DS-KD7003EY-IME2 Module Door Staon User Manual
i
PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR
LOSS.
●
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT SECURITY
RISKS, AND HIKVISION SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INFECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, HIKVISION WILL PROVIDE
TIMELY TECHNICAL SUPPORT IF REQUIRED.
●
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY
RIGHTS. YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT
RELATED TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF
HUMAN RIGHTS ABUSES.
●
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS DOCUMENT AND THE APPLICABLE LAW, THE
LATTER PREVAILS.
© Hangzhou Hikvision Digital Technology Co., Ltd. All rights reserved.
DS-KD7003EY-IME2 Module Door Staon User Manual
ii
Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note
Provides addional informaon to emphasize or supplement
important points of the main text.
DS-KD7003EY-IME2 Module Door Staon User Manual
iii
Regulatory Informaon
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE"
and comply therefore with the applicable harmonized European standards listed
under the EMC Direcve 2014/30/EU, the RoHS Direcve 2011/65/EU
2012/19/EU (WEEE direcve): Products marked with this symbol cannot be disposed
of as unsorted municipal waste in the European Union. For proper recycling, return
this product to your local supplier upon the purchase of equivalent new equipment,
or dispose of it at designated
collecon points. For more informaon see:
www.recyclethis.info
2006/66/EC (baery direcve): This product contains a baery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentaon for specic baery informaon. The baery is marked with this
symbol, which may include
leering to indicate cadmium (Cd), lead (Pb), or mercury
(Hg). For proper recycling, return the
baery to your supplier or to a designated
collecon point. For more informaon see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.
This device complies with Industry Canada licence-exempt RSS standard(s). Operaon is subject to
the following two
condions:
1. this device may not cause interference, and
2. this device must accept any interference, including interference that may cause undesired
operaon of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radioexempts de licence.
L'exploitaon est autorisée aux deux condions suivantes :
1. l'appareil ne doit pas produire de brouillage, et
2.
l'ulisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est suscepble d'en compromere le fonconnement.
Under Industry Canada regulaons, this radio transmier may only operate using an antenna of a
type and maximum (or lesser) gain approved for the transmier by Industry Canada. To reduce
potenal radio interference to other users, the antenna type and its gain should be so chosen that
the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communicaon.
DS-KD7003EY-IME2 Module Door Staon User Manual
iv
Conformément à la réglementaon d'Industrie Canada, le présent émeeur radio peut fonconner
avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émeeur par
Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à l'intenon des
autres
ulisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communicaon sasfaisante.
This equipment should be installed and operated with a minimum distance 20cm between the
radiator and your body.
Cet équipement doit être installé et
ulisé à une distance minimale de 20 cm entre le radiateur et
votre corps.
DS-KD7003EY-IME2 Module Door Staon User Manual
v
About this Manual
Get the manual and related soware from or the ocial website (hp://www.hikvision.com).
Product Model
Door Staon DS-KD7003EY-IME2
Scan the QR code to get the User Manual for detailed informaon.
DS-KD7003EY-IME2 Module Door Staon User Manual
vi
Contents
Chapter 1 Appearance ................................................................................................................ 1
Chapter 2 Terminal and Wiring ................................................................................................... 3
2.1 Terminal Descripon .............................................................................................................. 3
Chapter 3 Installaon ................................................................................................................. 5
3.1 One-Module Installaon ........................................................................................................ 6
3.1.1 One-Module Surface Mounng .................................................................................... 6
3.1.2 One-Module Flush Mounng ...................................................................................... 10
3.2 Two-Module Installaon ...................................................................................................... 17
3.2.1 Two-Module Surface
Mounng .................................................................................. 17
3.2.2 Two-Module Flush Mounng ...................................................................................... 23
3.3 Three-Module Installaon ................................................................................................... 29
3.3.1 Three-Module Surface
Installaon .............................................................................. 29
3.3.2 Three-Module Flush Mounng ................................................................................... 36
Chapter 4 Topology ................................................................................................................... 42
Chapter 5 Cable and Transmission Distance .............................................................................. 47
Chapter 6 Typical
Applicaon and Flow .................................................................................... 48
Chapter 7 Set Device Rotary DIP Switch .................................................................................... 49
Chapter 8 Call Indoor
Staon from Door Staon ....................................................................... 52
Chapter 9 Unlock Door ............................................................................................................. 53
Chapter 10 Enable AP Mode ..................................................................................................... 54
10.1 Enable AP Mode on Device ................................................................................................ 54
10.2 Enable AP Mode on PC Web .............................................................................................. 54
10.3 FAQ of AP Mode ................................................................................................................. 54
Chapter 11 Login Web Browser ................................................................................................. 57
Chapter 12 Forgot Password ..................................................................................................... 58
12.1 Forget Password via Mobile Web ....................................................................................... 58
DS-KD7003EY-IME2 Module Door Staon User Manual
vii
12.2 Forget Password via PC Web .............................................................................................. 58
Chapter 13 Overview ................................................................................................................ 59
13.1 Overview on Mobile Web .................................................................................................. 59
13.2 Overview on PC Web ......................................................................................................... 59
Chapter 14 Person Management .............................................................................................. 61
14.1 Person Management on Mobile Web ................................................................................ 61
14.2 Person Management on PC Web ....................................................................................... 62
Chapter 15 Device Management ............................................................................................... 64
15.1 View Room No. Details on Mobile Web ............................................................................. 64
15.2 Device Management on PC Web ....................................................................................... 64
Chapter 16 View Device
Informaon ........................................................................................ 65
16.1 View Device Informaon on Mobile Web .......................................................................... 65
16.2 View Device
Informaon on PC Web ................................................................................. 65
Chapter 17 Time
Sengs .......................................................................................................... 66
17.1 Set Time on Mobile Web ................................................................................................... 66
17.2 Set DST on Mobile Web ..................................................................................................... 67
17.3 Set Time on PC Web ........................................................................................................... 67
17.4 Set DST on PC Web ............................................................................................................ 68
Chapter 18 Audio
Sengs ........................................................................................................ 69
18.1 Set Audio Parameters on Mobile Web ............................................................................... 69
18.2 Set Audio Parameters on PC Web ...................................................................................... 69
Chapter 19 Image
Sengs ........................................................................................................ 70
19.1 Set Image Parameters on Mobile Web .............................................................................. 70
19.2 Set Image Parameters on PC Web ...................................................................................... 70
19.3 Set OSD (On-Screen Display) on PC Web ........................................................................... 71
19.4 Crop Target on PC Web ...................................................................................................... 71
Chapter 20
Moon Detecon Sengs ...................................................................................... 73
20.1 Set
Moon Detecon on Mobile Web ............................................................................... 73
DS-KD7003EY-IME2 Module Door Staon User Manual
viii
20.2 Set Moon Detecon on PC Web ...................................................................................... 73
Chapter 21 Access Control Sengs ........................................................................................... 74
21.1 Set Door Parameters on Mobile Web ................................................................................ 74
21.2 Set Public Password on Mobile Web .................................................................................. 74
21.3 Set I/O Parameters on Mobile Web ................................................................................... 74
21.4 Set Door Parameters on PC Web ....................................................................................... 75
21.5 Set Public Password on PC Web ......................................................................................... 75
21.6 Set I/O Parameters on PC Web .......................................................................................... 75
Chapter 22 Video Intercom
Sengs .......................................................................................... 77
22.1 Set Call Parameters on Mobile Web .................................................................................. 77
22.2 Press Buon to Call on Mobile Web .................................................................................. 77
22.3 Set Sub Module on Mobile Web ........................................................................................ 77
22.4 Set Ringtone on PC Web .................................................................................................... 78
22.5 Set Call Parameters on PC Web .......................................................................................... 78
22.6 Press Buon to Call on PC Web ......................................................................................... 78
22.7 Set Sub Module on PC Web ............................................................................................... 79
Chapter 23 Upgrade and Maintenance ..................................................................................... 80
23.1 Upgrade and Maintenance on Mobile Web ....................................................................... 80
23.2 Upgrade and Maintenance on PC Web .............................................................................. 80
Chapter 24 Change
Acvaon/Admin Password ....................................................................... 83
24.1 Change Administrator's Password on Mobile Web ............................................................ 83
24.2 Change Administrator's Password on PC Web ................................................................... 83
Chapter 25 Account Security
Sengs ........................................................................................ 85
25.1 Set Account Security on Mobile Web ................................................................................ 85
25.2 Set Account Security on PC Web ........................................................................................ 85
Chapter 26 View Device Arming/Disarming
Informaon on PC Web ......................................... 86
Chapter 27 View Online Users on PC Web ................................................................................. 87
Chapter 28 Set
Noce Publicaon on PC Web ........................................................................... 88
DS-KD7003EY-IME2 Module Door Staon User Manual
ix
Chapter 29 Device Debugging on PC Web ................................................................................. 89
Chapter 30 View Online Document ........................................................................................... 90
30.1 View Online Document on Mobile Web ............................................................................ 90
30.2 View Online Document on PC Web .................................................................................... 90
Chapter 31 View Open Source
Soware License ....................................................................... 91
31.1 View Open Source Soware License on Mobile Web ........................................................ 91
31.2 View Open Source Soware License on PC Web ............................................................... 91
Chapter 32 Quick Operaon via Web Browser .......................................................................... 92
32.1 Change Password Type ...................................................................................................... 92
32.2 Select Language ................................................................................................................. 92
32.3 Time Sengs ...................................................................................................................... 92
32.4 Administrator Sengs ....................................................................................................... 93
32.5 Link Video Intercom Devices .............................................................................................. 94
DS-KD7003EY-IME2 Module Door Staon User Manual
x
Chapter 1 Appearance
Main Unit
Figure 1-1 Main Unit Appearance
Note
●
Loudspeaker/Mic Adjustment Area: Press the buckle and push the tag to the le to uncover the
metal cover. Remove the dust-proof plug and use drill to adjust the volume of loudspeaker and
the microphone. (The rst is for the loudspeaker and the second is for the Mic.)
●
Reset
Buon：Reset AP Mode Password: Hold the buon for 5 s.
●
Restore Factory
Sengs: Hold the buon for 10 s.
●
DIP Switch: Set the door staon's DIP switch address and video intercom system can nd the
door staon according to the address.
●
Call
Buon: By default, press call buon 1 to call Room No.1 and press call buon 2 to call Room
No.2.
●
Name Tag：Remove the metal cover and you can sck a name tag according to your preference.
Name tag 1: Two call
buons Le: Press once to call a specic room No. Hold the buon for 10 s
to enable the device AP mode. Right: Press once to call a specic room No. Hold the buon for
DS-KD7003EY-IME2 Module Door Staon User Manual
1
10 s to synchronize the device parameters to the web, including contacts, language, device me,
etc.
Name tag 2: one call buon Press once to call a specic room No.
Name tag 3: No call
buon
DS-KD7003EY-IME2 Module Door Staon User Manual
2
Chapter 2 Terminal and Wiring
2.1 Terminal Descripon
Terminals
Figure 2-1 Main Unit Terminals
Table 2-1 Descripons of Terminals and Interfaces
No. Interface Descripon
A1 485- Module-connecng Interface
A2 485+
A3 12V 1A
A4 GND
B1 NC Door Lock Relay Output (NC)
B2 NO Door Lock Relay Output (NO)
B3 COM Common Interface
B4 LOCK1 Door Lock Interface
B5 485- Reserved
B6 485+
B7 12VDC 12 V power input
DS-KD7003EY-IME2 Module Door Staon User Manual
3
No. Interface Descripon
B8 GND Grounding
B9 AIN1 Alarm In Interface
B10 AIN2 Alarm In Interface
C 2-WIRE Interface 2-Wire Interface
Wiring
Figure 2-2 Wiring of Door Staon
DS-KD7003EY-IME2 Module Door Staon User Manual
4
Chapter 3 Installaon
Note
●
Make sure the device in the package is in good condion and all the assembly parts are included.
●
Sub module must work along with the main unit.
●
Set the sub module address before start the installaon steps.
●
Make sure the place for surface
mounng is at.
●
Make sure all the related equipment is
power-o during the installaon.
●
Tools that you need to prepare for installaon:
Drill (ø6), cross screwdriver (PH1*150 mm), and gradienter.
DS-KD7003EY-IME2 Module Door Staon User Manual
5
3.1 One-Module Installaon
3.1.1 One-Module Surface Mounng
Before You Start
Figure 3-1 Mounng Frame
Note
●
The depth of one module mounng frame is 33 mm.
●
The dimensions above are for reference only. The actual size can be slightly dierent from the
theorecal dimension.
Steps
1.
Paste the
installaon Scker 1 onto the wall. Make sure the scker is placed horizontally via
measuring with the gradienter.
2.
Drill 4 holes according to the screw holes on the
scker.
DS-KD7003EY-IME2 Module Door Staon User Manual
6
Figure 3-2 Drill Screw Holes
3.
Remove the scker and insert the expansion sleeves into the screw holes.
4.
Fix the
mounng frame onto the wall with 4 expansion bolts.
DS-KD7003EY-IME2 Module Door Staon User Manual
7
Figure 3-3 Fix the Mounng Frame
5.
Connect the cables to the corresponding interfaces of the main unit and insert the main unit
into the frame.
DS-KD7003EY-IME2 Module Door Staon User Manual
8
Figure 3-4 Insert the Main Unit
6.
Fix the cover onto the frame.
DS-KD7003EY-IME2 Module Door Staon User Manual
9
Figure 3-5 Fix the Cover
3.1.2 One-Module Flush
Mounng
Before You Start
Steps
1.
Drill an
installaon hole, and pull the cables out.
Note
The suggested dimension of installaon hole is 33 mm (depth).
DS-KD7003EY-IME2 Module Door Staon User Manual
10
Figure 3-6 Drill Installaon Hole
2.
Remove the plasc sheet of the cable entry.
3.
Mark the
mounng frame screw holes on the wall.
1) Route the cables through the mounng frame hole.
2) Insert the
mounng frame into the installaon hole.
3) Mark the mounng frame screw holes' posion with a marker, and take out the mounng
frame.
DS-KD7003EY-IME2 Module Door Staon User Manual
11
Figure 3-7 Mark the Screw Holes
4.
Drill 4 holes according to marks on the wall, and insert the expansion sleeves into the screw
holes.
5.
Route the cables through the gang box hole. Insert the
mounng frame into the installaon
hole. Fix the mounng frame with 4 expansion bolts.
DS-KD7003EY-IME2 Module Door Staon User Manual
12
Figure 3-8 Fix the Mounng Fame
6.
Fill the gap between the mounng frame and the wall with concrete. Remove the 4 mounng
ears with tool aer concrete is dry.
DS-KD7003EY-IME2 Module Door Staon User Manual
13
Figure 3-9 Remove the Mounng Ears
7.
Connect the cables to the corresponding interfaces of the main unit and insert the unit into the
mounng frame.
DS-KD7003EY-IME2 Module Door Staon User Manual
14
Figure 3-10 Insert the Main Unit
8.
Fix the cover and the main unit with 2 socket head cap screws by using a hexagon wrench
(supplied).
DS-KD7003EY-IME2 Module Door Staon User Manual
15
Figure 3-11 Fix the Cover
DS-KD7003EY-IME2 Module Door Staon User Manual
16
3.2 Two-Module Installaon
3.2.1 Two-Module Surface Mounng
Before You Start
Figure 3-12 Mounng Frame
DS-KD7003EY-IME2 Module Door Staon User Manual
17
Note
●
The suggested depth of the installaon hole is 33 mm.
●
The dimensions above are for reference only. The actual size can be slightly dierent from the
theorecal dimension.
Steps
1.
Paste the installaon Scker 1 onto the wall. Make sure the scker is placed horizontally via
measuring with the gradienter.
2.
Drill 4 holes according to the screw holes on the
scker. The suggested length of cables le
outside is 270 mm.
Figure 3-13 Drill Screw Holes
3.
Remove the scker and insert the expansion sleeves into the screw holes.
4.
Fix the mounng frame onto the wall with 4 expansion bolts.
DS-KD7003EY-IME2 Module Door Staon User Manual
18
Figure 3-14 Fix the Mounng Frame
5.
Thread the module-connecng line across the thread hole of the frame. Pass the main unit
connecng lines across the thread hole to the upper grid.
DS-KD7003EY-IME2 Module Door Staon User Manual
19
Figure 3-15 Placement of Lines
6.
Connect the cables.
1) Connect the lines and
module-connecng line to the corresponding interfaces of the main
unit, then place the main unit into the upper grid.
2) Connect the other end of the
module-connecng line to the input interface of the sub
module.
3) Organize the cable with cable e in the package. The suggested cable connecon picture as
shown below.
DS-KD7003EY-IME2 Module Door Staon User Manual
20
Figure 3-16 Line Connecon Eect Picture
7.
Insert the modules into the frame aer wiring. The main unit must be placed in the top grid.
DS-KD7003EY-IME2 Module Door Staon User Manual
21
Figure 3-17 Insert the Modules
8.
Use the hexagon wrench in the package to x the cover onto the frame.
DS-KD7003EY-IME2 Module Door Staon User Manual
22
Figure 3-18 Fix the Cover
3.2.2 Two-Module Flush
Mounng
Before You Start
Note
The suggested depth of the installaon hole is 33 mm.
Steps
1.
Drill the installaon hole, and pull the cable out.
Note
The suggested length of cables le outside is 270 mm.
DS-KD7003EY-IME2 Module Door Staon User Manual
23
Figure 3-19 Drill the Installaon Hole
2.
Select a cable entry and remove the plasc sheet.
3.
Mark the
mounng frame screw holes on the hole.
1) Routs the cables through the mounng frame hole.
2) Insert the
mounng frame into the installaon hole.
3) Mark the mounng frame screw holes' posion with a marker, and take out the frame.
4.
Drill 4 holes according to the marks on the wall, and insert the expansion sleeves into the screw
holes.
5.
Fix the
mounng frame with 4 expansion bolts.
DS-KD7003EY-IME2 Module Door Staon User Manual
24
Figure 3-20 Fix the Mounng Frame
6.
Fill the gap between the mounng frame and the wall with concrete. Remove the mounng ears
with tool
aer concrete is dry.
DS-KD7003EY-IME2 Module Door Staon User Manual
25
Figure 3-21 Remove the Mounng Ears
7.
Connect cables and insert the modules.
1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of the main unit,
then insert the main unit into the upper grid.
2) Connect the other end of Cable 2 to the input interface of the sub module. Insert it into the
lower grid.
DS-KD7003EY-IME2 Module Door Staon User Manual
26
Figure 3-22 Connect Cables and Insert the Modules
Note
Cable 1 refers to the cables pulled out from the wall that connected to the main unit. Cable 2
refers to the module-connecng line in the accessory package.
8.
Fix the cover with 2 socket head cap screws by using a hexagon wrench (supplied).
DS-KD7003EY-IME2 Module Door Staon User Manual
27
Figure 3-23 Fix the Cover
DS-KD7003EY-IME2 Module Door Staon User Manual
28
3.3 Three-Module Installaon
3.3.1 Three-Module Surface Installaon
Before You Start
Figure 3-24 Mounng Frame
DS-KD7003EY-IME2 Module Door Staon User Manual
29
Note
●
The dimension of two-module mounng frame (W × H × D) is: 320.8 mm × 107 mm × 32.7 mm.
●
The dimensions above are for reference only. The actual size can be slightly dierent from the
theorecal dimension.
Steps
1.
Paste the installaon scker 1 onto the wall. Make sure the scker is placed horizontally via
measuring with the gradienter.
2.
Drill 4 holes according to the screw holes on the
scker. The suggested size of hole is 6
(diameter) × 25 (depth) mm. The suggested length of cables le outside is 270 mm.
Figure 3-25 Drill Screw Holes
3.
Remove the scker and insert the expansion sleeves into the screw holes.
4.
Fix the mounng frame onto the wall with 4 expansion bolts.
DS-KD7003EY-IME2 Module Door Staon User Manual
30
Figure 3-26 Fix the Mounng Frame
Note
The mounng frame should be placed exactly as shown below for this step. The tamper plate
should be at the low right of the rst grid.
DS-KD7003EY-IME2 Module Door Staon User Manual
31
Figure 3-27 Mounng Frame
5.
Thread the module-connecng line across the thread holes of the frame. Pass the main unit
connecng line across the thread hole to the top grid.
6.
Connect the cables.
DS-KD7003EY-IME2 Module Door Staon User Manual
32
Figure 3-28 Connect the Cables
1) Connect the lines and module-connecng line 1 to the corresponding interfaces of the main
unit, then place the main unit into the upper grid.
2) Connect the other end of the
module-connecng line 1 to the input interface of the sub
module. Connect two sub modules via
module-connecng line 2.
3) Organize the cables with cable e in the package. The suggested cable connecon picture as
shown below.
DS-KD7003EY-IME2 Module Door Staon User Manual
33
Figure 3-29 Line Connecon Eect Picture
7.
Insert the modules into the frame aer wiring. The main unit must be placed in the top grid.
DS-KD7003EY-IME2 Module Door Staon User Manual
34
Figure 3-30 Insert the Modules into the Frame
8.
Use the hexagon wrench in the package to x the cover onto the frame.
DS-KD7003EY-IME2 Module Door Staon User Manual
35
Figure 3-31 Fix the Cover
3.3.2 Three-Module Flush
Mounng
Steps
1.
Cave the
installaon hole, and pull the cable out. The suggested dimension of installaon hole is
33 mm. The suggested length of cables le outside is 270 mm.
DS-KD7003EY-IME2 Module Door Staon User Manual
36
Figure 3-32 Cave the Installaon Hole
2.
Select a cable entry and remove the plasc sheet.
3.
Mark the
mounng frame screw holes on the wall.
1) Route the cables through the frame hole.
2) Insert the frame into the
installaon hole.
3) Mark the frame screw holes' posion with a marker, and take out the frame.
DS-KD7003EY-IME2 Module Door Staon User Manual
37
Figure 3-33 Mark the Screw Holes
4.
Drill 4 holes according to marks on the wall, and insert the expansion sleeves into the screw
holes.
5.
Fix the frame with 4 expansion bolts.
6.
Fill the gap between the
mounng frame and wall with concrete. Remove the mounng ears
with tool aer concrete is dry.
DS-KD7003EY-IME2 Module Door Staon User Manual
38
Figure 3-34 Remove the Mounng Ears
7.
Connect cables and insert the modules.
1) Connect Cable 1 and one end of Cable 2 to the corresponding interfaces of the main unit,
then insert the main unit into the upper grid.
2) Connect the other end of Cable 2 to the input interface of Sub Module 1. Connect one end of
Cable 3 to the output interface of Sub Module 1 and insert it into the middle grid.
3) Connect the other end of Cable 3 to the input interface of Sub Module 2. Insert it into the
boom grid.
DS-KD7003EY-IME2 Module Door Staon User Manual
39
Figure 3-35 Connect Cables and Insert Modules
Note
Cable 1 refers to the cables pulled out from the wall that connected to the main unit. Cable 2
and Cable 3 refer to the module-connecng line in the accessory package.
8.
Fix the cover and the main unit with 2 socket head cap screws by using a hexagon wrench.
DS-KD7003EY-IME2 Module Door Staon User Manual
40
Figure 3-36 Fix the Cover
DS-KD7003EY-IME2 Module Door Staon User Manual
41
Chapter 4 Topology
The 2-Wire HD devices can be used in dierent situaons.
●
Mul-Family Topology
Figure 4-1 Mul-Family Topology
Note
Each channel of the distributor can be connected to 1 door staon / 1 main and 3 sub indoor
staons / 8 main indoor staons.
●
Single Floor Topology
Figure 4-2 Single Floor Topology
DS-KD7003EY-IME2 Module Door Staon User Manual
42
●
Single Building Topology
Figure 4-3 Single Building Topology
Note
○
Up to 22 indoor staons with Wi-Fi or 64 without Wi-Fi can be used in one building. (The cable
needs to be beer than AWG20)
○
Up to 16 oor shunts can be cascaded.
●
Single Building (Combined)
DS-KD7003EY-IME2 Module Door Staon User Manual
43
Figure 4-4 Single Building (Combined)
Note
Due to system power consumpon limitaons, device needs to be powered separately aer 64
or 22 indoor staons are exceeded.
●
System Extension in one building
DS-KD7003EY-IME2 Module Door Staon User Manual
44
Figure 4-5 System Extension in one building
Note
Up to 99 indoor staons without Wi-Fi, 44 with Wi-Fi.
●
Mulple Building Topology
DS-KD7003EY-IME2 Module Door Staon User Manual
45
Figure 4-6 Mulple Building Topology
Note
○
Up to 16 buildings can be connected in the system via the distributor for cascading.
○
Up to 10 outer door staons can be connected.
○
Up to 16 sub door staons can be connected.
DS-KD7003EY-IME2 Module Door Staon User Manual
46
Chapter 5 Cable and Transmission Distance
Cable and transmission distance between devices should follow rules below.
Table 5-1 Cable and Transmission Distance
Cable
Type
DS-
KAD7061
to DS-
KAD7061
DS-
KAD7061
to Main
Indoor
Staon
Indoor
Staon to
Indoor
Staon
DS-
KAD7061
to DS-
KAD7060
DS-
KAD7060
to Power
Module/
KAD-7060-
S
DS-
KAD7060
to Door
Staon
Door
Staon to
Lock
(Power
Supply)
UTP 5 0.2
mm
2
(Cat.
5) AWG24
60 m 60 m 60 m 60 m 100 m 60 m NA
0.28 mm
2
(TP)
AWG23
60 m 40 m 40 m 40 m 80 m 40 m 30 m
0.5 mm
2
(Parallel)
AWG20
60 m 60 m 60 m 60 m 100 m 60 m 50 m
1 mm
2
(Parallel)
AWG17
60 m 60 m 60 m 60 m 100 m 60 m 50 m
1 mm
2
(TP)
AWG17
60 m 40 m 40 m 40 m 80 m 40 m 100 m
1 mm
2
(Parallel)
AWG15
60 m 40 m 60 m 60 m 100 m 60 m 100 m
Note
Distance from power supply to the furthest indoor staon is 200 m.
DS-KD7003EY-IME2 Module Door Staon User Manual
47
Chapter 6 Typical Applicaon and Flow
1. Device Deployment:
Basic Deployment
Figure 6-1 Basic Deployment
Advanced Deployment
Figure 6-2 Advanced Deployment
2. Device Management
Figure 6-3 Device Management
3. Conguraon and Management via Mobile Web
Figure 6-4 Conguraon and Management via Mobile Web
4. Call
Figure 6-5 Advanced Deployment
5. Add or Delete Person via Door Staon
Figure 6-6 Add or Delete Person via Door
Staon
6. Add or Delete Person via Door Staon
Figure 6-7 Add or Delete Person via Door Staon
DS-KD7003EY-IME2 Module Door Staon User Manual
48
Chapter 7 Set Device Rotary DIP Switch
Aer door staons have been connected to indoor staons, you can set rotary DIP switch of these
devices.
DIP Switch of Door Staon
Use the rotary switch to set the building No., door staon No., sub door staon, outer door staon
No. and door open duraon. The Tens column refers to the number in Tens, and the Units column
refers to the number in Units. On each rotary DIP switch, 0 to 9 refers to No. 0 to 9. In total, you
can use 1 to 99 to number the building. If the door
staon is main door staon, the Door Staon
No. should be set as 0; If it is sub door staon, set Door Staon No. as 1~16; If it is outer door
staon, set Door Staon No. as 90~99. Use the screwdriver to adjust the number. The arrow
indicates the number.
Building No. (1~99)
Figure 7-1 Building No.
Door Staon No.
Main Door
Staon: 0
Sub Door Staon: 1~16
Outer Door
Staon : 90~99
Figure 7-2 DIP Switch of Door
Staon No.
Door Open Duraon
Figure 7-3 DIP Switch of Door Open
Duraon
DS-KD7003EY-IME2 Module Door Staon User Manual
49
Table 7-1 Door Open Duraon
Rotary DIP Switch Door Open Duraon(s)
0 2
1 1
2 3
3 4
4 5
5 8
6 10
7/8/9 Reserved
Note
●
It is recommended to sck the supplied number remark on the back of the device to indicate the
device's No.
DIP Switch of Indoor Staon
Use the rotary DIP switch to set the indoor extension No., the building No., and the room No. The
Tens column refers to the number in Tens, and the Units column refers to the number in Units. On
each rotary DIP switch, 0 to 9 refers to No. 0 to 9. In total, you can use 1 to 3 to number the indoor
extension No., and use 1 to 99 to number the building or the room. Use the screwdriver to adjust
the number. The arrow indicates the number. An example is shown below.
Figure 7-4 Example: DIP Switch of Indoor Staon
DS-KD7003EY-IME2 Module Door Staon User Manual
50
Figure 7-5 Villa Mode
Villa Mode: The device can be powered by separate power supply. Under the villa mode, more
than one device can be lightened up; when the extension is called, it can be lightened up and
intercom via videos.
Figure 7-6 Building Mode
Building Mode: In one power supply system, up to 4 indoor staons can be wired and up to 1
indoor staon can be normally used at the same me. When other devices are lightened up, the IN
USE indicator will also be lightened up. Separate power supply is not supported. When the
extension is called, the screen cannot be lightened up.
Note
●
DIP 1 and DIP 2 are for mode sengs, and DIP 3 and DIP 4 are reserved.
●
If DIP 2 is set as 1, the funcon of Professional Studio will be enabled.
●
The device is on debugging mode when the extension No. is 9. You can operate the indoor
staon on debugging mode without connecng to the door staon.
DS-KD7003EY-IME2 Module Door Staon User Manual
51
Chapter 8 Call Indoor Staon from Door Staon
Aer powering on the device, the door staon and door staon can conduct the following
operaon.
Before You Start
The indoor staon and door staon should connect rst and nish the sengs of DIP switch.
Steps
1.
The door
staon call indoor staon directly.
2.
The indoor staon views the live video of the door staon.
DS-KD7003EY-IME2 Module Door Staon User Manual
52
Chapter 9 Unlock Door
Unlock Door by Public Password
You can unlock the door by public password.
1. Set public password:
-
Set Public Password on Mobile Web
-
Set Public Password on PC Web
2. Enter【#】+ Public Password +【#】to open the door.
Unlock Door by Card
1. Add Card: Person Management
2. Swipe the card on the card inducon area to unlock the door.
DS-KD7003EY-IME2 Module Door Staon User Manual
53
Chapter 10 Enable AP Mode
You can enable AP mode on device or on PC Web.
1.
Enable AP Mode on Device
2. Enable AP Mode on PC Web
10.1 Enable AP Mode on Device
You can enable the AP mode on device. Aer enabling the AP mode, you can log into the Web
Client of the door staon for conguraon with your mobile devices via the hotspot.
Steps
1.
Long press the buon on the lest side of the device to enable the AP mode.
Note
The AP mode will last for 30 minutes by default. 30 minutes aer the AP mode is enabled, it will
disable automacally.
10.2 Enable AP Mode on PC Web
You can enable the AP mode via enabling the Device Hotspot funcon on PC Web. Aer enabling
the AP mode, you can log into the Web Client of the door staon for conguraon with your
mobile devices via the hotspot.
Log into the Web Client, click
Conguraon → Network → Network Sengs → Device Hotspot .
Click Save to save the
sengs.
10.3 FAQ of AP Mode
The FAQ of AP Mode is listed as follows.
1. Q: How to enable AP mode of door staon?
A: Long press the le buon for 10 s and you will hear sound beepand the back light will
ashing for 2 minutes to indicate.
DS-KD7003EY-IME2 Module Door Staon User Manual
54
Figure 10-1 Long press the le buon
Note
if your device doesn't have le buon, please remove the cover then you can see the buon.
DS-KD7003EY-IME2 Module Door Staon User Manual
55
Figure 10-2 Remove the cover
2. Q: What is the default password of device hotspot?
A: The hotspot SSID name is AP_device SN, for example, AP_K12345678. Before acvaon, the
Wi-Fi password is on the label of door
staon. Aer acvaon and aer login in mobile phone
browser, you can modify the device acvaon and Wi-Fi password.
3. Q: I enabled the AP mode some
me ago, but now I can't search the hotspot with my mobile
phone or laptop.
A: The AP mode will be disabled
automacally aer 30 minutes, if you cannot search the Wi-Fi,
please enable it manually again by long pressing le buon for 10 s.
4. Q: How to disable the AP mode?
A: Just long press the
le buon for 15 s. Or if no device connects the AP, it will be disabled in
30 minutes automacally.
DS-KD7003EY-IME2 Module Door Staon User Manual
56
Chapter 11 Login Web Browser
You can log into the Web browser for device conguraon.
Before You Start
You need to make sure the device is on AP mode. For more details, please refer to
Enable AP Mode
Steps
1.
Connect your mobile devices or PCs to the device hotspot.
2.
Enter the device user name and the
acvaon password. Click Login.
Note
The device will be acvated automacally aer powered on. You can check the acvaon
password via the label on the surface of the device.
3.
For the rst-me login, you need to change the acvaon password: Click admin → Modify
Password on the upper right of the Web browser page. Enter the old and new password and
conrm the new password. Click Save.
Note
The hotspot password will be changed simultaneously aer the acvaon password is changed.
DS-KD7003EY-IME2 Module Door Staon User Manual
57
Chapter 12 Forgot Password
If you forget the password when logging in, you can change the password via PC Web or mobile
Web.
1
Forget Password via PC Web .
2. Forget Password via Mobile Web
12.1 Forget Password via Mobile Web
If you forget the password when logging in, you can change the password by email address or
security quesons.
On the login page, tap Forget Password.
Select
Vericaon Mode.
Security Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1. Export the QR code and send it to pw_rec[email protected] as aachment.
2. You will receive a vericaon code within 5 minutes in your reserved email.
3. Enter the
vericaon code into the vericaon code eld to verify your idencaon.
Click Next, create a new password and conrm it.
12.2 Forget Password via PC Web
If you forget the password when logging in, you can change the password by email address or
security quesons.
On the login page, click Forget Password.
Select Vericaon Mode.
Security Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1. Export the QR code and send it to pw_rec[email protected] as aachment.
2. You will receive a vericaon code within 5 minutes in your reserved email.
3. Enter the vericaon code into the vericaon code eld to verify your idencaon.
Click Next, create a new password and conrm it.
DS-KD7003EY-IME2 Module Door Staon User Manual
58
Chapter 13 Overview
You can take an overview of the PC Web and mobile Web page.
1.
Overview on PC Web
2. Overview on Mobile Web
13.1 Overview on Mobile Web
You can view the door status, network status and basic informaon, and set person management,
smart sengs, authencaon sengs, and door parameters via shortcut entry.
Funcon Descripons:
Door Status
/ / /
To set the door status as unlock/remaining open or to restore the sengs.
Device Component Status
You can view the device component status.
Building Informaon
You can view the Building No., Door Staon No. and Duraon of Remaining Open.
Shortcut Entry
You can quickly access to the following sengs page via Shortcut Entry.
●
Device Management
●
Person Management
●
Forgot Password
●
Set Door Parameters on Mobile Web
Basic Informaon
You can view the model, serial No. and rmware version.
13.2 Overview on PC Web
You can view the live video of the device, real-me event, person informaon, network status,
basic informaon, and device capacity.
Funcon Descripons:
Door Status
You can capture image when starng live view.
DS-KD7003EY-IME2 Module Door Staon User Manual
59
Select the streaming type when starng live view. You can select from the main stream and
the sub stream.
Full screen view.
/ / /
To set the door status as unlock/remaining open or to restore the sengs.
Controlled Status
You can select Unlock/ Restore/ Remain Open according to your actual needs.
Device Component Status
You can view the device component status.
Building Informaon
You can view the Building No., Door Staon No. and Duraon of Remaining Open.
Linked Device
You can view informaon of linked sub door staon, indoor staon and indoor extension.
Person Informaon
You can view the added and not added informaon of person.
Basic Informaon
You can view the model, serial No. and rmware version informaon.
Device Capacity
You can view the person and card capacity.
DS-KD7003EY-IME2 Module Door Staon User Manual
60
Chapter 14 Person Management
You can manage person informaon on PC Web and mobile Web.
●
Person Management on PC Web
●
Person Management on Mobile Web
14.1 Person Management on Mobile Web
You can add, edit, delete, and search users via mobile Web browser.
Steps
1.
Tap → Person Management to enter the sengs page.
2.
Add user.
1) Tap+.
2) Set the following parameters.
Employee ID
Enter the employee ID. The Employee ID cannot be 0 or exceed 32 characters. It can be a
combinaon of uppercase, lowercase leers and numbers.
Name
Enter your name. The name supports numbers, uppercase and lowercase English, and
characters. The name is recommended to be within 32 characters.
Room No.
Enter the Room No.
Note
The room No. refers to the mapping room No. which you can custom the No. on your own.
Long-Term Eecve User
Set the user permission as long-term eecve.
Start Date/End Date
Set Start Date and End Date of user permission.
Administrator
If the user needs to be set as administrator, you can enable Administrator.
User Role
Select your user role.
Card
Add card. Tap Add Card. Enter the Card No., or present the card on the device and tap
Read, and select the Property. Tap Save to add the card.
DS-KD7003EY-IME2 Module Door Staon User Manual
61
3) Tap Save.
3.
Tap the user that needs to be edited in the user list to edit the informaon.
4.
Tap the user that needs to be deleted in the user list, and tap to delete the user.
5.
You can search the user by entering the employee ID or name in the search bar.
14.2 Person Management on PC Web
Click Add to add the person's
informaon, including the basic informaon, cercate,
authencaon and sengs.
Add Basic Informaon
Click Person Management → Add to enter the Add Person page.
Add the person's basic informaon, including the employee ID, the person's name, person type,
etc.
Click Save to save the
sengs.
Set Permission Time
Click Person Management → Add to enter the Add Person page.
Enable Long-Term Eecve User, or set Start Time and End Time and the person can only has the
permission within the
congured me period according to your actual needs.
Click Save to save the sengs.
Add Administrator
Click Person Management → Add to enter the Add Person page.
Tap to enable Administrator, and the person you add will be administrator.
Click Save to save the
sengs.
Add Card
Click Person Management → Add to enter the Add Person page.
Click Add Card, enter the Card No. and select the Property, and click OK to add the card.
Click Save to save the
sengs.
Set Room No.
Click Person Management → Add to enter the Add Person page.
Click Add, enter the Room No. to add the room.
Note
The room No. refers to the mapping room No. which you can custom the No. on your own.
Click Save to save the sengs.
Set Door Permission
Click Person Management → Add to enter the Add Person page.
DS-KD7003EY-IME2 Module Door Staon User Manual
62
Select Door 1 or Door 2, to congure the door permission of the person.
Click Save to save the sengs.
View/edit Person
Click Person Management → Add to enter the Add Person page.
You can lter a person by entering the employee ID, name or card No.
You can view added people under the mode of card or list. You can click the card of the person or
the
eding icon to edit the informaon of the person.
Click Save to save the sengs.
DS-KD7003EY-IME2 Module Door Staon User Manual
63
Chapter 15 Device Management
You can manage the linked device on PC Web and mobile Web.
●
View Room No. Details on Mobile Web
●
Device Management on PC Web
15.1 View Room No. Details on Mobile Web
You can view the room No. details of linked indoor staon.
Steps
1.
Tap Device Management on the main page of mobile Web.
2.
Tap the room to view the room details.
15.2 Device Management on PC Web
Synchronizaon from Door Staon/Outer Door Staon
Long press to buon on the right side of the device to synchronize informaon.
Add Device
Click Device Management to enter the sengs page. Select device type and congure room
informaon to add device.
Upgrade / Delete Device
You can upgrade, edit and delete device.
Note
All indoor staons should be online before upgrading.
DS-KD7003EY-IME2 Module Door Staon User Manual
64
Chapter 16 View Device Informaon
You can view device informaon on PC Web and mobile Web.
●
View Device Informaon on Mobile Web
●
View Device Informaon on PC Web
16.1 View Device Informaon on Mobile Web
View the device name, No., language, model, serial No., QR code, version, Number of channels, IO
Input, IO Output, Local RS-485, Alarm Input/Output, MAC Address and Device Capacity, etc.
Tap Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, No., language, model, serial No., QR code, version, Number of
channels, IO Input, IO Output, Local RS-485, Alarm Input/Output, MAC Address and Device
Capacity, etc.
16.2 View Device
Informaon on PC Web
View the device name, device No., language, model, serial No., version, number of channels, IO
input, IO output, lock, alarm input, alarm output, and device capacity, etc.
Click
Conguraon → System → System Sengs → Basic Informaon to enter the conguraon
page.
You can view the device name, device No., language, model, serial No., version, number of
channels, IO input, IO output, lock, alarm input, alarm output, and device capacity, etc.
DS-KD7003EY-IME2 Module Door Staon User Manual
65
Chapter 17 Time Sengs
You can set me/DST on PC Web and mobile Web.
●
Set Time on Mobile Web
●
Set DST on Mobile Web
●
Set Time on PC Web
●
Set DST on PC Web
17.1 Set Time on Mobile Web
Set the
me zone, me sync. mode, and displayed me.
Tap → System Sengs → Time Sengs to enter the sengs page.
Figure 17-1 Time Sengs
Tap Save to save the sengs.
Time Zone
Select the me zone where the device is located from the drop-down list.
Time Sync. Mode
Manual
By default, the device me should be synchronized manually. You can set the device me
manually.
DS-KD7003EY-IME2 Module Door Staon User Manual
66
17.2 Set DST on Mobile Web
Steps
1.
Tap → System Sengs → Time Sengs , to enter the sengs page.
Figure 17-2 DST
2.
Tap Enable DST.
3.
Set the start me, end me, and DST bias.
4.
Tap Save.
17.3 Set Time on PC Web
Set the device's me zone, synchronizaon mode, server address, NTP port, and interval.
Click Conguraon → System → System Sengs → Time Sengs .
DS-KD7003EY-IME2 Module Door Staon User Manual
67
Figure 17-3 Time Sengs
Click Save to save the sengs aer the conguraon.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
Manual
By default, the device
me should be synchronized manually. You can set the device me
manually or check Sync. with Computer Time to synchronize the device me with the
computer's me.
17.4 Set DST on PC Web
Steps
1.
Click Conguraon → System → System Sengs → Time Sengs .
2.
Enable DST.
3.
Set the DST start
me, end me and bias me.
4.
Click Save to save the sengs.
DS-KD7003EY-IME2 Module Door Staon User Manual
68
Chapter 18 Audio Sengs
You can set audio parameters on PC Web and mobile Web.
●
Set Audio Parameters on Mobile Web
●
Set Audio Parameters on PC Web
18.1 Set Audio Parameters on Mobile Web
You can set the input volume and output volume.
Tap → Audio to enter the sengs page.
Set the input volume and output volume.
18.2 Set Audio Parameters on PC Web
Steps
1.
Click
Conguraon → Video/Audio → Audio .
2.
Select the audio encoding type.
3.
Set the input and output volume.
DS-KD7003EY-IME2 Module Door Staon User Manual
69
Chapter 19 Image Sengs
●
Set Image Parameters on Mobile Web
●
Set Image Parameters on PC Web
●
Set OSD (On-Screen Display) on PC Web
●
Crop Target on PC Web
19.1 Set Image Parameters on Mobile Web
You can enable WDR.
Tap → Image to enter the sengs page.
Tap to enable the funcon of WDR.
Note
WDR is used when there is a high contrast of the bright area and the dark area of the scene.
19.2 Set Image Parameters on PC Web
You can adjust the image parameters, video parameters, backlight parameters and Day/Night
Switch.
Steps
1.
Click
Conguraon → Image → Display Sengs .
2.
Congure the parameters to adjust the image.
Image Adjustment
Drag the block or enter the value to adjust the live video's brightness, contrast,
saturaon,
and sharpness.
Backlight
You can click to Enable BLC or enable WDR.
Note
●
BLC compensates light to the object.
●
WDR is used when there is a high contrast of the bright area and the dark area of the
scene.
●
These two
funcons cannot be enabled at the same me.
Day/Night Switch
Select the day/night switch mode to Dayme , Night, Auto or Scheduled-Switch.
DS-KD7003EY-IME2 Module Door Staon User Manual
70
Auto
The camera switches between the day mode and the night mode according to the
illuminaon automacally.
The sensivity ranges from 0 to 7, and the higher sensivity results in the more easily to
trigger the mode switch.
The switch
me refers to the interval me between the day/night switch. You can set it
from 5 sec to 120 sec.
Scheduled-Switch
The camera switches the day mode and the night mode according to the start me and
end
me you set.
Video Standard
Set the video frame rate when performing live view remotely. Aer changing the standard,
you should reboot the device to take eect.
PAL
25 frames per second. Suitable for mainland China, Hong Kong (China), the Middle East
countries, Europe countries, etc.
NTSC
30 frames per second. Suitable for the USA, Canada, Japan, Taiwan (China), Korea, the
Philippines, etc.
3.
Click Default to restore the parameters to the default
sengs.
19.3 Set OSD (On-Screen Display) on PC Web
You can customize the camera name, me/date format, display mode, and OSD size displayed on
the live view.
Steps
1.
Click Conguraon → Image → OSD Conguraon to enter the sengs page.
2.
Check the corresponding checkbox to select the display of camera name, date or week if
required.
-
Select Display Name: Edit the Camera Name.
-
Select Display Date: Select from the drop-down list to set the Time Format and Date Format.
3.
Drag to adjust the OSD
posion and alignment.
4.
Click Save to enable the sengs.
19.4 Crop Target on PC Web
You can select a target and crop images on the live view.
DS-KD7003EY-IME2 Module Door Staon User Manual
71
Steps
1.
Click Conguraon → Image → Target Cropping .
2.
Check Enable to enable the funcon.
3.
Select Cropping Resoluon.
4.
Click Save.
Note
●
You can select Cropping Resoluon as 704*576, 1280*720, or 1920*1080.
●
You can zoom in or zoom out the image by selecng Cropping Resoluon aer clicking Save.
DS-KD7003EY-IME2 Module Door Staon User Manual
72
Chapter 20 Moon Detecon Sengs
You can set moon detecon parameters on PC Web and Mobile Web.
●
Set Moon Detecon on PC Web
●
Set Moon Detecon on Mobile Web
20.1 Set Moon Detecon on Mobile Web
Aer enable the funcon of moon detecon, people or stu enter the congured area will trigger
alarm.
Steps
1.
Tap → Image to enter the image seng page.
2.
Tap to enable
Moon.
3.
Tap Save to save the seng.
Result
Aer enable the funcon of moon, people or stu enter the congured area will trigger alarm.
20.2 Set
Moon Detecon on PC Web
Aer enable the funcon of moon detecon, people or stu enter the congured area will trigger
alarm.
Steps
1.
Click
Conguraon → Event → Event Detecon → Moon .
2.
Enable Moon.
3.
Drag the process bar to adjust the Sensivity parameter.
4.
Click Save.
Note
The arming schedule is defaulted as all-day.
DS-KD7003EY-IME2 Module Door Staon User Manual
73
Chapter 21 Access Control Sengs
You can set access control parameters.
●
Set Door Parameters on PC Web
●
Set Door Parameters on Mobile Web
●
Set Public Password on PC Web
●
Set Public Password on Mobile Web
●
Set I/O Parameters on PC Web
●
Set I/O Parameters on Mobile Web
21.1 Set Door Parameters on Mobile Web
You can set door name and check open duraon.
Tap Conguraon → Access Control → Door Parameters .
Tap Save to save the sengs aer the conguraon.
Name
You can create a name for the door.
Open Duraon
You can check the unlocking duraon of the door.
Note
The Open Duraon is 3 by default.
21.2 Set Public Password on Mobile Web
Aer seng the public password, you can open the door via the public password.
Steps
1.
Tap Conguraon → Access Control → Password Sengs .
2.
Tap + to add public password.
1) Enter the password and
conrm the password.
2)
Oponal: Add remarks for the password.
3) Select Electric Lock.
3.
Tap Save to save the
sengs.
21.3 Set I/O Parameters on Mobile Web
You can set I/O Parameters on mobile Web.
DS-KD7003EY-IME2 Module Door Staon User Manual
74
Steps
1.
Tap Conguraon → Access Control → I/O Sengs .
2.
Select Input 2 as Disable or Unlock.
Note
The Input 1 is Unlock by default.
3.
Select Output 2 as Disable or Electric Lock.
Note
The Output 1 is Electric Lock by default.
21.4 Set Door Parameters on PC Web
You can set door name and check open duraon.
Click Conguraon → Access Control → Door Parameters .
Select a door and set the Door Name.
Click Save to save the
sengs aer the conguraon.
21.5 Set Public Password on PC Web
Aer seng the public password, you can open the door via the public password.
Steps
1.
Click Conguraon → Access Control → Password Sengs .
2.
Click Add to add public password.
1) Select Password Type.
2) Enter the password and
conrm the password.
3)
Oponal: Add remarks for the password.
4) Select Electric Lock.
3.
Click Save to save the
sengs.
21.6 Set I/O Parameters on PC Web
You can set I/O Parameters on PC Web.
Steps
1.
Click Conguraon → Access Control → Door Parameters .
2.
Select Input 2 as Disable or Unlock.
Note
The Input 1 is Unlock by default.
DS-KD7003EY-IME2 Module Door Staon User Manual
75
3.
Select Output 2 as Disable or Electric Lock.
Note
The Output 1 is Electric Lock by default.
DS-KD7003EY-IME2 Module Door Staon User Manual
76
Chapter 22 Video Intercom Sengs
You can set video intercom parameters.
●
Set Call Parameters on PC Web
●
Set Call Parameters on Mobile Web
●
Set Ringtone on PC Web
●
Press Buon to Call on PC Web
●
Press Buon to Call on Mobile Web
●
Set Sub Module on PC Web
●
Set Sub Module on Mobile Web
22.1 Set Call Parameters on Mobile Web
Set the Max. call duraon.
Tap → Intercom → Call Seng .
Set Max. Communicaon Time and Max. Ring Duraon . Press Save.
Note
●
The Max. communicaon me range is 15 s to 90 s.
●
The Max. ring duraon range is 65 s to 255 s.
22.2 Press Buon to Call on Mobile Web
Steps
1.
Tap
→ Intercom → Press Buon to Call .
2.
Tap 1 or 2 to select a buon to congure.
3.
Enable the funcon of Press Buon to Call.
4.
Tap Save.
22.3 Set Sub Module on Mobile Web
You can congure the sub modules on mobile Web.
Steps
1.
Tap → Intercom → Sub Module Conguraon .
2.
Tap Display Module.
3.
Drag the block to adjust the brightness.
4.
Tap to enable Buzzer.
DS-KD7003EY-IME2 Module Door Staon User Manual
77
22.4 Set Ringtone on PC Web
Steps
1.
Click Conguraon → Intercom → Ringbacktone Sengs to enter the sengs page.
2.
Click to import new ringtone.
Note
The supported audio le type for imporng is .wav. The le should be less than 800 KB.
22.5 Set Call Parameters on PC Web
Set the Max. call duraon.
Go to Conguraon → Intercom → Call Sengs .
Drag the block to set the Max.
Communicaon Time and Max. Ring Duraon . Click Save.
Note
●
The Max. communicaon me range is 15 s to 90 s.
●
The Max. ring duraon range is 65 s to 225 s.
22.6 Press Buon to Call on PC Web
You can set room No. of call buon, view buon image and set backlight.
Steps
1.
Click Conguraon → Intercom → Press Buon to Call to enter the sengs page.
2.
Set room No. of each
buon and click to enable Press Buon to Call, you can then press the
correspondent buon to call the specic indoor staon.
Note
The room No. refers to the mapping room No. which you can custom the No. on your own.
3.
Oponal: Click Backlight Sengs to set backlight mode as Open, Disable, Auto or Custom. Click
Save to save the
sengs.
Note
If you set the backlight mode as custom, you should then set the Start Time and End Time.
4.
Click View Buon Image and you can view the posion of the buon on the devices
5.
Click Save.
DS-KD7003EY-IME2 Module Door Staon User Manual
78
22.7 Set Sub Module on PC Web
You can congure the sub modules on PC Web.
Steps
1.
Click
Conguraon → Intercom → Sub Module Conguraon to enter the sengs page.
2.
Click Operaon to set sub module parameters.
1) Drag the block or enter the value of brightness.
2) Click to enable Buzzer.
3) Select the default home page of the sub module.
4) Add a call
buon. Click Add. Enter the name and call and click OK to save the sengs.
DS-KD7003EY-IME2 Module Door Staon User Manual
79
Chapter 23 Upgrade and Maintenance
●
Upgrade and Maintenance on PC Web
●
Upgrade and Maintenance on Mobile Web
23.1 Upgrade and Maintenance on Mobile Web
Restart device and restore device parameters.
Restart Device
Tap
→ Restart .
Tap Restart to restart the device.
Restore Parameters
Tap → Default .
Restore to Default Sengs
The device will restore to the default sengs, except for the device IP address and the user
informaon.
Restore to Factory Sengs
All parameters will be restored to the factory sengs. You should acvate the device before
usage.
Log Export
Tap → Log Export .
Tap Export to export the maintenance log.
23.2 Upgrade and Maintenance on PC Web
Reboot device, restore device parameters, and upgrade device version.
Reboot Device
Click Maintenance and Security → Maintenance → Restart .
Click Restart to reboot the device.
Upgrade
Click Maintenance and Security → Maintenance → Upgrade .
Select an upgrade type from the drop-down list. Click and select the upgrade le from your
local PC. Click Upgrade to start upgrading.
DS-KD7003EY-IME2 Module Door Staon User Manual
80
If the device has been connected to Hik-Connect and network, when there is a new installaon
package in Hik-Connect, you can click Upgrade aer Online Update to upgrade the device system.
Note
Do not power o during the upgrading.
Restore Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Restore All
All parameters will be restored to the factory sengs. You should acvate the device before
usage.
Restore
The device will restore to the default
sengs, except for the device IP address and the user
informaon.
Import and Export Parameters
Click Maintenance and Security → Maintenance → Backup and Reset .
Device Parameters
Export
Click Export to export the device parameters.
Note
You can import the exported device parameters to another device.
Import
Click and select the le to import. Click Import to start import conguraon le.
Data Migraon
Export
Click Export to migrate user informaon and conguraon details of the device to other
devices.
Note
You can migrate user informaon and conguraon details of the device to other devices.
The informaon and data may include door staon conguraon data, personal informaon,
card informaon, adversement informaon and etc.
Import
Click and select the le to import. Click Import to start import conguraon le.
DS-KD7003EY-IME2 Module Door Staon User Manual
81
Note
You can import migrated user data and conguraon details of other devices to this device.
DS-KD7003EY-IME2 Module Door Staon User Manual
82
Chapter 24 Change Acvaon/Admin Password
You can change acvaon/admin password on PC and Mobile Web.
●
Change Administrator's Password on PC Web
●
Change Administrator's Password on Mobile Web
24.1 Change Administrator's Password on Mobile Web
Steps
1.
Tap → User Management → User Management → admin to enter the seng page.
2.
Enter the old password and create a new password.
3.
Conrm the new password.
4.
Tap Save.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can
beer protect your product.
Proper conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
Aer the admin password is changed, the password of AP hotspot will be changed
simultaneously.
24.2 Change Administrator's Password on PC Web
Steps
1.
Click
Conguraon → System → User Management .
2.
Click .
3.
Enter the old password and create a new password.
4.
Conrm the new password.
5.
Click Save.
Cauon
The password strength of the device can be automacally checked. We highly recommend you
change the password of your own choosing (using a minimum of 8 characters, including at least
three kinds of following categories: upper case leers, lower case leers, numbers, and special
DS-KD7003EY-IME2 Module Door Staon User Manual
83
characters) in order to increase the security of your product. And we recommend you change
your password regularly, especially in the high security system, changing the password monthly
or weekly can beer protect your product.
Proper
conguraon of all passwords and other security sengs is the responsibility of the
service provider and/or end-user.
Aer the admin password is changed, the password of AP hotspot will be changed
simultaneously.
DS-KD7003EY-IME2 Module Door Staon User Manual
84
Chapter 25 Account Security Sengs
You can set account security on PC Web and Mobile Web.
●
Set Account Security on PC Web
●
Set Account Security on Mobile Web
25.1 Set Account Security on Mobile Web
You can change the security quesons and answers, or the email address on Mobile Web. Aer
change the sengs, once you forgot the device password, you should answer the new quesons or
use the new email address to reset the device password.
Steps
1.
Tap
→ User Management → User Management → ... → Account Security Sengs .
2.
Change the security quesons or email address according your actual needs.
3.
Enter the device password and tapSaveto conrm changing.
25.2 Set Account Security on PC Web
You can change the security quesons and answers, or the email address on PC Web. Aer change
the
sengs, once you forgot the device password, you should answer the new quesons or use
the new email address to reset the device password.
Steps
1.
Click Conguraon → System → User Management → Account Security Sengs .
2.
Change the security
quesons or email address according your actual needs.
3.
Enter the device password and click OK to conrm changing.
DS-KD7003EY-IME2 Module Door Staon User Manual
85
Chapter 26 View Device Arming/Disarming
Informaon on PC Web
View device arming type and arming IP address.
Go to
Conguraon → User Management → Arming/Disarming Informaon .
You can view the device arming/disarming informaon. Click Refresh to refresh the page.
DS-KD7003EY-IME2 Module Door Staon User Manual
86
Chapter 27 View Online Users on PC Web
The informaon of users logging into the device is shown.
Go to
Conguraon → User Management → Online Users to view the list of online users.
DS-KD7003EY-IME2 Module Door Staon User Manual
87
Chapter 28 Set Noce Publicaon on PC Web
You can set the noce publicaon for the device.
Click
Conguraon → Preference → Noce Publicaon .
Note
The device needs to connect to a touch display module rst.
Theme Management
Click Media Library Management → + to upload the picture from the local PC.
Note
Only the format of JPG is supported. Each picture should be smaller than 1 MB. Up to5 pictures
are supported.
You can click +Add Program, and set Name to create a theme. Aer creang the theme, click +
in the Theme Management panel to select pictures in the media library. Click OK to add
pictures to the theme.
Set Slide Show Interval
Drag the block or enter the number to set the slide show interval. The picture will be changed
according to the interval.
Note
The slide show interval ranges from 1 s to 120 s.
Customized Text Display
Click to enable customized text display and enter the custom content. Aer the seng, the
customized text will be displayed.
DS-KD7003EY-IME2 Module Door Staon User Manual
88
Chapter 29 Device Debugging on PC Web
You can set device debugging parameters.
Steps
1.
Click Maintenance and Security → Maintenance → Device Debugging .
2.
You can set the following parameters.
Enable SSH
To raise network security, disable SSH service. The
conguraon is only used to debug the
device for the professionals.
Print Log
You can click Export to export log.
Capture Network Packet
You can set the Capture Packet Duraon, Capture Packet Size, and click Start to capture.
DS-KD7003EY-IME2 Module Door Staon User Manual
89
Chapter 30 View Online Document
You can view online help document via PC Web and Mobile Web.
●
View Online Document on PC Web
●
View Online Document on Mobile Web
30.1 View Online Document on Mobile Web
Tap → View Online Document . Tap View Online Document, you can scan the QR code with
your mobile phone for details.
30.2 View Online Document on PC Web
On the main page of the device PC Web, click → Online Document , to view the help document.
DS-KD7003EY-IME2 Module Door Staon User Manual
90
Chapter 31 View Open Source Soware License
You can view Open Source Soware License via PC Web and Mobile Web.
●
View Open Source Soware License on PC Web
●
View Open Source Soware License on Mobile Web
31.1 View Open Source Soware License on Mobile Web
Tap → Open Source Soware Licenses to view the device license.
31.2 View Open Source
Soware License on PC Web
On the main page of the device PC Web, click → Open Source Soware Statement , to view the
device license.
DS-KD7003EY-IME2 Module Door Staon User Manual
91
Chapter 32 Quick Operaon via Web Browser
32.1 Change Password Type
If you forget the device acvaon password, you can change the password via security quesons
and E-mail. Set the security quesons before conguraon.
Click on the top right of the web page to enter the Change Password page.
Security Queson Vericaon
Answer the security quesons.
E-mail Vericaon
1. Export the QR code and send it to pw_rec[email protected] as aachment.
2. You will receive a vericaon code within 5 minutes in your reserved email.
3. Enter the
vericaon code into the vericaon code eld to verify your idencaon.
Click Next. Or you can click Skip to skip the step.
32.2 Select Language
You can select a language for the device system.
Click in the top right of the web page to enter the wizard page.
Click Next on the change password page. You can select a language for the device system from the
drop-down list.
By default, the system language is English.
Note
Aer you change the system language, the device will reboot automacally.
Click Next to complete the sengs.
32.3 Time
Sengs
DS-KD7003EY-IME2 Module Door Staon User Manual
92
Figure 32-1 Set Time and DST
Click on the top right of the web page to enter the wizard page. Aer previous sengs, you can
click Next to enter the Time
Sengs page.
Time Zone
Select the device located me zone from the drop-down list.
Time Sync.
Manual
You can set the device me manually or click Sync. with Computer Time to synchronize the
device
me with the computer's me.
DST
You can set the DST start me, end me and bias me.
Click Next to save the sengs and go to the next parameter. Or click Skip to skip me sengs.
32.4 Administrator
Sengs
Steps
1.
Click on the top right of the web page to enter the wizard page. Aer previous sengs, you
can click Next to enter the Administrator
Sengs page.
2.
Enter the employee ID and name of the administrator.
3.
Add card. Click + to enter the Card No. or click read to present the card on the card reading area
to read the card No.
automacally.
Note
Up to 5 cards can be supported.
4.
Click Next .
DS-KD7003EY-IME2 Module Door Staon User Manual
93
32.5 Link Video Intercom Devices
You can link to indoor staon and set DIP switch.
Steps
1.
Click
on the top right of the web page to enter the wizard page. Aer previous sengs, you
can click Next to enter the Link Video Intercom Devices page.
2.
Hold the
buon on the right side of the device for 10 s to trigger the funcon of device linkage.
Note
The IN USE indicator will be normally on.
3.
Make sure the DIP switch is correct.
4.
Click Complete .
DS-KD7003EY-IME2 Module Door Staon User Manual
94
UD32954B-A
