Compact Communication Module with
Increased Processing Power & Security!
Introducing . . .
MDI 2 - The Next Generation,
Global Diagnostic Interface Tool
EL-52100-AM MDI 2
The GM MDI 2 is the next generation Global Diagnostic Interface tool for both current and future vehicles.
It’s a compact communication module with increased processing power and security that manages the
transfer of data between a vehicle’s onboard ECU network with an auxiliary CAN bus.
The GM MDI 2 replaces the MDI introduced in 2007 and offers faster programming speed than the MDI. The
MDI 2 can be used to perform Pass-Thru programming on all GM vehicles built since 1996 and into the future.
Servicing the current generation vehicles will require the diagnostic software, GDS2, Global Diagnostic
System 2 running on a local PC device while the MDI or MDI 2 is connected to the vehicle.
The MDI 2 connects to the vehicle via the OBD II connector using a new DLC cable. Connection between the MDI
2 and the PC can be accomplished via standalone (USB) or through a NEW Point-to-Point wireless feature, and
the shops network (CAT5, or Wireless).
Now Available
Requires software licensed through ACDelco
Visit www.acdelcotds.com or Call 888-212-8959
Promo # GM20-143
Introducing . . . MDI 2
The Next Generation, GM Approved, Global Diagnostic Interface Tool
Introducing . . . MDI 2
The Next Generation Global
Diagnostic Interface Tool
Call 1-800-GM-TOOLS (468-6657) or visit GMDEsolutions.com
Promo # GM15-25A
Products sold F.O.B. Shipping Point.
1-800-GM-TOOLS
Wireless
Connecon
Point-to-Point — does not require an Access
Point, or IT support. Simple plug and play
conguraon.
Upgraded wireless protocol support
(includes 802.11bgn).
High Speed USB
2.0 Connection
Improved Protecon from Ground Oset
Failures.
Improved USB Performance (Faster Firmware
downloads).
Reinforced USB Connector and Connector
Housing (More robust design).
Device Powered Through USB or DLC
Connection— No AC Adaptor Required.
Operaon During
Engine Crank
Super-Caps provide improved stability
during engine crank — no baeries to leak
or replace.
Extended
Temperature Range
Industrial components extend operang
temperature range. Automac power down if
over temperature detected.
Enclosure Design
Improved enclosure design to protect from
exposure to uids and drops.
Vehicle Communicaon
Protocol Coverage
Addional Vehicle Communicaons
protocols — includes protocols for
upcoming Global B vehicles with faster data
busses. SAE J2534 and ISO-22900 compliant.
DLC cable
Longer DLC Cable (2 meters) with twisted pair
wire for Global B vehicles.
New Hardware
Expansion Capabilies
Two host USB expansion ports for future
peripher
als.
SD Memory Card slot for future soware
applicaons.
Programmable funcon buons for future
soware features and applicaons.
Features:
Note: Product not available until late 2015.
Requires software licensed through ACDelco
Visit www.acdelcotds.com or Call 888-212-8959
Promo # GM20-143
