WATER DISTILLER
INSTRUCTION MANUAL
Product Features
◆Advanced silent fan + two disc super cooling technology: Steam super cooling.
◆ON/OFF switch: Start or stop condensate production at any time.
◆Anti-dry burning function: After the water inside the main engine is dried, the
temperature control will auto
matically protect and turn off the power.
◆Rapid water production: 4L condensed water can be produced in 3.5 hours.
Notes(Danger and warnning)
Before using this product, please read this instruction carefully and keep it for
future reference.
★Do not immerse the head and base in water or other liquid, nor
flush with faucet.
★After the water in the distillation barrel is dried and automati-
cally protected by temperature control, the machine head as-
sembly shall be opened after an interval of about 10 minutes to
avoid possible burns caused by the steam in the barrel.
★Before the product is connected to the power supply, confirm whether the
marked voltage is consistent with the local used voltage.
★If the plug, socket or product is damaged, do not remove the machine for
repair without permission, to avoid the wrong connection of the internal circuit,
resulting in power short circuit and other dangers.
★This product is not suitable for children, people with physical or mental
disorders, to avoid harm caused by wrong use.
★When taking the head components or cleaning products, turn OFF the
ON/OFF switch first, and unplug the power plug of the head components and the
host power plug.
★For the first time, add 1.0L of water and 2 tablespoons of citric
acid into the tank of the main engine, cover the head assembly,
boil water with electricity for about 20 minutes, after pouring out
the water, rinse the tank and the distillation cover with clean
water (the distilled water made for the first time cannot be
drunk).
★When cleaning the interior, it is forbidden to use steel wire brush (velvet) and
other hard articles to scrub the
inner tank of the main engine and the inner tank of the machine head, so as to
avoid scratches formed on the
surface of the inner tank, which will cause dirt accumulation in the gap with fine
scratches.
★ When it is necessary to stop the production, you can close the ON/OFF
switch, there is no need to wait for the main tank of the water completely dry.
★ This product can continuously produce condensed water, that is, after the
water in the tank is distilled, close the ON/OFF switch, open the head assembly
after an interval of about 10 minutes, add the water with the maximum scale in
the tank of the main machine, and start the power supply operation again, so as
to circulate.
★ Installation and disassembly of outlet nozzle are shown in the diagram as
below:
Use Instructions
◆Open the package, take out the machine (the whole machine extension head
and host machine), extract the head, and take out the inner parts of the tank.
If it is a glass bottle, assemble the handle of the cup and make sure the handle is
firmly assembled.
◆ Add the water with the maximum scale water level into the main engine tank
(do not exceed the water level).
◆ Place the machine head on the main machine (check whether the sealing ring
of the machine head is properly installed or leaking), insert the connecting power
plug (product plug) of the machine head into the socket of the machine head, and
insert the power cord plug (product plug) into the power socket of the machine
head.
◆ After making sure the plug is properly connected and fastened, insert the
power plug into the wall socket.
◆ Turn ON the ON/OFF switch of the main engine, and then press the start
button. The indicator of the start button lights up, the head fan starts to turn, and
the main engine enters the heating state.
(When first used, turn ON the ON/OFF switch and the indicator light is ON)
◆ When the host machine is heated for about 30 minutes, the distilled water
starts to drip out slowly from the
outlet of the host machine until the water in the tank is completely dried and
automatically protected by temperature control.
Cleaning
◆If the shell is soiled, wipe it with a flexible cloth.
◆After each use of the main engine tank, clean the residual fouling with
clean water, and at least burn the cleaning reagent (citric acid) recommend-
ed by our company every month.
◆ Add 1.0L water and 2 tablespoons citric acid into the tank of the main
engine, without covering the head component, boil water for about 30
minutes after electrifying, then pour out the water and use it to clear rinse
with water. If scale cannot be removed at one time, the above method can
be repeated for cleaning.
◆If it is a plastic outlet, it is recommended to replace it every 2 to 3 months.
Common exceptions and handing
◆ Undistilled water drops out
1. The power supply of the host and the power socket of the machine head
are not plugged into the socket. Please check and plug it again.
2. Did not press the start button (the red indicator light did not go on).
3. No water is added to the main engine tank.
◆ The amount of water distilled each time is not enough
1. The water in the main engine tank does not reach the maximum water
level scale.
2. Leakage or poor sealing of the sealing ring of the nose assembly shall be
checked, and the sealing ring shall be reinstalled or replaced with a new
one.
3. No water is added to the tank of the main engine.
4. The outlet nozzle of the machine head is not properly installed, which
needs to be removed and reinstalled.
◆ The head assembly water boiling process shaking or water
overflow
1. The water in the main engine tank exceeds the scale line of the maximum
water level.
2. If the head component is not installed in place in conjunction with the host
machine, it shall be taken out and replaced on the host machine, and the
effect of placement shall be properly felt by hand.
3. The sealing ring of the machine head component is not installed well, it
needs to be taken out and reinstalled.
4. The outlet nozzle is clogged with dirt precipitation, and the outlet nozzle
needs to be replaced or cleaned.
Packing instructions
When opening the package, please confirm whether the following items
are complete item by item so that you can use this product effectively.
NO. Description Unit PP SUS304
1 Water distiller pc 1 1
2 Power cord pc 1 1
3 Water outlet pc 1 1
4 Citric acid cleaner pc 1 1
5 Active�carbon pc 1 1
6 Plastic bottle pc 1 ×
7 Plastic bottle cover pc 1 ×
8 Glass bottle pc × 1
9 Glass bottle handle pc × 1
10 Glass bottle fixed ring pc × 2
11 Screw pc × 1
3
