How to Wire and Operate Your Wall Control
WR501WH Wall Control
DESCRIPTION: 3-speed ceiling fan control with light dimmer switch and canopy receiver.
ELECTRICAL SPECS: 120V, 60Hz Ceiling Fan
FAN MODELS USED: most Fanimation fans - see catalog or visit our website, fanimation.com for
more information
SPECIFICATION and INSTRUCTION SHEET
NOTE: If fan or supply wires are different colors than
indicated, have this unit installed by a qualified electrician.
1. If fan and/or light kit are controlled by a pull chain, fan
must be set to high and light kit must be switched on.
2.
Install Receiver in the Hanger Bracket:
• Connect wires using connectors as shown in Figure 1.
• Position all connected wires and receiver antenna to
allow installation of ceiling canopy. (Figure 2)
• Using canopy screws threaded into the hanger bracket
reinstall ceiling canopy.
• Restore electrical power
3.
Dip Switch Set Up (Figure 3)
WARNING
To avoid possible electrical shock, be sure electricity is
Figure 2
Figure 3
Figure 1
NOTE: The remote unit has 32 different code
combinations. To prevent possible interference from or
to other remote units, simply change the combination
code in the remote and receiver.
NOTE: Factory setting is all up. Do not use this position.
• To set the code on receiver unit, slide dip switches to
the same positions as set on the remote.
• To set the remote code with a small screwdriver or
ball point pen (neither included), slide dip switches
firmly up or down to same as receiver unit.
Dip Switch
Dip Switch
AC120V 60HZ
INPUT
WHITE (AC IN N)
BLACK (AC IN L)
BLUE
BLACK
WHITE
BLUE(FOR LIGHT)
BLACK(TO MOTOR L)
WHITE(TO MOTOR N)
BLACK
(ANTENNA)
WHITE
(AC IN N )
BLACK
(AC IN L)
BLACK
(TO MOTOR L)
WHITE
(TO MOTOR N)
BLUE
(FOR LIGHT)
BLACK (AC IN L)
BLACK
BLACK
BLACK (TO MOTOR L)
BLACK (AC IN L)
GROUND WIRE
GREEN / YELLOW
