POLE SAW
HYPS5200X
Instruction Manual
www.hyundaipowerproducts.co.uk 01646 687 880
Introduction
Thank You For Purchasing Your HYUNDAI Product
We work very hard to give all of our customers the best possible service. If you have any
problems, before leaving negative feedback, please contact us to give us a chance to resolve
the issue. We would be delighted if you left us positive feedback! Thank you for purchasing this
product.
Important!
This manual has been produced by Hyundai Power Products and should be kept with the
product. Please read and understand these instructions before you use your product. Failure to
do this may result in personal injury or damage to the product.
The safety precautions and warnings are to ensure your safety and protect you from harm or
damage to the product.
The information contained in this manual was accurate at the time of production, however
HYUNDAI Power Products may make modifications to the product without notification.
WARNING : READ THE INSTRUCTION BOOKLET THOROUGHLY BEFORE
USING THE MACHINE. Keep for future reference and pass it on if the machine is
loaned or sold to another user.
!
2
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
4
Understand Your Machine
• WARNING! You must read these instructions carefully before operating the machine. Make
sure that you are familiar with the controls and properly operate the machine. You must learn how
to stop the machine quickly. If you do not follow the warnings and instructions, it may result in fire
and/or serious injury. Make sure to save all warnings and instructions for future reference.
• Read this manual and labels affixed to the machine to understand its limitations and potential
hazards.
• Be thoroughly familiar with the controls and their proper operation. Know how to stop the
machine and disengage the controls quickly.
• If the unit is to be used by someone other than original purchaser, or is to be loaned, rented, or
sold, always provide this manual and any needed safety training before operation. The user can
prevent and is responsible for accidents or injuries that may occur to themselves, to other
people, or to property.
• Do not force the machine beyond its limits. Use the correct machine for your application.
• Know how to stop the machine quickly in case of emergency. Understand the use of all
controls.
• ALL MAINTENANCE other than that listed in this manual, should be carried out by
professionally trained and certified personnel.
• When using this machine for the first time and before actual work, you MUST learn how to han-
dle the machine from an experienced or skilled person.
!
Safety
No list of safety guidelines can be complete. Every environment is different. Always consider
safety first, as it applies to your individual working conditions. Use this and other machinery with
caution and respect. Failure to do so could result in serious injury, damage to equipment, or poor
work results.
Some or all of the following - warning signs and symbols may appear throughout this
manual. You MUST adhere to their warnings. Failure to do so may result in personal injury to
yourself or those around you.
DANGER
Indicates a hazard, which, if not avoided, could result in serious injury or death.
WARNING
Indicates a hazard, which, if not avoided, could result in serious injury.
CAUTION
Indicates a hazard which, if not avoided, might result in minor or moderate injury.
!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
5
Personal Safety
!
• WARNING! Never allow children or people unfamiliar with these instructions to use the
product. Local regulations can restrict the minimum age of the operator.
• Keep children, pets, and other people not using the unit away from the work area (at least
15m). Be alert and shut off the unit if anyone enters work area. Keep children under the watchful
care of a responsible adult.
• Stay alert, watch what you are doing and use common sense when operating the machine.
Never operate the machine when unwell or tired, or if you have taken alcohol, medicine, drugs or
any substances which may slow your reflexes and compromise judgment. A moment of
inattention while operating the machine may result in serious personal injury.
• Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating
or repairing the machine. Always wear anti-slip and resistant work footwear and long trousers
while using the machine. Do not use the machine when barefoot, wearing sandals or similar
lightweight footwear. Do not wear chains, bracelets or clothing that is loose fitting or hanging
ties or cords. Tie long hair back. Always wear protective earplugs. Loose clothes, jewellery, or
long hair can be caught in moving parts. Protect eyes, face, and head from objects that may be
thrown from the unit. Always wear safety goggles or safety glasses with side shields when
operating.
• Always keep hands and feet away from all moving parts during operation. Moving parts can cut
or crush body parts. Always keep hands and feet away from all pinch points.
• Do not touch parts that might be hot from operation. Allow parts to cool before attempting to
maintain, adjust, or service.
• Do not overreach. Keep proper footing and balance at all times. This enables better control of
the machine in unexpected situations. Extending your body too far can result in a loss of balance
and you may fall which will result in injury.
• Never place any part of your body where it would be in danger if movement should occur
during assembly, installation, and operation, maintenance, repairing or moving.
• Start the machine carefully according to instructions and with feet away from the moving parts.
• Do not place your hands or feet near or under rotating parts. Keep away from any discharge
openings.
• Keep in mind that the operator or user is responsible for accidents, hazards or unexpected
events involving the machine that occur to other people or their property. It is the responsibility of
the user to assess the potential risk of the area where work is being carried out. The operator or
user must take all necessary precautions to ensure their own safety and that of others, especially
on slopes or rough, slippery and unstable ground.
• After 30 minutes of work, take a break of at least one hour.
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
6
Inspect Your Machine
• You must check the general condition of the machine before use. Keep guards in place and in
working order. Make sure all nuts, bolts, etc., are securely tightened.
• Never operate the machine when it is in need of repair or is in poor mechanical condition.
Replace damaged, missing, or failed parts before using it. Check for fuel leaks. Keep the machine
in safe working condition.
• Do not use the machine if the engine’s switch does not turn off the engine when running. Any
petrol powered machine that can’t be controlled with the engine switch is dangerous and must
be replaced.
• Regularly check to see that keys and adjusting wrenches are removed from the machine area
before starting it. A wrench or a key that is left attached to a rotating part of the machine may
result in personal injury.
• If the machine should start to vibrate abnormally, stop the engine and check immediately for the
cause. Vibration is generally a warning sign of trouble.
• Avoid accidental starting. Be sure the engine’s switch is off before transporting the machine or
performing any maintenance or service on the unit. Transporting or performing maintenance or
service on a machine with its switch on invites accidents.
• Do not tamper with or disable safety systems.
• Only use manufacturer-recommended attachments.
• Before using, always visually inspect to see that the tools are not worn out or damaged.
Replace worn out or damaged elements and bolts in set to preserve balance.
• Keep the machine in good operating condition. Operating the machine in poor or questionable
condition could result in serious injury.
• Be sure all safety devices are in working order and warning labels are in place. These items are
installed for your safety.
• Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges
are less likely to bind and are easier to control.
!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
7
Work Area
• Make sure you thoroughly inspect the entire work area and remove all objects and anything that
could be thrown by the machine or could damage the engine or machine (branches, stones, wire,
toys, etc). Attempting to clear the work area whilst using the machine will reduce your
concentration and creates a trip hazard. Any liquid spilled on the floor may result in you slipping.
• You must only work in daylight or with good artificial light in good visibility conditions. Do not
work at night, at times of heavy fog, or at any other times when your field of vision might be
limited and it would be difficult to gain a clear view of the area.
• Keep people, children and animals away from the working area.
• Operate on flat, level ground.
• DO NOT work on wet ground. If there has been heavy rain on the working site, wait until the
ground has dried up.
• You must pay special attention when approaching obstacles that could compromise visibility.
• Make sure on slopes you have a steady foothold.
• Never park the machine in a place with unstable ground which could give way.
• You must be careful near ravines, ditches or embankments.
• Exercise extreme caution when operating on or crossing gravel drives, walks, or roads. Stay
alert for hidden hazards or traffic.
• Pay the utmost attention when working on frozen ground as the machine may tend to skid.
• Do not work in the rain, when there is a thunderstorm or lightning risk, at times of strong or gale
force winds, or at any other times when the weather conditions might make it unsafe to use this
product. If there is bad weather conditions, do not use the machine.
• Do not use the appliance in a potentially explosive environment containing flammable liquids,
gases or dusts. The sparks generated by the machine could ignite the vapours or gases.
!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
8
During Use
• Always hold the unit with both hands when operating. Keep a firm grip on the handlebars
• Do not operate the machine in confined areas where there may be a risk of crushing the
operator between the machine and another object.
• Walk, never run with the machine.
• WARNING! If something breaks or an accident happens whilst working, you must turn off the
engine immediately and move the machine away to prevent further damage. If an accident
happens with injuries or third parties are injured, carry out the first aid measures most suitable
for the situation immediately and contact the medical authorities for any necessary health care.
Carefully remove any debris that might cause damage or harm persons or animals should it not
be seen.
• Never operate the machine at a fast pace.
• The excessive speed of movement or the absence of maintenance have a significant influence
on noise emissions and vibrations. It is necessary to take preventive steps to eliminate possible
damage due to high levels of noise and stress from vibration. You must maintain the machine
well, wear ear protection and take breaks from working.
• After striking a foreign object, stop the engine immediately, remove the spark plug cap and
inspect the machine thoroughly for damage. Repair the damage before continuing.
• Always disengage the levers, turn off the engine, and remove the spark plug, when the unit is
left unattended.
• Never attempt to make any adjustments, while the engine is running.
• Never attempt to move the machine in any way other than intended for normal use while the
engine is running.
• You must disengage the blade, switch off the engine and unplug the spark plug cable (making
sure that all moving parts are stationary):
- Before refuelling.
- After striking a foreign object, you must inspect the machine for damage and make repairs
before using it again.
- Before cleaning, checking or working on the machine.
- Before clearing blockages.
- When transporting the machine.
- Whenever you leave the machine unattended.
• Never use the appliance while standing on a ladder.
• Do not use the appliance near power lines. Maintain a minimum distance of 10m to above
ground power lines.
!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
9
• Be aware of your environment and all possible hazards that you may be unable to hear while
using the machine.
• Keep an eye not only on the branches being cut, but also on fallen material, to avoid tripping.
• Hold the power tool only by the insulated grips as the cutting blades could come into contact
with hidden power lines. Contact between the blades and a live wire may make exposed metal
parts of the power tool live and could give the operator an electric shock.
• Keep your hands away from the cutting blades. Do not attempt to clear clippings or hold onto
the material to be cut while the blades are still in motion. Remove any jammed clippings only
when the appliance has been switched off. A moment of inattention while operating the hedge
trimmer may result in serious personal injury.
• Wait until the tool has come to a standstill before putting it down.
• After making settings to the working angle, check whether both setting levers are clicked
firmly into place. If one of the setting levers remains open, the second could be unintentionally be
released by a branch and the cutter bar could swing down.
• Always ensure that the handles are dry and clean and that no petrol mixture is present.
• Do not touch the exhaust.
• Always hold the appliance with both hands. Your thumbs and fingers should encircle the
handles.
• Do not cut any wood that is lying on the ground and do not attempt to saw roots that are pro-
truding from the soil. Avoid immersing the saw chain in the soil at all costs, as this could blunt the
saw chain.
• Do not use the appliance unless the appropriate protective guard has been installed and is in
good condition.
• When starting and operating the appliance, ensure that it does not come into contact with the
ground, stones, wire or other foreign material. Switch off the appliance before you put it down.
• The cutting blade flings objects and soil with great force. These can blind or cause other
injuries. Wear eye, face and leg protection. Always remove objects from the work area before
using the cutting blade.
• The cutting blade continues running after the throttle lever has been released. A running-down
cutting blade can inflict cuts to yourself or other people standing nearby. Turn the engine off and
make sure that the cutting blade has come to a complete stop before performing any work on the
cutting blade.
During Use (Continued)
!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
10
Pole Saw Safety
!
• To avoid injuries due to falling branches, do not stand under the branches that you want to cut
off. Be aware of branches that may spring back and cause injuries. Work at an angle of
approximately 60°.
• Be aware that an appliance kickback can occur.
• Keep an eye not only on the branches being cut, but also on fallen material, to avoid tripping.
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
11
Engine Safety
• This machine is equipped with an internal combustion engine. Do not use on, or near,
forest-covered or brush-covered land unless the exhaust system is equipped with a spark
arrester meeting applicable local, state, or federal laws.
• A spark arrester, if used, must be maintained in effective working order by the operator.
• Never start or run the engine inside a closed area. The exhaust fumes are dangerous,
containing carbon monoxide, an odorless and deadly gas. Operate this unit only in a
well-ventilated outdoor area. (See carbon monoxide safety).
• Do not tamper with the engine in an effort to get it to run at higher speeds. The maximum
engine speed is preset by the manufacturer and is within safety limits.
• Keep a fire extinguisher on hand when operating this machine in dry areas as a precautionary
measure.
• Never leave the operating position when the engine is running.
• The engine parts get very hot when running, do not touch. Danger of burns.
• Follow the instructions to ignite the engine carefully whilst keeping feet away from moving
parts.
• Never incline the machine during ignition. Ignite the machine on a flat surface without obstacles
or high grass.
• Do not over-rev the engine or change the engine settings.
• Never pick up or carry the machine while the engine is running.
• Stop the engine whenever you leave the machine, or before refuelling, when cleaning or while
maintaining.
• Reduce the throttle setting during engine shut down and, if the engine is provided with a
shut-off valve, turn the fuel off at the conclusion of working.
• Do not tilt the lawnmower when starting the engine.
!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
12
Carbon Monoxide
!
CARBON MONOXIDE IS A COLOURLESS, ODOURLESS GAS. INHALING THIS GAS CAN
CAUSE DEATH OR SERIOUS LONG-TERM HEALTH PROBLEMS SUCH AS BRAIN DAMAGE.
Never operate the engine in a confined space where dangerous carbon monoxide fumes can
develop. All ignition operations have to be effected in an open or well-ventilated area. Always
remember that exhaust fumes are toxic.
The symptoms of carbon monoxide poisoning can include but are not limited to the following;
Headaches, dizziness, nausea, breathlessness, collapsing or loss of consciousness.
Carbon monoxide poisoning symptoms are similar to flu, food poisoning, viral infections and
simply tiredness. It is quite common for people to mistake this very dangerous poisoning for
something else.
To avoid carbon monoxide poisoning DO NOT use Petrol/Diesel powered equipment inside any
of the following; Home, garage, tent, camper van, mobile home, caravan or boat. DO NOT use
in an enclosed area or moving vehicle. This is not exhaustive and if you are in any doubt contact
your dealer.
If you think you have or someone around you has been affected by carbon monoxide poisoning;
Get them fresh air immediately, by leaving the affected area or by opening doors and windows. If
safe and practical to do so make sure that the machine is turned off. DO NOT enter a room you
suspect of having carbon monoxide present – instead call the emergency services.
Contact a Doctor immediately or go to Hospital – let them know that you suspect carbon
monoxide poisoning.
!
Engine exhaust fumes contain Carbon Monoxide. This is a poisonous gas and can kill in
minutes. NEVER use inside a building or in an area with poor ventilation. NEVER use inside
a confined space, such as but not limited to a house, garage, vehicle, boat or tent. ONLY
use outside and far away from windows, doors and vents.
DANGER!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
13
Batteries (Where Present)
Batteries present a risk if they become damaged by the possible leaking of electrolyte. This
electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on
or near them. NOTE the electrolyte may be in a liquid or gel form.
Should you come in to contact with electrolyte you should;
• Remove all clothing contaminated with
electrolyte. If you cannot remove then saturate them in water.
• Get medical assistance as soon as possible.
You must advise the medical staff of the type of acid.
• Lead/acid battery = dilute sulphuric acid.
• Nickel/cadmium = potassium hydroxide alkali electrolyte.
• Use fresh running water to wash off excess electrolyte, continue this until medical assistance
arrives. Make sure that you do not wash the electrolyte to another part of your body or face.
• If electrolyte comes in to contact with Eyes the electrolyte needs to be immediately washed
away with large amounts of water. Make sure that you do not wash the electrolyte to another part
of your face or body.
• Gasses from charging batteries are highly flammable and great care should be taken to charge
in well ventilated areas.
!
• There is an explosion risk if the battery terminals are short circuited, when
connecting/disconnecting ALWAYS exercise great care so that the terminals or battery
leads are NOT allowed to touch and cause a spark. ALWAYS use suitable insulated tools.
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
14
Spilled Fuel
• If you have spilled fuel, make sure you do not attempt to ignite the engine but move the
machine away from the area of spilled fuel and avoid creating any source of ignition until the fuel
has evaporated and fuel vapours have dissipated.
• When fuel is spilled on yourself or your clothes, wash your skin and change clothes
immediately.
• ALWAYS clean up spills promptly using absorbent granules and a lidded bin.
Fuel Safety
!
CAUTION! ALL FUELS ARE HIGHLY FLAMMABLE AND PETROL VAPOUR IS
EXPLOSIVE. TAKE EXTREME CARE WHEN HANDLING FUEL. KEEP FUEL OUT OF
REACH OF CHILDREN.
General Safety
• Do not smoke each time fuel is handled.
• ALWAYS avoid inhaling fumes.
• ALWAYS carry fuel in the correct and clearly marked container.
• ALWAYS wear correct, suitable and fit for purpose Personal Protective Equipment (PPE),
suggested items are but not limited to safety gloves and overalls.
• To avoid sparking or arcing, keep grounded conductive objects – such as tools – away from
exposed, live electrical parts and connections. These events could ignite fumes or vapors.
• Do not operate the machine with known leaks in the fuel system.
• Fire hazard - keep fuel away from all sources of ignition for example heaters, lamps, sparks
from grinding or welding.
• DO NOT carry out hot work on tanks that have contained fuel.
• ALWAYS keep the work area tidy.
• ALWAYS dispose of waste fuels correctly.
• Serious personal injury can occur when petrol is spilled on yourself or your clothes. Rinse your
skin and change your clothes immediately.
General Safety
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
15
• ALWAYS fuel and de-fuel in a well ventilated area outside of buildings. Use a funnel to add fuel,
only outdoors. Do not smoke during this and each time fuel is handled.
• Add fuel before igniting the engine, never remove the fuel tank cap or add fuel whilst the engine
is running or when it is hot.
• When de-fueling ALWAYS use a proper fuel retriever.
• Never overfill the fuel tank. Engine heat can cause fuel to expand, never fill the tank to more
than 1/2” below the bottom of the filler neck. This will provide space for fuel expansion.
• When refilling or draining the fuel tank, use an approved fuel storage container while in a clean,
well-ventilated outdoor area. While adding fuel or operating the unit, do not smoke, and stay
away from sparks, open flames, or other sources of ignition near the area of operation.
• Always stop the engine and allow it to cool before filling the fuel tank. Never remove the cap of
the fuel tank or add fuel while the engine is running or when the engine is hot.
• Loosen the fuel tank cap slowly to relieve any pressure in the tank.
• ALWAYS keep the handles dry, clean and free of oil and fuel.
• After fueling, ensure to tighten the cap securely.
• Never use the lock-function when filling with fuel.
• Open the fuel tank slowly in order to allow any pressure which may have built up in the tank to
dissipate. To prevent the risk of fire, move at least 3 metres away from the refuelling area before
starting the appliance.
Fueling / De-Fueling
• Store fuel in containers specifically designed and approved for fuel storage.
• Store fuel in a cool, well-ventilated area, safely away from sparks, open flames, or other
sources of ignition.
• Never store fuel – or a machine with fuel in the tank – inside a building where fumes may reach
a spark, open flame, or any other source of ignition (such as a water heater, furnace, or clothes
dryer). Allow the engine to cool before storing in any enclosure.
• Replace all fuel tank and container caps securely and wipe up spilled fuel. Never operate the
unit without the fuel cap securely in place.
Storage
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
16
Electrical Safety (Where Applicable)
!
ELECTRICITY CAN KILL - NEVER WORK ON LIVE/ENERGISED EQUIPMENT.
DANGER!
• Prior to carrying out any maintenance work you MUST identify electrical isolation methods and
isolate all electrical supplies.
• Prior to use and with all electrical supplies isolated, you MUST check all electrical cables, plugs
and connectors for the following;
- Are intact and have no signs of damage, to include but not limited to bare wires, chaffing, cuts
and loose wiring.
- If there are any signs of damage, the damaged item MUST be taken out of service until the
damage has been repaired by an electrically competent person.
- All trailing cables should be routed so as not to cause any kind of trip hazard.
- NEVER work on or near electricity with wet hands, wet clothing and wet gloves.
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
17
ELECTRICITY CAN KILL - NEVER WORK ON LIVE/ENERGISED EQUIPMENT.
• Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from
vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel
syndrome. This condition reduces the ability of the hand to feel and regulate temperature,
causing numbness and heat sensations and may cause nerve damage and circulatory tissue
death.
• Not all factors that lead to white finger disease are known, but cold weather, smoking and other
diseases that affect blood vessels and blood circulation as well as large and long-lasting impact
of shocks are considered factors in the formation of white finger. Note the following to reduce the
risk of white finger and carpal tunnel syndrome;
• Wear gloves and keep your hands warm.
• Take regular breaks.
• All of the above precautions may help reduce the risk of white finger disease but not rule out
the carpal tunnel syndrome. Long-term and regular users are therefore recommended to observe
the condition of your hands and fingers. Seek medical attention immediately if any of the above
symptoms should occur.
Vibrations (Where Applicable)
!
• The operating noise of the machine can damage your hearing. When wearing protection such
as earplugs or ear defenders to protect your hearing. Long-term and regular users are advised to
have hearing checked regularly. Be especially vigilant and cautious when wearing ear protection
because your ability to hear alarm warnings will be reduced.
• Noise emissions for this equipment is unavoidable. Carry out noisy work at approved times and
for certain periods. Limit the working time to a minimum. For your personal protection and
protection of people working nearby it is also advisable for them to wear hearing protection.
• See Certificate of Conformity section for Outdoor Noise declaration of conformity.
Noise (Where Applicable)
!
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
18
Personal Protective Equipment
!
HAND PROTECTION MUST BE WORN
Protective electrically non-conductive gloves are highly recommended when working.
HEARING PROTECTION MUST BE WORN
Suitable safety hearing protection is recommended.
EYE PROTECTION MUST BE WORN
Always wear safety glasses/goggles and/or face shields. Everyday eyeglasses have
only impact resistant lenses; they are not safety glasses/goggles.
FOOT PROTECTION MUST BE WORN
Non-skid heavy duty footwear are highly recommended when working.
PROTECTIVE CLOTHING MUST BE WORN
Do not wear loose clothing, gloves, scarfs, neckties or jewellery
(rings, wrist watches), which can be caught in moving parts.
HEAD PROTECTION MUST BE WORN
Wear a safety helmet with a safety visor.
FACE SHIELD MUST BE WORN
Wear a face shield to protect your face.
RESPIRATOR MUST BE WORN
Wear a respirator.
Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when
operating or repairing the machine. No protective equipment can ensure 100%
protection.
When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc. If
more than one item of PPE is worn at the same time, make sure they can be used together, e.g.
wearing safety glasses may disturb the seal of a respirator, causing air leaks.
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
19
The HYPS5200X is a petrol powered pole saw from HYUNDAI and is powered by a 52cc 4-stroke
OHV petrol engine.
The multi-tool is manufactured according to the latest safety requirements. Every precaution is
only effective when it is followed exactly.
Intended Use:
This appliance is intended for trimming branches in trees.
User Types
This machine is intended for use by consumers, i.e. non professional operators. The machine is
intended for “DIY” and domestic use only.
Improper Use
Any other usage not in keeping with the above mentioned ones may be hazardous and harm
persons and/or damage things. Due to the physical risk posed to the user, the appliance may not
be used to perform the following activities: cleaning footpaths and as a shredder for shredding
tree and hedge sections. Furthermore, the appliance may not be used to level ground elevations
such as molehills. For safety reasons, the appliance may not be used as a drive unit for any other
devices. The user, not the manufacturer, is liable for any resulting damage or injuries of any kind.
Intended Use
www.hyundaipowerproducts.co.uk 01646 687 880
Safety Information
20
Symbols On The Machine
We have provided safety messages in this manual and on the machine. This information alerts
you to potential hazards that could hurt you or others. Please read these messages carefully.
However, we may not have listed all of the possible hazards, you must also use your own
judgment.
PPE
Wear ear protection.
PPE
Wear protective goggles.
PPE
Wear a hard hat.
PPE
Wear protective goggles.
PPE
Wear safety shoes.
IMPORTANT
Keep a safe distance away.
WARNING
Hot parts.
PRIMER
Press the primer bulb.
SOUND
Sound power level LWA data in
dB.
WARNING
Risk of injury due to running
blades.
WARNING
Falling objects, especially when
cutting above head height.
WARNING
Protect the appliance from rain
and moisture.
CAUTION
Risk of injury from rotating cutting
blade. Keep hands and feet away.
WARNING
Beware of kickback!
IMPORTANT
Left hand thread.
CARBON MONOXIDE
Never operate the engine indoor
or in areas with low ventilation.
The exhaust gas from the engine
contains carbon monoxide.
WARNING
Do not use circular saw blades for
the cutting blade function.
WARNING
Beware of flung objects.
WARNING
Fire, naked flames and smoking
are prohibited.
IMPORTANT
Add a little grease after every 20
hours of operation (gear grease).
WARNING
Read the operating instructions
before use.
WARNING
You must read and understand all
instructions before use.
WARNING
Fire, naked flames and smoking
are prohibited.
www.hyundaipowerproducts.co.uk 01646 687 880
21
Safety Information
CE SYMBOL
This product complies with the
applicable European directives
and an evaluation method of
conformity for these directives
was done.
WARNING
Petrol is highly flammable!
Explosion hazard! Do not spill fuel!
WARNING
Turn the appliance off and
disconnect the spark plug before
performing any maintenance work.
WARNING
Risk of fatal electrical shock! Keep
at least 10m away from overhead
power lines.
WARNING
The cutting tool continues running
after it is turned off (cutting blade/
cutting filament)!
Symbols On The Machine (Continued)
www.hyundaipowerproducts.co.uk 01646 687 880
Features
22
HYPS5200X Features
*NOT TO SCALE
1
2
3
4
5
6 8
7
9
10
11
13
12
www.hyundaipowerproducts.co.uk 01646 687 880
Features
23
1
2
3
4
5
6
8
7
9
10
11
13
12
Engine
Handle
Hedge Trimmer
Extension Pole
Tool Kit
Hex Key 4mm
Hex Key 5mm
8mm/10mm Spanner
Spark Plug Box Spanner/
Screwdriver
Harness
Hedge Trimmer Protector
Pole Pruner Protector
Mixing Bottle
HYPS5200X Features
www.hyundaipowerproducts.co.uk 01646 687 880
Unboxing
WARNING! Unboxing and assembling the machine should be done on a flat, stable surface
with enough room. Disposal of the packaging should be done in accordance with the local
regulations in force.
WARNING! Some of the packaging material may be harmful to children. Keep out of reach of
children.
Unboxing Safety
!
Carefully remove the product from the packaging and examine it for any sign of damage caused
during shipping. Lay the contents out and check them. If any part is damaged or missing, you
must not use the machine. Contact HYUNDAI Power Products immediately. You must keep the
packaging material in case the machine needs to be returned or repaired.
Ensure that you have all the accessories and tools you need for assembly and operation
including the suitable personal protective equipment.
24
• Engine Unit
• Hedge Trimmer Attachment
• Extension Pole
• Tool Kit with 8mm/10mm Spanner, Spark Plug Box Spanner/Screwdriver, 4 & 5mm Hex Keys
• Oil/Petrol Mixing Container
• Carrying Harness
Box Contents
www.hyundaipowerproducts.co.uk 01646 687 880
Assembly
CAUTION - This guide is meant to serve as a quick reference for operating your HYUNDAI
machine. We always advise reading the manual in full before operation.
CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide –
poisonous, colourless and odourless gas that can cause serious injury or death. Petrol is highly
flammable, always handle with extreme care and in a well ventilated area.
NOTE - Images may vary depending on model.
NOTE - The machine may be supplied with some parts already assembled. Prior to assembly,
check all items have been received. The mulching plug may already be installed for transport.
NOTE - This machine is shipped without fuel and oil and MUST be filled before use. Failure to
do so may cause damage to the engine that will not be covered by warranty.
Assembly Safety
!
We recommend that you fill out the information on page 50. If you need to contact an
authorised dealer or customer service for information on servicing, you may need to
provide this information.
There is also a service record so you can keep track of your machine service dates.
25
www.hyundaipowerproducts.co.uk 01646 687 880
Assembly
Step 1 : Engine Unit Handle
26
Remove four bolts from handle.
1
Place handle clamp over bush and insert peg on clamp into one of the holes. See image 2.
3
Image 2
Image 1
Place the handle on to the bottom clamp and evenly tighten the four hex bolts. See image 3.
4
Put rubber bush around boom and line up the hole with a hole on the underside of boom.
See image 1.
2
You will need 5mm hex key.
Image 3
www.hyundaipowerproducts.co.uk 01646 687 880
Assembly
27
Step 2 : Harness
Attach harness using quick release mechanism. See image 1.
1
The white buckle goes to the front of your body. See image 2.
3
Image 2
Image 1
The black clamp can be loosened with 4mm hex key and adjusted back and forth to get the
required balance of the machine.
2
Always use the harness when working with the machine. Turn the engine off before removing
he harness.
www.hyundaipowerproducts.co.uk 01646 687 880
Assembly
28
Pole Saw Attachment
Using 10mm spanner, remove nut from the cover (anticlockwise).
1
Wearing thick gloves, fit the cutting chain over the drive sprocket, as shown.
2
Fit the bar and feed the inner teeth of the chain into the slot which runs around the bar.
Make sure the adjustment peg sits in the hole on the bar as indicated.
3
Fit the cover back on, but make sure the adjustment peg stays located in the saw bar.
Refit the nut and hand tighten only. (Clockwise)
4
Image 2
Image 1
Using flat bladed screw driver, turn the adjustment screw clockwise to tighten cutting chain
tension.
5
Do not over tighten the chain. Using gloves, you should be able to pull the chain up about
5mm from bar. Carefully, pull the chain around the bar. It should move freely with no tight
spots.
CAUTION: The teeth on the chain are very sharp. Wear thick gloves.
6
Finally, firmly tighten 10mm nut on the cover. Recheck the tension of the chain and adjust
as necessary by loosening the 10mm nut and turning the adjustment screw.
7
We recommend you put environmentally friendly, organic chain oil in the oil tank before you
use this attachment. Do not use old engine oil.
8
www.hyundaipowerproducts.co.uk 01646 687 880
Assembly
29
Image 3 Image 4
Image 5 Image 6
Image 7 Image 8
www.hyundaipowerproducts.co.uk 01646 687 880
Preparation
30
Before Each Use
Always ensure that the machine is in a safe working condition. Inspect and check safety
devices and guards and check all nuts, bolts and screws are secure.
1
Check the oil level and fill the fuel tank.
2
Make sure you know how to stop the machine and ensure you are familiar with emergency
stop.
3
Start the machine following the instructions and stay clear of the machine’s moving parts.
4
YOU MUST read and understand the full safety instruction manual before starting the
machine.
!
CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide –
poisonous, colourless and odourless gas that can cause serious injury or death. Petrol is highly
flammable, always handle with extreme care and in a well ventilated area.
www.hyundaipowerproducts.co.uk 01646 687 880
Preparation
31
This is a 2-stroke stroke engine and will need 2 stroke oil mixed with the unleaded petrol.
The mix is 40 parts petrol to 1 part oil. (40:1). i.e. 1 litre of petrol requires 25ml of
(semi-synthetic) 2 stroke oil.
Fuel And Oil
CAUTION - Petrol is extremely flammable and must be mixed away from any naked flame
or cigarette. Mixing petrol and oil must be done in a well ventilated area, preferably
outside. Make sure you read the fuel safety before handling fuel.
Fill the petrol tank with fuel. Do not fill to the top of tank but leave at least 50mm from the top of
cap.
2
Add the respective correct amounts of unleaded petrol and 2-stroke oil to the supplied oil/petrol
mixing canister then shake the canister well.
1
www.hyundaipowerproducts.co.uk 01646 687 880
Operation
32
Connecting Attachments To Motor Unit
Loosen off the blue hand screw.
1
Slide in attachment, it will only go in one way, so do not force it. Slide it in to the red line as
shown.
2
Firmly tighten blue hand screw.
3
Connecting Extension Boom
The extension boom is attached between the motor unit and the tool being used to increase
the height you can reach. Use the extra hand grips on the extension boom.
1
CAUTION: Be aware of overhead power/telephone
wires.
2
Do not put undue pressure on the tool when using
extension boom.
3
CAUTION: DO NOT use extension boom with the
strimmer/blade attachment.
4
www.hyundaipowerproducts.co.uk 01646 687 880
Operation
33
Using The Pruning Saw
CAUTION: Use extreme care whilst using this attachment, especially around children and pets.
1
CAUTION: Be aware of overhead power/telephone wires
2
Always check the tension of the cutting chain before use.
3
This tool is only for pruning trees. Do not cut wood lying on the ground.
4
Hold the saw firmly in two hands and make sure you have secure footing.
5
Saw down onto the branch. If you saw upwards, underneath the branch you will probably
trap the blade in the branch as it starts to fall.
CAUTION: Be aware of falling branches.
6
Preventing Kickback
Kick back happens when the tip of the blade catches in the wood you are cutting. This flicks
up the blade and you may lose control. Never cut using the top part of the tip of the blade.
1
Do not use too much pressure on the tool.
2
Always replace the guard over the blade when you are finished.
3
Avoid any abnormal posture and do not saw over shoulder height. This will prevent
inadvertent contact with the tip of the rail and allows a better control of the chainsaw in
unexpected situations.
4
Always use the replacement rails and saw chains specified by the manufacturer. Incorrect
replacement rails and saw chains can lead to a tearing of the saw chain and/or kickback.
5
Do not saw with the tip of the blade. This can lead to a kickback.
6
Ensure that there aren’t any objects on the ground that you can trip over.
7
Hold the saw firmly with both hands, with
your thumb and fingers around the
handles. Position your body and arms
so you can withstand kickback forces. If
suitable measures are taken, the operator
can control the recoil forces. Never let go
of the chainsaw.
8
Do not rely solely on the chainsaw’s
built-in safety devices. As the user of
a chainsaw, you can take a number of
measures to avoid accidents and injury.
A kickback is caused by incorrect use or
misuse. It can be avoided by taking proper
precautions
9
www.hyundaipowerproducts.co.uk 01646 687 880
Starting / Stopping
NOTE - This machine is shipped without fuel and oil and MUST be filled before use. Failure to
do so may cause damage to the engine that will not be covered by warranty.
34
Cold Start
Pump the primer bulb under the carburetor 6 times.
1
2
3
Slide the on/off switch back to (I).
Pull the red choke control out.
4
With your left hand holding down the engine, firmly pull the start cord with your right hand.
Repeat until the engine starts.
CAUTION: Pull cord slightly away from the engine to avoid catching the Choke knob.
Leave for a few seconds and then press down the throttle lock out lever. You will then be
able to pull up the throttle trigger. This will release the choke control and accelerate the
speed of the engine.
5
Warm Start
Slide the On/Off switch back towards the engine. Place left hand on top of engine
(Caution : engine may be hot). Pull the starter cord until engine starts. See image 4.
1
Stopping
Release the throttle. Slide the On/Off Switch away from engine
1
CAUTION - The engine and exhaust will remain hot for a while after use. Ensure the engine
and exhaust has cooled before carrying out any maintenance, refuelling or storage.
(the appliance has been turned off for less than 15-20 minutes)
www.hyundaipowerproducts.co.uk 01646 687 880
Starting / Stopping
35
Image 2
Image 1
Image 3 Image 4
Image 5
www.hyundaipowerproducts.co.uk 01646 687 880
Maintenance
36
Maintenance Safety
!
IMPORTANT - Routine and accurate maintenance is essential for maintaining original
machine safety and performance levels.
WARNING - Before cleaning or doing maintenance work, you need to stop the engine,
disconnect the spark plug cable and read the relevant instructions. You need to wear proper
clothing and protective gloves whenever your hands are at risk.
If there are worn or damaged parts, never use the machine. Faulty or worn-out parts must be
replaced and not repaired. You must only use original spare parts. The use of non-original and/or
incorrectly fitted parts will jeopardize the safety of the machine. This may also cause accidents or
personal injuries for which the manufacturer is under no circumstance liable or responsible.
Any maintenance operations or adjustments not explained in this manual must be carried out
by your Dealer or a specialised Service Centre with the necessary knowledge and equipment to
ensure that the work is done correctly maintaining the machine’s original safety level. Any
operations performed in unauthorised centres or by unqualified persons will invalidate the
Warranty and all obligations and responsibilities of the Manufacturer.
Be very careful during adjustment of the machine to prevent entrapment of the fingers
between moving parts and fixed parts of the machine.
!
!
!
!
!
Checking Your Machine
When checking your machine, we recommend you:
• Check for worn or damaged parts.
• Make sure all nuts, screws and bolts are tight.
• Make sure all warning stickers are in place and not damaged.
• Check for oil / fuel leaks.
• Check the oil and fuel levels regularly.
• All moving parts can move smoothly and freely.
www.hyundaipowerproducts.co.uk 01646 687 880
37
Maintenance
CAUTION - DO NOT use a hose pipe or pressure washer to clean the engine. Water can
damage the engine or contaminate the fuel system.
NOTE Engine must be switched off and spark plug lead disconnected.
!
!
General Cleaning
• You must remove grass and mud from the machine to prevent it from drying. This will cause
problems the next time the machine is used.
• Wipe the machine down with a damp cloth.
• For larger build ups of debris, use a scraper or similar product.
• Dry the machine completely to prevent rust from forming.
• Make sure not to drip petrol onto the plastic parts to prevent damaging them and remove all
traces of spilt petrol immediately. The warranty will not cover damage to plastic parts caused by
petrol.
• Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their use.
Cleaning
Cleaning The Pole Pruner
The pole pruner must be cleaned of sawdust at regular intervals.
• Remove the sprocket cover.
• Remove the saw chain from the blade and clean the guide rail.
• Dry the machine completely to prevent rust from forming.
• Keep the saw chain sharp and check the tension; check the oil level and the oil supply.
www.hyundaipowerproducts.co.uk 01646 687 880
Maintenance
Short Term Storage
After use, please follow the below steps before storing your machine.
Storage
Allow the engine to fully cool down.
1
Clean the machine. See the ‘Cleaning’ section.
2
Store the machine following the guidelines above.
3
Where To Store
!
Store in a cool, dry place away from sources of ignition and varying changes in temperature.
DO NOT stack other items on top of the machine when in storage. The protectors must be
fitted for transport and storage
Store the machine in a safe place, out of the reach of children or anyone who is not familiar
with operation.
To reduce fire hazards, keep the engine, silencer, and petrol storage area free of grass,
leaves, or excessive grease. Do not leave containers full of cut grass inside storage areas.
DO NOT store the machine with fuel in the tank in an area where the fuel vapours could reach
an open flame, a strong heat source or a spark.
DO NOT store a machine that has not been given time to fully cool down. Engine must be
cooled down fully before storage.
!
!
!
!
!
38
Long Term Storage
If storing the machine for a period of 30 days or more, you must follow proper storage and
winterisation guidelines to avoid any possible issues with the machine. Incorrect storage can lead
to possible fueling or engine issues that will not be covered by the warranty.
Allow the engine to fully cool down.
1
Drain all the fuel from the fuel tank and then run the machine until it has completely run out of
fuel to clear the remaining fuel from the fuel lines and carburettor.
2
Follow the cleaning instructions in the ‘Cleaning’ section.
3
Follow the maintenance section and check, service or replace serviceable items if required.
Visually inspect the machine and replace or repair any worn parts. Check the blade and sharpen
or replace if necessary.
4
Remove the spark plug. Add 1 teaspoon of 2-stroke oil to the combustion chamber. Pull the
starter pull cord several times to wet all mechanical parts with oil. Replace the spark plug.
5
www.hyundaipowerproducts.co.uk 01646 687 880
Maintenance
Preparation To Re-Use
Remove the spark plug.
1
Pull the starter pull cord quickly in order to remove any excess oil from the combustion chamber.
2
Clean the spark plug and observe the correct electrode gap on the
spark plug.
3
39
Fill the fuel tank.
4
Whenever the machine is to be handled, lifted, transported or tilted, you must:
Transportation
Wear sturdy work gloves.
1
Hold the machine at the points that offer a safe grip, taking into account the weight and
relative distribution of the same.
2
Use an appropriate number of people for the weight of the machine and the characteristics of
the vehicle or the place where it must be placed or collected.
3
You must make sure that machine movements to not cause petrol leaks, damage or injuries.
4
During transport, make sure to fasten the machine securely with cables or straps.
5
Always use the protective cases and ensure that the machine cannot switch on during transport.
Always carry the machine with the sharp parts facing away from your body.
6
www.hyundaipowerproducts.co.uk 01646 687 880
Maintenance
40
Pole Saw Oil
You can adjust the amount of oil that is applied to the chain by turning this screw. It has 3
positions. The middle is the factory set position. Push and click anticlockwise for more oil.
Push and click clockwise for less oil.
1
Check the oiling system is working by holding and running the saw blade close to a surface.
Oil will be flung off the chain and on to the surface if it is working properly.
2
Pole Saw Chain Sharpening
You can sharpen the chain using the correct tool available at most garden machinery shops.
The round file size is 3/8”. Please follow the instructions that come with the tool.
1
www.hyundaipowerproducts.co.uk 01646 687 880
Maintenance
Air Filter
Remove the cover of the air filter housing.
2
Remove the air filter.
3
Clean the air filter by tapping or blowing it out.
4
Assembly is done in the reverse order.
5
CAUTION - A dirty air filter will restrict the air flow to the carburettor, which will reduce engine
efficiency.
When using the machine in very dusty areas you must clean or replace the air filter more often.
Never operate the machine without the air filter being fitted it can cause damage to the engine
which is not covered by warranty.
!
41
Regular inspection is essential. The air filter must be inspected after every 25 hours of operation
and cleaned if necessary.
1
Spark Plug
For good performance, the spark plug must be properly gapped and free of deposits.
You MUST allow the engine to cool down before carrying out any maintenance.
1
Always use the correct spark plug.
2
Pull off the spark plug connector.
3
Remove the spark plug using the enclosed spark plug spanner.
4
Assembly is done in the reverse order.
5
Electrode gap = 0.6 mm (distance between the electrodes between which the ignition spark is
generated). Check the spark plug for contamination after the first 10 hours of operation and clean
it with a copper wire brush if required. Afterwards, service the spark plug after every 50 hours of
operation.
www.hyundaipowerproducts.co.uk 01646 687 880
Maintenance
42
Lubricating The Chain
Remove the oil filler cap.
1
Fill oil tank with organic chain oil.
2
The chain lubrication can be increased or decreased using the oil adjusting screw.
3
Press and then turn the oil adjusting screw clockwise to decrease the chain lubrication.
4
Press and then turn the oil adjusting screw anticlockwise to increase the chain lubrication.
5
WARNING- Never work without lubricating the chain first. If the saw chain runs dry, the
cutting equipment may become damaged within a short time. Always check chain lubrication
before starting work.
!
Tightening And Checking The Saw Chain
First loosen the cover retaining nut to release the bar. Turn the chain-tensioner screw in a
clockwise direction using the flat-blade screwdriver to increase the tension.
1
The saw chain must lie against the underside of the blade. Check whether the saw chain can
be drawn over the blade by hand.
2
WARNING- Wear protective gloves. There is a danger of injury from the sharp cutting teeth. A
new saw chain stretches and must be tightened more frequently.
!
A new saw chain stretches and must be tightened more frequently.
3
www.hyundaipowerproducts.co.uk 01646 687 880
Maintenance
43
Where necessary, all corrective actions should be carried out by a suitably qualified person.
Appliance
Part
Before
Starting Work
Weekly In The Event
Of Faults
In The Event
Of Damage
As
Required
Lubricating
The Chain
Check
Check Saw
Chain
1. Check The
Sharpness
2. Check
Chain
Tension
Sharpen
Check Guide
Rail
1. Check for
wear/damage
1. Clean and
turn
2. Deburr
Clean and turn Replace Replace
Check
Sprocket
Replace Replace
Maintenance Schedule
The figures given here are based on normal operating conditions. In the event of more difficult
conditions, such as strong dust generation and longer daily operating hours, the given intervals
are to be reduced correspondingly.
Problem Possible Cause Possible Solution
The engine does not start. Incorrect start-up process. Follow the instructions
regarding starting.
The engine starts but does not
run at full power.
1. Incorrect adjustment of the
choke lever.
2. Contaminated air filter.
1. Set the choke lever to
2. Clean air filter.
The engine does not run
smoothly.
Incorrect spark plug cap. Clean the spark plug and
adjust the spark plug gap or
replace the spark plug.
Soot deposits or wetness on
the spark plug.
Incorrect carburetor
adjustment.
Adjust the carburetor. Contact
aftersales.
Problem Possible Cause Possible Solution
Motor is running, saw chain
does not move.
Pole pruner attachment is not
connected properly to the
engine unit.
Check assembly.
Saw chain running slowly. Saw chain dry/over-heating or
is sagging.
Top up the oil or regrind,
replace or tighten the saw
chain.
Engine Unit Troubleshooting
Troubleshooting
www.hyundaipowerproducts.co.uk 01646 687 880
44
Technical Data
Engine Specifications
Engine Type 2-Stroke Engine, Air-Cooled
Engine Output (Max.) 1.45kW / 2.0hp
Engine Size 51.7cc
Engine Idle Speed 3000rpm
Engine Speed (Max.) With Chainsaw : 9200rpm
With Hedge Trimmer : 9200rpm
Max. Cutting Speed With Chainsaw : 20m/s
With Hedge Trimmer : 1550rpm
Ignition Electronic
Drive Centrifugal Clutch
Weight (Power Unit Empty Tank) Approx. 5.6kg
Fuel Tank Capacity 1200cm³
Spark Plug CDK L8RTC
Fuel Consumption At Max. Engine
Performance
0.6kg/h
Specific Fuel Consumption At Max. Engine
Performance
446g/kWh
Oil Tank Recommended Fill Level 140cm³
Cut Length Approx. 260mm
Blade 10 inch
Saw Chain 10 inch
Pole Pruner Specifications
www.hyundaipowerproducts.co.uk 01646 687 880
45
Technical Data
Noise Information
Hedge Trimmer Pole Pruner
Sound Pressure Level LpA 99.47dB(A) 99.5
Uncertainty KWA 2.5dB 2.5
Sound Power Level LWA 110.05dB(A) 111.54
Guaranteed Sound Power
Level LWA
114dB(A)
Uncertainty KWA 2.5dB 2.5
Vibration Information
Pole Pruner
Vibration On Front Handle Vibration
Emission Value
a = 7.41m/s²
Uncertainty K = 1.5m/s²
Vibration On Rear Handle Vibration
Emission Value
a = 7.993m/s²
Uncertainty K = 1.5m/s²
h,D
h,D
The vibration level varies in accordance with use and may be higher than the value specified in
these instructions in some cases. There is a risk of underestimation of the vibration load ii the
appliance is used regularly in this manner. To estimate the vibration load during a spe cific
working period accurately, periods during which the appliance is switched off (or running, but not
being used) must also be taken into account. This can significantly reduce the vibration load over
the total working period.
www.hyundaipowerproducts.co.uk 01646 687 880
46
Recycling And Disposal
We do not offer a takeback scheme for the recovery of Waste Electrical Electronic
Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or
Batteries is passed onto you by us.
So when it becomes necessary to dispose of your machine you must take it to your
local Civic Amenity Site. For further information please contact your local Authority
for disposal advice.
You MUST make sure that all unused oil and fuel is disposed of correctly either beforehand
or at your local Civic Amenity Site.
• Under NO circumstances must any fuel or oil be put down any drains.
• Certain products contain WEEE waste which should not be disposed of in your domestic waste.
• You MUST recycle WEEE in accordance with your local authority or recycling centre.
• Certain products contain batteries which should not be disposed of in your domestic waste.
• You MUST recycle batteries in accordance with your local authority or recycling centre.
• Unwanted packaging and materials should be stored and taken to a recycling centre so it can
be disposed of in a manner which is compatible with the environment.
We are a Member of the VALPAK National Compliance Scheme and our registration number is
RM08660. For further information about disposal please contact your Local Authority.
You can also get more advice and guidance about recycling at the following website
http://www.recycle-more.co.uk
Should you pass this product on to another user either sold or loaned, you MUST pass on this
user manual. This will make sure that all other users can use and maintain this machine safely.
1. Environmental protection should be a priority of considerable importance when using the
machine, for the benefit of both social coexistence and the environment in which we live. Try not
to cause any disturbance to the surrounding area.
2. You must comply with local regulations and provisions for the disposal of packaging, oils,
petrol, filters, damaged parts or any elements which have a strong impact on the environment.
This waste must not be disposed of as normal waste. It needs to be separated and taken to
specified waste disposal centres where the material will be recycled.
3. You must comply with local regulations for the disposal of waste materials after mowing.
4. When disposing, do not pollute the environment with the machine, but hand it over to a
disposal centre, in accordance with the local laws in force.
Recycling And Disposal
Environmental Protection
www.hyundaipowerproducts.co.uk 01646 687 880
48
Useful Information
Check Out Our YouTube Channel
Our videos on YouTube include:
• Unboxing
• Assembly of your machine
• How to service your machine
• Products in use
• ‘How To’ videos
• Product features
Go to www.hyundaisupport.co.uk or search ‘Hyundai Power Products’ in YouTube.
Warranty
Proof of purchase will be required before you make a warranty claim.
Full warranty terms and conditions can be found on the HYUNDAI POWER PRODUCTS website:
www.hyundaipowerproducts.co.uk
Manual Updates
Our manuals are constantly being reviewed and updated. Should you find an error, omission or
something unclear, please contact us for assistance.
We reserve the right to make any modifications without prior notice whenever necessary.
Our latest manuals are also placed online.
All our manuals can be downloaded at: www.hyundaipowerproducts.co.uk
Returning Your Product
If you are returning your product, please contact the dealer for their returns policy.
Leaving A Review
We work very hard to give all of our customers the best possible service. If you have any
problems, before leaving negative feedback, please contact us to give us a chance to resolve the
issue. We would be delighted if you left us positive feedback!
To leave a review, please go to: uk.trustpilot.com/review/hyundaipowerequipment.co.uk
Ordering Spare Parts
Only use original spare parts: The use of non-original and/or incorrectly fitted parts will jeopardize
the safety of the machine, may cause accidents or personal injuries for which the Manufacturer is
under no circumstance liable or responsible.
www.hyundaipowerproducts.co.uk 01646 687 880
Generators
Leisure Inverter, Petrol, Diesel And Built-In
Motorhome Generators
Pressure Washers
Petrol, Diesel And Electric Pressure Washers
Water Pumps
Submersible, Clean And Dirty Water And
Professional Chemical Water Pumps
Lawnmowers
Petrol, Cordless, Electric, Roller, Self Propelled,
Electric Start And Robotic Lawnmowers
Grass Trimmers And Brush Cutters
Petrol, Cordless, Electric And Wheeled Grass
Trimmers And Brush Cutters
Chainsaws
Petrol, Cordless And Electric Chainsaws
Hedge Trimmers
Petrol And Cordless Hedge Trimmers
Leaf Blowers
Petrol, Electric, Cordless, Backpack And 3 -in-1
Leaf Blowers
Log Splitters
Horizontal, Vertical, Petrol And Electric Log
Splitters
Wood Chippers
Petrol And Electric Start Wood Chippers
Tillers
Petrol Garden Tiller And Cultivator
Earth Augers And Trenchers
Petrol Earth Augers And Heavy Duty Trenchers
Compactor Plates
Petrol Compactor Plates
Cement Mixers
Portable Electric Cement Mixers
If you would like more information on any of
these products, please contact our sales team
on 01646 687880 or visit our website
www.hyundaipowerproducts.co.uk
Mini Dumpers
4-Wheel Drive Mini Dumpers And Tracked
Dumpers
Yard Sweeper
Self Propelled Yard Sweeper Power Brush
Scarifiers
Petrol Lawn Scarifier And Aerator
Stump Grinders
Petrol 4-Stroke Stump Grinders
Welders And Plasma Cutters
MIG, TIG, MMA, ARC Welders And Plasma Cutters
Power Tools And Tool Chests
Electric And Cordless Power Tools And Filled Tool
Chests
Vacuum Cleaners
Wet And Dry Vacuum Cleaners
Engines
Petrol And Electric Start Engines
Battery Chargers / Starters
6V, 12V, 24V Battery Chargers, Jump Starters And
Hydraulic Floor Jack
Air Compressors
Home, Domestic, DIY And Professional Use Air
Compressors
Lighting Towers
Mobile Lighting Towers With Diesel Generators
Portable Power Stations
Camping Power Packs And Solar Chargers
And More
We Are Constantly Expanding Our Range With
New Products
Our Product Range
49
50
Product Information
Date Of Purchase: ........................................................................................................................
Dealer Name:.................................................................................................................................
Dealer Phone:................................................................................................................................
Model Number:.............................................................................................................................
Serial Number:..............................................................................................................................
As soon as you have purchased the machine, we recommend that you fill out the
following. If you need to contact an authorised dealer or customer service for
information on servicing, you may need to provide the following information.
The model number and serial number can be found on the grey specification sticker on
your machine.
1st Service
Date Of Service..............................
Next Service Due...........................
2nd Service
Date Of Service..............................
Next Service Due...........................
3rd Service
Date Of Service..............................
Next Service Due...........................
4th Service
Date Of Service..............................
Next Service Due...........................
Information
Service Record
www.hyundaipowerproducts.co.uk 01646 687 880
Need Help? Talk To Our Experts
Contact Us
Our friendly aftersales team will be more than happy to help you.
Phone
Call our team on 01646 687880, open Monday-Friday 8.30am-5pm.
Email
Online Live Chat
Go to www.hyundaipowerproducts.co.uk
Live chat is open Monday-Friday from 8.30am-5pm.
Post
Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK.
51
www.hyundaipowerproducts.co.uk 01646 687 880
Importer:
GENPOWER LTD
Isaac Way, London Road,
Pembroke Dock, UNITED KINGDOM, SA72 4RW
T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198
www.hyundaipowerproducts.co.uk
Imported/Distributed by Genpower Ltd for The United Kingdom & Ireland
Licensed by Hyundai Corporation, Korea
