1
CDN41
CDN41
fisher-price.com
Please keep this instruction sheet for future reference,
as it contains important information.
Requires four AA (LR6) and two AAA (LR03) alkaline batteries (batteries not included).
Adult assembly is required.
Tool required: Phillips screwdriver (not included).
Use as a mobile from birth until 5 months.
A mobile is intended for visual stimulation and not to be grasped by a child.
Wipe this toy with a clean, damp cloth. Do not immerse this toy.
2
Assembled Parts
Soother
(2 pieces)
Mobile
3 Toys
Mobile Arm
Base
he
r
So
o
Note: All of the screws used to assemble this toy are attached to
the product. Follow these instructions carefully to fully secure the
screws. Tighten and loosen all screws with a Phillips screwdriver.
Do not over-tighten the screws.
M
obile A
rm
3
Mobile Assembly
2
Hint: You may want to install the batteries in this product before assembling soother. See the
Battery Installation section.
• Fit the top and bottom of the soother together. Tighten the three screws in the soother.
Soother Bottom
Soother Top
Tighten all
3 screws
1
• Slide the string on each toy into each slot in the mobile.
• Pull the strings down to secure in place.
Toy
Mobile
4
Mobile Assembly
3
• Fit the mobile arm into the socket in the top of the base. Push to “snap” in place. This is
a permanent assembly.
• “Snap” the mobile arm into the socket in the soother.
Mobile Arm
Base
Soother
5
Mobile Assembly
4
• Fit the open end of the link toy onto the soother.
6
Consumer Information
CO
N
SU
MER
ASS
I
S
T
A
N
CE
1-800-432-5437 (US & Canada)
1300 135 312 (Australia)
Fisher-Price, Inc., 636 Girard Avenue, East Aurora, NY 14052.
Hearing-impaired consumers: 1-800-382-7470.
Outside the United States:
Canada: Mattel Canada Inc., 6155 Freemont Blvd.,
Mississauga, Ontario L5R 3W2; www.service.mattel.com.
Great Britain: Mattel UK Ltd, Vanwall Business Park,
Maidenhead SL6 4UB. Helpline: 01628 500303.
www.service.mattel.com/uk
Mattel Europa B.V., Gondel 1, 1186 MJ Amstelveen, Nederland.
Australia: Mattel Australia Pty. Ltd., 658 Church Street,
Locked Bag #870, Richmond, Victoria 3121 Australia.
New Zealand: 16-18 William Pickering Drive,
Albany 1331, Auckland.
FCC STATEMENT (UNITED STATES ONLY)
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.This
equipment generates uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications.However, there is no
guarantee that interference will not occur
in a particular installation.If this equipment
does cause harmful interference to radio or
television reception, which can be determined
by turning the equipment off and on, the user
is encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Consult the dealer or an experienced radio/TV
technician for help.
NOTE: Changes or modifications not expressly
approved by the manufacturer responsible for
compliance could void the user’s authority to
operate the equipment.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired operation.
©2014 Mattel. All Rights Reserved.
PRINTED IN CHINA CDN41_1100587196_DOM
CAN ICES-3 (B)/NMB-3 (B)
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that
may cause undesired operation of the device.
L’utilisation de ce dispositif est autorisée
seulement aux conditions suivantes : (1) il ne
doit pas produire de brouillage et (2) il doit
pouvoir tolérer tout brouillage radioélectrique
reçu, même si ce brouillage est susceptible de
compromettre son fonctionnement.
• In the unlikely event that use of the remote
interferes with normal use of other remote
controlled equipment, such as televisions or
stereos, or use of other electronic or battery
powered appliances interfere with operation
of the mobile, do not use both at the
same time.
7
Battery Installation
Soother
• Loosen the screws in the bottom of the soother. Remove the bottom of the soother.
• Insert four AA (LR6) alkaline batteries.
• Replace the bottom of the soother and tighten the screws.
IMPORTANT! Under normal use conditions, the batteries in the soother will require replacement
more often than the batteries in the remote. When sounds or lights become faint or stop, it’s time
for an adult to change the batteries.
Remote
• Loosen the screw in the battery compartment door with a Phillips screwdriver and remove
the door.
• Insert two AAA (LR03) alkaline batteries.
• Replace the battery compartment door and tighten the screw.
• If this product begins to operate erratically, you may need to reset the electronics. Slide the
power/volume switch on the soother off and then back on. Remove the batteries from the
remote and reinstall them.
• Protect the environment by not disposing of this product with household waste
(2002/96/EC). Check your local authority for recycling advice and facilities.
Battery Safety Information
In exceptional circumstances, batteries may leak fluids that can cause a chemical burn injury or
ruin your product. To avoid battery leakage:
• Do not mix old and new batteries or batteries of different types: alkaline, standard (carbon-zinc)
or rechargeable (nickel-cadmium).
• Insert batteries as indicated inside the battery compartment.
• Remove batteries during long periods of non-use. Always remove exhausted batteries from the
product. Dispose of batteries safely. Do not dispose of this product in a fire. The batteries inside
may explode or leak.
• Never short-circuit the battery terminals.
• Use only batteries of the same or equivalent type, as recommended.
• Do not charge non-rechargeable batteries.
• Remove rechargeable batteries from the product before charging.
• If removable, rechargeable batteries are used, they are only to be charged under adult supervision.
1,5V x 4
AA (LR6)
For longer life, use
alkaline batteries.
1,5V x 2
AAA (LR03)
Soother Remote
8
Crib Attachment
IMPORTANT! Always attach all provided fasteners (strings, straps, clamps, etc.) tightly to
a crib or playpen according to the instructions. Do not add additional strings or straps to
attach to a crib. Check frequently.
Crib Rail
Attachment Strap
Attachment Strap
1
A
B
D
C
• Position the toy inside the crib. Make sure the attachment strap is on the outside of the crib
A
.
• Slide the end of the attachment strap down through the slot on the back of the toy
B
.
• Pull the end of the attachment strap up and fasten to the peg on the back of the toy
C
.
Note: This toy should be snug against the crib rail and spindles. Use the strap slot that provides
the tightest fit.
• If you have excess strap, slide the free end of the attachment strap up through the opening near
the top of the attachment strap
D
.
Peg
Peg
Prevent Entanglement Injury
Crib Mobile Use
• Keep out of baby’s reach.
• Remove mobile from crib or playpen when baby begins to push up on
hands and knees.
• This product may not attach to all crib designs. Do not add additional
strings or straps to attach to a crib or playpen.
Stroller Toy Use
• Do not attach link directly to crib or playpen.
WARNING
9
Crib Attachment
Mattress
Mattress
Bottom of
Bottom of
Mobile Base
Mobile Base
At Least
At Least
7 Inches (18 cm)
7 Inches (18 cm)
2
3
• Tie the toy’s strings to a crib spindle.
Note: It is better to tie the strings in a knot than a bow, since a bow may be easily untied.
• Make sure the distance between the bottom of the mobile base and the crib mattress is at least
7 inches (18 cm).
• If the distance is less than 7 inches (18 cm): readjust the attachment strap to lift the toy; or
lower the crib mattress.
10
Projection Mobile with Soothing Sounds
• Slide the power/volume switch to ON with low volume , ON with high volume or OFF .
• Press a sound selection button to turn on:
White noise and mobile motion
Music and mobile motion
Nature sounds and mobile motion
• Press the music button again to change the musical selection.
• Press and hold a sound selection button to turn off the music/sounds and mobile motion.
Hint: Music/sounds play for approximately 30 minutes. The mobile turns off after approximately
12 minutes. Press a sound selection button again to restart.
• Press the light button to turn on projector lights. Press the button again to turn the
lights off.
Hint: The lights time out after approximately 30 minutes. Press the light button again to restart.
• Press the button on the remote to start music/sounds.
Power/Volume Switch
11
Remote Use
• The soother is designed to go into sleep mode after several hours. If the soother does not
respond to the remote:
- slide the power/volume switch on the soother off and back on, or
- press a sound selection button on the soother, or
- replace the batteries in the soother, or
- replace the batteries in the remote to reactivate the remote.
• You may notice a loss of range between the remote and the mobile when using in bright light.
For best performance, avoid using the remote in areas of bright light. Move the mobile, or
reduce the amount of light to improve performance.
• Position the mobile so that the back of the soother points towards the area that the remote will
be used. Make sure there is a clear path between the remote and the soother. Point the end of
the remote toward the back of the soother and press the button.
12
Tabletop Soother
• Pull the mobile link off the soother.
• Slide the switch on the bottom of the soother
A
and pull to remove from the mobile arm
B
.
Stroller Toy
• Pull the mobile link off the soother.
• Fit the open end of the mobile link onto a stroller canopy.
B
A
