When using electrical appliances, basic safety precautions should always be followed, including the
following: PLEASE READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE UNIT.
WARNING: This product contains chemicals, including lead, known to the State of
California to cause cancer, and birth defects or other reproductive harm. Wash hands after handling.
WARNING: To reduce the risk of fire, electrical shock or injury:
•The intended use is described in this manual. The use of any accessory or attachment or the performance of any operation
with this appliance other than those recommended in this instruction manual may present a risk of personal injury.
•Close supervision is necessary when any appliance is used by or near children. Do not
allow to be used as a toy.
•Keep children
and animals at a safe distance when using this appliance.
• Never pull the power lead to disconnect the plug from the cigarette lighter socket. Keep the lead away from heat, oil and sharp edges.
•Be careful not to pinch the lead in the vehicle’s doors, windows or levers.
•Do not use automotive vac to pick up liquids, toxic substances, flammable or
combustible liquids such as gasoline or use in areas where they may be present.
•Do not operate in the presence of explosives and/or flammable fumes or liquids.
•Do not operate any appliance with a damaged cord or after the appliance malfunctions, is
left outdoors, dropped into water or is damaged in any manner. Return the appliance to any authorized service facility.
•Keep hair, loose clothing, and all parts of body away from openings and moving parts.
•Do not insert accessories when unit is running.
•Do not put any object into unit openings. Do not use with any openings blocked; keep free of dust, lint, hair, and anything
that may reduce air flow.
•Do not operate the unit without a filter in place. Replace a damaged filter promptly.
•Do not vacuum burning or smoking materials, such as lit cigarette butts, matches or hot ashes.
•Do not use on or near hot surfaces.
•When not in use, the appliance should be stored in a dry place. Children should not have access to stored appliances.
•Before use, check the appliance for damaged or defective parts. Check for breakage of parts, damage to switches and any
other conditions that may affect its operation.
•Have any damaged or defective parts repaired or replaced by an authorized repair agent.
•Regularly check the power lead for damage. Replace the lead if it is damaged or defective.
•Never attempt to remove or rep
lace any parts other than those specified in this manual.
•The appliance is designed for use with 12V negative ground vehicle battery systems.
•Toreduceriskofdamagetocigarettelighterconnectorandcord,pullbycigarettelighterconnectorratherthancordwhendisconnectingcharger.
•Makesurecordislocatedsothatitwillnotbesteppedon,trippedover,orotherwisesubjectedtodamageorstress.
•
Do not operate appliance with damaged cord or cigarette lighter connector – replace it immediately.
•Toreduceriskofelectricshock,unplugappliancebeforeattemptinganymaintenanceorcleaning.Turningoffcontrolswillnotreducethisrisk.
•
Do not leave appliance when plugged in. Unplug from outlet when not in use and before servicing.
•
Do not use on wet surfaces. Do not expose to rain. Store indoors.
•
Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull cord around sharp edges or corners. Do not run
appliance over cord. Keep cord away from heated surfaces.
•
Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
•
Turn off all controls before unplugging.
WARNING: Do not operate the appliance with systems which have
positive ground or a different voltage.
•The cigarette lighter socket may not be live when the ignition is off and/or the key is removed. If in doubt, consult your
vehicle’s owner’s manual for information regarding the above.
•Use only as described in this manual. Use only manufacturer’s recommended attachments.
•Do not use the appliance near water. Do not immerse the appliance in water.
WARNING: Risk of Fire. Do not replace any vehicle fuse with a rating higher than
recommended by the vehicle manufacturer. This product is rated to draw 10 amperes from a 12V vehicle outlet. Ensure
that the electrical system in your vehicle can supply this product without causing the vehicle fusing to open. This can
be determined by making sure the fuse in the vehicle which protects the outlet is rated higher than 10 amperes.
Information on the vehicle fuse ratings are typically found in the vehicle operator’s manual. If a vehicle fuse opens
repeatedly, do not keep on replacing it. The cause of the overload must be found. On no account should fuses be
patched up with tin foil or wire as this may cause serious damage elsewhere in the electrical circuit or cause fire.
IMPORTANT SAFETY INSTRUCTIONS
1
2
3
4
5
6
10
11
12
7
8
9
A
2
4
B
C
7
4
D
7
12
11
1
F
7
12
11
10
E
7
11
9
1
G
3
I
SAFETY GUIDELINES - DEFINITIONS
It is important for you to read and understand this manual. The information it contains relates to protecting YOUR
SAFETYandPREVENTINGPROBLEMS.Thesymbolsbelowareusedtohelpyourecognizethisinformation.
DANGER: Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION: Indicates a potentially haz ard ous situation which, if not
avoided, may result in minor or mod er ate injury.
CAUTION: Used without the safety alert symbol indicates potentially
hazardous situation which, if not avoided, may result in property damage.
3
H
Symbols
• Thelabelonyourtoolmayincludethefollowingsymbols.Thesymbolsandtheirdefinitionsareasfollows:
V ................. volts A ................. amperes
Hz ............... hertz W ................ watts
min .............minutes
or AC ...... alternating current
or DC ..direct current no ................ no load speed
...............Class I Construction ................ earthing terminal
(grounded)
................ safety alert symbol
................Class II Construction .../min or rpm..revolutions or reciprocation
(double insulated) per minute
............
Read instruction manual before use
................ Use proper respiratory protection
................Use proper eye protection ..................
Use proper hearing protection
SAVE THESE INSTRUCTIONS
Catalog No. BDH1200PVAV FORM NO. 90625976 rev01
Copyright
©
2015 Black & Decker
June 2015 PRINTED IN CHINA
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER purchase, go to
http://www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
1-800-544-6986 from 8 a.m. to 5 p.m. EST Mon. - Fri. to speak with an agent.
Please have the catalog number available when you call.
To purchase a replacement filter call 1-888-678-7278.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
VEA EL ESPANOL EN LA CONTRAPORTADA. INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y
PÓLIZA DE GARANTÍA. ADVERTENCIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
To register your new product, visit
www.BlackandDecker.com/NewOwner
CATALOG NUMBER
BDH1200PVAV
Instruction manual
13
J
K
PIVOT AUTO VAC
