MULTI-PATTERN SPRINKLER PLUS MISTING SYSTEM
WITH TELESCOPING TRIPOD
Step 2
Attach the Extension Tube to the tripod, then
connect the sprinkler head to the top of the
Tripod or Extension Tube (do not overtighen).
Adjust the range tabs and angle cap to change
the spray coverage(from 5° up to 360°) and
spraying angle to water just where you need.
Spray Coverage and
Distance Adjustment
Depending on your watering needs, you can manually select from the
various pattern settings:
FLAT - The at pattern will provide a at wave of water.
FAN - The fan pattern disperses water in a wide fan shape.
MIST - This pattern is useful to cool down a small area.
LARGE - This provides a larger watering spray area.
MULTI - This is a combination of the Flat, Fan and Large patterns.
MINI - Provides delicate plant watering
Spray Pattern Adjustments
FLAT
FAN
MIST
MINI
LARGE
MULTI
94152EDAMZ
Step 3
Use the Quick Connect to easily connect and disconnect the sprinkler from the hose.
Connect the Product Adapter to the base of the sprinkler. Attach the lockable Quick Connect
to the end of the hose, then simply snap in the hose to the sprinkler to begin using.
Premium Quick Connect
Starter Set
ts standard garden
hoses and watering tools
Note: If you are not using
the Quick Connect System,
simply connect the sprinkler
directly to the hose.
18.7”
(47.5cm)
63.7”
(162cm)
Place the tripod in the area
where you want to water.
Open the latches to release
the legs. Push down on the
tripod legs until the legs are
well seated in the ground.
Step 1
43.7”
(111cm)
