- 1 -
61000
Series
BROAN MFG. CO., INC.
926 W. State St. Hartford, WI 53027
04306120
99042527A
- 2 -
READ AND SAVE THESE INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELEC-
TRICAL SHOCK, OR INJURY TO PER-
SONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended
by the manufacturer. If you have ques-
tions, contact the manufacturer at the
address or telephone number listed in the
warranty.
2. Before servicing or cleaning unit, switch
power off at service panel and lock ser-
vice panel to prevent power from being
switched on accidentally. When the ser-
vice disconnecting means cannot be
locked, securely fasten a prominent
warning device, such as a tag, to the ser-
vice panel.
3. Installation work and electrical wiring
must be done by a qualified person(s) in
accordance with all applicable codes and
standards, including fire-rated construc-
tion codes and standards.
4. Sufficient air is needed for proper com-
bustion and exhausting of gases through
the flue (chimney) of fuel burning equip-
ment to prevent backdrafting. Follow the
heating equipment manufacturer’s guide-
lines and safety standards such as those
published by the National Fire Protection
Association (NFPA), and the American
Society for Heating, Refrigeration and Air
Conditioning Engineers (ASHRAE), and
the local code authorities.
5. When cutting or drilling into wall or ceil-
ing, do not damage electrical wiring and
other hidden utilities.
6. Ducted fans must always be vented to
the outdoors.
7. Do not use this unit with any solid-state
speed control device.
8. To reduce the risk of fire, use only steel
ductwork.
9. This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP
GREASE FIRE:
1. Keep fan, filters and grease laden sur-
faces clean.
2. Always turn hood ON when cooking at
high heat.
3. Use high range settings on range only
when necessary. Heat oil slowly on low
to medium setting.
4. Don’t leave range unattended when cook-
ing.
5. Always use cookware and utensils ap-
propriate for the type and amount of food
being prepared.
WARNING
TO REDUCE THE RISK OF INJURY TO
PERSONS IN THE EVENT OF A RANGE
TOP GREASE FIRE, OBSERVE THE FOL-
LOWING:*
1. SMOTHER FLAMES with a close-fitting
lid, cookie sheet, or metal tray, then turn
off the burner. BE CAREFUL TO PRE-
VENT BURNS. If the flames do not go
out immediately, EVACUATE AND CALL
THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN - You
may be burned.
3. DO NOT USE WATER, including wet
dishcloths or towels - violent steam ex-
plosion will result.
4. Use an extinguisher ONLY if:
A. You know you have a Class ABC ex-
tinguisher and you already know how
to operate it.
B. The fire is small and contained in the
area where it started.
C. The fire department is being called.
D. You can fight the fire with your back
to an exit.
* Based on “Kitchen Fire Safety Tips”
published by NFPA.
CAUTION
1. For general ventilating use only. Do not
use to exhaust hazardous or explosive
materials and vapors.
2. To avoid motor bearing damage and
noisy and/or unbalanced impellers, keep
drywall spray, construction dust, etc. off
power unit.
3. Your hood motor has a thermal overload
which will automatically shut off the mo-
tor if it becomes overheated. The motor
will restart when it cools down. If the mo-
tor continues to shut off and restart, have
the hood serviced.
4. For best capture of cooking impurities,
the bottom of the hood should be a mini-
mum of 24" and a maximum of 30" above
the cooking surface.
5. Two installers are recommended be-
cause of the large size and weight of this
hood.
6. Please read specification label on prod-
uct for further information and require-
ments.
- 3 -
6" ROUND
DUCT
ROOF CAP
6" ROUND
ELBOW
24" TO 30" ABOVE
COOKING SURFACE
WALL CAP
HOOD
DECORATIVE
FLUE
DEPTH ADJUSTMENT
SCREWS
L
L
C
5 "
7
8
5 "
7
8
to above cookto
p
30 "
5
8
36 "
5
8
FRAMING BEHIND DRYWALL
30
5
/8"= bottom of hood 24" above cooktop
36
5
/8"= bottom of hood 30" above cooktop
INSTALL THE DUCTWORK
NOTE: To reduce the risk of fire, use only
steel ductwork.
1. Decide where the ductwork will run between
the hood and the outside.
2. A straight, short duct run will allow the hood
to perform most efficiently.
3. Long duct runs, elbows, and transitions will
reduce the performance of the hood. Use as
few of them as possible.
4. Install a roof or wall cap. Connect 6" round
steel ductwork to cap and work back towards
hood location. Use duct tape to seal the joints
between ductwork sections.
INSTALL MOUNTING
BRACKETS
1. Construct wood wall framing that is flush with
interior surface of wall studs.
Make sure:
a) the framing is centered over installation
location.
b) the height of the framing will allow the
mounting brackets to be secured to the
framing within the dimensions shown.
2.
After wall surface is finished, secure mount-
ing brackets to framing using dimensions
shown.
INSTALL THE HOOD
3. Hang the hood from the brackets through the
rectangular cut-outs on the back of the
hood. Cut-outs are larger than the brackets
to allow for horizontal adjustment.
The bottom of the hood should be 24" to 30"
above the cooking surface.
4. Height adjustment screws provide vertical
adjustment.
5. Depth adjustment screws provide horizon-
tal adjustment.
6. Secure the hood with additional mounting
screws. Use drywall anchors, provided, if
wall studs or framing are not available.
WALL FRAMING
ADDITIONAL
MOUNTING
SCREWS
RECTANGULAR CUTOUTS
MOUNTING
BRACKETS
HEIGHT
ADJUSTMENT
SCREWS
ADDITIONAL
MOUNTING
SCREWS
- 4 -
6" ROUND
STEEL DUCT
DECORATIVE
FLUE
DUCT TAPE
AIR VENT
POSITION FOR
DUCTED
CONFIGURATION
WIRING
Note: This range hood must be properly
grounded. The unit should be installed by a
qualified electrician in accordance with all
applicable national and local electrical
codes.
1. Remove the wiring box cover. Remove a
knockout from the wiring box.
2. Feed 6" of power cable through the knock-
out opening and secure cable to the wiring
box with an appropriate connector.
3. Make electrical connections. Connect white
to white, black to black and green to green.
4. Replace wiring box cover and screws. Make
sure that wires are not pinched between
cover and box.
CONNECT DUCTWORK
Ducted Configuration
1. Use screws and wall anchors to secure up-
per bracket to the ceiling and wall as shown.
2. Use 6" round steel duct to connect the duct
collar on the hood to the ductwork above.
3. Use duct tape to make all joints secure and
air tight.
4.
Connect the upper section of decorative
flue to the bracket with screws provided.
5. Slide the lower section of decorative flue
downward, until it fits properly around hood.
6. Secure decorative flue to hood with screws
provided.
DUCT
COLLAR
WIRING BOX
COVER
UPPER
BRACKET
FASTEN
UPPER
BRACKET
TO CEILING &
WALL WITH
SCREWS (&
ANCHORS IF
NECESSARY)
FASTEN
FLUE TO
HOOD &
UPPER
BRACKET
WITH
SCREWS
- 5 -
CONNECT DUCTWORK
Ductfree Configuration
1. Use screws and wall anchors (sup-
plied) to secure the upper bracket
to wall and ceiling as shown.
2. Turn upper flue section upside
down so air vents are at the top.
Slide upper flue section into lower
flue section.
3. Snap the plastic duct collar into the
hole in the bottom of the ducfree ple-
num. Connect the ductfree plenum
to the upper flue section with (4) flat-
head screws (supplied).
4. Measure the distance from the top
of the discharge collar to the ceil-
ing. Cut a length of 6" round steel
duct 6" shorter than this dimension.
5. Fit duct section over the plastic duct
collar. For best fit, make sure duct
seam is toward the front.
6. Set duct/flue assembly on hood with top tilted away from wall. Reach around flue
to engage bottom of duct with discharge collar on hood. Tilt flue up against wall.
Upper flue section can be cut to length if necessary.
7. Raise upper flue section and screw it to upper bracket with (2) screws (supplied).
Screw lower flue section to hood with screws (supplied).
MEASURE
UPPER
FLUE SECTION
DUCTFREE
PLENUM
PLASTIC
DUCT COLLAR
AIR
VENTS
(in upper flue section)
UPPER
BRACKET
LOWER
FLUE SECTION
6" ROUND
STEEL DUCT
DISCHARGE
COLLAR
DUCT
SEAM
DUCTFREE FILTER
INSTALLATION
1. Purchase a ductfree filter kit (part no.
????) from your dealer.
2. Screw the plastic mounting brackets to
the blower inlet.
3. Position the filters over the mounting
brackets. Rotate mounting brackets to
lock filters in place.
- 6 -
MAINTENANCE
Grease Filters
The grease filters should be cleaned frequently.
Use a warm detergent solution. Grease filters
are dishwasher safe.
Remove filters by pushing filters towards the
back of hood and rotating filters downward.
Ductfree Filters
The ductfree filters should be changed every 6
months. Rotate the filters to remove and replace.
Hood Cleaning
Stainless steel is one of the easiest materials
to keep clean. Occasional care will help pre-
serve its fine appearance.
Cleaning tips:
• Hot water with soap or detergent is all that is
usually needed.
• Follow all cleaning by rinsing with clear wa-
ter. Wipe dry with a clean, soft cloth to avoid
water marks.
• For discolorations or deposits that persist,
use a non-scratching household cleanser or
stainless steel polishing powder with a little
water and a soft cloth.
• For stubborn cases, use a plastic scouring
pad or soft bristle brush together with cleaser
and water. Rub lightly in direction of polish-
ing lines or "grain" of the stainless finish.
Avoid using too much pressure which may
mar the surface.
• DO NOT allow deposits to remain for long
periods of time.
• DO NOT use ordinary steel wool or steel
brushes. Small bits of steel may adhere to
the surface causing rust.
• DO NOT allow salt solutions, disinfectants,
bleaches, or cleaning compounds to remain
in contact with stainless steel for extended
periods. Many of these compounds contain
chemicals which may be harmful. Rinse with
water after exposure and wipe dry with a
clean cloth.
Painted surfaces should be cleaned with warm
water and mild detergent only.
GREASE FILTERS
DUCTFREE
FILTERS
- 7 -
LIGHT LENS
TAB
HALOGEN BULBS
This range hood requires two halogen bulbs
(Type T4, 12V, 20W).
To change bulbs:
1. Open the light lens by grasping the tab on
the lens and rotating lens downward.
2. Remove the bulb by pulling sideward (Do not
rotate). CAUTION: BULB MAY BE HOT!
3. Do not touch replacement bulb with bare
hands! Push bulb securely into lamp socket
and snap lens closed.
OPERATION
Controls
The hood is operated using the slide controls
under the front edge of the hood.
The light switch turns the halogen lights on
and off.
The blower on / off switch turns the blower on
to the running speed set by the blower speed
control. The blower must be turned on and off
using this switch.
The blower speed control changes the running speed of the blower. It is infinitely
adjustable from low to high speed.
The pilot lamp lights up whenever the blower is on.
LIGHT
SWITCH
PILOT
LAMP
BLOWER
SPEED
CONTROL
BLOWER
ON / OFF
SWITCH
- 8 -
WARRANTY
BROAN ONE YEAR LIMITED WARRANTY
Broan warrants to the original consumer purchaser of its products that such
products will be free from defects in materials or workmanship for a period of
one year from the date of original purchase. THERE ARE NO OTHER WAR-
RANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OR MERCHANT ABILITY OR FITNESS FOR A PAR-
TICULAR PURPOSE.
During this one-year period, Broan will, at its option, repair or replace, without
charge, any product or part which is found to be defective under normal use
and service.
THIS WARRANTY DOES NOT EXTEND TO FLUORESCENT LAMP START-
ERS AND TUBES. This warranty does not cover (a) normal maintenance and
service or (b) any products or parts which have been subject to misuse, neg-
ligence, accident, improper maintenance or repair (other than by Broan), faulty
installation or installation contrary to recommended installation instructions.
The duration of any implied warranty is limited to the one-year period as speci-
fied for the express warranty. Some states do not allow limitation on how long
an implied warranty lasts, so the above limitation may not apply to you.
BROAN’S OBLIGATION TO REPAIR OR REPLACE, AT BROAN’S OPTION,
SHALL BE THE PURCHASER’S SOLE AND EXCLUSIVE REMEDY UNDER
THIS WARRANTY. BROAN SHALL NOT BE LIABLE FOR INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES ARISING OUT OF OR IN CON-
NECTION WITH PRODUCT USE OR PERFORMANCE. Some states do not
allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other
rights, which vary from state to state. This warranty supersedes all prior war-
ranties.
To qualify for warranty service, you must (a) notify Broan at the address stated
below or telephone: 1-800-637-1453, (b) give the model number and part
identification and (c) describe the nature of any defect in the product or part.
At the time of requesting warranty service, you must present evidence of the
original purchase date.
BROAN MFG. CO., INC., 926 West State Street Hartford, WI 53027
- 9 -
SERVICE PARTS
61000 SERIES RANGE HOOD
KEY NO. PART NO. DESCRIPTION
6 B02000191 Filter Spring
9 B08087485 Grease Filter
14 B02300730 Motor Capacitor
19 B03295005 Terminal Box
26 B02300722 Halogen Lamp Bulb
30 B03292291 Switch Cover
42 B03290377 Ductfree Filter Bracket
48 B02310094 Motor
49 B03295000 Blower Wheel
53 B03202007 Rubber Washer
57 B02000756 Damper Flap
68 B02000293 Right Blower Housing
69 B02000294 Left Blower Housing
99 BE3334372 Filter Channel
113 B03202433 Nameplate
115 BE3495228 Wiring Box
116 BE3334252 Wiring Box Cover
118 BE3342283 Decorative Flue Bottom
119 BE3342284 Decorative FlueTop
120 B03202118 Flue Mounting Bracket
122 B08089123 Ductfree Plenum
123 B03292283 Duct Connector
144 B03292287 Wire Clamp
165 B03292161 Control Board Box
166 B08086101 Control Board
167 B03292162 Control Board Box Cover
168 B03292163 Capacitor Box Cover
208 B02300717 Transformer
223 B03292294 Switch Button
474 B02300719 Halogen Lamp Housing
477 B03295006 Terminal Cover
* B06001768 Blower Assembly (Includes Key Nos. 42, 48,
49, 53, 68, 69)
* B06106282 Control Board Assembly (Includes Key Nos.
144, 165, 166, 167, 168)
* B06106286 Switch Assembly (Includes Key Nos. 222, 223,
224, 225, 226, 228, 229, 230)
* B06106285 Motor Capacitor Assembly w/ Wires (Includes
Key No. 14 & Wires)
- 10 -
SERVICE PARTS
61000 SERIES RANGE HOOD
