PROGRAMME CHART
CLEANING AND CARE
PROBLEM SOLVING GUIDE
Programme overview Cleaning and care Problem solving guide
Programme Load (weight
of dry
laundry)
Items
HygieneDry
Extra dry
Normal
Hand iron
DryCare40
Cottons 9 kg Cotton items such as those described under Cottons Normal with normal
residual moisture.
— — X — —
Cottons 9 kg Towelling, jersey wear, T-shirts, underwear, baby clothes, workwear, covers,
jackets, bathrobes, and flannelette bed linen.
Do not use Extra dry for jersey fabrics (e.g. T-shirts, underwear, baby
clothes), as they have a tendency to shrink.
X X X X X
Minimum iron 4 kg Workwear, overalls, pullovers, dresses, trousers, leggings and table linen. X — X X X
Delicates 2.5 kg Shirts, blouses, lingerie, appliquéd garments. — — X X X
Woollens handcare 2 kg Pullovers, knitted jackets, socks, stockings. — — — — —
Bed linen 4 kg Bed linen X X X X —
MobileStart The Miele App is used to select programmes and operate the appliance.
Wash2Dry Automatic programme selection depending on the networked washing machine.
Express 4 kg Garments suitable for the Cottons programme. — X X X —
Shirts 2 kg Shirts and blouses. — — X X X
Proofing 2.5 kg Microfibre fabric, skiwear, outerwear, fine close weave cotton garments
(poplin), tablecloths.
Risk of fire! Do not use proofing agents containing paraffin.
— — X — —
Warm air/DryFresh 9 kg - Warm air (for drying): Thick and multi-layered jackets, pillows, sleeping
bags, blankets.
- DryFresh (for freshening up): All fabrics.
– Use DryFresh flacon.
– Select min. 60 minutes.
— — — — X
X = Yes, – = No
Drying Ironing
Normal/Higher temperature Very hot
Reduced temperature: select DryCare40 (for delicate fabrics). Hot
Do not tumble dry Warm
— — Do not treat with heat
Fluff filter
Removing visible fluff
Clean the 2 fluff filters in the door opening
at the end of every programme.
Remove the fragrance flacon.
Pull the upper fluff
filter forwards to
remove it.
Use your fingers
or a vacuum
cleaner ...
... to remove the
fluff from the
surface of the
filter.
Push the upper fluff filter back in until it
clicks into position.
Close the door.
Cleaning the fluff filters and air flow
openings thoroughly
If the drying duration has become longer
or the surface of the filters is visibly
compacted with fluff, you should carry out
the following cleaning procedure.
Pull the upper fluff filter forwards to
remove it.
Turn the yellow
dial on the lower
fluff filter in the
direction of the
arrow (until you
hear it click).
Hold the dial and
pull the fluff filter
forwards to
remove it.
Use a vacuum
cleaner with a
long crevice
nozzle attached to
remove any visible
fluff from the
upper air flow
openings.
Flush the fluff filters through with warm
running water.
Shake the fluff filters thoroughly and then
dry them carefully.
Ensure the filters are dry before replacing
them. Wet filters could cause operational
faults.
Refit all of the fluff filters and close the
door.
Plinth filter
Clean the plinth filter when the
programme duration is longer than usual
or whenever the indicator light comes
on.
Open and close the door to clear the
message.
Press the round,
indented area on
the access panel
to open it.
Pull the plinth filter
out by the handle.
When the plinth filter is pulled out, the right
guide pin will slide out. The guide pin
prevents the flap from being closed without
the plinth filter in place.
Pull the handle out
of the plinth filter.
Clean the filter thoroughly under running
water.
Squeeze the plinth filter carefully several
times as you rinse it.
Rinse the plinth filter until all visible
residues have been removed.
Use a damp cloth
to remove any
fluff.
Refitting the plinth filter
Fit the plinth filter
back on the
handle the right
way round.
Push the plinth
filter in completely.
Insert the right guide
pin at the same time.
Close the panel.
Problem Possible cause and remedy
lights up after a
programme has been
cancelled.
The condensed water container is full or there is a kink in
the drain hose.
Open and close the door with the tumble dryer switched
on to clear the fault.
Empty the condensed water container.
Check the drain hose.
lights up at the end of
a programme.
There is a build-up of fluff.
Open and close the door with the tumble dryer switched
on to clear the fault.
Clean the fluff filter.
Clean the plinth filter.
lights up and
flashes; the programme is
cancelled.
There is a very significant build-up of fluff.
Switch the tumble dryer off to deactivate the message.
Clean the fluff filter.
Clean the plinth filter.
lights up.
The programme selector has been moved.
Select the original programme again. The time remaining
will appear in the display.
Bars flash in the display
at the end of a
programme: ……
…
The laundry is cooled down at the end of the programme.
Either remove the laundry and spread it out to cool down
or leave it in the tumble dryer to cool down during the
cooling phase.
flashes/lights up
after the tumble dryer is
switched on and a
programme cannot be
selected.
Access via a code has been activated.
You must enter the correct PIN code to use the tumble
dryer. See “Programmable functions” in the operating
instructions.
Problem Possible cause and remedy
The display is dark and
the Start/Add laundry
sensor is flashing slowly.
This is not a fault, but a normal function.
Touch a sensor to switch on the indicators.
The dryer is switched off
at the end of the
programme.
The tumble dryer switches off automatically. This is not a
fault, but a normal function.
The laundry is not
sufficiently dry.
The load consisted of different types of fabric.
Finish drying using the Warm air/DryFresh programme.
Select a more suitable programme next time.
Items made of synthetic
fibres are charged with
static electricity after
drying.
Items made of synthetic fibre can become charged with
static electricity in the tumble dryer.
Static charge can be reduced by adding fabric softener
to the final rinse in the washing programme.
There is a build-up of
fluff.
Fluff is principally the result of friction when garments are
being worn and to some extent when they are being
washed. Tumble drying hardly causes any fluff to form.
Fluff is collected by the fluff filters and the plinth filter.
See “Cleaning and care” in the operating instructions.
There are operating
noises (whirring/
humming).
This is not a fault.
The compressor (heat pump) is operating.
No action is required.
Quick Start Guide
Heat pump tumble dryer
These short instructions are not a substitute for the operating instructions supplied with
the appliance. Please read the operating instructions supplied with your tumble dryer
before using it for the first time and take note of the Warning and Safety instructions, as
well as the full descriptions on how to use your appliance.
en-AU, NZ
M.-Nr. 11 909 380 / 00
