Model Number:
RHM2565BCG (S)
Family Combination Microwave
User Guide
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
PLEASE RETAIN
FOR FUTURE REFERENCE
Page(s)
Safety instructions
3-9
About your microwave
10-11
Product information
12
Unpacking the microwave
13
Product overview
14
Microwave
oven installation
15-16
Turntable
installation
17-18
Control
panel
19
How to use the microwave
20-31
Cooking tips
32
Cleaning the microwave
33
Problem solving
34-37
Guarantee &
customer services
38
Spare parts
39
Connection to the mains supply
40-41
Notes
42-43
Disposal information
44
CONTENTS
2
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
3
SAFETY INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent
person.
• It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to microwave energy.
• Liquids and other foods must not be heated in sealed
containers since they are liable to explode.
• The appliance and its accessible parts may become hot
during use. Care should be taken to avoid touching
heating elements.
• Do not leave the microwave oven unattended while you
are using it.
• Do not use the microwave when it is empty. This could
damage the oven.
• This appliance is intended to be used in the household
and general domestic applications. It is not intended to
be used in industrial or commercial applications.
4
SAFETY INSTRUCTIONS
WARNING:
• This microwave is intended for heating food and
beverages only. The drying of food or clothing and
heating of warming pads, wheat bags, slippers, sponges,
damp cloth and similar is extremely dangerous and may
lead to risk of injury, ignition or fire.
• Do not use metal pans, dishes with metal handles or
anything with a metal trim inside the microwave. Do not
use paper covered wire twist-ties on plastic bags.
• Never put objects into the openings on the outer case.
• This appliance can be used by children aged from 8 years
and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge,
only if they are being supervised or have been given
instruction in the safe use of the appliance and
understand the hazards involved. Children should not
play with the appliance.
• Food containing a mixture of fat and water (for example,
stock) should stand for 30 to 60 seconds in the oven
after it has been turned off. This is to allow the mixture
to settle and to prevent it from bubbling when a spoon is
placed in it, or a stock cube is added.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
5
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• When heating or cooking food or liquid, remember
that there are certain foods (such as, jam, Christmas
pudding, and mincemeat) which heat up very quickly.
• Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
• The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature must be
checked before consumption, in order to avoid burns.
Do not heat baby bottles with the teat left on.
Remove it if replacing the bottle back into the oven.
• Eggs in their shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
• Do not cook any food surrounded by a membrane, such
as egg yolks, potatoes, chicken livers, sausages,
ready meals and so on without piercing them several
times with a fork.
• Do not try to deep-fry foods in this microwave oven.
• Do not overcook food.
6
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
• If materials inside the oven smoke or catch fire, keep
the oven door closed to stifle the flames, turn the oven
off at the wall switch, or shut the power off at the fuse
or circuit-breaker panel. If smoke is emitted , switch off
or unplug the appliance and keep the door closed in
order to stifle any flames.
• Please remember that as food or liquids heat up,
they will release steam or may be spitting. Never cover
any containers fully, always leave a gap for steam to
escape.
• Do not use plastic containers when heating or cooking
foods that contain a lot of fat or sugar.
• Always have the glass tray and turntable support in
place when using the microwave oven.
• Do not cook food directly on the glass tray. Put food on
a suitable plate or in a bowl before putting it in the oven.
7
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• When using the grill rack and baking tray, be aware that
these will become HOT during cooking as they aren’t
heatproof. Please use suitable oven gloves when
removing these.
• Do not use melamine dishes as they contain a
material which will absorb microwave energy. This may
cause the dishes to crack or burn, and will slow down
the cooking speed.
• Use only cookware and utensils that are approved to use
in a microwave oven.
• Do not use the microwave oven for heating utensils,
plates or dishes.
• Do not cook using a container with a restricted
opening, such as bottles, as they may explode.
• Before you clean your microwave oven, turn it off and
unplug it.
• Keep the inside of the oven clean. When food or
liquids stick to the oven walls, wipe with a damp
cloth. We recommend that you do not use harsh
detergent or abrasives.
8
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• On the right hand wall of the cavity is the wave
guide cover, microwaves are passed through this to
enable your food to cook. It is important that this
wave guide cover is kept clean at all times. To do
this wipe with mild detergent and water, then dry.
• The oven should be cleaned regularly and any food
deposits removed. Failure to maintain the oven in a
clean condition could lead to deterioration of the
surface that could adversely affect the life of the
appliance and possibly result in a hazardous situation.
• You should clean the outside of the oven with a
damp cloth. Do not allow water to seep into the
ventilation openings.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
• If steam builds up inside or around the outside of the
oven door, wipe with a soft cloth. This may happen
when the microwave oven is used in humid conditions.
9
SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
WARNING:
• Regularly remove the glass turntable to clean it, wash
it in warm soapy water or a dishwasher. Regularly
clean the turntable support and oven floor. Simply
wipe the bottom surface of the oven with mild
detergent and water, then dry. You can wash the
turntable support in mild soapy water.
• Failure to maintain the oven in a clean condition,
especially if liquid is left under the turntable, could lead
to deterioration of the surface that will adversely affect
the life of the appliance that may result in a
hazardous condition.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
ABOUT YOUR MICROWAVE
10
Thank you for purchasing your Russell Hobbs microwave oven.
This stylish large capacity 25 litre Russell Hobbs Microwave features
a sleek and modern design with a mirror finish door. It combines
microwave cooking with grill power and convection oven enabling
you to cook a variety of dishes with just one appliance.
First, all you need to do is to pick the perfect spot on your
countertop, then, follow the simple steps for installation, and
within minutes you’re ready to start cooking. Cooking meals for
family and friends or reheating large plates of food becomes simple
and easy with 900 watts of microwave power and 10 auto cook
menus.
The true fan assisted oven acts exactly the same as a conventional
oven which gives you the option of an extra cooking facility, for
large dinner parties and family gatherings. The combination aspect
enables you to combine microwave energy, a grill, and convection
heating (fan assisted) so you can heat, roast, crisp and brown. This
is ideal for cooking lasagnes, pizzas, baked potatoes and cottage
pies.
For added peace of mind, this microwave enables a child lock to be
set, meaning cooking cannot be started or interrupted. Cleaning is
straight forward, simply wipe the exterior, interior and wave guide
cover with a damp soft cloth to maintain peak performance.
ABOUT YOUR MICROWAVE
How do microwaves work?
Microwaves are high-frequency electromagnetic waves similar to
radio waves. While radio waves may vary in length from one metre
to many kilometres, microwaves are very short (less than 12.5
centimetres.)
Microwaves do not make any heat themselves but cause water
molecules in the food to vibrate.
This vibration produces heat that cooks the food. This is why your
food will come out of the microwave piping hot, while your utensils
inside the oven stay much cooler. The microwaves do not stay in the
air or in the food when you open the microwave oven door.
The microwave oven will work using an ordinary household
electrical socket. Inside the microwave oven is the magnetron,
which turns the electrical energy into microwaves.
Microwaves cannot travel through metal, so the inside of the oven
is lined with metal. The door is lined with a fine metal mesh which
stops microwaves getting through. This means that when the
microwave oven door is shut, there is no possibility that the
microwaves can be released.
11
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
12
PRODUCT INFORMATION
Model number RHM2565BCG (S)
Rated Voltage 230-240V ~ 50Hz
Rated Output Power (Microwave
)
850 - 900W
Rated Power (Grill) 1050 - 1100W
Rated Power (Convection) 2300 - 2500W
Imported by:
G2S Limited
Wigan
WN2 4AY
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
UNPACKING THE MICROWAVE
Before you use your microwave oven
1. Remove all the packaging. Do not remove the small piece of card
from the right hand side of the cavity wall (refer to the below
image). This is called a wave-guide cover which allows the
microwaves to pass through to cook the food.
Please ensure you keep this cover clean at all times by wiping it
with a damp cloth. Do not remove/place it in a dishwasher.
2. Check the oven after unpacking for any visual damage such as:
● A misaligned door
● Damage to the door
● Dents or holes in the door window and screen
● Dents in the inside
If you can see any damages do not use the oven, please contact
Product Care at www.productcare.co.uk or call 0345 209 7461.
This microwave oven weighs approximately 18.3Kg so you must put
it on a horizontal surface that is strong enough to support this
weight.
The oven must be placed away from high temperature and steam.
Do not put anything on the top of the microwave oven.
13
1. Safety interlock latches
2. Microwave window
3. Ventilation slots
4. Oven cavity
5. Turntable ring
6. Turntable coupling
7. Glass turntable
8. Waveguide cover
9. Control panel
14
PRODUCT OVERVIEW
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
1
2
3
4
5 6 7
8
9
Round Baking Tray with Handle Grill Rack
Grill Rack & Baking Tray to be used for grilling & convection cooking only.
CAUTION: GRILL RACK AND BAKING TRAY WILL BE HOT AFTER COOKING.
PLEASE WEAR OVEN GLOVES
15
MICROWAVE OVEN INSTALLATION
• Place the oven as far away from radios and televisions as
possible. Using the oven may cause interference with the
reception.
• Plug the oven into a suitable 13 amp mains socket, make
sure the voltage is the same as on the rating label (do not use
extension cables or mains socket adaptors.)
• The microwave oven should be used freestanding only and must
not be built-in or used in a cabinet.
• Select a level surface that provides enough space for the outlet
vents.
16
MICROWAVE OVEN INSTALLATION
DO NOT obstruct
the ventilation
from the microwave
30cm
0cm
20cm
20cm
Min85cm
WARNING:
DO NOT install the oven over a cooker or other heat or steam
producing appliances as this will damage the microwave oven.
The minimum installation height is 85cm.
A minimum clearance of 20cm is required between the oven and
the side walls and 0cm between the oven and the back wall. Leave
a minimum clearance of 30cm above the oven.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
STEP 1) The turntable coupling should slot into the centre of microwave
STEP 2) T he turntable ring slots into the indents in the middle
STEP 3) The glass tray indents fit around the turntable coupling
17
TURNTABLE INSTALLATION
• Before first use, check that any securing tape and all packaging
has been removed from the glass tray and turntable ring
assembly.
• These parts must never be restricted from rotating.
• Never place the glass tray upside down.
• To assemble the turntable, follow the steps below in numerical
order.
18
TURNTABLE INSTALLATION
The glass tray, turntable ring, and turntable coupling assembly
must always be used during cooking (as shown below).
• Do not place the food directly onto the glass tray, always place
on or in a suitable microwaveable cookware.
Please check that crockery is microwave safe before using.
• If the glass tray or turntable ring assembly has been
damaged in any way, contact Product Care using the below:
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
19
CONTROL PANEL
SCREEN DISPLAY
Cooking time, power, action indicators, and
clock time are displayed.
MICROWAVE/GRILL/COMBI./CONVE.
Press this button to use the microwave function, grill
function, combination function and convection
function.
WEIGHT/TIME DEFROST
Press this button for the defrost function.
STOP/CLEAR
Press the Stop/Clear button twice to clear
everything.
CLOCK/TIMER
Press this button to set the clock.
START/+30 SEC/CONFIRM
Press this button to start the cooking process.
TIMER/WEIGHT/AUTO MENU
This rotational dial is used for a number of functions
including the auto cook menus.
20
HOW TO USE THE MICROWAVE
Turn on the power
Insert the plug into a suitable 13amp mains socket.
Note: Make sure the voltage is the same as on the rating label located on
the back of the microwave (do not use extension cables or mains socket
adaptors.)
The microwave oven will flash and beep. The oven will display "0:00"
Setting the clock (24 hour)
When the microwave oven is first turned on, the oven will display "0:00", the
buzzer will ring once.
1) Press “CLOCK/TIMER” button to choose hours or minutes for alteration.
The hour figures will flash. When altering the hours the ‘’00’’ on the left hand
side will flash.
2) Turn the “TIMER/WEIGHT/AUTO MENU” dial to adjust the hour figures,
the input time should be within 00 – 23 (this is a 24-hour clock).
3) Press "CLOCK/TIMER“ button again and the minute figures will flash.
4) Turn the “TIMER/WEIGHT/AUTO MENU” dial to adjust the minute figures,
the input time should be within 00 - 59.
5) Press "CLOCK/TIMER" button to finish the clock setting procedure. The ":"
will then flash.
Note:
During the process of clock setting, if you press the "STOP/CLEAR“ button, the
clock will return to the previous setting.
Using the Kitchen Countdown Timer
1) Press the “CLOCK/TIMER” button twice, “00:00” will be displayed.
2) Turn the “TIMER/WEIGHT/AUTO MENU” dial to select the desired time.
The input time is between 0:05 – 95:00.
3) Press the “START/+30 SEC/CONFIRM” button to start the timer. The time
will count down without activating the microwave power.
21
HOW TO USE THE MICROWAVE
Microwave cooking
Once you have correctly installed the unit, turned on the power and set the
clock, you are ready to start cooking.
Your microwave has 5 power levels, the lowest at 10%, then 30%, 50%, 80%,
up to 100% (or full power.)
Most recipes are cooked on full power – this should be indicated on the
packaging of microwavable food.
1. To select a power level, press the “MICROWAVE/GRILL/COMBI./CONVE.”
button.
2. Turn the “TIMER/WEIGHT/AUTO MENU” dial clockwise to select the
microwave power. "P100", "P80","P50", "P30","P10"will be displayed.
3. Press “START/+30SEC/CONFIRM” to confirm.
4. Turn the “TIMER/WEIGHT/AUTO MENU” dial to adjust the cooking time.
The time setting should be set between 0:05- 95:00.
5. Press “START/+30 SEC./CONFIRM” button to start the cooking process.
The maximum cooking time is 95 minutes. To add more time during cooking,
simply press the “START/+30 SEC/CONFIRM” button.
Do not operate the oven empty, this can cause irreparable damage.
Pausing cooking
If you want to pause the cooking to turn over or stir the contents, simply open
the door, then close again and press the “START/+30SEC/CONFIRM” button to
continue the cycle.
If you wish to stop cooking with time left on the display, take out the
contents, close the door and press the “STOP/CLEAR” button once to clear.
Press power
button
Cooking power
Equivalent
power
rating
P100 100% 900W
P80 80% 720W
P50 50% 450W
P30 30% 270W
P10 10% 90W
22
HOW TO USE THE MICROWAVE
Grill cooking
Note:
This function is only recommended for browning food as it is not as powerful
as a household grill. The grill element should be preheated to ensure
optimum operation and cooking. The recommended preheat time is 10-15
minutes. To preheat simply run the microwave on grill setting using the steps
shown below for the desired preheat time.
A grill rack has been provided for use in the microwave when using the grill
function. This can be used on either side for grilling closer to or further away
from the element.
1. Keep pressing the “MICROWAVE/GRILL/COMBI./CONVE.” button till “G-1”
is displayed on the screen.
2. Press “START/+30 SEC./CONFIRM” button to confirm the grill function.
3. Turn the “TIMER/WEIGHT/AUTO MENU” dial to adjust the cooking time.
The time setting should be between 0:05- 95:00.
4. Press “START/+30 SEC./CONFIRM” button to start the cooking process.
Note:
Half way through the grill time, the unit will pause and sound twice to tell
you to turn the food over (if possible.) In order to achieve more even grilling,
you should turn the food over, close the door, and then press “START/+30
SEC./CONFIRM” to continue cooking. If the food is not turned, the oven will
continue cooking without interruption.
COMBINATION COOKING (MICROWAVE + GRILL + CONVECTION)
Combination cooking enables you to combine microwave energy, a grill
and convection heating (fanned hot air) so you can heat, roast, crisp and
brown.
Which function shall I use?
C-1 Method: Microwave & Convection.
This is for when you would heat food quickly in the microwave, but give an
oven/baked finish. For example, heating lasagne: the lasagne is cooked
quickly in the microwave, but partially cooked in convection mode.
C-2 Method: Microwave & Grill.
This is for when you would cook food quickly using the microwave
function, but want a crisp grilled result. For example, a jacket potato: the
potato is cooked using the microwave but grilled for a crisp skin, giving an
oven result.
C-3 Method: Grill & Convection.
You would use this method as you would use your household oven to cook
food, but also give a grilled finish. For example, Pizza: the convection mode
creates a crisp pizza, and grills cheese for a better result.
C-4 Method: Microwave, Grill & Convection.
This is for when you would heat food quickly in the microwave, but give an
oven/baked finish. For example, cottage pie: the cottage pie is cooked fast
in the microwave, but partially cooked in convection mode and grilled.
23
HOW TO USE THE MICROWAVE
24
COMBINATION COOKING (MICROWAVE + GRILL + CONVECTION)
Combination function/program table
For the various settings the cooking time is divided as below:
Please note the wattage, temperatures and duration of the functions
cannot be adjusted, as these are pre-set into the appliance. If you wish
to set the wattage, temperature and duration of the microwave, grill and
convection functions in combination, please use the multistage cooking
function that is detailed on page 27.
Microwave Grill Convection
C-1
900W 165
℃
48% 52%
C-2
900W 165
℃
48% 52%
C-3
200
℃
200
℃
50% 50%
C-4
900W 200
℃
200
℃
16% 42% 42%
HOW TO USE THE MICROWAVE
25
HOW TO USE THE MICROWAVE
Convection cooking (With preheating function)
The convection cooking allows you to cook food using the unit as a
traditional oven; the microwave function is not used. It is recommended
that you preheat the oven to the appropriate temperature before placing
the food in the oven.
1. Keep pressing the “MICROWAVE/GRILL/COMBI./CONVE.” button till the
cooking temperature of “150°C” display and flash.
2. Turn “TIMER/WEIGHT/AUTO MENU” dial to select the desired
convection function temperature. Note: The temperature can be set
between 150°C to 240°C, in 10 degree intervals.
3. Press the “START/+30 SEC./CONFIRM” button to confirm the chosen
temperature.
4. Press the “START/+30 SEC./CONFIRM” button to start preheating. When
the preheating temperature is reached, the buzzer will sound twice to
remind you to place the food in the oven. The preheated temperature will
display and flash. Open the door and place the food in the microwave oven,
then close the door.
5. Turn “TIMER/WEIGHT/AUTO MENU” dial to adjust the cooking time. The
maximum time available is 95 minutes.
6. Press the “START/+30 SEC./CONFIRM” button to commence cooking.
Note:
• The cooking time cannot be entered until the preheating temperature is
reached. Once the temperature is reached, the door must be opened to
input the cooking time.
• If the time is not entered after 5 minutes of reaching the temperature,
the oven will stop preheating. The buzzer will sound five times and turn
back to the waiting state.
26
HOW TO USE THE MICROWAVE
Convection cooking (Without preheating function)
The convection cooking allows you to cook food using the unit as a
traditional oven when the microwave function is not used. It is
recommended that you preheat the oven to the appropriate temperature
before placing the food in the oven. However if you want to start cooking
without preheating the oven please follow the below steps and be aware
that the cooking time of the food will have to be extended:
1. Keep pressing the “MICROWAVE/GRILL/COMBI./CONVE.” button till the
cooking temperature of “150°C” display and flash.
2. Turn “TIMER/WEIGHT/AUTO MENU” dial to select the desired
convection function temperature. Note: The temperature can be set
between 150°C to 240°C, in 10 degree intervals.
3. Press the “START/+30 SEC./CONFIRM” button to confirm the chosen
temperature.
4. Turn “TIMER/WEIGHT/AUTO MENU” dial to adjust the cooking time. The
maximum time available is 95 minutes.
6. Press the “START/+30 SEC./CONFIRM” button to commence cooking.
27
HOW TO USE THE MICROWAVE
Multi-stage cooking
Two cooking stages can be set in sequence.
If one of your required cooking stages is for defrosting, make sure this is
programmed to come on first.
The buzzer will ring once after each stage and then the next stage will
proceed.
Note: The Auto menu or the pre-heating functions cannot be set as part of
the multi-stage cooking sequence.
For example, if you want to defrost the food for five minutes, then cook
with 80% microwave power for 7 minutes:
1. Press the “WEIGHT/TIME DEFROST” button twice and the screen will
display "d-2“.
2. Turn the “TIMER/WEIGHT/AUTO MENU” dial to adjust the defrost time
to 5 minutes.
3. Press the “MICROWAVE/GRILL/COMBI./CONVE.” button once.
4. Turn the “TIMER/WEIGHT/AUTO MENU” dial to choose 80% microwave
power till "P80" is displayed (refer to earlier instructions for power levels.)
5. Press the “START/+30SEC./CONFIRM” button to confirm.
6. Turn the “TIMER/WEIGHT/AUTO MENU” dial to adjust the cooking time
to 7 minutes.
7. Press “START/+30SEC./CONFIRM” to commence cooking.
28
HOW TO USE THE MICROWAVE
Quick Start cooking
One of the quickest ways to start microwave cooking is by using the
“+30SEC.” function.
1. Press the “START/+30SEC./CONFIRM” button to cook with 100% power
level for 30 seconds. Each press on the same button increases the cooking
time by 30 seconds. The maximum cooking time is 95 minutes.
2. During the microwave cooking process, press the
“START/+30SEC./CONFIRM” button to cook with 100% power level for 30
seconds. Each press of the button increases the microwave cooking time by
30 seconds.
Note: This function does not work for defrost and auto menu cooking.
Defrosting by Weight
1. Press the “WEIGHT/TIME DEFROST” button once and the oven will
display “d-1”.
2. Turn the “TIMER/WEIGHT/AUTO MENU” dial to select the weight of the
food. At the same time, “100g” will illuminate in red.
The weight should be set between 100g - 2000g.
3. Press the “START/+30SEC./CONFIRM” button to start defrosting.
Defrosting by Time
1. Press “WEIGHT/TIME DEFROST” button twice and the oven will display
“d-2”.
2. Turn the “TIMER/WEIGHT/AUTO MENU” dial to select the cooking time.
The maximum time is 95 minutes.
3. Press “START/+30SEC./CONFIRM” button to start the defrosting process.
29
HOW TO USE THE MICROWAVE
Auto Menu
1. Turn the “TIMER/WEIGHT/AUTO” dial clockwise to choose the required
function. "A1","A2","A3"...."A10" will display and flash. An Auto Menu
cooking guide is on the following page.
2. Press the “START/ +30 SEC./CONFIRM” button to confirm the menu you
require.
3. Turn the “TIMER/WEIGHT/AUTO MENU” dial to choose the weight of the
food or the quantity of food, (if weight is required the “g” or grams indicator
will illuminate).
4. Press “START/ +30 SEC./CONFIRM” to commence the cooking process.
Note: When you select “A-8” for cake, please do not put the cake mix into
the oven immediately. Follow the pre-heating instructions ( refer to page 25)
and the over will be pre-heated to 180 degrees.
After several minutes, the buzzer sounds twice to remind you to put the cake
into the oven. After putting the cake in the oven, please press “START/ +30
SEC./CONFIRM” to start again.
30
HOW TO USE THE MICROWAVE
Display Weight (g) Power Setting
A1 – Auto Reheat
150g 150
100%
250g 250
350g 350
450g 450
600g 600
A2 - Potato
1 1 (approx. 230g)
100%2 2 (approx. 460g)
3 3 (approx. 690g)
A3 - Meat
150g 150
100%
300g 300
450g 450
600g 600
A4 - Vegetable
150g 150
100%350g 350
500g 500
A5 - Fish
150g 150
80%
250g 250
350g 350
450g 450
650g 650
A6 - Pasta
50g 50 (add 450ml of water)
80%100g 100 (add 800ml of water)
150g 150 (add 1200ml of water)
A7 - Soup
200g 200ml
100%400g 400ml
600g 600ml
A8 - Cake 475g 475
Pre-heat to 180
degrees
A9 - Pizza
200g 200
C-4300g 300
400g 400
A10 - Chicken
500g 500
C-4
750g 750
1000g 1000
1200g 1200
31
HOW TO USE THE MICROWAVE
Child lock function
The child lock function is ideal to stop children from altering cooking times if
unsupervised. No buttons will function in this mode.
To set the lock, in waiting state, press “STOP/CLEAR” for 3 seconds, there
will be a long ‘beep’ as the lock activates, and a red key will illuminate on
the display.
The lock is now functional.
To cancel the lock, press “STOP/CLEAR” for 3 seconds, there will be a long
‘beep’ signalling that the lock is cancelled, and the lock symbol will
disappear.
Utensil information
• Do not use metal pans or dishes with metal handles.
• Do not use anything with a metal trim.
• Do not use paper-covered wire twist-ties on plastic bags.
• Do not use melamine dishes as they contain a material which will
absorb microwave energy. This may cause the dishes to crack or burn,
and will slow down the cooking speed.
• Use only cookware that is approved to be used in a microwave oven.
• Do not cook using a container with a restricted opening, such as bottles,
as they may explode.
• Do not heat baby bottles with the teat left on. Remove before placing
the bottle back into the oven.
• Only use thermometers that are approved for microwave ovens.
• Do not use the microwave oven for heating utensils.
General information
• The “START/+30SEC/CONFIRM” button must be pressed again to
continue cooking if the door is opened during a cooking cycle.
• Once the cooking programme has been set, if the
“START/+30SEC/CONFIRM” button is not pressed within 5 minutes, the
current time will display and the setting will be cancelled.
• The buzzer will sound five times to remind you when cooking is finished.
Defrosting tips
Microwaves penetrate around 4cm into most food. To maximize defrosting
effectiveness follow the below guidelines.
1. For thick foods, turn regularly during operation in order to defrost evenly.
2. If food weighs over 500g, it is advised to turn at least 2 times.
3. Defrosted food should be consumed as soon as possible, it is not
advisable to put back into the fridge or freeze again.
Cooking tips - The following may affect cooking results:
Food arrangement
If possible, thicker bits of food should be placed around the outside of the
dish and the thinner parts toward the centre, spread out as evenly as
possible. Do not overlap food if possible as this could result in uneven
cooking results.
Cooking length
If you are unsure of the cooking time it is advisable to start with a short
cooking time and monitor cooking progress before adding further time.
Overcooking could lead to a risk of fire. Ensure food is cooked thoroughly
before consuming.
Cooking food evenly
Foods such as meat should be turned frequently to ensure more even
cooking results. If the food is liquid based, stir during the cooking time is
advisable.
Allow standing time
When the microwave has stopped cooking, leave the food to rest for an
adequate length of time to allow for cooking completion and cooling.
32
COOKING TIPS
33
CLEANING THE MICROWAVE
• Before you clean the oven, turn it off and unplug it.
• Keep the inside of the oven clean. When food or liquids stick to the
oven walls, wipe with a damp cloth. We recommend that you do not
use harsh detergents or abrasives.
• On the right hand side wall of the cavity is the wave guide cover,
microwaves are passed through this to enable your food to cook. It is
important that this wave guide cover is kept clean at all times. To do
this wipe with mild detergent and water, then dry.
• You should clean the outside of the oven with a damp cloth. Do not
allow water to seep into the ventilation openings.
• Do not allow the control panel to become wet. Clean with a soft,
damp cloth. Do not use detergents, abrasives or spray-on cleaners
on the control panel.
• If steam builds up inside or around the outside of the oven door,
wipe with a soft cloth. This may happen when the microwave oven is
used in humid conditions.
• Regularly remove the glass turntable to clean it, and wash it in warm
soapy water. Regularly clean the turntable support and oven floor.
Simply wipe the bottom surface of the oven with mild detergent and
water, then dry. You can wash the turntable support in mild soapy
water.
• When removing the turntable support of the oven, make sure you
put it back properly.
• If the inside of the oven smells, put a cup of water with the juice and
skin of one lemon in a deep microwave bowl. Microwave it for three
minutes, wipe thoroughly and then dry with a soft cloth.
Problem Potential reason
Potential solution
If the
microwave
doesn’t work
1. Microwave is not
plugged in
Make sure
that the plug is plugged in securely into
the
mains and the
switch is on
. If it is not, remove the plug
from the socket, wait 10 seconds and plug it in again
securely.
2. Plug is not working
The plug socket that the microwave is plugged into may
have become faulty. Plug the microwave into another
known good plug socket, ensure that the socket is
turned on and check if the microwave now works.
3
.
The plug has a blown
fuse or the mains circuit
has a blown fuse/tripped
fuse
Check the plug for a blown circuit fuse or a tripped main
circuit breaker. If these seem to be working properly,
test the socket with another appliance.
4. Microwave has
developed a fault
Contact customer services to talk through the problem
to see if any
solutions
for the fault can be found. If not
and the product is
within its warranty period, then
the
microwave should be returned to the retailer where
it
was purchased from for a replacement or refund.
If the
microwave
power will not
work
1. Door is not closed
Make sure the door is securely closed. Otherwise, the
microwave will not engage or operate.
2. The timer dial has not
been turned.
Start the microwave by turning the dial and pressing the
start button.
Not heating
Magnetron not working
The component that produces the microwaves is called
a magnetron, if food is not being heated or is 'luke'
warm then it is likely this component has developed a
fault.
If the microwave is within its
warranty period, please
contact customer services for further advice or take the
microwave back to the
retailer where it was
purchased
from for a refund or replacement.
34
PROBLEM SOLVING
The microwave oven may cause interference to your radio, TV or similar
equipment. If this happens, you can stop the interference by moving the
radio, TV or equipment as far away from your microwave oven as possible.
WARNING: To reduce the risk of personal injury, always
unplug the microwave before performing maintenance
or trouble shooting checks.
35
PROBLEM SOLVING
Problem Potential reason Potential solution
Sparking
1. Burnt on food
debris
Spillages or splashes can burn and catch fire, all food that is
put into the microwave should be appropriately covered. All
spillages or splashes must be cleaned, and all areas of
microwave cleaned after each use.
Burnt on food debris in the microwave, on the wave guide
and the behind the
wave guide
can cause the microwave to
'spark'. This is because burnt on debris can be focused on by
the microwaves and spark.
Microwaves must be cleaned thoroughly after
every use to
ensure no food is burnt on to any part of the microwave.
If the microwave does 'spark' the wave guide must be
disposed, the microwave must be cleaned thoroughly and
then contact customer services for a replacement wave
guide.
The replacement wave guide should be fitted and the
microwave should operate normally. However, if the
microwave 'sparks' again on first use (after the waveguide has
been replaced and the microwave been cleaned,) please
contact customer services for further advice.
2. Metal or foil
No metal or foil should be put inside a microwave as it can
cause 'sparking' which can damage the microwave.
The only metal accessories that should be used inside the
microwave are the ones supplied by the manufacturer.
3. Pressure build up in
food
Food with none porous skins (potatoes for example), must be
pierced to allow steam to escape. As the
buildup
of pressure
can cause food to burst and create a 'fire hazard‘.
Heat spots
Operated empty or
with no moisture
Microwaves cannot be run
empty. Microwaves
need moisture
to operate correctly.
If microwaves are operated empty or
used
to heat up plates
(this
is not
permitted), the microwaves can focus on a single
point inside the microwave. This can cause a heat spot, which
can cause the area to become deformed, warped or start to
melt.
If microwaves are operated empty or to heat up foreign
objects, this will void the warranty.
36
PROBLEM SOLVING
Problem Potential reason
Potential solution
Condensation
or excess
water
1. Food that is being
cooked
By the very nature of how a microwave works, it ‘excites’ the
water molecules in the food it is heating, causing them to
move about and generate heat from within the food. Often
when the food heats up it reaches the point where steam is
released. Dependant on the food type being heated (and its
water content level), the length of time being heated for –
and so the amount of steam generated
–
it is inevitable that
some of the steam will condense and form back into water
droplets within the microwave cavity. This can usually be
found on the inner walls or most commonly on the back of
the glass door. If not cleaned up, these droplets can start to
form small ‘pools’ of water.
2. Cooling vents covered
Cooling vents allow the heat and steam to escape from the
microwave. These cannot be covered as it can cause
excessive water to settle inside the microwave or the
microwave to overheat.
The
installation instructions
in the instruction manual must be
followed or the warranty will be void.
Paint damage/
peeling
Maintenance
If the microwave is within
its
warranty period, please contact
customer services for further advice or take the microwave
back to the retailer
where it was purchased
from for a refund
or replacement
Light not
working
Bulb not working
Due to the construction of microwaves and certain
'dangerous' components inside, the light bulb can only be
changed by a qualified service engineer.
If the microwave is within
its
warranty period, please contact
customer services for further advice or take the microwave
back to the
retailer where it was purchased
from for a refund
or replacement
Over heating
Cooling vents covered
Cooling vents allow the heat and steam to escape from the
microwave. These cannot be covered as it can cause
excessive water to settle inside the microwave or the
microwave to overheat.
The
installation instructions in the
manual must be followed
or the warranty will be void.
Too noisy
1. Glass turntable fitted
incorrectly
Check
if
the glass turntable has been placed correctly on the
turntable and is not hitting the walls/doors of the microwave
during operation.
2. Dishes/plate are too
large for the microwave
Check if the dishes/plates are the correct size for the
microwave and that are not hitting the walls/door of
microwave during operation.
37
PROBLEM SOLVING
Problem Potential reason
Potential solution
Door not
shutting/
locking
1. Glass turntable fitted
incorrectly
Check
if
the glass turntable has been placed correctly on the
turntable and is not stopping the door from shutting
correctly.
2. Latches have become
deformed
If the microwave is within its warranty period, please
contact customer services for further advice or take the
microwave back to the retailer
where it was purchased
from
for a refund or replacement.
Turntable not
rotating
1. Turntable coupling
not fitted or tape not
removed
Check if the turntable coupling is fitted correctly
and the
transportation tape has been removed.
2. Turntable roller ring
not fitted or fitted
incorrectly
Check
if the coupling has
be placed under the turntable and
that it is positioned correctly.
3. Glass turntable fitted
incorrectly
Check
if
the glass turntable has been placed correctly on the
turntable.
4. Turntable has
developed a fault
If the microwave is within its warranty period, please
contact customer services for further advice or take the
microwave back to the
retailer where it was purchased
from
for a refund or replacement.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
38
GUARANTEE & CUSTOMER SERVICES
At Russell Hobbs, we take all our customer feedback seriously.
Feel free to contact our Product Care Team, on 0345 209 7461
Monday – Friday: 8am-8pm & Saturday: 9am – 1pm,
who will be more than happy to assist you.
This product is guaranteed for 12 months from the date of the
original purchase. If any defect arises due to faulty materials or
workmanship, the faulty product must be returned to the place of
purchase.
Refund or replacement is at the discretion of the retailer.
The following conditions apply:
• The product must be returned to the retailer with the original
proof of purchase.
• The product must be installed and used in accordance with the
instructions contained in this instruction guide and any other
instructions for use which are supplied.
• It must be used for domestic purposes only and for its intended
use.
• This warranty does not cover wear and tear, damage, misuse
or consumable parts.
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
39
SPARE PARTS
For Customer Services & Spare Parts please call 0345 209 7461
Opening times: Monday - Friday 8am – 8pm & Saturday 9am – 1pm
Or visit us at www.productcare.co.uk
To check the availability of the following spare parts, simply contact
our friendly Customer Services team using the details provided at the
bottom of this page.
Glass turntable
Turntable Ring
Wave Guide cover
Turntable coupling
Grill rack
Baking tray
40
CONNECTION TO THE MAINS SUPPLY
WARNING- THIS APPLIANCE MUST BE EARTHED
This appliance is designed to operate from a mains supply of
220-240V~ 50Hz.
Check that the voltage marked on the product corresponds
with your supply voltage.
This product is fitted with a 13A plug complying with BS1363.
If this plug is unsuitable or needs to be replaced, refer to customer
services.
Important: The wires in the mains lead are coloured in
accordance with the following code:
GREEN/YELLOW – EARTH
BLUE - NEUTRAL
BROWN – LIVE
41
CONNECTION TO THE MAINS SUPPLY
For UK use only – PLUG
• As the colours of the wires in the mains lead of this appliance may
not correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
• The GREEN/YELLOW wire is the EARTH and must be connected to
the terminal which is marked with the letter E or by the earth
symbol or coloured GREEN or GREEN/YELLOW.
• The BLUE wire is the NEUTRAL and must be connected to the
terminal marked with the letter N or coloured BLACK.
• The BROWN wire is the LIVE wire and must be connected to the
terminal marked with the letter L or coloured RED.
• Always ensure that the plug cord grip is fastened correctly.
• If a 13A (BS1363) fused plug is used it must be fitted with a 13amp
fuse conforming to BS1362 and be BSI or ASTA approved.
If the fuse cover is lost the plug must not be used until a replacement
is obtained from an electrical supplier.
If you need to remove the plug, cut it from the mains lead and
dispose of it. NEVER attempt to re-use this plug or insert it into a
socket outlet, as there is a very great risk of electrical shock.
42
NOTES
43
NOTES
44
Revision 3
This symbol is known as the 'Crossed-out wheelie bin Symbol'. When this symbol is
marked on a product/batteries, it means that the product/batteries should not be
disposed of with your general household waste. Only discard
electrical/electronic/battery items in separate collection schemes, which cater for the
recovery and recycling of materials contained within. Your co-operation is vital to ensure
the success of these schemes and for the protection of the environment. For your
nearest disposal facility, visit www.recycle-more.co.uk or ask in store for details.
We reserve the right, due to possible changes to design, to alter the instruction manual
without prior notice.
For Customer Services & Spare
Parts please call
0345 209 7461
Opening times: Monday - Friday
8am – 8pm & Saturday 9am –1pm
Or visit us at
www.productcare.co.uk
