Wireless Switch
LED Puck Lights
LED PUCK
BATTERY INSTALLATION:
1. Turn the back cover of the puck counterclockwise and remove it.
2. Insert 3 AA baeries, noting polarity. Replace the cover and turn it clockwise.
MOUNTING INSTRUCTIONS:
1. Use the included screws or double-sided tape to mount the back cover. Make sure the
mounting surface area is clean and dry before mounting with the double-sided tape.
2. To install the puck using screws, take o the back cover and insert the screws through
the holes. Do not overtighten.
NOTE: The puck’s back cover may remain mounted when changing batteries.
WALL SWITCH
BATTERY INSTALL AND REPLACEMENT
1. The baery comes pre-installed. To activate for use, pull out the baery tab.
2. To replace baery, slide and remove the baery door from the back of the wall switch.
3. Replace with one A23 baery – noting polarity.
4. Replace the baery door of the wall switch and ensure it is firmly closed.
SWITCH INSTALLATION
1. Remove the back mounting plate from the wall switch by sliding the wall switch
remote upwards.
2. Install the mounting plate using included screws through the mounting plate.
Do not overtighten.
3. Mount the wall switch onto the mounting plate by gently sliding it downward to secure
it in place.
SWITCH OPERATION
• Press up on the switch to turn the light ON, press down to turn the light OFF.
NOTE: There is a 60min. timeout feature that will turn the light OFF to conserve battery life. The wall-
switch remote will control all Energizer Wireless Switch LED Puck Lights (58822)
within a 50-foot range.
MADE IN CHINA/HECHO EN CHINA
Wireless Switch LED Puck Lights
FCC NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this
equipment. Such modifications could void the user’s authority to operate the equipment.
FCC STATEMENT:
Suppliers Declaration of Conformity | Model #: 58822 | Jasco Products Co., 10 E. Memorial Rd., Oklahoma City, OK 73114,
www.byjasco.com
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation. This device must not be co-located or operating in conjunction with any other antenna or transmier.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.To comply with FCC’s RF radiation exposure limits for general
population/uncontrolled exposure, this device must be installed to provide a seperation distance of at least 20cm from all
persons.
WARNING: changes or modifictions to this unit not expressly approved by the party resposible for compliance could void the
user’s authority to operate the equipment.
• BATTERIES MAY LEAK HARMFUL
LIQUIDS OR IGNITABLE MATERIALS
OR EXPLODE CAUSING INJURY AND
PRODUCT DAMAGE
• DO NOT MIX OLD AND NEW OR OTHER
BATTERY TYPES
• REPLACE ALL BATTERIES AT THE
SAME TIME
• REMOVE BATTERIES IF PRODUCT
IS TO BE UNUSED FOR EXTENDED
PERIODS OF TIME
WARNING
©2021 Energizer. Energizer and certain graphic designs are trademarks of Energizer
Brands, LLC and related subsidiaries and are used under license by Jasco Products
Company, LLC.
Questions? Contact our U.S.-based Consumer Care at 1-800-654-8483 between
7AM-8PM, M-F, Central Time.
90-day warranty. Visit www.byjasco.com for warranty details.
58822 EnSp Manual v1
12/16/20 MS
