E-bike User’s Manual
CAUTION READ THIS MANUAL BEFORE USING YOUR EQUIPMENT
CONTANTS
Sa fet y ins t ruc ti on -- -- -- -- -- -- -- -- --- -- -- -- -- --- -- -- -- -- -- -- -- -- --- -- -- -- -- -- -- -- -- -
Instruction-------------------------------------------------------------------------
M et e r o pe r a t i o n -- - - - -- - - - - -- - - - - - - - -- - - - - -- - - - - -- - - - - - -- - - - - - - -- - - - - -- - - - - -- - - - - -
B at t e r y : F u r th e r in f o r m a t i o n a n d m a i nt e n a n c e - - - -- - - - - - - - - -- - - - - - - - - - -- - - - - - - - - -
Charging---------------------------------------------------------------------------
Installation Instruction----------------------------------------------------------
1. Safety Instruction ___________________
1. Thank you for purchasing the ANCHEER E-BIKE. The E-BIKE features the most recent
innovation in technology.
2. For Safety reasons, it is most important that you read this user’s manual before you operate the
bike. Improper handling can reduce its riding performance and most importantly, cause danger to
your safe and healthy.
3. For handling and maintenance of the bicycle, please refer to the E-BIKE user’s manual which is
an integral part of this e-bike user’s manual!
4. Do not at any time dismantle or disassemble any of the above e-bike components!
5. Please check all parts are tighten and locked before riding.
6. Please make sure that the battery charger and charging plug are always kept dray and never get
wet.
7. The charger should only be cleaned with a dry cloth. Never use a wet cloth, oil or any other
liquid.
2. Instruction
3. Meter operation
3.1 Meter instruction
3.2 Meter operation
3.3 Operation Cautions
Be careful of the safety use. Don’t attempt to release the connector when charging the
battery.
● Avoid the risk of collision.
● Don’t modify system parameters to avoid parameters disorder.
● Make the display repaired when error code appears.
Operating instructions
To switch on/off
the E-Bike
system, hold the
button for
2s. The default
value is “low”
pedal assist
level.
Press “+” to
crease into
pedal assist
level “Mid”.
Press “+”
again to move
into pedal
assist level
“High”. “High”
is the
maximum
power of PAS.
Full Electric
Function
(Pure electric
mode):
Press”-“, until
all the three
“low””Mid””Hi
gh” indicators
are off.
4. Battery: further information and maintenance
1. How far full charge battery can go? That depends on the loading weight, road condition
and battery capacity. But in the same condition, average speeds can continuous longer
travel range.
2. When storing the battery for a longer time period, (e.g. during winter time) it is important
to place the fully charged battery on a flat surface in a dry place.
3. Attention: The battery should be re-charged once every 2-3 month when it is not used.
4.1.Keep the battery out of reach for children.
4.2.Never try to open the battery.
4.3.If the battery is damaged because it has been dropped somewhere or because of a
biking accident, there might be a risk of electrolytes leakage. Beware of chemical burns!
And immediately stop using a damaged battery.
4.4Do not touch the battery without a cloth or gloves and make sure no acid touches your
eyes.
5. Charging
1.To charge the battery with the bike, simply place the bike within reach of the power supply
and plug it in.
2. The battery only can be charged on the bike.
3.The RED light indicates it is in charging and GREEN light indicates the battery is fully
charged. (Please put off plug from wall) Usually the charging time is 4-6 hours depends on
the battery capacity remain.
4.Warning: Charging time over 10 hours is prohibited please kept it away from high
temperature environment and stores it in a cool place.
6. Installation Instruction
1. When open the bike's carton box, take out E-bike and use tools to cut off the package
strings.
2. Install Kickstand
2.1 Unscrew the screw in the kickstand.
2.2 install the kickstand.
2.3 Then tighten with tool.
3. Install Stem and handle bar
3.1 Insert the stem and tighten the screw.
3.2 Using the wench from tool kit to loosen the four screws and put the bike into the stem in balance and you
can adjust the handlebar in a property angel and position
4. Install front wheel
4.1 Take out the front fork protector from the front fork.
(Please note: Front fork protector is used to prevent the forks from being deformed during transport. it
belongs to the packing material. You can just throw away this accessory!)
4.2 Take out the quick release from Wheel and unscrew the bolt from the quick release
4.3 Set front wheel set into front fork. Make sure fork hanger hold onto wheel axle, and make sure the disc
put into middle of brake.
4.4 Insert the quick release though the axle and tighten bolts
5. Install front light
5.1 Screw front light right on front fork holder as shown
6. Install Pedal
6.1There is a right pedal marked “R” and a left pedal marked “L”.
6.2 The pedal marked “R” has right-hand threads. Tighten it in a clockwise direction.
The pedal marked “L” has left-hand threads. Tighten it in a counterclockwise direction (anti-clockwise).
Turn the right pedal marked “R” into the right side of the crank arm, and the left pedal marked “L” into the
left side of the crank arm.
Make sure the threads of each pedal are fully into the crank arm.
Make sure pedals are fully tightened with wrench.
☛Note
Be sure to identify R/L letters on pedal’s bolt when you installing.
7. Install seat tube
7.1Insert seat post into post receiver, set right its position and adjust height to fit your ridding habit
7.2 Tighten seat by clamp.
8. Adjust angle of brake lever, meter, gear shifter, throttle and louder controller on handle
bar, then tightens them with tools.
9. Install battery
9.1 Open the box of battery
9.2 connect the connectors
9.3 Put the battery in bag and lock tighten the belts
