QUICK REFERENCE GUIDE > CPV3-486GD N Date: 07.04.2022 > 1
Gas Rangetop, 48", Griddle
Series 9 | Professional
Stainless Steel | Natural gas
A powerful six burner rangetop with Professional styling and the
additional cooking flexibility of a stainless steel griddle.
Griddle with burners that deliver up to 23,500 BTU heat per
burner, for seriously fast boiling
Continuous surface grates designed for pots and pans to move
safely across the cooktop
The stainless steel griddle is great for cooking anything from
grilled cheese to quesadillas
Made from quality materials and real stainless steel
DIMENSIONS
Height
8 5/16"
Width
47 7/8"
Depth
28"
FEATURES & BENEFITS
COOKTOP POWER
Sealed Dual Flow Burners™ deliver rangetop power up to 23,500
BTU for seriously fast boiling right down to a precise 140°F full
surface simmer with the gentlest of flames.
PRECISE CONTROL
From the highest to the lowest temperatures you get total
control with halo-illuminated rangetop dials. A precise full
surface simmer is delivered across all burners.
COOKING FLEXIBILITY
The continuous surface grates are designed for pots and pans to
move safely across the rangetop. The deep-platform style grates
provide full coverage so heat goes directly onto the pot, for a
faster boil.
EASY TO CLEAN
These rangetops are easy to clean with sealed burners and a
continuous, porcelain basepan.
INFORMATION AT A GLANCE
LED halo control dials provide information at a glance and assist
in alerting you if any burners are accidentally left on.
DESIGN QUALITY
This rangetop is built to last with craftsmanship in every detail,
featuring real stainless steel, cast-iron trivets, and titanium
coated dials.
SPECIFICATIONS
Burner ratings
Max burner power 23500BTU
Power back centre 18500BTU
Power back left 18500BTU
Power back right 18500BTU
Power front centre 18500BTU
Power front left 23500BTU
Power front right 18500BTU
Power griddle 18000BTU
Total cooktop power 134000BTU
Cleaning
Easy clean porcelain basepan •
Controls
Metal illuminated dials •
Star K Certification •
Gas Requirements
Fitting and pipe ½ NPT, min. ⅝" flex line
Supply Pressure (natural gas) 6" to 9" W.C
Performance
Sealed Dual Flow Burners™ 6
Sealed range top •
Simmer on all burners 140°F
Power requirements
Amperage 15A
Supply frequency 60Hz
