Technical Specification
Water
Filters
Steaming Hot
Water Tap
Specification
Chemical & Mechanical F-701R (Use replacement cartridge F-701R)
Reduction Filter This cartridge (included with the system)
Specifications: provides mechanical and chemical reduction
of dirt/rust, taste/odour, chlorine, lead and
particulates. Also has the ability to reduce
scale formation by reducing hardness and
alkalinity
Caution: Do not use with water that is microbiologically
unsafe or of unknown quality without
adequate disinfection before or after system
Warning: For correct operation of this appliance, it
is essential to observe the manufacturer’s
instructions. Do not install where freezing
may occur
Incoming cold water pressure: 172-862 kPa (25-125 psi) (1.7-8.6 bar)
Incoming water temperature: 0.6ºC-38ºC (33°F-100°F)
Flow Rate: 2.84 lpm (0.75 gpm)
Capacity: F-701R: 454 litres (120 gallons)
Influent
F-701R
Average Challenge Product Average % Reduction Max. Min. %
Contaminant Reduction Influent Concentration Water Reduction Requirements Effluent Reduction
Chlorine 2.1 2.0 mg/L ± 10% 0.03 98 75% N/A N/A
Taste & Odour
F-701 Particulate Class III 49333 At least 10,000 312 99 85% 640 98.70
Particule size: particles/mL
5.0 to < 15.0 µm
Lead @ pH 6.5, mg/L 0.14 0.15 ± 10% 0.0011 99.21 0.01 0.0014 99.00
Lead @ pH 8.5, mg/L 0.15 0.15 ± 10% 0.0042 97.08 0.01 0.0069 95.40
Scale mg/L 478 mg/L ± 10% 250 50 N/A 95% non- N/A
sealing
F-701R
Technical Specification
Water Filters
InSinkErator
®
is a registered trademark of
Emerson Electric Co.
Emerson
™
is a trademark of Emerson Electric Co.
© Copyright 2006
INS 14641/4 MDG 08/06 AUST/NZ
InSinkErator
471 Mountain Highway
Bayswater Vic 3153
Australia
Phone: 1300 136 205
Fax: 03 9720 3178
Email: sales@insinkerator.com.au
Web: www.insinkerator.com.au
Parex Industries Ltd.
103 Central Park Drive
P.O. Box 21-102
Henderson
Auckland 0650
New Zealand
Phone: 0800 200 510
Fax: 0800 200 520
Web: www.parex.co.nz
®
Fitting
Below are replacement instructions, and a guide to fitting
a tandem filtration system.
To install new filter:
Insert in the filter head
and twist 1/4 turn counter
clockwise
Replacement Instructions:
Note: Water automatically shuts off when filter is removed.
To remove old filter:
Twist 1/4 turn clockwise
and remove
Application
InSinkErator water filters are designed
exclusively for use with the InSinkErator
Steaming Hot Water Tap system. A premium
sink appliance for the kitchen that conveniently
dispenses instant 98°C water from a single tap.
Ideal for making tea, preparing pasta, cleaning
dishes, blanching vegetables, warming baby’s
bottle or for any other activity that requires the
use of steaming hot water.
Models
F-701R
F-701R will come standard with
all 1100 series systems. It is a
chlorine, taste and odour filter
with additional lead protection
and a scale reduction capability.
It filters sediment at a 5 micron
level. It is sold as replacement
filters in a two pack carton
Technical Specification
Water Filters
Features
• Shut off valve built into
filter head to automatically
stop water flow
• Easy, no mess,
replaceable filter
• Adjustable
temperature dial
• Compact design
Benefits
• Better tasting filtered
drinking water
• Reduces chlorine, lead,
turbidity, particulates
and other unpleasant
tastes and odours from
water
• Special scale reduction
technology to protect
heating elements in
hard water
• Time-tested quality
