SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.
14 INCH
TOWER FAN
T629000 Applicable to all
colour variants
2
This box contains:
Instruction Manual
14 Inch Tower Fan
1. Control Panel
2. Air Inlet (back of unit)
3. Air Outlet
4. Base
5. OFF/ 3 Speed Buttons
6. Timer Control Dial
7. Oscillation Button
Specifications:
Model: T629000 aplicable to all colour variants
Rated Voltage: 220-240V~
Frequency: 50Hz
Power consumption: 30W
Technical Data:
HIGH VOLTAGE ROTATING PARTS
3
2
1
7 4
5 6
3
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• Please ensure that the
appliance is used on a
stable, level, and heat
resistant surface.
• DO NOT immerse
cords, plugs or any
part of the appliance
in water or any other
liquid.
• DO NOT leave the
appliance unattended
while it is operating.
• Close supervision is
necessary when any
appliance is used by or
near children or pets.
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Children shall not play
with the appliance.
• Cleaning and user
maintenance shall not
be made by children
without supervision.
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:
4
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or
before cleaning.
• If the supply cord or
appliance is damaged,
stop using the
appliance immediately
and seek advice from
the manufacturer or
its service agent or
a similarly qualified
person.
• DO NOT let the cord
hang over the edge of a
table or counter or let it
come into contact with
any hot surfaces.
• The use of accessory
attachments is not
recommended
by the appliance
manufacturer, apart
from those supplied
with this product.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• DO NOT use this
product for anything
other than its intended
use.
• This appliance is for
household use only.
• DO NOT carry the
appliance by the power
cord.
• DO NOT use the
appliance outdoors. DO
NOT run the cord under
carpeting. DO NOT
cover the cord with
throw rugs, runners or
the like. To prevent a
trip hazard, arrange the
cord away from traffic
areas.
• DO NOT insert foreign
objects or fingers
into any ventilation
opening as this may
cause an electric shock,
fire, or damage to an
individual or a property.
• To prevent overload
and blown fuses,
ensure that no other
appliance is plugged
into the same outlet
(receptacle) or into
another outlet
(receptacle) wired into
the same circuit.
• We DO NOT
recommend use of an
extension cord as it may
overheat and cause a
risk of fire. However,
if you have to use an
extension cord, the cord
should be No: 14 AWG
minimum size and
rated not less than 1875
watts, and has to be
used only for supplying
power to this fan.
• The fan should be set
up on a stable and level
surface to avoid it being
knocked over.
5
• DO NOT expose the
fan to excessive heat
or humidity as this can
cause damage to the
electrical components.
• The fan should be kept
out of the reach of
children.
• DO NOT use this fan
in the immediate
surroundings of a
bath, a shower or a
swimming pool. Never
locate the fan where it
may fall into the bath
tub or other water
container.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
seek advice from the
Customer Support
Team.
6
Before First Use:
Read all instructions and safety information
carefully before first use. Please retain this
information for future reference.
1. Remove the parts from the packaging.
2. Remove the cable tie and unravel the
power cord.
3. Your appliance is now ready for normal
use.
4. Dispose of the packaging in a responsible
manner.
5. Place the unit on a firm and level surface.
Using Your Appliance:
1. Place the fan in a suitable location.
2. Plug the unit into a mains socket.
3. Choose one of the settings to select
the required fan speed. Press the
corresponding button:
1 = Low
2 = Medium
3 = High
4. The fan will turn on and air will be
emitted.
5. Press the OFF button to turn the unit off.
Oscillation:
Press the oscillation button to activate the
oscillation function, if required. Press the
oscillation button again to stop the oscillation
function.
Timer:
Turn the timer control dial to pre-set a time
for the fan to operate in a range of between 20
and 120 minutes, in 20 minute increments.
Cleaning and care:
• Before cleaning always switch off the
appliance and remove the plug from the
electrical socket.
• Wipe the exterior of the unit with a soft,
damp cloth. A little mild detergent may
be used if required. Remove any soap
film with a damp cloth.
• DO NOT allow any water or other liquid to
enter the motor housing.
• Keep the air vents at the rear of the
main body free from dust or fluff– use a
vacuum cleaner to remove these when
necessary. DO NOT probe any opening to
remove fluff.
• Never use an abrasives, harsh detergents,
chemical cleaners or solvents.
• When not in use, store the fan (preferably
in its original box) in a cool, clean and dry
location out of reach of children.
WARNING:
DO NOT immerse any electrical part of
the appliance in water such as motor units
or plugs.
Please see cleaning section for further
instructions.
Model Identifier(s): T629000
Item Symbol Value Unit
Maximum fan flow rate F 7.4 m
3
/min
Fan Power input P 31.8 W
Service value SV 0.2 (m
3
/min)/W
Standby power consumption PSB 0.0 W
Seasonal electricity consumption Q 10.2 kWh/a
Fan sound power level LWA 54 dB(A)
Maximum air velocity C 1.5 m/sec
Contact Details:
RKW LTD, Sutton House, Berry Hill Industrial Estate,
Berry Hill Road, Stoke-on-Trent, ST4 2NL
7
Wiring safety for UK use only
IMPORTANT
As the colours in the
mains lead of this
appliance may not
correspond with the
coloured markings
identifying the
terminals in your
plug, please proceed as
follows:
The wires in the mains lead are coloured in
accordance with the following code:
Blue neutral [N] Brown live [L]
Plug Fitting Details (Where Applicable).
The wire coloured blue is the neutral and
must be connected to the terminal marked
[N] or coloured black.
The wire coloured brown is the live wire
and must be connected to the terminal
marked [L] or coloured red.
On no account must either the brown or
the blue wire be connected to the [EARTH]
terminal .
Always ensure that the cord grip is fastened
correctly.
The plug must be fitted with a fuse of the
same rating already fitted and conforming
to BS 1362 and be ASTA approved.
If in doubt consult a qualified electrician
who will be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead
and should the fuse need replacing,
you must use an ASTA approved one
(conforming to BS 1362 of the same rating).
If in doubt, consult a qualified electrician
who will be pleased to do this for you.
If you need to remove the plug - disconnect
it from the mains - and then cut it off the
mains lead and immediately dispose of its
safely. Never attempt to reuse the plug or
insert it into a socket outlet as there is a
danger of an electric shock.
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the recycling
of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
WARNING:
This appliance is double insulated. Do not
connect any wire to the earth terminal.
Model Identifier(s): T629000
Item Symbol Value Unit
Maximum fan flow rate F 7.4 m
3
/min
Fan Power input P 31.8 W
Service value SV 0.2 (m
3
/min)/W
Standby power consumption PSB 0.0 W
Seasonal electricity consumption Q 10.2 kWh/a
Fan sound power level LWA 54 dB(A)
Maximum air velocity C 1.5 m/sec
Contact Details:
RKW LTD, Sutton House, Berry Hill Industrial Estate,
Berry Hill Road, Stoke-on-Trent, ST4 2NL
0122.V1
thank you!
We hope you enjoy your appliance for many years.
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to
the place of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in this
instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
Tower has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular
product upon registration of the product within 28 days of purchase. If you do not register the
product with us within the 28 day period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.towerhousewares.co.uk and register with us online.
Please note that length of extended warranty offered is dependent on product type and that each
qualifying product needs to be registered individually in order to extend its warranty past the
standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
+44 (0) 333 220 6066
