pet bathtub instructions
& Parts list
1: bathtub box 12: connector
2: rear baffle of the tub 13: Shower head
3: derrick 14: shower hose
4: the bathtub left
15: Soap cylinder
and right baffle
5: step stair 16: water inlet hose
6: bathtub base 17: water leakage
7:Door plank 18: gasket
8: step 19: rubber gasket
9: M8 hexagon nut 20: fixed ring
10: M8 head screw 21: outlet
11: faucet
Tools: cross screwdriver, wrench
&Assembly instructions
1:As shown in the figure, place the tub box properly
on the bottom rack and lock the box with the screw
(see figure)
2: the gasket set into the water leakage into the
bath together at the bottom of the hole, then the
rubber gasket (with thread side down) from the tub
at the bottom of the box body into the water
leakage, and fixed plastic retainer ring is tightened,
the last on the water hose and hose connection of
the screw to prevent loss
3:place the left and right baffle and the rear fender
on the upper part of the box, and use the screw to
fix it (the left and right baffle and the rear should
also be fixed with screws)
4. Place the horizontal bar on the right left and right
side of the Assemble the box, and tighten the
screw on the hole position
5: put the pedals into the bathtub
6:Screw the soap box with screws on the right side
of the two long lumbar holes and adjust the position
to tighten the screws
7: take the tap into the water inlet through the two
large holes of the right board, and turn the joint to
the inlet on the other side of the side plate
8:connect the two ends of the hose to the outlet of
the faucet and the sprinkling water inlet to tighten it
and then place the shower head on the bracket
9：Connect two water inlet pipes to the other side
of the joint and tighten to prevent leakage
Tools: screwdriver, wrench
Complete assembly
TIP: after installation, adjust the bathtub adjustable foot to hold the bathtub smooth and steady, and
adjust the leaking end to keep it low to make the waste water emissions more smoothly.
After using please thoroughly clean the bathtub and keep dry clean, can only use mild soap or
detergent for cleaning, do not use the rough or corrosion were role cleaner, bleach, also can not use
with metal or metal arts and tools (such as: steel wire ball, steel brush) clean surface to prevent scratch
damage bathtub
