Version: V1.01.000
Revised date: 08-18-2021
LAUNCH X-431 PROS V
1.0
User Manual
i
Copyright Information
Copyright © 2021 by LAUNCH TECH CO., LTD. (also called LAUNCH for short).
All rights reserved. No part of this publication may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying and recording or otherwise, without the prior written
permission.
Statement: LAUNCH owns the complete intellectual property rights for the
software used by this product. For any reverse engineering or cracking actions
against the software, LAUNCH will block the use of this product and reserve the
right to pursue their legal liabilities.
Disclaimer of Warranties and Limitation of Liabilities
All information, illustrations, and specifications in this manual are based on the
latest information available at the time of publication.
The right is reserved to make changes at any time without notice. We shall not
be liable for any direct, special, incidental, indirect damages or any economic
consequential damages (including the loss of profits) due to the use of the
document.
LAUNCH X-431 PROS V
1.0
User Manual
ii
Important Safety Precautions
To avoid personal injury, property damage, or accidental damage to the product,
read all of the information in this section before using the tool.
DANGER
• When an engine is operating, keep the service area well-ventilated or attach
a building exhaust removal system to the engine exhaust system. Engines
produce various poisonous compounds (hydrocarbon, carbon monoxide,
nitrogen oxides, etc.) that cause slower reaction time and result in death or
serious personal injury.
• Please use the included battery and power adaptor. Risk of explosion if the
battery is replaced with an incorrect type.
• DO NOT attempt to operate the tool while driving the vehicle. Have second
personal operate the tool. Any distraction may cause an accident.
WARNING
Always perform automotive testing in a safe environment.
Do not connect or disconnect any test equipment while the ignition is on or
the engine is running.
Before starting the engine, put the gear lever in the Neutral position (for
manual transmission) or in the Park (for automatic transmission) position to
avoid injury.
NEVER smoke or allow a spark or flame in vicinity of battery or engine. Do
not operate the tool in explosive atmospheres, such as in the presence of
flammable liquids, gases, or heavy dust.
Keep a fire extinguisher suitable for gasoline/chemical/electrical fires nearby.
Wear an ANSI-approved eye shield when testing or repairing vehicles.
Put blocks in front of the drive wheels and never leave the vehicle unattended
while testing.
Use extreme caution when working around the ignition coil, distributor cap,
ignition wires and spark plugs. These components create hazardous voltage
when the engine is running.
To avoid damaging the tool or generating false data, please make sure the
vehicle battery is fully charged and the connection to the vehicle DLC (Data
Link Connector) is clear and secure.
LAUNCH X-431 PROS V
1.0
User Manual
iii
Automotive batteries contain sulfuric acid that is harmful to skin. In operation,
direct contact with the automotive batteries should be avoided. Keep the
ignition sources away from the battery at all times.
Keep the tool dry, clean, free from oil, water or grease. Use a mild detergent
on a clean cloth to clear the outside of the equipment when necessary.
Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or
hot engine parts.
Store the tool and accessories in a locked area out of the reach of children.
Do not use the tool while standing in water.
Do not expose the tool or power adapter to rain or wet conditions. Water
entering the tool or power adaptor increases the risk of electric shock.
This tool is a sealed unit. There are no end-user serviceable parts inside. All
internal repairs must be done by an authorized repair facility or qualified
technician. If there is any inquiry, please contact the dealer.
Keep the tool far away from magnetic devices because its radiations can
damage the screen and erase the data stored on the tool.
Do not attempt to replace the internal rechargeable lithium battery. Contact
the dealer for factory replacement.
Do not disconnect battery or any wiring cables in the vehicle when the ignition
switch is on, as this could avoid damage to the sensors or the ECU.
Do not place any magnetic objects near the ECU. Disconnect the power
supply to the ECU before performing any welding operations on the vehicle.
Use extreme caution when performing any operations near the ECU or
sensors. Ground yourself when you disassemble PROM, otherwise ECU and
sensors can be damaged by static electricity.
When reconnecting the ECU harness connector, be sure it is attached firmly,
otherwise electronic elements, such as ICs inside the ECU, can be damaged.
LAUNCH X-431 PROS V
1.0
User Manual
iv
Table of Contents
1 Introduction ......................................................................................... 1
1.1 Product Profile ................................................................................ 1
1.2 Package List .................................................................................. 2
1.3 Components & Controls .................................................................. 3
1.3.1 Display Tablet .................................................................................... 3
1.3.2 VCI Connector (Only applies to 12V cars) ......................................... 5
1.4 Technical Parameters ..................................................................... 5
2 Initial Use ............................................................................................. 7
2.1 Charging ........................................................................................ 7
2.2 Power on/off ................................................................................... 7
2.3 Basic Gestures ............................................................................... 7
2.4 Screen Layout ................................................................................ 8
2.5 Adjust brightness ............................................................................ 8
2.6 Set Standby Time ........................................................................... 8
2.7 Change System Language.............................................................. 9
2.8 Network Setup ................................................................................ 9
3 Getting Started .................................................................................. 10
3.1 Register & Download Diagnostic Software ..................................... 10
3.2 Job menu ..................................................................................... 12
3.3 Diagnostics toolbar ....................................................................... 13
4 Connections ...................................................................................... 15
4.1 Preparation .................................................................................. 15
4.2 Vehicle connection ....................................................................... 15
5 Diagnosis........................................................................................... 18
5.1 Intelligent Diagnosis ..................................................................... 18
5.2 Local Diagnosis ............................................................................ 21
5.2.1 Health Report (Quick Test) .............................................................. 26
5.2.2 System Scan ................................................................................... 28
5.2.3 System Selection ............................................................................ 29
LAUNCH X-431 PROS V
1.0
User Manual
v
5.3 Remote Diagnosis ........................................................................ 38
5.3.1 Add Friends ..................................................................................... 39
5.3.2 Start Instant Messaging ................................................................... 40
5.3.3 Launch Remote Diagnosis (Device-To-Device) ............................... 41
5.3.4 Launch Remote Diagnosis (Device-To-PC) ..................................... 45
5.4 Feedback ..................................................................................... 47
5.5 Diagnostic History ........................................................................ 48
6 Service (Reset) Function ................................................................... 49
6.1 Oil Reset Service .......................................................................... 49
6.2 Electronic Parking Brake Reset ..................................................... 50
6.3 Steering Angle Calibration ............................................................ 50
6.4 ABS Bleeding ............................................................................... 50
6.5 Tire Pressure Monitor System Reset ............................................. 50
6.6 Gear Learning .............................................................................. 50
6.7 IMMO Service .............................................................................. 51
6.8 Injector Coding ............................................................................. 51
6.9 Battery Maintenance System Reset............................................... 51
6.10 Diesel Particulate Filter (DPF) Regeneration................................ 51
6.11 Electronic Throttle Position Reset ................................................ 52
6.12 Gearbox Matching ...................................................................... 52
6.13 AFS (Adaptive Front-lighting System) Reset ................................ 52
6.14 Sunroof Initialization ................................................................... 52
6.15 Suspension Calibration ............................................................... 52
6.16 IMMO Programming ................................................................... 53
7 Software Update ................................................................................ 54
7.1 Update Diagnostic Software & APP ............................................... 54
7.2 Update Frequently Used software ................................................. 55
7.3 Renew Subscription ...................................................................... 55
8 Add-on Modules ................................................................................ 58
8.1 ADAS (Calibration) ....................................................................... 58
8.2 TPMS .......................................................................................... 58
LAUNCH X-431 PROS V
1.0
User Manual
vi
8.3 Videoscope .................................................................................. 58
8.4 BST360 (Battery Tester) ............................................................... 58
8.5 X-PROG 3 (Immobilizer Programmer) ........................................... 58
9 User Info ............................................................................................ 60
9.1 My Report .................................................................................... 60
9.2 VCI .............................................................................................. 60
9.3 VCI Management ......................................................................... 60
9.4 Activate VCI ................................................................................. 60
9.5 Firmware Fix ................................................................................ 61
9.6 My Order ...................................................................................... 61
9.7 Subscription Renewal Card ........................................................... 61
9.8 Profile .......................................................................................... 61
9.9 Change password ........................................................................ 62
9.10 Settings ...................................................................................... 62
9.10.1 Units of Measurement ................................................................... 62
9.10.2 Shop Information ........................................................................... 62
9.10.3 Printer Set ..................................................................................... 63
9.10.4 Orientation .................................................................................... 66
9.10.5 Clear Cache .................................................................................. 66
9.10.6 About ............................................................................................. 66
9.10.7 Diagnostic Software Auto Update .................................................. 66
9.10.8 Device Account Management ........................................................ 66
9.10.9 Login/Logout ................................................................................. 68
9.11 Diagnostic Software Clear ........................................................... 68
10 FAQ .................................................................................................. 69
LAUNCH X-431 PROS V
1.0
User Manual
1
1 Introduction
1.1 Product Profile
X-431 PROS V
1.0
adopts a higher performance-price ratio display tablet, which is
equipped with Android operating system and 8” HD capacitive touch screen. It
inherits from LAUNCH’s advanced diagnosing technology and is characterized
by covering a wide range of vehicles, featuring powerful functions, and providing
precise test result.
Through the simple Bluetooth communication between VCI (Vehicle
Communication Interface) device and the display tablet, it achieves full car
model and full system vehicle trouble diagnosis, which include Reading DTCs,
Clearing DTCs, Reading Data Stream, Actuation Test and Special Functions.
It has the following features:
Intelligent Diagnose: This module allows you to use the VIN information of the
currently identified vehicle to access its data (including vehicle information,
historical diagnostic records) from the cloud server to perform quick test,
eliminating guesswork and step-by-step manual menu selection.
Local Diagnose: Follow the on-screen prompts to start diagnostic session
step by step.
Remote Diagnose: This option aims to help repair shops or technicians
launch instant messaging and remote diagnosis, making the repair job getting
fixed faster.
Service Function: Performs all kinds of common maintenance and reset items
including Oil Reset Service, Electronic Parking Brake Reset, Steering Angle
Calibration, ABS Bleeding, TPMS (Tire Pressure Monitor System) Reset,
Gear Learning, IMMO Service, Injector Coding, Battery Maintenance System,
Diesel Particulate Filter (DPF) Regeneration, Electronic Throttle Position
Reset, Gearbox Matching, AFS (Adaptive Front-lighting System) Reset,
Sunroof Initialization, Suspension Calibration and IMMO Programming.
One-click Update: Lets you update your diagnostic software online.
ADAS calibration: Allows you to perform Advanced Driver Assistance System
(ADAS) calibration operations. This function needs to be activated before
normal use and only works with the specific ADAS calibration tool.
LAUNCH X-431 PROS V
1.0
User Manual
2
TPMS: Configures the tool as a professional Tire Pressure Monitoring
System (TPMS) service tool. It needs to work with the TSGUN device (sold
separately) to perform all kinds of various TPMS functions.
Mall: Enables you to subscribe some extra software or service functions that
are not integrated in the tool online.
Diagnostic History: This function provides a quick access to the tested
vehicles and users can choose to view the test report or resume from the last
operation, without starting from scratch.
Feedback: Enables you to submit the vehicle issue to us for analysis and
troubleshooting.
Vehicle Coverage: Quick dial to view the vehicle models that the tool covers.
Add-on modules (Optional): BST 360 Battery Tester and Videoscope are
available as add-on modules, extending the functions of the tool.
1.2 Package List
Common accessories are same, but for different destinations, the accessories
(such as diagnostic software, testing connectors) may vary. Please consult from
the local agency or check the package list supplied with this tool together.
No.
Item
Descriptions
Q
t.
1 Display tablet Indicates the test result. 1
2
VCI connector
Collects the vehicle data and sends it
to the tablet for analysis.
1
3
OBD II extension
cable
To connect the VCI connector to the
OBD II vehicle’s DLC.
1
4
Password envelope
A piece of paper bearing the product
Serial Number and Activation Code for
product registration.
1
5
Power adaptor
For charging the tablet via AC outlet. 1
6
USB/Charging
cable
Connect the power adaptor to charge
the tablet.
1
LAUNCH X-431 PROS V
1.0
User Manual
3
7
Cigarette lighter
cable
To supply power to the non-16pin
connector from the vehicle’s cigarette
lighter receptacle.
(Optional)
8
Battery clamps
cable
To supply power to the non-16pin
connector from the vehicle’s battery.
(Optional)
9
OBD I adaptor box
For connecting the VCI connector and
non-16pin adaptor cable.
(Optional)
10
Non-16pin adaptor
cable kit
To connect to the vehicle equipped
with non-OBD II management system.
(Optional)
1.3 Components & Controls
There are two main components to the diagnostic system:
Display tablet – the central processor and monitor for the system (See
Chapter 1.3.1).
VCI connector – the device for accessing vehicle data (See Chapter 1.3.2).
1.3.1 Display Tablet
The tablet acts as the central processing system, which is used to receive and
analyze the live vehicle data from the VCI connector and then output the test
result.
LAUNCH X-431 PROS V
1.0
User Manual
4
1
V
OLUME +/
-
K
ey
To adjust the volume.
2
POWER Key
In Off mode, press it for 3 seconds to turn the
handset on.
In On mode:
Press it to activate the LCD if the LCD is off.
Press it to turn off the LCD if the LCD lights up.
Press it for 3 seconds to turn it off.
Press it for 8 seconds to perform forced
shutdown.
3
Microphone
4
Charging/Data I/O
Port
To connect to AC outlet for charging.
To connect to PC for data exchange.
5
LCD Screen
6
Front Camera
7
Speakers
8
Rear
C
amera
LAUNCH X-431 PROS V
1.0
User Manual
5
9
Adjustable
Kickstand
Flip out it to any angle and work comfortable at
your desk, or hang it on automotive part.
1.3.2 VCI Connector (Only applies to 12V cars)
The VCI works as a vehicle communication interface device, which is used to
connect to the vehicle’s DLC (Data Link Connector) socket directly or via OBD II
extension cable to read the vehicle data and then send it to the tablet via
Bluetooth.
1
OBD
-
16
diagnostic
connector
To connect on vehicle’s OBD II DLC socket.
2
Mode indicator
It illuminates red when the VCI connector is
connected to the vehicle’s DLC.
Blue indicates the VCI connector is working
in wireless (BT) communication mode.
1.4 Technical Parameters
Display tablet:
Operating system Android
LAUNCH X-431 PROS V
1.0
User Manual
6
Memory 3GB
Storage 32GB
Screen
8 inch high-definition capacitive touch screen
with a resolution of 1280 x 800 pixels
Camera
Front-facing 2.0MP camera + Rear-facing
5.0MP camera
Working temperature 0℃ ~ 50℃
Storage temperature -20 ~ ℃ 70℃
VCI connector:
Working voltage
9 ~18V
Working temperature
0℃ ~ 50℃
Relative humidity
20% ~ 90%
LAUNCH X-431 PROS V
1.0
User Manual
7
2 Initial Use
2.1 Charging
1. Plug one end of the included charging port of the tool, and the other end to
the power adaptor.
2. Connect the other end to the AC outlet.
If appears on the screen, it indicates it is being charged. If the logo changes
into , it indicates that the battery is fully charged. Unplug the power adaptor
from the tablet.
Caution: Please use the included power adaptor to charge your tool. No
responsibility can be assumed for any damage or loss caused as a result of using power
adaptors other than the one supplied.
Notes:
If the battery remains unused for a long period of time or the battery is completely
discharged, it is normal that the tool will not power on while being charged. Please
charge it for a period of 5 minutes and then turn it on.
While the tablet has low battery, a beep will sound. If it is very low, the tablet will be
switched off automatically.
2.2 Power on/off
Press the POWER button to turn the tool on.
Note: If it is the first time you have used this tool or the tool remains idle for a
long period of time, the tool could fail to turn on. Please charge the tool for a minimum
of 5 minutes and attempt to turn on again.
Press the POWER button for 3 seconds, an option menu will pop up on the
screen. Tap Power off to turn the tool off.
2.3 Basic Gestures
Single-tap: To select an item or launch a program.
LAUNCH X-431 PROS V
1.0
User Manual
8
Double-tap: To zoom in so that the text on a webpage appears
in a column that fits your device’s screen.
Long press: Tap and hold on the current interface or area until a
contextual menu pops up on the screen, and then release it.
Slide: To jump to different pages.
Drag: Tap the application icon and drop it to other location.
Spread apart/p
inch together
: To zoom in manually, place two
fingers on the screen and then spread them apart. To zoom out,
place two fingers apart on the screen and then pinch them
together.
2.4 Screen Layout
There are four on-screen buttons available on the bottom of the screen.
BACK
Tap it to return to the previous screen.
HOME
Tap it to navigate to the Android’s home screen.
Recent Apps
Tap it to view the recently launched applications.
Screenshot
Tap it to capture the current screen.
2.5 Adjust brightness
Note: Reducing the brightness of the screen is helpful to conserve the battery
power.
1. On the home screen, tap Settings -> Display -> Brightness level.
2. Drag the slider to adjust it.
2.6 Set Standby Time
If no activities are made within the defined standby period, the screen will be
locked automatically and the system enters sleep mode to save power.
LAUNCH X-431 PROS V
1.0
User Manual
9
1. On the home screen, tap Settings -> Display -> Advanced -> Sleep.
2. Choose the desired sleep time.
2.7 Change System Language
The tool supports multiple system languages. To change the language of the
tool, please do the following:
1. On the home screen, tap Settings -> System -> Language & input ->
Languages.
2. Tap Add a language, and then choose the desired language from the list.
3. Tap and hold the desired language and drag it to the top of the screen and
then release it, the system will change into the target language.
2.8 Network Setup
The tablet has built-in Wi-Fi that can be used to get online. Once you’re online,
you can register your tool, surf the Internet, get apps, send email, launch the
remote diagnosis, and check for software updates etc.
1. On the home screen, tap Settings -> Network & Internet -> WLAN.
2. Slide the Wi-Fi switch to ON, the tablet starts searching for available wireless
networks.
3. Select a wireless network,
If the chosen network is open, the tablet will connect automatically.
If the selected network is encrypted, a network password will need to be
entered.
4. When Connected appears, it indicates the Wi-Fi connection is complete.
Note: When Wi-Fi is not required, this should be disabled to conserve battery
power.
LAUNCH X-431 PROS V
1.0
User Manual
10
3 Getting Started
3.1 Register & Download Diagnostic Software
Follow the steps below to proceed registration and update:
Tap the application icon on the home screen to launch it, and then tap Login to
enter the login interface of diagnosis software.
(If you are a new user, follow A to proceed.)
(If you have registered to be a member, go to B to login the system directly.)
(If you have bound a sub-account to this tool, go to C to login the system.)
(In case you forgot password, refer to D to reset a new password.)
A. If you are a new user, tap New Registration to enter the sign-up page.
LAUNCH X-431 PROS V
1.0
User Manual
11
Fill in the information in each field (Items with * must be filled). After inputting,
tap Register, the following screen will appear:
Input the 12-digit Product Serial Number and 8-digit Activation Code (can be
obtained from the password envelope), and then tap Activate.
Tap Yes to navigate to the update center to update all available software. Tap
No to ignore it. In this case, follow Chapter 7 to check for updates.
After the registration is successfully complete, the wireless communication
between the tablet and the VCI device is automatically established and user has
no need to configure it again.
LAUNCH X-431 PROS V
1.0
User Manual
12
B. If you have registered to be a member, input your name and password, and
then tap Login to enter the main menu screen directly.
Note: The tablet has an auto-save function. Once the username and password are
correctly entered, the system will automatically store it. Next time you login the system,
you will not be asked to input the account manually.
C. If you have created a sub-account or bound an existing account to the tool,
tap Technician login to login. For more details on sub-accounts, refer to
Chapter 9.10.8.
D. If you forgot the password, tap Retrieve password and then follow
on-screen instructions to set a new password.
3.2 Job menu
It mainly includes the following items:
Name
Description
Intelligent
Diagnose
• Obtain vehicle data from the cloud server to perform
quick test via reading VIN, to avoid various defects
resulting from step-by-step menu selection.
• Check the historical repair records online.
Local
Diagno
s
e
To diagnose a vehicle manually.
Service Function
Perform commonly used repair & maintenance
services.
Remote Diagnose
This option aims to help repair shops or technicians
launch instant messaging and remote diagnosis,
making the repair job getting fixed faster.
TPMS
Configure the tool as a professional Tire Pressure
Monitoring System (TPMS) service tool.
Software Update
To update vehicle diagnostic software and APK.
Diagnostic History
• Access the diagnostic reports from the previously
tested vehicles.
• Resume the previous operation without starting from
scratch.
LAUNCH X-431 PROS V
1.0
User Manual
13
Feedback
Feedback the recent 20 diagnostic logs to us for issue
analysis.
ADAS
Perform ADAS (Advanced Driver Assistance System)
calibration operations.
Mall
Subscribe some extra software or service functions that
are not included in the diagnostic tool online.
Vehicle Coverage
Check all the vehicle models that the tool covers.
Info Center
Includes product manual, FAQ, product information and
repair data etc.
User Info
To manage VCI, reports, change password, configure
system settings and logout etc.
Other Modules
Includes some add-on modules (such as Videoscope,
BST360, Immo Programmer) and other system apps.
3.3 Diagnostics toolbar
The diagnostics toolbar contains a number of buttons that allow you to print the
displayed data or make other controls. It is displayed on the upper right corner of
the screen and goes through the whole diagnostic session. The table below
provides a brief description for the operations of the diagnostics toolbar buttons:
Name
Button
Description
Home
Returns to Job menu screen.
LAUNCH X-431 PROS V
1.0
User Manual
14
Print
Tap to print the current screen. Before printing,
you need to configure the wireless printer
following the steps described in Chapter
9.10.3.
Exit
To exit the diagnostic application.
LAUNCH X-431 PROS V
1.0
User Manual
15
4 Connections
4.1 Preparation
The vehicle ignition is turned on.
The vehicle battery voltage range is 11-14 volts.
The throttle is in the closed position.
Find DLC location.
The DLC(Data Link Connector) is usually located 12 inches from the center of the
instrument panel, under or around the driver’s side for most vehicles. For some
vehicles with special designs, the DLC location may vary. Refer to the following
figure for location.
A. Opel, Volkswagen, Audi
B. Honda
C. Volkswagen
D. Opel, Volkswagen, Citroen
E. Changan
F. Hyundai, Daewoo, Kia, Honda, Toyota, Nissan, Mitsubishi, Renault, Opel, BMW,
Mercedes-Benz, Mazda, Volkswagen, Audi, GM, Chrysler, Peugeot, Regal, Beijing
Jeep, Citroen and other most popular models
If the DLC cannot be found, refer to the vehicle’s service manual for the location.
4.2 Vehicle connection
The method used to connect the VCI connector to a vehicle’s DLC depends on
the vehicle’s configuration as follows:
A vehicle equipped with an OBD II management system supplies both
LAUNCH X-431 PROS V
1.0
User Manual
16
communication and 12V power through a standardized DLC.
A vehicle not equipped with an OBD II management system supplies
communication through a DLC connection, and in some cases supplies 12V
power through the cigarette lighter receptacle or a connection to the vehicle
battery.
Follow the steps mentioned below to connect OBD II vehicle:
Use the included OBD II extension cable to connect the VCI connector to the
vehicle’s DLC port (recommended) / Plug the VCI connector into the vehicle’s
DLC port directly.
For non-OBDII vehicle, proceed as follows:
1. Locate vehicle’s DLC socket.
2. Select the corresponding non-16pin connector.
3. Plug the non-16pin end of the connector into the DLC socket, then connect
the other end to the OBD I adaptor, and then tighten the captive screws.
4. Connect the other end of the adaptor to the VCI connector.
Note: If the pin of the DLC is damaged or the DLC has insufficient power, you can
get power via either of the following methods:
A. Cigarette Lighter Cable (optional):
LAUNCH X-431 PROS V
1.0
User Manual
17
B. Battery Clamps Cable (optional):
LAUNCH X-431 PROS V
1.0
User Manual
18
5 Diagnosis
5.1 Intelligent Diagnosis
Through simple Bluetooth communication between the display tablet and VCI,
you can easily get the VIN (Vehicle Identification Number) information of the
currently identified vehicle. Once the VIN is successfully identified, the system
will retrieve it from the remote server and then guide you to vehicle information
page without the necessity of step-by-step manual menu selection.
The vehicle information page lists all historical diagnostic records of the vehicle,
which lets the technician have a total command of the vehicle faults. In addition,
a quick dial to local diagnosis and diagnostic function are also available on this
page for reducing the roundabout time and increasing productivity.
Notes:
• Before using this function, please make sure the VCI is properly connected to the
vehicle’s DLC. For detailed connection, see Chapter 4.2.
• A stable network connection is required for this function.
Follow the steps below to proceed.
1. Tap Intelligent Diagnose on the Job menu to start pairing with the VCI.
2. After pairing is complete, the tablet starts reading the vehicle VIN.
A. If the VIN can be found from the remote server database, the following
screen will appear:
• Tap Diagnostic to start a new diagnostic session.
LAUNCH X-431 PROS V
1.0
User Manual
19
• Tap Scan History to view its historical repair record. If there are records
available, it will be listed on the screen in sequence of date. If no records
exist, the screen will show “No Record”.
• Tap View record to view the details of the current diagnostic report.
• To perform other functions, tap Quick access to directly go to the function
selection screen. Choose the desired one to start a new diagnostic
session.
B. If the tablet failed to access the VIN information, the following screen will
appear:
• Tap the input field to directly, tap OK. If the VIN exists on the remote server,
the system will enter the diagnostic function selection screen.
• Tap to launch the VIN recognition module.
LAUNCH X-431 PROS V
1.0
User Manual
20
Place the VIN inside the viewfinder rectangle to scan it. The most
recognizable location for this number is in the top left corner on the
vehicle’s dashboard. Other locations include the driver’s door or post, and
the firewall under the hood.
• Tap to switch the display mode of the screen.
• Tap to turn the camera flash on.
• Tap to choose it from the record list if the VIN of the vehicle has
been scanned before.
• Tap to input the VIN manually if the tablet has failed to identify the
VIN of the vehicle.
• Tap to scan the VIN barcode. If the VIN barcode cannot be
recognized, please manually input the VIN.
• Tap to scan the VIN character. If the VIN character cannot be
recognized, please manually input the VIN.
Note: In general, vehicle identification numbers are standardized - all
contain 17 characters. VIN characters may be capital letters A through Z and
numbers 1 through 0; however, the letters I, O and Q are never used in order to
avoid mistakes of misreading. No signs or spaces are allowed in the VIN.
After scanning, the screen automatically displays the result.
LAUNCH X-431 PROS V
1.0
User Manual
21
• If the VIN scanned is incorrect, tap the result field to modify it and then tap
OK.
• To scan it again, tap REPEAT.
If the VIN exists on the remote server, the system will enter the diagnostic
function selection screen.
5.2 Local Diagnosis
In this mode, you need to execute the menu-driven command and then follow
the on-screen instruction to proceed.
Tap Local Diagnose to enter the vehicle selection page.
2 approaches are provided for you to access the vehicle diagnostic software.
Choose any one of the following ways:
1. VIN SCAN enables you to access it more quickly.
Tap VIN Scan, the following screen will appear:
In this case, camera scan and enter VIN are available.
LAUNCH X-431 PROS V
1.0
User Manual
22
A. Camera Scan: In this mode, the VCI should be connected to the vehicle’s
DLC first, and then a Bluetooth communication should be established
between the tablet and the VCI.
Tap Camera Scan, the following screen will appear:
Place the VIN inside the viewfinder rectangle to scan it. The most
recognizable location for this number is in the top left corner on the vehicle’s
dashboard. Other locations include the driver’s door or post, and the firewall
under the hood.
• Tap to switch the display mode of the screen.
• Tap to turn the camera flash on.
• Tap to choose it from the record list if the VIN of the vehicle has been
scanned before.
• Tap to input the VIN manually if the tablet has failed to identify the
VIN of the vehicle.
• Tap to scan the VIN barcode. If the VIN barcode cannot be
recognized, please manually input the VIN.
• Tap to scan the VIN character. If the VIN character cannot be
recognized, please manually input the VIN.
After scanning, the following screen will appear.
LAUNCH X-431 PROS V
1.0
User Manual
23
If the VIN scanned is incorrect, tap the result field to modify it and then tap OK.
If the VIN exists on the remote server, the system will navigate to the
diagnostic function selection screen directly.
Tap the desired option to perform the corresponding diagnostic function.
B. INPUT VIN: In this mode, you can input the vehicle VIN manually.
Tap Enter VIN, the following screen will appear.
Input the VIN, and tap OK, the tablet will automatically identify the vehicle
model and directly navigate to the diagnostic function selection menu.
2. Tap a corresponding diagnostic software logo, and then follow the on-screen
instruction to access the diagnostic software.
Take Demo (Version 15.32) as an example to demonstrate how to diagnose a
vehicle.
1). Select diagnostic software version: Tap the DEMO to go to Step 2.
LAUNCH X-431 PROS V
1.0
User Manual
24
On-screen Buttons:
Vehicle Coverage: Tap to view the vehicle models that the current diagnostic
software covers.
What’s new: Tap to view the optimized items and enhancements.
Introduction: Tap to check the software function list.
Note: Tap to read some precautions on using the current diagnostic software.
Search Bluetooth: Tap to search for the available VCI. After the VCI is
successfully activated, it will be bound to the user account and paired with the
tablet automatically.
Note: No Bluetooth connection is required for DEMO program.
OK: Tap it to go to next step.
2). Select vehicle model (varies with different versions): Select the desired
vehicle model. Here we take Ford for example to demonstrate how to
diagnose a vehicle.
LAUNCH X-431 PROS V
1.0
User Manual
25
3). Turn the ignition key to ON: Set the ignition switch to on.
4). Read vehicle information: After reading the vehicle information, double check
if the vehicle information is correct or not. If yes, tap Yes to continue.
5). Select test item: Select the desired test item to proceed.
LAUNCH X-431 PROS V
1.0
User Manual
26
5.2.1 Health Report (Quick Test)
This function varies from vehicle to vehicle. It enables you to quickly access all
the electronic control units of the vehicle and generate a detailed report about
vehicle health.
On the test item selection screen, tap Health Report and turn on the ignition
switch, the system will start scanning the ECUs. Once the scanning process is
complete, the following screen will appear:
The tested system with fault code appears in red and the system functioning
properly displays in black (normally).
Warning: Diagnostic Trouble Codes or Fault Codes can be used to identify which
engine systems or components that are malfunctioning. Never replace a part based only
on the DTC definition. Retrieving and using DTCs for troubleshooting vehicle
operation is only one part of an overall diagnostic strategy. Follow testing procedures
(in vehicle’s service manual), instructions and flowcharts to confirm the locations of the
problem.
On-screen Buttons:
Enter: Tap to enter the diagnostic function selection screen.
(Search): Highlight certain diagnostic trouble code and tap it to retrieve it in
the search engine.
Report: Tap to save the diagnostic result as a health report.
LAUNCH X-431 PROS V
1.0
User Manual
27
Note: Diagnostic report is classified into three categories: Pre-Repair report,
Post-Repair report and Diagnostic Scan. No matter which type you saved the report as,
the report type will be appended as a tag on the upper right corner of the diagnostic
report for easier identification.
Tap to select the report type from the option list and input the required
information, and then tap OK.
Note: To facilitate the comparison of the pre-repair and post-repair reports and get
accurate test result, please make sure you saved the right type of the diagnostic report.
To save the report as a common diagnostic report, select Diagnostic Scan.
Note: For workshop information, tap the input box to enter it. Alternatively you can
also set it in User Info -> Settings -> Shop Information.
Once you configured the information, it will be automatically generated every time you
saved the diagnostic report. All vehicle and workshop information will be appended as
tags on the diagnostic report.
LAUNCH X-431 PROS V
1.0
User Manual
28
To ignore the workshop information, tap Skip to go to the report details screen.
On the report details screen, tap Save to save it. All diagnostic reports are saved
in Report -> Health Report.
Help: Tap to view the help information of the selected DTC item.
Compare Results: Tap to select the pre-repair report to compare. By
comparison of the pre- and post- repair reports, you can easily identify which
DTCs are cleared and which remain unfixed.
• Post indicates DTC status of post-repair.
• Pre indicates DTC status of pre-repair.
Note: Before performing this function, please make sure that:
• You have saved a pre-repair report of the currently tested vehicle, and
• You have already made some repairs and service and cleared the DTCs after the
pre-repair reported is generated. Otherwise, no differences exist between the pre-
and post- repair reports.
Clear DTCs: Tap to clear the existing diagnostic trouble codes.
Note: Clearing DTCs does not fix the problem(s) that caused the code(s) to be set.
If proper repairs to correct the problem that caused the code(s) to be set are not made,
the code(s) will appear again and the check engine light will illuminate as soon as the
problem that cause the DTC to set manifests itself.
5.2.2 System Scan
This option allows you to quickly scan which systems are installed on the
vehicle.
LAUNCH X-431 PROS V
1.0
User Manual
29
On the test item selection screen, tap System Scan, the system start scanning
the systems. Once the scanning process is complete, the following screen will
appear.
Tap the desired system to go to the diagnostic function selection screen. For
detailed operations on diagnostic function, please refer to Chapter 5.2.3.
5.2.3 System Selection
This option allows you to manually select the test system and function step by
step.
On the test item selection screen, tap System Selection, the screen displays as
follows:
Swipe the screen from the bottom to view the vehicle system on the next page.
Tap the target system (take PCM for example) to navigate to the diagnostic
function selection screen.
LAUNCH X-431 PROS V
1.0
User Manual
30
Note: Different vehicle has different diagnostic menus.
A. Version Information
This function is used to read the version information of system mode, vehicle
VIN, software and ECU.
B. Read Fault Code
This function displays the detailed information of DTC records retrieved from the
vehicle’s control system.
Caution: Retrieving and using DTCs for troubleshooting vehicle operation is only
one part of an overall diagnostic strategy. Never replace a part based only on the DTC
definition. Each DTC has a set of testing procedures, instructions and flow charts that
must be followed to confirm the location of the problem. This information can be found
in the vehicle’s service manual.
On the diagnostic function selection screen, tap Read Fault Code, the screen
will display the diagnostic result.
LAUNCH X-431 PROS V
1.0
User Manual
31
On-screen Buttons:
Freeze Frame: When an emission-related fault occurs, certain vehicle
conditions are recorded by the on-board computer. This information is referred
to as freeze frame data. Freeze frame data includes a snapshot of critical
parameter values at the time the DTC is set.
Help: Tap to view the help information.
Code Search: Tap to search for more information about the current DTC online.
Report: Tap to save the current data in text format. All reports are saved in
Report -> Health Reports.
C. Clear Fault Code
This function enables you to erase the codes from the vehicle after reading the
retrieved codes from the vehicle and certain repairs have been carried out.
Before performing this function, make sure the vehicle’s ignition key is in the ON
position with the engine off.
Clearing DTCs does not fix the problem(s) that caused the code(s) to be set. If
proper repairs to correct the problem that caused the code(s) to be set are not
made, the code(s) will appear again and the check engine light will illuminate as
soon as the problem that cause the DTC to set manifests itself.
On the diagnostic function selection screen, tap Clear Fault Code, the following
screen will appear.
Tap YES, the system will automatically delete the currently existing trouble
code.
Note: After clearing, you should retrieve trouble codes once more or turn ignition
LAUNCH X-431 PROS V
1.0
User Manual
32
on and retrieve codes again. If there are still some trouble codes in the system, please
troubleshoot the code using a factory diagnosis guide, then clear the code and recheck.
D. Read Data Stream
This option lets you view and capture (record) real-time Live Data. This data
including current operating status for parameters and/or sensor information can
provide insight on overall vehicle performance. It can also be used to guide
vehicle repair.
Warning: If you must drive the vehicle in order to perform a troubleshooting
procedure, ALWAYS have a second person help you. Trying to drive and operate the
diagnostic tool at the same time is dangerous, and could cause a serious traffic accident.
Note: The real time (Live Data) vehicle operating information (values/status) that
the on-board computer supplies to the tool for each sensor, actuator, switch, etc. is
called Parameter Identification Data (PID).
On the diagnostic function selection screen, tap Read Data Stream, the
following screen will appear.
On-screen Buttons:
Select Page: Tap to select all items of the current page.
Select All: Tap to select all items. To select certain data stream item, just check
the box before the item name.
Unselect: Tap to deselect all data stream items.
OK: Tap to confirm and jump to the next step.
After selecting the desired items, tap OK to enter the data stream reading page.
LAUNCH X-431 PROS V
1.0
User Manual
33
Notes:
1. Tap , the following popup will appear.
Here the user can set different display style for each selected item.
indicates sticky top. If it is tapped, it will change into . On the data stream
display screen, the data stream item with will be shown on the top of the selected
data stream list. To remove it from the top of the list, just tap it again.
B indicates this item will be displayed in Bold.
A indicates this item will be displayed in Red.
2. Tap English or Metric to switch the measurement unit.
3. If the value of the data stream item is out of the range of the standard (reference)
value, the whole line will display in red. If it complies with the reference value, it
displays in blue (normal mode).
4. The indicator 1/X shown on the bottom of the screen stands for the current
page/total page number. Swipe the screen from the right/left to advance/return to the
LAUNCH X-431 PROS V
1.0
User Manual
34
next/previous page.
There are 3 types of display modes available for data viewing, allowing you to
view various types of parameters in the most suitable way.
Value – This is the default mode which displays the parameters in texts and
shows in list format.
Graph – Displays the parameters in waveform graphs.
Combine – This option is mostly used in graph merge status for data
comparison. In this case, different items are marked in different colors.
On-screen Buttons:
Graph(Single): Tap to view the parameter in waveform graph.
• Min/Max: Tap to define the maximum / minimum value. Once the value
goes beyond the specified value, the system will alarm.
Graph: Tap to view the parameters in waveform graphs.
LAUNCH X-431 PROS V
1.0
User Manual
35
• Combine: This option is mostly used in graph merge status for data
comparison. In this case, different items are marked in different colors
(maximum 8 items can be displayed on the same screen simultaneously).
If the graph is more than one page, swipe the screen from the left to jump
to the next page.
• Value: Switches the current graph display mode to the Value display
mode.
• Customize: Tap , a pull-down list of the data stream items appears on
the screen. Select / deselect the desired items, and then screen will
display / remove the waveforms corresponding to these items immediately.
Compare Sample: Tap to select the sample DS file.
All the values you customized and saved in process of DS sampling will be
imported into the Standard Range (See below) column for your comparison.
Note: Before executing this function, you have to sample the values of data stream
LAUNCH X-431 PROS V
1.0
User Manual
36
items and save it as a sample Data Stream file.
Report: Tap to save the current data in text format. All reports are saved in
Report -> Health Reports. For details on report operations, please refer to
Chapter 5.6.
Record: Tap to start recording diagnostic data. Recorded live data can serve as
valuable information to help you in troubleshooting of vehicle problems.
Tap to end recording and save it. The saved file follows the naming rule: It
begins with vehicle type, and then the product S/N and ends with record starting
time (To differentiate between files, please configure the accurate system time).
All diagnostic records can be replayed from Report -> Recorded Data.
Save Sample: This item enables you to customize the standard range of live
data stream items and save it as DS sample file. Each time you run the data
stream items, you can call out the corresponding sample data to overwrite the
current standard range.
LAUNCH X-431 PROS V
1.0
User Manual
37
Tap it to start recording the sample data ( Note: Only data stream items with
measurement units will be recorded), the following screen will appear:
Once the recording process is complete, tap to stop it and navigate to the
data revision screen.
Tap the Min./Max. value to change it. After modifying all desired items, tap Save
to save it as a sample DS file. All DS files are stored in User Info -> Data
Stream Sample.
E. Actuation Test
This option is used to access vehicle-specific subsystem and component tests.
Available test vary by vehicle manufacturer, year, and model.
During the actuation test, the display tablet outputs commands to the ECU in
order to drive the actuators, and then determines the integrity of the system or
parts by reading the ECU data, or by monitoring the operation of the actuators,
such as switching an injector between two operating states.
LAUNCH X-431 PROS V
1.0
User Manual
38
On the diagnostic function selection screen, tap Actuation Test, the following
screen will appear:
Simply follow the on-screen instructions and make appropriate selections to
complete the test.
Each time when an operation is successfully executed, Completed displays.
F. Special Function
In addition to amazing & powerful diagnostic function, the tool also features
various reset functions, which varies from vehicle to vehicle.
5.3 Remote Diagnosis
This option aims to help repair shops or technicians launch instant messaging
and remote diagnosis, making the repair job getting fixed faster.
Tap Remote Diagnosis on the Job menu, the screen appears blank by default.
LAUNCH X-431 PROS V
1.0
User Manual
39
1
Search bar
Directly input the registered username of the tool to start
searching, and then tap the desired one to add it into
your friend list.
2
Messages tab
Once an incoming message reaches, a red dot will
appear on the upper right corner of the tab.
3
Contacts tab Tap to enter the friend list.
4
Remote switch
Tap to slide the switch to ON, the tool keeps online and
becomes accessible on the web client. In this case,
inform the technician of your product S/N, and he/she
will control your device remotely.
5.3.1 Add Friends
Tap Contacts. By default it appears blank.
In the search bar, input the partner’s username and tap Search to start
searching.
The partner must be the users who have registered specific diagnostic tools.
They may be the following:
Workshop
Technician
golo users
Once the result matches the keyword, the following screen will appear:
LAUNCH X-431 PROS V
1.0
User Manual
40
Here you can tap Remote Diagnose to launch remote diagnostics directly or
choose to add the partner into the Contacts list.
Tap the desired name from the list, the following screen will appear:
Tap Add friend to send your request.
Once the partner receives the request, a beep will sound. Tap Messages:
• Once the partner agreed your request, he/she will automatically be listed in
the Contacts tab.
• If a technician sent you a friend request, tap Agree and his/her name will
appear in the Contacts list. Or tap Ignore to ignore this request.
5.3.2 Start Instant Messaging
The I/M (Instant Messaging) function is open to all users who had the diagnostic
tool equipped with this module.
After adding your friends, tap the desired one’s photo to enter the following
screen:
LAUNCH X-431 PROS V
1.0
User Manual
41
Tap the input field and use the on-screen keyboard to send the text message.
Tap
to send the voice message.
Tap
to send the emoj.
Tap
to call out more function options.
File: Choose diagnostic reports or local files to send.
Picture: Choose screenshots or pictures to send.
Remote Diagnose: To start a remote diagnostic session. For details, refer to
Chapter 5.3.4.
Camera: Open camera to take pictures.
5.3.3 Launch Remote Diagnosis (Device-To-Device)
The tool is allowed to initiate remote diagnosis with other diagnostic tools, which
are equipped with this module.
On the function option selection screen, tap Remote Diagnostic, the following
LAUNCH X-431 PROS V
1.0
User Manual
42
pull-down menu will appear:
These options are defined as follows:
Actions
Results
Request control
remote device
Request to control the partner’
s device remotely to
help him diagnose the vehicle.
Notes:
In process of remote diagnosis, tap the button to
send a voice message.
Once vehicle diagnosis is complete, a report will be
created. Input your comments on this report, and then
tap Send Report to send it to the partner.
LAUNCH X-431 PROS V
1.0
User Manual
43
Tap “Request control remote device”
Wait for partner’s confirmation
Start connecting after request confirmed
Start Diagnosis
Generate diagnostic report
Invite remote
diagnostic assistant
Use this option to invite a technician to perform a
remote control on your tool.
Notes:
In process of remote diagnosis, tap the button to
send a voice message.
Once you received the report from the partner, tap
View Report to view details. All diagnostic reports are
saved under Report -> Remote Report.
LAUNCH X-431 PROS V
1.0
User Manual
44
Cancel To cancel this operation.
LAUNCH X-431 PROS V
1.0
User Manual
45
5.3.4 Launch Remote Diagnosis (Device-To-PC)
User also can ask for remote control from a PC client technician.
Tap Remote, the following screen will appear:
LAUNCH X-431 PROS V
1.0
User Manual
46
1. Slide the switch to ON so that the partner can find and connect to this device
while using the PC.
2. Notify the partner of the PC client website http://remote.x431.com. When the
partner accesses the link, the PC displays as below:
Note: Before processing remote diagnosis, please make sure the tool is properly
connected to the vehicle.
3. Tell the partner to input his own official technician account and password, and
then tap Login to navigate to the following figure.
LAUNCH X-431 PROS V
1.0
User Manual
47
4. Tell the partner to enter the Serial Number provided by you, and then tap
Start remote diagnosis to control your device remotely.
In process of remote diagnosis, please note the following things:
1) You are not suggested to execute any actions.
2) The partner is not allowed to save any diagnostic reports or records on
your tablet.
Once the session is complete, a remote diagnostic report will be automatically
generated.
5.4 Feedback
This function enables you to feedback the diagnostic issues to us for analysis
and troubleshooting.
Tap Feedback, and tap OK to enter into the vehicle diagnostic record page.
A. Feedback
Tap the target vehicle to enter the feedback page.
B. History
Tap it to view the diagnostic feedback logs which are marked with different color
LAUNCH X-431 PROS V
1.0
User Manual
48
indicating the process status of the diagnostic feedback.
C. Offline list
Tap it to enter the diagnostic feedback offline list page. Once the tablet gets a
stable network signal, it will be uploaded to the remote server automatically.
5.5 Diagnostic History
This function enables users to directly get access to the previously tested
vehicle’s diagnostic records in details, so users can resume from the last
operation, without starting from scratch.
Tap Diagnostic History on the Job menu screen, all diagnostic records will be
listed on the screen in date sequence.
• Tap certain vehicle model to view the details of the last diagnostic report.
• To delete certain diagnostic history, select it and then tap Delete. To
delete all historical records, tap Select All and then tap Delete.
• Tap Quick Access to directly navigate to the function selection page of
last diagnostic operation. Choose the desired option to proceed.
LAUNCH X-431 PROS V
1.0
User Manual
49
6 Service (Reset) Function
This module provides an easy dial to quickly access the most commonly
performed service functions as follows.
Oil Reset Service
Electronic Parking Brake Reset
Steering Angle Calibration
ABS Bleeding
TPMS (Tire Pressure Monitor System) Reset
Gear Learning
IMMO Service
Injector Coding
Battery Maintenance System (BMS) Reset
Diesel Particulate Filter (DPF) Regeneration
Electronic Throttle Position Reset
Gearbox Matching
AFS (Adaptive Front-lighting System) Reset
Sunroof Initialization
Suspension Calibration
IMMO Programming
6.1 Oil Reset Service
This function enables you to reset the oil service for the engine oil life system,
which calculates an optimal oil life change interval depending on the vehicle
driving conditions and weather events.
It needs to be performed in the following cases:
1. If the service lamp is on, run car diagnostics first for troubleshooting. After
that, reset the driving mileage or driving time, so as to turn off the service
lamp and enable a new driving cycle.
2. If the service lamp is not on, but you have changed the engine oil or electric
appliances that monitor oil life, you need to reset the service lamp.
LAUNCH X-431 PROS V
1.0
User Manual
50
6.2 Electronic Parking Brake Reset
This function enables you to reset the brake pad after replacing the brake pad.
It needs to be performed in the following cases:
1. The brake pad and brake pad wear sensor are replaced.
2. The brake pad indicator lamp is on.
3. The brake pad sensor circuit is short, which is recovered.
4. The servo motor is replaced.
6.3 Steering Angle Calibration
This function enables you to reset the steering angle, after replacing the steering
angle position sensor, replacing steering mechanical parts (such as steering
gearbox, steering column, end tie rod, steering knuckle), performing four-wheel
alignment, or recovering car body.
6.4 ABS Bleeding
This function allows you to perform various bi-directional tests to check the
operating conditions of Anti-lock Braking System (ABS).
It needs to be performed in the following cases:
1. When the ABS contains air.
2. When the ABS computer, ABS pump, brake master cylinder, brake cylinder,
brake line, or brake fluid is replaced.
6.5 Tire Pressure Monitor System Reset
This function enables you to quickly look up the tire sensor IDs from the vehicle’s
ECU, reset tire pressure and turn off the tire pressure MIL.
It needs to be performed in the following cases:
Tire pressure is too low, tire leaks, tire pressure monitoring device is replaced or
installed, tire is replaced, tire pressure sensor is damaged, and tire is replaced
for the car with tire pressure monitoring function.
6.6 Gear Learning
This function enables you to perform tooth learning for the car, to turn off the
MIL.
LAUNCH X-431 PROS V
1.0
User Manual
51
It needs to be performed in the following cases:
1. After the engine ECU, crankshaft position sensor, or crankshaft flywheel is
replaced.
2. The DTC 'tooth not learned' is present.
6.7 IMMO Service
This function enables you to perform the anti-theft key matching function, so that
the immobilizer control system on the car identifies and authorizes remote
control keys to normally use the car.
It needs to be performed in the following cases:
When the ignition switch key, ignition switch, combined instrument panel, ECU,
BCM, or remote control battery is replaced.
6.8 Injector Coding
This function enables you to write injector actual code or rewrite code in the ECU
to the injector code of the corresponding cylinder, so as to more accurately
control or correct cylinder injection quantity.
It needs to be performed in the following cases:
After the ECU or injector is replaced.
6.9 Battery Maintenance System Reset
This function enables you to perform a resetting operation on the monitoring unit
of vehicle battery, in which the original low battery fault information will be
cleared and battery matching will be done.
It needs to be performed in the following cases:
1. The main battery is replaced.
2. The battery monitoring sensor is replaced.
6.10 Diesel Particulate Filter (DPF) Regeneration
This function enables you to clear PM (Particulate Matter) from the DPF filter
through continuous combustion oxidation mode (such as high temperature
heating combustion, fuel additive or catalyst reduce PM ignition combustion) to
stabilize the filter performance.
LAUNCH X-431 PROS V
1.0
User Manual
52
It needs to be performed in the following cases:
1. The exhaust back pressure sensor is replaced.
2. The PM trap is removed or replaced.
3. The fuel additive nozzle is removed or replaced.
4. The catalytic oxidizer is removed or replaced.
5. The DPF regeneration MIL is on and maintenance is performed.
6. The DPF regeneration control module is replaced.
6.11 Electronic Throttle Position Reset
This function enables you to make initial settings to throttle actuators and returns
the learned values stored on ECU to the default state. Doing so can accurately
control the actions of regulating throttle (or idle engine) to adjust the amount of
air intake.
6.12 Gearbox Matching
This function enables you to complete the gearbox self-learning to improve gear
shifting quality.
It needs to be performed in the following cases:
When the gearbox is disassembled or repaired.
6.13 AFS (Adaptive Front-lighting System) Reset
This function enables you to initialize the adaptive headlamp system.
6.14 Sunroof Initialization
This function enables you to set the sunroof lock off, closed when it rains, sliding
/ tilting sunroof memory function, temperature threshold outside the car etc.
6.15 Suspension Calibration
This function enables you to adjust the height of the body.
It needs to be performed in the following cases:
1. When replacing the body height sensor, or control module in the air
suspension system.
2. When the vehicle height is incorrect.
LAUNCH X-431 PROS V
1.0
User Manual
53
6.16 IMMO Programming
This function enables you to perform read-write function for vehicle key,
EEPROM, MCU, and EEPROM/FLASH data of vehicle engine/gearbox ECU. It
needs to work with the specific immobilizer programmer (sold separately).
LAUNCH X-431 PROS V
1.0
User Manual
54
7 Software Update
This module enables you to update the diagnostic software & App and frequently
used software.
7.1 Update Diagnostic Software & APP
Go to Software Update on the Job Menu and tap the Downloaded tab.
The Available tab displays a list of software that can be updated. Under it, all
software is categorized into three kinds:
• Common software: mainly includes some common apps that are associated
with the diagnostic app. The software of this kind always stays at the top of
the list, which can be deselected manually (excluding the system app, such
as firmware and ECU aid).
• Frequently used vehicle software: refers to the diagnostic software that is
frequently used, including the vehicle diagnostic software and Reset software.
It is generally displayed following the Common software list.
• Other vehicle software: refers to the diagnostic software that is rarely used
or never used. It is generally displayed following the Frequently used
software list.
1). If the user does not download any diagnostic software during the sign-up
process, all diagnostic software is selected by default. Tap Update to start
downloading.
2). If the user downloaded all/some vehicle software during the sign-up process
and had it serviced for a long period of time, only the frequently used
software is selected. Tap Update to start downloading. Other vehicle
software that is rarely used will also be listed under the Available tab, but it
is not selected at default.
LAUNCH X-431 PROS V
1.0
User Manual
55
To download certain software that is not frequently used, check the box before
the vehicle model. Tap Update to start downloading.
Once download is finished, the software packages will be installed automatically.
7.2 Update Frequently Used software
If the user only intends to update the frequently used software, go to Software
Update and tap the Downloaded tab.
Tap Update to start downloading. Once download is finished, the software
packages will be installed automatically.
7.3 Renew Subscription
If the software subscription is due or expires, the system will prompt you to
renew your subscription.
Tap Renewals on the bottom of the screen to enter the payment screen.
LAUNCH X-431 PROS V
1.0
User Manual
56
There are three ways available for you to make payment: PayPal, Subscription
Renewal Card (*need to buy it from the local dealer where you purchased the tool)
and Credit Card.
1. Using PayPal
1. Select PayPal, and then follow the on-screen instructions to finish the
transaction.
2. After payment, go to update center to update the diagnostic software.
2. Using Subscription Renewal Card
1. Select Subscription Renewal Card.
2. Input the 24-digit pin code of Subscription Renewal Card and then tap Submit
to finish the renewal.
3. Go to update center to update the diagnostic software.
3. Using Credit Card
LAUNCH X-431 PROS V
1.0
User Manual
57
1. Select Credit Card, and then follow the on-screen instructions to finish the
transaction.
2. After payment, go to update center to update the diagnostic software.
LAUNCH X-431 PROS V
1.0
User Manual
58
8 Add-on Modules
8.1 ADAS (Calibration)
This module enables you to effectively and accurately calibrate a wide range of
camera-based & radar-based driver assistance systems, e.g. the front camera
for the lane departure warning system, the radar sensor for the ACC (Adaptive
Cruise Control) or the camera for adaptive headlights. It needs to work with the
specific ADAS calibration tool (sold separately).
For more details, please refer to the User Manual included with the module.
8.2 TPMS
This module allows you to configure the tablet as TPMS activation & diagnostic
tool, which provides the ability to trigger TPMS sensor, program TPMS sensor,
perform the relearning procedure. It needs to work with the compatible TSGUN
device (sold separately).
For more details, please refer to the User Manual included with the module.
8.3 Videoscope
This module allows you to check those unseen parts of engine, fuel tank,
braking system. It needs to work with the compatible Videoscope device (sold
separately).
For more details, please refer to the User Manual included with the module.
8.4 BST360 (Battery Tester)
This module allows you to fix battery detection faster and easier. It needs to
work with the specific Bluetooth battery tester (sold separately).
For more details, please refer to the User Manual included with the module.
8.5 X-PROG 3 (Immobilizer Programmer)
This module allows you to perform the read-write function for vehicle keys,
EEPROM, MCU, and EEPROM/FLASH of vehicle engine and gearbox ECU. It
LAUNCH X-431 PROS V
1.0
User Manual
59
needs to work with the specific immobilizer programmer (sold separately).
For more details, please refer to the User Manual included with the module.
LAUNCH X-431 PROS V
1.0
User Manual
60
9 User Info
This function allows users to manage personal information and VCI.
9.1 My Report
This option is used to view, delete or share the saved reports.
Tap Report, there are total 3 options available.
In case the DTC result is saved on Read Trouble Code page, the files will be
listed under Health Reports tab.
If user records the running parameters while reading data stream, the tablet will
save the file which appears under Recorded Data tab.
Remote Reports lists all diagnostic reports generated in process of remote
diagnosis.
9.2 VCI
This option allows you to manage all your activated VCI devices.
If several VCI devices are activated on this tool, a list of VCIs will be displayed
on the screen. Once you choose the VCI that belongs to other account, you
have to log out, and then input the right account to continue.
9.3 VCI Management
This option is used for the tablet to deactivate pairing up with the VCI device via
Bluetooth.
9.4 Activate VCI
This item lets you activate the VCI connector in case you ignore the Activate VCI
step in process of the product sign-up.
LAUNCH X-431 PROS V
1.0
User Manual
61
Input the Serial Number and Activation Code, and then tap Activate to activate
the VCI.
9.5 Firmware Fix
Use this item to upgrade and fix diagnostic firmware. During fixing, please do not
cut power or switch to other interfaces.
9.6 My Order
This item allows you to check the status of all your orders.
9.7 Subscription Renewal Card
This item is used to check the status of the subscription renewal card.
Input the 12-digit subscription renewal card number. Tap Search to get the
search result.
9.8 Profile
Use this item to view and configure personal information.
LAUNCH X-431 PROS V
1.0
User Manual
62
• Tap the user image to change it.
• Tap > next to “Free Upgrade Period” to check the due date of all diagnostic
software.
9.9 Change password
This item allows you to modify your login password.
9.10 Settings
It enables you to make some application settings and view software version
information etc.
9.10.1 Units of Measurement
It is designed to configure the measurement unit. Metric System and English
System are available.
9.10.2 Shop Information
This option lets you define your print information. It mainly includes Workshop,
Address, Telephone, Fax and License Plate.
LAUNCH X-431 PROS V
1.0
User Manual
63
After inputting, tap Save.
Once you saved the print information, it will be entered automatically in the
“More Information” box every time you save the diagnostic report.
9.10.3 Printer Set
This option is designed to establish a wireless connection between the tablet
and the Wi-Fi printer (sold separately) while performing printing operations.
The App is compatible with the LAUNCH
®
Wi-Fi Printer (sold separately) and
System (external printer).
For LAUNCH
®
Wi-Fi printer, follow the steps below to connect the printer.
1. Tap Printer Set.
A. If it is the first time you have operated this printer, please proceed the
following:
1. For initial use, you are suggested to reset the printer: Press and hold MODE
& FEED for 8 seconds, the following resetting command will be printed out:
LAUNCH X-431 PROS V
1.0
User Manual
64
at + default = 1
ok
at + reboot = 1
rebooting...
2. Tap Reset to configure Wi-Fi printer.
Step 1: Connect the printer:
Tap Scan to start scanning and select the desired printer hotspot named with
X-431PRINTER-XXXX (XXXX stands for 4 characters), and then tap
Connect to enter Step 2.
Step 2: Join the Wi-Fi printer into LAN:
Tap Scan to select the desired local Wi-Fi network from the list, and type in
the security password (If it is an open network, password is not required), and
then tap Confirm.
3. Once the Wi-Fi network of the printer is connected and the printer is found,
tap Printing test to test the printing.
Now the Wi-Fi printer is ready for printing.
If the printer is not found, please reset the printer to default factory settings (refer
to Step 2 for details) and check whether the current device and the printer are on
the same LAN.
B. If you have configured the Wi-Fi printer to the LAN:
2. Tap Connect to Printer:
a). If the local network remains as it is, tap Test Print directly to test the
printing.
b). If the local network changes, you have to reset the Wi-Fi printer.
For other Wi-Fi printers,
Before printing, make sure the following conditions are met:
• The Wi-Fi printer is powered on and working normally.
• The print service plug-in associated with the printer is already installed on the
tablet (Go to Google Play or use the Browser to download and install it).
Follow the steps below to proceed:
1. Set the default printer as System.
LAUNCH X-431 PROS V
1.0
User Manual
65
2. Go to Other Modules -> Tablet Settings -> WLAN, set the WLAN switch to
Off.
3. On the report details page, tap .
4. Touch next to Select a printer on the upper left corner of the screen.
5. Select All Printers -> Add printer and enable the installed printer service,
the system starts searching for all available Wi-Fi printers of the brand.
LAUNCH X-431 PROS V
1.0
User Manual
66
6. Select the desired Wi-Fi printer from the list. If the chosen Wi-Fi printer
hotspot is open, the tablet can connect it directly. If it is encrypted, a
password may be required. Refer to the Wi-Fi printer user manual to get the
default password.
7. Now the printer is ready for printing.
Alternatively, you can also choose Save as PDF to save the current diagnostic
report as a PDF file for later printing.
9.10.4 Orientation
The option is used to set the screen display orientation.
9.10.5 Clear Cache
This option allows you to clear the App cache. Clearing the cache will restart the
App.
9.10.6 About
The software version information and disclaimer are included.
9.10.7 Diagnostic Software Auto Update
This option is used to set whether automatic update function is ON.
9.10.8 Device Account Management
This option is used to manage the sub-accounts. The added sub-account allows
the VCI connector to be used by different users to log in the tool, which is
convenient for multiple VCIs to perform diagnostic service at the same time.
The newly added sub-account has a one-year validity period. After the expiration,
LAUNCH X-431 PROS V
1.0
User Manual
67
the VCI bound to the sub-account cannot be used and the sub-account will no
longer enjoy the rights and interests of the main account. The main account can
modify the validity period of the sub-account.
There are two types of sub-accounts: one is an existing account and the other is
a newly created account. The main account has the functions of adding and
removing sub-accounts, the sub-account can also be unbound from the main
account.
Tap Device account management, the following screen will appear:
Tap Add technician account, the following popup will appear:
• If you already have an account, please enter the user name and password.
After inputting, tap Add Immediately to add it as a sub-account.
• If you have not registered any account, tap Create sub user. Enter the user
name and password, and then tap Add Immediately to add it as a
sub-account.
After adding the sub-account, the following screen will appear:
LAUNCH X-431 PROS V
1.0
User Manual
68
To unbind it from the main account, tap Remove. To revise the validity period,
tap Change.
9.10.9 Login/Logout
To logout the current user ID, tap Logout.
To login the system again, tap Login.
9.11 Diagnostic Software Clear
This item allows you to hide/clear the diagnostic software that is not frequently
used.
Note: Removing software may completely delete the software from the tablet. If
some software is not used and the tablet runs out of space, you can use this feature to
remove it. To re-download it, go to Software Update -> Available.
LAUNCH X-431 PROS V
1.0
User Manual
69
10 FAQ
1. How to save power?
Please turn off the screen while the tool keeps idle.
Set a shorter standby time.
Decrease the brightness of the screen.
If WLAN connection is not required, please turn it off.
Disable GPS function if GPS service is not in use.
2. Communication error with vehicle ECU?
Please confirm:
1. Whether the VCI connector is correctly connected.
2. Whether ignition switch is ON.
3. If all checks are normal, send vehicle year, make, model and VIN number to
us using Feedback feature.
3. Failed to enter into vehicle ECU system?
Please confirm:
1. Whether the vehicle is equipped with this system.
2. Whether the VCI connector is correctly connected.
3. Whether ignition switch is ON.
4. If all checks are normal, send vehicle year, make, model and VIN number to
us using Feedback feature.
4. How to reset the tablet?
Resetting may cause data loss. Before doing so, please make sure important data
and information has been backed up.
Do the following to reset the tablet:
1. Tap System -> Reset options.
2. Tap Erase all data (factory reset).
3. Tap Reset tablet.
4. Tap Erase everything to start resetting until the tool automatically reboots.
LAUNCH X-431 PROS V
1.0
User Manual
70
5. How to download the App after resetting the tablet?
Note: Before registration, please make sure the network is properly connected.
After the tablet has been successfully reset, follow the steps below to download
the App:
1. Launch the browser and the default official Launch website opens (If a blank
page pops up, just type in www.x431.com in the input bar).
2. Tap Login, input the username and password and tap Log In.
3. Make sure that the serial number is correct, tap APP application program
and tap the Download icon to start downloading.
4. After the download is complete, follow the on-screen instructions to install it.
5. After installation, use the existing username and password to login and go to
update center to download the diagnostic software.
6. What to do if the language of vehicle diagnostic software does not
match the system language?
1. English is the default system language of the tool. After the system language
is set to the preference language, please go to the update center to
download the vehicle diagnostic software of the corresponding language.
2. If the downloaded diagnostic software is still displayed in English, it indicates
that the software of the current language is under development.
7. How to backup data?
You can transfer data between the PC and the tablet.
1. Use the USB cable to connect the tablet to your PC.
2. Swipe from the top, tap Android System Charging this device via USB
to enter.
3. Change the “Use USB for” to “File Transfer”.
4. Now it is ready for data backup.
Warranty
THIS WARRANTY IS EXPRESSLY LIMITED TO PERSONS WHO PURCHASE
LAUNCH PRODUCTS FOR PURPOSES OF RESALE OR USE IN THE
ORDINARY COURSE OF THE BUYER’S BUSINESS.
LAUNCH electronic product is warranted against defects in materials and
workmanship for one year from date of delivery to the user.
This warranty does not cover any part that has been abused, altered, used for a
purpose other than for which it was intended, or used in a manner inconsistent
with instructions regarding use. The exclusive remedy for any automotive meter
found to be defective is repair or replacement, and LAUNCH shall not be liable
for any consequential or incidental damages.
Final determination of defects shall be made by LAUNCH in accordance with
procedures established by LAUNCH. No agent, employee, or representative of
LAUNCH has any authority to bind LAUNCH to any affirmation, representation,
or warranty concerning LAUNCH automotive meters, except as stated herein.
Disclaimer
The above warranty is in lieu of any other warranty, expressed or implied,
including any warranty of merchantability or fitness for a particular purpose.
Purchase Order
Replaceable and optional parts can be ordered directly from your LAUNCH
authorized tool supplier. Your order should include the following information:
Order quantity
Part number
Part name
Customer Service
Any question during the operation, please call 86-755-84528722.
If your unit requires repair service, return it to the manufacturer with a copy of
the sales receipt and a note describing the problem. If the unit is determined to
be in warranty, it will be repaired or replaced at no charge. If the unit is
determined to be out of warranty, it will be repaired for a nominal service charge
plus return freight. Send the unit pre-paid to:
Attn: Customer Service Department
LAUNCH TECH. CO., LTD.
Launch Industrial Park,
North of Wuhe Avenue,
Banxuegang, Bantian,
Longgang, Shenzhen, Guangdong
P.R.China, 518129
Launch website: http://www. cnlaunch.com
http://www.x431.com
Statement:
LAUNCH reserves the rights to make any change to product designs and
specifications without notice. The actual object may differ a little from the
descriptions in the manual in physical appearance, color and configuration. We
have tried our best to make the descriptions and illustrations in the manual as
accurate as possible, and defects are inevitable, if you have any question,
please contact local dealer or after-sale service center of LAUNCH, LAUNCH
does not bear any responsibility arising from misunderstandings.
