Write the model and serial
numbers here:
Model # _________________
Serial # _________________
You can find them on a label
behind the door or drawer.
ESPAÑOL
Para consultar una version en
español de este manual de
instrucciones, visite nuestro sitio de
internet GEAppliances.com.
OWNER’S MANUAL
RANGES
Electric Front Control
49-2000831 Rev. 2 04-21 GEA
SAFETY INFORMATION .......... 3
USING THE RANGE
Surface Units ........................... 7
Cookware for Radiant Glass Cooktop. . . . . . 9
Oven Controls ..........................10
Special Features ........................11
Sabbath Mode ..........................12
Oven Racks ............................13
Aluminum Foil and Oven Liners ...........13
Cookware ..............................13
Cooking Modes .........................14
Cooking Guide .........................15
CARE AND CLEANING
Cleaning the Range – Exterior ............16
Cleaning the Range – Interior ............17
Cleaning the Glass Cooktop ..............18
Oven Light ............................20
Oven Door .............................21
Storage Drawer. . . . . . . . . . . . . . . . . . . . . . . . .21
TROUBLESHOOTING TIPS ....... 22
LIMITED WARRANTY ............ 26
ACCESSORIES .................... 27
CONSUMER SUPPORT ........... 28
JS645 - 30" Front Control Range
GE is a trademark of the General Electric Company. Manufactured under trademark license.
2 49-2000831 Rev. 2
THANK YOU FOR MAKING GE APPLIANCES A PART OF YOUR HOME.
Whether you grew up with GE Appliances, or this is your first, we’re happy to have you in the family.
We take pride in the craftsmanship, innovation and design that goes into every GE Appliances
product, and we think you will too. Among other things, registration of your appliance ensures that we
can deliver important product information and warranty details when you need them.
Register your GE appliance now online. Helpful websites and phone numbers are available in the
Consumer Support section of this Owner’s Manual. You may also mail in the pre-printed registration
card included in the packing material.
49-2000831 Rev. 2 3
READ AND SAVE THESE INSTRUCTIONS
SAFETY INFORMATION
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
ANTI-TIP DEVICE
To reduce the risk of tipping the range,
the range must be secured by a properly
installed anti-tip bracket. See installation
instructions shipped with the bracket for
complete details before attempting to install.
For Free-Standing and Slide-In Ranges
To check if the bracket is installed and
engaged properly, look underneath the
range to see that the rear leveling leg is
engaged in the bracket. On some models, the storage drawer or kick panel
can be removed for easy inspection. If visual inspection is not possible,
slide the range forward, confirm the anti-tip bracket is securely attached to
the floor or wall, and slide the range back so the rear leveling leg is under
the anti-tip bracket.
If the range is pulled from the wall for any reason, always repeat this
procedure to verify the range is properly secured by the anti-tip bracket.
Never completely remove the leveling legs or the range will not be secured
to the anti-tip device properly.
WARNING
Read all safety instructions before using the product. Failure to follow these instructions may result
in fire, electrical shock, serious injury or death.
• A child or adult can tip the range and be killed.
• Install the anti-tip bracket to the wall or floor.
•
Engage the range to the anti-tip bracket by sliding th
e
range back such that the foot is engaged.
• Re-engage the anti-tip bracket if the range is moved.
• Failure to do so can result in death or serious burns
to children or adults.
Tip-Over Hazard
WARNING
Anti-Tip
Bracket
Leveling Leg
Free-Standing and Slide-In Ranges
WARNING
GENERAL SAFETY INSTRUCTIONS
Ŷ 8VHWKLVDSSOLDQFHRQO\IRULWVLQWHQGHGSXUSRVHDV
described in this Owner’s Manual.
Ŷ %HVXUH\RXUDSSOLDQFHLVSURSHUO\LQVWDOOHGDQG
grounded by a qualified installer in accordance with
the provided installation instructions.
Ŷ 'RQRWDWWHPSWWRUHSDLURUUHSODFHDQ\SDUWRI\RXU
range unless it is specifically recommended in this
manual. All other servicing should be transferred to
a qualified technician.
Ŷ %HIRUHSHUIRUPLQJDQ\VHUYLFHXQSOXJWKHUDQJH
or disconnect the power supply at the household
distribution panel by removing the fuse or switching
off the circuit breaker.
Ŷ 'RQRWOHDYHFKLOGUHQDORQH²FKLOGUHQVKRXOGQRW
be left alone or unattended in an area where an
appliance is in use. They should never be allowed
to climb, sit or stand on any part of the appliance.
Ŷ
CAUTION
'RQRWVWRUHLWHPVRILQWHUHVWWR
children above a range or on the backguard of a
UDQJH²FKLOGUHQFOLPELQJRQWKHUDQJHWRUHDFK
items could be seriously injured.
4 49-2000831 Rev. 2
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
WARNING
KEEP FLAMMABLE MATERIALS AWAY FROM THE RANGE
Failure to do so may result in fire or personal injury.
Ŷ 'RQRWVWRUHRUXVHIODPPDEOHPDWHULDOVLQDQRYHQ
or near the cooktop, including paper, plastic, pot
holders, linens, wall coverings, curtains, drapes and
gasoline or other flammable vapors and liquids.
Ŷ 1HYHUZHDUORRVHILWWLQJRUKDQJLQJJDUPHQWVZKLOH
using the appliance. These garments may ignite if
they contact hot surfaces causing severe burns.
Ŷ 'RQRWOHWFRRNLQJJUHDVHRURWKHUIODPPDEOH
materials accumulate in or near the range. Grease
in the oven or on the cooktop may ignite.
Ŷ &OHDQYHQWLODWLQJKRRGVIUHTXHQWO\*UHDVHVKRXOG
not be allowed to accumulate on the hood or filter.
WARNING
IN THE EVENT OF A FIRE, TAKE THE FOLLOWING
STEPS TO PREVENT INJURY AND FIRE SPREADING
Ŷ 'RQRWXVHZDWHURQJUHDVHILUHV1HYHUSLFNXS
a flaming pan. Turn the controls off. Smother a
flaming pan on a surface unit by covering the pan
completely with a well-fitting lid, cookie sheet or flat
WUD\8VHDPXOWLSXUSRVHGU\FKHPLFDORUIRDPW\SH
fire extinguisher.
Ŷ ,IWKHUHLVDILUHLQWKHRYHQGXULQJEDNLQJVPRWKHU
the fire by closing the oven door and turning the
oven off or by using a multi-purpose dry chemical or
foam-type fire extinguisher.
Ŷ ,IWKHUHLVDILUHLQWKHRYHQGXULQJVHOIFOHDQWXUQ
the oven off and wait for the fire to go out. 'RQRW
force the door open. Introduction of fresh air at self-
clean temperatures may lead to a burst of flame
from the oven. Failure to follow this instruction may
result in severe burns.
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
GENERAL SAFETY INSTRUCTIONS (Cont.)
Ŷ 8VHRQO\GU\SRWKROGHUV²PRLVWRUGDPSSRW
holders on hot surfaces may result in burns from
VWHDP'RQRWOHWSRWKROGHUVWRXFKKRWVXUIDFH
XQLWVRUKHDWLQJHOHPHQWV'RQRWXVHDWRZHORU
other bulky cloth in place of pot holders.
Ŷ 1HYHUXVH\RXUDSSOLDQFHIRUZDUPLQJRUKHDWLQJ
the room.
Ŷ 'RQRWWRXFKWKHVXUIDFHXQLWVWKHKHDWLQJHOHPHQWV
or the interior surface of the oven. These surfaces
may be hot enough to burn even though they are
GDUNLQFRORU'XULQJDQGDIWHUXVHGRQRWWRXFK
or let clothing or other flammable materials contact
the surface units, areas nearby the surface units or
any interior area of the oven; allow sufficient time
for cooling first. Other surfaces of the appliance
may become hot enough to cause burns. Potentially
hot surfaces include the cooktop, areas facing the
cooktop, oven vent opening, surfaces near the
opening and crevices around the oven door.
Ŷ 'RQRWKHDWXQRSHQHGIRRGFRQWDLQHUV3UHVVXUH
could build up and the container could burst,
causing an injury.
Ŷ 'RQRWXVHDQ\W\SHRIIRLORUOLQHUWRFRYHUWKH
oven bottom or anywhere in the oven, except as
described in this manual. Oven liners can trap heat
or melt, resulting in damage to the product and risk
of shock, smoke or fire.
Ŷ $YRLGVFUDWFKLQJRULPSDFWLQJJODVVGRRUVFRRN
WRSVRUFRQWUROSDQHOV'RLQJVRPD\OHDGWRJODVV
EUHDNDJH'RQRWFRRNRQDSURGXFWZLWKEURNHQ
glass. Shock, fire or cuts may occur.
Ŷ &RRNPHDWDQGSRXOWU\WKRURXJKO\²PHDWWRDWOHDVW
an internal temperature of 160°F and poultry to at
least an internal temperature of 180°F. Cooking
to these temperatures usually protects against
foodborne illness.
49-2000831 Rev. 2 5
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
COOKTOP SAFETY INSTRUCTIONS
Ŷ 1HYHUOHDYHWKHVXUIDFHXQLWVXQDWWHQGHG%RLORYHUV
cause smoking and greasy spillovers that may catch
on fire.
Ŷ 1HYHUOHDYHRLOXQDWWHQGHGZKLOHIU\LQJ,IDOORZHG
to heat beyond its smoking point, oil may ignite
resulting in fire that may spread to surrounding
FDELQHWV8VHDGHHSIDWWKHUPRPHWHUZKHQHYHU
possible to monitor oil temperature.
Ŷ 7RDYRLGRLOVSLOORYHUDQGILUHXVHDPLQLPXP
amount of oil when shallow pan-frying and avoid
cooking frozen foods with excessive amounts of ice.
Ŷ 8VHSURSHUSDQVL]H²VHOHFWFRRNZDUHKDYLQJ
flat bottoms large enough to cover the surface
heating element. The use of undersized cookware
will expose a portion of the surface unit to direct
contact and may result in ignition of clothing. Proper
relationship of cookware to surface unit will also
improve efficiency.
Ŷ 2QO\FHUWDLQW\SHVRIJODVVJODVVFHUDPLF
earthenware or other glazed containers are suitable
for cooktop service; others may break because of
the sudden change in temperature.
Ŷ 7RPLQLPL]HWKHSRVVLELOLW\RIEXUQVLJQLWLRQRI
flammable materials and spillage, the handle of a
container should be turned toward the center of the
range without extending over nearby surface units.
Ŷ :KHQSUHSDULQJIODPLQJIRRGVXQGHUDKRRGWXUQ
the fan on.
Ŷ ,ISRZHULVORVWWRDQHOHFWULFFRRNWRSZKLOHDVXUIDFH
unit is ON, the surface unit will turn back on as
soon as power is restored. In the event of power
loss, failure to turn all surface unit knobs to the OFF
position may result in ignition of items on or near the
cooktop, leading to serious injury or death.
WARNING
RADIANT COOKTOP SAFETY INSTRUCTIONS
Ŷ 8VHFDUHZKHQWRXFKLQJWKHFRRNWRS7KHJODVV
surface of the cooktop will retain heat after the
controls have been turned off.
Ŷ 'RQRWFRRNRQDEURNHQFRRNWRS,IJODVVFRRNWRS
should break, cleaning solutions and spillovers
may penetrate the broken cooktop and create a
risk of electric shock. Contact a qualified technician
immediately.
Ŷ $YRLGVFUDWFKLQJWKHJODVVFRRNWRS7KHFRRNWRS
can be scratched with items such as knives, sharp
instruments, rings or other jewelry, and rivets on
clothing.
Ŷ 'RQRWSODFHRUVWRUHLWHPVWKDWFDQPHOWRUFDWFK
fire on the glass cooktop, even when it is not being
used. If the cooktop is inadvertently turned on, they
may ignite. Heat from the cooktop or oven vent after
it is turned off may cause them to ignite also.
Ŷ 8VHFHUDPLFFRRNWRSFOHDQHUDQGQRQVFUDWFK
cleaning pad to clean the cooktop. Wait until the
cooktop cools and the indicator light goes out
before cleaning. a wet sponge or cloth on a hot
surface can cause steam burns. Some cleaners can
produce noxious fumes if applied to a hot surface.
NOTE: Sugar spills are an exception. They should
be scraped off while still hot using an oven mitt
and a scraper. See the Cleaning the glass cooktop
section for detailed instructions.
Ŷ 5HDGDQGIROORZDOOLQVWUXFWLRQVDQGZDUQLQJVRQWKH
cleaning cream label.
6 49-2000831 Rev. 2
SAFETY INFORMATION
READ AND SAVE THESE INSTRUCTIONS
How to Remove Protective Shipping Film and Packaging Tape
Carefully grasp a corner of the protective shipping film
with your fingers and slowly peel it from the appliance
VXUIDFH'RQRWXVHDQ\VKDUSLWHPVWRUHPRYHWKHILOP
Remove all of the film before using the appliance for the
first time.
To assure no damage is done to the finish of the
product, the safest way to remove the adhesive from
packaging tape on new appliances is an application of
a household liquid dishwashing detergent. Apply with a
soft cloth and allow to soak.
NOTE: The adhesive must be removed from all parts. It
cannot be removed if it is baked on.
IMPORTANT SAFETY INFORMATION
READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE
WARNING
SELF-CLEANING OVEN SAFETY INSTRUCTIONS
The self-cleaning feature operates the oven at temperatures high enough to burn away food soils in the oven.
Follow these instructions for safe operation.
Ŷ 'RQRWWRXFKRYHQVXUIDFHVGXULQJVHOIFOHDQ
operation. Keep children away from the oven during
self-cleaning. Failure to follow these instructions
may cause burns.
Ŷ %HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHUHPRYHSDQV
shiny metal oven racks and other utensils from the
oven. Only gray porcelain-coated oven racks may
EHOHIWLQWKHRYHQ'RQRWXVHVHOIFOHDQWRFOHDQ
other parts, such as drip pans or bowls.
Ŷ %HIRUHRSHUDWLQJWKHVHOIFOHDQF\FOHZLSHJUHDVH
and food soils from the oven. Excessive amount
of grease may ignite leading to smoke damage to
your home.
Ŷ ,IWKHVHOIFOHDQLQJPRGHPDOIXQFWLRQVWXUQWKH
oven off and disconnect the power supply. Have it
serviced by a qualified technician.
Ŷ 'RQRWFOHDQWKHGRRUJDVNHW7KHGRRUJDVNHWLV
essential for a good seal. Care should be taken not
to rub, damage or move the gasket.
Ŷ 'RQRWXVHDSURWHFWLYHFRDWLQJWROLQHWKHRYHQDQG
do not use commercial oven cleaner unless certified
for use in a self-cleaning oven.
WARNING
OVEN SAFETY INSTRUCTIONS
Ŷ 6WDQGDZD\IURPWKHUDQJHZKHQRSHQLQJWKHRYHQ
door. Hot air or steam which escapes can cause
EXUQVWRKDQGVIDFHDQGRUH\HV
Ŷ 'RQRWXVHWKHRYHQLIDKHDWLQJHOHPHQWGHYHORSV
a glowing spot during use or shows other signs
of damage. A glowing spot indicates the heating
element may fail and present a potential burn, fire,
or shock hazard. Turn the oven off immediately and
have the heating element replaced by a qualified
service technician.
Ŷ .HHSWKHRYHQYHQWXQREVWUXFWHG
Ŷ .HHSWKHRYHQIUHHIURPJUHDVHEXLOGXS*UHDVHLQ
the oven may ignite.
Ŷ 3ODFHRYHQUDFNVLQGHVLUHGORFDWLRQZKLOHRYHQLV
cool. If rack must be moved while oven is hot, do not
let pot holder contact hot heating element in oven.
Ŷ :KHQXVLQJFRRNLQJRUURDVWLQJEDJVLQWKHRYHQ
follow the manufacturer’s directions.
Ŷ 3XOOWKHRYHQUDFNWRWKHVWRSORFNSRVLWLRQZKHQ
loading and unloading food from the oven. This
helps prevent burns from touching hot surfaces of
the door and oven walls.
Ŷ 'RQRWOHDYHLWHPVVXFKDVSDSHUFRRNLQJXWHQVLOV
or food in the oven when not in use. Items stored in
an oven can ignite.
Ŷ 1HYHUSODFHFRRNLQJXWHQVLOVSL]]DRUEDNLQJVWRQHV
or any type of foil or liner on the oven floor. These
items can trap heat or melt, resulting in damage to
the product and risk of shock, smoke or fire.
49-2000831 Rev. 2 7
USING THE RANGE:6XUIDFH8QLWV
Surface Units
WARNING
FIRE HAZARD: Never leave the range ON unattended. Keep flammable items away from the
cooktop. Turn off all controls when done cooking. Failure to follow these instructions can result in
fire, serious injury or death.
Throughout this manual, features and appearance may vary from your model.
NOTE: Before using the cooktop for the first time, clean it with ceramic cooktop cleaner. This helps protect the top
and makes cleanup easier.
How to Set
Push the knob in and turn in either direction to the
setting you want.
A surface ON indicator light will glow when any surface
unit is on
For glass cooktop surfaces:
A HOT COOKTOP indicator light will:
Ŷ FRPHRQZKHQWKHXQLWLVKRWWRWKHWRXFK
Ŷ VWD\RQHYHQDIWHUWKHXQLWLVWXUQHGRII
Ŷ VWD\RQXQWLOWKHXQLWLVFRROHGWR
approximately 150°F.
Dual Surface Units and Control Knobs (on some models)
The surface unit has 2 cooking sizes to select from so you can match the size of the unit to the size of the cookware
you are using.
At both OFF and HI the control clicks
into position. You may hear slight
clicking sounds during cooking,
indicating the control is maintaining
your desired setting.
Be sure you turn the control knob to
OFF when you finish cooking.
Melt setting (on some models)
will melt chocolate or butter.
0RGHOVZLWKD'XDO5LQJ
surface element only
8 49-2000831 Rev. 2
Surface Units (Cont.)
USING THE RANGE:6XUIDFH8QLWV
Home Canning Tips
Be sure the canner is centered over the surface unit.
Make sure the canner is flat on the bottom.
To prevent burns from steam or heat, use caution when
canning.
8VHUHFLSHVDQGSURFHGXUHVIURPUHSXWDEOHVRXUFHV
These are available from manufacturers such as Ball
®
and Kerr
®
DQGWKH'HSDUWPHQWRI$JULFXOWXUH([WHQVLRQ
Service.
)ODWERWWRPHGFDQQHUVDUHUHFRPPHQGHG8VHRIZDWHU
bath canners with rippled bottoms may extend the time
required to bring the water to a boil.
Temperature Limiter on Radiant Glass Cooktops
Every radiant surface unit has a temperature limiter.
The temperature limiter protects the glass cooktop from
getting too hot.
The temperature limiter may cycle the surface units off
for a time if:
Ŷ WKHSDQERLOVGU\
Ŷ WKHSDQERWWRPLVQRWIODW
Ŷ WKHSDQLVRIIFHQWHU
Ŷ WKHUHLVQRSDQRQWKHXQLW
Radiant Glass Cooktop
The radiant cooktop features heating units beneath a
smooth glass surface.
NOTE: A slight odor is normal when a new cooktop is
used for the first time. It is caused by the heating of new
parts and insulating materials and will disappear in a
short time.
NOTE: On models with light-colored glass cooktops, it is
normal for the cooking zones to change color when hot
or cooling down. This is temporary and will disappear as
the glass cools to room temperature.
The surface unit will cycle on and off to maintain your
selected control setting.
It is safe to place hot cookware on the glass surface
even when the cooktop is cool.
Even after the surface units are turned off, the glass
cooktop retains enough heat to continue cooking. To
avoid overcooking, remove pans from the surface units
when the food is cooked. Avoid placing anything on the
surface unit until it has cooled completely.
Ŷ :DWHUVWDLQVPLQHUDOGHSRVLWVDUHUHPRYDEOHXVLQJ
the cleaning cream or full-strength white vinegar.
Ŷ 8VHRIZLQGRZFOHDQHUPD\OHDYHDQLULGHVFHQWILOPRQ
the cooktop. The cleaning cream will remove this film.
Ŷ 'RQ¶WVWRUHKHDY\LWHPVDERYHWKHFRRNWRS,IWKH\
drop onto the cooktop, they can cause damage.
Ŷ 'RQRWXVHWKHVXUIDFHDVDFXWWLQJERDUG
Never cook directly on the glass. Always
use cookware.
Always place the pan in the center of the
surface unit you are cooking on.
'RQRWVOLGHFRRNZDUHDFURVVWKHFRRNWRSEHFDXVH
LWFDQVFUDWFKWKHJODVV²WKHJODVVLVVFUDWFK
resistant, not scratch proof.
49-2000831 Rev. 2 9
Cookware for Radiant Glass Cooktop
The following information will help you choose cookware which will give good performance on glass cooktops.
NOTE: Follow all cookware manufacturer’s recommendations when using any type of cookware on the ceramic cooktop.
Recommended
Stainless Steel
Aluminum:
heavy weight recommended
Good conductivity. Aluminum residues
sometimes appear as scratches on the
cooktop but can be removed if cleaned
immediately. Because of its low melting
point, thin weight aluminum should not
be used.
Copper Bottom:
Copper may leave residues which can
appear as scratches. The residues can
be removed, as long as the cooktop
is cleaned immediately. However, do
not let these pots boil dry. Overheated
metal can bond to glass cooktops. An
overheated copper bottom pot will leave
a residue that will permanently stain the
cooktop if not removed immediately.
Enamel (painted) on Cast Iron:
recommended if bottom of pan is coated
Avoid/Not Recommended
Enamel (painted) on Steel:
Heating empty pans can cause
permanent damage to cooktop glass.
The enamel can melt and bond to the
ceramic cooktop.
Glass-ceramic:
Poor performance. Will scratch the
surface.
Stoneware:
Poor performance. May scratch the
surface.
Cast Iron:
QRWUHFRPPHQGHG²XQOHVVGHVLJQHG
specifically for glass cooktops
Poor conductivity and slow to absorb
heat. Will scratch the cooktop surface.
Check pans for flat bottoms by
using a straight edge.
Pans with rounded, curved,
ridged or warped bottoms are
not recommended.
For Best Results
Ŷ 3ODFHRQO\GU\SDQVRQWKHVXUIDFHHOHPHQWV'RQRW
place lids on the surface elements, particularly wet lids.
Wet pans and lids may stick to the surface when cool.
Ŷ 'RQRWXVHZRNVWKDWKDYHVXSSRUWULQJV7KLVW\SHRI
wok will not heat on glass surface elements.
Ŷ :HUHFRPPHQGWKDW\RXXVHRQO\DIODWERWWRPHG
wok. They are available at your local retail store. The
bottom of the wok should have the same diameter as
the surface element to ensure proper contact.
Ŷ 6RPHVSHFLDOFRRNLQJSURFHGXUHVUHTXLUHVSHFLILF
cookware such as pressure cookers or deep-fat
fryers. All cookware must have flat bottoms and be
the correct size.
'RQRWSODFHZHWSDQVRQWKHJODVVFRRNWRS
'RQRWXVHZRNVZLWKVXSSRUWULQJVRQWKHJODVVFRRNWRS
8VHIODWERWWRPHGZRNVRQWKHJODVVFRRNWRS
USING THE RANGE: Cookware for Radiant Glass Cooktop
10 49-2000831 Rev. 2
Oven Controls
1. Traditional Cooking Modes: Your oven has
the following traditional cooking modes: Bake, Broil
Hi/Lo, and Warm. See the Cooking Modes section for
more information.
2. Clean: Your oven has two cleaning modes: Self
Clean and Steam Clean. See the Cleaning the Oven
section for important information about using these
modes.
3. Start: Must be pressed to start any cooking,
cleaning, or timed function.
4. Cancel/Off: Cancels ALL oven operations except
WKHFORFNWLPHU:DUPLQJ'UDZHUDQG:DUPLQJ=RQH
5. Cook Time: Counts down cooking time and turns
off the oven when the cooking time is complete. Press
the Cook Time pad, use the number pads to program
a cooking time in hours and minutes, then press Start.
This can only be used with Bake and Warm.
You may use Cook Time at any point during the oven
cooking cycle
6. Set Clock: Press to set clock and follow display
instructions.
7. Timer On/Off: Works as a countdown timer.
Press the Timer On/Off pad and the number pads
to program the time in hours and minutes. Press the
Start pad. The timer countdown is complete. To turn
the timer off press the Timer On/Off pad.
8.
Delay Time: 'HOD\VZKHQWKHRYHQZLOOWXUQRQ8VH
this to set a time when you want the oven to start. Press
the Delay Time pad and use the number pads to program
the time of day for the oven to turn on then press Start.
Press the desired cooking mode and temperature then
press Start. A Cook Time may also be programmed if
desired. Follow the directions under Cook Time for setting
this feature. This can only be used with Bake and Self-
Clean.
NOTE: :KHQXVLQJWKH'HOD\7LPHIHDWXUH foods that
VSRLOHDVLO\²VXFKDVPLONHJJVILVKVWXIILQJVSRXOWU\
DQGSRUN²VKRXOGQRWEHDOORZHGWRVLWIRUPRUHWKDQ
1 hour before or after cooking. Room temperature
promotes the growth of harmful bacteria. Be sure that
the oven light is off because heat from the bulb will
speed harmful bacteria growth.
9. Oven Light: Turns the oven light on or off.
10. Lock Controls: Locks out the control so that
pressing the pads does not activate the controls. Press
the Lock Controls pad, for three seconds to lock or
unlock the control. Cancel/Off is always active, even
when the control is locked.
2
8
9
1
9
10
34675
USING THE RANGE: Oven Controls
49-2000831 Rev. 2 11
USING THE RANGE: Special Features
Special Features
There are several different special features on your range. To change the settings of these special features:
Ŷ 3UHVVWKHBake and Broil pads at the same time and hold until the special features menu is displayed.
Ŷ 8VHWKH2 or 8 number pads to scroll through the special features until the desired feature is displayed.
Ŷ 3UHVVWKH6 number pad to enter into the feature’s menu and scroll through the options.
Ŷ 2QFHWKHGHVLUHGRSWLRQLVGLVSOD\HGSUHVVWKH6 pad to save the setting and the 4 pad to exit the menu.
Adjust the Oven Temperature (OFSt)
This feature allows the oven baking temperature to be
DGMXVWHGXSWR)KRWWHURUGRZQWR)FRROHU8VH
this feature if you believe your oven temperature is too
hot or too cold and wish to change it. This adjustment
affects every cooking mode except broil.
Enter into the special features menu as outlined above.
Scroll through the features until “OFSt” is displayed
and press 68VHWKH2 pad to increase the adjusted
temperature or use the 8 pad to decrease the adjusted
temperature. Save and exit the special features menu.
End of Timer Signals (End tonE)
This is the tone that signals the end of a timer. The
tone can be either continuous (Cont) or single (bEEp).
The continuous setting (Cont) will repeatedly sound a
tone every few seconds until a button on the control
is pressed. A single setting (bEEp) will sound just a
single tone at the end of the timer. Enter into the special
features menu as outlined above. Scroll through the
options until “End tonE” is displayed and press 6. Scroll
through the options until the desired setting is displayed.
Press 6 to save the setting and then 4 to exit the menu.
Fahrenheit or Celsius Temperature
Display (Unit dEg)
The oven control is set to use Fahrenheit temperatures
(F), but you can change it to use Celsius temperatures
(C). Enter into the special features menu as outlined
DERYH6FUROOWKURXJKWKHRSWLRQVXQWLO³GHJ8QLW´LV
displayed and press 6. Scroll through the options until
the desired setting is displayed. Press 6 to save the
setting and then 4 to exit the menu.
Clock Display (CLoc diSP)
7KLVIHDWXUH2Q2IIVSHFLILHVLIWKHWLPHRIGD\LV
displayed. Enter into the special features menu as
outlined above. Scroll through the options until “Cloc
diSP” is displayed and press 6. Scroll through the
options until the desired setting is displayed. Press 6 to
save the setting and then 4 to exit the menu.
Clock Configuration (Cloc cFg)
This feature specifies how the time of day will be
displayed. You can select a standard 12-hour clock (12)
or 24-hour military time display. Enter into the special
features menu as outlined above. Scroll through the
options until “Cloc cFg” is displayed and press 6. Scroll
through the options until the desired setting is displayed.
Press 6 to save the setting and then 4 to exit the menu.
Sound Volume (Snd)
This feature allows the oven tone volume to be adjusted
on and off (oFF). Enter into the special features menu as
outlined above. Scroll through the options until “sound”
is displayed and press 6. Scroll through the options until
the desired setting is displayed. Press 6 to save the
setting and then 4 to exit the menu. The selected sound
option will play once 6 is pressed.
12-Hour Auto Shut Off (12H Shut)
This feature turns off the oven after 12 hours of
FRQWLQXRXVRSHUDWLRQ2Q2II(QWHUWKH VSHFLDOIHDWXUHV
menu as outlined above. Scroll through the options until
+6KXWLVGLVSOD\HG8VHWRHQWHUWKHPHQXDQG
toggle the setting using the 2 or 8 key. Press the 6 key
to save the setting and then 4 to exit the menu.
&DQFHO%DFN 8S 'RZQ 6DYH)RUZDUG
12 49-2000831 Rev. 2
Sabbath Mode
The Sabbath mode feature complies with standards set forth by Star K. Some of these standards that will be noticed
by the consumer include the disabling of tones, disabling of oven lights, and delays of about 30 seconds to one
minute on display changes. Only continuous baking or timed baking is allowed in the Sabbath mode. Cooking in the
Sabbath mode is a two-step process, first the Sabbath mode must be set and then the bake mode must be set.
Setting the Sabbath Mode
1. Press and hold Bake + Broil to enter special features
menu.
8VHQXPEHUNH\WRQDYLJDWHWR³6DEE´PHQX(QWHU
the menu using number key 6.
8VHQXPEHUNH\DJDLQWRWRJJOH WKHVHWWLQJWR21
8VHQXPEHUNH\WRFRQILUPWKHVHWWLQJ
8VHQXPEHUNH\WRH[LW6SHFLDOIHDWXUHVPHQX
Starting a Continuous Bake
1. Press the Bake pad.
2. If the desired temperature is 350F, press Start. If
a different cooking temperature is desired, use the
1 through 5 number pads or Timer pad to select a
preset cooking temperature, then press Start. Refer
to the graphic below to determine which pad sets the
desired cooking temperature.
After a delay, a second bracket “] [“ will appear in the
display indicating that the oven is baking.
Adjusting the Temperature
1. Press Bake, use the 1 through 5 number pads and
the Timer pad to select a different preset cooking
temperature, and press Start.
2. Since no feedback is given during temperature
change, an oven thermometer can be used to confirm
temperature changes.
Starting a Timed Bake
1. Press the Bake pad.
2. If the desired temperature is 350F, use the 6 through
0 number pads or the Lock Control pad to select
a cooking time. If a cooking temperature other
than 350F is desired, use the 1 through 5 number
pads or the Timer pad to select a preset cooking
temperature, then select the cooking time. Refer to
the graphic on this page to determine which pad sets
the desired cooking temperature and cooking time.
3. Press Start.
After a delay, a second bracket “] [“ will appear in the
display indicating that the oven is baking. When the cook
time expires, the display will change back to a single
bracket “]” indicating that the oven is no longer baking.
No tone will sound when the cook time is complete.
Exit the Sabbath Mode
Exiting the Sabbath mode should be done after the
Sabbath is over.
1. Press Cancel/Off to end any bake mode that may be
running.
2. Press and hold Bake + Broil to enter special features
menu.
8VHQXPEHUNH\WRQDYLJDWHWR³6DEE´PHQX(QWHU
the menu using num key 6.
8VHQXPEHUNH\DJDLQWRWRJJOHWKHVHWWLQJWR2))
8VHQXPEHUNH\WRFRQILUPWKHVHWWLQJ
8VHQXPEHUNH\WRH[LW6SHFLDOIHDWXUHVPHQX
Sabbath Mode Power Outage Note
If a power outage occurs while the oven is in Sabbath
Mode, the unit will return to Sabbath Mode when power
is restored, however the oven will return to the off state
even if it was in the middle of a bake cycle when the
power outage occurred.
1 = 170° F, 2 = 200° F, 3 = 250° F, 4 = 300° F, 5 = 325° F, Timer = 400° F
6 = 2 hours, 7 = 2.5 hours, 8 = 3 hours, 9 = 3.5 hours,
0 = 4 hours, Lock Controls = 6 hours
Temperature (°F) 400
Time (hours)
6h
170
2h
200
2.5h
250
3h
300
3.5h
325
4h
USING THE RANGE: Sabbath Mode
49-2000831 Rev. 2 13
USING THE OVEN: 2YHQ5DFNV$OXPLQXP)RLODQG2YHQ/LQHUV&RRNZDUH
The number of rack positions may vary by model.
Oven Racks
Recommended rack positions for various types of
foods are provided in the Cooking Guide. Adjusting
rack position is one way to impact cooking results. For
example, if you would prefer darker tops on cakes,
muffins, or cookies, try moving food one rack position
higher. If you find foods are too brown on top try moving
them down next time.
When baking with multiple pans and on multiple racks,
ensure there is at least 1½" between pans to allow
sufficient space for air to flow.
<RXU2YHQPD\KDYHH[WHQVLRQUDFNVDQGRUWUDGLWLRQDO
flat racks.
To avoid possible burns, place the racks in the desired
position before you turn the oven on.
Oven Cookware
Cookware Guidelines
The material, finish, and size of cookware affect baking
performance.
'DUNFRDWHGDQGGXOOSDQVDEVRUEKHDWPRUHUHDGLO\
than light, shiny pans. Pans that absorb heat more
readily can result in a browner, crisper, and thicker crust.
If using dark and coated cookware check food earlier
than minimum cook time. If undesirable results are
obtained with this type of cookware consider reducing
oven temperature by 25º F next time.
Shiny pans can produce more evenly cooked baked
goods such as cakes and cookies.
Glass and ceramic pans heat slowly but retain heat well.
These types of pans work well for dishes such as pies
and custards.
Air insulated pans heat slowly and can reduce bottom
browning.
Keep cookware clean to promote even heating.
Stoneware heats slowly and retains heat well. It is
recommended to preheat this type of cookware if
possible. Additional cook time may be required.
Cookware used in broil modes and air fry must be broil-
safe.
CAUTION
Do not use any type of foil or oven liner to cover the oven bottom. These items can trap heat
or melt, resulting in damage to the product and risk of shock, smoke or fire. Damage from improper use of
these items is not covered by the product warranty.
)RLOPD\EHXVHGWRFDWFKVSLOOVE\SODFLQJDVKHHWRQDORZHUUDFNVHYHUDOLQFKHVEHORZWKHIRRG'RQRWXVHPRUH
IRLOWKDQQHFHVVDU\DQGQHYHUHQWLUHO\FRYHUDQRYHQUDFNZLWKDOXPLQXPIRLO.HHSIRLODWOHDVW´IURPRYHQZDOOV
to prevent poor heat circulation.
Aluminum Foil and Oven Liners
14 49-2000831 Rev. 2
Your new oven has a variety of cooking modes to help you get the best results. These modes are described below.
Refer to the Cooking Guide section for rack position and other recommendations for specific modes and foods.
Remember, your new oven may perform differently than the oven it is replacing.
Baking and Roasting Modes
Select a mode for baking and roasting based on the
type and quantity of food you are preparing. When
preparing baked goods such as cakes, cookies, and
pastries always preheat the oven first. Follow recipe
recommendations for food placement. If no guidelines
are provided, center food in the oven.
Traditional Bake
The Bake mode is for baking and roasting. When
preparing baked goods such as cakes, cookies, and
pastries, always preheat the oven first. To use this mode
press the Bake pad, enter a temperature, and then press
Start.
Broiling Modes
Always broil with the oven door closed. Monitor food
FORVHO\ZKLOHEURLOLQJ8VHFDXWLRQZKHQEURLOLQJSODFLQJ
food closer to the broil element increases smoking,
spattering, and the possibility of fats igniting. It is not
necessary to preheat when using the Broil modes.
Broil Hi
The Broil Hi mode uses intense heat from the upper
HOHPHQWWRVHDUIRRGV8VH%URLO+LIRUWKLQQHUFXWV
RIPHDWDQGRUZKHQ\RXZRXOGOLNHWRKDYHDVHDUHG
surface and rare interior. To use this mode press the
Broil pad once and then press Start.
Broil Lo
The Broil Lo mode uses less intense heat from the upper
element to cook food thoroughly while also browning
WKHVXUIDFH8VH%URLO/RIRUWKLFNHUFXWVRIPHDWDQGRU
foods that you would like cooked all the way through. To
use this mode press the Broil pad twice and then press
Start.
Warm
Warm modes are designed to keep hot, cooked foods
hot. Cover foods that should remain moist and do
not cover foods that should be crisp. Preheating is
QRWUHTXLUHG'RQRWXVHZDUPWRKHDWFROGIRRG,WLV
recommended that food not be kept warm for more than
2 hours. To use this mode, press the Warm pad then
press Start. The control display will show the oven is set
to Bake at 170F.
Cooking Modes
USING THE RANGE: Cooking Modes
49-2000831 Rev. 2 15
USING THE RANGE: Cooking Guide
FOOD TYPE
RECOMMENDED
MODE(S)
RECOMMENDED
RACK POSITION(S) ADDITIONAL SUGGESTIONS
Baked Goods
Layer Cakes, sheet cakes, bundt
cakes, muffins, quick breads on a
Single Rack
Bake 3 8VHVKLQ\FRRNZDUH
Layer cakes* on Multiple Racks Bake 3 and 5
8VHVKLQ\FRRNZDUH(QVXUHDGHTXDWHDLUIORZ
(see illustration below).
Chiffon cakes (angel food) Bake 1 8VHVKLQ\FRRNZDUH
Cookies, biscuits, scones on a Single
Rack
Bake 3 8VHVKLQ\FRRNZDUH
Cookies, biscuits, scones on Multiple
Racks
Bake 3 and 5
8VHVKLQ\FRRNZDUH)RUIRRGVOLNHVXJDUFRRNLHVVZLWFK
food location partially through cooking for more even
cooking results between racks. Ensure adequate airflow.
Beef & Pork
Hamburgers Broil Hi 6
8VHDEURLOSDQPRYHIRRGGRZQIRUPRUHGRQHQHVV
less searing. Watch food closely when broiling. For best
performance center food below the broil heater.
Steaks & Chops Broil Hi 6
8VHDEURLOSDQPRYHIRRGGRZQIRUPRUHGRQHQHVV
less searing. Watch food closely when broiling. For best
performance center food below the broil heater.
Roasts Bake 2 or 3
8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Preheating is not necessary.
Poultry
Whole chicken Bake 2 or 3
8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Preheating is not necessary.
Bone-in chicken breasts, legs, thighs
Broil Lo
Bake
3
If breaded or coated in sauce avoid Broil Hi modes. Broil
skin side down first. Watch food closely when broiling.
For best performance when broiling, center food below
the broil heater.
Boneless chicken breasts
Broil Lo
Bake
2 or 3
If breaded or coated in sauce avoid Broil Hi modes. Broil
skin side down first. Watch food closely when broiling.
For best performance when broiling, center food below
the broil heater.
Whole turkey Bake 1
8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Preheating is not necessary.
Turkey Breast Bake 3
8VHDORZVLGHGSDQVXFKDVDEURLOSDQ
Preheating is not necessary.
Fish Broil Lo
WKLFNRUOHVV
!LQFK
Watch food closely when broiling. For best performance
center food below the broil heater.
Casseroles Bake 3
Frozen Convenience Foods
Single Rack Bake 4
3ODFHIRRGLQRYHQSULRUWRVWDUWLQJPRGH8VHGDUN
FRRNZDUHIRUPRUHEURZQLQJFULVSLQJXVHVKLQ\
cookware for less browning.
Cooking Guide
*When baking four cake layers at a time with traditional
bake, use racks 3 and 5.
Cook food thoroughly to help protect against food
borne illness. Minimum safe food temperature
recommendations for food safety can be found at
IsItDoneYet.gov. Make sure to use a food thermometer
to take food temperatures.
16 49-2000831 Rev. 2
Cleaning the Range – Exterior
WARNING
If your range is removed for cleaning, servicing or any reason, be sure the
anti-tip device is reengaged properly when the range is replaced. Failure to
take this precaution could result in tipping of the range and can result in death
or serious burns to children or adults.
Be sure all controls are off and all surfaces are cool before cleaning any part of the range.
Control Knobs
The control knobs may be removed for easier cleaning.
Make sure the knobs are in the OFF positions and pull
them straight off the stems for cleaning.
The knobs can be cleaned in a dishwasher or they may
also be washed with soap and water. Make sure the
inside of the knobs are dry before replacing.
Replace the knobs, in the OFF position to ensure proper
placement.
Control Lockout
If desired, the touch pads may be deactivated before
cleaning.
See Lock Controls in the Oven Controls section in this
manual.
Clean up splatters with a damp cloth.
5HPRYHKHDYLHUVRLOZLWKZDUPVRDS\ZDWHU'RQRWXVH
abrasives of any kind.
Reactivate the touch pads after cleaning.
Control Panel
It’s a good idea to wipe the control panel after each use.
Clean with mild soap and water or vinegar and water,
rinse with clean water and polish dry with a soft cloth.
'RQRWXVHDEUDVLYHFOHDQVHUVVWURQJOLTXLGFOHDQVHUV
plastic scouring pads or oven cleaners on the control
panel - they will damage the finish, including Black
Stainless Steel.
Oven Exterior
'RQRWXVHRYHQFOHDQHUVDEUDVLYHFOHDQVHUVVWURQJ
liquid cleansers, steel wool, plastic scouring pads, or
cleaning powders on the exterior of the oven. Clean with
a mild soap and water or vinegar and water solution.
Rinse with clean water and dry with a soft cloth. When
cleaning surfaces, make sure that they are at room
temperature and not in direct sunlight.
If stain on the door vent trim is persistent, use a mild
abrasive cleaner and a sponge-scrubber for best results.
Spillage of marinades, fruit juices, tomato sauces and
basting liquids containing acids may cause discoloration
and should be wiped up immediately. Let hot surfaces
cool, then clean and rinse.
Painted Surfaces and Black Stainless Steel
Painted surfaces include the sides of the range and the
door, top of control panel, maintop trims and the drawer
front. Clean these with soap and water or a vinegar and
water solution.
'RQRWXVHFRPPHUFLDORYHQFOHDQHUVFOHDQLQJ
powders, steel wool or harsh abrasives on any painted
surface, including Black Stainless Steel.
Stainless Steel - Excluding Black Stainless Steel (on some models)
'RQRWXVHDVWHHOZRROSDGLWZLOOVFUDWFKWKHVXUIDFH
To clean the stainless steel surface, use warm sudsy
water or a stainless steel cleaner or polish. Always wipe
the surface in the direction of the grain. Follow the cleaner
instructions for cleaning the stainless steel surface.
To inquire about purchasing cleaning products including
stainless steel appliance cleaner or polish, see the
Accessories and Consumer Support sections at the end
of this manual.
CARE AND CLEANING: Cleaning the Range – Exterior
49-2000831 Rev. 2 17
CARE AND CLEANING: Cleaning the Range – Interior
Be sure all controls are off and all surfaces are cool before cleaning any part of the range. The interior of your new
oven can be cleaned manually or by using Steam Clean or Self Clean modes.
Spillage of marinades, fruit juices, tomato sauces and basting liquids containing acids may cause discoloration and
should be wiped up immediately. Let hot surfaces cool, then clean and rinse.
Manual Cleaning
'RQRWXVHRYHQFOHDQHUVXQOHVVFHUWLILHGIRUVHOI
cleaning oven), abrasive cleaners, strong liquid
cleansers, steel wool, scouring pads, or cleaning
powders on the interior of the oven. Clean with a mild
soap and water or vinegar and water solution. Rinse with
clean water and dry with a soft cloth. When cleaning
surfaces, make sure that they are at room temperature.
Self Clean Mode
Read Self-Cleaning Oven Safety Instructions at the
beginning of this manual before using Self Clean Mode.
Self clean uses very high temperatures to clean the oven
interior. The oven door will lock when using this feature.
Before operating the self-clean cycle, wipe up grease
and soils from the oven. Remove all items from the oven
other than enameled (dark color) racks. Shiny or silver
racks, the meat probe, and any cookware or other items
should all be removed from the oven before initiating a
self-clean cycle. Close the door. Press the Self Clean
pad and a default self-clean time is displayed. The clean
time can be changed to any time between 3:00 and
5:00 hours by using the number pads to enter a different
time and pressing Start. For heavily soiled ovens, the
maximum 5 hour clean time is recommended. If you wish
to use the default time, press the Start pad immediately
after pressing the Clean pad. The oven will turn off
automatically when the self-clean cycle is complete. The
door will stay locked until the oven has cooled down. After
the oven has cooled down wipe any ash out of the oven.
We recommend venting your kitchen with an open
window or using a ventilation fan or hood during the first
self-clean cycle.
Soil on the front frame of the range and outside the
gasket on the door will need to be cleaned by hand.
Clean these areas with hot water, soap-filled steel-wool
pads or cleansers such as Soft Scrub
®
. Rinse well with
clean water and dry.
'RQRWFOHDQWKHJDVNHW7KHILEHUJODVVPDWHULDORI
the oven door gasket cannot withstand abrasion. It is
essential for the gasket to remain intact. If you notice it
becoming worn or frayed, replace it.
Make sure the oven light bulb cover is in place and the
oven light is off.
IMPORTANT: The health of some birds is extremely
sensitive to the fumes given off during the self-cleaning cycle
of any range. Move birds to another well-ventilated room.
On Some Models:
The surface units are automatically disabled during the
self-clean cycle. Make sure that all surface unit controls
are turned off at all times during the self-clean cycle.
Any surface unit that is set to an “on” position while the
self-clean cycle is operating will automatically come on
after the self-clean cycle is finished, and could result in
an “on” unattended surface unit. Wait until the self-clean
cycle is finished to set and use the surface units.
Cleaning the Range – Interior
Racks
All racks can be washed with warm, soapy water.
Enameled (not shiny) racks can be left in the cavity
during self clean.
Racks may be more difficult to slide, especially after
a self-clean. Put some vegetable oil on a soft cloth or
paper towel and rub onto the left and right edges.
NOTE: 8VLQJRWKHUFRRNLQJRLOVZLOOFDXVHDGLVFRORULQJ
or a rust like color residue on the racks and cavity sides.
To clean this residue, use a soap and water or a vinegar
and water solution. Rinse with clean water and dry with a
soft cloth.
Oven Heating Elements
'RQRWFOHDQWKHEDNHHOHPHQWRUWKHEURLOHOHPHQW$Q\
soil will burn off when the elements are heated.
To clean the oven floor when the bake element is
exposed, gently lift the bake element. On some models,
the bake element is not exposed and is under the oven
floor. Clean the oven floor with warm, soapy water.
Wipe up heavy soil on the oven bottom.
Gently lift the bake element
Steam Clean Mode
Steam clean is intended to clean small spills using water
and a lower cleaning temperature than Self-Clean.
To use the Steam Clean feature, wipe grease and soils
from the oven. Pour one cup of water into the bottom of
the oven. Close the door.
Press the Steam Clean pad and then press Start'R
not open the door during the 30 minute steam clean as
this will decrease the steam clean performance. Wipe
out any excess water and any remaining soil.
18 49-2000831 Rev. 2
To maintain and protect the surface of your glass cooktop,
follow these steps:
1. Before using the cooktop for the first time, clean it
with a ceramic cooktop cleaner. This helps protect the
top and makes cleanup easier.
2. Regular use of ceramic cooktop cleaner will help keep
the cooktop looking new.
3. Shake the cleaning cream well. Apply a few drops of
ceramic cooktop cleaner directly to the cooktop.
8VHDSDSHUWRZHORUQRQVFUDWFKFOHDQLQJSDGIRU
ceramic cooktops to clean the entire cooktop surface.
8VHDGU\FORWKRUSDSHUWRZHOWRUHPRYHDOOFOHDQLQJ
residue. No need to rinse..
NOTE:,WLVYHU\LPSRUWDQWWKDW\RX'2127KHDWWKH
cooktop until it has been cleaned thoroughly.
Burned-On Residue
NOTE:'$0$*(WR\RXUJODVVVXUIDFHPD\RFFXULI\RX
use scrub pads other than those recommended.
1. Allow the cooktop to cool.
2. Spread a few drops of ceramic cooktop cleaner on
the entire burned residue area.
8VLQJDQRQVFUDWFKFOHDQLQJSDGIRUFHUDPLF
cooktops, rub the residue area, applying pressure as
needed.
4. If any residue remains, repeat the steps listed above
as needed.
5. For additional protection, after all residue has been
removed, polish the entire surface with ceramic
cooktop cleaner and a paper towel.
Heavy, Burned-On Residue
1. Allow the cooktop to cool.
8VHDVLQJOHHGJHUD]RUEODGHVFUDSHUDWDSSUR[LPDWHO\
a 45° angle against the glass surface and scrape the
soil. It will be necessary to apply pressure to the razor
scraper in order to remove the residue.
3. After scraping with the razor scraper, spread a few drops
of ceramic cooktop cleaner on the entire burned residue
DUHD8VHDQRQVFUDWFKFOHDQLQJSDGWRUHPRYHDQ\
remaining residue.
4. For additional protection, after all residue has been
removed, polish the entire surface with ceramic
cooktop cleaner and a paper towel.
Cleaning the Glass Cooktop
8VHDQRQVFUDWFKFOHDQLQJSDGIRU
ceramic cooktops.
Clean your cooktop after each
VSLOO8VHDFHUDPLFFRRNWRS
cleaner.
Ceramic
Cooktop
Cleaner
The ceramic cooktop scraper and all recommended supplies
are available through our Parts Center. See the Accessories
and Consumer Support sections at the end of this manual.
NOTE:'RQRWXVHDGXOORUQLFNHGEODGH
CARE AND CLEANING: Cleaning the Glass Cooktop
49-2000831 Rev. 2 19
CARE AND CLEANING: Cleaning the Glass Cooktop
Metal Marks and Scratches
1. Be careful not to slide pots and pans across your
cooktop. It will leave metal markings on the cooktop
surface.
These marks are removable using the a ceramic
cooktop cleaner with a non-scratch cleaning pad for
ceramic cooktops.
2. If pots with a thin overlay of aluminum or copper
are allowed to boil dry, the overlay may leave black
discoloration on the cooktop.
This should be removed immediately before heating
again or the discoloration may be permanent.
NOTE: Carefully check the bottom of pans for roughness
that would scratch the cooktop.
Damage from Sugary Spills and Melted Plastic
Special care should be taken when removing hot substances to avoid permanent damage of the glass surface.
Sugary spillovers (such as jellies, fudge, candy, syrups) or melted plastics can cause pitting of the surface of your
cooktop (not covered by the warranty) unless the spill is removed while still hot. Special care should be taken when
removing hot substances.
Be sure to use a new, sharp razor scraper.
'RQRWXVHDGXOORUQLFNHGEODGH
1. Turn off all surface units. Remove hot pans.
2. Wearing an oven mitt:
D 8VHDVLQJOHHGJHUD]RUEODGHVFUDSHUWRPRYH
the spill to a cool area on the cooktop.
b. Remove the spill with paper towels.
3. Any remaining spillover should be left until the surface
of the cooktop has cooled.
'RQ¶WXVHWKHVXUIDFHXQLWVDJDLQXQWLODOORIWKH
residue has been completely removed.
NOTE: If pitting or indentation in the glass surface has
already occurred, the cooktop glass will have to be
replaced. In this case, service will be necessary.
Cooktop Seal
To clean the cooktop seal around the edges of the glass,
lay a wet cloth on it for a few minutes, then wipe clean
with nonabrasive cleaners.
Cleaning the Glass Cooktop (Cont.)
20 49-2000831 Rev. 2
Oven Light
CARE AND CLEANING: Oven Light
WARNING
SHOCK OR BURN HAZARD: Before replacing oven light bulb, disconnect the electrical power to the
range at the main fuse or circuit breaker panel. Failure to do so may result in electric shock or burn.
CAUTION
BURN HAZARD: The glass cover and bulb should be removed when cool. Touching hot glass with
bare hands or a damp cloth can cause burns.
Oven Light Replacement (on some models)
To remove:
7XUQWKHJODVVFRYHUFRXQWHUFORFNZLVHWXUQXQWLO
the tabs of the glass cover clear the grooves of the
socket. Wearing latex gloves may offer a better grip.
8VLQJJORYHVRUDGU\FORWKUHPRYHWKHEXOEE\SXOOLQJ
it straight out.
To replace:
8VHDQHZYROWKDORJHQEXOEQRWWRH[FHHG
50 watts. Replace the bulb with the same type of bulb
that was removed. Be sure the replacement bulb is
rated 120 volts or 130 volts (NOT 12 volts).
8VLQJJORYHVRUDGU\FORWKUHPRYHWKHEXOEIURPLWV
SDFNDJLQJ'RQRWWRXFKWKHEXOEZLWKEDUHILQJHUV2LO
from skin will damage the bulb and shorten its life.
3. Push the bulb straight into the receptacle all the way.
4. Place the tabs of the glass cover into the grooves of
WKHVRFNHW7XUQWKHJODVVFRYHUFORFNZLVHWXUQ
For improved lighting inside the oven, clean the glass
cover frequently using a wet cloth. This should be
done when the oven is completely cool.
5. Reconnect electrical power to the oven.
Oven Light Replacement (on some models)
To remove:
1. Turn the glass cover
FRXQWHUFORFNZLVHWXUQXQWLOWKH
tabs of the glass cover clear the
grooves of the socket. Wearing
latex gloves may offer a better grip.
2. Remove the bulb by turning it
counter-clockwise.
To replace:
1. Replace bulb with a new 40-watt appliance bulb.
Insert the bulb and turn it clockwise until it is tight.
2. Place the tabs of the glass cover into the grooves of
WKHVRFNHW7XUQWKHJODVVFRYHUFORFNZLVHWXUQ
For improved lighting inside the oven, clean the glass
cover frequently using a wet cloth. This should be
done when the oven is completely cool.
3. Reconnect electrical power to the oven.
G9 Bulb
Socket
Tab
Glass cover
Receptacle
8VHJORYHV
or cloth
Receptacle
Oven Light Replacement (on some models)
The oven light bulb is covered with a removable glass cover that is held in place with a bail-shaped wire. Remove
WKHRYHQGRRULIGHVLUHGWRUHDFKWKHFRYHUHDVLO\6HHWKH/LIW2II2YHQ'RRUVHFWLRQIRUGHWDLOHGRYHQGRRU
removal instructions.
Replacing the Light Bulb:
'LVFRQQHFWHOHFWULFDOSRZHUWRWKHUDQJH
2. Hold the glass cover stable, so it doesn’t fall when
released.
3. Slide near the indent of the cover holder until the
cover is released. Do not remove any screws to
release the glass cover.
4. Replace bulb with a 40-watt household appliance
bulb. Do not touch hot bulb with hand or wet
cloth. Only remove bulb when it is cool.
5. Hold glass cover stable over new bulb.
6. Pull the wire cover holder near the indent until the
indent in the
wire cover
holder is located
in the indent of
the glass cover.
7. Connect
electrical power
to range.
Wire cover holder
Indent
Glass cover
(on self clean
model only)
49-2000831 Rev. 2 21
CARE AND CLEANING: 2YHQ 'RRU 6WRUDJH 'UDZHU
The door is very heavy. Be careful when removing and lifting the door.
'RQRWOLIWWKHGRRUE\WKHKDQGOH
To remove the door:
1. Fully open the door.
2. Pull the hinge locks down toward the door frame, to
the unlocked position. A tool, such as a small flat-
blade screwdriver, may be required.
3. Firmly grasp both sides of the door at the top.
4. Close door to the door removal position. The door
should be open approximately 3" with no obstruction
above the door.
5. Lift door up and out until both hinge arms are clear of
the slots.
To replace the door:
1. Firmly grasp both sides of the door at the top.
2. Starting on the left side, with the door at the same
angle as the removal position, seat the indentation of
the hinge arm into the bottom edge of the hinge slot.
The notch in the hinge arm must be fully seated into
the bottom of the slot. Repeat for right side.
3. Fully open the door. If the door will not fully open, the
indentation is not seated correctly in the bottom edge
of the slot.
4. Push the hinge locks up against the front frame of the
oven cavity, to the locked position.
5. Close the oven door.
Removal position
Hinge lock
Slot
Pull hinge locks down to unlock
Push hinge locks up to lock
Hinge
lock
Hinge
arm
Indentation
Bottom
edge of
slot
Hinge arm
Oven Door
Removable Storage Drawer
For Metal Rails (on some models)
The storage drawer is a good place to store cookware
DQGEDNHZDUH'RQRWVWRUHSODVWLFVRUIODPPDEOH
material in the drawer.
The storage drawer may be removed for cleaning under
the range. Clean the storage drawer with a damp cloth or
sponge. Never use harsh abrasives or scouring pads.
To remove the drawer:
1. Pull the drawer out until it stops.
2. Lift the front of the drawer until the stops clear the
guides.
3. Remove the drawer.
To replace the drawer:
1. Place the drawer rails on the guides.
2. Push the drawer back until it stops.
3. Lift the front of the drawer and push back until the
stops clear the guides.
4. Lower the front of the drawer and push back until it
closes.
Stop guide
Rail
22 49-2000831 Rev. 2
Troubleshooting Tips ... Before you call for service
Save time and money! Review the charts on the following pages first and you may not need to call for service.
Problem Possible Cause What To Do
Surface units will not
maintain a rolling boil or
cooking is not fast enough
Improper cookware being used. 8VHSDQVZKLFKDUHIODWDQGPDWFKWKHGLDPHWHURIWKH
surface unit selected.
In some areas, the power (voltage) may be low. Cover pan with a lid until desired heat is obtained.
Surface units do not work
properly
A fuse in your home may be blown or the circuit
breaker tripped.
Replace the fuse or reset the circuit breaker.
Cooktop controls improperly set. Check to see the correct control is set for the surface
unit you are using.
Surface unit stops glowing
when turned to a lower
setting
The unit is still on and hot. This is normal.
Scratches (may appear as
cracks) on cooktop glass
surface
Incorrect cleaning methods being used. Scratches are not removable. Tiny scratches will become
less visible in time as a result of cleaning.
Cookware with rough bottoms being used or coarse
particles (salt or sand) were between the cookware
and the surface of the cooktop. Cookware has been
slid across the cooktop surface.
To avoid scratches, use the recommended cleaning
procedures. Make sure bottoms of cookware are clean
before use, and use cookware with smooth bottoms.
Areas of discoloration on
the cooktop
Food spillovers not cleaned before next use. See the Cleaning the glass cooktop section.
Hot surface on a model with a light-colored cooktop. This is normal. The surface may appear discolored when
it is hot. This is temporary and will disappear as the
glass cools.
Plastic melted to the
surface
Hot cooktop came into contact with plastic placed
on the hot cooktop.
See the Cleaning the glass cooktop section as there is
potential for permanent damage without proper care.
Pitting (or indentation) of
the cooktop
Hot sugar mixture spilled on the cooktop. Call a qualified technician for replacement.
Frequent cycling off and on
of surface units
Improper cookware being used. 8VHRQO\IODWFRRNZDUHWRPLQLPL]HF\FOLQJ
My new oven doesn't
cook like my old one. Is
something wrong with the
temperature settings?
Your new oven has a different cooking system from
your old oven and therefore may cook differently
than your old oven.
For the first few uses, follow your recipe times and
temperatures carefully. If you still think your new oven is
too hot or too cold, you can adjust the temperature yourself
by following the steps in Special Features to meet your
specific cooking preference. NOTE: This adjustment affects
Bake temperatures; it will not affect Broil or Clean.
Food does not bake
properly
Oven controls improperly set. See the Cooking Modes section.
Rack position is incorrect or rack is not level. See the Cooking Modes section and Cooking Guide.
Incorrect cookware or cookware of improper size
being used.
See the Cookware section.
Oven temperature needs adjustment. See the Special Features section.
Ingredient substitution Substituting ingredients can change the recipe outcome.
Food does not broil
properly
Oven controls improperly set. Make sure you select the appropriate broil mode.
Improper rack position being used. See Cooking Guide for rack location suggestions.
Food being cooked in a hot pan. Make sure cookware is cool.
Cookware not suited for broiling. 8VHDSDQVSHFLILFDOO\GHVLJQHGIRUEURLOLQJ
Aluminum foil used on the broiling pan and grid has
not been fitted properly and slit as recommended.
If using aluminum foil conform to pan slits.
In some areas the power (voltage) may be low. Preheat the broil element for 10 minutes.
Oven temperature too hot
or too cold
Oven temperature needs adjustment. See the Special Features section.
TROUBLESHOOTING TIPS
49-2000831 Rev. 2 23
TROUBLESHOOTING TIPS
Problem Possible Cause What To Do
Oven does not work or
appears not to work
A fuse in your home may be blown or the circuit
breaker tripped.
Replace the fuse or reset the circuit breaker.
Oven controls improperly set. 6HHWKH8VLQJWKH2YHQVHFWLRQ
Oven is in Sabbath Mode. Verify that the oven is not in Sabbath Mode. See the Special
Features section.
“Crackling” or “popping”
sound
This is the sound of the metal heating and cooling
during both the cooking and cleaning functions.
This is normal.
Why is my range making
a "clicking" noise when
using my oven?
Your range cycles the heating elements by
turning relays on and off to maintain the oven
temperature.
This is normal.
Clock and timer do not
work
A fuse in your home may be blown or the circuit
breaker tripped.
Replace the fuse or reset the circuit breaker.
Plug on range is not completely inserted in the
electrical outlet.
Make sure electrical plug is plugged into a live, properly
grounded outlet.
Oven controls improperly set. 6HHWKH8VLQJWKHNLWFKHQWLPHUVHFWLRQ
Clock display turned off &KHFN&ORFN'LVSOD\VHWWLQJVLQWKH6SHFLDO)HDWXUHVVHFWLRQ
Storage drawer won’t
close
Power cord may be obstructing drawer in the
lower back of the range.
Reposition the drawer and power cord. See the Storage
'UDZHU5HPRYDOLQVWUXFWLRQVLQWKH&DUHDQGFOHDQLQJRIWKH
range section.
'UDZHUVOLGHRUUDLOLPSURSHUO\DOLJQHGZLWK
support
5HSRVLWLRQWKHGUDZHU6HHWKH6WRUDJH'UDZHU5HPRYDO
instructions in the Care and cleaning of the range section.
Oven door is crooked The door is out of position. Because the oven door is removable, it sometimes gets out
of position during installation. To straighten the door, re-install
WKHGRRU6HHWKH/LIW2II2YHQ'RRULQVWUXFWLRQVLQWKH&DUH
and Cleaning section.
Oven light does not work Light bulb is loose or defective. Tighten or replace bulb.
Pad operating light is broken. Call for service.
Oven is in Sabbath mode Verify that the oven is not in Sabbath mode. See the Special
Features section.
Oven will not self-clean The temperature is too high to set a self-clean
operation.
Allow the oven to cool and reset the controls.
Oven controls improperly set. See the Cleaning the Oven section.
'RRUQRWVKXWFORVHG Close the oven door completely.
Excessive smoking
during clean cycle
Excessive soil or grease. Press the Cancel/Off pad. Open the windows to rid the room
RIVPRNH:DLWXQWLOWKH/2&.('OLJKWJRHVRII:LSHXSWKH
excess soil and reset the clean cycle.
Excessive smoking
during broiling
Food too close to burner element. Lower the rack position of the food.
Oven door will not open
after a clean cycle
Oven too hot. Allow the oven to cool below locking temperature.
Oven not clean after a
clean cycle
Oven controls improperly set. See the Cleaning the Oven section.
Oven was heavily soiled. Clean up heavy spillovers before starting the clean cycle.
Heavily soiled ovens may need to self-clean again or for a
longer period of time.
"LOCK DOOR" flashes in
the display
The self-clean cycle has been selected but the
door is not closed.
Close the oven door. Latch the door for units that have a
manual latch.
DOOR LOCK light is on
when you want to cook
The oven door is locked because the
temperature inside the oven has not dropped
below the locking temperature.
Press the Cancel/Off pad. Allow the oven to cool.
“F— and a number or
letter” flash in the display
You have a function error code. Press the Cancel/Off pad. Allow the oven to cool for one hour.
Put the oven back into operation.
If the function code repeats. 'LVFRQQHFWDOOSRZHUWRWKHRYHQIRUDWOHDVWVHFRQGVDQG
then reconnect power. If the function error code repeats, call
for service.
Troubleshooting Tips ... Before you call for service
24 49-2000831 Rev. 2
Problem Possible Cause What To Do
Display goes blank A fuse in your home may be blown or the
circuit breaker tripped.
Replace the fuse or reset the circuit breaker.
The clock is turned off. See the Special features section.
Power outage, clock flashes Power outage or surge Reset the clock. If the oven was in use, you must reset it by
pressing the Cancel/Off pad, setting the clock and resetting any
cooking function.
“Burning” or “oily” odor
emitting from the vent
This is normal in a new oven and will
disappear in time.
To speed the process, set a self-clean cycle for a minimum of 3
hours. See the Cleaning the Oven section.
Strong odor An odor from the insulation around the
inside of the oven is normal for the first few
times the oven is used.
This is temporary and will go away after several uses or a self-
clean cycle.
Fan noise A cooling fan may automatically turn on This is normal on some models. The cooling fan will turn off and
on to cool internal parts. It may run after the oven is turned off.
My oven door glass appears
to be "tinted" or have a
"rainbow" color. Is this
defective?
No. The inner oven glass is coated with
a heat barrier to reflect the heat back into
the oven to prevent heat loss and keep the
outer door cool while baking.
7KLVLVQRUPDO8QGHUFHUWDLQOLJKWRUDQJOHV\RXPD\VHHWKLVWLQW
or rainbow color.
Sometimes the oven takes
longer to preheat to the
same temperature
Cookware or food in oven. The cookware or food in the oven will cause the oven to take
longer to preheat. Remove items to reduce preheat time.
Number of racks in oven. Adding more racks to the oven will cause the oven to take longer
to preheat. Remove some racks.
Display flashes Power failure. Reset the clock.
Unable to get the display to
show “oFFSEt”
Oven control pads were not touched
properly.
The Broil Hi/Lo and Bake pads must be touched at the same
time and held for 3 seconds.
Control signals after
entering cooking time or
start time
You forgot to enter a bake temperature or
cleaning time.
Touch the Bake pad and desired temperature or the Self Clean
pad and desired clean time.
Oven racks are difficult to
slide
The shiny, silver-colored racks were
cleaned in a self-clean cycle.
Apply a small amount of vegetable oil to a paper towel and wipe
WKHHGJHVRIWKHRYHQUDFNVZLWKWKHSDSHUWRZHO'RQRWVSUD\
with Pam
®
or other lubricant sprays.
Drawer does not slide
smoothly or drags
The drawer is out of alignment. Fully extend the drawer and push it all the way in. See the Care
and cleaning of the range section.
'UDZHULVRYHUORDGHGRUORDGLV
unbalanced.
Reduce weight. Redistribute drawer contents.
Steam from the vent When using the ovens, it is normal to see
steam coming out of the oven vents. As
the number of racks or amount of food
being cooked increases, the amount of
visible steam will increase.
This is normal.
Troubleshooting Tips ... Before you call for service
TROUBLESHOOTING TIPS
49-2000831 Rev. 2 25
Notes
26 49-2000831 Rev. 2
Staple your receipt here. Proof of the original purchase
date is needed to obtain service under the warranty.
GEAppliances.com
All warranty service is provided by our Factory Service Centers, or an authorized Customer Care
®
technician. To schedule
service online, visit us at GEAppliances.com/service, or call GE Appliances at 800.GE.CARES (800.432.2737). Please
have your serial number and your model number available when calling for service.
Servicing your appliance may require the use of the onboard data port for diagnostics. This gives a GE Appliances factory
service technician the ability to quickly diagnose any issues with your appliance and helps GE Appliances improve its
products by providing GE Appliances with information on your appliance. If you do not want your appliance data to be
sent to GE Appliances, please advise your technician not to submit the data to GE Appliances at the time of service.
What GE Appliances will not cover:
Ŷ Service trips to your home to teach you how to use
the product.
Ŷ ,PSURSHULQVWDOODWLRQGHOLYHU\RUPDLQWHQDQFH
Ŷ )DLOXUHRIWKHSURGXFWLILWLVDEXVHGPLVXVHG
modified or used for other than the intended purpose
or used commercially.
Ŷ 'DPDJHWRWKHJODVVFRRNWRSFDXVHGE\XVHRI
cleaners other than the recommended cleaning
creams and pads.
Ŷ 'DPDJHWRWKHJODVVFRRNWRSFDXVHGE\KDUGHQHGVSLOOV
of sugary materials or melted plastic that are not cleaned
according to the directions in the Owner's Manual.
Ŷ 5HSODFHPHQWRIKRXVHIXVHVRUUHVHWWLQJRIFLUFXLW
breakers.
Ŷ 'DPDJHWRWKHSURGXFWFDXVHGE\DFFLGHQWILUH
floods or acts of God.
Ŷ 'DPDJHWRILQLVKVXFKDVVXUIDFHUXVWWDUQLVKRUVPDOO
blemishes not reported within 48 hours of delivery.
Ŷ ,QFLGHQWDORUFRQVHTXHQWLDOGDPDJHFDXVHGE\
possible defects with this appliance.
Ŷ 'DPDJHFDXVHGDIWHUGHOLYHU\
Ŷ 3URGXFWQRWDFFHVVLEOHWRSURYLGHUHTXLUHGVHUYLFH
Ŷ 6HUYLFHWRUHSDLURUUHSODFHOLJKWEXOEVH[FHSWIRU
/('ODPSV
LIMITED WARRANTY
GE Appliances Electric Range Limited Warranty
EXCLUSION OF IMPLIED WARRANTIES
Your sole and exclusive remedy is product repair as provided in this Limited Warranty. Any implied warranties,
including the implied warranties of merchantability or fitness for a particular purpose, are limited to one year or
the shortest period allowed by law.
This limited warranty is extended to the original purchaser and any succeeding owner for products purchased for
KRPHXVHZLWKLQWKH86$,IWKHSURGXFWLVORFDWHGLQDQDUHDZKHUHVHUYLFHE\D*($SSOLDQFHV$XWKRUL]HG6HUYLFHU
is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized
GE Appliances Service location for service. In Alaska, the limited warranty excludes the cost of shipping or service
calls to your home.
Some states do not allow the exclusion or limitation of incidental or consequential damages. This limited warranty
gives you specific legal rights, and you may also have other rights which vary from state to state. To know what your
legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.
Warrantor: GE Appliances, a Haier company
Louisville, KY 40225
Extended Warranties: Purchase a GE Appliances extended warranty and learn about special discounts that are
available while your warranty is still in effect. You can purchase it online anytime at
GEAppliances.com/extended-warranty
or call 800.626.2224 during normal business hours. GE Appliances Service will still be there after your warranty expires.
For the period of GE Appliances will replace
One year
From the date
of the original
purchase
Any partRIWKHUDQJHZKLFKIDLOVGXHWRDGHIHFWLQPDWHULDOVRUZRUNPDQVKLS'XULQJWKLV
limited one-year warranty, GE Appliances will provide, free of charge, all labor and in-home
service to replace the defective part.
49-2000831 Rev. 2 27
ACCESSORIES
Looking For Something More?
GE Appliances offers a variety of accessories to
improve your cooking and maintenance experiences!
Refer to the Consumer Support page for phone numbers
and website information.
The following products and more are available:
Accessories
Accessories
Small Broiler Pan (8 ¾ ” x 1 ¼” x 13 ½ “)
Large Broiler Pan (12 ¾ ” x 1 ¼” x 16 ½ “)
;/%URLOHU3DQ´[ó´[³
Parts
Oven racks
Oven elements
Light bulbs
Cleaning Supplies
CitruShine™ Stainless Steel Wipes
Stainless Steel Appliance Cleaner
Non-scratch Cleaning Pads for Ceramic Cooktops
Ceramic Cooktop Cleaner
Ceramic Cooktop Scraper
Kit (Kit includes cream and cooktop scraper)
7KHODUJHEURLOHUSDQGRHVQRWILWLQ´´UDQJHV
7KH;/EURLOHUSDQGRHVQRWILWLQ´ZDOORYHQV´GURSLQVRU´´UDQJH
NOTE: Go to GE Appliances website to view recommended cleaners.
28 49-2000831 Rev. 2
3ULQWHGLQWKH8QLWHG6WDWHV
Consumer Support
CONSUMER SUPPORT
GE Appliances Website
Have a question or need assistance with your appliance? Try the GE Appliances Website 24 hours a day, any day
of the year! You can also shop for more great GE Appliances products and take advantage of all our on-line support
VHUYLFHVGHVLJQHGIRU\RXUFRQYHQLHQFH,QWKH86GEAppliances.com
Register Your Appliance
Register your new appliance on-line at your convenience! Timely product registration will allow for enhanced
communication and prompt service under the terms of your warranty, should the need arise. You may also mail in
WKHSUHSULQWHGUHJLVWUDWLRQFDUGLQFOXGHGLQWKHSDFNLQJPDWHULDO,QWKH86GEAppliances.com/register
Schedule Service
Expert GE Appliances repair service is only one step away from your door. Get on-line and schedule your service at
\RXUFRQYHQLHQFHDQ\GD\RIWKH\HDU,QWKH86GEAppliances.com/service
or call 800.432.2737 during normal business hours.
Extended Warranties
Purchase a GE Appliances extended warranty and learn about special discounts that are available while your
warranty is still in effect. You can purchase it on-line anytime. GE Appliances Services will still be there after your
ZDUUDQW\H[SLUHV,QWKH86GEAppliances.com/extended-warranty
or call 800.626.2224 during normal business hours.
Remote Connectivity
For assistance with wireless network connectivity (for models with remote enable),
visit our website at GEAppliances.com/connect RUFDOOLQWKH86
Parts and Accessories
Individuals qualified to service their own appliances can have parts or accessories sent directly to their homes
9,6$0DVWHU&DUGDQG'LVFRYHUFDUGVDUHDFFHSWHG2UGHURQOLQHWRGD\KRXUVHYHU\GD\
,QWKH86GEApplianceparts.com or by phone at 877.959.8688 during normal business hours.
Instructions contained in this manual cover procedures to be performed by any user. Other servicing
generally should be referred to qualified service personnel. Caution must be exercised, since improper
servicing may cause unsafe operation.
Contact Us
If you are not satisfied with the service you receive from GE Appliances, contact us on our Website with all the
details including your phone number, or write to:
,QWKH86*HQHUDO0DQDJHU&XVWRPHU5HODWLRQV_*($SSOLDQFHV$SSOLDQFH3DUN_/RXLVYLOOH.<
GEAppliances.com/contact
