INSTALLATION INSTRUCTION
WEEE Number: 80133970
WIFI SPIKE LIGHT
2
YEARS
WARRANTY
*
Ok Google
works with
IP65
RATING
INTRODUCTION & WARRANTY
TECHNICAL DATA
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST
DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
MODEL VT-5167 VT-5168
POWER 7W 7Wx3
MODULE POWER 5.2W 5.2Wx3
VOLTAGE
MODULE VOLTAGE DC:24, 7V DC:24, 7V
CURRENT 21MA 21MA
MODULE CURRENT 52MA 52MA
LUMEN 520LM
520LMx3
MODULE LUMEN 700LM
700LMx3
BEAM ANGLE 70° 70°
MODULE BEAM
ANGLE
SPHERE 360° SPHERE 360°
DIMENSION 232x140mm 232x140mm
LIFE SPAN 25,000 Hours 25,000 Hours
BODY TYPE PC PC
AC:220-240V, 50/60Hz
EU PLUG
SAFETY WARNING
APP INSTALLATION
NOTE:
22
PAP
MULTI-LANGUAGE
MANUAL QR CODE
ALEXA SETTINGS
Note: Discovering the device must be done every time the device’s name is changed on
the app.
! Alexa, turn on/off bedroom light.
! Alexa, set bedroom light to 50 percent.
! Alexa, set bedroom light to green.
! Alexa, set bedroom light to warm white.
2. Make sure you have Amazon Alexa Device(including Echo, Echo Tap, or Echo Dot)
4. Stable Wifi network
1. V-TAC Smart Light App & Amazon Alexa App
3. Smart Device - Lamp
ALEXA Commands
THINGS TO REMEMBER BEFORE STARTING INSTALLATION:
GOOGLE HOME SETTINGS
! Ok, Google, turn on/off bedroom light
! Ok, Google, set bedroom light to 50 percent.
Ok, Google, set bedroom light to green.
!
! Ok, Google, set bedroom light to warm white.
2. Make sure you have Google Home Device
4. Stable Wifi network
1. V-TAC Smart Light App & Google Home App
3. Smart Device - Lamp
Google Commands:
THINGS TO REMEMBER BEFORE STARTING INSTALLATION:
DISASSEMBLING DIAGRAM
HOW TO DISASSEMBLE THE DEVICE
STEPS TO DISSASSEMBLE THE LAMP
(ONLY FOR MARKET SURVEILLANCE AUTHORITY)
