HOICE
Your choice for value!
INSTRUCTIONS FOR USE AND CARE
OF YOUR INSULATED PRODUCTS
Care and Cleaning of Insulated Carrier
1. Clean after every use. Destaining
compounds approved for food or
beverage contact may be used. Ask your
detergent supplier for proper compound.
2. Make sure gasket is removed prior
to running through a dishwasher. Also,
prevent latches from getting caught in the
conveyor.
Proper Use of Your Insulated Product
1. Wash and rinse the unit prior to its use.
2. Preheating interior with hot water will
improve heat retention.
3. Pre-chilling entire unit will improve cold
retention.
4. Load container to its maximum capacity.
Make sure the gasket is in place. Replace
lid and lock in position.
Beverage Dispenser Filling Instructions
CAUTION Liquid can overflow or squirt out of the vent cap when securing lid if the unit
is overfilled. TO PREVENT OVERFLOW, DO NOT FILL HIGHER THAN 1⁄” FROM TOP.
EXPLODED PARTS DIAGRAM
Beverage Dispenser Faucet
Number Part Name
1 Faucet Lever
2 Bonnet
3 Stem End
4 Spring
5 Rubber Seat Cup
6 Faucet Body
7 Union Nut
8 Wing Nut
9 Large Rubber Washer
10 Small Rubber Washer
11 Metal C Ring
12 Spout
Care and Cleaning of the Faucet
To remove faucet assembly from unit:
1. Unscrew union nut to remove faucet from unit.
2. Unscrew bonnet from faucet body to expose rubber seat cup
and stem end. Pull down on seat cup to remove.
3. Push back union nut and remove metal “c” ring. Unscrew wing
nut to remove spout from unit completely. Set aside large rubber
washer, small rubber washer and “c” ring.
4. Depress faucet lever in “locked open” position to clean top of
bonnet thoroughly.
5. Clean all parts of faucet with a solution of hot water and urn cleaner. Use a faucet brush to clean the insides of
the faucet and spout.
To return faucet assembly to unit:
1. Place small rubber washer on spout first. Then place spout inside unit.
2. Place large rubber washer on spout from outside the unit.
3. Screw wing nut on spout with circle base facing the unit. Fit union nut on spout with inner screw side facing
out. Replace metal “c” ring.
4. Replace rubber seat cut on spring and stem end of faucet. Apply pressure to secure seat cup.
5. Screw bonnet onto faucet body.
6. Screw faucet onto spout and tighten union nut.
