Installation Guide
Parts List
Assembly
1 2
Cable Runway Center Support Kit
Models: SRLCNTRSPPT12, SRLCNTRSPPT18
The SRLCNTRSPPT12/18 simplifies ceiling installation of runway by creating a single point of attachment.
Español 2 • Français 3 • Русский 4
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2018 Tripp Lite. All rights reserved.
Center Support
Bracket (x1)
Threaded Rod
Cover (x1)
5/8-11 Hex Nut
(x2)
5/8 Lock Washer
(x2)
M8 J-Bolt
(x2)
M8 Lock Washer
(x2)
M8 Hex Nut
(x2)
Cable Ladder
Not Included
Tripp Lite Center Support Kit Raceway Width
SRLCNTRSPPT12 12” (300 mm)
SRLCNTRSPPT18 18” (460 mm)
The mounting surface must
be able to safely support the
combined load of the equipment.
Use appropriate fasteners (not
included) to secure the bracket.
Use suitable mounting means
when installing to cinder block,
concrete, drywall or wood studs.
Threaded Rod
Not Included
