CR0016W
OFF
115V
REMINDING
When opening the door, please pay attention to tearing off the tape in the picture first, and then taking out the
plastic limit block. Otherwise, directly opening the door may catch the plastic limit, which may cause deformation
of the door panel or shell!
!
5
(at the back of refrigerator)
1
.
2
To avoid to yourself and/or property, we recommend someone assist you during the door
reversal process.
injury
NOTE:
To take the door off it is necessary to tilt the
Appliance backward. You should rest the
Appliance on something solid, e.g. a chair just
below the top panel.
DO NOT lay the Appliance completely
as
this may damage the coolant system.
Ensure the Appliance is unplugged and empty.
Adjust the two leveling feet to their highest
position.
We recommend you have someone to assist
you.
8mm socket screw driver
Phillips style screw driver
1. Upper Hinge Bracket
2. Adjustable Leveling Foot
3. Machine Screw
4. Bottom Hinge Bracket
Remove the upper hinge cover, then unscrew the upper screws of metal hinge bracket and take off the
hinge. Then take off the right side screw cover. Pull the appliance door upward to take it off.
Remove the screws and take out the lower hinge. Rotate counterclockwise to unscrew the hinge shaft.
Rotate the hinge shaft clockwise on the other side of the lower hinge to screw it in. Flip over the lower hinge
and fix it on the box and door body with screws.
REVERSING THE DOOR POSITION
Slot in the appliance door into the bottom hinge pin. Replace the upper hinge bracket on the new side
and check the fitting between the door/ hinge moving smoothly. Then tighten the screws of upper hinge
bracket. Replace the hinge cover and the left side screw cover.
Check that the door is aligned horizontally and vertically and that the seals are closed on all sides before
finally tightening the upper hinge.
17.5 x 18.1 x 19.6
AC115V 60Hz
208 kwh
CR0016W
959 Route 46 East
Suite 210, 2 Floor
Parsippany, NJ 07054
15-01-1402
nd
CR0016W-20230615-01
