FRUIT PRESS
Model: YZQ-6L SC-W12L SC-W18L
Technical Support and E-Warranty Certificate
www.vevor.com/support
1
Model: YZQ-6L SC-W12L SC-W18L
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions carefully before operat-
ing. VEVOR reserves a clear interpretation of our user manual. The appearance of the
product shall be subject to the product you received. Please forgive us that we won't inform
you again if there are any technology or software updates on our product.
Have product questions? Need technical support? Please feel free to contact us:
Fruit Press
CustomerService@vevor.com
• Presses fruit quickly into juice
• Stable and powerful
• Easy turns on the spindle
• Improving health and quality of life
2
Important Safeguards
WARNING：
Read and understand all instructions before using this fruit press. The operator must follow
basic precautions to reduce the risk of personal injury and/or damage to the equipment.
WORK AREA
1.Operate in a safe work environment. Keep your work area clean, well-lit and free of distrac-
tions.
2. Always Wear gloves that provide protection based on the work materials or to reduce the
effects of tool vibration.. Keep anyone not wearing the appropriate safety equipment away from
the work area.
3. Store unused fruit press properly in a safe and dry location to prevent rust or damage. Lock
fruit press away and keep out of the reach of children.
4. Always place the fruit press on a level and firm surface.
PERSONAL PRECAUTIONS
Control the fruit press, personal movement and the work environment to avoid personal injury
or damage to fruit press.
1. Do not operate any fruit press when tired or under the influence of drugs, alcohol or medica-
tions.
2. Avoid wearing clothes or jewelry that can become entangled with the moving parts of a tool.
Keep long hair covered or bound.
SPECIFIC SAFETY PRECAUTIONS
1. Use the correct fruit press for the job. This fruit press was designed for a specific function. Do
not modify or alter this fruit press or use it for an unintended purpose.
2.After use, the fruit press must be stored in a safe and dry place.
WARNING!
DO NOT let comfort or familiarity with product (gained from repeated use) replace strict adher-
ence to the fruit press safety rules. If you use this fruit press unsafely or incorrectly, you can
suffer serious personal injury.
2
3
4
5
6
7
8
9
10
11
12
13
14
* Additional parts that may be needed but are not included: additional
wooden blocks and screws to mount feet of base.
Remark
3
Part List
Part6 Part10 Part11 Part12Model#
6pcs 2pcs 45pcs 20pcsYZQ-6L
6pcs 2pcs 55pcs 25pcsSC-W12L
8pcs 2pcs 55pcs 25pcsSC-W18L
Part12
6pcs
6pcs
6pcs
Handle1 1
Trunnion2 1
Nylon washer3 1
Metal Pressing Plate4 1
Wooden Pressing Plate5 1
Wooden Blocks6
See remark
Wooden Plate7 2
Threaded Rod8 1
Juice Bag9 1
Metal Ring10
See remark
Screw11 See remark
Cage Slat12 See remark
Base13 1
Screw,nuts and gaskets14 3
Description
Part No.
QTY
1
4
3. Threaded Rod Assembly (8), then mount to the Base (13).
NOTE the threaded rod is with two small pieces, should assemble first.
4. The base of the press should be screwed to a firm, solid floor or base,
using the holes in the feet. (screw not included)
Attention:
smooth edge
contact the base
5. Put the Juice Bag (9), containing the chopped fruit, into the wooden
barrel, and hanging over the sides. Press down the fruit by hand.
Harderfruits-apples, pear etc., should be cut into small pieces and ideally
crushed using a fruit crusher or shredder before placing in the bag.
13
9
8
5
ASSEMBLY & OPERATION
1. Wooden Barrel Assembly--- Assemble Metal Ring (10) and Cage Slat
(12), make sure all Cage Slats (12) with bevel edge are in one direction,
the opposite end with smooth edge in line in the opposite side.
2. Wooden Pressing Plate (5) and Metal Pressing Plate (4) assembly with
Screws (11).
10
11
12
11
11
5
4
bevel edge
smooth edge
3 2
6
6. Place the Wooden Plate / Semi-Disc (7) on top of the fruit, ensuring
they are central within the barrel, then add the Wooden Blocks (6), (if
there is sufficient room) followed by the Pressing Plate Assembly (4&5)
on top of these so it is crossing lengthwise over the wooden plates.
7. Place the nylon washer (3) on top of the Pressure Plate Assembly as
shown in the illustration. Screw on the trunnion (2) , push the handle intot
he trunnion and rotate the handle (1) down to press the fruit down into
the barrel.
Put chopped fruits inside the bucket
7 6 4&5
1
7
* Attach legs of unit to a flat surface and screwed before presing. This
will prevent the unit from sliding or tilting over.
* Do not reach into the press with your hands while the press is turning.
* Do not alter the handle by making it longer
* Keep the working area clean.
* Clean up any spills immediately to eliminate the risk of slipping/falling.
CLEANING AND MAINTENCE
After use, the complete press must be thoroughly washed in a mild
detergent, rinsed in clean water and dried.
Do not dispose of this product with general household waste at the end of
its life.
Before use, all components must be scrupulously clean and all traces of
old oil removed to avoid the possibility of contamination of the produce
If left unused for prolonged periods, coat all metal components with a
thin film of Vaseline or food oil and store in a clean, dry environment.
Check the press's condition before using again and if mould is apparent,
wash thoroughly, rinse, dry and apply a film of fresh food oil to its metal
components.
FRUIT PRESS PROCEDURE:
Puree the hard and soft fruit,then put it in a nylon bag,finally ,put it in the
pot and press by turning the handle.
8
DISASSEMBLY
SAFETY CONSIFERATIONS
SAVE THESE INSTRUCTIONS
* Disassemble unit by removing handle from the trunnion.
* Unscrew the trunnion from the threaded bar.
* Remove all wooden blocks and pressing plates.
* Barrel can now be lifted from the base.
* Unscrew the feet of the baselipping/falling.
When using this press it is necessary to follow these safety precautions.
IMPORTANT: It may be necessary to crush the fruits, mainly grapes and
apples, prior to pressing. Crushing can be done by running the fruit
through your fruit crusher or shredder, or food mill.
8. Never use an extension bar on the handle. The second pair of blocks
provided may be inserted when space allows, to force the Wooden Plates
as near the base of the press as possible. If the handle reaches the wooden
barrel assembly and pressure still needs to be increased, release the
trunnion and re-fill with more fruit or use wooden blocks between the
wooden plates and pressing plates. (Additional wooden blocks may be
needed and can simply be made by cutting small blocks of wood or
purchased). Place a container beneath the outlet spout in the Base (13)
ready to collect the juice.
