling system and save
energy, it is necessary to
maintain good ventilation around the
appliance for the dissipation of heat. For
this reason, sufficient clear space should
be available around the refrigerator.
Suggest:
It is advisable for there to be
50mm of space from the back to the wall,
at least 100mm from its top, at least
50mm from its side to the wall and a clear
space in front to allow the doors to open
135°. As shown in follow diagrams.
Note:
This appliance performs well within the
climate class from SN to T showed in the
table below. It may not work properly if
being left at a temperature above or below
the indicated range for a long period.
Climate class Ambient temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
Stand your appliance in a dry place to
avoid high moisture.
Keep the appliance out of direct
sunlight, rain or frost. Stand the appliance
away from heat sources such as stoves,
fires or heaters.
Leveling of appliance
8
For sufficient leveling and air circulating in
the lower rear section of the appliance, the
bottom feet may need to be adjusted. You
can adjust them manually by hand or by
using a suitable spanner.
Tools you will need:
Not provided
Philips Screwdriver &
Slotted Screwdriver
Provided
Allen wrench
Handle supports
Handle
To allow the doors to self-close, tilt the
top backwards by 10-15mm.
You can adjust them manually by hand or
using a suitable spanner.
Note:
If required you may lay the refrigerator
on its back in order to gain access to the
base, you should rest it on soft foam
packaging or similar material to avoid
damaging the backboard of the
refrigerator.
There is no need to install these
accessories under normal usage.
Only under the extreme circumstances,
that is opening the door about 90 degree,
this refrigerator may take risk of tipping.
Then rubber supporting pad should be
fastened to the lower base cover to
steady this appliance.
1. Tilt appliance to find screw hole on the
left of lower base cover.
2. Put screw into the hole of rubber
supporting pad.
3. Make screw in alignment with the hole
on lower base cover. Fasten rubber
supporting pad to the base cover firmly by
a cross screwdriver (self-provided).
9
Installing the handles
Before you use the appliance, you have to
install the handles provided in the fridge
chamber.
Please follow procedures below to install
and reverse the handle.
Fasten the handle supports (C) to the
door by a cross screwdriver (self-
provided).
Place the handle (A) on the door by
fitting the handle footprints over the
handle supports (C), then fasten the
screws (B) with Allen wrench (provided in
plastic).
10
Description of the appliance
View of the appliance
1. Display panel
2. Upper air duct
3. Shelf part (Upper)
4. Lower air duct
5. Shelf part (Middle)
6. Shelf part (Lower)
7. Drawer
8. Adjustable bottom feet
9. Door switch
10. Door
11. Freezer shelf (Big)
12. Door gasket
13. Handle
14. Freezer shelf (Small)
Note
！
Due to unceasing modification of our products, your refrigerator may be slightly different
from this instruction manual, but its functions and using methods remain the same.
To get the best energy efficiency of this product, please place all shelves, drawers and
baskets on their original position as the illustration above.
11
Display controls
Use your appliance according to the following control regulations, your appliance has the
corresponding functions as the control panels showed in the pictures below.
Controlling the temperature
Use your appliance according to the
following control regulations, your
appliance has the corresponding functions
as the control panels showed in the
pictures above.
Caution!
When you set a temperature, you set an
average temperature for the whole
refrigerator cabinet. Temperatures inside
each compartment may vary from the
temperatures displayed on the panel,
depending on how much food you store
and where you place it. High or low room
temperature may also affect the actual
temperature inside the appliance.
1. POWER
Press and hold the
POWER
button at
least 3 seconds to enter/exit standby
mode. After entering the standby mode,
the POWER icon will light up, the
temperature area will display "OF", other
icons will be extinguished, and other key
functions will be invalid, until the original
control state is restored after pressing the
button again to exit the standby mode.
2. Freezer/Fridge conversion
Press and hold Freezer/Fridge conversion
button for 3 seconds to convert between
freezer compartment and fridge
compartment.
After that, the light will go out first,
and then turn on or flash once, which is
a normal phenomenon that the
control system has realized switching.
Caution
！
Before changing the compartment
setting, make sure that the stored food
is suitable for new setting mode. If
not, please empty it first.
When the freezer mode is changed
to fridge mode, please open the door
for 5 minutes before putting in the food
that needs to be refrigerated.
When the fridge mode is changed
to freezer mode, please close the door
and run for 200 minutes before putting
in the food that needs to be frozen.
When the fridge mode is changed
to freezer mode,
ensure there are no
bottled or canned drinks (especially
carbonated drinks) in the freezer
compartment. Bottles and cans may
explode.
3. T E M P.
Press the TEMP. button to
adjust the
temperature to the desired setting.
If you have set the Freezer
compartment type to Fahrenheit,
the
temperature will be set in the following
sequence.
If you have set the Freezer
compartment type to Celsius,
the
temperature will be set in the following
sequence.
12
If you have set the Fridge compartment
type to Fahrenheit,
the temperature will
be set in the following sequence.
If you have set the Fridge compartment
type to Celsius,
the temperature will be
set in the following sequence.
4.
°F /°C
Press and hold the “T E M P. ” button for 3
seconds to toggle between Celsius and
Fahrenheit on the display.
5. Door Alarm
When the door has been opened for over
2 minutes, the door alarm will come on.
In case of door alarm, the door alarm
indicator will light up and blink, and "dr" is
displayed in the temperature display area,
meanwhile, the buzzer will sound 3 times
every 1 minute and will stop alarming
automatically after 8 minutes. The door
alarm can be cleared by closing the door.
In case of door alarm, it can be
turned off by closing the door.
In case of door alarm, you can press
and hold the “MODE” button for at
least 3 seconds to clear the door
alarm sound, and then the control
panel will show “dr” and the “Alarm”
icon will light.
To save energy, please avoid
keeping the door open for a long time
when using the appliance.
6. Energy Saving
This function makes the refrigerator
work in a power saving mode which is
useful for reducing energy consumption
when you are away.
Press the “MODE” button to turn on the
Energy saving function. The “Energy
Saving” icon will be illuminated.
When the Energy Saving function is
on, in the fridge state, the
temperature is set to 6°C (43°F); in
the freezer state, the temperature is
set to -17°C (1°F).
When Energy Saving function is on,
you can turn it off by pressing the
“MODE” or “TEMP.” button and the
refrigerator temperature setting will
revert back to the previous setting.
7. Super Freeze
The Super Freeze feature helps to keep
the food stored in the freezer at the set
temperature during periods of high
usage, large grocery loads, or
temporarily warm room temperatures.
In the freezer state, press the “MODE”
button to turn on the Super Freeze
function. The “Super Freeze/Super
Cool” icon will be illuminated.
When the Super Freeze function is
on, in the freezer state, the
temperature is set to -24°C (-11°F).
When Super Freeze function is on,
you can turn it off by pressing the
“MODE” or “TEMP.” button and the
refrigerator temperature setting will
revert back to the previous setting.
Super Freeze will automatically turn
off after 52 hours.
NOTE:
Do not leave glass bottles or
canned drinks (especially carbonated
drinks) in the freezer
compartment.
Bottles and cans may explode.
8. Super Cool
The Super Cool feature helps to keep
food stored in the refrigerator at the set
temperature during periods of high
usage, large grocery loads, or
temporarily warm room temperatures.
In the fridge state, press the “MODE”
button to turn on the Super Cool
function. The “Super Freeze/Super
Cool” icon will be illuminated.
13
When the Super Cool function is
on, in the fridge state, the
temperature is set to 2°C (36°F).
When Super Cool function is on,
you can turn it off by pressing the
“MODE” or “TEMP.” button and the
refrigerator temperature setting will
revert back to the previous setting.
Super Cool will automatically turn
off after 6 hours.
9. Demo mode
Demo mode is for store display and it
prevents the refrigerator from
generating cool air. In this of Cooling off
Mode, the refrigerator may seem like it
is working but it will not make cool air.
The display panel will show special
segments as follow.
Press and hold the "POWER" and
"MODE" buttons at the same time for 3
seconds to turn off the demo mode and
the buzzer gave a long sound.
14
Reversing the door
The side at which the door opens can
be changed, from the right side (as
supplied) to the left side, if the
installation site requires.
Warning! When reversing the door, the
appliance must not be connected to the
mains. Ensure that the plug is removed
from the mains socket.
Tools you will need
Note: If required you may lay the
refrigerator on its back in order to gain
access to the base, you should rest it on
soft foam packaging or similar material
to avoid damaging the backboard of the
refrigerator. To reverse the door, the
following steps are generally
recommended.
1. Use a putty knife or thin-blade
screwdriver to prize the screw hole
cover which is at the top left corner of
the refrigerator, and the upper hinge
cover which is at the top right corner of
the refrigerator.
2. Unscrew the special flange self-
tapping screws which are used for fixing
the right upper hinge part by an 8mm
socket driver or a spanner (please
support the upper door with your hand
when doing it).
3. Remove the door from the lower hinge.
NOTE: When removing the door, watch
for washer(s) between the lower hinge
and the bottom of the lower door that
may stick to the door. Do not lose.
4. Place it on a smooth surface with its
panel upwards. Loose screw 2 and part
1, then install them to the left side and
tighten securely.
15
5. Lay the refrigerator on soft foam
packaging or similar material. Remove
both adjustable bottom feet parts, and
the lower hinge part by unscrewing the
special flange self-tapping screws.
6. Loose out the lower hinge pin,
change it to the reverse hole site, then
tighten it into position follow the picture
below.
7. Replace the lower hinge part to the
left side and fixing it with the special
flange self-tapping screws. Replace the
adjustable bottom feet parts to another
side and fixing it.
8. Transfer the door to the property
position, adjust the lower hinge part,
make the hinge axis into the lower hole
of the door.
9. Transfer the upper hinge part and
make the upper hinge axis into the
upper hole of the door, and adjust the
position of the door (please support the
door with your hand when doing it),
fixing the upper hinge part with the
special flange self-tapping screws.
10. Install the screw hole cover on the
top right corner of the refrigerator. Install
the upper hinge cover (which is in the
plastic bag) on the left corner. Put the
other upper hinge cover into the plastic
bag.
16
11. Move the handle from the left side of
door to the right side.
Warning! When changing the side at
which the door opens, the appliance
must not be connected to the mains.
Remove plug from the mains
beforehand.
17
Using your appliance
Your appliance has the accessories as the “Description of the appliance” showed in
general, with this part of instruction you can have the right way to use them. We
recommend that you read through them carefully before using the appliance.
Door rack
●
It is suitable for the storage
of eggs,
canned liquid,
bottled drinks and packed
food, etc. under fridge mode. Do not
place too many heavy things in the
racks.
Shelf in Refrigerator chamber
1.There are shelves in refrigerator
chamber, and they can be taken out to be
cleaned.
2.The crisper is suitable for storage of
vegetables and fruit, etc.
under fridge
mode.
Freezer chamber
(
under freezer mode
)
The freezer chamber is suitable for
storage of foods required to be frozen,
such as meat, ice.
Caution!
Do not close refrigerator door
when installing deep bracket, It may
damage the unit.
Ensure that drink bottles are not left in the
freezer for a longer time than needed as
freezing liquid may cause the bottle to
break.
18
Cleaning and care
For hygienic reasons the appliance
(including exterior and interior
accessories) should be cleaned at least
every two months.
Warning!
To avoid electrical shock, the appliance
must not be connected to the main power
supply during cleaning. Before cleaning,
switch the appliance off and remove the
plug from the main socket.
Exterior cleaning
To maintain good appearance of your
appliance, you should clean it regularly.
Spray water onto a cleaning cloth
instead of spraying directly on the
surface of the appliance. This helps
ensure an even distribution of moisture
to the surface.
Clean the doors, handles and cabinet
surfaces with a mild detergent and then
wipe dry with a soft cloth.
Caution!
Don’t use sharp objects to clean with, as
they are likely to scratch the surface.
Don’t use Thinner, Car detergent,
bleach,
ethereal oil, abrasive cleansers or organic
solvent such as Benzene for cleaning.
They may damage the surface of the
appliance and may cause fire.
Interior cleaning
You should clean the appliance interior
regularly. It will be easier to clean when
food stocks are low. Wipe the inside of the
fridge freezer with a weak solution of
backing soda and water, and then rinse
with warm water using a wrung-out
sponge or cloth. Wipe completely dry
before replacing the shelves and baskets.
Thoroughly dry all surfaces and
removable parts before putting them back
into place.
Although this appliance automatically
defrosts, a layer of frost may occur on the
freezer compartment’s interior walls if the
freezer door is opened frequently or kept
open too long. If the frost is too thick,
choose a time when the freezer is nearly
empty and proceed as follows:
1. Remove existing food and accessories
baskets, unplug the appliance from the
main power and leave the doors open.
Ventilate the room thoroughly to
accelerate the process.
2. When defrosting is completed, clean
your freezer as described above.
Warning!
Do not use sharp objects to remove frost
from the freezer compartment. Only after
the interior is completely dry should the
appliance be switched back on and
plugged back into the main socket.
Door seals cleaning
Take care to keep door seals clean. Sticky
food and drinks can cause seals to stick
to the cabinet and tear when you open the
door. Wash seal with a mild detergent and
warm water. Rinse and dry it thoroughly
after cleaning.
Caution!
Only after the door seals are
completely dry should the appliance be
powered on.
Replacing the LED light
Warning: The LED light must be replaced
by a competent person. If the LED light is
damaged, follow the steps below:
1. Unplug your appliance.
2. Remove light cover by rising up and
pulling out the LED light.
3. Hold the LED light with one hand and
pull it with the other hand while pressing
the connector latch.
4. Replace LED light and snap it correctly
in place and recover the light cover.
19
Helpful hints and tips
Energy saving tips
We recommend that you follow the tips
below to save energy.
Try to avoid keeping the door open for
long periods in order to conserve energy.
Ensure the appliance is away from any
sources of heat (Direct sunlight, electric
oven or cooker etc.)
Don‘t set the temperature colder than
necessary.
Don’t store warm food or evaporating
liquid in the appliance.
Place the appliance in a well ventilated,
humidity free, room. Please refer to
Installing your new appliance chapter.
If the diagram shows the correct
combination for the drawers, crisper and
shelves, do not adjust the combination as
this is designed to be the most energy
efficient configuration.
Hints for fresh food refrigeration
Do not place hot food directly into the
refrigerator or freezer, the internal
temperature will increase resulting in the
compressor having to work harder and will
consume more energy.
Do cover or wrap the food
，
particularly if
it has a strong flavor.
Place food properly so that air can
circulate freely around it.
Hints for refrigeration
Meat (All Types) Wrap in polythene food:
wrap and place on the glass shelf above
the vegetable drawer. Always follow food
storage times and use by dates
suggested by manufacturers.
Cooked food, cold dishes, etc.:
They should be covered and may be
placed on any shelf.
Fruit and vegetables:
They should be stored in the special
drawer provided.
Butter and cheese:
Should be wrapped in airtight foil or
plastic film wrap.
Milk bottles:
Should have a lid and be stored in the
door racks.
Hints for freezing
When first starting-up or after a period
out of use, let the appliance run at least 2
hours on the higher settings before putting
food in the compartment.
Prepare food in small portions to enable
it to be rapidly and completely frozen and
to make it possible to subsequently thaw
only the quantity required.
Wrap up the food in aluminum foil or
polyethylene food wraps which are
airtight,
Do not allow fresh
，
unfrozen food to
touch the food which is already frozen to
avoid temperature rise of the latter.
Iced products
，
if consumed immediately
after removal from the freezer
compartment, will probably cause frost
burns to the skin.
It is recommended to label and date
each frozen package in order to keep
track of the storage time.
Hints for the storage of frozen food
Ensure that frozen food has been stored
correctly by the food retailer
Once defrosted
，
food will deteriorate
rapidly and should not be re-frozen. Do
not exceed the storage period indicated
by the food manufacturer.
Switching off your appliance
If the appliance needs to be switched off
for an extended period, the following
steps should be taken to prevent mold on
the appliance.
20
1. Remove all food.
2. Remove the power plug from the mains
socket.
3. Clean and dry the interior thoroughly.
4. Ensure that all the doors are wedged
open slightly to allow air to circulate.
21
Troubleshooting
If you experience a problem with your appliance or are concerned that the appliance is
not functioning correctly, you can carry out some easy checks before calling for service,
please see below.
Warning!
Don’t try to repair the appliance yourself. If the problem persists after you have
made the checks mentioned below, contact a qualified electrician, authorized service
engineer or the shop where you purchased the product.
Problem Possible cause & Solution
Appliance is not working
correctly
Check whether the power cord is plugged into the power
outlet properly.
Check the fuse or circuit of your power supply, replace if
necessary.
It is normal that the freezer is not operating during the defrost
cycle, or for a short time after the appliance is switched on to
protect the compressor.
Odors from the
compartments
The interior may need to be cleaned.
Some food, containers or wrapping cause odors.
Noise from the
appliance
The sounds below are quite normal:
Compressor running noises.
Air movement noise from the small fan motor in the freezer
compartment or other compartments.
Gurgling sound similar to water boiling.
Popping noise during automatic defrosting.
Clicking noise before the compressor starts.
Other unusual noises are due to the reasons below and may
need you to check and take action:
The cabinet is not level.
The back of appliance touches the wall.
Bottles or containers fallen or rolling.
The motor runs
continuously
It is normal to frequently hear the sound of the motor, it will
need to run more when in following circumstances:
Temperature setting is set colder than necessary.
Large quantity of warm food has recently been stored within
the appliance.
The temperature outside the appliance is too high.
Doors are kept open too long or too often.
After you installing the appliance or it has been switched off
for a long time.
22
A layer of frost occurs in
the compartment
Check that the air outlets are not blocked by food and ensure
food is placed within the appliance to allow sufficient
ventilation. Ensure that door is fully closed. To remove the
frost, please refer to the “Cleaning and care” chapter.
Temperature inside is
too warm
You may have left the doors open too long or too frequently;
or the doors are kept open by some obstacle; or the
appliance is located with insufficient clearance at the sides,
back and top.
Temperature inside is
too cold
Increase the temperature by following the “controls panel”
chapter.
Doors can’t be closed
easily
Check whether the top of the refrigerator is tilted back by 10-
15mm to allow the doors to self-close, or if something inside
is preventing the doors from closing.
23
Disposal of the appliance
It is prohibited to dispose of this appliance as household waste.
Packaging materials
Packaging materials with the recycle symbol are recyclable. Dispose of the packaging
into a suitable waste collection container to recycle it.
Before disposal of the appliance
1. Pull out the mains plug from the mains socket.
2. Cut off the power cord and discard with the mains plug
Warning!
Refrigerators contain refrigerant and gases in the insulation. Refrigerant and
gases must be disposed of professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.
Correct Disposal of this product
This symbol on the product or in its packing indicates that this product may
not be treated as household waste. Instead, it should be taken to the
appropriate waste collection point for the recycling of electrical and
electronic equipment. By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by the inappropriate
waste handling of this product. For more detailed information about the
recycling of this product, please contact your local council your household
waste disposal service, or the shop where you purchased the product.
To avoid contamination of food, please respect the following instructions
- Opening the door for long periods can cause a significant increase of the temperature in
the compartments of the appliance.
- Clean regularly surfaces that can come in contact with food and accessible drainage
systems.
- Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
- Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making ice-cream and making ice cubes.
- One-, two- and three- star compartments are not suitable for the freezing of fresh food.
Order
Compartments
TYPE
Target storage
temp.[ °C]
Appropriate food
1 Fridge +2~+8
Eggs, cooked food, packaged food, fruits
and vegetables, dairy products, cakes,
Drinks and other foods which are not
suitable for freezing.
2 (***)*-Freezer ≤-18
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
products(recommended time is 3 months –
24
nutrition values and taste decrease with
time), suitable for frozen fresh food.
3 ***-Freezer ≤-18
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
products(recommended time is 3 months –
nutrition values and taste decrease with
time). Not suitable for freezing fresh food.
4 **-Freezer ≤-12
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
products(recommended time is 2 months –
nutrition values and taste decrease with
time). Not suitable for freezing fresh food.
5 *-Freezer ≤-6
Seafood(fish, shrimp, shellfish), freshwater
aquatic products and meat
products(recommended time is 1 month –
nutrition values and taste decrease with
time). Not suitable for freezing fresh food.
6 0-star -6~0
Fresh pork, beef, fish, chicken, some
packaged processed foods, etc.
(Recommended to eat within the same day,
preferably not later than 3 days).
7 Chill -2~+3
Fresh/frozen pork, beef, fish, chicken,
freshwater aquatic products, etc. (7 days
below 0°C and above 0°C is recommended
for consumption within that day, preferably
no more than 2 days). Seafood(less than 0
for 15 days, it is not recommended to store
above 0°C).
8 Fresh Food 0~+4
Fresh pork, beef, fish, chicken, cooked
food, etc.(Recommended to eat within the
same day, preferably no more than 3 days).
9 Wine +5~+20 red wine, white wine, sparkling wine etc.
Note: please store different foods according to the compartments or target storage
temperature of your purchased products.
- If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mold developing within the appliance.
Water dispenser cleaning(special for water dispenser products):
- Clean water tanks if they have not been used for 48h; flush the water system connected
to a water supply if water has not been drawn for 5 days.
WARNING!
Food needs to be packed in bags before putting into the refrigerator, and
liquids need to be packed in bottles or capped containers to avoid the problem that the
product design structure is not easy to clean.
