Refrigerator
use & care
Introduction .......................................................2
Important Safety Information ....................3
Features ..............................................................6
Installation .........................................................7
Door Removal ...................................................9
Door Handle Installation ............................. 13
Water Supply Connection ..........................14
Controls and Settings .................................. 16
Automatic Ice and Water Dispenser ...... 19
Storage Features ........................................... 21
Storing Food and Saving Energy ........... 25
Normal Operating Sounds ........................26
Filter Replacement ...................................... 27
Care and Cleaning .......................................30
Troubleshooting ............................................ 32
Limited Warranty ......................................... 37
A22186602 (October 2022)
INTRODUCTION
Doors
Handles are secure and tight
Door seals completely to cabinet on
all sides
Leveling
Refrigerator is level side-to-side and
slightly elevated in front to assist
with door and drawer closing (front
should be higher than back)
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to
refrigerator (Warning: Potable
water supply only)
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser
operates correctly
Final Checks
Shipping material removed
Fresh food and freezer
temperatures set
Registration card sent in
Installation Checklist
Welcome to our family
Thank you for bringing Frigidaire into
your home! We see your purchase as the
beginning of a long relationship together.
This manual is your resource for the use
and care of your product. Please read
it before using your appliance. Keep it
handy for quick reference. If something
doesn’t seem right, the troubleshooting
section will help you with common issues.
FAQs, helpful tips and videos, cleaning
products, and kitchen and home accessories
are available at Frigidaire.com.
We are here for you! Visit our website,
chat with an agent, or call us if you need
help. We may be able to help you avoid
a service visit. If you do need service, we
can get that started for you.
Let’s make it ocial! Be sure to register
your product.
Keep your product info here so it’s easy
to find.
Model Number
Serial Number
Purchase Date
jfdka; jfdk;a jfdk; jfdk;a j;da
jfdka; jfdk;a jfdk; jfdk;a j;da
Serial Number Location
2
WARNING
WARNING indicates a potentially
hazardous situation which, if not avoided,
could result in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, oper-
ation or maintenance information which
is important but not hazard-related.
DANGER
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in death or serious injury.
CAUTION
CAUTION indicates a potentially
hazardous situation which, if not
avoided, may result in minor or
moderate injury.
Safety Definitions
This is the safety alert symbol. It is
used to alert of potential personal injury
hazards. Obey all safety messages that
follow this symbol to avoid possible injury
or death.
WARNING
CALIFORNIA RESIDENTS ONLY
Cancer and Reproductive Harm
www.P65Warnings.ca.gov
3
IMPORTANT SAFETY INFORMATION
WARNING
Please read all instructions before using
this refrigerator.
DANGER
DANGER Risk of fire or explosion.
Flammable refrigerant used. Do not use
mechanical devices to defrost refrigera-
tor. Do not puncture refrigerant tubing.
DANGER Risk of fire or explosion.
Flammable refrigerant used. To be
repaired only by trained service person-
nel. Use only manufacturer-authorized
service parts. Any repair equipment
used must be designed for flammable
refrigerants. Follow all manufacturer
repair instructions. Do not puncture
refrigerant tubing.
CAUTION
CAUTION Risk of fire or explosion.
Dispose of refrigerator properly
in accordance with the applicable
federal or local regulations. Flammable
refrigerant used.
CAUTION Risk of fire or explosion
due to puncture of refrigerant tubing.
Follow handling instructions carefully.
Flammable refrigerant used.
WARNING
Do not use electrical appliances inside
the food storage compartments of the
appliance unless they are of the type
recommended by the manufacturer.
4
IMPORTANT SAFETY INFORMATION
Safety Instructions
• DO NOT store or use gasoline, or
other flammable liquids in the vicinity
of this or any other appliance. Read
product labels for warnings regard-
ing flammability and other hazards.
• DO NOT operate the refrigerator in
the presence of explosive fumes.
• Avoid contact with any moving parts
of automatic ice maker.
• Remove all staples from the carton.
Staples can cause severe cuts, and
also destroy finishes if they come in
contact with other appliances
or furniture.
IMPORTANT
CFC/HCFC Disposal
Some old refrigerators may have a cool-
ing system that used CFCs or HCFCs
(chlorofluorocarbons or hydrochloro-
fluorocarbons). CFCs and HCFCs are
believed to harm stratospheric ozone if
released to the atmosphere. Other re-
frigerants may also cause harm to the en-
vironment if released to the atmosphere.
If disposing of an old refrigerator, make
sure the refrigerant is removed for proper
disposal by a qualified technician. Inten-
tionally released refrigerant may subject
one to fines and imprisonment under
provisions of environmental legislation.
Before disposing of an old refrigerator/
freezer:
• Remove doors.
• Leave shelves in place so children
may not easily climb inside.
• Have refrigerant removed by a
qualified service technician.
Child Safety
Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the refrigerator is
unpacked. Children should NEVER use
these items to play. Cartons covered with
rugs, bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
can quickly cause suocation.
Proper Disposal of Refrigerator
or Freezer
Risk of child entrapment
Child entrapment and suocation are not
problems of the past. Junked or aban-
doned refrigerators or freezers are still
dangerous – even if they will sit for “just
a few days”. When disposing of an old
refrigerator or freezer, please follow the in-
structions below to help prevent accidents.
Proper Disposal of Refrigerators/Freezers
We strongly encourage responsible appli-
ance recycling/disposal methods. Check
with the utility company or visit energy-
star.gov/recycle for more information on
recycling an old refrigerator.
NOTE
This unit is equipped with a cooling
system where one of the Refrigerator/
Freezer sections may cool slower than
the other initially. Allow 24 hours for
unit to stabilize and reach the desired
temperatures.
5
IMPORTANT SAFETY INFORMATION
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
Electrical information
• The refrigerator must be plugged
into its own dedicated 115 Volt, 60
Hz., 15 Amp, AC only electrical outlet.
The power cord of the appliance
is equipped with a three-prong
grounding plug for protection against
electrical shock hazards. It must
be plugged directly into a properly
grounded three prong receptacle.
The receptacle must be installed in
accordance with local codes and
ordinances. Consult a qualified
electrician. Avoid connecting
refrigerator to a Ground Fault
Interrupter (GFI) circuit. Do not use
an extension cord or adapter plug.
• If the power cord is damaged, it
should be replaced by an authorized
service technician to prevent any risk.
• Never unplug the refrigerator by
pulling on the power cord. Always
grip the plug firmly, and pull straight
out from the receptacle to prevent
damaging the power cord.
• Unplug the refrigerator before
cleaning and before replacing a light
bulb to avoid electrical shock.
• Performance may be aected if
the voltage varies by 10% or more.
Operating the refrigerator with
insucient power can damage the
compressor. Such damage is not
covered under the warranty.
• Do not plug the unit into an electrical
outlet controlled by a wall switch or
pull cord to prevent the refrigerator
from being turned o accidentally.
IMPORTANT
Accessories are available for refrigerator and can be purchased at Frigidaire.com or
by calling 1-800-374-4432.
6
FEATURES
A Anti-tip Leg
B Lower Freezer Basket
C Upper Freezer Drawer
D Ice Bin
E Ice Maker
F Custom-Flex™ Temp Drawer
G Adjustable Hinges
H Door Bin*
I Side Water Dispenser
J Appliance Display Control
K Flipper Mullion
L Flipper Guide
M Air Filter
N Water Filter
O Dairy Compartment*
P Shelf
Q Adjustable Door Bin
R CrispSeal™ Fresh Crispers
S Gallon Door Bins
R
H
K
L
J
I
A
B
C
D
F
G
H
M
O
P
R
N
G
A
H
S
Q
P
P
S
E
H
7
INSTALLATION
Tools Necessary:
Phillips Head
or
Quadrex Head
Screwdriver
(OR)
OR
8mm Socket
Wrench
Adjustable
Wrench
OR
⅜"
Fixed
Wrench
ANDAND
6mm
Allen Wrench
CAUTION
Do Not install the refrigerator where
the temperature will drop below 55°F
(13°C) or rise above 110°F (43°C).
The compressor will not be able to
maintain proper temperatures inside
the refrigerator.
WARNING
Installation
Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides & Top ⅜ in. (9.5 mm)
Back 1 in. (25.4 mm)
This Use & Care Manual provides general
installation and operating instructions for
this model. We recommend using a service
or kitchen contracting professional to
install the refrigerator. Use the refrigerator
only as instructed in this Use & Care
Manual. Before starting the refrigerator,
follow these important first steps.
Location
• Choose a place near a grounded, non-
GFCI, electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from a range,
dishwasher, or other heat sources.
• Install the refrigerator on a floor that
is level and strong enough to support
a fully loaded refrigerator.
• Consider water supply availability for
models equipped with an automatic
ice maker.
Door opening
Position the refrigerator to allow easy
access to a counter when removing food.
For best use of refrigerator drawers and
freezer baskets, position the refrigerator
where both can be fully opened.
NOTE
If you place the refrigerator with the
door hinge side against a wall, allow
additional space so you can open the
door wider.
WARNING
This appliance is intended for use
in residential household and similar
interior applications such as:
• a kitchen/kitchenette
• a pantry room
• a basement
• an enclosed garage
• other interior residential-type
environments
12.25 in
8.75 in
1 in
1 in
56.75 in
25.4 mm
.37 in
9.5 mm
.37 in
9.5 mm
8
INSTALLATION
Cabinet Leveling & Refrigerator
Door Alignment (if necessary)
Guidelines for final positioning of refrigerator:
• All four corners of the cabinet must
rest firmly on the floor.
• The front should be slightly elevated
to ensure the doors close and
seal properly.
• Doors should align with each other
and be level.
Most of these conditions can be met by raising
or lowering the adjustable anti-tip legs.
To level the cabinet using the anti-tip legs:
1. Slightly open freezer drawer.
2. Lower the anti-tip legs until they are
both touching the floor. Use a pair of
pliers to adjust.
To raise unit: turn leg clockwise
(as shown below).
To lower unit: turn leg counterclockwise.
Raise
Flipper Mullion
Adjust the flipper mullion for proper
connection with the mullion guide by
ensuring the flipper mullion is folded and
perpendicular to the fresh food door. If
the mullion
guide is not
in the correct
position, it
could prevent
the door
from closing
completely.
WRONG
Anti-Tip
Legs
3. Ensure both doors are bind-free with
their seals touching the cabinet on all
4 sides and the cabinet is stable.
Door
Door
Door
Door
To make final door height adjustments:
1. Open the Custom-Flex Temp drawer
to make the lower hinge visible.
2. Insert a 6 mm Allen
TM
wrench into
the shaft of the lower hinge.
To lower door: turn the adjustment
screw clockwise.
To raise door: turn the adjustment
screw counterclockwise
(as shown below).
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and
cause personal injury, or damage to the
doors or handles.
9
DOOR REMOVAL
Getting through narrow spaces
If the refrigerator will not fit through an
entrance area, you can remove the doors.
Check first by measuring the entrance.
To prepare for removing the doors:
1. Make sure the electrical power cord
is unplugged from the wall outlet.
2. Remove any food from the door
shelves and close the doors.
To remove the refrigerator doors:
1. Open doors to 90°.
2. Remove all 5 Phillips
TM
screws from
top hinge cover and lift up.
5. Pull up on the water line gently to
remove it from the door.
3. Trace lightly around the door’s top
hinges with a pencil. This makes
reinstallation easier.
4. Disconnect electrical harness
running from door to hinge cover.
6. Remove three 8 mm bolts from both
top hinges. Lift the doors up o the
lower hinges and carefully set aside.
x2
NOTE
Use care while pulling the water tube
from the door to be sure the tube does
not kink. To prevent damaging the water
line, install the water line in a pro tective
spring after reinstalling the doors.
NOTE
You will pull approximately 4 ft of water
tube from the refrigerator door.
10
DOOR REMOVAL
Lower Hinge Removal
Once both doors are in place, ensure they
are aligned with each other and level
(Reference INSTALLATION for more de-
tails), and replace the top hinge cover.
8. To reinstall the doors, reverse
the procedure.
7. You may need to remove the lower
hinges for clearance purposes. To gain
access to the lower hinge, first extend
the Custom Flex Temp Drawer. Unscrew
the 3 lower hinge screws and slide the
hinge inward.
To remove the Custom-Flex
Temp Drawer
1. Fully open the drawer.
2. Remove the basket from the drawer.
3. Unsnap the 4 cable ties by pressing
clip sides together and pushing
them through the opening.
NOTE
When reinserting the water tube and
replacing the top hinge cover, carefully
ensure the tube does not kink.
IMPORTANT
Make sure the water line tubing goes
through the hole at the top of the
dispenser pocket. There is also a metal
wrap on the tubing to prevent damage
from the hinge rubbing against it. This
needs to be fixed back around the tube
in the proper location upon reinstallation
(just as long as the tube is protected
from the hinge).
11
4. Remove the screw and the retaining
clip and disconnect the harness.
DOOR REMOVAL
Reinstalling the Custom-Flex
Temp Drawer
1. Place the drawer with the brackets
and sliders inside the compartment
and click the sliders into place on
each side.
2. Reconnect the cabinet harness.
3. Replace the retaining clip and secure it
with the screw.
4. Reattach the electrical harness by
positioning the cable clips over the
black markings on the harness and
push the 4 cable clips through the
openings in the rail to secure the
harness in place.
5. Slide the basket into place.
6. Close the drawer.
5. Remove the drawer by pressing
on the liner clips and slide the rail
past the clips on both sides to fully
remove drawer from cabinet.
CAUTION
Drawer is heavy. Use caution when lifting.
12
Removing Freezer Drawer
1. Open the drawer and fully extend it.
2. Remove the freezer drawer.
3. Remove the freezer basket.
4. Inside the cabinet, press the 2 tabs
on both sides to release the sliders.
5. Remove the drawer with brackets
and sliders.
Reinstalling Freezer Drawer
1. Place the drawer with brackets and
sliders inside the cabinet and click it
into place.
2. Replace the lower freezer basket
first, and then the upper freezer
basket. Ensure the upper freezer
basket rollers are seated correctly
into the tracks before closing the
freezer drawer.
NOTE
For additional instructions, see
STORAGE FEATURES.
DOOR REMOVAL
1
2
3
4
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
13
NOTE
Tighten all set screws so the screw is below the surface of the handle. Draw the
handles tight to the doors/drawer with no gaps. Open the opposite door while
tightening the Allen screw to make installation easier.
The door handle may loosen over time if you installed it improperly. If this happens,
tighten the set screws on the handles.
Door Handle Mounting Instructions
Mounting Refrigerator Handles
DOOR HANDLE INSTALLATION
NOTE
When tightening the Allen set screws, you must apply force to the longer arm of
the Allen wrench supplied in the handle packaging.
1. Remove the handles from the carton
and any other protective packaging.
2. Position the fresh food handle
end caps over the upper and
lower pre-installed shoulder bolts
(A) fastened into door, ensuring
the holes for the set screws are
facing toward the opposite door.
3. While holding the handle firmly
against door, fasten the upper
and lower Allen set screws (B)
with the supplied Allen wrench.
4. Repeat steps 2 and 3 to install
the opposite handle. Ensure
the holes for the set screws are
facing toward the first door.
CAUTION
To Avoid Property Damage:
• We recommend copper or stainless
Steel braided tubing for the water
supply line. We do not recommend
using water supply tubing made of
¼ inch plastic. Plastic tubing greatly
increases the potential for water
leaks, and the manufacturer will not
be responsible for any damage if you
use plastic tubing for the supply line.
• DO NOT install water supply tubing
in areas where temperatures fall
below freezing.
• Chemicals from a malfunctioning
water softener can damage the ice
maker. If a water softening system
is present, ensure the softener is
maintained and working properly.
14
WATER SUPPLY CONNECTION
IMPORTANT
Ensure the water supply line connections
comply with all local plumbing codes.
To install the water supply line, you will
need the following:
• Basic Tools: adjustable wrench,
flat-blade screwdriver, and Phillips
TM
screwdriver
• Access to a household cold water
line with water pressure between 30
and 100psi.
• A water supply line made of ¼"
(6.4mm) OD, copper or braided
stainless steel tubing. To determine
the length of tubing needed,
measure the distance from the main
water inlet valve at the back of the
refrigerator to the cold water pipe.
Then add approximately 6 feet (1.8
meters), so the refrigerator can be
moved out for cleaning.
• A shuto valve to connect the water
supply line to the household water
system. DO NOT use a self-piercing
type shuto valve.
• Do not reuse compression fitting or
use thread seal tape.
• A compression nut and ferrule
(sleeve) for connecting a copper
water supply line to the main water
inlet valve.
IMPORTANT
The refrigerator’s water supply system
includes several tubing lines, a water fil-
ter, and a water valve. To ensure the wa-
ter dispenser works properly, you must
completely fill this system with water
when the refrigerator is first connected
to the household water supply line.
WARNING
To avoid electric shock, which can
cause death or severe personal injury,
disconnect the refrigerator from
electrical power before connecting a
water supply line to the refrigerator.
NOTE
Check with local building authority for
recommendations on water lines and
associated materials prior to install-
ing refrigerator. Depending on local/
state building codes, we recommend
for homes with existing valves its Smart
Choice
®
water line kit 5304437642 with
a 6ft. (1.8 meters) braided Stainless
Steel Water Line. Please refer to
Frigidaire.com for more information.
NOTE
Expect the first ice harvest within first
24hours of unit operation. To prevent any
issues concerning ice production, please
ensure that all water lines are primed.
See Priming the water supply system
in the AUTOMATIC ICE AND WATER
DISPENSER section.
15
WATER SUPPLY CONNECTION
To Connect Water Tube to
Household Water Supply
1. Disconnect the
refrigerator
from electrical
power source.
2. Place the end
of water supply
line into a sink
or bucket. Turn
ON the water
supply and
flush the supply
line until the
water is clear.
Turn OFF the
water supply at
the shuto valve.
Place 7/16" wrench
here. Do not turn.
Place 1/2" wrench
here. Turn
clockwise.
6. Replace the connected tubes into the
clips and lock clips back in place to
keep the tubing in the right position.
7. Turn ON water supply at shuto
valve and tighten any connections
that leak.
8. Reconnect the refrigerator to an
electrical power source.
9. Ensure ice maker is turned ON.
10. Purge air from the ice and water
dispenser system by operating the
water dispenser for 3-4 minutes. This
will require dispensing several glasses
of water.
3. Open the locking
clips and grab
the water line
coming from
the refrigerator.
Remove the plastic
cap from water
inlet fitting and
discard the cap.
4. If using
(recommended) stainless steel
braided tubing - the nut and ferrule
are already assembled on the tubing.
Slide the compression nut onto water
inlet fitting and finger tighten.
5. Using ½” and 7/16” wrenches (one
to hold the household water line nut
and the other to hold the water inlet
fitting nut), tighten a half turn with
wrench. DO NOT over tighten.
Water
inlet
fitting
Plastic
tubing
to
water
valve
6 ft. (1.8 Meters) Stainless
Steel water line from
household water supply line
Connection to Household Water Supply
with 1/4" compression
fitting
Plastic
Cap
Remove
plastic cap
from water
inlet fitting
Water Inlet
Brass
Fitting
¼ inch
plastic tube
to water
valve
To
household
water
supply
To
unit
water valve
16
CONTROLS AND SETTINGS
Side Door Dispenser Display Mode Views
Your display is equipped with a sleep and lock mode to prevent accidental changes
to the unit settings during opening and closing of the doors. When both doors are
closed, the display is in sleep mode. When either door is first opened, the display is in
lock mode where all the current settings are visible but dimmed.
Pressing any button on the display awakens the display and a tone sounds. All
settings will then fully light. Touch the display again to change any setting.
If you do not press a button for 10 seconds while any door is open, the display
defaults back to lock mode.
Awake Mode View Lock Mode View Sleep Mode View
17
CONTROLS AND SETTINGS
2
10
9
87
65
4
3
1
3
Temp Settings
Select compartment for tem-
perature change (FREEZER or
REFRIGERATOR). Press either the
+ or - to adjust to desired tem-
perature setting.
Freezer temp - Control tempera-
tures range from -6°F / -21°C to
+6°F / -15°C.
Refrigerator temp - Control
temperatures range from +34°F /
+1°C to +44°F / +7°C.
4
Clear Alerts
Resets any alarms that are active
and illuminated on the display
(Door Open, High Temp,
Power Outage).
NOTE
The recommended settings for a prod-
uct installed in a kitchen is 37°F for the
fresh food compartment and 0°F for
the freezer.
NOTE
This unit is equipped with a cooling
system where one section (Refrigerator/
Freezer) may cool slower than the other
initially. Allow 24 hours for unit to stabi-
lize and reach the desired temperatures.
1
Control Lock
Use to lock the display. Press and
hold
for 3 seconds to enable/
disable. The indicator flashes and
an alert sounds when CONTROL
LOCK is enabled. You cannot
make changes on the display
while the lock is engaged.
2
Exterior light
Your appliance has exterior lights
under the refrigerator doors and the
Custom-Flex Temp drawer. Press
and hold for 5 seconds to enable
the lights. The lights will remain on
until you disable them by pressing
and holding for 2 seconds.
18
CONTROLS AND SETTINGS
Clear Alerts
Door Open
If the freezer or fresh food doors have been
left open for 5 minutes or more, an alarm
will sound and the door ajar indicator will
illuminate on the display. Press Clear Alerts
to reset any system alarms.
High Temp Alarm
High temp will illuminate next to clear alerts
button. Alarm is played every 60 seconds.
Press
Clear Alerts
to acknowledge the alarm
The highest temp value will be displayed
when the alarm is first acknowledged.
Power Outage
In the event of a power failure, the power
fail alert will be illuminated. Press
Clear
Alerts
to acknowledge the alarm. Other
modes may be turned o until the alarm is
Sabbath Mode
The Sabbath Mode is a feature that
disables portions of the refrigerator
and its controls in accordance with
observance of the weekly Sabbath and
religious holidays within the Orthodox
Jewish community.
Sabbath Mode is turned ON and OFF by
simultaneously pressing and holding both
- and Temp F-C for 5 seconds. Other than
the High Temp alarm, no audible sounds
will occur until the user exits the Sabbath
mode. The display shows Sb while in
Sabbath mode.
In the Sabbath Mode, the High Temp
alarm is active for health reasons. For
example, if the door is left ajar the High
Temp alarm is activated. The refrigerator
will function normally once the door
is closed, without any violation of the
Sabbath/Holidays. The High Temp alarm
is permitted when cabinet temperature is
outside the safe zone for 20 minutes. The
alarm silences itself after 10 minutes while
High Temp stays lit until the Sabbath
mode is exited.
For further assistance, guidelines for
proper usage and a complete
list of models with the Sabbath
feature, please visit the web at
star-k.org.
NOTE
While in Sabbath Mode, neither the lights,
dispenser, nor the control panel will work
until you deactivate Sabbath Mode.
The refrigerator stays in Sabbath Mode
after power failure recovery. You must
deactivate it with the buttons on the
appliance control display.
NOTE
Although you have initiated the Sab-
bath Mode, the ice maker will complete
the cycle it had already started. The
ice cube compartment will remain cold
and you can make new ice cubes with
standard trays.
5
Freeze Boost
Prior to grocery shopping,
activate Freeze Boost so newly
purchased food designated for
the freezer will be preserved as
quickly as possible. It automati-
cally deactivates after 12 hours.
6
Temp F•C Press to toggle display
settings between Fahrenheit (°F)
and Celsius (°C).
7
Water Dispenser
Press and hold for 3 seconds
to enable/disable the water
dispenser. When enabled, the
LEDs above Water Dispenser
illuminate.
8
Default Settings
Press and hold for 3 seconds to
reset to default settings.
9
Water Filter
Your appliance is equipped with
an electronically authenticated
water filter. If an error relating to
authentication occurs, press and
hold Water Filter for 3 seconds to
delay the alert.
See FILTER REPLACEMENT for
more information.
10
Air Filters
Status is shown at the right of
button. After replacing the filters,
press and hold for 3 seconds to
reset. Status resets to Good.
acknowledged. While a power failure alert is
displayed on the control panel, the unit will
continue normal operation. The high temp
alarm may also be illuminated until a safe op-
erating range temperature has been reached.
Side Water Dispenser
Your refrigerator is equipped with a side
water dispenser mounted to the inside
face of the left hand refrigerator door.
Water dispenser OFF Water dispenser ON
Your appliance will arrive with the side
water dispenser already activated and
ready to use. To disable the water dis-
penser, press and hold Water Dispenser
for 3 seconds. When the LEDs are lit
above, the water dispensing function is
enabled.
To use the dispenser, place a cup against
the paddle and press to dispense water.
Priming the water supply system
CAUTION
For proper dispenser operation, the
recommended water supply pressure
should fall between 30psi and 100psi.
Excessive pressure may cause the
system to malfunction.
Before dispensing water for the first
time, be sure to prime the water supply
system. If the system is not flushed, the
first glasses of water may have discolored
water or have an odd flavor.
Using the dispenser
after installation
CAUTION
Hold the door with one hand while
dispensing water to keep the door from
moving and possibly dispensing water
on floor.
NOTE
If you prefer to keep the side water
dispenser disabled, use the appliance
control display to disable it by press-
ing and holding Water Dispenser for
3 seconds. When the LEDs are not
illuminated above Water Dispenser, the
dispenser will be disabled.
1. Before dispensing, please ensure you
enable Water Dispenser on the display
(LEDs above the button are lit).
2. Begin filling the system by pressing
and holding a drinking glass against
the water dispenser paddle.
3. Keep the glass in this position until
water comes out of the dispenser. It
may take about 1½ minutes.
4. Continue dispensing water for
about 4 minutes to flush the system
and plumbing connections of any
impurities (stopping to empty the
glass as necessary).
19
AUTOMATIC ICE AND WATER DISPENSER
NOTE
The water dispenser has a built-in de-
vice that shuts o the water flow after
2 minutes of continuous use. To reset
this shuto device, simply release the
dispenser paddle.
NOTE
If your cup doesn’t enable the water dis-
penser paddle due to size, use your finger
to activate the paddle for dispensing.
Ice maker tips
• The following sounds are normal
when the ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• Ice cubes stored too long may
develop an odd flavor. Empty the ice
bin as explained below.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This
could damage the ice bin.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure
it is completely dry.
Cleaning the ice maker
Clean the ice maker and ice bin at
regular intervals, especially prior to
vacation or moving.
1. Turn o the ice maker using
the switch. The indicator will
no longer illuminate.
2. Extend the upper freezer basket,
and then remove the ice bin.
3. Empty and carefully clean the ice
bin with mild detergent. Do not use
harsh or abrasive cleaners. Rinse
with clean water.
4. Allow the ice bin to dry completely
before replacing in the freezer.
5. Replace the ice bin. Turn the ice
maker on.
Remove and empty the ice bin if an
extended power failure (one hour or
longer) causes ice cubes in the ice bin to
melt and refreeze together after power is
restored.
Remove the ice bin and shake to loosen
the cubes or clean as explained above.
Ice Maker Operation & Care
After you have properly installed the re-
frigerator, the ice maker can produce ice
within 24hours. When using the ice mak-
er for the first time, and in order for it to
work properly, you must clear air from the
water tubing and the filter. Furthermore,
you do not flush the system, the first ice
cubes may be discolored or have an odd
flavor. Once the ice maker begins making
ice, allow the bin to fill completely, and
then discard the first FULL bin of ice.
Ice Maker and Storage
Bin Capacity
Both counter depth and standard depth
model ice makers should produce 2 to 2.5
pounds of ice per 24 hours depending on
usage conditions. The counter depth ice
bin will hold about 4.5 pounds of ice, and
the standard depth ice bin will hold about
7 to 7.5 pounds of ice.
Turning the ice maker on and o
Press the power button to turn the ice
maker on (button should illuminate).
NOTE
The ice maker will only produce the ad-
vertised production rate if the product
is set at 0°F.
NOTE
The freezer ice maker fills in the center
of the ice bin. Occasionally move the
ice to the borders to allow the bin to
fill completely.
20
AUTOMATIC ICE AND WATER DISPENSER
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly
if nicked, scratched, or exposed to
sudden temperature change. Allow
the glass shelves to stabilize to room
temperature before cleaning. Do not
wash in dishwasher.
21
STORAGE FEATURES
NOTE
Features may vary according to model.
Shelf positions can easily be adjusted in
the fresh food compartments as needed.
The shelves have mounting brackets that
attach to slotted supports at the rear of
each compartment.
Change the Position of a Shelf
1. Remove all food from the shelf.
2. Lift the front edge up and pull the
shelf out.
3. Replace by inserting the mounting
bracket hooks into the desired
support slots.
4. Lower the shelf and lock it
into position.
Slide-Under Shelf
To adjust slide-under shelf (some models):
1. Push front
half shelf
backward
toward the
rear of the
cabinet until
the rear half
shelf drops
down, and then gently continue
pushing the front half shelf back and
under the rear half shelf.
Drawers
The refrigerator includes a variety of
storage drawers.
CrispSeal Fresh Crisper
Use our crisper to keep your produce fresh
for longer, or flip it around to use as an
open compartment to easily access items
such has beverages, yogurts or snacks.
Flexible Storage with our Reversible Bin
Angle the bin up to reinstall
22
Removing Auto CrispSeal Fresh Drawer
STORAGE FEATURES
Removing Auto Humidity
Control Membrane
Opening SnackZone
Recessed Snack Drawers
4. Remove the humidity membrane from
the housing by lifting up sliding over.
5. Clean humidity membrane with hot
soapy water.
6. Replace membrane in housing and
unit by reversing the steps above.
NOTE
Frigidaire does not recommend replac-
ing the auto-humidity membrane unless
it becomes damaged or ruined. If the
membrane becomes soiled, it can be
washed with soap and water. Ensure
membrane is dry before replacing in unit.
To remove the auto humidity control
membrane for cleaning:
1. Reach to back of humidity
control cover.
2. Place fingers between the humidity
control and the back wall, pull up
on cover.
3. Pull cover toward the front of
cabinet and remove.
Removing Auto Humidity
Control Membrane
To remove the Auto CrispSeal Fresh
drawer for cleaning:
1. Pull the drawer out until it stops.
2. Lift the front slightly and remove
the drawer.
SnackZone Recessed Snack Drawers
These drawers are ideal for storage of deli
meats and cheeses.
To open: slide back the cover to allow
access to the drawers.
NOTE
Remove the crisper insert and the
Produce Keeper Plus filter before
washing the crisper.
IMPORTANT
Do not use the Custom-Flex
TM
Temp Drawer
to store fresh produce as these items may
freeze and cause damage to the fruits and
leafy vegetables stored in the drawer.
23
STORAGE FEATURES
Doors
Storage bins
The doors to the fresh food compartment
use a system of modular storage bins.
All of these bins are removable for easy
cleaning. Bins can be adjusted as needed.
Door bins are ideal for storing jars, bottles, cans,
and large drink containers. They also enable
quick selection of frequently used items.
Adjustable door bins
Some models have adjustable door bins
that can be moved to suit individual needs.
To adjust the collapsible door bin:
1. Make sure bin is securely seated on rail
in door.
2. Grab one side of bin and place other
hand on adjustable side.
3. Pull on side of bin until the bin is
adjusted to desired width.
NOTE
It can be dicult to pull out the collapsible
bin. Some force may be required.
1 2 3 4 5 6
Using Your Custom-Flex Temp
Drawer Controls
1
The drawer automatically defaults to a
locked state to prevent any unwanted
use. To change the drawer’s settings, it
first needs to be unlocked. To unlock,
press and hold the UNLOCK icon for 3
seconds. It will automatically lock after
10 seconds without any interaction.
Custom-Flex Temp Drawer Dividers (may
vary by model
To position
drawer dividers,
slide left or
right. For easier
repositioning,
dividers do not
lock but instead
use the weight
of stored items
to keep the
dividers in place. Dividers may shift when
opening/closing drawer when fewer items
are stored.
CAUTION
Do not store glass bottles in the Custom-
Flex Temp Drawer when the Temperature
setting is in Freezer, Meat/Seafood, or Cold
Drink modes. The glass may break and
shatter, causing physical harm and injury.
Freezer:
2
To change the drawer temperature
when in the freezer temp setting, use
the control panel display on the front
door. Changing the temp on the display
will change both the drawer temp
setting AND the freezer compartment.
Refrigerator:
3
Choosing Meat/Seafood will set drawer
temperature to 28°F (-2°C). A tone will
sound to confirm choice. Use this setting
for short term storage. Any meat to be kept
longer than two days should be frozen.
4
Choosing Cold Drinks will set drawer
temperature to 32°F (0°C). A tone will
sound to confirm choice.
5
Choosing Deli/Snacks will set drawer
temperature to 37°F (3°C). A tone will
sound to confirm choice.
6
Choosing White Wine will set drawer
temperature to 45°F (7°C). A tone will
sound to confirm choice.
24
To remove upper freezer drawer:
1. Open freezer compartment completely.
2. Lift up and out to remove upper
freezer drawer.
3. Reverse the steps to reinstall drawer.
Freezer Drawer
Freezer Features
STORAGE FEATURES
NOTE
If basket is not resting on stabilizer bar retainer
clips, the drawer will not close properly.
Plastic Lower Basket Divider
Dividers
Grab hand hold on lower divider and pull
up slightly to slide to next position. (The
divider cannot be removed.)
IMPORTANT
There are wheels on the bottom of the
drawer. Make sure all wheels are aligned on
their respective tracks for proper function.
If drawer is not aligned properly, it will
cause problems with the door operation.
Adjustable Door Bins
To move door bin side-to-side:
4. Tilt bin up so the back of the bin is o
the door but the hook is still engaged.
5. Slide bin along rail to desired position.
6. Lower bin back into place.
To move door bin up or down:
7. Lift bin up disengaging the hook.
8. Move bin to desired rail location.
9. Push bin hook into rail engaging
the hook.
To remove freezer basket:
1. Open freezer compartment
completely.
2. Lift the
basket up
and remove.
3. Reverse
the steps
to reinstall
freezer
basket.
25
STORING FOOD AND SAVING ENERGY
Ideas for storing foods
Fresh food storage
• Keep the fresh food compartment
between 34°F and 44°F with an
optimum temperature of 37°F.
• Avoid overcrowding the refrigerator
shelves, which reduces air circulation
and causes uneven cooling.
• Avoid placing food in front of air ports.
(See CONTROLS AND SETTINGS for
illustration.)
Fruits and vegetables
• Store fruits and vegetables in crisper
drawers, where trapped moisture
helps preserve food quality for longer
time periods.
• Do not wash items until ready to use.
Remove excess water before placing
inside unit.
• Wrap any items that have strong
odors or high moisture content.
Meat
• Wrap raw meat and poultry separately
and securely to prevent leaks and
contamination of other foods or surfaces.
• Use the Custom-Flex
TM
Temp Drawer
to store meat/poultry for short-term
storage. Any meat to be kept longer
than two days should be frozen.
Frozen food storage
• Keep the freezer compartment at 0°F
(-18°C) or lower.
• A freezer operates most eciently
when it is at least ⅔ full.
Packaging foods for freezing
• To minimize food dehydration and quality
deterioration, use aluminum foil, freezer
wrap, freezer bags, or airtight containers.
Force as much air out of the packages as
possible and seal them tightly. Trapped air
can cause food to dry out, change color,
and develop an o-flavor (freezer burn).
• Wrap fresh meats and poultry with
suitable freezer wrap prior to freezing.
• Do not refreeze meat that has
completely thawed.
Loading the freezer
• Prior to grocery shopping, activate
Freeze Boost
so newly purchased
food designated for the freezer will
be preserved as quickly as possible.
• Activating Freeze Boost also will
help the freezer more eciently
maintain the selected temperature
after placing new purchases with
pre-existing frozen foods.
• Avoid adding too much warm food
to the freezer at one time. This
overloads the freezer, slows the
rate of freezing, and can raise the
temperature of frozen foods.
• Leave a space between packages, so
cold air can circulate freely, allowing
food to freeze as quickly as possible.
Ideas for saving energy
Installation
• Locate the refrigerator in the coolest
part of the room, out of direct
sunlight, and away from heating
ducts or registers.
• Do not place the refrigerator next to
heat-producing appliances such as a
range, oven, or dishwasher. If this is
not possible, a section of cabinetry or
an added layer of insulation between
the two appliances will help the
refrigerator operate more eciently.
• Level the refrigerator so that the
doors close tightly.
Temperature settings
• Refer to CONTROLS AND
SETTINGS for illustration and
recommended settings.
Food storage
• Avoid overcrowding the refrigerator
or blocking cold air vents. Doing so
causes the refrigerator to run longer
and use more energy.
• Cover foods and wipe containers
dry before placing them in the
refrigerator. This cuts down on
moisture build-up inside the unit.
• Organize the refrigerator to reduce
door openings. Remove as many
items as needed at one time and
close the door as soon as possible.
• Do not place a hot container directly
on a cold shelf. Remember, such an
extreme temperature change may
damage the glass.
26
NORMAL OPERATING SOUNDS
Understanding the sounds
coming from the refrigerator
High-eciency refrigerators may
introduce unfamiliar sounds. These
sounds normally indicate the refrigerator
is operating correctly. Some surfaces on
floors, walls, and kitchen cabinets may
make these sounds more noticeable.
The following is a list of major
components in the refrigerator and the
sounds they can cause:
A Evaporators Refrigerant through the
evaporators may create a boiling or
gurgling sound.
B Evaporator fans Sounds of air being
forced through the refrigerator by the
evaporator fans may be heard.
C Defrost heaters During defrost cycles,
water dripping onto the defrost
heaters may cause a hissing or sizzling
sound. After defrosting, a popping
sound may occur.
D Automatic ice maker When ice has
been produced, sounds of ice cubes
falling into the ice bin may be heard.
Ice maker fan, water valve activation,
and refrigerant gas fluid may create
sounds from its operation.
E Electronic control & automatic
defrost control These parts can
produce a snapping or clicking sound
when turning the cooling system on
and o.
F Condenser fan Sounds of air being
forced through the condenser may be
heard.
G Compressor Modern, high-eciency
compressors run much faster than
previous models. The compressor may
have a noticeable hum or pulsating
sound during operation.
H Water valves Make a buzzing sound
each time they open to fill the ice
maker.
I Drain pan (not removable) Sounds
of water dripping into the drain pan
during the defrost cycle may be heard.
J Condenser May create minimal sounds
from forced air.
K Motorized damper May produce a
light humming during operation.
Features vary by model
L Ice dispenser When dispensing ice, a
snapping, clicking, or popping sound
may be heard.
NOTE
Energy ecient foam in the refrigerator
is not a sound insulator.
NOTE
During automatic defrost cycle, a red
glow in the back wall vents of the freez-
er compartment is normal.
K
J
I
B
C
D
F
H
G
A
E
B
B
A
C
27
FILTER REPLACEMENT
Ordering Replacement Air Filters
Order replacement filters online at
Frigidaire.com, by calling 1-800-374- 4432
or through the dealer from which the
refrigerator was purchased. Frigidaire
recommends replacing filters at least once
every 6 months.
Here is the product number to request
when ordering:
PureAir RAF-2 Air Filter
Part #FRGPAAF2
PureAir
RAF-2™Air Filter
(select models)
The air filter is located in the top center of
the fresh food compartment.
Replacing Your Air Filter
To ensure optimal filtering of refrigerator
odors, change the air filter every 6
months (Replace Air Filter on the
appliance control display indicates
replacing the filter after 6 months).
1. Remove the air filter cover by
squeezing the top and bottom of the
cover together and removing from liner.
2. Remove the old filter and discard it.
3. Unpack the new filter and snap it
into the filter cover. The open face
(carbon media) of the filter should be
installed facing outward in the cover.
4. Replace
the air filter
cover by
squeezing
the sides
and
snapping it
back into
place.
5. To reset,
press and hold Reset Air Filter on
the
appliance control display
for 3
seconds. Tone will sounds once it has
been reset.
PurePour Connect™ PWF-2™
Water Filter
The refrigerator is equipped with a water
filtering system. The water filtering
system filters all dispensed drinking water,
as well as the water used to produce ice.
The water filter is located at the top right
side of the fresh food compartment.
Accessing Your Water Filter
Change the water filter every 6 months to
ensure the highest possible water quality.
Replace Water Filter on the display indicates
when to replace the filter after a standard
amount of water (125 gallons/473 liters
for PurePour Connect PWF-2)
has flowed
through the system.
If the refrigerator has not been used
for a period of time (during moving for
example), change
the filter before
reinstalling the
refrigerator.
To Remove: Pull
the cover forward
and the cover will
drop down and
allow access to
the filter. Push on
the end/face of
the filter to remove it from the unit and
discard it.
To Reinstall: Push the cover up toward
the liner, and then push it toward the rear
of the cabinet. The filter cover will snap
back into place.
Ordering Replacement Water Filters
Order replacement filters online at
Frigidaire.com, by calling 1-800-374-
4432 or through the dealer from which
the refrigerator was purchased. We
recommend replacing filters at least once
every 6 months.
Here is the product number to request
when ordering:
PurePour Connect PWF-2
Part #FPPWFU02
NOTE
When ordering replacement filters,
please reorder the same filter type that
is currently in the refrigerator.
28
FILTER REPLACEMENT
Do not use with water that is
microbiologically unsafe or of unknown
quality without adequate disinfection
before or after the system. Use systems
certified for cyst reduction on disinfected
waters that may contain filterable cysts.
Test & certification results:
• Rated Capacity - 125 gal/453 L for
PurePour Connect PWF-2
ice and
water filter
• Rated service flow - .50 gal/min.
• Operating Temp: Min. 33°F, Max. 100°F
• Maximum Rated Pressure - 100 lbs/in
2
• Recommended Minimum Operating
Pressure: 30lbs/in
2
Replacing Your Water Filter:
It is not necessary to turn the water
supply o to change the filter. Be ready
to wipe up any small amounts of water
released during the filter replacement.
1. Turn O the ice maker(s).
2. Pull the water filter cover forward
and the cover will drop down to
allow access to the filter.
3. Remove the filter by pushing on
the end/face of the filter (you
should hear a click as the cartridge
disengages the snap-in connector).
4. Slide the old water filter cartridge
straight out of the housing and
discard it.
5. Unpack the new filter cartridge.
Remove the 2 clear plastic cap
covers on the filter connector. Using
the alignment guide, slide the filter
gently into the filter housing until it
stops against the snap-in connector
at the back of the housing.
6. Push firmly until the cartridge snaps
into place (you should hear a click as
the cartridge engages the
snap-in connector).
Tested and certified by NSF/
ANSI Standards 42, 53, 401
and CSA B483.1 in
PurePour
Connect PWF-2
systems for the
reduction of claims specified
on the performance data sheet.
More about the Advanced
Water Filter
Keep safe, great-tasting water flowing with
a
PurePour Connect PWF-2
water filter. Us-
ing a
PurePour Connect PWF-2
water filter:
• Makes Safer Water Second Nature
PurePour Connect PWF-2
water filters
are certified to reduce contaminants*
and keep great-tasting water flowing
for you and your family.
• Produces Purity You Can Trust
Know for certain your
PurePour
Connect PWF-2
water filter is a
protector. Counterfeits and knockos
put your refrigerator and health at
risk. Frigidaire Genuine Filters are the
smarter, safer choice.
• Every Drop Gives Back
Partnered on sustainability eorts,
the use of a
PurePour Connect PWF-2
water filter saves the cost of bottled
water and cuts back on plastic.
*For the complete list, please see Performance
DataSheet on Frigidaire.com
PurePour Connect PWF-2
Authentication
Your refrigerator contains a water filter
authentication system to protect you
from the harm that can occur when using
counterfeit filters. We recommend you
use only the
PurePour Connect PWF-2
water filter with this appliance. Using any
other filter can cause an error (Er FA) to
appear on the appliance control display.
Errors can occur:
• If an authentic expired filter is removed
and reinserted into the appliance
• If an authentic, but incorrect filter is
installed
• If a non-authentic filter is installed
• If the filter is not installed properly
In the cases above, the appliance control
display may show an error code related to
the filter authentication, and Replace Wa-
ter Filter will appear on the display. You
can still use dispensing functions while
the error displays. You can temporarily
dismiss the error twice by holding Water
Filter for 3 seconds to delay the alert
each time it appears. On the third appear-
ance of the error, the error code perma-
nently displays on the appliance control
until you install a new authentic filter.
29
FILTER REPLACEMENT
7. Press a drinking glass against the
water dispenser while checking for
any leaks at the filter housing. Any
spurts and sputters that occur as
the system purges air out of the
dispenser system are normal.
8. Push the cover up toward the liner.
Then push the filter cover toward
the rear of the cabinet. The filter
cover will snap back into place.
9. After filling one glass of water,
continue flushing the system for about
4 minutes. See Priming the water
supply system for more information
10. Once you have properly installed the
filter, the authentication process may
take up to 30 seconds to complete.
After authentication is complete,
the filter status on the display will
automatically update based on the
condition of the filter
11. Turn on the ice maker(s).
PureAir PK-2 Produce Keeper Plus™
Keep fruits and vegetables fresher longer
with PureAir Produce Keeper Plus. Our
produce keeper absorbs ethylene gas, the
natural gas that causes produce to ripen
quicker. Reduce food waste, save money
and enjoy fresh-tasting produce with a
longer storage life.
Ordering Replacement Filters
Order replacement filters online at
Frigidaire.com, by calling 1-800-374-
4432 or through the dealer from which
the refrigerator was purchased. Frigidaire
recommends replacing filters at least
once every 12 months.
Here is the product number to request
when ordering:
PureAir Produce Keeper Plus
Part # FRPAPK2RF™
=
Installing the PureAir Produce Keeper Plus:
1. Remove the plastic wrapper. Insert
the packet into the holder in the rear
of the Crisper.
2. For optimal results, replace the
refill every 12 months along with
your air filter.
CAUTION
DO NOT OPEN CLOTH POUCH. Keep
out of the reach of children.
DO NOT EAT. If ingested, seek medical
treatment immediately.
WASH HANDS AFTER HANDLING.
DO NOT SUBMERGE IN WATER.
IMPORTANT
When storing or moving refrigerator in freezing temperatures, be sure to completely drain
the water supply system. Failure to do so could result in water leaks when the refrigerator
is put back into service. Contact a service representative to perform this operation.
CAUTION
• Pull the refrigerator straight out to move it. Shifting it from side to side may damage
flooring. Be careful not to move the refrigerator beyond the plumbing connections.
• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces
with wet or damp hands.
NOTE
Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable
fluids, cleaning waxes, concentrated detergents, bleaches, or cleansers containing
petroleum products on plastic parts, interior doors, gaskets, or cabinet liners. Do
not use scouring pads or other abrasive cleaning materials.
NOTE
When setting temperature controls to turn o cooling, power to lights and other electrical
components will continue until the power cord is unplugged from the wall outlet.
30
CARE AND CLEANING
Care & Cleaning Tips
Keeping the refrigerator clean maintains its appearance and prevents odor build-up. Wipe up
any spills immediately and clean the freezer and fresh food compartments at least twice a year.
• Always unplug the electrical power cord from the wall outlet before cleaning.
• Remove adhesive labels by hand. Do not use razor blades or other sharp
instruments which can scratch the appliance surface.
• Do not remove the serial plate. Removal of the serial plate voids the warranty.
• Before moving refrigerator, raise the anti-tip brackets so the rollers will work
correctly. This will prevent the floor from being damaged.
Refer to the guide on the next page for details on caring and cleaning specific areas of refrigerator.
• Never use metallic scouring pads, brushes, abrasive cleaners, or strong alkaline
solutions on any surface.
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Do not wash any removable parts in a dishwasher.
Vacation and moving tips
Occasion Tips
Short
Vacations
• Leave refrigerator operating during vacations of 3 weeks or less.
• Use all perishable items from refrigerator compartment.
• Turn automatic ice maker o and empty ice bucket, even if only away a few days.
Long
Vacations
• Remove all food and ice if leaving for one month or more.
• Turn the cooling system o (see CONTROLS AND SETTINGS for the
location of On/O) and disconnect the power cord.
• Turn the water supply valve to close.
• Clean interior thoroughly.
• Leave both doors open to prevent odors and mold build-up. Block
doors open if necessary.
Moving • Unplug the unit
• Remove all food and ice.
• If using a handcart, load from the side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad cabinet to avoid scratching surface.
31
CARE AND CLEANING
Care & Cleaning Tips
Part What To Use Tips and Precautions
Interior & Door
Liners
• Soap and water
• Baking soda and
water
Use two tablespoons of baking soda in
one quart of warm water. Be sure to wring
excess water out of sponge or cloth
before cleaning around controls, light
bulb or any electrical part.
Door Gaskets • Soap and water Wipe gaskets with a clean soft cloth.
Drawers & Bins • Soap and water Use a soft cloth to clean drawer runners
and tracks.
Glass Shelves • Soap and water
• Glass cleaner
• Mild liquid sprays
Allow glass to warm to room temperature
before immersing in warm water.
Exterior &
Handles
• Soap and water
• Non Abrasive Glass
Cleaner
Do not use commercial household clean-
ers containing ammonia, bleach or alcohol
to clean handles. Use a soft cloth to clean
smooth handles or exterior. DO NOT use a
dry cloth to clean smooth doors.
Exterior &
Handles
(Stainless Steel
Models Only)
• Soap and water
• Stainless Steel
Cleaners such
as Frigidaire
ReadyClean™
Stainless Steel
Cleaner.
Never use CHLORIDE or cleaners with
bleach to clean stainless steel.
Clean stainless steel front and handles
with non-abrasive soapy water and a dish-
cloth. Rinse with clean water and a soft
cloth. Use a non-abrasive stainless steel
cleaner. These cleaners can be purchased
at most home improvement or major de-
partment stores. Always follow manufac-
turer’s instructions. Do not use household
cleaners containing ammonia or bleach.
NOTE: Always clean, wipe and dry with
the grain to prevent scratching. Wash the
rest of the cabinet with warm water and
mild liquid detergent. Rinse well, and wipe
dry with a clean soft cloth. Stainless steel
cleaning supplies can be purchased from
Frigidaire.com
32
TROUBLESHOOTING
1-800-265-8352 (Canada)
Frigidaire.ca
1-800-374-4432 (United States)
Frigidaire.com
Let us help you troubleshoot your concern! This section will help you with common
issues. If you need us, visit our website, chat with an agent, or call us. We may be able
to help you avoid a service visit. If you do need service, we can get that started for you!
Concern Potential Cause Common Solution
Automatic Ice Maker
Ice maker is
not making
any ice.
• Ice maker is turned o.
• Refrigerator is not
connected to water line or
water valve is not open.
• The water supply line
is kinked.
• The water filter is not
seated properly.
• The water filter may
be clogged with
foreign material.
• Ice maker signal arm is
being prevented from
lowering down to check
the ice level in the bin at
the appropriate time.
• Ensure the ice maker switch is ON
and the green light is illuminated.
• Connect the unit to the household
water supply and ensure the
water valve is open.
• Ensure the supply line does not
kink when you push the refrigerator
into place against the wall.
• Remove and reinstall the water
filter. Be sure to seat it fully into
the locked position.
• If water dispenses slowly or not at
all, or if the filter is 6 months old
or older, replace it.
• Remove any item or frozen clump
of cubes that may prevent the
signal arm from lowering down
to check the ice level in the bin.
Additionally, be sure the bin is in
its properly installed position.
33
TROUBLESHOOTING
Concern Potential Cause Common Solution
Automatic Ice Maker (Continued)
Ice maker is
not making
enough ice.
• Ice maker is producing
less ice than expected.
• The water filter may
be clogged with
foreign material.
• The water supply line
is kinked.
• Saddle valve on
cold water pipe is
clogged or restricted
by foreign material.
• Freezer control is
set too warm.
• Water pressure is
extremely low. Cut-o and
cut-on pressures are too
low (well systems only).
• Reverse osmosis system
is in regenerative phase.
• Both counter depth and standard
depth model ice makers should
produce 2 to 2.5 lbs of ice per
24 hours depending on usage
conditions. The counter depth ice
bin will hold about 4.5 lbs of ice,
and the standard depth ice bin
will hold about 7 to 7.5 lbs of ice.
• If water dispenses slower than
normal, or if the filter is 6 months
old or older, replace it.
• Ensure the supply line does not
kink when you push the refrigerator
into place against the wall.
• Turn o household water line
valve. Remove the valve. Ensure
the valve is not a self-piercing
saddle valve. Clean the valve.
Replace the valve if necessary.
• Set the freezer control to a colder
setting to improve performance
of the ice maker. Allow 24 hours
for temperature to stabilize.
• Have someone turn up the cut-o
and cut-on pressure on the water
pump system (well systems only).
• It is normal for a reverse osmosis
system to be below 20 psi during
the regenerative phase.
Ice cubes
are freezing
together.
• Ice cubes are not being
used frequently enough
or interruption of power
for prolonged time.
• Ice cubes are hollow
(shells of ice with water
inside). The hollow cubes
break open in the bin
and leak their water onto
existing ice, which causes
it to freeze together.
• Remove ice container and discard
ice. The ice maker will produce
fresh supply. Ice should be used
at least twice weekly to keep the
cubes separated.
• This generally occurs when the ice
maker does not get enough water.
This is usually the result of a clogged
water filter or restricted water sup-
ply. Replace the water filter and if the
condition still occurs, check to see if
the water valve is not turned on all
the way or if there is a kinked water
supply line.
34
Concern Potential Cause Common Solution
Dispenser
Dispenser will
not dispense
water.
• Water filter not seated
properly.
• Water filter is clogged.
• Household water line
valve is not open.
• Remove and reinstall the water
filter. For
PurePour
, be sure to
push the filter in all the way until
it clicks into place and is secured
inside of the water filter housing.
• Replace filter cartridge. Be sure
to push filter all the way in until
it clicks into place and is secured
inside of the water filter housing.
• Open household water line
valve. See CONCERN column
AUTOMATIC ICE MAKER.
Water not
cold enough.
• As warmer tap water
goes through the filter
and enters the water
supply system, the
chilled water is pushed
through to the dispenser.
Once the chilled water
is used up, it will take
several hours to bring the
freshly replaced water to
a cooler temperature.
• Add ice to cup or container
before dispensing water.
Note: Only the first 26 oz are chilled.
Water has
an odd taste
and/or odor.
• Water has not been
dispensed for an
extended period of time.
• Unit not properly con-
nected to cold water line.
• Draw and discard 10-12 glasses of
water to freshen the supply.
• Connect unit to cold water
line that supplies water to the
kitchen faucet.
Opening/Closing Of Doors/Drawers
Door(s) will
not close.
• Door was closed too
hard, causing other door
to open slightly.
• Refrigerator is not level.
It rocks on the floor
when moved slightly.
• Refrigerator is touching
a wall or cabinet.
• Food/packaging is
obstructing the door
from closing.
• Flipper mullion on left
fresh food door is not in
the correct position.
• Close both doors gently.
• Ensure floor is level and solid,
and can adequately support the
refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
• Ensure floor is level and solid,
and can adequately support the
refrigerator. Contact a carpenter to
correct a sagging or sloping floor.
• Make sure there is no food/
packaging blocking the doorway.
• Ensure the flipper mullion is in the
correct position to allow the door
to close. (See Flipper Mullion
in INSTALLATION.)
TROUBLESHOOTING
35
TROUBLESHOOTING
Concern Potential Cause Common Solution
Opening/Closing Of Doors/Drawers (continued)
Drawers are
dicult to
move.
• Food is touching shelf
on top of drawer.
• Track that drawers slide
on is dirty.
• Remove top layer of items in drawer.
• Ensure drawer is properly
installed on track.
• Clean drawer, rollers, and track.
See CARE AND CLEANING.
Running of Refrigerator
Compressor
does not run.
• Refrigerator is in defrost
cycle.
• Plug at electrical outlet
is disconnected.
• House fuse blown or
tripped circuit breaker.
• Power outage.
• This is normal for a fully automatic
defrost refrigerator. The defrost
cycle occurs periodically, lasting
about 30 minutes.
• Ensure plug is tightly pushed
into outlet.
• Check/replace fuse with a 15 amp
time-delay fuse. Reset circuit breaker.
• Check house lights. Call local
electric company.
Refrigerator
seems to run
too much or
too long.
• The variable speed
compressor is designed
to run 100% of the
time except during the
defrost cycle. At times
it will run faster, such as
after a defrost cycle.
• It is normal for the compressor to
run continuously except during
defrost mode.
One compart-
ment feels
cooler than
the other after
installation.
• This unit is equipped
with a refrigeration
system that changes
between compartments
periodically.
• This is normal behavior right after
installation. Allow 24 hours for
the unit to stabilize and reach the
desired temperatures.
Digital Temperature Setting Display
Digital temper-
ature displays
an error.
• Electronic control
system has detected a
performance problem.
• For assistance with any errors or
codes flashing in the appliance
control display call 1-800-374-4432.
Water Filter
Authentication
Error (ErFA)
• If you remove and reinsert
an authentic expired filter
into the appliance.
• If you install an authentic
but incorrect filter.
• If you install a non-
authentic filter.
• If you do not properly
install the filter.
• The temperature display will
show an error code related to
the filter authentication. You can
temporarily dismiss the error
twice by holding Water Filter
for 3 seconds to delay the alert
each time it appears. On the third
appearance of the error, the error
code permanently displays on the
appliance control display until you
install a new authentic filter.
36
TROUBLESHOOTING
Concern Potential Cause Common Solution
Water/Moisture/Frost Inside Refrigerator
Moisture
collects on
inside of
refrigerator
walls.
• Weather is hot and
humid.
• Flipper mullion
• The rate of frost buildup and
internal sweating increases.
• Adjust flipper mullion. (See Flipper
Mullion in INSTALLATION.)
Water/Moisture/Frost Inside Refrigerator (continued)
Water collects
on bottom
side of drawer
cover.
• Vegetables contain and
give o moisture.
• It is not unusual to have moisture
on the bottom side of the cover.
• Both crispers contain an
automatic humidity control, which
should adjust automatically to
the varying levels of moisture
inside the drawer without creating
additional condensation or drying
out the air inside the crisper
drawer, works with various types
of produce. If excess moisture is
noticed, check to verify humidity
membrane is not damaged and
replace as necessary.
Water collects
in bottom of
drawer.
• Washed vegetables
and fruit drain while
in the drawer.
• Dry items before putting them in
the drawer. Water collecting in
bottom of drawer is normal.
Water/Moisture/Frost Outside Refrigerator
Moisture
collects on
outside of
refrigerator
or between
doors.
• Weather is humid. • This is normal in humid weather.
When humidity is lower, the
moisture should disappear.
Food/Drinks in Fresh Food Compartment/Custom-Flex™ Drawer
Food is
freezing.
• Temperature setting is
too low.
• Temperature sensor is
covered by food (right
side of fresh food area).
• Food is covering the
air ports.
• Move the setting to a higher degree.
• Allow space for air flow to the sensor.
• Allow space between the air ports
and the food.
37
LIMITED WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that
prove to be defective in materials or workmanship when such appliance is installed, used and
maintained in accordance with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily
determined.
2. Product that has been transferred from its original owner to another party or removed
outside the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or
for appliances not in ordinary household use or used other than in accordance with the
provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your
appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim,
cupboards, shelves, etc., which are not a part of the appliance when it is shipped from the
factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other
consumables, or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls,
tolls, ferry trip charges, or mileage expense for service calls to remote areas, including the
state of Alaska.
12. Damages to the finish of appliance or home incurred during installation, including but not
limited to floors, cabinets, walls, etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts
other than genuine Electrolux parts or parts obtained from persons other than authorized
service companies; or external causes such as abuse, misuse, inadequate power supply,
accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE
YEAR. ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH
AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS
WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO
NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR
LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS
MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY
ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the
warranty period should service be required. If service is performed, it is in your best interest
to obtain and keep all receipts. Service under this warranty must be obtained by contacting
Electrolux at the addresses or phone numbers below.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted
by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In
Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person
to change or add to any obligations under this warranty. Obligations for service and parts under
this warranty must be performed by Electrolux or an authorized service company. Product
features or specifications as described or illustrated are subject to change without notice.
USA
1-800-374-4432
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
Frigidaire.com
1-800-374-4432
Frigidaire.ca
1-800-265-8352
owner support
accessories
service
Our home is your home. Visit us if you
need help with any of these things:
registration
(See your registration card
for more information.)
welcome home
