Simply attach the sprinkler head to the top of the base.
Hold the bottom of the sprinkler head and base of the
sprinkler to tighten by hand (do not overtighten).
Assembly
Use the Quick Connect System to easily connect and disconnect the sprinkler from the hose. Connect the Product Adapter
to the base of the sprinkler. Attach the lockable Quick Connect to the end of the hose, then simply snap in the hose to the
sprinkler to begin using.
Use the additional included Product Adapter for your nozzles, wands, or other watering tools to switch between tools, even
with the water running.
LOCK
WATER
+
94124EDAMZ
5 spray patterns -
Flat, Fan, Large, Multi and Mist!
Spray Angle - adjust the tabs to change
the spray angle from 5° to 360°
Hose end connector with
added lter to prevent
sediment and dirt from
reaching sprinkler
Flow through design allows
for additional units to be
connected in series
Wide "H" shape
platform design
for more stability
Quick Connect Starter Set
ts standard garden hoses
and watering tools
To extend, simply remove the end-cap and attach
another hose and connect another sprinkler.
MULTI-PATTERN SPRINKLER
PLUS MISTING SYSTEM
Connect the Hose
Note: If you are not using the Quick Connect System,
simply connect the sprinkler directly to the hose.
Move the angle cap to control the distance
of your watering area. The higher level will
create a higher arc for greater water
coverage. The lower level will reduce the
watering area. Convenient indicators help
you remember your settings for next time.
Level Adjustment Indicator
HIGHER LEVEL (1-3):
Adjust the spray upwards for
maximum distance.
LEVEL (0)
Adjust the spray in between a
dispersed and concentrated
watering area.
40 PSI Large Multi Flat Fan
Radius of Spray 39 ft (12 m ) 37 ft (11.5 m) 29 ft (9 m) 27 ft (8.5 m)
Coverage Area
up to
4860 sq ft
(452 m²)
4470 sq ft
(415 m²)
2730 sq ft
(250 m²)
2440 sq ft
(226 m²)
LOWER LEVEL (3-1)
Adjust the spray downwards
to reduce the watering area.
The Quick Connect Adapter (2 pcs) and Hose Connector
with Water Stop (1 pc) simplify your watering experience.
Simply attach the connector at the end of your hose.
Then, connect the adapters to your watering tools.
Interchange various tools in a snap without turning o the
water as the adapter will stop the water ow. No more
kinking or hose twisting as the adapter allows the hose to
swivel 360 degrees.
A
C
A B C D
B
D
Quick and easy connections to 5/8-inch and
1/2-inch garden hoses, sprinklers, nozzles, and/or
any other garden watering tools
-For outdoor use with cold water only
-Do not spray near electrical connections
-When not in use, rinse the tool with water
to remove most of the dirt, dry your tool,
and store indoors
WARNING: This product can expose you to
chemicals including styrene, which is known to
the State of California to cause cancer. For more
information go to www.P65Warnings.ca.gov
UNLOCK
LOCK
UNLOCK
LOCK
Secure twist-and-lock
mechanism prevents
accidental disconnection
Adjust the range tabs and angle cap to change the spray
coverage (from 5° up to 360°) and spraying angle to water
just where you need without wasting water.
Spray Coverage and Distance Adjustment
Depending on your watering needs, you can manually select from the various pattern settings:
FLAT - The at pattern will provide a at wave of water.
FAN - The fan pattern disperses water in a wide fan shape.
MIST - This pattern is useful to cool down a small area.
LARGE - This pattern covers the maximum area.
MULTI - This is a combination of the Flat, Fan and Large patterns.
Spray Pattern Adjustments
FLAT
FAN
MIST
LARGE
MULTI
