For domestic household use
only.
INSTRUCTION MANUAL
96cm DC Tower Fan
Model: DCTF96WT
IMPORTANT
THESE INSTRUCTIONS SHOULD BE READ CAREFULLY
AND RETAINED FOR FUTURE REFERENCE.
Note also the information presented on the appliance
CAUTION: FAILURE TO FOLLOW THESE INSTRUCTIONS MAY
CAUSE INJURY AND/OR DAMAGE AND MAY INVALIDATE
YOUR WARRANTY
Please read the operating instructions carefully before using your
fan for the first time and keep them in a safe place.
WARNING – This appliance must not be used in a bathroom.
WARNING – Do not use this appliance in the immediate
surroundings of a bath, a shower or a swimming pool.
• If the mains lead is damaged it must only be replaced by the
manufacturers service agent or a similarly qualified person in
order to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• Children should be supervised to ensure they do not play with
the appliance.
• Never immerse the appliance in water or other liquids.
• Operate this unit only on a firm, flat surface.
• Do not place on soft, unstable or non-horizontal/angled
surfaces.
• Never operate the appliance if a cable or connector has been
damaged, after appliance malfunction or if the appliance was
dropped or is otherwise damaged.
• Please ask a professional service agent to repair the product.
Improper repair may cause danger to users.
• Disconnect the appliance from mains power whenever it is not
in use, before relocating it, and before cleaning.
• Operate the appliance only at the voltage specified on the
2
rating label.
• Only connect the unit to a properly installed and easily accessible
socket so that you can quickly disconnect the plug if necessary.
• Do not connect this product to the mains using an extension
lead.
• This fan is only intended for INDOOR RESIDENTIAL applications.
This fan should not be used for commercial or industrial or
leisure applications or in small enclosed spaces.
• Never use the mains lead as a carrying strap or pulling lead.
• To avoid a fire or electrocution hazard, NEVER put the cord
near heat registers, radiator, stoves or heaters.
• DO NOT cover cord with carpeting, throw rugs, runners, or
similar coverings.
• DO NOT route cord under furniture or appliances. Take care to
position the cord away from traffic areas and where it will not
be a tripping hazard.
• DO NOT use the unit near windows or where water collects.
Rain and water collection may lead to a risk of fire or electric
shock.
• Only operate this appliance with a minimum of 50cm clearance
all around i.e. away from walls, furniture and overhanging
objects such as curtains or a shelf.
• To prevent spillage, empty the water tank before lifting or
relocating the appliance.
• WARNING: To avoid danger of suffocation please remove all
packaging materials particularly plastic and EPS and keep
these away from vulnerable people, children and babies.
• NEVER drop or insert any object or fingers into any openings.
• Do not use the appliance in locations where paint, petrol or
other flammable liquids are used or stored.
• Do not use bug sprays or other flammable cleansers/vapour
sprays on or around the unit.
3
• Always switch off the unit and take the plug out of the socket:
•
If you are not using the unit
•
Before you clean or carry out maintenance on the unit
•
If a fault occurs
•
In the event of an electrical storm.
• Avoid electromagnetic interference. Keep the unit at least 1
metre away from electrical appliances such as televisions &
radios.
• DO NOT use this appliance with an extension lead or power
board.
WARNING - KEEP BATTERIES OUT OF REACH OF CHILDREN
• Swallowing may lead to serious injury in as little as 2 hours or
death, due to chemical burns and potential perforation of the
oesophagus.
• If you suspect your child has swallowed or inserted a button
battery immediately call the 24-hour Poisons Information Centre
on 13 11 26 (in Australia) or 0800 764 766 (in New Zealand) for
fast, expert advice.
• Examine devices and make sure the battery compartment
is correctly secured, e.g. that the screw or other mechanical
fastener is tightened. Do not use if the compartment is not
secure.
• Dispose of used button batteries immediately and safely. Flat
batteries can still be dangerous.
4
Exposed to the
weather outdoors
Near water If the power cable
wires are frayed or cut
Where small children
may be left unattended
No extension
leads or power
boards
Where there is risk
of fire or close to
a naked flame
Where the power
cable may be
damaged
On a slope or
uneven surface
Where it may be
damaged by
chemicals
If there is a risk
of water falling on
the unit
Where there is a risk
of interference by
foreign objects
This product is not
made for DIY repair
5
Model no. DCTF96WT
Colour
White
Power supply
220-240V~ 50Hz
Rated power
25W
Speed settings
15
Modes 3
Timer 0-7hrs
Air speed 14m/s
Oscillating 70-75°
Controls Touch or Remote
Noise level
50-60db(A)
Weight (net) 2.2kg
Dimensions (w x d x h) 260 x 260 x 960mm
Specification
• For greater precision, please always refer to the rating label placed on the product.
6
Parts
Top Control
panel
Air outlet
Base
Front housing
Back housing
7
Assembly
1. Place the two parts of the base together.
2. Line up the Tower Fan with the base.
3. Use the fixed knob to secure the base onto the Tower Fan.
Operation
This tower fan can be operated by the control panel or remote control. Please refer to
the below diagrams and descriptions.
Remote Control
1. Install x1 CR2025 (included) button cell battery into the remote.
2. All remote control buttons are labled as below and function work identically to the
manual controls.
8
Operation
Manual Controls
1.
Place the fan on a stable and flat surface. Plug the cord set into a 220-240V A.C.
electrical outlet.
2.
Turn the fan on by pressing the 'POWER' button. Turn the fan off by pressing the
'POWER' button again.
3.
You can adjust the fan speed to the desired level between 1-15 by pressing the 'SPEED'
button. The speed setting is displayed on the LED panel.
4. You can adjust the fan mode by pressing the 'MODE' button. The three modes are
'natural,' 'normal' and 'sleep.'
5. To set the fans timer, press the 'TIMER' button. This allows you to set the fans length
of operation between 1-7 hours.
6. To make the fan oscillate, press the 'OSC' button. This allows the fan to oscillate up
to 70-75°.
9
Cleaning
Over time, dust can accumulate on the fan grille, which can affect the fans
performance. It is recommended to clean the fan at least once a month.
1. Turn the unit OFF and disconnect the appliance from the power supply.
2. Remove any dust build up with a soft brush.
3. Wipe the surface of the unit with a soft damp cloth. Mild detergent can be used
for any stubborn marks.
Do not use abrasive sponges, scouring pads, or a stiff brush to clean the unit.
IMPORTANT
The control panel and other parts must not come into contact with water or any
other liquids.
Storage
If not using the unit for an extended period of time. After cleaning please:
• Turn the unit off, unplug and take care of the mains lead & plug.
•
Cover the unit and store it upright in a location where it will not receive direct
sunlight. NB- Prolonged exposure to direct sunlight will discolour the enclosure.
10
If the unit fails to operate efficiently, is broken or other problems arise, unplug and
do not operate. Ask for advice by calling your local after sales service agent or the
Customer Care Centre on 1300 556 816 (AU) / 0800 666 2824 (NZ).
Maintenance
Recycling: Do not dispose of electrical appliances as unsorted
municipal waste. Use separate collection facilities. Contact your
local government for information regarding the collection systems
available. If electrical appliances are disposed of in landfills or dumps,
hazardous substances can leak into the ground water, polluting the
food chain and damaging health and well-being.
Warranty
Please refer to the warranty card in the box for warranty information. For any
troubleshooting advice, please contact the relative Customer Care Centre below.
Glen Dimplex Australia Pty Ltd Glen Dimplex New Zealand Ltd
8 Lakeview Drive, 38 Harris Road, East Tamaki,
Scoresby 3179, Victoria Auckland 2013
Australia New Zealand
Ph: 1300 556 816 Ph: 0800 666 2824
