TOP LOAD WASHER
Finally, a top load washer engineered for
multi-housing providers.
SMART DESIGN FOR A BETTER EXPERIENCE
• Large Capacity for Families and Bulky Items
• Superior Cleaning Performance
• 4 Cycle Options: Cold, Warm, Hot, and Delicate
• Separate Controls for Heavy Soil and Extra Rinse
• Quicker Drying Time Due to a Fast 745 RPM Spin
Real Choice
Better Solutions
• 2.9 cu. ft. Capacity
• 155 G-Force Extraction
• Direct Drive Motor
• Onboard Self Diagnostics
• Pro Smart Accelerometer
• Quieter Operation
• Sharp LED Display
• No Lid Lock
• 4 Wash Cycles
• Add Revenue with Heavy Soil
and Extra Rinse Options
• Easy Adjustable Legs
• Durable 3-Layer Paint
Application
• Coin and Card Compatibility
• 5-Year Parts Warranty
Built with professional-grade components,
outlasting the competition and backed by
the best 5-year parts warranty.
SIGNATURE PRO FEATURES
PRO GRADE
OUTER TUB
ULTRA CONVENIENT
NON LOCKING LID
EASY ACCESS
REPAIR PANEL
SIMPLE SELECT
CONTROL
Greater durability for years of
superior performance.
Safely add or remove items
at any point in the cycle.
90% serviceability from the
front of the machine.
Eliminate error with intuitive
controls and wash options.
© 2021 Laundrylux. All rights reserved.
Laundrylux, 461 Doughty Blvd., Inwood, NY 11096. Tel: 1-800-645-2204. laundrylux.com
WMTW4371
20210315
SPECIFICATIONS
Model WMTW4371FMI (coin)
WMTW4371DC (card)
WMTW4371OPL (OPL)
Capacity – lb (kg) 18 lb (8 kg)
Cylinder Volume – cu. ft. (liters) 2.9 cu. ft. (82 l)
Wash Cycles & Options Cold, Warm, Hot, Delicate,
Heavy Soil, Extra Rinse
Motor 0.34 HP (0.25 kW)
Electrical Rating – v/Hz/Ph 120 V/60 hz/1-phase
Breaker Requirements – Amps 15 A
Wash Speed – RPM 745 RPM (maximum)
Maximum G-force 155 G
Inlet Hose – in 2x ⅜ in (hoses included)
Water Pressure – Psi (kPa) 8-145 psi (50 -1000 kPa)
Drain Hose – in (mm) 0.94 in (24 mm)
Crated Weight – lb (kg) 163 lb (74 kg)
Uncrated Weight – lb (kg) 137 lb (62 kg)
EQUIPMENT DIMENSIONS
A. Overall Width – in (mm) 27 in (686 mm)
B. Overall Depth – in (mm) 27 in (686 mm)
C. Overall Height – in (mm) 44
21
/64 in (1126 mm)
D. Height with Lid Up – in (mm) 52
61
/64 in (1345 mm)
Actual color may vary. Dimensions are for planning purposes only.
Refer installation and servicing to qualied, licensed personnel. Always read Installation and
Operating Manuals and consult local codes before installation. Protect machines with properly
rated circuit breakers ONLY. Warranty void if not properly installed.
Because of continuous product improvement, specications are subject to change without notice.
Laundrylux assumes no responsibility for errors or omissions in this information.
W
A
R
R
A
N
T
Y
P
A
R
T
S
TOP LOAD WASHER
COMPLIMENTARY PRODUCTS
Gas Dryer
Electric Dryer
DLHF0315G (coin)
DLHF0315GDC (card)
DLHF0315GOPL (OPL)
DLHF0315E (coin)
DLHF0315EDC (card)
DLHF0315EOPL (OPL)
