Tripp Lite PDUH20HVL6 3.8kW Single-Phase 208/240V Basic PDU, 14 Outlets (12 C13 & 2 C19), NEMA L6-20P Input, 15 ft. (4.57 m) Cord, 1U Rack-Mount

Owner's Manual

For PDUH20HVL6. Also, The document are for others Tripp Lite models: PDUH20DV

PDF File Manual, 16 pages, Read Online | Download pdf file

Owner’s Manual

Rackmount Power Distribution Unit (PDU)

Models: PDUH20DV & PDUH20HVL6

Important Safety Instructions 2

Features 2-3

Installation 3-4

Warranty & Warranty Registration 5

Español 6

Français 11

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

14-02-329-933047.indb 1 4/23/2014 3:39:23 PM

Loading ...

File type: PDF

File name: 91356042_pduh20hvl6.pdf

File size: 1.31 MB

File Language: English, French, Spanish

Pages: 16

Author: Tripp Lite

File created: 2014-04-23

Published: 2023-11-25

Updated: 2023-12-12

Download File

Specifications

Brand: Tripp Lite

Model: PDUH20HVL6

Category: Tools - Home Improvement

PDU Input Voltage: 208; 240

Maximum Input Amps: 16

Maximum Input Amps Details: Agency de-rated to 16A continuous

Frequency Compatibility: 50 / 60 Hz

Output Nominal Voltage: 208/240V

Input Cord Details: Input cable is attached

Input Cord Length (ft.): 15

Output Capacity (kW): 3840

Minimum Required Rack Depth (inches): 6.8

Shipping Dimensions (hwd / in.): 11.00 x 2.25 x 20.25

Shipping Weight (lbs.): 5.90

Unit Dimensions (hwd / in.): 1.750 x 17.250 x 3.750

Unit Weight (lbs.): 3.75

Material of Construction: Metal

Operating Temperature Range: 32° to 104°F (0° to 40°C)

Storage Temperature Range: -22° to 122°F (-30° to 50°C)

Relative Humidity: 5% to 95% non-condensing

Operating Elevation (ft.): 0-10,000

Operating Elevation (m): 0-3000

Product Compliance: RoHS; FCC Part 15 Class A (USA)
