QUICK REFERENCE GUIDE > HC36DCXB4 Date: 02.03.2023 > 1
Wall Range Hood, 36", Box
Chimney
Series 7 | Contemporary
Stainless Steel and Glass
This Contemporary style range hood extracts steam, grease and
cooking odors quietly and efficiently.
With three fan speeds plus a boost function, select the perfect
extraction rate for your cooking
Energy-efficient LED lighting to illuminate your cooking surface
Powerful maximum air movement of 400CFM
Wi-Fi enabled for notifications through the SmartHQ™ app
DIMENSIONS
Height 23 3/4 - 41 1/16"
Width 35 3/8"
Depth 19 11/16"
FEATURES & BENEFITS
QUIET AND EFFECTIVE
Featuring perimeter extraction, four fan speeds, and a boost
function, this range hood provides powerful extraction to quickly
remove odors and steam. Odors can linger in the kitchen well
after cooking is finished so the timer keeps the hood working for
up to 15 minutes before automatically turning off.
SIMPLE CONTROLS
The intuitive control panel responds to the touch of your finger.
LED strip lighting illuminates the entire cooktop surface for the
perfect sear or ideal reduction. Range hood settings, including
temperature and fan speed, can be controlled via the SmartHQ™
app, with additional voice control options for fan speeds and
lighting.
EASY CLEANING
Designed for simple removal, the filters are easy to clean and
dishwasher safe, while the glass and stainless steel finish is easily
wiped clean. The SmartHQ™ app will notify you when to clean
the filter to ensure you get the best performance out of your
range hood.
COMPLEMENTARY DESIGN
The stainless steel finish of this vent hood will complement any
contemporary kitchen and is designed to match the rest of
Fisher & Paykel kitchen appliance family.
EASY INSTALLATION
This range hood is the perfect partner to your Fisher & Paykel
cooktop. It can be either externally ducted or internally
recirculated, making it perfect for apartments.
SPECIFICATIONS
Accessories
Aluminium filter 792577
Chimney extension 791774
Recirculation carbon filter 792481
Recirculation diverter 792560
Fan ratings
Maximum air movement 400CFM
Installation and cleaning
Air outlet size 6"
Dishwasher safe filters 4
Ducted Top extraction
Recirculation Optional - top extraction
