GIGA 5 Instructions for Use
The Instructions for Use has been awarded the seal of
approval by the independent German Technical Inspection
Agency, TÜV SÜD, due to its easy-to-understand style, its
thoroughness and coverage of safety aspects.
2
Table of contents
Your GIGA 5
Control elements 4
Important information 6
Proper use ......................................................................................................................................................6
For your safety ...............................................................................................................................................6
1 Preparing and using for the first time 9
JURA on the Internet .....................................................................................................................................9
Setting up the machine ...............................................................................................................................9
Filling the water tank ....................................................................................................................................9
Filling the bean container ...........................................................................................................................10
First-time use ................................................................................................................................................10
Determining the water hardness ..............................................................................................................14
Connecting milk ...........................................................................................................................................14
2 Preparation 15
Coffee, latte macchiato etc. – options for preparation .........................................................................15
Preparation at the touch of a button ........................................................................................................16
Preparation using the product selector ...................................................................................................17
Ground coffee ...............................................................................................................................................17
Permanently setting amounts for the cup size ......................................................................................18
Activating the grinder selection ................................................................................................................19
Hot water ......................................................................................................................................................20
3 Daily operation 21
Switching on .................................................................................................................................................21
Daily maintenance .......................................................................................................................................21
Switching off ................................................................................................................................................22
4 Permanent settings in programming mode 23
Possible settings in programming mode ...............................................................................................23
Product settings ..........................................................................................................................................24
Setting the consistency of grind ..............................................................................................................26
Maintenance settings .................................................................................................................................26
Setting the water hardness .......................................................................................................................28
Energy-saving mode ..................................................................................................................................28
Time and date ..............................................................................................................................................29
Timer .............................................................................................................................................................30
Automatic switch-off ...................................................................................................................................31
Units ..............................................................................................................................................................32
Restore factory settings .............................................................................................................................32
Language ......................................................................................................................................................33
Display settings ...........................................................................................................................................34
Background ..................................................................................................................................................34
Querying information ................................................................................................................................35
3
Table of contents
Warnings
J WARNING
J CAUTION
Always take note of any information marked with the words CAUTION or
WARNING and a warning sign. The signal word WARNING draws your attention
to potential serious injury, and the signal word CAUTION to potential minor
injury.
CAUTION CAUTION draws your attention to potential damage to the machine.
Symbols used
T Prompt to take action. This symbol means that you are being prompted to
perform some action.
E Information and tips to make it even easier to use your GIGA.
‘Espresso’
Display
Symbol description
5 Maintenance 36
Rinsing the coffee system .........................................................................................................................36
Rinsing the milk system .............................................................................................................................37
Cleaning the milk system ..........................................................................................................................37
Dismantling and rinsing the dual spout .................................................................................................38
Inserting and activating the filter ..............................................................................................................41
Changing the filter ......................................................................................................................................42
Cleaning the machine ................................................................................................................................43
Descaling the machine ..............................................................................................................................44
Cleaning the bean container .....................................................................................................................46
Descaling the water tank ...........................................................................................................................47
6 Display messages 48
7 Troubleshooting 50
8 Transport and environmentally friendly disposal 52
Transport / Emptying the system .............................................................................................................52
Disposal .........................................................................................................................................................52
9 Technical data 53
10 Index 54
11 JURA contact details / Legal information 59
4
Control elements
Control elements
1 Bean container with aroma preservation
cover
2 Bean container status indicator
3 Water tank cover
4 Water tank
5 Power switch and plug-in mains
cable (back of the machine)
6 Coffee grounds container
7 Drip tray
8 Cup grille
9 Filler funnel for ground coffee
10 Ventilation slats (Venti Ports)
11 Storage compartment cover
12 Measuring spoon for ground coffee
13 Height- and width-adjustable dual spout
14 Splash guard
15 Height-adjustable hot-water spout
5
Control elements
Top of the machine
1 Q On/Off button
2 g Rotary Switch
3 O P button (programming)
Front
4 Display
5 Multi-function buttons (button function
depends on what is shown in the display)
Back of the machine
1 Service cover (Open by pressing with your
finger)
2 Locking device
3 Sliding catch
4 Service socket (underneath cover)
6
Important information
Important information
The machine is designed and intended for private domestic use. It
should only be used for coffee preparation and to heat milk and
water. Use for any other purpose will be deemed improper. JURA
Elektroapparate AG cannot accept any responsibility for the con-
sequences of improper use.
Before using the machine read these instructions for use thoroughly
and completely and comply with the instructions they contain. A
warranty service is not applicable for damage or defects caused by
non-compliance with the instructions for use. Keep these instruc-
tions for use close to the machine and pass them on to the next user.
Please carefully read and observe the important safety information
set out below.
To avoid danger of potentially fatal electric shock:
U
Never use a machine which is damaged or has a defective
mains cable.
U
In the event of signs of damage, for example if there is a smell
of burning, unplug the machine immediately from the mains
supply and contact JURA service.
U
If the mains cable of this machine is damaged, it must
be repaired either directly by JURA or by an authorised JURA
service centre.
U
Make sure that the GIGA and the mains cable are not located
close to hot surfaces.
U
Be careful to ensure that the mains cable is not trapped and
does not rub against sharp edges.
U
Never open and repair the machine yourself. Do not modify
the machine in any way that is not described in these instruc-
tions for use. The machine contains live parts. If opened, there
is a danger of potentially fatal injury. Repairs may only be car-
ried out by authorised JURA service centres, using original
spare parts and accessories.
Proper use
For your safety
J
7
Important information
U
To completely and safely disconnect the machine from the
power supply, first switch off the GIGA using the On/Off but-
ton and then at the power switch. Only then should you
remove the mains plug from the power socket.
There is a risk of scalds or burns on the spouts.
U
Place the machine out of the reach of children.
U
Do not touch any hot parts. Use the handles provided.
A defective machine is not safe and could cause injury or fire. To
avoid damage and any associated risk of injury or fire:
U
Never allow the mains cable to loosely hang down. The mains
cable could pose a tripping hazard or become damaged.
U
Protect the GIGA from environmental influences such as rain,
frost and direct sunlight.
U
Do not immerse the GIGA, mains cable or connections in
water.
U
Do not put the GIGA or any individual parts in the dishwasher.
U
Switch your GIGA off at the power switch before any cleaning
operation. Always wipe the GIGA with a damp cloth rather
than a wet one, and protect it from prolonged exposure to
water splash.
U
Only connect the machine to the mains voltage in accordance
with the information on the rating plate. The rating plate is
located on the underside of your GIGA. Further technical data
is provided in these instructions for use (see Chapter 9 ‘Tech-
nical data’).
U
Please only use original JURA maintenance products. Use of
products that are not explicitly recommended by JURA could
damage the GIGA.
U
Do not use any coffee beans treated with additives or caramel-
ised coffee beans.
U
Only fill the water tank with fresh, cold water.
U
Switch the machine off at the power switch if you are going to
be absent for a longer period of time.
8
Important information
People, including children, who
U
do not have the physical, sensory or mental capabilities to use
the machine safely or
U
are inexperienced or lack knowledge in how to use the
machine safely
must be supervised by a responsible person when using it, or must
be instructed in how to use it correctly.
Safety when handling the CLARIS Blue filter cartridge:
U
Filter cartridges should be kept out of the reach of children.
U
Store filter cartridges in a dry place in the sealed packaging.
U
Protect cartridges from heat and direct sunlight.
U
Do not use damaged filter cartridges.
U
Do not open filter cartridges.
9
1 Preparing and using for the first time
1 Preparing and using for the first time
Visit us on the Internet. You can download short operating instruc-
tions for your machine from the JURA website (www.jura.com). You
will also find interesting and up-to-date information on your GIGA
and on every aspect of coffee.
When setting up your GIGA, please note the following:
U
Place the GIGA on a horizontal surface that is not sensitive to
water.
U
Choose a spot for your GIGA which protects the machine
against overheating. Ensure that the ventilation slats are not
covered.
Daily maintenance of the machine and hygiene when handling milk,
coffee and water are key to a perfect coffee result in the cup every
time. You should therefore change the water daily.
Milk, sparkling mineral water or other liquids can damage the water
tank or the machine.
T Only fill the water tank with fresh, cold water.
T Open the water tank cover.
T Remove the water tank and rinse it with cold water.
T Fill the water tank with fresh, cold water and reinsert the
tank.
T Close the water tank cover.
JURA on the Internet
Setting up the machine
Filling the water tank
CAUTION
10
1 Preparing and using for the first time
The bean containers have an aroma preservation cover. This will
ensure that your coffee beans retain their aroma for longer.
Coffee beans which have been treated with additives (e.g. sugar),
ground coffee or freeze-dried coffee will damage the grinders.
T Only use untreated coffee beans to fill the bean containers.
T Remove the aroma preservation cover.
T Remove any dirt or foreign objects from inside the bean
container.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
During first-time use, you can choose between the
‘Quick installa-
tion’
and the ‘Standard installation’.
U
‘Quick installation’: After setting the time and date, your GIGA
is ready for use.
U
‘Standard installation’: Here, you can also decide whether you
want to operate your GIGA with or without a CLARIS Blue
filter cartridge. If the water hardness is 10° dH or more, we
recommend using the filter cartridge. If you do not know
the hardness of your water, you can find this out first (see
Chapter 1 ‘Preparing and using for the first time – Deter-
mining the water hardness’).
U
‘Use filter’ / ‘Active’: Here, you can fit the CLARIS Blue filter
cartridge. Descaling will no longer be necessary.
U
‘Use filter’ / ‘Inactive’: Here, you can set the water hardness
of the water used. This setting influences when your GIGA
prompts you to perform descaling.
If the machine is operated with a defective mains cable, there is a
danger of potentially fatal electric shock.
T Never use a machine which is damaged or has a defective
mains cable.
Filling the bean container
CAUTION
First-time use
J
WARNING
11
1 Preparing and using for the first time
Precondition: The water tank and bean containers have been filled.
T Connect the mains cable to the machine.
T Insert the mains plug into a power socket.
3 T Switch on the GIGA using the power switch on the back of
the machine.
Q T Press the On/Off button to switch the GIGA on.
‘Welcome to JURA’ appears on the display. The display then
shows the languages you can choose from.
E To display more languages, press the
‘Next’ button (bottom
right).
T Press the button that corresponds to the language you want,
e.g.
‘English’.
‘Saved’ appears briefly on the display to confirm the setting.
‘First-time use’
E Now choose between ‘Quick installation’ and ‘Standard instal-
lation’
.
T Press the
‘Quick installation’ button.
‘Time’
T Press the ‘+’ or ‘–’ button to set the hours.
T Press the
‘Save’ button.
T Press the
‘+’ or ‘–’ button to set the minutes.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Date’
T Press the ‘+’ or ‘–’ button to set the day.
T Press the
‘Save’ button.
T Press the
‘+’ or ‘–’ button to set the month.
T Press the
‘Save’ button.
T Press the
‘+’ or ‘–’ button to set the year.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Press the Rotary Switch.’, the Rotary Switch lights up.
Quick installation
12
1 Preparing and using for the first time
T Place a receptacle under the dual spout.
k T Press the Rotary Switch.
‘System is filling.’, the system fills up with water. The opera-
tion stops automatically.
‘Welcome to JURA’, ‘Machine is
heating.’
, ‘Press the Rotary Switch.’ appears on the display.
k T Press the Rotary Switch.
‘Machine is rinsing.’, the machine rinses. The operation
stops automatically.
‘Please select product:’ appears on the
display. Your GIGA is ready for use.
T Press the
‘Standard installation’ button.
‘Time’
T Press the ‘+’ or ‘–’ button to set the hours.
T Press the
‘Save’ button.
T Press the
‘+’ or ‘–’ button to set the minutes.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Date’
T Press the ‘+’ or ‘–’ button to set the day.
T Press the
‘Save’ button.
T Press the
‘+’ or ‘–’ button to set the month.
T Press the
‘Save’ button.
T Press the
‘+’ or ‘–’ button to set the year.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Use filter’
E Now decide whether you want to operate your GIGA with or
without a CLARIS Blue filter cartridge.
T Press the
‘Active’ button.
T Press the
‘Save’ button.
‘Press the Rotary Switch.’, the Rotary Switch lights up.
k T Press the Rotary Switch.
‘System is filling.’, the system fills up with water. The opera-
tion stops automatically.
‘Insert filter.’/ ‘Press the Rotary Switch.’
T Remove the filter cartridge extension from the Welcome
Pack.
T Fit the filter extension on top of a CLARIS Blue filter cartridge.
Standard installation
Activating the filter
13
1 Preparing and using for the first time
T Remove and empty the water tank.
T Open the filter holder and insert the filter cartridge into the
water tank, exerting slight pressure.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
k T Press the Rotary Switch.
‘Filter is being rinsed.’, the filter is rinsed. Rinsing of the filter
stops automatically.
‘Empty drip tray.’ appears on the dis-
play.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Filter’ / ‘Filter rinsing complete.’
‘Welcome to JURA’
, ‘Machine is heating.’, ‘Press the Rotary
Switch.’
.
k T Press the Rotary Switch.
‘Machine is rinsing.’, the machine rinses. The operation
stops automatically.
‘Please select product:’ appears on the
display. Your GIGA is ready for use.
T Press the
‘Inactive’ button.
T Press the
‘Save’ button.
‘Press the Rotary Switch.’, the Rotary Switch lights up.
k T Press the Rotary Switch.
‘System is filling.’, the system fills up with water. The opera-
tion stops automatically.
‘Water hardness’
E If you do not know the hardness of your water, you must find
this out first (see Chapter 1 ‘Preparing and using for the first
time – Determining the water hardness’).
T Press the
‘+’ or ‘–’ button to set the water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Welcome to JURA’, ‘Machine is heating.’, ‘Press the Rotary
Switch.’
.
Deactivating the filter
14
1 Preparing and using for the first time
T Place a receptacle under the dual spout.
k T Press the Rotary Switch.
‘Machine is rinsing.’, the machine rinses. The operation
stops automatically.
‘Please select product:’ appears on the
display. Your GIGA is ready for use.
You can find out what the water hardness is by using the Aquadur®
test strip supplied as standard.
T Hold the test strip briefly (for 1 second) under flowing water.
Shake off the water.
T Wait for about 1 minute.
T You will then be able to read the degree of water hardness
from the discolouration of the Aquadur® test strip and the
description on the packaging.
Your GIGA creates fine, creamy, feather-light milk foam with a per-
fect consistency. The most important requirement for frothing milk
is a milk temperature of 4–8 °C. We would therefore recommend
using a milk cooler or a vacuum milk container.
T Connect the milk pipe to the dual spout. To do this, attach
the end of the milk pipe (without the connector) to the con-
nector on the right-hand side of the dual spout. Use the
short pipe for a milk container and the long pipe for a milk
carton.
T Connect the other end of the milk pipe to a milk container
or immerse it in a milk carton.
Determining the water
hardness
Connecting milk
15
2 Preparation
2 Preparation
E While a product is being prepared, you can stop preparation
at any time. To do this, press the Rotary Switch k or the
‘’
button.
E During preparation, you can change the preset amounts
(e.g. amount of milk foam or water) by turning the Rotary
Switch g.
E You can follow the current status of preparation on the display.
Coffee tastes best served hot. A cold porcelain cup cools the bever-
age – and impairs the taste. We therefore recommend prewarming
the cups. The full coffee aroma can develop only in prewarmed cups.
You can purchase a JURA cup warmer from your specialised dealer.
You can make permanent settings for all products in programming
mode (see Chapter 4 ‘Permanent settings in programming mode –
Product settings’).
The GIGA provides you with two options for preparing a speciality
coffee, milk or hot water.
U
Preparation at the touch of a button: Simply press the cor-
responding preparation button for the product shown on the
display (start screen) that you want.
U
Preparation using the product selector (Rotary Selection):
Only some of the products you can prepare are shown on the
start screen. As soon as you turn the Rotary Switch, more
products are displayed in a product selector.
U
Turn the Rotary Switch to bring the product you want into
focus. Start preparation by pressing the Rotary Switch or the
‘Prepare’ button.
U
The product selector view disappears automatically after
5 seconds if no preparation is started.
The two preparation options will now be described in more detail in
the following sections.
Coffee, latte macchiato
etc. – options for
preparation
16
2 Preparation
On the display (start screen), you will see different products, which
you can prepare by simply pressing the corresponding button.
A speciality coffee displayed on the start screen is always prepared
in the same way.
Example: Proceed as follows to prepare one coffee.
Precondition:
‘Please select product:’ is displayed.
T Place a cup under the dual spout.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the fill volume are displayed.
The preset amount of water for coffee flows into the cup.
Preparation stops automatically.
‘Please select product:’
appears on the display.
Two speciality coffees can always be prepared in the same way: Press
the preparation button you want twice within two seconds.
Your GIGA prepares latte macchiato, cappuccino and other speciality
coffees with milk at the touch of a button. There is no need to move
the glass or cup.
Example: Proceed as follows to prepare one latte macchiato.
Precondition:
‘Please select product:’ is displayed, milk is connected
to the dual spout.
T Place a glass under the dual spout.
T Press the
‘Latte macchiato’ button.
‘Latte macchiato’ and the various amounts are displayed.
‘Latte macchiato’, the preset amounts of milk and milk foam
flow into the glass.
Coffee preparation starts. The preset amount of water for
espresso flows into the glass. Preparation stops automati-
cally.
‘Please select product:’ appears on the display.
To ensure that the milk system in the dual spout always works
properly, you must clean it daily (see Chapter 5 ‘Maintenance –
Cleaning the milk system’).
Preparation at the touch
of a button
Speciality coffees at the
touch of a button
Two speciality coffees at the
touch of a button
Speciality coffees with milk
at the touch of a button
17
2 Preparation
As soon as you turn the Rotary Switch, more products are displayed
in a product selector.
E The product selector view disappears automatically after
5 seconds if no preparation is started.
Example: Proceed as follows to prepare a milky coffee using the
product selector.
Precondition:
‘Please select product:’ is displayed, milk is connected
to the dual spout.
T Place a cup under the dual spout.
g T Turn the Rotary Switch to view the product selector.
g T Turn the Rotary Switch until the
‘Caffè latte’ product is in
focus.
k T Press the Rotary Switch to start preparation.
The milky coffee is prepared.
Preparation stops automatically.
‘Please select product:’
appears on the display.
You can choose to use a second coffee variety, for example decaf-
feinated coffee, with the filter funnel for ground coffee.
E Never add more than two level measuring spoons of ground
coffee.
E Use ground coffee which is not ground too finely. Very fine
coffee can block up the system so that the coffee only comes
out in drips.
E If you did not fill the machine with a sufficient amount of
ground coffee,
‘Not enough ground coffee.’ is displayed and
the GIGA stops the operation.
E The desired speciality coffee must be prepared within approx-
imately one minute after filling with the ground coffee. Oth-
erwise the GIGA stops the operation and is once more ready
for use.
All speciality coffees with ground coffee are prepared following this
model.
Preparation using the
product selector
Preparation of a speciality
coffee using the product
selector
Ground coffee
18
2 Preparation
Example: Proceed as follows to prepare one coffee using ground
coffee.
Precondition:
‘Please select product:’ is displayed.
T Place a cup under the dual spout.
T Open the cover of the filler funnel for ground coffee.
‘Please add ground coffee.’
T Place one level measuring spoon of ground coffee into the
filler funnel.
T Close the cover of the filler funnel.
‘Please select product:’, the speciality coffees you can pre-
pare with ground coffee are displayed.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the fill volume are displayed.
The preset amount of water for coffee flows into the cup.
Preparation stops automatically.
‘Please select product:’
appears on the display.
It is easy to make permanent settings for the amounts (amount of
water, amount of milk etc.) for all products according to the cup size.
Adjust the amount once as shown in the following example. Every
time you prepare a drink in the future, this amount of water will be
dispensed.
The permanent settings for adapting the amounts to the cup size
for all products follow this model.
Example: Proceed as follows to permanently set the amount of
water for one coffee.
Precondition:
‘Please select product:’ is displayed.
T Place a cup under the dual spout.
T Press and hold the
‘Coffee’ button.
‘Coffee’ and the fill volume are displayed.
T Hold the
‘Coffee’ button down until ‘Enough coffee? Press
button.’
appears.
T Release the
‘Coffee’ button.
Preparation starts and the coffee flows into the cup.
Permanently setting
amounts for the cup size
19
2 Preparation
T Press any button as soon as there is sufficient coffee in the
cup.
Preparation stops.
‘Saved’ appears briefly on the display. The
set amount of water for one coffee is permanently stored.
‘Please select product:’ appears on the display.
E You can alter this setting at any time by repeating the above
procedure.
E The amount can be permanently adjusted to the cup size for
the products (apart from milky coffee) shown in the product
selector too. To do this, press and hold the Rotary Switch k
until
‘Enough coffee? Press button.’ appears.
E You can also permanently set the amount for all speciality
coffees, milk and hot water in programming mode (see Chap-
ter 4 ‘Permanent settings in programming mode – Product
settings’).
You have the option of configuring the start screen such that the
grinder selection (‘beans à la carte’) is always displayed. Before each
preparation, you can select which grinder is to be used and therefore
which coffee beans are to be used.
E If the grinder selection is activated, you can no longer set the
grinder for the individual products in programming mode (in
the
‘Product settings (2/5)’ programme item).
Example: Proceed as follows to activate ‘beans à la carte’ mode.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (4/5)’
is displayed.
T Press the
‘Café à la carte’ button.
T Press the
‘Active’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings (4/5)’
O T Press the P button to exit programming mode.
‘Please select product:’
Activating the grinder
selection
20
2 Preparation
Example: Proceed as follows to prepare a coffee with coffee beans
from the grinder on the left.
Precondition:
‘Please select product:’ is displayed. ‘Beans à la carte’
mode is activated.
T Place a cup under the dual spout.
T Press the
‘+’ button on the left-hand side several times until
the value is set to ‘100%’.
E The grinder selection remains active until the setting is
changed by you, even if the GIGA is switched off in the mean-
time.
T Press the
‘Coffee’ button.
Preparation starts.
‘Coffee’ and the fill volume are displayed.
The preset amount of water for coffee flows into the cup.
Preparation stops automatically.
‘Please select product:’
appears on the display.
The following temperatures can be selected for preparing hot water:
‘Low’, ‘Normal’, ‘High’.
There is a danger of scalding from hot water splashes.
T Avoid direct contact with the skin.
Precondition:
‘Please select product:’ is displayed.
T Place a cup under the hot-water spout.
T Press the
‘Hot water’ button.
‘Hot water’ and the temperature are displayed.
E By pressing the
‘+’ or ‘–’ button (within approximately
2 seconds) you can set the temperature to your individual
preference. This setting is not saved.
‘Hot water’, hot water flows into the cup. Preparation stops
automatically when the preset amount of water is reached.
‘Please select product:’ appears on the display.
Preparation of a speciality
coffee with grinder
selection
Hot water
J
CAUTION
21
3 Daily operation
3 Daily operation
When the GIGA is switched on, it automatically prompts you to per-
form the rinse operation. Start the rinse operation by pressing the
Rotary Switch k . In programming mode you can change this set-
ting so that the machine starts the switch-on rinse automatically
(see Chapter 4 ‘Permanent settings in programming mode – Main-
tenance settings’).
Precondition: Your GIGA is switched on at the power switch.
T Place a receptacle under the dual spout.
Q T Press the On/Off button to switch the GIGA on.
‘Welcome to JURA’ appears on the display. The machine
heats up.
‘Press the Rotary Switch.’
k T Press the Rotary Switch.
‘Machine is rinsing.’, the machine rinses. The operation
stops automatically.
‘Please select product:’ appears on the
display.
To ensure that you get many years of reliable service out of your
GIGA and to guarantee the optimum coffee quality, the machine
requires daily maintenance.
T Pull out the drip tray.
T Empty the coffee grounds container and the drip tray. Rinse
them both with warm water.
T Dry the metal contacts on the back of the drip tray.
T Refit the coffee grounds container and the drip tray.
T Rinse the water tank with clean water.
T Dismantle and rinse the dual spout (see Chapter 5 ‘Mainte-
nance – Dismantling and rinsing the dual spout’).
T Wipe the surface of the machine with a clean, soft, damp
cloth (e.g. microfibre cloth).
E In the interests of hygiene, we recommend changing the milk
pipe on a regular basis (approx. every 6 months). Replacement
pipes are available from specialised dealers.
Switching on
Daily maintenance
22
3 Daily operation
When you switch off your GIGA, the dual spout is rinsed automati-
cally.
Precondition:
‘Please select product:’ is displayed.
T Place a receptacle under the dual spout.
Q T Press the On/Off button.
‘Machine is rinsing.’, ‘Milk system is being rinsed.’ (if you
have prepared a speciality coffee with milk). The system
rinses itself. The operation stops automatically. Your GIGA is
switched off.
E When the GIGA is switched off with the On/Off button, the
machine consumes less than 0.1 W of standby energy. The
machine can be completely disconnected from the power
supply using the power switch.
Switching off
23
4 Permanent settings in programming mode
4 Permanent settings in programming mode
Press the P button to enter programming mode. You can navigate
through the programme items and permanently save the required
settings simply by turning the Rotary Switch and using the multi-
function buttons. The following settings can be made:
Programme item Sub-item Explanation
‘Maintenance status
(1/5)’
‘Clean’,
‘Change the filter’,
‘Descale’ (only if filter is
not activated),
‘Rinse the milk system’,
‘Rinse the coffee system’,
‘Clean the milk system’
T Start the required maintenance pro-
gramme here.
‘Product settings
(2/5)’
‘Expert mode’,
‘Set consistency of grind’
T Select your settings for speciality coffees,
milk and hot water.
T Adjust the consistency of grind for both
grinders to the coffee beans used.
‘Machine settings
(3/5)’
‘Maintenance settings’
(filter, water hardness,
switch-on rinse, milk
system rinsing),
‘Time / date’,
‘Timer’,
‘Save energy’,
‘Units’,
‘Factory setting’
T Adjust the water hardness or activate the
filter.
T Change the settings for the switch-on rinse
and milk system rinse.
T Set the time after which the GIGA should
switch off automatically.
T Select an energy-saving mode.
T Select the unit for the amount of water.
T Reset the machine or the permanently set
values of all products to the factory settings.
‘Machine settings
(4/5)’
‘Choose language’,
‘Display’,
‘Colour scheme’,
‘Café à la carte’
T Select your language.
T Change the display settings.
T Activate the grinder selection.
‘Information (5/5)’ ‘Product counter’,
‘Maintenance counter’,
‘Version’
T Keep track of all products prepared and
view the number of maintenance pro-
grammes performed.
Possible settings in
programming mode
24
4 Permanent settings in programming mode
In the programme item ‘Product settings (2/5)’ you can make indi-
vidual settings for all speciality coffees, milk and hot water.
The following settings can be made in the
‘Expert mode’:
Product Coffee strength Amount More settings
Ristretto,
espresso,
coffee
; (extra-mild),
;; (mild),
;;; (normal),
;;;; (strong),
;;;;; (extra-strong)
Water: 25 ml – 240 ml Temperature (low,
normal, high),
grinder on the left and/or
right (as %)
Two ristretti,
two espressi,
two coffees
– Water: 25 ml – 240 ml
(per cup)
Temperature (low,
normal, high),
grinder on the left and/or
right (as %)
Cappuccino,
milky coffee,
espresso macchiato,
latte macchiato
; (extra-mild),
;; (mild),
;;; (normal),
;;;; (strong),
;;;;; (extra-strong)
Water: 25 ml – 240 ml
Milk: 0 sec. – 120 sec.
Milk foam:
0 sec. – 120 sec.
Temperature (low,
normal, high),
grinder on the left and/or
right (as %)
Two cappuccini,
two milky coffees,
two espressi
macchiati,
two latte macchiati
– Water: 25 ml – 240 ml
Milk: 0 sec. – 120 sec.
Milk foam:
0 sec. – 120 sec.
(per cup)
Temperature (low,
normal, high),
grinder on the left and/or
right (as %)
Portion of milk
foam,
portion of milk
– Milk: 0 sec. – 120 sec.
Milk foam:
0 sec. – 120 sec.
–
Two portions of milk
foam,
two portions of milk
– Milk: 0 sec. – 120 sec.
Milk foam:
0 sec. – 120 sec.
(per cup)
–
Hot water – Water: 25 ml – 450 ml Temperature (low,
normal, high)
E In addition to the settings listed, you can reset the values for
all products to the factory settings.
Product settings
Expert mode
25
4 Permanent settings in programming mode
Example: Proceed as follows in the ‘Expert mode’ to change the
amount of milk for a latte macchiato from
‘4 sec.’ to ‘6 sec.’, the
amount of milk foam from
‘12 sec.’ to ‘14 sec.’ and the amount of
water from
‘45 ml’ to ‘40 ml’.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Product
settings (2/5)’
is displayed.
T Press the
‘Expert mode’ button.
‘Expert mode’
E Next select the button of the product for which you would like
to make settings. No product is prepared at this point.
E You can also select the products in the product selector. To do
this, turn the Rotary Switch to view the product selector.
T Press the
‘Latte macchiato’ button.
T Press the
‘Amount of milk’ button.
T Press the
‘+’ or ‘–’ button to change setting for the amount
of milk to
‘6 sec.’.
T Press the
‘Save’ button.
T Press the
‘Amount of milk foam’ button.
T Press the
‘+’ or ‘–’ button to change setting for the amount
of milk foam to
‘14 sec.’.
T Press the
‘Save’ button.
T Press the
‘Volume’ button.
T Press the
‘+’ or ‘–’ button to change setting for the fill vol-
ume to
‘40 ml’.
T Press the
‘Save’ button.
O T Press the P button to exit programming mode.
‘Please select product:’
26
4 Permanent settings in programming mode
In the programme item ‘Product settings (2/5)’ / ‘Set consistency of
grind’
you can adjust both grinders separately to the degree of roast
of your coffee.
The consistency of grind setting is correct if the coffee flows regu-
larly from the dual spout. In addition a fine, thick crema forms.
Example: Proceed as follows to change the consistency of grind for
the grinder on the right.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Product
settings (2/5)’
is displayed.
T Press the
‘Set consistency of grind’ button.
‘Set consistency of grind’
T Press the ‘Right grinder’ button.
‘Right grinder’
T Press the ‘+’ or ‘–’ button to change the setting for the con-
sistency of grind.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Set consistency of grind’
O T Press the P button to exit programming mode.
‘Please select product:’
In the programme item ‘Machine settings (3/5)’ / ‘Maintenance set-
tings’
you can make the following settings:
U
‘Filter’
U
Activate the CLARIS Blue filter cartridge (see Chapter 5
‘Maintenance – Inserting and activating the filter’).
U
‘Water hardness’
U
If you do not have a filter cartridge, you will need to set the
water hardness (see Chapter 4 ‘Permanent settings in pro-
gramming mode – Setting the water hardness’).
U
‘Switch-on rinse’ / ‘Manual’
U
The switch-on rinse must be started manually.
U
‘Switch-on rinse’ / ‘Automatic’
U
The switch-on rinse is started automatically.
Setting the consistency
of grind
Maintenance settings
27
4 Permanent settings in programming mode
U
‘Rinse the milk system’ / ‘Manual after 10 min.’
U
You are prompted to rinse the milk system 10 minutes after
preparation of a speciality coffee with milk.
U
‘Rinse the milk system’ / ‘Manual immediate’
U
You are prompted to rinse the milk system immediately
after preparation of a speciality coffee with milk.
U
‘Rinse the milk system’ / ‘Automatic after 10 min.’
U
Milk system rinsing is automatically initiated 10 minutes
after preparation of a speciality coffee with milk.
U
‘Rinse the milk system’ / ‘Automatic immediate’
U
Milk system rinsing is automatically initiated approx. 30 sec-
onds after preparation of a speciality coffee with milk.
Example: Proceed as follows to make the machine prompt you to
rinse the milk system immediately after preparing a speciality cof-
fee with milk.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Maintenance settings’ button.
‘Maintenance settings’
T Press the ‘Rinse the milk system’ button.
‘Rinse the milk system’
T Press the ‘Manual immediate’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Maintenance settings’
O T Press the P button to exit programming mode.
‘Please select product:’
28
4 Permanent settings in programming mode
The harder the water is, the more frequently the GIGA needs to be
descaled. It is therefore important to adjust the water hardness.
The water hardness can be adjusted on a continuous scale between
1° dH and 30° dH.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Maintenance settings’ button.
‘Maintenance settings’
T Press the ‘Water hardness’ button.
‘Water hardness’
T Press the ‘+’ or ‘–’ button to set the water hardness.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Maintenance settings’
O T Press the P button to exit programming mode.
‘Please select product:’
In the programme item ‘Machine settings (3/5)’ / ‘Save energy’ you
can permanently set an energy-saving mode (Energy Save Mode,
E.S.M.
©
):
U
‘Save No’
U
All speciality coffees, speciality coffees with milk and hot
water can be prepared without having to wait.
U
‘Save Level 1’
U
Your GIGA is only constantly ready for use for speciality cof-
fees and hot water.
U
Before you can prepare a speciality coffee with milk, the
machine must heat up.
U
‘Save Level 2’
U
Soon after the last preparation, the GIGA stops heating up.
After about 5 minutes the message
‘Energy Save’ is dis-
played.
U
Before you can prepare a speciality coffee, speciality coffee
with milk, or hot water, the machine must heat up.
Setting the water
hardness
Energy-saving mode
29
4 Permanent settings in programming mode
Example: Proceed as follows to change the energy-saving mode
from
‘Save Level 1’ to ‘Save Level 2’.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Save energy’ button.
‘Save energy’
T Press the ‘Save Level 2’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings (3/5)’
O T Press the P button to exit programming mode.
‘Please select product:’
You already set the time and date during first-time use. You can
change this setting.
E For the time format, you can choose between ‘24 hrs’ and
‘AM / PM’ (see Chapter 4 ‘Permanent settings in programming
mode – Units’).
Example: Proceed as follows to change the time.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Time / date’ button.
‘Time / date’
T Press the ‘Time’ button.
‘Time’
T Press the ‘+’ or ‘–’ button to set the hours.
T Press the
‘Save’ button.
T Press the
‘+’ or ‘–’ button to set the minutes.
Time and date
30
4 Permanent settings in programming mode
T Press the ‘Save’ button.
‘Saved’ appears briefly on the display.
‘Time / date’
O T Press the P button to exit programming mode.
‘Please select product:’
In the programme item ‘Machine settings (3/5)’ / ‘Timer’ you can set
an individual switch-on and switch-off time for every day of the
week.
E Automatic switch-on only works when the machine is switched
on at the power switch.
E For the time format, you can choose between ‘24 hrs’ and
‘AM / PM’ (see Chapter 4 ‘Permanent settings in programming
mode – Units’).
Example: Proceed as follows to set your GIGA to switch on and off
at a time defined by you every day of the week.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Timer’ button.
‘Timer’
T Press the ‘Monday’ button (example).
‘Monday’
T Press the ‘+’ or ‘–’ button to set the hours (for ‘Switch
machine on’
).
T Press the
‘’ button.
T Press the
‘+’ or ‘–’ button to set the minutes (for ‘Switch
machine on’
).
T Press the
‘’ button.
T Press the
‘+’ or ‘–’ button to set the hours (for ‘Switch
machine off’
).
T Press the
‘’ button.
T Press the
‘+’ or ‘–’ button to set the minutes (for ‘Switch
machine off’
).
Timer
31
4 Permanent settings in programming mode
T Press the ‘Every weekday’ button.
‘Saved’ appears briefly on the display. The switch-on and
switch-off times you just set are adopted for every day of the
week.
‘Timer’
O T Press the P button to exit programming mode.
‘Please select product:’
By instructing your GIGA to automatically switch itself off, you can
cut down your energy consumption. If this function is activated,
your GIGA switches off automatically after the preset time following
the last action on the machine.
You can set the automatic switch-off time to 15 minutes or
0.5 – 15 hours.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Timer’ button.
T Press the
‘Next’ button.
T Press the
‘Switch off after’ button.
‘Switch off after’
T Press the ‘+’ or ‘–’ button to change the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Timer’
O T Press the P button to exit programming mode.
‘Please select product:’
Automatic switch-off
32
4 Permanent settings in programming mode
In the programme item ‘Machine settings (3/5)’ / ‘Units’ you can
make the following settings:
U
Unit for amount of water: ‘ml’ or ‘oz’
U
Time format: ‘24 hrs.’ or ‘AM / PM’
Example: Proceed as follows to change the unit for the amount of
water from
‘ml’ to ‘oz’.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Units’ button.
‘Units’
T Press the ‘oz’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings (3/5)’
O T Press the P button to exit programming mode.
‘Please select product:’
In the programme item ‘Machine settings (3/5)’ / ‘Factory setting’
you can reset various settings to their factory settings:
U
‘All products’
U
The settings (amount of water, coffee strength, temperature
etc.) for all products are reset to the factory settings.
U
‘Machine’
U
All user settings (apart from the ‘filter’, ‘water hardness’ and
time and date settings) are reset to the factory settings. The
GIGA then switches off.
U
‘Empty system’
U
The system is emptied. Your GIGA then switches off.
Example: Proceed as follows to reset the values for all products to
the factory settings.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
Units
Restore factory settings
33
4 Permanent settings in programming mode
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Factory setting’ button.
‘Factory setting’
T Press the ‘All products’ button.
‘All products’ / ‘Reset all products to the factory settings?’
T Press the ‘Yes’ button.
‘Saved’ appears briefly on the display.
‘Factory setting’
O T Press the P button to exit programming mode.
‘Please select product:’
In this programme item you can set the language used by your
GIGA.
Example: Proceed as follows to change the language from
‘English’
to
‘Deutsch’.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (4/5)’
is displayed.
T Press the
‘Choose language’ button.
‘Choose language’
E To display more languages, press the ‘Next’ button (bottom
right).
T Press the
‘Deutsch’ button.
‘Gespeichert’ appears briefly on the display.
‘Geräteeinstellungen (4/5)’
O T Press the P button to exit programming mode.
‘Bitte wählen Sie Ihr Produkt:’
Language
34
4 Permanent settings in programming mode
In the programme item ‘Machine settings (4/5)’ / ‘Display’ you can
make the following settings:
U
‘Brightness’ (as percentages)
U
‘Contrast’ (high, normal, low)
U
‘Backlight’ (backlighting; as percentages)
Example: Proceed as follows to change the brightness of the display.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (4/5)’
is displayed.
T Press the
‘Display’ button.
‘Display’
T Press the ‘Brightness’ button.
T Press the
‘+’ or ‘–’ button to change the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Display’
O T Press the P button to exit programming mode.
‘Please select product:’
In this programme item you can set the background for the display
of your GIGA.
E The set background is only displayed on the start screen.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (4/5)’
is displayed.
T Press the
‘Colour scheme’ button.
‘Colour scheme’
T Press the ‘+’ or ‘–’ button to change the setting.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Machine settings (4/5)’
O T Press the P button to exit programming mode.
‘Please select product:’
Display settings
Background
35
4 Permanent settings in programming mode
In the programme item ‘Information (5/5)’ you can view the follow-
ing information:
U
‘Product counter’: Number of prepared coffee speciality cof-
fees, speciality coffees with milk and hot water
U
‘Maintenance counter’: Number of maintenance programmes
performed (cleaning, descaling, changing the filter etc.)
U
‘Version’: Software version
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Informa-
tion (5/5)’
is displayed.
T Press the
‘Product counter’ button.
‘Product counter’ and the number of products prepared is
displayed.
E You can also view the number of products prepared in the
product selector. To do this, turn the Rotary Switch.
T Press any button or the Rotary Switch to exit the programme
item.
‘Information (5/5)’
O T Press the P button to exit programming mode.
‘Please select product:’
Querying information
36
5 Maintenance
5 Maintenance
Your GIGA has the following integrated maintenance programmes:
U
Rinsing the coffee system (‘Rinse the coffee system’)
U
Rinsing the milk system in the dual spout (‘Rinse the milk
system’
)
U
Cleaning the milk system in the dual spout (‘Clean the milk
system’
)
U
Changing the filter (‘Change the filter’)
U
Cleaning the machine (‘Clean’)
U
Descaling the machine (‘Descale’) (only if filter is not acti-
vated)
E Clean or descale the machine, rinse the milk system or change
the filter when you are prompted to do so.
E Press the P button to view a list of the maintenance pro-
grammes (
‘Maintenance status (1/5)’). By referring to the bar
you can see how soon each maintenance programme is due.
When the bar is completely filled with red, your GIGA will
prompt you to perform the maintenance programme.
E The GIGA will not prompt you to clean the milk system. In the
interests of hygiene, you should clean the milk system daily
when you have been preparing milk.
You can perform coffee system rinsing at any time.
Precondition:
‘Please select product:’ is displayed.
T Place a receptacle under the dual spout.
O T Press the P button.
‘Maintenance status (1/5)’
T Press the ‘Rinse the coffee system’ button.
‘Machine is rinsing.’, water flows out of the dual spout.
The rinse stops automatically.
‘Please select product:’
appears on the display.
Rinsing the coffee system
37
5 Maintenance
Depending on the setting in programming mode, the GIGA prompts
you to rinse the milk system or automatically performs rinsing fol-
lowing milk preparation.
Example: Proceed as follows to rinse the milk system when
prompted to do so.
Precondition:
‘Rinse the milk system.’ and the c symbol are dis-
played.
T Place a receptacle under the dual spout.
O T Press the P button.
‘Maintenance status (1/5)’
T Press the ‘Rinse the milk system’ button.
‘Milk system is being rinsed.’, water flows out of the dual
spout.
The rinse stops automatically.
‘Please select product:’
appears on the display.
To ensure that the milk system in the dual spout always works prop-
erly, you must clean it daily when you have been preparing milk. The
GIGA will not prompt you to clean the milk system.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E JURA Cappuccino Cleaner is available from specialised dealers.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
T Press the ‘Clean the milk system’ button.
T Press the
‘Start’ button.
T Press the
‘Start’ button again.
‘Cleaning agent for milk system.’
T Pour 250 ml of fresh water into a receptacle and add one
capful (max. 15 ml) of Cappuccino Cleaner.
T Immerse the milk pipe in the receptacle.
Rinsing the milk system
Cleaning the milk system
CAUTION
38
5 Maintenance
T Place another receptacle under the dual spout.
T Press the
‘Next’ button.
‘Milk system is being cleaned.’, water flows out of the dual
spout.
‘Water for cleaning milk system.’
T Rinse the receptacle thoroughly, fill it with 250 ml of fresh
water and immerse the milk pipe in the water.
T Empty the other receptacle and place it under the dual spout
again.
T Press the
‘Next’ button.
‘Milk system is being cleaned.’, the dual spout and the pipe
are rinsed with fresh water.
The operation stops automatically.
‘Milk system cleaning
complete.’
appears briefly on the display.
‘Please select product:’
The dual spout must be dismantled and rinsed daily if milk has been
prepared to make sure it functions perfectly and also in the interests
of hygiene.
T Remove the milk pipe and rinse it thoroughly under running
water.
T Press the releasing devices and pull the cover of the dual
spout up and off.
Dismantling and rinsing
the dual spout
39
5 Maintenance
T Carefully pull the bottom part of the milk system down and
off.
T Remove the milk system from the dual spout.
T Remove the air intake pipe.
T Dismantle the milk system into its individual parts.
T Rinse all the parts under running water. If there are severely
dried-on milk residues, firstly immerse the individual parts
in JURA Cappuccino Cleaner and then rinse them thor-
oughly.
T Reassemble the milk system. When doing this, note the
arrows (circled in red in the picture) on the individual parts.
40
5 Maintenance
T Fit the air intake pipe.
T Fit the assembled individual parts back in the dual spout and
press it firmly.
T Attach the bottom part of the milk system to the part
already inserted from below.
T Fit the cover of the dual spout. It will click into place audibly.
T Insert the milk pipe into the dual spout.
41
5 Maintenance
Your GIGA no longer has to be descaled if you are using the CLARIS
Blue filter cartridge. If the water hardness is 10° dH or more, we rec-
ommend using the filter cartridge. If you do not know the hardness
of your water, you can find this out first (see Chapter 1 ‘Preparing and
using for the first time – Determining the water hardness’).
If you did not activate the filter cartridge the first time you used the
machine, you can do this now as follows.
E Perform the ‘inserting the filter’ operation without any inter-
ruptions. This will ensure that your GIGA always produces its
best.
Precondition:
‘Please select product:’ is displayed.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Maintenance settings’ button.
T Press the
‘Filter’ button.
‘Filter’
T Press the ‘Active’ button.
T Press the
‘Save’ button.
‘Saved’ appears briefly on the display.
‘Insert filter.’ / ‘Press the Rotary Switch.’
T Remove the filter cartridge extension from the Welcome
Pack.
T Fit the filter extension on top of a CLARIS Blue filter cartridge.
T Remove and empty the water tank.
T Open the filter holder and insert the filter cartridge into the
water tank, exerting slight pressure.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
k T Press the Rotary Switch.
‘Filter is being rinsed.’, the filter is rinsed. Rinsing of the filter
stops automatically.
‘Empty drip tray.’ appears on the dis-
play.
Inserting and activating
the filter
42
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Filter’ / ‘Filter rinsing complete.’
The machine heats up. ‘Please select product:’ appears on
the display. Your GIGA is once more ready for use.
E After 50 litres of water have flowed through or after two
months, the filter will cease to work. Your GIGA will automati-
cally prompt you to change the filter.
E If the CLARIS Blue filter cartridge is not activated in program-
ming mode, you will not be prompted to change the filter.
Example: Proceed as follows to change the filter when prompted to
do so.
Precondition:
‘Change the filter’ and the c symbol are displayed.
O T Press the P button.
‘Maintenance status (1/5)’
T Press the ‘Change the filter’ button.
T Press the
‘Start’ button.
T Press the
‘Start’ button again.
‘Change filter.’ / ‘Press the Rotary Switch.’
T Remove and empty the water tank.
T Open the filter holder and remove the old CLARIS Blue filter
cartridge and filter extension.
T Fit the filter extension on top of a new filter cartridge.
T Insert the filter cartridge into the water tank, exerting slight
pressure.
T Close the filter holder. It will click into place audibly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
k T Press the Rotary Switch.
‘Filter is being rinsed.’, the filter is rinsed. Rinsing of the filter
stops automatically.
‘Empty drip tray.’ appears on the dis-
play.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Change the filter’ / ‘Filter rinsing complete.’
The machine heats up. ‘Please select product:’ appears on
the display.
Changing the filter
43
5 Maintenance
After 220 preparations or 80 switch-on rinses, the GIGA will prompt
you to clean it.
If the wrong cleaning agent is used, the machine could be damaged
and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
E The cleaning programme lasts approximately 20 minutes.
E Do not interrupt the cleaning programme. The quality of
cleaning will be impaired if you do so.
E JURA cleaning tablets are available from specialised dealers.
Example: Proceed as follows to clean when prompted to do so.
Precondition:
‘Clean machine.’ and the c symbol are displayed.
O T Press the P button.
‘Maintenance status (1/5)’
T Press the ‘Clean’ button.
T Press the
‘Start’ button.
T Press the
‘Start’ button again.
‘Empty coffee grounds container.’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Press the Rotary Switch.’.
T Place a receptacle under the dual spout.
k T Press the Rotary Switch.
‘Machine is being cleaned.’, water flows out of the dual
spout.
The operation is interrupted,
‘Add cleaning tablet.’.
T Open the cover of the filler funnel for ground coffee.
T Insert a JURA cleaning tablet into the filler funnel.
T Close the cover of the filler funnel.
‘Press the Rotary Switch.’
k T Press the Rotary Switch.
‘Machine is being cleaned.’, water flows out of the dual spout
repeatedly.
The operation is interrupted,
‘Empty coffee grounds contai-
ner.’
.
Cleaning the machine
CAUTION
44
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Clean’ / ‘Cleaning complete.’
Cleaning is now complete. Your GIGA is once more ready for
use.
The GIGA builds up deposits of limescale over time and automati-
cally prompts you to descale it when necessary. The degree of calci-
fication depends on the hardness of your water.
If the descaling agent comes into contact with the skin or eyes, this
can cause irritation.
T Avoid contact with the skin or eyes.
T Rinse off the descaling agent with clean water. Should you get
any descaling agent in your eye, see a doctor.
If the wrong descaling agent is used, the machine could be dam-
aged and/or traces could be left behind in the water.
T Use only original JURA maintenance products.
If the descaling operation is interrupted, there may be damage to
the machine.
T Allow the descaling programme to run to the end.
If the descaling agent comes into contact with sensitive surfaces
(e.g. marble), damage cannot be ruled out.
T Clean up any splashes immediately.
E The descaling programme lasts approximately 45 minutes.
E JURA descaling tablets are available from specialised dealers.
E If you use a CLARIS Blue filter cartridge and this is activated,
you will not be prompted to descale.
Example: Proceed as follows to perform descaling when prompted
to do so.
Precondition:
‘Decalcify machine.’ and the c symbol are displayed.
O T Press the P button.
‘Maintenance status (1/5)’
T Press the ‘Descale’ button.
T Press the
‘Start’ button.
Descaling the machine
J
CAUTION
CAUTION
CAUTION
CAUTION
45
5 Maintenance
T Press the ‘Start’ button again.
‘Empty drip tray.’
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Pour descaling agent into water tank.’
T Remove and empty the water tank.
T Completely dissolve the contents of one blister (3 JURA des-
caling tablets) in a receptacle holding 600 ml of water. This
may take several minutes.
T Pour the solution into the empty water tank and insert it into
the machine.
‘Press the Rotary Switch.’
T Place one receptacle under the dual spout and another
under the hot-water spout.
k T Press the Rotary Switch.
‘Machine is being descaled.’, water flows repeatedly out of
the dual spout and the hot-water spout.
The operation stops automatically.
‘Empty drip tray.’ appears
on the display.
T Empty both receptacles.
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Fill water tank.’
T Remove the water tank and rinse it thoroughly.
T Fill the water tank with fresh, cold water and reinsert the
tank.
‘Press the Rotary Switch.’
T Place the receptacles back under the dual spout and the hot-
water spout.
k T Press the Rotary Switch.
‘Machine is being descaled.’, water flows out of the dual
spout and the hot-water spout.
The operation stops automatically.
‘Empty drip tray.’ appears
on the display.
46
5 Maintenance
T Empty the drip tray and coffee grounds container and put
them back into the machine.
‘Descale’ / ‘Descaling complete.’
Descaling is now complete. Your GIGA is once more ready
for use.
E If the descaling operation stops unexpectedly, rinse the water
tank thoroughly.
Coffee beans may be covered with a slight oil film which remains on
the walls of the bean containers. These traces may negatively affect
the coffee result. For this reason clean the bean containers from time
to time.
Precondition:
‘Fill bean container.’ is displayed.
Q T Switch the machine off with the On/Off button.
3 T Switch the machine off at the power switch.
T Open the service cover on the back of the machine by press-
ing above the JURA logo.
T Push the red sliding catch completely to the rear to close the
bean container.
T Turn the blue locking device outwards.
T Remove the bean container.
T Remove the aroma preservation cover.
T Empty the bean container.
T Clean the bean container with a soft, dry cloth.
T Fit the bean container.
T Turn the blue locking device inwards.
T Pull the red sliding catch completely forwards.
T Refit the service cover and fix it by pressing above the JURA
logo. It will click into place audibly.
T Fill the bean container with coffee beans and close the
aroma preservation cover.
Cleaning the bean
container
47
5 Maintenance
Limescale deposits may form in the water tank. To ensure correct
function of the machine, descale the water tank from time to time.
T Remove the water tank.
T If you use a CLARIS Blue filter cartridge, remove this.
T Descale the tank with a mild conventional descaling agent
in accordance with the manufacturer's instructions.
T Rinse out the water tank thoroughly.
T If you use a CLARIS Blue filter cartridge, insert this again.
T Fill the water tank with fresh, cold water and reinsert the
tank.
Descaling the water tank
48
6 Display messages
6 Display messages
Message Cause/Result Action
‘Fill water tank.’ The water tank is empty. You cannot
prepare any products.
T Fill the water tank (see Chapter 1
‘Preparing and using for the first
time – Filling the water tank’).
‘Empty coffee
grounds
container.’
The coffee grounds container is full.
You cannot prepare any products.
T Empty the coffee grounds
container and the drip tray (see
Chapter 3 ‘Daily operation – Daily
maintenance’).
‘Coffee grounds
container not
fitted.’
The coffee grounds container is not
fitted. You cannot prepare any
products.
T Fit the coffee grounds container.
‘Empty drip tray.’ The drip tray is full. You cannot prepare
any products.
T Empty the drip tray.
T Clean and dry the metal contacts
on the back of the drip tray.
‘Drip tray not
fitted.’
The drip tray is not inserted correctly
or is not inserted at all. You cannot
prepare any products.
T Fit the drip tray.
‘Press the
Rotary Switch.’
The system must be filled with water
or the GIGA prompts you to continue
a started maintenance programme.
T Turn the Rotary Switch to continue
with the maintenance programme
or to fill the system.
‘Fill bean
container.’
, the
bean container
status indicator
flashes.
One of the bean containers is empty.
You cannot prepare any speciality
coffees for which coffee beans are
required from this bean container.
You can prepare hot water or milk.
T Fill the bean container (see
Chapter 1 ‘Preparing and using for
the first time – Filling the bean
container’).
‘Rinse the milk
system.’
The GIGA is prompting you to rinse the
milk system.
T Press the P button and then the
‘Rinse the milk system’ button to
initiate milk system rinsing.
‘Clean machine.’ The GIGA is prompting you to clean it.
T Perform cleaning (see Chapter 5
‘Maintenance – Cleaning the
machine’).
‘Decalcify
machine.’
The GIGA is prompting you to
descale it.
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the
machine ’).
49
6 Display messages
Message Cause/Result Action
‘Change filter.’ After 50 litres of water have flowed
through the CLARIS Blue filter
cartridge or after two months, it will
cease to work.
T Replace the CLARIS Blue filter
cartridge (see Chapter 5 ‘Mainte-
nance – Changing the filter’).
‘Spout is not
fitted.’
The cover of the dual spout is not
fitted correctly.
T Fit the cover of the dual spout
correctly.
‘Not enough
ground coffee.’
There is insufficient ground coffee in
the machine; the GIGA stops the
operation.
T The next time you prepare a
beverage, add more ground coffee
(see Chapter 2 ‘Preparation –
Ground coffee’).
‘Service cover is
not fitted.’
The service cover on the back of the
machine is not fitted. You cannot
prepare any products.
T Fit the service cover.
‘Please check the
ventilation slats.’
The ventilation slats on the top of
the machine cannot be opened.
You cannot prepare any products.
T Contact customer support in your
country (see Chapter 11 ‘JURA
contact details / Legal information’).
50
7 Troubleshooting
7 Troubleshooting
Problem Cause/Result Action
Insufficient foam is
produced when the milk
is frothed, or milk sprays
from the dual spout.
The dual spout is dirty.
T Rinse and clean the dual spout (see
Chapter 5 ‘Maintenance – Cleaning
the milk system’).
Coffee only comes out in
drips when it is being
prepared.
Coffee or ground coffee has
been ground too finely and
is blocking the system. The
same filter cartridge may
have been used several
times or the water hardness
set incorrectly in the
programming mode.
T Put the grinder on a coarser setting
or use coarser ground coffee (see
Chapter 4 ‘Permanent settings in
programming mode – Setting the
consistency of grind’).
T Perform descaling (see Chapter 5
‘Maintenance – Descaling the
machine ’).
‘Fill bean container.’
is not displayed although
the bean container is
empty.
The bean monitor is dirty.
T Clean the bean container (see
Chapter 5 ‘Maintenance – Cleaning
the bean container’).
Preparation stops,
‘Fill bean container.’
is briefly displayed
although the bean
container has been filled.
The sliding catch for the
bean container has not been
pulled out or has not been
pulled out completely.
T Open the service cover on the back
of the machine and pull the sliding
catch all the way out (see Chapter 5
‘Maintenance – Cleaning the bean
container’).
‘Empty drip tray.’
is always displayed.
The metal contacts of the
drip tray are dirty or wet.
T Clean and dry the metal contacts on
the back of the drip tray.
‘Fill water tank.’
is displayed although the
water tank is full.
The water tank float is
trapped.
T Descale the water tank (see
Chapter 5 ‘Maintenance – Descaling
the water tank’).
‘Error 2’ is displayed. If the machine was exposed
to the cold for a long period
of time, heating is disabled
for safety reasons.
T Warm the machine at room
temperature.
51
7 Troubleshooting
Problem Cause/Result Action
Other
‘Error’ messages
are displayed.
–
T Switch the GIGA off at the power
switch. Contact customer support in
your country (see Chapter 11 ‘JURA
contact details / Legal information’).
E If you were unable to solve the problem, contact customer
support in your country (see Chapter 11 ‘JURA contact details /
Legal information’).
52
8 Transport and environmentally friendly disposal
8 Transport and environmentally friendly disposal
In order to protect the GIGA from frost during transport, the system
must be emptied.
Precondition:
‘Please select product:’ is displayed.
T Place one receptacle under the dual spout and another
under the hot-water spout.
O T Press the P button.
‘Maintenance status (1/5)’
g T Turn the Rotary Switch until the programme item ‘Machine
settings (3/5)’
is displayed.
T Press the
‘Factory setting’ button.
‘Factory setting’
T Press the ‘Empty system’ button.
‘Empty system’ / ‘Remove the water tank.’
T Remove and empty the water tank.
‘Press the Rotary Switch.’
k T Press the Rotary Switch.
‘System is emptying.’, water flows out of the dual spout and
the hot-water spout.
The operation stops automatically. Your GIGA is switched
off.
Please dispose of old machines in an environmentally neutral way.
H
Old machines contain valuable, recyclable materials which should
be recycled. Please therefore dispose of old machines via suitable
collection systems.
Transport / Emptying the
system
Disposal
53
9 Technical data
9 Technical data
Voltage 220–240 V ~, 50 Hz
Power 2300 W
Conformity mark
A S
Energy consumption
‘Save energy’ / ‘Save No’
Approx. 30 Wh
Energy consumption
‘Save energy’ / ‘Save Level 1’
Approx. 12 Wh
Energy consumption
‘Save energy’ / ‘Save Level 2’
Approx. 15 Wh
Pump pressure Static, max. 15 bar
Holding capacity of water tank 2.6 l
Holding capacity of bean container 2× 280 g
Holding capacity of coffee grounds
container
Max. 20 portions
Cable length Approx. 1.2 m
Weight Approx. 18 kg
Dimensions (W H D) 32 41.5 48 cm
Information for testers (repeat test in accordance with DIN VDE
0701-0702): The central grounding point (CGP) is located on the back
of the machine below the JURA logo (remove service cover, turn
JURA logo anti-clockwise).
54
Index
10 Index
A
Addresses 59
Aroma preservation cover
Bean container with aroma preservation
cover 4
Automatic switch-off 30, 31
Automatic switch-on 30
B
Background 34
Bean container
Bean container with aroma preservation
cover 4
Cleaning 46
Filling 10
Status indicator 4
Bean container status indicator 4
Beans à la carte
Activating the grinder selection 19
Bus bar
Technical data 53
Button
On/Off button 5
P button (programming) 5
C
Cappuccino 15
Cappuccino frother cleaning
Cleaning the milk system 37
Cappuccino frother rinsing
Rinsing the milk system 37
CLARIS Blue filter cartridge
Changing 42
Inserting and activating the filter 41
Cleaning
Bean container 46
Machine 43
Coffee 15
Coffee à la carte 15
Coffee grounds container 4
Consistency of grind
Setting the consistency of grind 26
Contact details 59
Cover
Service cover 5
Water tank 4
Cup grille 4
Customer support 59
D
Date 29
Descaling
Machine 44
Water tank 47
Display 5
Display messages 48
Display settings 34
Disposal 52
Double product 16
Drip tray 4
Dual spout
Dismantling and cleaning 38
Height- and width-adjustable dual
spout 4
E
Emptying the system 52
Energy-saving mode 28
Errors
Troubleshooting 50
Espresso 15
Expert mode 24
F
Factory settings
Restore factory settings 32
Filler funnel
Filler funnel for ground coffee 4
Filling
Bean container 10
Water tank 9
Filter
Changing 42
Inserting and activating the filter 41
First-time use 10
G
Grinder
Activating the grinder selection 19
Setting the consistency of grind 26
Ground coffee 17
55
Index
H
Hotline 59
Hot water 20
Hot-water spout
Height-adjustable hot-water spout 4
I
Instant coffee
Ground coffee 17
Internet 9
J
JURA
Contact details 59
Internet 9
L
Language 33
Latte macchiato 15
Locking device 5
M
Machine
Cleaning 43
Descaling 44
Rinsing the coffee system 36
Setting up 9
Switching off 22
Switching on 21
Mains cable 4
Maintenance
Daily maintenance 21
Maintenance 36
Maintenance settings 26
Messages, display 48
Milk
Connecting milk 14
Milk system
Cleaning 37
Rinsing 37
P
Permanently setting amounts for the cup
size 18
Permanent settings in programming mode
23
Power switch 4
Preparation 15
At the touch of a button 16
Cappuccino 15
Coffee 15
Espresso 15
Ground coffee 17
Hot water 20
Latte macchiato 15
Ristretto 15
Two speciality coffees 16
Using the product selector 17
Preparation options 15
At the touch of a button 16
Using the product selector 17
Problems
Troubleshooting 50
Product selector 15, 17
Product settings 24
Expert mode 24
Programming mode 23
Automatic switch-off 31
Background 34
Display settings 34
Energy-saving mode 28
Language 33
Maintenance settings 26
Product settings 24
Querying information 35
Restore factory settings 32
Setting the consistency of grind 26
Setting the water hardness 28
Time and date 29
Timer 30
Units 32
Proper use 6
56
Index
Q
Querying information 35
Quick installation 11
Quick mode 24
R
Rinsing the coffee system 36
Ristretto 15
Rotary Selection 15
Product selector 17
Rotary Switch 5
S
Safety 6
Safety information 6
Service cover 5
Service socket 5
Settings
Maintenance settings 26
Permanent settings in programming
mode 23
Setting up
Setting up the machine 9
Short operating instructions 9
Sliding catch 5
Splash guard 4
Spout
Height-adjustable hot-water spout 4
Height- and width-adjustable dual spout
4
Standard installation 12
Switching off
Machine 22
Switching on
Machine 21
Switch-off
Automatic switch-off 30, 31
Switch-off time 30
Switch-on
Automatic switch-on 30
Switch-on time 30
Symbol description 3
T
Technical data 53
Tel 59
Time 29
Time format
Programming mode 32
Timer 30
Transport 52
Troubleshooting 50
Two products 16
U
Units 32
Use, First-time 10
V
Ventilation slats 4
Venti Ports
Ventilation slats 4
W
Water hardness
Determining the water hardness 14
Setting the water hardness 28
Water tank 4
Descaling 47
Filling 9
Website 9
57
58
59
11 JURA contact details / Legal information
11 JURA contact details / Legal information
JURA Elektroapparate AG
Kaffeeweltstrasse 10
CH-4626 Niederbuchsiten
Tel. +41 (0)62 38 98 233
@ You will find additional contact details for your country at
www.jura.com.
The machine complies with the following directives:
U
2006/95/EC – Low Voltage Directive
U
2004/108/EC – Electromagnetic Compatibility
U
2009/125/EC – Ecodesign Directive
We reserve the right to make technical changes. The diagrams used
in these instructions for use are for illustration purposes only and do
not represent the original colours of the machine. Some details of
your GIGA may vary.
Your opinion is important to us! Use the contact link at
www.jura.com.
The instructions for use contain information which is protected by
copyright. It is not permitted to photocopy these instructions for use
or translate them into another language without the prior written
consent of JURA Elektroapparate AG.
Directives
Technical changes
Feedback
Copyright
60
11 JURA contact details / Legal information
1. Preparation
Checking the scope of supply
Setting up and connecting the machine
Filling with coffee beans
2. First-time use
Selecting your language
Setting the time and date
Inserting and activating the CLARIS Blue filter
cartridge
Filling the system
Determining and setting the water hardness
3. Product preparation
Preparation at the touch of a button
Preparation using the Rotary Switch
1. Your personal hotline number 2. Date of purchase
3. Name and stamp of specialised dealer
Machine data
Checklist for first-use training
4. Control options
Operation using the multi-function buttons
Operation with the Rotary Switch
Demonstrating the beans à la carte function
Permanent settings by cup size
Permanent settings in programming mode
Setting the consistency of grind
5. Maintenance
Cleaning the milk system
Dismantling and rinsing the dual spout.
Explaining the maintenance programmes
6. Date of first-use training
7. Training was undertaken by
FIRST USE
Art. 69878/GIGA5/en/201110
