OPERATION MANUAL OF FOLDABLE FAN
F10
Instructions × 1 Remote Control × 1
Power Adapter x 1
Front GRILL COVER
REAR GRILL COVER
Upper column
Push button
Chassis upper cover
Chassis lower cover
Power interface
Blades
Telescopic tube
Decorative ring
Display panel
Lower column
PART NAME
ACCESSORIES LIST
INSTRUCTIONS FOR FOLDING AND ADJUSTING
Tips:
Operation steps:
USER GUIDE
Push
button
1. In the folded state, firmly hold the base by hand, and then place the fan head at
2. After fixing the fan head, lift the telescopic tube 90°.
3. Rotate the fan head by 90° while ensuring that the telescopic tube is not shaking.
4. Adjust the height of the fan: hold the
upper column with one hand, press the base
5. Storage: do the operation steps in reverse to fold and store the Fan.
Power
Turn on/off
Speed
1. Short press to adjust the
wind speed, and control the
speed from 01 to 12, then
cycle from 01 again.
2. Long press button for 3
seconds when running to
switch fan toSleep Mode -
Smart Mode - or Normal Mode.
Swing
Turn on/off
the oscillating function
Timer
1. In running, you can set a
Timer to turn off Fan.
2. In Standby , you can
set a Timer to start.
3. Timer can be cycle from 01 to 12.
BUTTON DESCRIPTION
Display panel
Control panel
Timer display indicator:
When displayed, the“88”shows
the timer’s remaining time.
Smart mode:
Wind speed will be adjusted by
temperature: the Fan automatically
adjusts the fan speed according to the
indoor temperature, and the ndigital
displays the real-time gear.
Speed/Timer display:
When timer is not on, it shows the
speed. When timer is on, it shows
speed /timer’s remaining time every
5 seconds.
Sleep mode:
Under the sleep mode, the fan starts
with normal wind and reduces by 1
gear every half an hour. The wind
will finally fall to 1 if starting at 1-3,
and finally fall to 3 if starting at 4-12.
REMOTE CONTROL OPERATING INSTRUCTIONS
1. Remove the insulating sheet from the remote control before use.
2. Recycle battery as it contains hazardous substances.
On/Off
Turn Display on/off
Decrease wind speedIncrease wind speed
Mute
Turn on/off the oscillating
function
Smart mode:
The speed will be
adjusted by temperature
Make an appointment to
power on /off up to 12 hours.
Sleep mode
1. Battery power display: Every two small bars represent one grid of electricity.
2. During the charging state of the machine, six small bars display the battery power.
In the case of charging without connecting the adapter and starting up, six small bars
will show the remaining battery power (from left to right: 30%, 60%, 100%).
3. When the battery is low, the indicator flashes.
Note:
1. When the power supply is not switched on ( i.e. in standby ), the fan has memory
function. It can remember the wind speed, swing head and mode state before standby.
2. The whole machine shuts down automatically for 24 hours without operation. If no
button is pushed on the remote control and control panel within a 24 hour period, the
fan will automatically shut down.
A. The unfolding & folding of the whole machine needs to be operated on a flat and
B. The telescopic tube should be adjusted one by one from top to bottom.
stable surface, such as the ground or a desktop.
or telescopic tube with the other hand, and gently adjust the tube upward to your
desired height. Make sure to be gentle while adjusting the telescopic tube and push
button during use.
QUALITY ASSURANCE CARD
Matters Needing Attention
1. When the product is used in a commercial setting, the time limit of the warranty guarantee
will be reduced by half.
2. If the purchase date of the guarantee is filled in, altered or inconsistent with the material
object, the guarantee will lose its effectiveness.
3. The accessories and consumable parts of this product are not guaranteed
(such as remote control, packaging materials, user manual...).
4. In case of any of the following circumstances, no free preferential treatment will be given
during the warranty period.
(A) Failure or damage caused by natural or man-made disasters.
(B) Failure or damage caused by the relocation or handling of the body position.
(C) The cause of the failure occurs outside the body, such as failure or damage caused
by external forces during outdoor activities.
(D) Damage or misuse of the goods due to malfunction or misuse.
(E) Failure or damage caused by unauthorized modification of goods or maintenance by
professionals not affiliated to the company.
AIRDOG USA INC.
Official Website: https://airdogusa.com/
Customer Service: [email protected]
Official Website: https://airdogusa.com/
C. Always turn off the power before unfolding & folding the fan.
a 90°.
