Instruction Manual
Item: 17046
Model: 32510016
10 Inch
Metal Table Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc. may
deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166
(8:30 am - 5:00 pm EST) Monday - Friday
or contact us at info@getholmesfans.com.
Our customer service will be happy to assist you.
www.getholmesfans.com
© 2021 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH009-112221
MAINTENANCE
USER SERVICING INSTRUCTIONS
Follow these instructions to safely and correctly care for your fan.
REPLACEABLE FUSE
If your (5 Amp, 125 Volt) replaceable fuse blows, please visit our website at www.getholmesfans.com for information on
how to order a new fuse.
REPLACING THE FUSE
1. Unplug your fan.
Grasp plug and remove from the receptacle or other outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by using your thumb or a flathead
screwdriver to slide the cover towards the prongs.
NOTE: Ensure the fuse cover is completely open before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver to pry it from the compartment at
the metal ends of the fuse. (See Figure 2)
4. Place plug on a solid, flat surface. Insert new 5 Amp, 125 Volt fuse into fuse
compartment. Use a small screwdriver to secure the metal ends of the fuse into the
compartment.
CAUTION: Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure the fuse is completely secured in place by pressing on metal
ends of the fuse.
CAUTION: Risk of fire. Do not replace the attachment plug. It contains a safety device (fuse) that should not be
removed. Discard product if the attachment plug is damaged.
Figure 2
Fuse
Fuse cover
Metal ends
IMPORTANT SAFETY INSTRUCTIONS
FEATURES CLEANING / MAINTENANCE
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or into the fan
housing.
• Use only a soft cloth moistened with a mild soap
solution.
• Do not use harsh chemicals such as gasoline,
thinner or benzene as a cleaner.
• Do not attempt to remove the fan blade.
• Please use caution around the motor housing area.
Do not allow the motor or other electrical
components to be exposed to water.
FAN BLADE CLEANING
1. Remove the front grill by opening the clips located
around the perimeter.
2. Remove the blade by loosening the securing
screws.
3. Clean the fan blade, front and rear grills with a
soft cloth moistened with a mild soap solution.
4. Replace the fan blade and tighten the securing
screw.
5. Securely fasten the front grill to the rear grill by
closing the clips over the perimeter.
FAN HEAD AND BASE CLEANING
1. Using a soft, moist cloth, with or without a mild soap
solution, carefully clean the fan base (I) and head (C).
Use CAUTION around the motor housing area.
Do not allow the motor or other electrical components
to be exposed to water.
FAN STORAGE
• Store the fan in a clean, dry location between seasons
or when not in use for an extended period.
• Keep the fan head protected from dirt and dust during
storage.
TILT ADJUSTMENT
1. Loosen the tilt-adjustment knob and move the fan
head to the desired angle.
2. Tighten the knob by turning clockwise.
ASSEMBLY
Your Table Fan comes completely assembled and is ready
for use.
OPERATING INSTRUCTIONS
1. Set the fan base on a dry, level surface.
2. Make sure the Speed Control Knob (F) is in the OFF
(0) position.
3. Plug cord into any standard 120 volt AC outlet.
4. To adjust the speed, turn the speed control knob (F) to
the desired setting, 0-3-2-1.
5. To start OSCILLATION, press control knob (G) down. To
stop oscillation, pull control knob up.
FIGURE 1
B
E
F
G
D
C
A
I
H
A. FRONT GRILL
B. REAR GRILL
C. FAN HEAD
D. FAN BLADE
E. CARRY HANDLE
F. SPEED CONTROL KNOB
G. OSCILLATION CONTROL KNOB
H. TILT ADJUSTMENT KNOB
I. BASE
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all parts
properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock and
injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This product employs overload protection (fuse).
A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or contact customer service.
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse unit,
plug or cord in water or spray with liquids and plug
the appliance directly into a 120V AC electrical outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on or
taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under rugs
or any parts near an open flame, cooking or other
heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange cord
away from traffic area and where it will not be tripped
over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to info@getholmesfans.com. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste
management facility.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
IMPORTANT SAFETY INSTRUCTIONS
FEATURES CLEANING / MAINTENANCE
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or into the fan
housing.
• Use only a soft cloth moistened with a mild soap
solution.
• Do not use harsh chemicals such as gasoline,
thinner or benzene as a cleaner.
• Do not attempt to remove the fan blade.
• Please use caution around the motor housing area.
Do not allow the motor or other electrical
components to be exposed to water.
FAN BLADE CLEANING
1. Remove the front grill by opening the clips located
around the perimeter.
2. Remove the blade by loosening the securing
screws.
3. Clean the fan blade, front and rear grills with a
soft cloth moistened with a mild soap solution.
4. Replace the fan blade and tighten the securing
screw.
5. Securely fasten the front grill to the rear grill by
closing the clips over the perimeter.
FAN HEAD AND BASE CLEANING
1. Using a soft, moist cloth, with or without a mild soap
solution, carefully clean the fan base (I) and head (C).
Use CAUTION around the motor housing area.
Do not allow the motor or other electrical components
to be exposed to water.
FAN STORAGE
• Store the fan in a clean, dry location between seasons
or when not in use for an extended period.
• Keep the fan head protected from dirt and dust during
storage.
TILT ADJUSTMENT
1. Loosen the tilt-adjustment knob and move the fan
head to the desired angle.
2. Tighten the knob by turning clockwise.
ASSEMBLY
Your Table Fan comes completely assembled and is ready
for use.
OPERATING INSTRUCTIONS
1. Set the fan base on a dry, level surface.
2. Make sure the Speed Control Knob (F) is in the OFF
(0) position.
3. Plug cord into any standard 120 volt AC outlet.
4. To adjust the speed, turn the speed control knob (F) to
the desired setting, 0-3-2-1.
5. To start OSCILLATION, press control knob (G) down. To
stop oscillation, pull control knob up.
FIGURE 1
B
E
F
G
D
C
A
I
H
A. FRONT GRILL
B. REAR GRILL
C. FAN HEAD
D. FAN BLADE
E. CARRY HANDLE
F. SPEED CONTROL KNOB
G. OSCILLATION CONTROL KNOB
H. TILT ADJUSTMENT KNOB
I. BASE
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all parts
properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock and
injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This product employs overload protection (fuse).
A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or contact customer service.
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse unit,
plug or cord in water or spray with liquids and plug
the appliance directly into a 120V AC electrical outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on or
taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under rugs
or any parts near an open flame, cooking or other
heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange cord
away from traffic area and where it will not be tripped
over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to info@getholmesfans.com. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste
management facility.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
IMPORTANT SAFETY INSTRUCTIONS
FEATURES CLEANING / MAINTENANCE
FAN CLEANING
• Always unplug the fan before cleaning.
• Do not allow water to drip on or into the fan
housing.
• Use only a soft cloth moistened with a mild soap
solution.
• Do not use harsh chemicals such as gasoline,
thinner or benzene as a cleaner.
• Do not attempt to remove the fan blade.
• Please use caution around the motor housing area.
Do not allow the motor or other electrical
components to be exposed to water.
FAN BLADE CLEANING
1. Remove the front grill by opening the clips located
around the perimeter.
2. Remove the blade by loosening the securing
screws.
3. Clean the fan blade, front and rear grills with a
soft cloth moistened with a mild soap solution.
4. Replace the fan blade and tighten the securing
screw.
5. Securely fasten the front grill to the rear grill by
closing the clips over the perimeter.
FAN HEAD AND BASE CLEANING
1. Using a soft, moist cloth, with or without a mild soap
solution, carefully clean the fan base (I) and head (C).
Use CAUTION around the motor housing area.
Do not allow the motor or other electrical components
to be exposed to water.
FAN STORAGE
• Store the fan in a clean, dry location between seasons
or when not in use for an extended period.
• Keep the fan head protected from dirt and dust during
storage.
TILT ADJUSTMENT
1. Loosen the tilt-adjustment knob and move the fan
head to the desired angle.
2. Tighten the knob by turning clockwise.
ASSEMBLY
Your Table Fan comes completely assembled and is ready
for use.
OPERATING INSTRUCTIONS
1. Set the fan base on a dry, level surface.
2. Make sure the Speed Control Knob (F) is in the OFF
(0) position.
3. Plug cord into any standard 120 volt AC outlet.
4. To adjust the speed, turn the speed control knob (F) to
the desired setting, 0-3-2-1.
5. To start OSCILLATION, press control knob (G) down. To
stop oscillation, pull control knob up.
FIGURE 1
B
E
F
G
D
C
A
I
H
A. FRONT GRILL
B. REAR GRILL
C. FAN HEAD
D. FAN BLADE
E. CARRY HANDLE
F. SPEED CONTROL KNOB
G. OSCILLATION CONTROL KNOB
H. TILT ADJUSTMENT KNOB
I. BASE
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. Do not use outdoors.
14. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
15. Always use on a dry, level surface.
16. Do not operate fan until fully assembled with all parts
properly in place.
17. This product is intended for household use ONLY and
not for commercial or industrial applications.
18. WARNING: To reduce the risk of electrical shock and
injury to persons, do not use in window.
19. WARNING: To reduce the risk of fire or electric
shock, do not use this fan with any solid-state speed
control device.
20. This product employs overload protection (fuse).
A blown fuse indicates an overload or short-circuit
situation. If the fuse blows, unplug the product from
the outlet. Replace the fuse as per the user servicing
instructions (follow product marking for proper fuse
rating) and check the product. If the replacement fuse
blows, a short circuit may be present and the product
should be discarded or contact customer service.
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse unit,
plug or cord in water or spray with liquids and plug
the appliance directly into a 120V AC electrical outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on or
taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under rugs
or any parts near an open flame, cooking or other
heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner. Discard fan or
contact customer service.
10. Do not run cord under carpeting. Do not cover cord
with throw rugs, runner, or similar coverings. Do not
route cord under furniture or appliances. Arrange cord
away from traffic area and where it will not be tripped
over.
11. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
If you have any questions regarding your product
or would like to learn more about other Holmes
®
products, please visit our website at
www.getholmesfans.com or call customer service:
1-866-769-3166 (8:30 am - 5:00 pm E.S.T.) or send
an email to [email protected]. For inquiries
regarding recycling and proper disposal of this
product, please contact your local waste
management facility.
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than
the other). To reduce the risk of electric shock, this plug is intended to
fit in a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
Instruction Manual
Item: 17046
Model: 32510016
10 Inch
Metal Table Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc. may
deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166
(8:30 am - 5:00 pm EST) Monday - Friday
or contact us at info@getholmesfans.com.
Our customer service will be happy to assist you.
www.getholmesfans.com
© 2021 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH009-112221
MAINTENANCE
USER SERVICING INSTRUCTIONS
Follow these instructions to safely and correctly care for your fan.
REPLACEABLE FUSE
If your (5 Amp, 125 Volt) replaceable fuse blows, please visit our website at www.getholmesfans.com for information on
how to order a new fuse.
REPLACING THE FUSE
1. Unplug your fan.
Grasp plug and remove from the receptacle or other outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by using your thumb or a flathead
screwdriver to slide the cover towards the prongs.
NOTE: Ensure the fuse cover is completely open before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver to pry it from the compartment at
the metal ends of the fuse. (See Figure 2)
4. Place plug on a solid, flat surface. Insert new 5 Amp, 125 Volt fuse into fuse
compartment. Use a small screwdriver to secure the metal ends of the fuse into the
compartment.
CAUTION: Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure the fuse is completely secured in place by pressing on metal
ends of the fuse.
CAUTION: Risk of fire. Do not replace the attachment plug. It contains a safety device (fuse) that should not be
removed. Discard product if the attachment plug is damaged.
Figure 2
Fuse
Fuse cover
Metal ends
Instruction Manual
Item: 17046
Model: 32510016
10 Inch
Metal Table Fan
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
WARRANTY INFORMATION
Printed In China
3 YEAR LIMITED WARRANTY
This device has a limited warranty of 3 years from the original date of purchase against workmanship and defects
in material. If under normal use, your product fails to operate, please contact our customer service department at
[email protected]. A refund or replacement will be provided to you with proof of purchase. Star Elite Inc. may
deny claims of damage caused by misuse or modications of this product.
How to Obtain Warranty Service
If you have any problems, please do not contact the store.
Contact our customer service at 1-866-769-3166
(8:30 am - 5:00 pm EST) Monday - Friday
or contact us at [email protected].
Our customer service will be happy to assist you.
www.getholmesfans.com
© 2021 Sunbeam Products, Inc. All rights reserved.
HOLMES
®
is a registered trademark of Sunbeam Products, Inc. used under license.
Distributed by Star Elite Inc., Montreal, Canada H3B 3X9
SEH009-112221
MAINTENANCE
USER SERVICING INSTRUCTIONS
Follow these instructions to safely and correctly care for your fan.
REPLACEABLE FUSE
If your (5 Amp, 125 Volt) replaceable fuse blows, please visit our website at www.getholmesfans.com for information on
how to order a new fuse.
REPLACING THE FUSE
1. Unplug your fan.
Grasp plug and remove from the receptacle or other outlet device.
NOTE: Do not unplug by pulling on cord.
2. Open fuse cover, located on the top of the plug, by using your thumb or a flathead
screwdriver to slide the cover towards the prongs.
NOTE: Ensure the fuse cover is completely open before attempting to remove fuse.
3. Remove fuse carefully by using a small screwdriver to pry it from the compartment at
the metal ends of the fuse. (See Figure 2)
4. Place plug on a solid, flat surface. Insert new 5 Amp, 125 Volt fuse into fuse
compartment. Use a small screwdriver to secure the metal ends of the fuse into the
compartment.
CAUTION: Risk of fire. Replace fuse only with 5 Amp, 125 Volt fuse.
5. Slide fuse cover closed completely.
NOTE: If fuse cover is difficult to close, make sure the fuse is completely secured in place by pressing on metal
ends of the fuse.
CAUTION: Risk of fire. Do not replace the attachment plug. It contains a safety device (fuse) that should not be
removed. Discard product if the attachment plug is damaged.
Figure 2
Fuse
Fuse cover
Metal ends
